LOW-TEMPERATURE GROWTH CONDITIONS AND PROPERTIES OF AlGa (As) Sb ON GaSb SUBSTRATE BY LPE

(1)

HAL Id: jpa-00222224

https://hal.archives-ouvertes.fr/jpa-00222224

Submitted on 1 Jan 1982

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are pub- lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

LOW-TEMPERATURE GROWTH CONDITIONS AND PROPERTIES OF AlGa (As) Sb ON GaSb

SUBSTRATE BY LPE

S. Fujita, N. Hamaguchi, Y. Takeda, A. Sasaki

To cite this version:

S. Fujita, N. Hamaguchi, Y. Takeda, A. Sasaki. LOW-TEMPERATURE GROWTH CONDITIONS

AND PROPERTIES OF AlGa (As) Sb ON GaSb SUBSTRATE BY LPE. Journal de Physique Col-

loques, 1982, 43 (C5), pp.C5-29-C5-38. �10.1051/jphyscol:1982505�. �jpa-00222224�

(2)

JOURNAL DE PHYSIQUE

CoZZoque C5, suppZ6ment au n012, Tome 43, d6cembre 1982 page C5-29

LOW-TEMPERATURE GROWTH CONDITIONS AND PROPERTIES OF A ~ G ~ ( A S )

Sb O N

GaSb SUBSTRATE BY LPE

S.

F u j i t a ,

N.

Hamaguchi,

Y.

Takeda and

A.

Sasaki

Department o f EZectricaZ Engineering, Kyoto University, Kyoto 606, Japau

Resume.- La croissance par epitaxie en phase liquide des a l l i a g e s semiconducteurs AlGaSb e t AlGaAsSb sur l e s u b s t r a t GaSb a St& etudiee en fonction de l a temperature de croissance (Tc) . A une temperature de croissance inferieure

&

450°C, l a morpho- logie e t l a v i t e s s e de croissance des couches obtenues par e p i t a x i e sont fortement influencees par l e processus de preearation du s u b s t r a t . Les couches t e r n a i r e s ob- tenues par epitaxie A1 Ga Sb avec x=0,84 sont obtenues avec succPs sans instabi- l i t 6 d ' i n t e r f a c e entrexle&- ouches e t l e s u b s t r a t en diminuant l a temperature de croissance

1

400°C.

A

une temperature de croissance de 540°C, l e plus grand taux de composition en A1 pour une couche t e r n a i r e sans instabilitfi d ' i n t e r f a c e e s t -0,64 a l o r s que, pour une couche quaternaire, i l e s t -0,78. Les couches quaternaires A1 Ga As Sbl-y

1

i n t e r f a c e d r o i t peuvent &re obtenues de maniere sOre pour ung3@mp0e~%urg dc croissance de 540°C. La concentration en porteurs e s t reduite d'une maniere signi ficativelgn ab i s s a n t l a temperature de croissance

:

p=1017cm-3

1

TC=54O0C a l o r r

que

p=8x10

?I

TC=40O0C. La photoluminescence des couches ternai res obtenues par @pi taxi e met en 6vi dence quatre bandes d' emi ssion di s t i nctes 1 4 , 2 K probablement dues

1

l a recombinaison radiative d'un exciton l i b r e , d'un ex- citon l i e

&

l'accepteur neutre e t d'une paire

D-A lice 1 2

niveaux accepteurs d i f f e r e n t s .

Abstract. - Liquid-phase epitaxial growth of AlGaSb and AlGaAsSb alloy semiconductors on GaSb substrates has been investigated a s a function of growth temperature(

TG ).

A t a growth temperature lower than 450°C, the morphology and the growth r a t e of the epilayer a r e greatly affected by the substrate preparation processes. AlxGal-xSb ternary epilayer with x=0.84 i s successfully grown without i n t e r f a c e i n s t a b i l i t y between the epilayer and the substrate by lowering the growth temperature t o 400°C.

A t a

TG

of 540°C, the l a r g e s t Al-composition r a t e f o r a ternary layer without the i n s t a b i l i t y i s ~ 0 . 6 4 , whereas i t f o r a quaternary layer extends t o ~ 0 . 7 8 . A10.78 Ga0.22As~Sbl-~ layer with s t r a i g h t i n t e r f a c e can be r e l i a b l y grown a t T~=540"C.

Carrier concentration i s s i g n i f i c a n t l y reduced by decreasing TG: p=l 017cm-3 a t

TG=

540°C, whereas p=8x1 o1 5cm-3 a t T~=400"C. Photo1 uminescence of the ternary 1 ayers exhibits four d i s t i n c t emission bands a t 4.2K which a r e presumably a r i s e d from radi- a t i v e recombination of f r e e exciton, exciton bound t o neutral acceptor and

D-A

pair re1 ated t o two d i f f e r e n t acceptor 1 eve1 s .

