DEFECT ANNEALING IN DILUTE Cu-ALLOYS AFTER IRRADIATION AND DEFORMATION

HAL Id: jpa-00223343

https://hal.archives-ouvertes.fr/jpa-00223343

Submitted on 1 Jan 1983

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are pub- lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

DEFECT ANNEALING IN DILUTE Cu-ALLOYS AFTER IRRADIATION AND DEFORMATION

K. Tatsumi, H. Schmidt, D. Lenz, K. Lücke

To cite this version:

K. Tatsumi, H. Schmidt, D. Lenz, K. Lücke. DEFECT ANNEALING IN DILUTE Cu-ALLOYS AFTER IRRADIATION AND DEFORMATION. Journal de Physique Colloques, 1983, 44 (C9), pp.C9-723-C9-728. �10.1051/jphyscol:19839109�. �jpa-00223343�

JOURNAL DE PHYSIQUE

Colloque C9, suppl6ment a u n012, Tome 44, d k e m b r e 1983 page C9-723

DEFECT ANNEALING I N D I L U T E Cu-ALLOYS AFTER IRRADIATION AND DEFORMATION

K. Tatsumi, H. Schmidt, D. Lenz and K. Liicke

Institut ftir ATZgemeine MetaZZkunde und MetaZZPhysik, RWTH Aachen, F.R.G.

A b s t r a c t - S i n g l e c r y s t a l l i n e Cu and d i l u t e Cu-alloys ( w i t h S, Fe, Mn, Au, Be) were i s o c h r o n i c a l l y annealed (up t o 920 K) a f t e r i r r a d i a t i o n (3 MeV

-

s t r a h l u n g ) o r deformation (0.05<~<0.15% compression

1 1

I - INTRODUCTION

U l t r a s o n i c measurements of d i s l o c a t i o n resonance damping y i e l d i n f o r m a t i o n on t h e mean d i s l o c a t i o n l o o p l e n g t h L and d i s l o c a t i o n d e n s i t y h / l / . I n o r d e r t o g e t qood q u a n t i - t a t i v e data on d i s l o c a t i o n p i n n i n g (point d e f e c t annealing k i n e t i c s e. g. a f t e r i r r a - d i a t i o n ) s u i t a b l e values f o r A and Lo have t o be i n s t a l l e d by proper sample p r e p a r a t i o n i.e. deformation, a l l o y i n g and heat treatment. Measurements on d i l u t e a l l o y s a r e of s p e c i a l i n t e r e s t f o r s t u d i e s o f t h e i n t e r a c t i o n between f o r e i a n atoms (FA) and i r r a - d i a t i o n - i n d u c e d p o i n t - d e f e c t s (PD). Knowledge o f t h e FA/PD b i n d i n g energies i s impor- t a n t w i t h respect t o m a t e r i a l s behaviour e.g. under c o n d i t i o n s o f h i g h temperatures and/or i r r a d i a t i o n fluences. The present paper shows t h a t FA a d d i t i o n a l l y determine A and Lo i n a s p e c i f i c manner. This i s i n v e s t i g a t e d i n t h e present work by measure- ments o f L and A as f u n c t i o n o f annealing temperature TA a f t e r s l i g h t deformation a t

RT o f 5 d i l u t e Cu-alloys. The r e s u l t s a r e i n t e r p r e t e d by comparison w i t h t h e annealing behaviour o f pure copper b o t h a f t e r deformation and a f t e r y - i r r a d i a t i o n .

I 1 - EXPERIMENTAL

I n Tab.1 t h e d i f f e r e n t Cu-alloys a r e l i s t e d up (e.g. #Fe91 Cu+9latppmFe). The i n - f l u e n c e o f c o n c e n t r a t i o n o f t h e annealing i s r e p o r t e d elsewhere /2/. A l l samples

( I x l x l c m 3 ) were prepared by standard techniques /3/ (spark e r o s i o n c u t t i n g , g r i n d i n g , l a p p i n g ) from <I I I > - o r i e n t e d Bridgeman c r y s t a l s (1 1 x2x1 .5cm3 ). The f i n a l p l a n p a r a l l e - l i t y o f t h e a c o u s t i c endfaces was b e t t e r 5x10-5 cm/cm, t h e c r y s t a l o r i e n t a t i o n was w i t h i n 30' from t h e sound propagation d i r e c t i o n < I l l > . The a t t e n u a t i o n was measured a t RT w i t h MATEC-equipment (10

-

(RRR = 1000-2500). The d i l u t e a l l o y s were vacuum i n d u c t i o n smelted from ELMORE-Cu and 1% master a l l o y s . With a l l FA good s i n g l e c r y s t a l s were obtained i n t h e 10-500 ppm range except i n t h e case o f S where o n l y s t r i a t e d c r y s t a l s c o u l d be grown a t

c > 20 ppm. The S-, Mn-, and Au-crystals showed considerable m i c r o p o r o s i t y which was

detected u l t r a s o n i c a l l y and m e t a l l o g r a p h i c a l l y /4/. The f i n a l FA content was de- termined by t h e r e s i d u a l r e s i s t i v i t y o f t h e u l t r a s o n i c samples themselves (eddy c u r r e n t technique).

