HAL Id: jpa-00220724
https://hal.archives-ouvertes.fr/jpa-00220724
Submitted on 1 Jan 1981
HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are pub- lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.
L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.
A STUDY OF A NEW HETEROJUNCTION MADE OF n-TYPE SILICON AND p-TYPE AMORPHOUS
SEMICONDUCTOR
Y. Sawan, M. El-Gabaly, F. Wakim, S. Atari
To cite this version:
Y. Sawan, M. El-Gabaly, F. Wakim, S. Atari. A STUDY OF A NEW HETEROJUNCTION MADE
OF n-TYPE SILICON AND p-TYPE AMORPHOUS SEMICONDUCTOR. Journal de Physique
Colloques, 1981, 42 (C4), pp.C4-511-C4-514. �10.1051/jphyscol:19814109�. �jpa-00220724�
JOURNAL DE PHYSIQUE
CoZZoque C4, suppZ6ment au nOZO, Tome 42, octobre 1381
A STUDY O F A NEN HETEROJUNCTION MADE OF h-TYPE S I L I C O N AND p-TYPE AMORPHOUS SEMICOKDUCTOR
Y. Sawan, M. El-Gabaly, F. Wakim and S. Atari University of Kuwa;t, Kuwait
A b s t r a c t . - A p-n h e t e r o j u n c t i o n was p r e p a r e d by d e p o s i t i n g a t h i n f i l m o f p - t y p e amorphous As2Se3Cux ( X = 0 . 2 , 0 . 4 and 1 . 0 ) on n - t y p e c r y s t a l l i n e s i l i c o n w a f e r s . The I - V c h a r a c t e r i s t i c s o f t h e j u n c t i o n were t y p i c a l o f t h o s e of p-n j u n c t i o n s b o t h i n t h e d a r k and under i l l u m i n a t i o n . The p r e l i m i n a r y optimum c h a r a c t e r i s t i c s were o b t a i n e d w i t h an a n n e a l e d p-type amorphous A S ~ S ~ ~ C U ~ , ~ w i t h an o p t i c a l gap of 1 . 4 3 eV. A maximum open c i r c u i t v o l t a g e (Voc) of 0 . 3 7 V and s h o r t c i r c u i t c u r r e n t ( I s c )
2 2
o f 10 mA/cm was o b s e r v e d under s o l a r r a d i a t i o n o f 800 w/m
.
I n t r o d u c t i o n . - I n t h e amorphous A s , S e , Cu s y s t e m it was found t h a t t h e e l e c t r i c a l c o n d u c t i v i t y c a n be v a r i e d from t h a t o f an i n s u l a t o r t o a m e t a l depending on t h e c o n c e n t r a t i o n o f c o p p e r ( 1 ) . These changes i n e l e c t r i c a l c o n d u c t i v i t y a r e accompanied by s u b s t a n t i a l changes i n t h e m o b i l i t y gap which s u g g e s t s t h a t one can choose any c o n d u c t i v i t y and m o b i l i t y gap t h a t one needs o v e r a r e l a t i v e l y wide r a n g e . I n a d d i t i o n , a l l t h e c o m p o s i t i o n s s t u d i e d i n t h i s system were p-type s e m i c o n d u c t o r s .
Due t o t h e s e e n c o u r a g i n g p r o p e r t i e s , we a t t e m p t e d t o check t h e f e a s i b i l i t y o f making a s o l a r c e l l of c h a l c o g e n i d e As2Se3Cux g l a s s on c r y s t a l l i n e n - s i l i c o n h e t e r o j u n c t i o n . Not a l l t h e p a r a m e t e r s of such a j u n c t i o n can be o p t i m i z e d due t o t h e g r e a t number o f v a r i a b l e t h a t one e n c o u n t e r s . These i n c l u d e t h e c o n c e n t r a t i o n o f c o p p e r ( v a l u e of
X ) , c h a l c o g e n i d e f i l m t h i c k n e s s , t y p e of c o n t a c t , h e a t t r e a t m e n t and o t h e r s . I n t h i s p a p e r , o n l y a few p a r a m e t e r s were checked and t h e r e s u l t s were e n c o u r a g i n g b u t n o t i d e a l .