1 . Introduction. - Much attention has been given t o AlGa(As)Sb ternary o r quaternary

a l l o y semiconductor as an a t t r a c t i v e candidate material f o r optoelectronic device

application in a 1-vm wavelength range because of i t s wide variation of bandgap

energy by adjusting a l l o y composition r a t e together with i t s close o r exact l a t t i c e

matching with GaSb. Investigations in l a s e r diodes and photodetectors u t i l i z i n g an

AlGa(As)Sb/GaSb heterostructure have been carried out by manyauthor$l-121 as an

a1 t e r n a t i v e t o an InGaAsP/InP system. A1 though A1 Ga(As)Sb a1 loy semiconductors

have intensively grown by a

1

iquid-phase epitaxial (LPE) technique, problems s t i l l

remain with the growth of device-quality s i n g l e crystal and also there s t i l l remain

unresolved in e l e c t r i c a l and optical properties of these epilayersC131. In order

t o make the best use of high potential of AlGa(As)Sb/GaSb system a s a material f o r

1 ong wave1 ength optoel ectronic devices, i t i s of great importance t o investigate

further the growth conditions f o r high-quality epilayers imperative f o r a high device

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphyscol:1982505

(3)

performance.

In t h i s paper, we describe experimental r e s u l t s of LPE-grown AlGaSb o r AlGaAsSb on a GaSb substrate. The relationship between the growth temperature and the epi- layer properties i s investigated by changing the temperature over a wide range from 600 t o 400°C. In p a r t i c u l a r , we demonstrate t h a t the i n t e r f a c e i n s t a b i l i t y between the epilayer and the substrate can be e f f e c t i v e l y suppressed by lowering the growth temperature even i n the epilayer with a high A1 composition r a t e . Arsenic addition to ternary layer releases the interface i n s t a b i l i t y : a t the same growth temperature, the 1argestAl compositicn r a t e becomes higher i n AlGaAsSb quaternary epilayer than in AlGaSb ternary epilayers which can be grokn without the i n s t a b i l i t y . Further, i t i s described t h a t c a r r i e r concentration i s s i g n i f i c a n t l y reduced by decreasing the growth temperature. Finally, i t i s also reported t h a t two d i s t i n c t acceptor levels a r e found t o e x i s t i n the epilayers by photoluminescence measurements.

2. Experimental procedures.- The epitaxial layers of the ternary or the quaternary a l l o y semiconductors a r e grown from Ga-rich solution on (111)-B oriented GaSb sub- s t r a t e s using a s l i d i n g boat technique in a Pd-diffused hydrogen stream i n horizontal furnace. The s l i d i n g boat used in t h i s work i s composed by a double-bin type c r u s i - ble which enables us t o supply fresh and almost thermal equilibrium melt t o a

sub-

strate[13]. The GaSb substrate

( MCP

Electronics

LTD. )

a r e both of n-type

(

Te aoped, n-6x1017 t o lx1018cm-3

)

and p-type

(

Zn doped, p=3x1018cm-3

)

. These sub- s t r a t e s a r e etched in a solution of HF:HN03:CH3COOH=1:19:30

( F

solution

)

o r

B r 2

in methanol and subsequently rinsed in deionized water o r methanol, prior to loading to the furnace. The preparation procedures f o r t h e substrate a r e important f o r growing uniform and smooth epilayers. The s u b s t r a t e orientation must be accurate within k0.2" t o obtain an as-grown mirror-like epilayer. The best r e s u l t s are well reproduced with thorough r i n s e by pure methanol a f t e r a final etching of the sub- s t r a t e in the F solution. The raw materials f o r the melt a r e 7N-Ga, 5N-A1, 6N-Sb, and a GaAs polycrystal. The dew point a t the downstream of the growth tube i s lower than -76°C during the growth runs. The heating cycles f o r the growth a r e schemati- c a l l y i l l u s t a t e s i n Fig. 1. The cycle

A

i s f o r the melt baking of Ga and Sb, where the temperature i s kept a t 70G°C f o r 3 t o

24

hrs. After the baking, A1 and GaAs a r e adaed t o the me1 t and the substrate i s loaded to the boat

(

cycle

B ):

For a high temperature growth

( TG >

500°C

) ,

the growth solution i s heated to a tempera- t u r e s l i g h t l y above the growth temperature and maintained a t t h i s temperature f o r 30 min t o e q u i l i b r a t e the me1 t , and then the growth i s s t a r t e d

(

Fig. 1 ( a )

) .

For a low temperature growth

(

TG

<

500°C

)

, a heat cleaning cycle

C

f o r the substrate a t 550°C f o r 1 hr has t o be added before the growth in order t o obtain smooth and uniform a l l o y epilayers

(

Fig. (b)

). A

cooling r a t e of 0.2 t o 0.3OC/min i s used and the thickness of the epilayers i s

about 0.5 t o 15um depending on the grow-

^W^a₃

t h i n t e r v a l . 2

a

W a

3. Results and discussions.

I w +

3.1 Relationship between epilayer

W u a

growth and substrate preparation

z

process.

^a³

In

LPE

technique, good "wetting"

^u.

between a melt and a substrate i s needed for uniform and smooth morphology toge- ther with thickness control of a grown layer. The "wetting" is greatly depend-

ent on a substrate surface condition .just

^TIME

-

7 0 0 ~ ~ 3-6hrs HEAT CYCLE FOR LPE

70$C 3-24hrs (b) A

-

prior t o the growth. We investigate the of sub- temperature growth ( a ) and low tempera- Fig. 1. Temperature p r o f i l e s of high s t r a t e preparation condition and growth

temperature on the "wetting" o r the t u r e growth ( b ) . growth r a t e of AlGaSb ternary a l l o y epi-

layer.