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphyscol:19839109

JOURNAL DE PHYSIQUE

Tab. I

E I I

-

(i) Annealing a f t e r y - i r r a d i a t i o n o f pure Cu:

Fiq.l shows t h e a t t e n u a t i o n cx measured a t RT a t d i f f e r e n t frequencies f f o r t h e sample R1 (stan- dard p r e p a r a t i o n /3/: 0.1% predeformation + Zh,

923 K anneal) b e f o r e and a f t e r y - i r r a d i a t i o n (2400 yAh a t RT) and a f t e r isochronal annealing a t TA. The n o n - d i s l o c a t i o n background a t t e n u - a t i o n ag i s shown f o r comparison.

& shows t h e corresponding f-dependence o f d i s l o c a t i o n decrement 6 before i r r a d i a t i o n ( s o l i d c i r c l e s ) a f t e r i r r a d i a t i o n (0) and a f t e r annealing a t s e l e c t e d TA f i t t e d by KGL-master curves (exponential L - d i s t r i b u t i o n /2/). From fMAX(T ) t h e mean l o o p l e n g t h L ( T A )

is

l a t e d ? I / .

Fig.3 shows t h e TA-dependence L/L (Lo = l o o p l e n g t h i n t h e u n i r r a d i a t e d sample? and i r r a d i - a t i o n induce p i n n i n g p o i n t d e n s i t y An = L(TA!-I - Lo-?: d u r i n g i r r a d i a t i o n s t r o n g p i n n i n g takes p l a c e ( t h e corresponding pinning stage i s s i t u a t e d a t ² 260 K and a t t r i b u t e d t o s i n g l e vacancies, m i g r a t i o n energy UMv = 0.7 eV /5/). A second p i n n i n g stage i s observed a t 350-400 K and a t r r i b u t e d t o vacancies de- trapped from t r a c e i m p u r i t i e s ( e f f e c t i v e mi- g r a t i o n energy

UW

Annealing Temperature b rC1 p loo 200 MO WM

I C

--=-=---

# RllRRR=11001

Annealing Temperature TA lKI Fig. I

Frequency f [MHz1

Annealing Temperature T, rC1

2 0 100 2W 300 WM 500 600

b L

: ^:An -

La

9 ....

A

Anneating Temperature T* iK1

sample no change i n d i s l o c a t i o n d e n s i t y i s ob- served up t o t h e pre-annealing temperature 923 K.

The present r e s u l t s c o n f i r m e a r l i e r r e s u l t s by Inagaki e t a l . /6/.

( i i ) Annealing a f t e r deformation o f pure Cu:

Fig.4 shows a(TA) f o r sample R2 (annealed 6 d a t 1223 K a f t e r p r e p a r a t i o n ) b e f o r e ( E = 0%) and (0.5 h ) a f t e r deformation ( E = 0.04% compression a t RT). During these 30' a t RT t h e a t t e n u a t i o n decreases by about 20% which e f f e c t continues d u r i n g annealing up t o 480 K w i t h a w e l l d e f i n e d stage centered a t about 350 K (Stage E corres- ponding t o Stage I V o f p o i n t d e f e c t annealing).

I n Stage F (Fig.4) t h e a t t e n u a t i o n increases and f i n a l l y decreases i n Stage G.

Fig.5a-c show ~ ( f ) - d a t a f i t t e d by t h e KGL-master- curves. From Fig.5a i t i s seen t h a t Stage E i s caused by p i n n i n g and from Fig.5b t h a t Stage F i s caused by depinning o f d i s l o c a t i o n s w i t h no change o f A (up t o 676 K a l l s ( f )-curves have i d e n t i c a l HF-asymptotes). However, a t T > 676 K t h i s asymptote decreases i n d i c a t i n g a decrease o f A ( t h e annealing-out o f d i s l o c a t i o n s i s accompagnied by a minor L-increase, c f . s l i g h t decrease o f f M ~ X i n F i g . 5 ~ ) .

