Endothelial thrombomodulin induces Ca2+ signals and nitric oxide synthesis through epidermal growth factor
receptor kinase and calmodulin kinase II.
Monique David-Dufilho, Elisabeth Millanvoye-van Brussel, Gokce Topal, Laurence Walch, Annie Brunet, Francine Rendu
To cite this version:
Monique David-Dufilho, Elisabeth Millanvoye-van Brussel, Gokce Topal, Laurence Walch, Annie Brunet, et al.. Endothelial thrombomodulin induces Ca2+ signals and nitric oxide synthesis through epidermal growth factor receptor kinase and calmodulin kinase II.. Journal of Biological Chem- istry, American Society for Biochemistry and Molecular Biology, 2005, 280 (43), pp.35999-6006.
�10.1074/jbc.M506374200�. �hal-00123726�
Endothelial Thrombomodulin Induces Ca 2 ⴙ Signals and Nitric Oxide Synthesis through Epidermal Growth Factor Receptor Kinase and Calmodulin Kinase II *
Received for publication, June 10, 2005, and in revised form, August 2, 2005 Published, JBC Papers in Press, August 26, 2005, DOI 10.1074/jbc.M506374200
Monique David-Dufilho1, Elisabeth Millanvoye-Van Brussel2, Gokce Topal3, Laurence Walch, Annie Brunet, and Francine Rendu2
From the Department of Signalisation Cellulaire et Atherosclerose Precoce, Universite Paris 6-CNRS, Paris 75014, France
Endothelial membrane-bound thrombomodulin is a high affinity receptor for thrombin to inhibit coagulation. We previously dem- onstrated that the thrombin-thrombomodulin complex restrains cell proliferation mediated through protease-activated receptor (PAR)-1. We have now tested the hypothesis that thrombomodulin transduces a signal to activate the endothelial nitric-oxide synthase (NOS3) and to modulate G protein-coupled receptor signaling. Cul- tured human umbilical vein endothelial cells were stimulated with thrombin or a mutant of thrombin that binds to thrombomodulin and has no catalytic activity on PAR-1. Thrombin and its mutant dose dependently activated NO release at cell surface. Pretreatment with anti-thrombomodulin antibody suppressed NO response to the mutant and to low thrombin concentration and reduced by half response to high concentration. Thrombin receptor-activating pep- tide that only activates PAR-1 and high thrombin concentration induced marked biphasic Ca2ⴙsignals with rapid phosphorylation of PLC3and NOS3 at both serine 1177 and threonine 495. The mutant thrombin evoked a Ca2ⴙspark and progressive phosphoryl- ation of Src family kinases at tyrosine 416 and NOS3 only at threo- nine 495. It activated rapid phosphatidylinositol-3 kinase-depend- ent NO synthesis and phosphorylation of epidermal growth factor receptor and calmodulin kinase II. Complete epidermal growth fac- tor receptor inhibition only partly reduced the activation of phos- pholipase C␥1and NOS3. Prestimulation of thrombomodulin did not affect NO release but reduced Ca2ⴙresponses to thrombin and histamine, suggesting cross-talks between thrombomodulin and G protein-coupled receptors. This is the first demonstration of an out- side-in signal mediated by the cell surface thrombomodulin recep- tor to activate NOS3 through tyrosine kinase-dependent pathway.
This signaling may contribute to thrombomodulin function in thrombosis, inflammation, and atherosclerosis.
Thrombomodulin (TM)4is a transmembrane glycoprotein synthe- sized by endothelial cells and a membrane receptor for thrombin. It consists of an amino-terminal domain homologous to C-type lectins, six
tandemly repeated epidermal growth factor (EGF)-like domains, a Ser/
Thr-rich sequence, a transmembrane domain, and a short cytoplasmic tail (1, 2). Thrombin binds to the EGF-like domains 5 and 6 of TM to form a high affinity complex (3). The latter is essential for hemostasis regulation by accelerating the activation of protein C, a physiological inhibitor of coagulation (2), and TAFI (thrombin-activable fibrinolysis inhibitor), an endogenous inhibitor of fibrinolysis (4).
Thrombin also plays a key role in vessel wound healing and revascu- larization. It induces multiple phenotypic changes of blood and vascular cells to affect vascular tone, cell permeability and growth, and leukocyte trafficking (5). Thrombin mediates cellular events by signal transduc- tion through protease-activated receptors (PARs) (6). It activates PAR-1 by cleavage of its N terminus extremity, thereby unmasking the tethered ligand SFLLRN that flips over to activate the receptor. We have previ- ously shown that the thrombin-TM complex restrains endothelial cell proliferation activated by the synthetic peptide SFLLRN, so-called thrombin receptor-activating peptide (TRAP) (7). The binding of thrombin to endothelial TM indeed decreased the DNA synthesis by prolonging the phosphorylation and the nuclear retention of extracel- lular signal-regulated kinases 1 and 2 (ERK1/2) (8).
Phosphorylation of ERK1/2 is dependent on nitric oxide (NO) gen- erated by NO synthase (NOS) (9). Through ERK1/2 phosphorylation, NO mediates either proliferative or anti-proliferative responses (10 – 12). As a messenger, NO is also involved in vascular endothelial growth factor-mediated angiogenesis (13, 14). It was recently reported that a human recombinant TM containing the six EGF-like domains and the Ser/Thr-rich sequence induces angiogenesis through activation of the endothelial NOS (NOS3) and ERK1/2, as do growth factors (15). We previously demonstrated that thrombin activates NOS3 in human umbilical vein endothelial cells (HUVECs) (16). The purpose of the present study was to investigate whether thrombin binding to endothe- lial membrane-bound TM induced signaling events to activate NOS3 and modulate G protein-coupled receptor (GPCR) signals. Our tool was a mutant of thrombin that binds to TM but has no catalytic activity on PAR-1. We report that endothelial TM mediates Ca2⫹spark and NO synthesis through the EGF receptor (EGFR) kinase and calmodulin kinase II (CaMKII).
