DETERMINATION OF THE DEGREE OF CRYSTALLITES ORIENTATION IN PERMANENT MAGNETS BY X-RAY SCATTERING AND MAGNETIC MEASUREMENTS

HAL Id: jpa-00224911

https://hal.archives-ouvertes.fr/jpa-00224911

Submitted on 1 Jan 1985

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are pub- lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

DETERMINATION OF THE DEGREE OF

CRYSTALLITES ORIENTATION IN PERMANENT MAGNETS BY X-RAY SCATTERING AND

MAGNETIC MEASUREMENTS

D. Givord, A. Liénard, R. de la Bâthie, P. Tenaud, T. Viadieu

To cite this version:

D. Givord, A. Liénard, R. de la Bâthie, P. Tenaud, T. Viadieu. DETERMINATION OF THE

DEGREE OF CRYSTALLITES ORIENTATION IN PERMANENT MAGNETS BY X-RAY SCAT-

TERING AND MAGNETIC MEASUREMENTS. Journal de Physique Colloques, 1985, 46 (C6),

pp.C6-313-C6-317. �10.1051/jphyscol:1985656�. �jpa-00224911�

DETERMINATION OF THE DEGREE OF CRYSTALLITES ORIENTATION I N PERMANENT MAGNETS BY X-RAY SCATTERING AND MAGNETIC MEASUREMENTS

D.

Givord,

Lignard,

P e r r i e r de l a Bzthie,

~ e n a u d * and T. Viadieu

X,

R6sumB - ^{Les aimants} permanents s o n t e s s e n t i e l l e m e n t des compos4s ferromagnetiques e t uniaxiaux. C e r t a i n s aimants s o n t Blabores en f r i t t a n t d e s poudres prealablement o r i e n t 6 e s e t comprim6es sous champ. La v a l e u r de l ' i n d u c t i o n remanente Br depend directement du degrd d'alignement des c r i s t a l l i t e s e t nous prgsentons dans c e t a r t i c l e deux mdthodes q u a n t i t a t i v e s d i f f e r e n t e s pour l e d8terminer.Ltanalyse aux rayons X permet de comparer l e s i n t e n s i t e s des r e f l e x i o n s de Bragg pour l e s d i f f e r e n t e s v a l e u r s de l ' a n g l e e n t r e une d i r e c t i o n [ h k l l e t l ' a x e c r i s t a l l o g r a p h i q u e p r i n c i p a l . L'analyse magnetique permet de comparer l e s courbes d'aimantation experimentales e t c e l l e s c a l c u l 8 e s , pour d i f f e r e n t e s d i s t r i b u t i o n s s t a t i s t i q u e s des o r i e n t a t i o n s des g r a i n s . Les deux methodes ont 6 t 6 appliquees & des aimants Nd-Fe-B e t SmCo5. E l l e s r e v e l e n t que l a d e s o r i e n t a t i o n des p a r t i c u l e s dans c e s systSmes conduit b une r e d u c t i o n d'environ 10 % de l ' i n d u c t i o n remanente.

Abstract - Permanent magnet compounds a r e b a s i c a l l y ferromagnets with u n i a x i a l a n i s o t r o p y . I n d i f f e r e n t c a s e s , the magnets a r e e l a b o r a t e d by s i n t e r i n g of powders previously o r i e n t e d and compressed under f i e l d . The value of t h e remanent induction Br is d i r e c t l y dependent on t h e degree of c r y s t a l l i t e s alignment, and we present i n t h i s paper two d i f f e r e n t q u a n t i t a t i v e methods t o determine i t . X-ray a n a l y s i s involves t h e comparison of t h e i n t e n s i t i e s of Bragg r e f l e c t i o n s , f o r d i f f e r e n t values of t h e angle of a d i r e c t i o n [hkl] with r e s p e c t t o the unique c r y s t a l l o g r a p h i c a x i s of t h e compound. Magnetic a n a l y s i s involves t h e comparison between experimental magnetization curves and c a l c u l a t e d ones f o r d i f f e r e n t s t a t i s t i c a l d i s t r i b u t i o n s of c r y s t a l l i t e s o r i e n t a t i o n s . Both methods were applied t o NdFeB and SmCo5 magnets. They r e v e a l t h a t t h e m i s o r i e n t a t i o n of p a r t i c l e s i n t h e s e systems l e a d s t o a r e d u c t i o n of t h e remanent induction

about 10 8 .