I

\ \I

I@\ 10 100 I\.. ₁₀₀₀ I

Frequency f LMHd

Fig.5b

Annealing Temperature 1,[*C1

0 100 200 3w w 540 600

Frequency [MHz] #R2IRRR=22001

-0-290 -n- 190 -0- 90 ~=0.04%

-0- 270 -v- 170

-.-

-0- 250 -*- 150 -a- 50

-1- 230 ^-s- 130 -0- 30

- -0-210 -'I10 -0- 10 A 5

2 -StogeE+StogeF+StageG-

I R .

3W LOO 5W 600 7W BW mi+

Annealing Temperature T.I K I

#RZ~RRR=22001

" .

0

Annealing Temperature

5 IKI

101 10 100 1000

Frequency f LMHzI

1*1 10 1W

Frequency f IMHd ¹⁰⁰⁰

F i g . 5 ~

Fig.6 shows L(TA) and h(TA) c a l c u l a t e d from _Anneal~ng Temperature T,PC1

Figs.5a-c. By comparison w i t h Fig.3 i t i s o IW 200 30 400 500 600 700

seen t h a t up t o 400 K y - i r r a d i a t i o n and de- -

f o r m a t i o n r e s u l t i n very s i m i l a r d i s l o c a t i o n p i n n i n g behaviour i n d i c a t i n g t h a t t h e same

g

pinners ( i .e. t h e same p i n n i n g k i n e t i c s ) a r e g4 involved. However, a f t e r deformation addi-

"

t i o n a l p i n n i n g takes p l a c e a t 400- 480 K

whereas a f t e r i r r a d i a t i o n depi nning i s already

g

measured a t T>440K. T h i s i n d i c a t e s t h a t FA-

t r a p p i n g o f vacancies has no i n f l u e n c e a t -

CI

T > 4 0 0 K i n pure Cu b u t t h a t i n t h e deformed sample t h e vacancies a r e " s e l f - t r a p p e d " i n

deformation induced vacancy agglomelates MO LOO 500 MK) 7w 8W 901

from which t h e y evaporate a t T > 4 0 0 K. Thus Annedmg Temperature Ta IK1

a t T > 450 K simultaneous p i n n i n g by such Fig. 6 vacancies

and

#R2IRRR=22001

5 \ ,&.-&

\

_\ -FkCP

o - - ~ ~ . /

-b 1

YoA-

"b

E=O \o\

--

. 4 % C ,.

&

-3 g

.-

2 1

1

C9-726 JOURNAL DE PHYSIQUE

o f s i n g l e pinners a t t h e d i s l o c a t i o n s takes place. Annealing Temperature T~ ~ C I

Both a f t e r i r r a d i a t i o n and a f t e r deformation t h e .O 100 ZOO 300 400 500 600 7%

depinning i s complete a t T

=

perature, however, a l r e a d y s i g n i f i c a n t changes o f A a r e observed a f t e r d e f o m a t i o n (Fig.6). I t i s known t h a t A-anneal i n g ( d i s l o c a t i o n recovery) i s a f u n c t i o n o f ^E and s t a r t s a t lower tempera- t u r e s w i t h i n c r e a s i n g E.

( i i i ) A n n e a l i n g a f t e r d e f o r m a t i o n o f d i l u t e c u - A1 l o y s :

F i q s . 7 a - e show a(TA) f o r t h e Cu-alloys i n Tab.1. 300 4 ~ ) 500 600 100 BOO 900

The a(T )-behaviour i s q u a n t i t a t i v e l y s i m i l a r t o Annealing Temperature E IKI

~ ( T A ) o f deformed pure Cu ( c f . Fig.4). The KGL

evaluated L(TA) and n(TA) behaviour i s shown i n F i g.7a Fig.8 and 9, resp.

Anneal~ng Temperature TA I'C1 Annealing Temperature T,I'C1

Annealing Temperature TA [KI Annealing Temperature h lK1

Fig. 7b F i q . 7 ~

Annealing Temperature TA I'C1 Annealing Temperature h rC1

.o loo

mo

# Hn2O # 5 5

~ o - ~ - O - ~ - o - . , - - "

300 400 500 600 700 800 900

Annealing Temperature & [KI Anneoling Temperature TA IK1

Fig.7d Fig. 7e

Annealing Temperature TA PC1

F i .8 shows t h a t t h e p i n n i n g stage E ( = Stage ^loo im 300 LOO 500 MIO m o

I V i s observed i n a l l a l l o y s w i t h t h e c e n t e r

-9-

An e s t i m a t e o f t h e FA/vacancy b i n d i n g energy UBV (see Tab.1) can be obtained by simply s c a l i n g TE w i t h t h e e f f e c t i v e m i g r a t i o n energy o.f t h e t r a c e i m p u r i t y determined 350 K p i n n i n g stage i n pure Cu ( ~ i = 1 . 0 5 eV = UMV+UBV = 0.7 eV + 0.35 ev, c f . ( i ) ) . Fig.8 shows (by comparison w i t h A ~ ( T ) a f t e r v - i + r a d i a t i o n ) t h a t i n t h e a l l o y s tfte Stage E p i n n i n g i n t e r - f e r e s w i t h d i s l o c a t i o n depinning a t T > 400 K.