MATERIALS AND METHODS
Reagents and Antibodies—Primers, TRIzol®, and culture medium were purchased from Invitrogen. Fura-2 acetoxymethyl ester (fura-2 AM) and Alexa 488-conjugated anti-mouse IgG antibody were obtained from Molecular Probes (Eugene, OR). TRAP was purchased from Bachem. The thrombin mutant S195A, which has no catalytic activity but binds to TM, was provided by Dr. B. Le Bonniec (INSERM Unit 428, Paris, France) (17). Human thrombin and the selective inhibitors of phosphatidylinositol-3 kinase (PI3K) (LY294002), EGFR kinase
*The costs of publication of this article were defrayed in part by the payment of page charges. This article must therefore be hereby marked “advertisement” in accordance with 18 U.S.C. Section 1734 solely to indicate this fact.
1To whom correspondence should be addressed: Unite Mixte de Recherche, 7131 CNRS- Universite Paris 6, 102 Rue Didot, Paris 75014, France. Tel.: 33-1-43-95-92-97; Fax:
33-1-43-95-93-27; E-mail: monique.dufilho@brs.aphp.fr.
2Supported by INSERM.
3Supported by the International Society of Thrombosis and Hemostasis.
4The abbreviations used are: TM, thrombomodulin; EGF, epidermal growth factor; EGFR, EGF receptor; PAR, protease-activated receptor; TRAP, thrombin receptor-activating peptide; ERK, extracellular signal-regulated kinase; NO, nitric oxide; NOS, NO syn- thase; HUVEC, human umbilical vein endothelial cell; GPCR, G protein-coupled recep- tor; CaMKII, calmodulin kinase II; PKC, protein kinase C; PLC, phospholipase C.
(AG1478), Src family kinases (PP2), protein kinase C (PKC␣,: Go6976 and PKC␦: rottlerin) and CaMKII (KN62) were from Calbiochem. The mouse monoclonal antibody against the EGF5– 6region of TM was from American Diagnostica Inc. (Greenwich, CT). The rabbit polyclonal antibodies against phosphor-Thr495-eNOS, phospho-Tyr416-Src, phos- pholipase C3 (PLC3), phospho-Ser537-PLC3, phospho-Tyr1068- EGFR, EGFR, and PLC␥1, the mouse monoclonal antibody against Src and the anti-rabbit IgG antibody linked to horseradish peroxidase were from Cell Signaling Inc. (Beverly, MA). The rabbit polyclonal antibody against phospho-Tyr783-PLC␥1 was from BIOSOURCE (Camarillo, CA). The mouse monoclonal antibodies against phospho-Ser1177-eNOS and eNOS were from BD Biosciences. The rabbit polyclonal antibodies against phospho-Thr286-CaMKII␣and CaMKII and horseradish perox- idase-linked anti-mouse IgG antibody were from Santa Cruz Biotech- nology (Santa Cruz, CA).
Cell Culture—Endothelial cells were isolated from segments of human umbilical cord vein and cultured as previously described (18). At confluence, HUVECs were detached with trypsin/versene (Invitrogen), washed, and grown for 3– 4 days. At subconfluence, cells were serum starved (0.5% (v/v) fetal calf serum) for 18 h. Cells were incubated in phosphate buffer, pH 7.4, containing 5 mMglucose, 0.5 mMMgCl2, and 1 mMCaCl2(PBS-MgCa), except for Ca2⫹measurements for which a specific reaction buffer was used (in mM: NaCl 136, KCl 5, Na2PO42, MgSO40.4, NaHCO34, CaCl21, glucose 8, glutamine 2, a mixture of amino acids, and HEPES 25, pH 7.4).
RT-PCR—Total RNA was extracted from HUVECs grown on 60-mm plastic dishes using the TRIzol®reagent according to the manufacturer’s instructions. The cDNA was synthesized from 1g of total RNA by incubation for 15 min at 42 °C with 2.5 units/l murine leukemia virus reverse transcriptase (PE Applied Biosystems) in 20l of PCR buffer II containing 5 mMMgCl2, 1 mMof deoxy-NTP, 1 unit/l ribonuclease inhibitor, and 2.5 mMrandom hexamers. PCR was performed by using 3
l of cDNA and the following primers: eNOS sense primer, 5⬘-GAA- GAGGAAGGAGTCCAGTAACACAGC-3⬘; eNOS antisense primer, 5⬘-GGACTTGCTGCTTTGCAGGTTTTC-3⬘(438-bp product). The PCR reaction mixture (25l) contained 2 mMMgCl2, PCR buffer II, AmpliTaq DNA polymerase (PE Applied Biosystems) at 25 milliunits/
l, and each primer at 0.2M. Amplification was performed in a pro- grammable thermal controller (model PTC-100; MJ Research Inc.).
Sample denaturation at 95 °C for 2 min was followed by 35 PCR cycles of 30 s at 95 °C, 30 s at 60 °C, and 90 s at 72 °C and a further incubation of 7 min at 72 °C after the last cycle. Each sample (5l) was electrophore- sed on polyacrylamide gels (4 –20% Tris/boric acid/EDTA) and stained for 15 min with ethidium bromide (2.5 g/ml) for densitometric analysis.
Western Blot—Proteins of cell homogenates were resolved by SDS- PAGE as previously described (19). The proteins transferred onto nitro- cellulose membranes were incubated overnight at 4 °C with primary mouse- or rabbit-specific antibody (1:1000 dilution), rinsed, and further incubated at room temperature for 90 min with 1:2000 dilution of horseradish peroxidase-linked anti-mouse or anti-rabbit IgG secondary antibody, respectively. Membranes were reprobed with antibodies against unphosphorylated proteins.