I - INTRODUCTION

Permanent magnet compounds a r e b a s i c a l l y ferromagnets with u n i a x i a l anisotropy. The c o e r c i v i t y of the magnets, c l o s e l y r e l a t e d t o t h i s a n i s o t r o p y , develops i n m a t e r i a l s which a r e inhomogeneous a t a microscopic s c a l e . Such a property

i n p a r t i c u l a r obtained i n f e r r i t e s and r a r e e a r t h - t r a n s i t i o n metal magnets, by s i n t e r i n g of powders previously o r i e n t e d and compressed under f i e l d . The value of t h e remanent induction

is d i r e c t l y dependent on t h e degree of c r y s t a l l i t e s alignment.

quick method t o determine a n average value of t h e i r degree of alignment c o n s i s t s i n measuring t h e remanent induction Br of t h e magnet with r e s p e c t t o t h e spontaneous induction of t h e compound / I / . We p r e s e n t i n t h i s paper a more q u a n t i t a t i v e a n a l y s i s of t h e s t a t i s t i c a l d i s t r i b u t i o n of g r a i n s o r i e n t a t i o n , which was obtained by X-ray a n a l y s i s and magnetostatic measurements, on NdFeB and SmCo5 magnets.

I1 - ^X-RAY DETERMINATION OF THE DEGREE OF G R A I N ALIGNMENT

For a r e f l e c t i o n Q k l , Bragg s c a t t e r i n g occurs i f t h e d i r e c t i o n [hkl] is along t h e s c a t t e r i n g v e c t o r K , defined a s t h e b i s s e c t r i c e of t h e angle between t h e d i r e c t i o n of the i n c i d e n t beam and t h a t of the s c a t t e r e d beam. I n a p o l y c r y s t a l l i n e sample, i n

* p a r t l y supported by a fellowship from "Aimants UGIMAG S.A.", France

JOURNAL DE PHYSIQUE

6

8 Nd-Fe-B magnet

3

i

Fig. 1 - X-ray diffractogram of a Nd-Fe-B magnet obtained with t h e Co r a d i a t i o n

1.7903

which c r y s t a l l i t e s o r i e n t a t i q n s a r e p e r f e c t l y a t random, t h e p r o b a b i l i t y f o r any d i r e c t i o n [ h k l l t o be along

c o n s t a n t . I n t h e case of a s i n g l e c r y s t a l 4 i t is necessary t o a d j u s t t h e c r y s t a l o r i e n t a t i o n i n o r d e r t o a l i g n [hkl] along K.

Permanent magnets e l a b o r a t e d by s i n t e r i n g of powders, can be,considered a s an assembly of s i n g l e c r y s t a l s , f o r which t h e c r y s t a l l o g r a p h i c c-axes, i . e . t h e d i r e c t i o n s [0011 of t h e r e c i p r o c a l space, a r e d i s t r i b u t e d w%thin a c e r t a i n s o l i d angle. I f t h e a x i s of t h e s o l i d a n g l e , z , is a l i g n e d along K,+the p r o b a b i l i t y p(w

f o r c r y s t a l l o g r a p h i c c-axes t o be along a

given d i r e c t i o n a t an angle

with r e s p e c t t o

is simply equal t o t h e p r o b a b i l i t y f o r a d i r e c t i o n Lhkl] a t an+angle whkl

from COO11 t o be along

Thus t h e compa- r i s o n of the i n t e n s i t y of a r e f l e c t i o n

[hkl], ~ ~ t o t h a t observed i n a ~ g ~ ~ ~ , p o l y c r y s ~ ! $ ~ l i n e sample, 01y, is a measu-

rement of the

along any d i r e c t i o n a t w// from

We used t h i s method t o determine t h e degree of g r a i n alignment i n Nd-Fe-B and SmCog magnets. X-ray diffractograms were recorded on s l i c e s of Nd-Fe-B permanent magnets, c u t a t d i f f e r e n t t h i c k n e s s e s p e r p e n d i c u l a r l y t o

z .

The r e s u l t s obtained show t h a t t h e degree

of g r a i n alignment is a c o n s t a n t over t h e volume of t h e magnet, except on a very t h i n s k i n of about 0.1 mm a t the s u r f a c e . Typical X-ray p a t t e r n i s presented i n f i g u r e 1 . Comparison t o the i n t e n s i t i e s measured on a non-oriented powder /2,3/ l e a d s t o t h e determination of Ima net/lpoly which i s

hkB hkl

C

p l o t t e d a s a f u n c t i o n of whkl

c V

A s shown i n f i g u r e 3, the decrease of Fig.

- ~ m a g n e t / ~ P o l Y a s f u n c t i o n of

Ib,fnet/ipoly

hkl hkl

the angle whkl between d i r e c t i o n s Lhkll hkl and C0011.