Furthermore t h e FA/vacancy t r a p p i n g i s super- Annealing Temperature 5 [KT

imposed on t h e vacancy evaporation from de- Fig. 8

formation induced agglomerates ( c f . ( i i ) ) . The comparatively s t r o n g p i n n i n g i n Cu440Be and Cu5S a t temperatures where p i n n i n g by FA d e t r a p p i n g and/or evaporated va- cancies i n t e r f e r e s w i t h depinning by c l u s t e r i n g on t h e d i s l o c a t i o n s i s remarkable.

I n Cu440Be (Fig.7b) t h e p i n n i n g i s so s t r o n g t h a t t h e d i s l o c a t i o n s become almost completely pinned (which makes q u a n t i t a t i v e e v a l u a t i o n impossible a t T > 400 K.) To e x p l a i n t h i s we have t o assume t h a t Be-atoms are t r a n s p o r t e d t o d i s l o c a t i o n s by a vacancy- and/or mixed-dumbbell mechanism /7/. Even more remarkable i s t h e s t r o n g p i n n i n g i n Cu w i t h o n l y 5 ppm S. Here a l l p i n n i n g occurs r i g h t i n t h e f i r s t de- p i n n i n g range o f pure Cu (cf. Fig.3). Thus we conclude, t h a t i n Cu5S a l a r g e c o n t r i - b u t i o n t o t h e p i n n i n g i s caused by S-atoms t r a n s p o r t e d t o t h e d i s l o c a t i o n s by de- formation-induced vacancies. Fig.8 shows t h a t such a FA-transport a l s o i n f l u e n c e s p i n n i n g i n t h e o t h e r a l l o y s a t T 3 600 K and becomes predominant i n a l l a l l o y s a t T > 6 5 0 K: I n c o n t r a s t t o pure Cu where t h e depinning i n Stage F r e s u l t s i n complete unpinning (An = O), Stage F unpinning i n a l l o y s i s incomplete (An > 6 ) . Thus we con- clude t h a t t h e pinners which remain s t a b l e (e.g. a t 700 K) a r e n o t o f vacancy t y p e b u t a r e s o l u t e atoms; t h e i r number ~ n ( 7 5 0 K) i s given i n Tab.1. Since ~ n ( 7 0 0 K) i s expected t o be l a r g e r i n more concentrated a l l o y s a l s o t h e q u a n t i t y ~ n ( 7 0 0 K)/ci i s given i n Tab.1. The l a t t e r q u a n t i t y shows t h a t t h e s o l u t e t r a n s p o r t by deformation induced vacancies i s t h e more e f f e c t i v e t h e l a r g e r UBV i s .

With respect t o Stage G (T > 700 K) t h e a1 l o y s behave q u i t e d i f f e r e n t as compared w i t h pure copper: i n t h e a l l o y s f u r t h e r p i n n i n g occurs a t T where i n pure Cu a l l deforma- t i o n induced vacancy agglomerates a r e annealed o u t and depinning i s complete. Thus T > 700 K p i n n i n g i s due t o s o l u t e atoms which a r e t r a n s p o r t e d by thermal vacancies and segregate a t t h e d i s l o c a t i o n s according t o t h e i r d i s l o c a t i o n b i n d i n g energy UBD.

I n t h e case o f s h o r t range ( r - b) p i n n i n g f o r c e An.b=ci exp(UBD/kT). From ~ n ( 9 2 0 K) i n F i g.8 we o b t a i n t h e UBD-values given i n Tab.1. Such an e v a l u a t i o n o f U D i s j u s t i - f i e d o n l y i f ~ n ( 9 2 O K) r e f e r s t o thermal e q u i l i b r i u m . The f a c t t h a t An(iAY tends t o decrease a t v e r y h i g h temperatures (e.g. T > 850 K f o r Cu20Mn) i n d i c a t e s t h a t t h e