Measurements of Nitric Oxide—The NO released at the surface of cells grown on 35-mm plastic culture dishes was measured by differen- tial pulse amperometry at a porphyrinic NO-selective microsensor as previously described (20). The NO sensor was calibrated by the addition of NO standard solutions. Treatment of HUVECs with kinase inhibitors did not change the NO calibration curves. Results were expressed as the maximum of the agonist-induced oxidation current.
Cytosolic [Ca2⫹] Measurement—HUVECs seeded onto glass cover- slips were loaded with 2Mfura-2AM as previously described (21). Cell fluorescence intensities were recorded alternately at 340 and 380 nm with an emission wavelength of 505 nm using a spectrofluorimeter SPEX CMIII (ISA-Jobin-Yvon, Longjumeau, France), and [Ca2⫹]iwas calculated as previously detailed (21).
Statistical Analysis—Results are expressed as means⫾S.E. ofninde- pendent cultures. Multiple comparisons and time-dependent effects were examined by one-way analysis of variance withpost hocFisher’s test. Comparison of time-dependent effects between two groups was assessed by two-way analysis of variance. Comparisons between two groups were analyzed by paired Student’sttest.
RESULTS
The amplitude of NO release at cell surface rose with increasing concentrations of both thrombin and the mutant thrombin S195A (Fig.
1,AandB). Thrombin activated NO synthesis with an EC50of 0.2 (0.1– 0.5) nMand S195A with an EC50of 20 (7–70) nM. Noteworthy, the dose-response curve for thrombin was biphasic with a first plateau between 0.5 and 2 nMand a second one at 20 nM, suggesting that the two receptors TM and PAR-1 are involved in NOS3 activation (Fig. 1A). In contrast, the dose-response curve for the mutant thrombin was charac- terized by only one plateau of saturation between 200 nMand 1M(Fig.
1B). Cell pretreatment with an anti-TM antibody totally suppressed the NO release induced by 200 nM S195A and 0.5 nM thrombin but decreased by only 50% that activated by saturating concentration of thrombin (Fig. 1C). The results demonstrate the stimulation of NO synthesis by thrombin binding to TM at concentrations below the nanomolar range and to PAR-1 at upper concentrations.
To investigate the transduction pathway of TM and its role in the regulation of PAR-1 signaling, we used the maximal concentrations of 200 nMfor S195A and 20 nMfor thrombin. Because agonist-activated NO synthesis is dependent on Ca2⫹(18), we first examined intracellular
FIGURE 1.Activation of NO release by thrombin and mutant thrombin S195A.Aand B, dose-dependent effect of thrombin and S195A. Serum-starved HUVECs were stimu- lated by thrombin at concentrations ranging from 0.1 to 20 nM(A) or by S195A from 1 nM
to 1M(B).C, effect of anti-EGF5– 6-TM antibody on thrombin- and S195A-activated NO release. Cells were treated for 30 min with (filled column) or without (open column) anti-TM antibody (530 nM) and were then stimulated by either 0.5 or 20 nMthrombin or by 200 nMS195A. Results are means⫾S.E. of five (AandB) and three (C) independent experiments. *,p⬍0.05; **,p⬍0.001versusthe lowest concentration of thrombin or S195A.⫹,p⬍0.05versusuntreated cells.
Signaling Pathway of Endothelial Thrombomodulin
Ca2⫹signaling. Both NO synthesis and Ca2⫹signals activated by the mutant thrombin S195A, thrombin, or the PAR-1-activating peptide TRAP were maximal at 15–30 s and rapidly decreased thereafter (Fig. 2).
The maximum NO production was 21⫾2 nMafter stimulation by S195A, 19⫾2 nMafter thrombin, and 17⫾2 nMafter 100MTRAP, a concentration that induced maximal Ca2⫹signals in HUVECs (22). The Ca2⫹signals evoked by the three agonists were, however, of different amplitudes (Fig. 2B). After addition of S195A the peak value (57⫾14 nM) was followed by a decrease back to initial value. After thrombin and TRAP, the peak was of much higher amplitude (254⫾46 and 281⫾49 nM, respectively) and followed by a plateau well above initial value (50⫾ 11 and 61⫾8 nM, respectively). Cell treatment with the anti-TM anti- body had no effect on the Ca2⫹response to 20 nMthrombin (250⫾60 and 38⫾14 nMfor peak and plateau, respectively). This indicates that thrombin-induced Ca2⫹signal is mainly caused by PAR-1 stimulation.
Because PAR-1-mediated Ca2⫹signal results from PLCactivation (6), we examined the phosphorylation of an upstream (PLC) and a downstream (NOS3) Ca2⫹signal-related enzyme. Thrombin induced a rapid and sustained phosphorylation of Ser537-PLC3(Fig. 3A). In con- trast, the mutant thrombin S195A did not activate the PLC3. As shown
by the dose-response curve for thrombin (Fig. 3B), Ser537-PLC3phos- phorylation was detectable with 2 nMbut was significant only at 20 nM. This suggests that another PLC isoform is responsible for Ca2⫹-depend- ent activation of NOS3 by S195A and low thrombin concentrations. It has been reported that high thrombin concentration activates Ca2⫹-de- pendent phosphorylation of Ser1177-NOS3 (23). In the present study, 20 nMthrombin induced a transient Ser1177-NOS3 phosphorylation with a maximum at 1 min followed by a return toward basal levels within 20 min (Fig. 4). The time courses obtained here for Ser1177-NOS3 phos- phorylation and also for NO release (Fig. 2A),i.e.in serum-starved HUVECs, were similar to those we previously observed in cells cultured with 20% serum (16). During the first 5 min, the Ser1177-NOS3 phos- phorylation activated by TRAP was similar to that induced by thrombin (Fig. 4). At 20 min, however, Ser1177-NOS3 remained phosphorylated in TRAP-treated cells. No phosphorylation of Ser1177-NOS3 occurred fol- lowing S195A stimulation. The results suggest that the amplitude of TM-induced Ca2⫹spark was too low to activate the kinase responsible for phosphorylation of Ser1177and demonstrate that this residue is not involved in TM-mediated NOS3 activation.