"the sample Of SmCog was kindly provided t o u s by "Aimants

S.A."

angle s m a l l e r tQan 55O with r e s p e c t t o t h e z-axis of t h e magnet. However, t h e

observation of weak r e f l e c t i o n s with w// > 45O r e v e a l s a n a d d i t i o n a l small c o n t r i b u t i o n of another gaussian with

36O, corresponding t o a much broader d i s t r i b u t i o n of c r y s t a l l i t e s o r i e n t a t i o n

(Figure 3 ) . The proportion of

approximately 15

of t h e t o t a l number of c r y s t a l l i t e s . This property can be

understood by considering

0 4000 8000

t h a t a proportion of

c r y s t a l l i t e s obtained a f t e r Fig. 3 -

dependence of t h e logarithm of grinding of t h e bulk i n g o t s normalized Bragg r e f l e c t i o n s i n Nd-Fe-B and a r e not s i n g l e c r y s t a l s . Such

SmCo5 magnets. c r y s t a l l i t e s a r e not

e f f i c i e n t l y o r i e n t e d i n t h e f i e l d a p p l i e d during the compression.

The same a n a l y s i s was performed f o r a SmCo5 magnet. The r e s u l t s a r e presented i n f i g u r e s

and 3. Very s i m i l a r r e s u l t s a r e obtained. The main gaussian d e s c r i b i n g t h e s t a t i s t i c a l d i s t r i b u t i o n of g r a i n s o r i e n t a t i o n is determined by a

14". The

accuracy of the r e s u l t s is not s u f f i c i e n t t o r e v e a l a p o s s i b l e a d d i t i o n a l contribu- t i o n from another gaussian d e s c r i b i n g a broader d i s t r i b u t i o n of g r a i n s o r i e n t a t i o n . Such a c o n t r i b u t i o n is i n any case much weaker than i n NdFeB, and suggests t h e r e f o r e t h a t , i n SmCo5 magnets, almost a l l g r a i n s can be considered a s s i n g l e c r y s t a l s .

-

DETERMINATION OF

OF GRAINS ALIGNMENT

The f i e l d dependence of t h e magnetization of an u n i a x i a l s i n g l e - c r y s t a l l i n e compound h a s been z a l c u l a t e d by N6el e t a 1

f o r any angle between t h e applied f i e l d and t h e easy c-axis. The f i r s t magnetization curve can be divided i n t o two p a r t s a s s o c i a t e d with d i f f e r e n t p h y s i c a l processes. I n low f i e l d s , t h e c r y s t a l i s

decomposed i n t o s e v e r a l domains, and t h e magnetization measured along t h e f i e l d H i s

2 2

m(4, H )

H x ~ ~ C c o s 4/HD

s i n $/(HD

HA)]

1

where MS is t h e spontaneous magnetization, HD t h e demagnetizing f i e l d f o r s a t u r a t e d magnetization and HA t h e anisotropy f i e l d . The magnetization follows t h i s law u n t i l a threshold f i e l d , Hs($), f o r which t h e c r y s t a l becomes s i n g l e domain. Above

t h e angle

between t h e magnetization and t h e easy a x i s is given by

and the magnetization measured along the f i e l d is

The c a l c u l a t e d r e c o i l magnetization curve, assuming t h a t t h e c o e r c i v i t y impedes t h e n u c l e a t i o n of r e v e r s e domains, corresponds t o t h e second process alone.

A s described i n t h e previous s e c t i o n , t h e permanent magnets considered h e r e a r e

formed of independent c r y s t a l l i t e s whose easy axes a r e d i s t r i b u t e d about a p r e f e r r e d

d i r e c t i o n

When t h e f i e l d is a p p l i e d along z , c r y s t a l l i t e s which make t h e same

angle

with r e s p e c t t o z , i . e . with r e s p e c t t o t h e f i e l d , e x h i b i t i d e n t i c a l

magnetization law. The number of C r y s t a l l i t e S between w// and w//+ is obtained

by i n t e g r a t i n g over a around t h e z-axis

JOURNAL DE PHYSIQUE

where p(wN) is t h e s t a t i s t i c a l d i s t r i b u t i o n o f c r y s t a l l i t e s . When t h e f i e l d is a p p l i e d p e r p e n d i c u l a r t o z , t h e c r y s t a l l i t e s behaving i d e n t i c a l l y make t h e same a n g l e w w i t h r e s p e c t t o t h e f i e l d . The number o f c r y s t a l l i t e s between w and

+

d d i s

I

I

w i t h w// depending on a t h r o u g h

c o s w l

s i n w// x c o s a ( 6 )

I n Both c a s e s , t h e c a l c u l a t e d m a g n e t i z a t i o n of t h e magnet is t h e r e f o r e

r r / 2

where m ( w , H) is deduced from r e l a t i o n s

t o ( 3 ) w i t h

o r Y depending whether t h e f i e l d is a l o n g o r p e r p e n d i c u l a r t o H.

