(2) Conversion Factors from BG to SI Units. Acceleration. To convert from. To. Multiply by. ft/s2. m/s2. 0.3048. 2. 2. Area. ft mi2 acres. m m2 m2. 9.2903 E 2 2.5900 E 6 4.0469 E 3. Density. slug/ft3 lbm/ft3. kg/m3 kg/m3. 5.1538 E 2 1.6019 E 1. Energy. ft-lbf Btu cal. J J J. 1.3558 1.0551 E 3 4.1868. Force. lbf kgf. N N. 4.4482 9.8067. Length. ft in mi (statute) nmi (nautical). m m m m. 0.3048 2.5400 E 2 1.6093 E 3 1.8520 E 3. Mass. slug lbm. kg kg. 1.4594 E 1 4.5359 E 1. Mass flow. slug/s lbm/s. kg/s kg/s. 1.4594 E 1 4.5359 E 1. Power. ftlbf/s hp. W W. 1.3558 7.4570 E 2.

(3) Conversion Factors from BG to SI Units (Continued) To convert from. To. Multiply by. Pressure. lbf/ft2 lbf/in2 atm mm Hg. Pa Pa Pa Pa. 4.7880 6.8948 1.0133 1.3332. Specific weight. lbf/ft3. N/m3. 1.5709 E 2. Specific heat. ft2/(s2R). m2/(s2K). 1.6723 E 1. Surface tension. lbf/ft. N/m. 1.4594 E 1. Temperature. F R. C K. tC 59(tF 32) 0.5556. Velocity. ft/s mi/h knot. m/s m/s m/s. 0.3048 4.4704 E 1 5.1444 E 1. Viscosity. lbfs/ft2 g/(cms). Ns/m2 Ns/m2. 4.7880 E 1 0.1. Volume. ft3 L gal (U.S.) fluid ounce (U.S.). m3 m3 m3 m3. 2.8317 E 2 0.001 3.7854 E 3 2.9574 E 5. Volume flow. ft3/s gal/min. m3/s m3/s. 2.8317 E 2 6.3090 E 5. E1 E3 E5 E2.

(4) EQUATION SHEET Ideal-gas law: p RT, Rair 287 J/kg-K. 1 Surface tension: p Y(R1 1 R2 ). Hydrostatics, constant density:. Hydrostatic panel force: F hCGA,. p2 p1 (z2 z1), g. yCP Ixxsin /(hCG A), xCP Ixy sin /(hCG A) CV mass: d/dt( CV d ) g(AV)out. Buoyant force: FB fluid(displaced volume) CV momentum: d/dt1 CV Vd 2. g 3 (AV )V 4 out g 3 (AV )V 4 in g F Steady flow energy: (p/V 2/2gz)in . g (AV)in 0 CV angular momentum: d/dt( CV (r0 V)d ) g AV(r0V)out g AV(r0V)in g M 0 Acceleration: dV/dt V/t. (p/V2/2gz)out hfriction hpump hturbine. u(V/x) v(V/y) w(V/z). Incompressible continuity: V 0. Navier-Stokes: (dV/dt)gp 2V. Incompressible stream function (x,y):. Velocity potential (x, y, z):. u /y;. v /x. Bernoulli unsteady irrotational flow: /t dp/ V 2/2 gz Const Pipe head loss: hf f(L /d)V 2/(2g) where f Moody chart friction factor Laminar flat plate flow: /x 5.0/Re1/2 x , cf 0.664/Re1/2 x ,. CD 1.328/Re1/2 L. CD Drag/1 12V 2A2; CL Lift/1 12V2A2. Isentropic flow: T0 /T 1 5(k1)/26Ma2, 0/ (T0/T)1/(k1),. p0 /p (T0/T)k(k1). Prandtl-Meyer expansion: K (k1)/(k1), K1/2tan1[(Ma21)/K]1/2tan1(Ma21)1/2 Gradually varied channel flow: dy/dx (S0 S)/(1 Fr2), Fr V/Vcrit. u /x; v /y; w /z Turbulent friction factor: 1/ 1f . 2.0 log10 3

(5) /(3.7d) 2.51/1Red 1f)4. Orifice, nozzle, venturi flow: QCdAthroat 3 2 p/5(1 4)6 4 1/2, d/D Turbulent flat plate flow: /x 0.16/Re1/7 x , 1/7 cf 0.027/Re1/7 x , C D 0.031/Re L. 2-D potential flow: 2 2 0 One-dimensional isentropic area change: A/A*(1/Ma)[1{(k1)/2}Ma2](1/2)(k1)/(k1) Uniform flow, Manning’s n, SI units: V0(m/s) (1.0/n) 3 Rh(m) 4 2/3S1/2 0 Euler turbine formula: Power Q(u2Vt2 u1Vt1), u r.