A s shown i n Table I , the apparent

(4)

growth r a t e f o r A10.3gGa0.61Sb

grown a t T~=500"C e x h i b i t e d r e - ^{Table I} Relationship between substrate preparation processes

markable dependence on t h e GaSb and A10.39Ga0.61Sb growth characteristics.

s u b s t r a t e p r e p a r a t i o n process. Thickness (m) of Surface The growth r a t e i s seen t o be r e -

:b7~:iLp,,

the epilayer a t

TG = 500°C morphology

duced w i t h decreasing t h e r e s i s - t i v i t y o f t h e water used as a

f i n a l r i n s e s o l u t i o n f o r t h e sub- ^{(a) Pure}_methanol ^9.3 mirror-1 i k e

s t r a t e . A t T ~ = 4 0 0 and 450°C,

Al(j.3yGa0.61Sb was n o t grown a t ( b ) Water 7.5 m i r r o r - l i k e (p>lY(R.cm)

a l l unless t h e h e a t c y c l e C men-

t i o n e d i n t h e previous s e c t i o n (c) Uater

( ~ ? . l R - c m ) 2.8 rough surface

was introduced p r i o r t o the

growth regardless o f t h e process (d) water

subjected, t o t h e substrate, where- ( P % B K ~ . c ~ ) ^0%2.9 no growth o r rough surface

as no s i g n i f i c a n t d i f f e r e n c e i n t h e growth r a t e f o r A10.3gGa0.61 Sb was observed a t a h i g h e r TG

than 550°C w i t h v a r i o u s kinds o f t h e f i n a l r i n s e f o r GaSb.

Judging from the above experimental observation, t h e s u r f a c e o f t h e GaSb sub- s t r a t e would be presumably covered by some undesirable t h i n l a y e r o f which thickness i s dependent on t h e q u a l i t y o f t h e water, which gives g r e a t influence on t h e "wet- t i n g " o r t h e apparent growth r a t e o f the e p i l a y e r . Although i t i s s t i l l unrevealed whether t h e t h i n s u r f a c e l a y e r covering t h e s u b s t r a t e s u r f a c e i s formed b y an o x i d e o r o t h e r m a t e r i a l s , t h e f a c t t h a t t h e growth r a t e a t a h i g h TG i s l e s s s e n s i t i v e t o t h e f i n a l r i n s e s o l u t i o n s f o r GaSb used i n t h i s experiment suggests t h a t t h e t h i n surface l a y e r can e a s i l y be removed by thermal e t c h i n g a t a h i g h temperature j u s t b e f o r e t h e m e l t comes i n t o c o n t a c t w i t h t h e substrate, which leads t o a good "wet- t i n g ' ' o f t h e m e l t w i t h a substrate. However, t h e surface morphology o f t h e e p i l a y e r was u n i f o r m and smooth when u s i n g pure methanol o r water w i t h p > 15N2.cm as a f i n a l r i n s e s o l u t i o n f o r t h e substrate. Thus, t h e thickness c o n t r o l o f the e p i l a y e r w i t h e x c e l l e n t morphology becomes e a s i e r i n t h e LPE growth a t a lower temperature.

3.2 Low-temperature growth o f AlGaSb and AlGaAsSb

The low-temperature growth o f AlGa(As)Sb has been found t o be very e f f e c t i v e t o reduce t h e c o n c e n t r a t i o n o f background i m p u r i t i e s o r defectsC9, 13, 143 and f u r t h e r t o suppress t h e i n t e r f a c e i n s t a b i l i t y between t h e a l l o y e p i l a y e r and t h e GaSb sub- s t r a t e [ l 3 ] . C a l c u l a t i o n s and experiments f o r t h e phase diagram o f the t e r n a r y a1 l o y semiconductors have been c a r r i e d o u t by several authorsCl5-191. However, t h e r e a r e o n l y a few r e p o r t s [13, 14, 171 on experimental s t u d i e s f o r low-temperature LPE grow-

~ 6 0 . 1 3 ~ I ~ I lB~1*~ ~ ~ I

g . Al,Gq,Sb AI,Ga,-x Sb

z ^-

z 0.6

-

5

2 0 -

I- 3

g

^10-

+

c

A1 ATOM FRACTION I N LIQUID 0 0 1 1 , 1 1 1 I 1 1 1 1 1

0.001 0 01 0.1

Al ATOM FRACTION IN LIQUID Fig. 2. S o l i d u s isotherms i n AlGaSb a t

TG=400 and 540°C. S o l i d curves a r e t h e Fig. 3. A1 d i s t r i b u t i o n c o e f f i c i e n t c a l c u l a t e d r e s u l t s a f t e r Cheng e t a1 .[I71 o f AlGaSb a t T ~ = 4 0 0 and 540°C.

(5)

l ' l ' l ' l ' 5

.- C Al, Gal, Sb

E

0.5

5

0 0.2 0.4 0.6 0.8 1.0

A1 COMPOSITION RATE IN SOLID

0 . 0 5 0

400 500 600

GROWTH TEMPERATURE ('C ) Fig. 4. R e l a t i o n s h i p between A1 GaSb F i g . 5. Growth temperature dependence growth r a t e and A1 composition r a t e on t h e growth r a t e o f AlGaSb.

i n s o l i d .

t h o f these t e r n a r y and quaternary a l l o y semiconductors. I n o r d e r t o o b t a i n high- q u a l i t y heteroepi t a x i a l l a y e r s o f these m a t e r i a l s , the LPE growth was performed a t TG'S be1 ow 540°C.