In contrast to that of Ser1177, NOS3 phosphorylation at the Thr495 residue depended on serum concentration in culture medium (Fig. 5,A andB). Reducing the serum level from 20 to 0.5% decreased the phos- phorylation ratio of unstimulated cells from 0.74⫾0.02 (Fig. 5A) to 0.03⫾0.01 (p⬍0.001) (Fig. 5B). In the presence of serum, thrombin induced Thr495-NOS3 phosphorylation at 2 min (Fig. 5A), whereas in serum-starved cells, Thr495-NOS3 phosphorylation started at 1 min (Fig. 5). Under the latter conditions, all three agonists,i.e.thrombin, the mutant thrombin S195A, and TRAP, progressively increased Thr495- NOS3 phosphorylation up to a plateau reached at 5 min (Fig. 5C). From 1 to 20 min, the intensities of phosphorylation were, however, lower in S195A-stimulated HUVECs than in TRAP-activated cells (p⬍0.001) and intermediate in thrombin-stimulated ones (Fig. 5C). The results show that factors present in serum regulate Thr495-NOS3 phosphoryl- ation and that TM mediates NOS3 phosphorylation at this residue.
Both PKC and PI3K are involved in NOS3 activation by growth fac- tors (24). To analyze the role of these two kinases in NOS3 activation mediated by TM, we studied the effects of the PKC␦and PI3K inhibi-
FIGURE 2.Time courses of NO synthesis and Ca2ⴙsignals activated by S195A, thrombin, and TRAP.A, representative time course of NO release at cell surface.B, representative time course of cytosolic Ca2⫹movements in fura-2-loaded cells. Serum- starved HUVECs were stimulated by either 200 nMS195A (A,n⫽17;B,n⫽5) or 20 nM
thrombin (A,n⫽20;B,n⫽9) or 100MTRAP (A,n⫽11;B,n⫽6) as indicated by the arrows.
FIGURE 3.Phosphorylation of Ser537-PLC3by thrombin and S195A.A, time course of PLC3 phosphorylation at serine537. Serum-starved HUVECs were stimulated with 20 nMthrombin (●) or 200 nMS195A (Œ).B, dose-dependent effect of thrombin. Cells were stimulated by thrombin at concentrations ranging from 0.1 to 20 nM. Western blot analysis of total and phosphorylated proteins was performed using specific antibodies. Left panelshows representative blots of cell lysates andright panelthe densitometric analysis of three independent experiments where data deter- mined in unstimulated cells have been subtracted.
*,p⬍0.05; **,p⬍0.01; ***,p⬍0.001versuscon- trol (0).
tors, rottlerin and LY 294002, respectively. The two inhibitors reduced TRAP-activated NO release, but they had opposite effects in thrombin- and S195A-stimulated cells (Fig. 6). Thrombin-activated NO release was not affected by LY 294002 but was markedly reduced by rottlerin. In contrast, S195A-induced NO synthesis was not altered by rottlerin but was abolished by LY 294002, indicating that TM-mediated NOS3 acti- vation depended on PI3K. The activities of PI3K and Src family kinases are tightly linked in endothelial cells (25). We thus analyzed the partic- ipation of Src kinases in TM-induced NO synthesis. Although the Src inhibitor PP2 (100 nM) had no effect on S195A-activated NO release detected at 20 –30 s (20⫾4versus18⫾3 nMin untreated cells,n⫽5), Src was progressively phosphorylated at Tyr416by S195A (Fig. 7). Phos-
phorylation of Tyr416-Src was maximal at 5 min and remained stable over 20 min. Following thrombin, a phosphorylation peak appeared at 1 min and was followed by a decrease back to a plateau of similar intensity as that evoked by S195A. As Src family kinases are upstream activators of ERK1/2 (26, 27), we examined whether S195A activated this cascade.
Thrombin rapidly increased ERK1/2 phosphorylation (281⫾82% at 5 min,n⫽4,p⬍0.05), whereas S195A did not (19⫾28%,n⫽5). The results demonstrate that TM signaling involves PI3K-dependent NOS3 activation and Src phosphorylation.
Because thrombin binds to the EGF-like domains of TM (2) and Src participates in receptor tyrosine kinase signaling (26), we investigated whether the EGFR kinase and its downstream effectors PLC␥ and
FIGURE 4.Phosphorylation of Ser1177-NOS3 by S195A, thrombin, or TRAP.Time course of NOS3 phosphorylation at serine1177. Serum-starved HUVECs were stimulated with 20 nMthrombin, 200 nMS195A, or 100MTRAP. Western blot analysis of total and phosphorylated proteins was performed using specific antibodies.Left panelshows repre- sentative blots of cell lysates andright panelthe densitometric analysis of six independent experi- ments. Data are given after subtraction of corre- sponding values determined in unstimulated cells. *,p⬍0.05; **,p⬍0.01; ***,p⬍0.001versus control (0).
FIGURE 5.Influence of serum on thrombin-acti- vated Thr495-NOS3 phosphorylation and effect of S195A and TRAP. A, thrombin-activated Thr495-NOS3 phosphorylation in HUVECs cultured with 20% (v/v) serum. B, thrombin-activated Thr495-NOS3 phosphorylation in serum-starved cells.C, serum-starved HUVECs were stimulated with 20 nMthrombin, 200 nMS195A, or 100M TRAP. Western blot analysis of total and phospho- rylated proteins was performed using specific antibodies. Representative blots of cell lysates and densitometric analysis were from four (A) and six (B,C) independent experiments. Data are given as the ratio of phospho-NOS3 to total one (A,B) or after subtraction of corresponding values deter- mined in unstimulated cells (C).⫹,p⬍0.05versus values from control (0). *,p⬍0.05versusvalues from S195A-activated cells.