(6) This page intentionally left blank.

(7) whi29346_fm_i-xvi.qxd. 12/14/09. 7:09PM. Page i ntt 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Fluid Mechanics.

(8) whi29346_fm_i-xvi.qxd. 12/14/09. 7:09PM. Page ii ntt 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. McGraw-Hill Series in Mechanical Engineering Alciatore/Histand Introduction to Mechatronics and Measurement Systems Anderson Computational Fluid Dynamics: The Basics with Applications Anderson Fundamentals of Aerodynamics Anderson Introduction to Flight Anderson Modern Compressible Flow Beer/Johnston Vector Mechanics for Engineers: Statics and Dynamics Beer/Johnston Mechanics of Materials Budynas Advanced Strength and Applied Stress Analysis Budynas/Nisbett Shigley’s Mechanical Engineering Design Çengel Heat and Mass Transfer: A Practical Approach Çengel Introduction to Thermodynamics & Heat Transfer Çengel/Boles Thermodynamics: An Engineering Approach Çengel/Cimbala Fluid Mechanics: Fundamentals and Applications Çengel/Turner Fundamentals of Thermal-Fluid Sciences Dieter Engineering Design: A Materials & Processing Approach Dieter Mechanical Metallurgy Dorf/Byers Technology Ventures: From Idea to Enterprise Finnemore/Franzini Fluid Mechanics with Engineering Applications. Hamrock/Schmid/Jacobson Fundamentals of Machine Elements Heywood Internal Combustion Engine Fundamentals Holman Experimental Methods for Engineers Holman Heat Transfer Kays/Crawford/Weigand Convective Heat and Mass Transfer Meirovitch Fundamentals of Vibrations Norton Design of Machinery Palm System Dynamics Reddy An Introduction to Finite Element Method Schey Introduction to Manufacturing Processes Smith/Hashemi Foundations of Materials Science and Engineering Turns An Introduction to Combustion: Concepts and Applications Ugural Mechanical Design: An Integrated Approach Ullman The Mechanical Design Process White Fluid Mechanics White Viscous Fluid Flow.

(9) whi29346_fm_i-xvi.qxd. 12/14/09. 7:09PM. Page iii ntt 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Fluid Mechanics Seventh Edition. Frank M. White University of Rhode Island.

(10) whi29346_fm_i-xvi.qxd. 12/30/09. 1:16PM. Page iv ntt 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. FLUID MECHANICS, SEVENTH EDITION Published by McGraw-Hill, a business unit of The McGraw-Hill Companies, Inc., 1221 Avenue of the Americas, New York, NY 10020. Copyright © 2011 by The McGraw-Hill Companies, Inc. All rights reserved. Previous editions © 2008, 2003, and 1999. No part of this publication may be reproduced or distributed in any form or by any means, or stored in a database or retrieval system, without the prior written consent of The McGraw-Hill Companies, Inc., including, but not limited to, in any network or other electronic storage or transmission, or broadcast for distance learning. Some ancillaries, including electronic and print components, may not be available to customers outside the United States. This book is printed on acid-free paper. 1 2 3 4 5 6 7 8 9 0 DOC/DOC 1 0 9 8 7 6 5 4 3 2 1 0 ISBN 978-0-07-352934-9 MHID 0-07-352934-6 Vice President & Editor-in-Chief: Marty Lange Vice President, EDP/Central Publishing Services: Kimberly Meriwether-David Global Publisher: Raghothaman Srinivasan Senior Sponsoring Editor: Bill Stenquist Director of Development: Kristine Tibbetts Developmental Editor: Lora Neyens Senior Marketing Manager: Curt Reynolds Senior Project Manager: Lisa A. Bruflodt Production Supervisor: Nicole Baumgartner Design Coordinator: Brenda A. Rolwes Cover Designer: Studio Montage, St. Louis, Missouri (USE) Cover Image: Copyright SkySails Senior Photo Research Coordinator: John C. Leland Photo Research: Emily Tietz/Editorial Image, LLC Compositor: Aptara, Inc. Typeface: 10/12 Times Roman Printer: R. R. Donnelley All credits appearing on page or at the end of the book are considered to be an extension of the copyright page. Library of Congress Cataloging-in-Publication Data White, Frank M. Fluid mechanics / Frank M. White. —7th ed. p. cm. — (Mcgraw-Hill series in mechanical engineering) Includes bibliographical references and index. ISBN 978–0–07–352934–9 (alk. paper) 1. Fluid mechanics. I. Title. TA357.W48 2009 620.1’06—dc22 2009047498 www.mhhe.com.