Experimentally determined s o l i d u s isotherms i n AlGaSb system grown a t 400 and 540°C a r e shown i n F i g . 2. These experimental r e s u l t s a r e i n good agreement a t a low

xA1

r e g i o n w i t h t h e c a l c u l a t e d r e s u l t s based on a simple s o l u t i o n model r e p o r t e d by Cheng e t a1 .[17]. F i g u r e 3 shows the r e l a t i o n s h i p between A1 a t o m - f r a c t i o n i n s o l i d u s uhase and i n l i ~ u i d u s ohase, i.e., A1 d i s t r i b u t i o n c o e f f i c i e n t . I t i s seen t h a t A1 d i s t r i b u t i o n c o e f f i c i e n t ,

xil/xA1 1

i n A1 GaSb

a t T~=400"C decreases from 50 t o 15 w i t h i n c r e a s i n g

xA,

from 0.001 t o 0.55. The r a i s i n g o f TG t o 540°C reduces

~2~ /xil

by approximately one ha1 f w i t h i n

xA1

employed i n t h i s The growth r a t e decreases w i t h i n c r e a s i n g b o t h TG's, as shown i n F i g . 4.

I n p a r t i c u l a r , a submicron AlGaSb e p i l a y e r can be easi 1 y reproduced by decreasing TG t o 400°C.

F i g u r e 5 i n d i c a t e s t h e growth temperature dependence on t h e growth r a t e o f AlxGal-xSb w i t h x=0.38

-

0.40.

I t i s w e l l known t h a t c r y s t a l i n s t a b i l i t y i s o f t e n observed a t t h e i n t e r f a c e i n a h e t e r o e p i t a x i a l growth o f AlGaSb ob GaSb[13, 17, 20, 211. We observed t h a t t h e low-temperature growth o f AlGaSb i s

verv e f f e c t i v e t o suuuress t h e i n t e r f a c e i n s t a b i l i t v (a) a n d - t h a t t h e As a d d i t i o n t o t h e melt, i . e . , the

t e r n a r y e p i l a y e r growth leads t o u n i f o r m s t r a i g h t i n t e r f a c e . The A1 composition r a t e x i n AlxGal -xSb beyond which the i n t e r f a c e becomes nonuniform was extended from 0.47 t o U.84 bv l o w e r i n a TG from 600 t o 400°C. F i g u r e 6 shows a - t y p i c a l e x a i p l e o f

A1~.84Gao.l6Sb l a y e r surface and cleaved c r o s s sec-

-

t i o n where TG i s 400°C. No i n t e r f a c e i n s t a b i l i t y i s observed. Re1 a t i o n s h i p between t h e i n t e r f a c e i n s t a b i l i t y and t h e growth temperature as w e l l as t h e As a d d i t i o n i s shown i n F i g . 7 where one can c l e a r l y see t h a t t h e i n s t a b i l i t y i s a b l e t o be suppress b y

l o w e r i n g TG o r by t h e As a d d i t i o n even i n t h e hetero- (b)

e p i t a x i a l growth o f these a l l o y s w i t h a h i g h A1 com- F i g . 6. Surface (a) and p o s i t i o n r a t e . The avoidance o f i n s t a b i l i t y i s ess- cleaved cross s e c t i o n ( b ) o f e n t i a l l y important i n wide-gap h e t e r o j u n c t i o n device A10.84Ga0.16Sb grown a t TG=

a p p l i c a t i o n s . I n general, i n t e r f a c e i n s t a b i l i t y i s 4000C. I

caused by a c o n s t i t u t i o n a l supercooling phenomenon[22]. 1 0um

(6)

F i g . 8. Cleaved cross s e c t i o n As Sb w i t h y=

Of A10.4Ga0.6 y 1-y

0.007 grown a t 540°C on,GaSb.,

--

2 > , - 20vm

cl,

Assume t h a t t h e i n s t a b i l i t y i n t h e present experiments i s due- t o t h e supercooling phenomenon.

I n o r d e r t o avoid t h e supercool- i n g , a c r i t e r i o n must be f o l l o w e d t h a t r e q u i r e d GL/V be g r e a t e r than a c e r t a i n value[22], where GL i s t h e 'temperature g r a d i e n t i n t h e l i q u i d u s

a t t h e i n t e r f a c e and v t h e growth v e l o c i t y . I f GL i s assumed t o be c o n s t a n t i n each growth r u n i n Fig.7, a value o f GL/V would be increase w i t h reducinq Tc o r w i t h t h e As addi- Fig. 7. R e l a t i o n s h i p between i n t e r f a c e t i o n since ttie growth r a t e i s s i g n i - i n s t a b i l i t y and growth temperature. f i c a n t l y decreased by 1 owering TG o r

by t h e As a d d i t i o n , which agrees w i t h t h e requirement f o r suppression of c o n s t i t u t i o n a l supercooling. A t t h e same TG, on t h e o t h e r hand, t h e growth r a t e decreases w i t h i n c r e a s i n g A1 composition r a t e as shown i n F i g . 4. Howeverythe i n - s t a b i l i t y i s easy t o occur i n t h e growth a t higher A1 composition r a t e s . Therefore, i t cannot be explained o n l y i n terms o f t h e growth r a t e . Since t h e c r i t i c a l value o f GL/V depends on t h e l i q u i d u s slope, t h e l i q u i d concentration, t h e d i s t r i b u t i o n c o e f f i c i e n t and t h e d i f f u s i o n constant a t the i n t e r f a c e o f each component, i t i s f u r - t h e r r e q u i r e d t o take these f a c t o r s i n t o account f o r t h e i n t e r p r e t a t i o n of t h e i n s t a - b i l i t y phenomenon.