Signaling Pathway of Endothelial Thrombomodulin
CaMKII contributed to the TM transduction pathway. As shown in Fig.
8A, significant phosphorylation of Tyr1068-EGFR, Tyr783-PLC␥1, and Thr286-CaMKII␣ occurred in HUVECs stimulated for 30 s by the mutant thrombin S195A. The EGFR kinase inhibitor AG1478 reduced EGFR and PLC␥1 phosphorylation but had no effect on Thr286- CaMKII␣autophosphorylation (Fig. 8A). Interestingly, the S195A-acti- vated NO release was inhibited by AG1478 and by KN62, a CaMKII inhibitor (Fig. 8B). The results demonstrate that TM induces NOS3 activation through the EGFR kinase and the CaMKII.
As shown above, thrombin activates NO synthesis through both TM and PAR-1. We previously demonstrated that TM negatively modulates PAR-1-induced activation of ERK1/2 cascade (8). In addition, the GPCR
activators thrombin and histamine inhibit the EGF-mediated activation of PI3K/Akt cascade (28). To examine whether a cross-talk between TM and GPCR exists, we measured NO and Ca2⫹responses to thrombin or to histamine after a previous stimulation with the mutant thrombin S195A, thrombin, or TRAP. When cells were prestimulated by S195A, the NO response to thrombin or histamine was not altered (Fig. 9A), indicating that TM signaling does not modulate NOS3 activation by GPCR activators. When cells were prestimulated by thrombin or the PAR-1 agonist TRAP, thrombin-activated NO synthesis was reduced (Fig. 9A,left panel) but that induced by histamine was not (right panel), indicating that PAR-1 signal down-regulates TM-mediated NOS3 activation.
Concerning Ca2⫹ signals, the thrombin-induced Ca2⫹ peak was reduced following prestimulation by thrombin but not following pre- stimulation by S195A or TRAP (Fig. 9B,left panel). Interestingly, both Ca2⫹peak and plateau evoked by histamine were decreased irrespective of the agonist used to engage TM,i.e.thrombin or S195A (right panel).
The results demonstrate that TM mediates a signal able to modulate GPCR-induced Ca2⫹signal.
Angiogenic factors such as vascular endothelial or platelet-derived growth factors, but not EGF, have been shown to increase NOS3 expres- sion (29, 30). We thus examined whether TM activated NOS3 tran- scription. As demonstrated by RT-PCR, the expression of NOS3 mRNA remained unchanged by treatment for 4 –18 h with thrombin or S195A (not shown). Similarly, the protein levels did not significantly vary in HUVECS treated for 18 h with thrombin or S195A (116⫾19 or 124⫾ 22% of control, respectively), suggesting that TM-mediated EGFR sig- naling does not modulate NOS3 expression.
DISCUSSION
We previously demonstrated that the high affinity thrombin-throm- bomodulin complex restrains PAR-1-induced activation of ERK1/2 cas- cade (8). We have now shown that thrombin binding to the membrane- bound TM activated NO synthesis through the EGFR kinase and the CaMKII in human endothelial cells. Our results demonstrate for the
FIGURE 6.Role of PI3K and PKC␦TM-activated NO synthesis.Cells were pretreated either for 30 min in culture medium containing 0.5% (v/v) fetal calf serum without (⫺) or with (⫹) 2MLY294002 or for 10 min in PBS-MgCa without (⫺) or with (⫹) 5Mrottlerin.
After treatment, NO release was activated by addition of 20 nMthrombin, 200 nMS195A, or 100MTRAP. Data are from three to four independent experiments. *,p⬍0.05; **, p⬍0.01versuscontrol (⫺).
FIGURE 7.Phosphorylation of Tyr416-Src by S195A and thrombin.Time course of Src phosphorylation at tyrosine 416. Serum-starved HUVECs were stimulated with 20 nM
thrombin or 200 nMS195A. Western blot analysis of total and phosphorylated proteins was performed using specific antibodies.Upper panelshows representative blots of cell lysates andlower paneldensitometric analysis of six independent experiments. Data are given after subtraction of corresponding values determined in unstimulated cells. *, p⬍0.05; **,p⬍0.01versuscontrol (0).
FIGURE 8.Participation of EGFR kinase, PLC␥, and CaMKII in TM signaling.A, effects of AG1478 on Tyr1068-EGFR kinase, Tyr783-PLC␥1, and Thr286-CaMKII␣phosphorylation in serum-starved cells stimulated for 30 s with 200 nMS195A in PBS-MgCa (n⫽6).B, effect of AG1478 and KN62 on S195A-activated NO release (n⫽3– 4). Serum-starved HUVECs were pretreated for 30 min in culture medium containing 0.5% fetal calf serum without (Control) or with 100 nMAG1478 or 1MKN62. *,p⬍0.05versuscontrol.
first time that the endothelial TM mediates an outside-in signal to acti- vate NOS3 and modulate GPCR-induced Ca2⫹signaling.
Through its exosite I, thrombin binds to EGF-like domains 5 and 6 of its high affinity receptor TM (3) and to its low affinity receptor PAR-1 to activate its proteolysis (6). We observed a biphasic dose-response curve of NO release with detectable NO synthesis from 0.1 nMthrombin. The high affinity receptor responsible for NOS3 activation was saturated with 0.5 nMthrombin, totally inactivated by the anti-TM antibody, and independent of PLC. Phosphorylation of PLCwas detectable from 2 nMthrombin. The low affinity receptor involved in NOS3 activation was saturated with 20 nMthrombin and insensitive to anti-TM antibody. Its signaling is associated with PLCactivation and a Ca2⫹signal similar to that induced by PAR-1 agonist peptide. In HUVECs, increases in phos- phoinositide hydrolysis have been readily detected at 0.1 nMthrombin (31). At this concentration, thrombin induced a transient Ca2⫹signal of low amplitude (32) and increased by 50% the endothelial barrier perme- ability (33). The thrombin binding to TM may activate another PLC isoform to stimulate NO synthesis and endothelial barrier permeability.