P r e p a r a t i o n and P r o p e r t i e s o f As2Se3Cux.- A p p r o p r i a t e r a t i o s o f h i g h p u r i t y A s , Se and Cu were h e a t e d i n f u s e d s i l i c a a t 9 5 0 ~ ~ under vacuum f o r a b o u t 6 h o u r s . D e t a i l e d d e s c r i p t i o n o f p r e p a r a t z o n condi- t i o n s was d e s c r i b e d e l s e w h e r e ( 2 ) . S i n c e a l l t h e t h r e e p r e p a r e d compo- s i t i o n s As2Se3Cux ( X = 0 . 2 , 0 . 4 and 1 . 0 ) c o n t a i n e d c o p p e r l e s s t h a n 28 a t . % , t h e y were a l l o b t a i n e d i n t h e amorphous s t a t e . 6 ) .
Sandwich e l e c t r o d e c o n f i g u r a t i o n w i t h two ohmic c o n t a c t s was used t o i n v e s t i g a t e t h e dark c o n d u c t i v i t i e s i n t h e t e m p e r a t u r e r a n g e 70 K up t o 400 K a t low e l e c t r i c f i e l d s o f 10-100 V/cm. Photoacousti'c t e c h n i q u e u s i n g powdered samples a s w e l l a s o p t i c a l a b s o r p t i o n t e c h - n i q u e f o r amorphous f i l m s were used t o measure t h e o p t i c a l gap Eg
( E c
-
E v ) . The r e s u l t s o f d a r k c o n d u c t i v i t y and o p t i c a l measurements f o r t h e i n v e s t i g a t e d amorphous m a t e r i a l s a r e g i v e n i n t h e f o l l o w i n gArticle published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphyscol:19814109
JOURNAL DE PHYSIQUE
t a b l e .
No. Composition a t % - l o g o / E o p t i c a l E Thermal copper 20°c (Ec
-
Ev) (Ef-
E v )S i n c e a l l copper c o n t a i n i n g samples a r e p - t y p e , t h e main c u r r e n t i s c a r r i e d o u t by h o l e s and t h e r m a l a c t i v a t i o n e n e r g y i s g i v e n by (Ef-EJ i n t h e e x p r e s s i o n :
A l l t h e c o n d u c t i v i t y v e r s u s t e m p e r a t u r e c u r v e s were found t o e x h i b i t one s l o p e i n t h e t e m p e r a t u r e r a n g e s t u d i e d . The c h o i c e of t h e s e com- p o s i t i o n s f o r t h e p r e p a r a t i o n o f t h e h e t e r o j u n c t i o n was d e c i d e d because t h e i r o p t i c a l gaps match w e l l w i t h t h e maximum s o l a r d i s t r i - b u t i o n and a t t h e same t i m e t h e i r e l e c t r i c a l c o n d u c t i v i t i e s a r e i n t e r - mediate between h i g h l y c o n d u c t i n g doped semiconductors and poor con- d u c t i n g amorphous m a t e r i a l s . A t t h e same t i m e s i n c e t h e amorphous f i l m w i l l s e r v e a s a window i n t h e h e t e r o j u n c t i o n , i t s o p t i c a l gap must be g r e a t e r t h a n t h e o p t i c a l gap o f t h e n-Si a b s o r b e r C 3 ) . P r e p a r a t i o n o f t h e H e t e r o j u n c t i o n s . - N-type c r y s t a l l i n e s i l i c o n 200.1.1m w a f e r s ( p = 1-3 ohm-cm) were e t c h e d and c l e a n e d w i t h t h e p r o p e r r e a g e n t s and t h e n d r i e d . A t h i c k aluminum f i l m was d e p o s i t e d on one s u r f a c e of t h e w a f e r s which s e r v e d a s t h e back c o n t a c t . The w a f e r s w i t h t h e aluminum c o n t a c t were a n n e a l e d i n a n i t r o g e n atmosphere a t
2 0 0 ~ ~ f o r a b o u t 30 m i n u t e s . The o t h e r s u r f a c e o f t h e s i l i c o n w a f e r s was a g a i n e t c h e d and c l e a n e d . T h i s was f o l l o w e d by d e p o s i t i n g amor- phous As3Se3Cux ( X - = 0 . 2 , 0 . 4 and 1 . 0 ) f i l m whose t h i c k n e s s ranged from 300-to 3000
X.