The As composition r a t e i s q u i t e l i m i t e d i n t h e AlGaAsSb quaternary a l l o y system, which r e s u l t s i n d i f f i c u l t y i n growing AlGaAsSb l a t t i c e - m a t c h e d w i t h GaSb. This would be due t o low s o l u b i l i t y o f As i n t o the l i q u i d u s phase[2] o r due t o a m i s c i b i - l i t y gap i n a Ga-As-Sb systemC23, 24). Therefore, AlGaAsSb w i t h a h i g h As-composi- t i o n lattice-matched w i t h GaSb cannot be grown a t a l o w growth temperatureC9, 191.

However, even i n t h e quaternary e p i l a y e r 1 a t t i c e - m i smatched w i t h GaSb, we were a b l e t o r e p r o d u c i b l y grow t h e excel 1 e n t morphological e p i l a y e r w i t h a h i g h A1 composition r a t e , which i s f r e e from t h e i n t e r f a c e i n s t a b i l i t y as shown i n F i g . 8.

F i g u r e 9 shows t h e TG dependence o f t h e As composition r a t e i n s o l i d u s phase of AlGaAsSb. A t T~=400'C, t h e maximum As composition r a t e y i n A10.4Ga0.6AsySbl-y i s estimated around 0.0045. A10.3gGa0.61AsySbl- w i t h y-0.025%0.03 l a t t i c e - m a t c h e d w i t h A10.07Ga0.93Sb was reproduced by r a i s i n g

fG

up t o 540°C as shown i n F i g . 10.

However, t h e increase i n As atom f r a c t i o n i n l i q u i d u s phase leads t o i r r e g u l a r v a r i a - t i o n i n t h e l a t t i c e constant o f t h e quaternary l a y e r s , which i s probably caused by the m i s c i b i l i t y gap o f t h i s quaternary system[2, 241. Since t h e growth r a t e o f t h e quaternary e p i l a y e r i s s i g n i f i c a n t l y decreased w i t h t h e As composition r a t e i n l i q u i - dus phase as i n d i c a t e d i n F i g . 11, we can s u c c e s s f u l l y reproduce t h e submicron ( ~ 0 . 5 pm ) quaternary l a y e r s , which i s very u s e f u l f o r double h e t e r o j u n c t i o n a p p l i c a t i o n s .

(7)

GROWTH TEMPERATURE(°C )

Fig. 9. Growth temperature dependence of Fig. 10. Relationship between As atom the As composition r a t e in solidus phase f r a c t i o n in liquidus phase

xis

^and

in A1 0.4Ga0.6As Sbl y quaternary epilayers. l a t t i c e constant of A1 xGal -xAsySbl -y The r e s u l t s by gotoiugi e t a1 .[19], and quaternary epi 1 ayers

.

Law e t a1 .[21 are a l s o indicated f o r com-

parison.

-

.- C ¹

-

_I A!, Ga .sAs,Sq-,: _I _J

-

_W

_- -

3.3 Electrical and 1 uminescent properties of A1 GaSb.

In order t o investigate the e l e c t r i c a l properties of epilayers, the Hall measurements have been carried out by a p-n junction separation technique because of a semi- insulating GaSb substrate unavailable.

The undoped AlGaSb epilayers show p- type conduction regardless of TG's employed

a t present work. However, hole concentra- 0.01 ^I ^I

tions a r e s i g n i f i c a n t l y reduced by about 0 1 .o 2.0 (XIO-3)

two orders in magnitude by lowering TG from As ATOM FRACTION IN LIQUID

600 t o 400 O C as shown in Fig. 12.

A10.4Ga0.6Sb epilayer a t T~=400'C i s seen t o Fig. 11. Dependence of growth r a t e

have a typical value of p=8x101 5cm-3 a t room _~ _~ _i _~ _~ _~ _i _~ _~ _~ _i ₆ _~ _~ _$ _s _~ _~ _; _{ _t _~ _~ _~ _~ _~ _~ _~ _~ _~ _n temperature. Temperature dependence of hole i n l i q u i d u s

phase XAs.

concentration of the epilayers a t T~=400 and 536OC i s shown in Fig. 13. These r e s u l t s

could allow us t o evaluate acceptor l e v e l s , the acceptor and the compensating donor concentrations by computer analyses. Although attempts t o estimate these material parameters of the epilayers by the computer analyses have been made, i t i s found to d i f f i c u l t t o evaluate the reasonable values of the parameters because of remarkable influence on the Hall measurements a t a high temperature region of leakage current of p-n junction used e l e c t r i c a l separation between the epilayers and t h e substrates.

A rough estimation from the data a t a low temperature region gives a value of 25 t o 30 meV f o r an acceptor level.