S u b s e q u e n t l y , t h i s method was u s e d t o deduce t h e d e g r e e o f g r a i n s o r i e n t a t i o n from m a g n e t i c measurements. The f i e l d dependence o f t h e m a g n e t i z a t i o n f o r a Nd-Fe-B magnet, under f i e l d s a p p l i e d r e s p e c t i v e l y a l o n g z and p e r p e n d i c u l a r t o z , a r e p r e s e n t e d i n f i g u r e 4 . S a t i s f a c t o r y agreement between c a l c u l a t e d f i r s t m a g n e t i z a t i o n c u r v e s and e x p e r i m e n t a l r e s u l t s c a n b e o b t a i n e d i f c o n s i d e r i n g a unique g a u s s i a n d i s t r i b u t i o n f o r p(w//). However a b e t t e r f i t is o b t a i n e d w i t h t h e s u p e r p o s i t i o n o f

M (uem / g )

150 -

Nd-Fe-B magnet

100-

.

T=300 K

SmCog magnet

T=300 K

Fig.

- Experimental (---I and F i g . 5 - Experimental

and c a l c u l a t e d c a l c u l a t e d

m a g n e t i z a t i o n c u r v e s

m a g n e t i z a t i o n c u r v e s o f a SmCo5 o f a NdFeB magnet. C a l c u l a t i o n p a r a - magnet. C a l c u l a t i o n p a r a m e t e r s

m e t e r s

M,

150 e.m.u./g, M,

98 e.m.u./g, HA

350 kOe.

HA

7 3 k0e.

two g a u s s i a n s w i t h a

and

28O, and r e s p e c t i v e weight 90

and 10 % ( F i g u r e

The d i f f e r e n c e s between e x p e r i m e n t a l a n d c a l c u l a t e d m a g n e t i z a t i o n c u r v e s i n i n t e r m e d i a t e f i e l d s c a n b e a t t r i b u t e d t o t h e i n h o m o g e n e i t i e s o f t h e demagnetizing f i e l d i n t h e c u b i c specimen s t u d i e d , a s v e r i f i e d by measuring a n Fe sample of i d e n t i c a l s h a p e .

A

same a n a l y s i s f o r SmCog magnet is p r e s e n t e d i n f i g u r e 5. The c a l c u l a t e d c u r v e s

were o b t a i n e d f o r a main

g a u s s i a n w i t h

and a weak a d d i t i o n a l

c o n t r i b u t i o n ( 5

w i t h

30°.

obtained. The r e d u c t i o n of t h e remanent induction B,, due t o misalignment of t h e g r a i n s , reaches about 10 i n both Nd-Fe-B and SmCo5 magnets. Comparing both

methods, X-ray a n a l y s i s is more q u a n t i t a t i v e , but not a s e a s y t o r e a l i z e a s magnetic a n a l y s i s . I t is worth r e c a l l i n g t h a t t h e usual way t o determine g r a i n s o r i e n t a t i o n involves a d i r e c t measurement of B,. The r e s u l t may be a f f e c t e d by a p o s s i b l e decrease of t h e induction r e s u l t i n g from domain n u c l e a t i o n i n g r a i n s of small c o e r c i v i t y . The measurement of t h e f i r s t magnetization curve considered i n t h i s s t u d y , is obviously not a f f e c t e d by such a phenomenon. F i n a l l y , a s t r a i g h t

g e n e r a l i z a t i o n of t h i s method would permit a more q u a n t i t a t i v e a n a l y s i s of magnetic p r o p e r t i e s i n u n i a x i a l systems where s i n g l e c r y s t a l s a r e not a v a i l a b l e /3,5/.

REFERENCES

/1/ McCurrie,

Appl. Phys. 52

(1981) 73'14.

/2/

Sagawa, M., Fujimura, S., Yamamoto, H. Matsuura.

and Hiraga,

I.E.E.E.

Trans. Mag. 20 ( 5 ) (1984) 1584.

/3/ Sinnema, S.. Radwanski, R.J., Franse,

.J.M., de Mooij,

and Buschow, K.H.J., J . Magn. Magn. Mat. 44 (198'1) 333.

/'1/

Nkel, L . , Pauthenet,

Rimet, G., son, ^V.S.,

Appl. Phys. 2 Suppl.,

(1960).

/5/ DBportes, J . , T h e s i s , University of Grenoble (1977).