" C o t t r e l l cloud" evaporates already a t these temperatures and e q u i l i b r i u m i s a t t a i n e d . Fiq.9 shows t h a t t h e A-recovery i s s t r o n g l y Anneabng Temperature T~ I'CI

i n f l u e n c e d by t h e FA. Tab.1 gives t h e cha- o loo 200 300 400 500 wo 700

r a c t e r i s t i c temperatures TA d e f i n e d by

A / A o = 0.95 ( c f . Fig.9) T h i s temperature i s

expected t o be t h e h i g h e r t h e l a r g e r UBD i s because UBD determines t h e d i s l o c a t i o n mo- b i 1 i t y f o r t h e recovery processes (anni h i la - t i o n by c l i m b and/or g l i d e ) . The FA-segrega-

4

t i o n r e i n f o r c e s t h i s FA e f f e c t on d i s l o c a t i o n I

recovery. I t i s i n t e r e s t i n g t o note t h a t t h i s

g

s y n e r g i s t i c FA e f f e c t r e s u l t s i n a narrow

O ~ W 400 40 tm mo BOO 'XK) IW

A-annealing range (as compared w i t h pure Cu) Anneal~ng Temperahre E IKI

and t h a t TA i n Cu5S i s more than 300 K h i g h e r

than i n pure Cu, where recovery s t a r t s a t F i q. 9 400 K and continues up t o about 800 K.

I V

-

The i n t e r a c t i o n between f o r e i g n atoms (FA) and deformation-induced l a t t i c e defects (vacancies and d i s l o c a t i o n s ) determines t h e annealing behaviour o f d i l u t e Cu a l l o y s i n t h e T-range 290 - 920 K. The observed FA-effects r e f e r t o

( a ) t h e FA dependent p o s i t i o n o f the recovery stage I V , i n d i c a t i n g t h a t t h i s stage i s due t o annealing o u t o f vacancies a f t e r d e t r a p p i n g from FA.

(b) t h e FA t r a n s p o r t t o d i s l o c a t i o n s by deformation-induced vacancies.

( c ) t h e s o l u t e segregation a t d i s l o c a t i o n s under thermal equi 1 ib r i u m

( d ) t h e temperature above which d i s l o c a t i o n recovery occurs a f t e r deformation The present values f o r t h e FA/vacancy (UBV) and t h e F A / d i s l o c a t i o n (UBD) b i n d i n g energies i n Tab.1 a r e presumed t o be accurate by 2 0.1 eV, b u t t o represent c o r r e c t r e l a t i v e values o f t h e b i n d i n g energies f o r 5 i n t e r e s t i n g types o f FA i n Cu. The r e s u l t s f o r pure Cu and Cu91Fe i n d i c a t e t h a t (unknown) t r a c e i m p u r i t i e s ( i n t h e 1-5 ppm range) determine t h e p i n n i n g i n Stage I V i n these cases. T h i s shows t h a t t h e

C9-728 JOURNAL DE PHYSIQUE

Fe/vacancy binding energy must be smaller than 0.35 eV; possibly i t i s close t o zero as shown by recent MoRbauer s t u d i e s 181. The present investigation provides t h e proper annealing parameters f o r d i l u t e Cu alloys t o be used f o r point defect studies a f t e r i r r a d i a t i o n . The t r a c e impurity influence indicates t h a t improved UBV-data can be obtained by t h e present ultrasonic technique on 1 - 10 ppm alloys of a very high purity Cu-matrix (of s 0.1 ppm t o t a l impurities corresponding t o a residual r e s i s t i - v i t y r a t i o ² 10.000).

ACKNOWLEDGEMENTS

Work supported by t h e Deutsche Forschunqsgemeinschaft (SFB 125 Aachen-Julich-Koln) and t h e Minister f u r k'issenschaft und Forschung NRW (providing the Van-de-Graaff-

y - i rradiation f a c i l i t y ) . REFERENCES

/ I / D. Lenz, K., Lucke; "Proc. 5th ICIFUA" (D.Lenz, K-Liicke, ~ds.) Vol.11, p.48, Springer Berlin, Heidelberg, New York 1974

.

/2/ K. Tatsumi; Thesis RWTH Aachen, 1983.

/3/ P. Winterhager, K. Lucke; J. Appl. Phys. - 44 (1973) 4855.

/4/ H. Schmidt, D. Lenz, W. Uelhoff; t h i s conference /5/ P. Winterhager; Thesis RWTH Aachen, 1968

.

/6/ H. Inagaki, F. Hu)tgren, K. Lucke; Acta Met. 18 (1970) 713. -

/7/ A. Bartels, F. Dworschak, H.P. Meurer, C. Abromeit, H. Wollenberger;

J. Nucl. Mat. 83 (1979)

-