In undoped p-type GaSb, a model of doubly-ionizable acceptor whose origin i s connected with an i n t r i n s i c Sb vacancy has been reportedC25-J. I t has been indicated, on the other hand, t h a t by reducing

TG

undoped AlGaSb o r GaSb epilayers exhibit

n-

type[9 14, 261 and f u r t h e r residual donor concentration decreases d r a s t i c a l l y up t o 2-4xl0f5cm-3 f o r A10.2Gao.aSb and up t o 2xl013cm-3 f o r GaSb[14, 261. The origin of p-type conduction in our epilayers i s s t i l l unknown whether i t i s due t o i n t r i n s i c defects related t o a Sb vacancy[25] o r to e x t r i n s i c impurities such a s Si[30].

Further experiments f o r obtaining high-purity epilayers a r e needed to elucidate the origin.

(8)

I I I I

R.T. I " " I ' ~ " 1 " " I

GROWTH TEMPERATURECC)

Fig . 13. Temperature dependence Fig. 12 Growth temperature dependence of hole concentration of p-A1 GaSb of hole concentration of p-AlGaSb l a e r a t T~=400 and 540°C. Rapid in- Solid square i s a f t e r Gautier e t al.f32j. crease in hole concentration i s

due t o leakaae current from

p-n

junction a t high temperatures.

Photoluminescence

( PL )

measurements were made f o r A10.07Ga0.93Sb ternary epi-

layers grown a t TG's from 550 t o 400°C t o obtain information on impurity or defect l e v e l s involved. A high-pressure

Hg

lamp with a f i l t e r o r argon ion l a s e r

(

1W

)

f o r excitation source and a cooled PbS photoconductive c e l l f o r a detector were used f o r the measurements.

Fig. 14 shows

PL

spectra measured a t 77 and 4.2K in an epilayer grown a t TG=450

OC.

A t 4.2K four emission bands labelled a s I x , 11, Ia , and Ic can be observed a t 0.873, 0.870, 0.844, and 0.815eV, respectively, while one can see two d i s t i n c t emis- sion bands of 10 and I$ located a t 0.870 and 0.842eV a t 77K, respectively.

The 10 emission band a t 77K varies in peak photon energy depending on the s l i g h t difference in the A1 composition r a t e among the epilayers grown a t d i f f e r e n t TG's, a s shown in Fig. 15. However, the peak

energy difference between 10 and I$ re- mains almost unchanged among the epi-

layers: the value i s about 27meV. Fur-

₈₆₇₄

.

^TG-^450.C

t h e r , the i n t e n s i t y of I$ w i t h respect t o t h a t of 10 tends t o decrease a t low- e r TG's which lead t o decrease i n t h e acceptor concentration.

From these r e s u l t s , the 10 emis- sion band may be arised from d i r e c t t r a n s i t i o n from electron i n the conduc- tion band t o hole i n the valence band, deducing from data of temperature dep- endence of bandgap f o r GaSb together with A1 composition dependence of t h a t f o r the ternary a1 loy systemC28-301.

And i n addition,

I$

can be ascribed t o

r a d i a t i v e recombination due t o a tran-

^1.40 1.44 1 . 4 1.52

s i t i o n of f r e e electron i n t o an accep-

WAVELENGTH ( pm)

t o r level EA located a t about 27meV

above the valence band. This value Fig. 14.

PL

spectra a t 77 and 4.2K

o f

an i s interpreted with the acceptor level A1 0.07Ga0. 93Sb epilayer grown a t 450°C.

deduced from the e l e c t r i c a l measure-

ments.

(9)

PHOTON ENERGY (eV )

0.900 0.850 0.800

- !

-

>

t V)

z

r

f

U W

z W

S:

W

I

e 3

P

1.40 1.50

WAVELENGTH ( pm )

Table I 1 Sunnary of emission peak energies and proposed mechanisms for PL spectra of Alpl-,Sb with ~ 2 0 . 0 7 .

A 7K 77K

Emission

eE:k

band ( e V Y Mechanism band e g k ( e ~ ? Mechanism Ix 0.873 Free exciton IO 0.870 d i r e c t band to

band 1, 0.870 Exciton bound to 1; 0.842 Free to shallbw

neutral acceptor acceptor

I, 0.844 0-A pair(donor- shallow acceptor)

I b 0.815 0-A pair(donor-

deep acceptor?)

A t 4.2K, t h e emission i n t e n s i t y o f I 1 band increases strong1 y w i t h i n c r e a s i n g t h e e x c i t a t i o n i n t e n s i t y b u t no displacement o f t h e emission peak energy i s observed, and i n a d d i t i o n , t h e emis- s i o n i n t e n s i t y of I 1 i s s t r o n g l y dependent on TG:

t h e I 1 i n t e n s i t y of an e p i l a y e r grown a t T~=400'C i s r e l a t i v e l v s t r o n s e r than t h a t o f an e ~ i l a v e r Fig. 15. PL spectra a t 77K a t TG=%O'C whose c a r r i e r c o n c e n t r a t i o n i s h i g h e r by about one order i n magnitude than t h a t grown a t

Of A1xGal-xSb at various T~=400'C. Further, t h e I 1 i n t e n s i t y i s d r a s t i c a l -

temperatures

.

l y reduced a t above 4.2K. These observations

s t r o n g l y suggest t h a t t h e I 1 band i s due t o r a d i - a t i v e recombination from e x c i t o n bound t o n e u t r a l acceptor, c o n s i d e r i n g t h a t t h e e p i l a y e r s a r e p-type. S i m i l a r c a r r i e r c o n c e n t r a t i o n dependence on emission i n t e n s i t y o f bound e x c i t o n complex t o our r e s u l t s has been observed i n GaAs[31]. The r e l a t i v e l y broad emission band o f I 1 would be ascribed t o f l u c t u a t i o n o f energy s t a t e due t o perturbed d i s o r d e r arrangement o f t h e c o n s t i t u e n t group-I11 atoms i n t h e l a t t i c e .