A t h i n t r a n s p a r e n t g o l d f i l m was t h e n d e p o s i t e d on t h e amorphous m a t e r i a l f o l l o w e d by a g o l d g r i d which s e r v e d a s a f r o n t c o n t a c t . I - V c h a r a c t e r i s t i c s f o r t h e p r e p a r e d h e t e r o j u n c t i o n s were p l o t t e d b o t h i n t h e d a r k and under i l l u m i n a t i o n . I n l a b o r a t o r y measurements a xenon lamp (1 KW power) was used a s a l i g h t s o u r c e , b u t i n some o t h e r measuremnts d i r e c t s o l a r r a d i a t i o n was used whose i n t e n s i t y was a b o u t 800 w/n2.The I - V C h a r a c t e r i s t i c s . - Although t h e I - V c h a r a c t e r i s t i c s v a r i e d from d e v i c e t o d e v i c e , a l l showed t h e same g e n e r a l b e h a v i o r . The I - V c h a r a c t e r i s t i c s were found t o be h i g h l y dependent on t h e composition of t h e amorphous window and i t s t h i c k n e s s . The b e s t i l l u m i n a t e d I - V c h a r a c t e r i s t i c s o f t h e h e t e r o j u n c t i o r s w i t h p-type amorphous l a y e r w i t h minimum copper c o n t e n t (sample 1 i n t a b l e w i t h Eg=1.5 eV and p/20°c = 5 x 1 0 8 ohm-cm) gave an open c i r c u i t v o l t a g e o f 0.26 V and s h o r t c i r c u i t c u r r e n t of 2 . 7 mA/cm 2 under l a b o r a t o r y c o n d i t i o n s (2400 w / m 2 ) . The t h i c k n e s s o f t h e amorphous l a y e r i n t h i s j u n c t i o n was a b o u t 1200 A . 0 The h e t e r o j u n c t i o n c o n t a i n i n g t h e maximum copper c o n t e n t amorphous l a y e r (sample 3 i n t a b l e w i t h Eg = 1 . 3 eV and
p / 2 0 ° ~ = 4 X 1 0 4 ohm-cm) gave under t h e same l a b o r a t o r y i l l u m i n a t i o n c o n d i t i o n s Voc = 0.24 and Isc = 2.4 mA/cm2. The t h i c k n e s s o f t h e amorphous l a y e r i n t h i s j u n c t i o n was t h e same a s i n t h e j u n c t i o n w i t h minimum Cu c o n t e n t . The b e s t i l l u m i n a t e d I - V c h a r a c t e r i s t i c s were n o t i c e d f o r t h e h e t e r o j u n c t i o n - w i t h p-type amorphous l a y e r w i t h 7 . 4 a t . % Cu (sample 2 i n t a b l e ) w i t h Eg = 1 . 4 3 eV and p/20Qc = 8 X 106 ohm-cm and a t h i c k n e s s r a n g i n g between 1200
-
1500 A . 0 These c h a r a c - t e r i s t i c s a r e g i v e n i n t h e f o l l o w i n g f i g u r e under l a b o r a t o r y i l l u m i n a - t i o n c o n d i t i o n s .(Volt
1
F i g u r e . - The d a r k ( d ) and i l l u m i n a t e d ( i ) I - V c h a r a c t e r i s t i c s of t h e p-type amorphous A S ~ S ~ ~ C U ~ . ~ -n-type c r y s t a l l i n e s i l i c o n b e f o r e a n n e a l i n g ( c u r u e s l ( d ) and l ( i ) and a f t e r a n n e a l i n g ( c u r v e s 2 ( d ) , 2 ( i ) and 3 ( i ) ) .