The mutant thrombin S195A we used binds to TM and PAR-1, but as a result of the mutation in its active site S195A is unable to activate PAR-1. Here, we showed that the mutant thrombin induced (i) rapid phosphorylation of PLC␥1, CaMKII␣, and EGFR, Ca2⫹spark, and PI3K- dependent NO synthesis; (ii) long-lasting phosphorylation of Thr495- NOS3 and tyrosine kinases of Src family without activation of ERK1/2 cascade; and (iii) cross-talks with G protein-coupled receptors.
Through a specific transduction pathway, the transmembrane glyco- protein TM may control interactions of soluble ligands, such as throm- bin, activated protein C, and its own ectodomain, with cell surface receptors of the vascular wall. Thrombin and protein C, as well as a recombinant soluble TM containing the six EGF-like domains and the Ser/Thr-rich sequence, activate NOS3 and ERK1/2 cascade to regulate coagulation, fibrinolysis, inflammation, and cell proliferation (5, 15, 34, 35). Thrombomodulin may modulate the thrombin-activated PAR-1 signaling as described for the endothelial protein C receptor in PAR-1 activation by activated protein C (36).
In our study, the rapid EGFR and PLC␥1phosphorylation and NO synthesis generated by thrombin binding to TM was reduced by inhibi- tion of the EGFR kinase. In addition, inhibition of PI3K and CaMKII␣
activities suppressed the NO release at cell surface. In various cell types, the EGFR mediates direct activation of PI3K and phospholipase C␥, resulting in inositol 1,3,5-triphosphate (IP3) generation and Ca2⫹
release from internal stores and subsequent CaMKII activation (37).
Similarly, TM would activate a receptor tyrosine kinase analogous to that of EGFR. Hence, it would phosphorylate PI3K and phospholipase C␥and activate CaMKII through IP3-dependent Ca2⫹spark and for- mation of Ca-calmodulin complex (Fig. 10,Ca-CaM). The NOS3 is in turn activated by Ca-CaM binding and by PI3K- and CaMKII-depend- ent phosphorylation. However, we observed that the inhibition of EGFR kinase did not prevent the Tyr286autophosphorylation of CaMKII. The Ca-CaM binding alone allows maximal activity and access of CaMKII to protein substrates, including NOS3, whereas Tyr286autophosphoryla- tion converts the enzyme into a Ca-CaM-independent state (38). Here, complete EGFR inhibition did not abolish CaMKII autophosphoryla- tion or the activation of PLC␥1and NOS3. This indicates that the TM transduction pathway only partly depends on EGFR.
The soluble tyrosine kinases of Src family are involved in the signal transduction of EGFR (26, 37). Activation of TM by the mutant throm- bin induced sustained Src phosphorylation. However, NO synthesis remained unchanged in the presence of the potent Src inhibitor even at high concentration, suggesting that NO is upstream from Src. Such a proposal is supported by the comparison of NO release and Tyr416-Src phosphorylation kinetics. The TM-induced NO release was rapid and reached a maximum at 20 –30 s, whereas Src phosphorylation was max- imal between 5 and 20 min. This agrees with a NO-dependentS-ni- trosylation of Src that activates Tyr416autophosphorylation and forma- tion of disulfide-linked multimers (27). NO thus appears as a transducer of the outside-in signal mediated by TM to regulate cell proliferation through Src family kinases (26, 39).
The NOS3 activity depends on Ca2⫹ and/or phosphorylations on serines 114, 615, 633, and 1177 and threonine 495 (human amino acids) (16, 19, 40 – 42). To stimulate its catalytic activity, GPCR agonists and growth factors evoke NOS3 phosphorylation at Ser615, Ser633, and Ser1177(16, 19, 41– 43). The GPCR agonists mediate high Ca2⫹signal and rapid transient phosphorylation at Ser615and Ser1177(41, 42). In contrast, growth factors induced low Ca2⫹signal and progressive long lasting phosphorylation at Ser615and Ser1177(41, 44). In the present
FIGURE 9.NO and Ca2ⴙresponses to thrombin or histamine after TM- and PAR-1-activation.A, NO production induced by 20 nMthrombin or 100
Mhistamine.B, cytosolic Ca2⫹signals activated by thrombin or histamine. Serum-starved HUVECs were prestimulated for 15 min in PBS-CaMg with- out (⫺) or with 200 nMS195A or 20 nMthrombin or 100MTRAP, washed, and stimulated with throm- bin.Bar graphsrepresent the means⫾S.E. of four to six independent experiments. *,p⬍0.05; **, p⬍0.01versusuntreated cells.
Signaling Pathway of Endothelial Thrombomodulin
study, the TM-induced NO synthesis occurred independently of NOS3 phosphorylation at Ser1177. Binding of mutant thrombin to TM acti- vated Thr495phosphorylation with, however, a kinetic different from that of NO release. Noteworthy, we observed that factors present in serum influence the Thr495dephosphorylation/phosphorylation, sug- gesting participation of this residue in NO-regulated proliferative mechanisms. Long lasting incubation in a low serum medium (0.5%) resulted in dephosphorylation of Thr495in unstimulated cells. Such an attenuated Thr495phosphorylation was reported following PKC deple- tion in unstimulated cells (42). Growth factors present in serum may stimulate Thr495phosphorylation and basal NOS3 activity in a PKC-de- pendent manner. In our study, neither the PKC␦inhibitor rottlerin nor the PKC␣,inhibitor Go6976 (not shown) had any effect on TM-in- duced NO release. Because PKC activates Thr495phosphorylation (43), it is not unlikely that another residue than Thr495may be responsible for rapid TM-dependent NOS3 activation.