(11) whi29346_fm_i-xvi.qxd. 12/14/09. 7:09PM. Page v ntt 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. About the Author. Frank M. White is Professor Emeritus of Mechanical and Ocean Engineering at the University of Rhode Island. He studied at Georgia Tech and M.I.T. In 1966 he helped found, at URI, the first department of ocean engineering in the country. Known primarily as a teacher and writer, he has received eight teaching awards and has written four textbooks on fluid mechanics and heat transfer. From 1979 to 1990 he was editor-in-chief of the ASME Journal of Fluids Engineering and then served from 1991 to 1997 as chairman of the ASME Board of Editors and of the Publications Committee. He is a Fellow of ASME and in 1991 received the ASME Fluids Engineering Award. He lives with his wife, Jeanne, in Narragansett, Rhode Island.. v.

(12) whi29346_fm_i-xvi.qxd. 12/14/09. 7:09PM. Page vi ntt 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. To Jeanne.

(13) whi29346_fm_i-xvi.qxd. 12/14/09. 7:09PM. Page vii ntt 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Contents. Preface. xi. Chapter 1 Introduction 3 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 1.10 1.11 1.12 1.13 1.14. Preliminary Remarks 3 History and Scope of Fluid Mechanics 4 Problem-Solving Techniques 6 The Concept of a Fluid 6 The Fluid as a Continuum 8 Dimensions and Units 9 Properties of the Velocity Field 17 Thermodynamic Properties of a Fluid 18 Viscosity and Other Secondary Properties 25 Basic Flow Analysis Techniques 40 Flow Patterns: Streamlines, Streaklines, and Pathlines 41 The Engineering Equation Solver 46 Uncertainty in Experimental Data 46 The Fundamentals of Engineering (FE) Examination 48 Problems 49 Fundamentals of Engineering Exam Problems 57 Comprehensive Problems 58 References 61. Chapter 2 Pressure Distribution in a Fluid 65 2.1 2.2 2.3 2.4. Pressure and Pressure Gradient 65 Equilibrium of a Fluid Element 67 Hydrostatic Pressure Distributions 68 Application to Manometry 75. 2.5 2.6 2.7 2.8 2.9 2.10. Hydrostatic Forces on Plane Surfaces 78 Hydrostatic Forces on Curved Surfaces 86 Hydrostatic Forces in Layered Fluids 89 Buoyancy and Stability 91 Pressure Distribution in Rigid-Body Motion 97 Pressure Measurement 105 Summary 109 Problems 109 Word Problems 132 Fundamentals of Engineering Exam Problems 133 Comprehensive Problems 134 Design Projects 135 References 136. Chapter 3 Integral Relations for a Control Volume 139 3.1 3.2 3.3 3.4 3.5 3.6 3.7. Basic Physical Laws of Fluid Mechanics 139 The Reynolds Transport Theorem 143 Conservation of Mass 150 The Linear Momentum Equation 155 Frictionless Flow: The Bernoulli Equation 169 The Angular Momentum Theorem 178 The Energy Equation 184 Summary 195 Problems 195 Word Problems 224 Fundamentals of Engineering Exam Problems 224 Comprehensive Problems 226 Design Project 227 References 227 vii.