The b i n d i n g energy of f r e e e x c i t o n , Eex f o r A10.07Ga0.93Sb can be estimated t o be Eex-3meV by e x t r a p o l a t i n g p h y s i c a l constants f o r each b i n a r y compound[23]. I f t h e h i g h e s t energy emission band Ix l o c a t e d a t 0.873eV i s assumed t o be due t o f r e e e x c i t o n emission, t h e band gap energy EG a t 4.2K f o r t h e a l l o y e p i l a y e r i s evaluated t o be 0.876eV which i s s m a l l e r by about 15meV than t h a t deduced from PL data r e p o r t e d by A l l e g r e e t a1 .[28]. This r e l a t i v e l y l a r g e discrepancy i n t h e energy gap i s n o t c l e a r , b u t i t would be caused by t h e p o s s i b i l i t y t h a t t h e A1 composition r a t e d e t e r - mined by an X-ray d i f f r a c t i o n technique s l i g h t l y d i f f e r s from the r a t e o f the a c t u a l e p i l a y e r . Using EA, Eex, and EG thus estimated, we can c a l c u l a t e t h e b i n d i n g energy o f 11. From an e f f e c t i v e mass arguments developed by Hopfield[27], t h e photon energy e m i t t e d by r a d i a t i v e recombination o f e x c i t o n bound n e u t r a l acceptor, E(AO,X) i s g i v e n by a f o l l o w i n g e q u a t i o n : E(A0,X) = E G - E e x - 0 . 0 6 E ~

where t h e e l e c t r o n mass, me and t h e h o l e mass, mh f o r A10.07Ga0.93Sb i s taken as 0.0476mo and 0.479mo[23] (mo i s f r e e e l e c t r o n mass), r e s p e c t i v e l y . Then, the c a l - c u l a t e d value f o r E(A0,X) i s 0.871eV which i s i n good agreement w i t h t h e peak energy of 11.

As f o r I,observed a t 4.2K, we can assign i t as t h e D-A p a i r emission because the emission peak p o s i t i o n i s s l i g h t l y d i s p l a c e d t o h i g h e r energy as t h e e x c i t a t i o n i n t e n s i t y increases. Although t h e emission i n t e n s i t i e s o f I b among t h e samples i s too weak t o c h a r a c t e r i z e the emission mechanism, i t i s presumably a r i s e d from t h e D-A p a i r emission where t h e r e l a t e d acceptor i s deep one w i t h an a c t i v a t i o n energy of around 50 t o 60meV. Table I 1 shows the summary o f t h e peak energies and t h e

proposed mechanisms o f each l i n e observed by t h e PL measurements.

(10)

4. Conclusions.

-

The experimental r e s u l t s o b t a i n e d i n t h i s work can be summarized i n t h e f o l l w i n g :

( i ) The morphology and t h e growth r a t e o f AlGa(As)Sb e p i l a y e r s a r e g r e a t l y a f f e c t - ed by t h e GaSb s u b s t r a t e p r e p a r a t i o n processes when growing a t a low tempera- t u r e o f 400 o r 450°C. A heat c l e a n i n g process a t 500 o r 550°C j u s t p r i o r t o t h e low temperature growth gives t h e e x c e l l e n t e p i l a y e r s .

( i i ) I n t e r f a c e i n s t a b i l i t y can be avoided by l o w e r i n g TG. A t T~=540"C, t h e l a r g e s t A1 -composi t i o n r a t e f o r a t e r n a r y l a y e r w i t h o u t t h e i n s t a b i l i t y i s around 0.64, whereas i t f o r a quaternary l a y e r extends t o about 0.78.

( i i i ) Lowering the growth temperature c o n t r i b u t e s s i g n i f i c a n t l y t o r e d u c t i o n i n

c a r r i e r concentration: p-l 018cm-3 a t T~=600'C whereas p-8xl015cm-3 a t T ~ = 4 0 0 ~ C . ( i v ) PL spectra o f Alr).07Gao.g3Sb show f o u r emission bands a t 4.2K. Ix a t 0.873eV,

I 1 a t 0.870eVY Ia a t 0.844eVY and I b a t 0.815eV a r e presumably a r i s e d from f r e e e x c i ton, e x c i t o n bound t o n e u t r a l acceptor, donor-shallow acceptor p a i r , and donor-deep acceptor p a i r , r e s p e c t i v e l y . A t 77K, band-to-band and f r e e - t o - bound recombination a r e dominant i n t h e t e r n a r y e p i l a y e r .