Membrane-bound TM negatively modulates cellular functions asso- ciated with thrombin-induced PAR-1 activation, such as cell prolifera- tion (7), and contractility (45). These regulatory processes may rely on cross-talks between TM and GPCRs. Both Ca2⫹and NO are cellular messengers involved in signal transduction (46, 47). Using a monoclonal antibody against the thrombin-binding domain of TM (EGF5– 6region), we demonstrated that thrombin generates Ca2⫹signal through PAR-1 and NO synthesis through both TM and PAR- 1. A first TM stimulation reduced the Ca2⫹ signal subsequently activated by GPCR agonists (thrombin, histamine), not the NO release. Calcium is one of the key regulators of cell proliferation, especially through interactions with cas- cade of mitogen-activated protein kinases including ERK1/2 (46). Effec- tors of the TM signaling pathway may inhibit PAR-1-dependent Ca2⫹
signal and contribute to restraining thrombin-induced cell proliferation and vasoconstriction. The EGFR-dependent TM signaling may inter- fere with PAR-1 transduction pathway by a cross-talk, in the same way as tyrosine kinase receptors and G protein-coupled receptors are linked by transactivation mechanisms (48). That previous TM stimulation did not prevent GPCR agonists from activating NOS3 suggests the involve- ment of distinct kinases and phosphorylation sites. On one hand, TM activated PI3K- and CaMKII-dependent NO synthesis independently of
Ser1177-NOS3 phosphorylation. On the other hand, thrombin and his- tamine activate NOS3 and Ser1177phosphorylation independently of PI3K and CaMKII (23). Furthermore, a first PAR-1 stimulation inhib- ited subsequent thrombin activation of NO synthesis, not of Ca2⫹sig- nal. Altogether, the results confirm the existence of cross-talks between GPCR and TM and show the absence of PAR-1 desensitization. Because thrombin inhibits the EGF-induced phosphorylation of the main down- stream PI3K effector, Akt (28), transactivation of receptor tyrosine kinases through PAR-1 may prevent a subsequent activation of TM by thrombin.
The identification of the signaling pathway activated by the cell sur- face receptor TM is essential for understanding the physiological role of its soluble form. Plasma TM levels are inversely correlated with the development of new-onset coronary heart disease, suggesting that sol- uble TM may be cardioprotective (49, 50). Thrombin binding to endo- thelial TM could trigger outside-in signal and conversion of membrane TM into a soluble ligand. It has recently been demonstrated that the intramembrane protease rhomboids involved in EGFR signaling cleave TM at the top of its transmembrane domain (51). The regulatory func- tion of the membrane-bound TM could be comparable with that of syndecans, a family of heparan- and chondroitin-sulfate-carrying trans- membrane proteins. These glycoproteins modulate cell-extracellular matrix interactions, growth factor signaling, and cell adhesion by medi- ating outside-in signal and shedding of their extracellular domain (52).
Acknowledgments—We thank Dr. Bernard Le Bonniec for providing the mutant of thrombin S195A and for stimulating discussions. We thank the maternity teams of Notre Dame de Bon Secours Hospital and Institut Mutu- aliste Montsouris for collecting umbilical cords.
REFERENCES
1. Sadler, J. E. (1997)Thromb. Haemostasis78,392–395 2. Esmon, C. T. (2003)Chest124,26S-32S
3. Ye, J., Liu, L. W., Esmon, C. T., and Johnson, A. E. (1992)J. Biol. Chem.267, 11023–11028
4. Nesheim, M. (2003)Chest124,(suppl.) 33–39
5. Minami, T., Sugiyama, A., Wu, S. Q., Abid, R., Kodama, T., and Aird, W. C. (2004) Arterioscler. Thromb. Vasc. Biol.24,41–53
FIGURE 10.Hypothetical scheme of NOS3 and Src activation by thrombin through TM.Binding of thrombin to TM activates a receptor tyrosine kinase analogous to EGFR, which in turn stimulates the PLC␥and PI3K. The subsequent increase in Ca2⫹ induces formation of the Ca-calmodulin complex (Ca-CaM), which activates CaMKII and NOS3. NOS3 activity is amplified by phosphoryla- tion through PI3K and CaMKII, and NO activates Src family kinases by nitrosylation.
6. Macfarlane, S. R., Seatter, M. J., Kanke, T., Hunter, G. D., and Plevin, R. (2001) Pharmacol. Rev.53,245–282
7. Lafay, M., Laguna, R., Le Bonniec, B. F., Lasne, D., Aiach, M., and Rendu, F. (1998) Thromb. Haemostasis79,848 – 852
8. Olivot, J. M., Estebanell, E., Lafay, M., Brohard, B., Aiach, M., and Rendu, F. (2001) Circ. Res.88,681– 687
9. Lander, H. M., Jacovina, A. T., Davis, R. J., and Tauras, J. M. (1996)J. Biol. Chem.271, 19705–19709
10. Parenti, A., Morbidelli, L., Cui, X. L., Douglas, J. G., Hood, J. D., Granger, H. J., Ledda, F., and Ziche, M. (1998)J. Biol. Chem.273,4220 – 4226
11. Gu, M., Lynch, J., and Brecher, P. (2000)J. Biol. Chem.275,11389 –11396 12. Cha, M. S., Lee, M. J., Je, G. H., and Kwak, J. Y. (2001)Biochem. Biophys. Res. Commun.