Area o f t h e sample = 2 . 7 cmL L i g h t i n t e n s i t y = 2400w/m 2
JOURNAL DE PHYSIQUE
I n t h i s f i g u r e t h e d a r k and i l l u m i n a t e d I - V c h a r a c t e r i s t i c s a r e g i v e n by c u r v e s l ( d ) and l ( i ) r e s p e c t i v e l y . From t h e s e c u r v e s we n o t i o e d
2 2
t h a t Voc=0.37 V and I s c = 2 3 mA/2.7cm =8.5 mA/cm
.
We b e l i e v e t h a t - -p r o p e r t h e r m a l a n n e a l i n g o f t h e j u n c t i o n may improve t h e I s c . When t h i s sample was a n n e a l e d f o r a maximum p e r i o d o f 30 min. a t 1 0 0 ~ ~ i n n i t r o g e n atmosphere we n o t i c e d l a r g e changes i n t h e I - V c h a r a c t e r i s - t i c s . T h i s i s g i v e n by c u r v e s 2 ( d ) and 2 ( i ) i n t h e f i g u r e f o r d a r k and i l l u m i n a t e d c h a r a c t e r i s t i c s r e s p e c t i v e l y . The i l l u m i n a t e d Voc was t h e same a s b e f o r e a n n e a l i n g b u t t h e I i n c r e a s e d by a f a c t o r
S C
of 3.7 a f t e r a n n e a l i n g f o r 30 min. The v a l u e o f t h e s h o r t c i r c u i t
-
c u r r e n t was 83 mA/2.7 cm = 30.7 mA/cmL
.
When t h i s sample was checked under s o l a r r a d i a t i o n o f 800 w/m2 i n t e n s i t y t h e Voc was .37 V and Isc = 10 mA/cm 2.
T h i s was t h e b e s t c h a r a c t e r i s t i c s o b t a i n e d f o r a l l t h e s t u d i e d h e t e r o j u n c t i o n s . F u r t h e r t h e r m a l a n n e a l i n g of t h i s sam- p l e f o r 30 min. a t 200°C i n n i t r o g e n atmosphere was c a r r i e d . A l a r g e d e c r e a s e i n t h e V o c a s w e l l a s i n I s c was n o t i c e d ( c u r v e 3 ( i ) i n f i g u r e ) .C o n c l u s i o n . - From t h e s e r e s u l t s , it seems f e a s i b l e t o make a hetero- j u n c t i o n s o l a r c e l l of p - t y p e amorphous As2Se3Cux and n - t y p e s i l i c o n . The i d e a l c e l l c h a r a c t e r i s t i c s w i l l depend on many v a r i a b l e s t h a t have t o be o p t i m i z e d i n d e p e n d e n t l y and c o l l e c t i v e l y , which r e q u i r e e x t e n d e d r e s e a r c h on t h i s s u b j e c t .
T h i s r e s e a r c h was s u p p o r t e d by Kuwait I n s t i t u t e f o r S c i e n t i f i c R e s e a r c h .
R e f e r e n c e s .
-
1- SAWAN Y . , BORISOVA Z.U., J . o f I n o r g a n i c M a t e r i a l , Academy o f S c i e n c e , USSR, 4 ,
12
(1968) 2089.2- SAWAN Y . , WAKIM F . G . , EL-GABALY M . and EL-RAYES M . K . , J. o f Non- c r y s t a l l i n e S o l i d s ,
%
(1980) 319.3- FONASH S . J . , ASHOK S . , P r o c e e d i n g s o f t h e 1 4 t h P h o t o v o l t a i c s S p e c i a l i s t s C o n f e r e n c e , I E E E N . Y . , N . Y . (1980) 591.