Experiments w i l l be f u r t h e r continued t o o b t a i n t h e h i g h - q u a l i t y e p i l a y e r s impe- r a t i v e f o r o p t o e l e c t r o n i c device a p p l i c a t i o n s , which a l s o enables us t o e l u c i d a t e b u l k and surface p r o p e r t i e s o f AlGa(As)Sb a l l o y semiconductors

Acknowledgments.

-

The authors would l i k e t o thank A. Ohishi and E. Sogawa f o r t h e i r h e l p on growth experiments and measurements.

References

[1] SUKEGAWA T, HIRAGUCHI T, TANAKA A, and HAGINO My Appl. Phys L e t t . ,

32

(1978) 376.

[2] LAW H D ,HARRIS J r . J S

,

WONG K C

,

and TOMASETTA L R

,

I n s t . Phys. Conf. Ser.

No.45 (1979) 420.

[3] KAGAWA T, and MOTOSUGI G, Jpn. J. Appl

.

^Phys., ^j^t³^- (1979) 2317.

[4] CAPASSO F, PANISH M B, SUMSKI S, and FOY P W, Appl

.

Phys L e t t . ,

36

(1980) 165.

[5] MOTOSUGI G and KAGAWA T, Jpn. J. Appl

.

^Phys., (1980) 230.

[6] SASAKI A, NISHIUMA M, and TAKEDA Y, Jpn. J. Appl

.

^Phys., 19 (1980) 1695.

[7] KUBATA K and IKOMA T, OYO BUTSURI 50 (1981) 108 ( i n japanese ) .

[8] OHISHI A, MIZUGAKI S, TAKEDA Y,

~ ~ ~ S A S A K I

A, Trans. IECE Japan, J64-C (1981) 335 ( i n japanese ).

[9] LAW H D, CHIN R, NAKANO K, and MIRANO R A, IEEE J. Quant. Electron., QE-17 (1981 ) 275.

[ l o ]

HILDEBRAND 0, KUEBART W, BENZ K W, and PILKUHN M H, IEEE J. Quant. E l e c t r o n . , QE-17 (1981) 284.

[ll] m R and HILL C M, Appl

.

Phys. Lett.,

9

(1982) 332.

[12] TABATABAIE N, STILLMAN G E, CHIN R, and DAPKUS P D, Appl

.

Phys L e t t . ,

40

(1982) 415.

[13] SASAKI A, OHISHI A, SOGAWA E, MIZUGAKI S, TAKEDA Y, and FUJITA S, I n s t . Phys.

Conf. Ser. No.63 (1981) 83.

[ I 4 1 CAPASSO F, PANISH M 6, BONNOR W A, and SUMSKI S, I n s t . Phys. Conf. Ser. No. 56 (1980) 125.

[15] BEDAIR S M, J. Electrochem. Soc.,

122

(1975) 1150.

[ I 6 1 VAN MAU A N, ANCE C, and BOUGNOT G, J. Cryst. Growth 36 (1976) 273.

[I

71 CHENG K Y and PEARSON G L, J. Electrochem. Soc.

,

1 2 r ( 1 9 7 7 ) 753.

[ I 8 1 OSAMURA K, NAKAJIMA Ky and MURAKAMI Y, J. Electrochem. Soc.,

126

(1979) 1992.

El91 MOTOSUGI G and KAGAWA K, J. Cryst. Growth 49 (1980) 102.

[20] IMENKOV A N LIDEIKIS T P, TSARENCOV B V, SKRNYAKOV Y M, and YAKOVLEV Y P, Sov. Phys. Semicond., 10 (1976) 748.

[21] KAWASHIMA M, A b s t r a c t ofthe Annual Meeting o f Appl. Phys. $ 5 ~ - L - 1 4 Nov. (1978) ( i n japanese)

.

[22] TILLER W A, J . C r y s t . Growth

2

(1968) 69.

[231 CASEY H C and PANISH H B, i n H e t e r o s t r u c t u r e l a s e r , p a r t B, (Academic Press, New York, 1978) p.37 and references t h e r e i n .

C241 NAHORY R E, POLLACK M A, DEWINTER J C, and WILLIAMS K M y J . Appl

.

^Phys.,

48

(1977) 1607.

[25] NAKASHIMA K, Jpn. J. Appl

.

^Phys.,

20

(1981) 1085 and references t h e r e i n .

(11)

[26] CAPASSO F. HUTCHINSON A L, and BONNOR W A, 24th Annual E l e c t r o n i c M a t e r i a l s Conference Tech. D i g e s t #P-7, F o r t C o l l i n s CO. U.S.A. (1982).

1271 HOPFIELD J J, i n Proc. 7 t h I n t . Conf. on Physics on Semiconductors, Dunod, P a r i s (Academic Press, New York, 1964) p.725.

[28] ALLEGRE J, AVEROUS M, and JOULIE A, J. Lum., 7-j (1 978) 301

.

[29] BEDAIR S M, J . Appl

.

^Phys.,

47

(1976) 4145.

[30] SONOMURA H and MIYAUCHI T, J

.

^Phys

.

^D, ^Appl

.

^Phys

. ^,

13 (1 980) 667.

[31] BOGARDUS E H. and BEBB H B, Phys. Bev.,

176

(1968) 9 9 K

[32] GAUTIER P, JOULLIE A, and BOUGNOT G., J Cryst. Growth

51

(1981 ) 336.