282,1061–1066
13. Papapetropoulos, A., Garcia-Cardena, G., Madri, J. A., and Sessa, W. C. (1997)J. Clin.
Investig.100,3131–3139
14. Bussolati, B., Dunk, C., Grohman, M., Kontos, C. D., Mason, J., and Ahmed, A. (2001) Am. J. Pathol.159,993–1008
15. Shi, C. S., Shi, G. Y., Chang, Y. S., Han, H. S., Kuo, C. H., Liu, C., Huang, H. C., Chang, Y. J., Chen, P. S., and Wu, H. L. (2005)Circulation111,1627–1636
16. Topal, G., Brunet, A., Millanvoye, E., Boucher, J. L., Rendu, F., Devynck, M. A., and David-Dufilho, M. (2004)Free Radic. Biol. Med.36,1532–1541
17. Stone, S. R., and Le Bonniec, B. F. (1997)J. Mol. Biol.265,344 –362
18. Lantoine, F., Iouzalen, L., Devynck, M. A., Millanvoye-Van Brussel, E., and David- Dufilho, M. (1998)Biochem. J.330,695– 699
19. Millanvoye-Van Brussel, E., Topal, G., Brunet, A., Do Pham, T., Deckert, V., Rendu, F., and David-Dufilho, M. (2004)Biochem. J.380,533–539
20. Lantoine, F., Tre´vin, S., Be´dioui, F., and Devynck, J. (1995)Electroanal. Chem.392, 85– 89
21. Iouzalen, L., Devynck, M., and David-Dufilho, M. (1995)Eur. J. Pharmacol.289, 189 –195
22. Schaeffer, P., Riera, E., Dupuy, E., and Herbert, J. M. (1997)Biochem. Pharmacol.53, 487– 491
23. Thors, B., Halldorsson, H., and Thorgeirsson, G. (2004)FEBS Lett.573,175–180 24. Zachary, I., and Gliki, G. (2001)Cardiovasc. Res.49,568 –581
25. Stephens, L. R., Anderson, K. E., and Hawkins, P. T. (2001)J. Biol. Chem.276, 42767– 42773
26. Bromann, P. A., Korkaya, H., and Courtneidge, S. A. (2004)Oncogene23,7957–7968 27. Hess, D. T., Matsumoto, A., Kim, S. O., Marshall, H. E., and Stamler, J. S. (2005)Nat.
Rev. Mol. Cell. Biol.6,150 –166
28. Thors, B., Halldorsson, H., Clarke, G. D., and Thorgeirsson, G. (2003)Atherosclerosis 168,245–253
29. Shen, B. Q., Lee, D. Y., and Zioncheck, T. F. (1999)J. Biol. Chem.274,33057–33063 30. Li, H., Wallerath, T., and Forstermann, U. (2002)Nitric Oxide7,132–147 31. Ludeman, M. J., Kataoka, H., Srinivasan, Y., Esmon, N. L., Esmon, C. T., and Coughlin,
S. R. (2005)J. Biol. Chem.280,13122–13128
32. Brock, T. A., and Capasso, E. A. (1988)J. Cell. Physiol.136,54 – 62
33. McLaughlin, J. N., Shen, L., Holinstat, M., Brooks, J. D., Dibenedetto, E., and Hamm, H. E. (2005)J. Biol. Chem.280,25048 –25059
34. Van de Wouwer, M., Collen, D., and Conway, E. M. (2004)Arterioscler. Thromb. Vasc.
Biol.24,1374 –1383
35. Uchiba, M., Okajima, K., Oike, Y., Ito, Y., Fukudome, K., Isobe, H., and Suda, T. (2004) Circ. Res.95,34 – 41
36. Riewald, M., and Ruf, W. (2005)J. Biol. Chem.280,19808 –19814
37. Jorissen, R. N., Walker, F., Pouliot, N., Garrett, T. P., Ward, C. W., and Burgess, A. W.
(2003)Exp. Cell Res.284,31–53
38. Hudmon, A., and Schulman, H. (2002)Biochem. J.364,593– 611 39. Stork, P. J., and Schmitt, J. M. (2002)Trends Cell Biol.12,258 –266
40. Drew, B. G., Fidge, N. H., Gallon-Beaumier, G., Kemp, B. E., and Kingwell, B. A. (2004) Proc. Natl. Acad. Sci. U. S. A.101,6999 –7004
41. Michell, B., Harris, M., Chen, Z-P., Ju, H., Venema, V., Blacstone, M., Huang, W., Venema, R., and Kemp, B. (2002)J. Biol. Chem.277,42344 – 42351
42. Fleming, I., Fisslthaler, B., Dimmeler, S., Kemp, B. E., and Busse, R. (2001)Circ. Res.
88,E68 –75
43. Lin, M. I., Fulton, D., Babbitt, R., Fleming, I., Busse, R., Pritchard, K. A., Jr., and Sessa, W. C. (2003)J. Biol. Chem.278,44719 – 44726
44. Brouet, A., Sonveaux, P., Dessy, C., Balligand, J. L., and Feron, O. (2001)J. Biol. Chem.
276,32663–32669
45. Bhattacharya, A., and Cohen, M. L. (2000)J. Pharmacol. Exp. Ther.295,284 –290 46. Berridge, M. J., Lipp, P., and Bootman, M. D. (2000)Nat. Rev. Mol. Cell. Biol.1,11–21 47. Hanafy, K. A., Krumenacker, J. S., and Murad, F. (2001)Med. Sci. Monit.7,801– 819 48. Wetzker, R., and Bohmer, F. D. (2003)Nat. Rev. Mol. Cell. Biol.4,651– 657 49. Salomaa, V., Matei, C., Aleksic, N., Sansores-Garcia, L., Folsom, A. R., Juneja, H.,
Chambless, L. E., and Wu, K. K. (1999)Lancet353,1729 –1734
50. Wu, K. K., Aleksic, N., Ballantyne, C. M., Ahn, C., Juneja, H., and Boerwinkle, E. (2003) Circulation107,1729 –1732
51. Lohi, O., Urban, S., and Freeman, M. (2004)Curr. Biol.14,236 –241 52. Tkachenko, E., Rhodes, J. M., and Simons, M. (2005)Circ. Res.96,488 –500