(14) whi29346_fm_i-xvi.qxd. viii. 12/14/09. 7:09PM. Page viii ntt 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Contents. Chapter 4 Differential Relations for Fluid Flow 229 4.1 4.2 4.3 4.4 4.5 4.6 4.7 4.8 4.9 4.10. The Acceleration Field of a Fluid 230 The Differential Equation of Mass Conservation 232 The Differential Equation of Linear Momentum 238 The Differential Equation of Angular Momentum 244 The Differential Equation of Energy 246 Boundary Conditions for the Basic Equations 249 The Stream Function 253 Vorticity and Irrotationality 261 Frictionless Irrotational Flows 263 Some Illustrative Incompressible Viscous Flows 268 Summary 276 Problems 277 Word Problems 288 Fundamentals of Engineering Exam Problems 288 Comprehensive Problems 289 References 290. Chapter 5 Dimensional Analysis and Similarity 5.1 5.2 5.3 5.4 5.5. Introduction 298 The Principle of Dimensional Homogeneity 296 The Pi Theorem 302 Nondimensionalization of the Basic Equations 312 Modeling and Its Pitfalls 321 Summary 333 Problems 333 Word Problems 342 Fundamentals of Engineering Exam Problems 342 Comprehensive Problems 343 Design Projects 344 References 344. Chapter 6 Viscous Flow in Ducts 6.1 6.2 6.3 6.4 6.5. 293. 347. Reynolds Number Regimes 347 Internal versus External Viscous Flow 352 Head Loss—The Friction Factor 355 Laminar Fully Developed Pipe Flow 357 Turbulence Modeling 359. 6.6 6.7 6.8 6.9 6.10 6.11 6.12. Turbulent Pipe Flow 365 Four Types of Pipe Flow Problems 373 Flow in Noncircular Ducts 379 Minor or Local Losses in Pipe Systems 388 Multiple-Pipe Systems 397 Experimental Duct Flows: Diffuser Performance 403 Fluid Meters 408 Summary 429 Problems 430 Word Problems 448 Fundamentals of Engineering Exam Problems 449 Comprehensive Problems 450 Design Projects 452 References 453. Chapter 7 Flow Past Immersed Bodies 457 7.1 7.2 7.3 7.4 7.5 7.6. Reynolds Number and Geometry Effects 457 Momentum Integral Estimates 461 The Boundary Layer Equations 464 The Flat-Plate Boundary Layer 467 Boundary Layers with Pressure Gradient 476 Experimental External Flows 482 Summary 509 Problems 510 Word Problems 523 Fundamentals of Engineering Exam Problems 524 Comprehensive Problems 524 Design Project 525 References 526. Chapter 8 Potential Flow and Computational Fluid Dynamics 8.1 8.2 8.3 8.4 8.5 8.6 8.7 8.8 8.9. 529. Introduction and Review 529 Elementary Plane Flow Solutions 532 Superposition of Plane Flow Solutions 539 Plane Flow Past Closed-Body Shapes 545 Other Plane Potential Flows 555 Images 559 Airfoil Theory 562 Axisymmetric Potential Flow 574 Numerical Analysis 579.

(15) whi29346_fm_i-xvi.qxd. 12/14/09. 7:09PM. Page ix ntt 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Contents ix Summary 593 Problems 594 Word Problems 604 Comprehensive Problems 605 Design Projects 606 References 606. Chapter 9 Compressible Flow 609 9.1 9.2 9.3 9.4 9.5 9.6 9.7 9.8 9.9 9.10. Introduction: Review of Thermodynamics 609 The Speed of Sound 614 Adiabatic and Isentropic Steady Flow 616 Isentropic Flow with Area Changes 622 The Normal Shock Wave 629 Operation of Converging and Diverging Nozzles 637 Compressible Duct Flow with Friction 642 Frictionless Duct Flow with Heat Transfer 654 Two-Dimensional Supersonic Flow 659 Prandtl-Meyer Expansion Waves 669 Summary 681 Problems 682 Word Problems 695 Fundamentals of Engineering Exam Problems 696 Comprehensive Problems 696 Design Projects 698 References 698. Chapter 10 Open-Channel Flow 701 10.1 10.2 10.3 10.4 10.5 10.6. Introduction 701 Uniform Flow: The Chézy Formula 707 Efficient Uniform-Flow Channels 712 Specific Energy: Critical Depth 714 The Hydraulic Jump 722 Gradually Varied Flow 726. 10.7. Flow Measurement and Control by Weirs 734 Summary 741 Problems 741 Word Problems 754 Fundamentals of Engineering Exam Problems 754 Comprehensive Problems 754 Design Projects 756 References 756. Chapter 11 Turbomachinery 11.1 11.2 11.3 11.4 11.5 11.6. 759. Introduction and Classification 759 The Centrifugal Pump 762 Pump Performance Curves and Similarity Rules 768 Mixed- and Axial-Flow Pumps: The Specific Speed 778 Matching Pumps to System Characteristics 785 Turbines 793 Summary 807 Problems 807 Word Problems 820 Comprehensive Problems 820 Design Project 822 References 822. Appendix A Physical Properties of Fluids Appendix B Compressible Flow Tables Appendix C Conversion Factors. 824 829. 836. Appendix D Equations of Motion in Cylindrical Coordinates Answers to Selected Problems 840 Index 847. 838.


(17) whi29346_fm_i-xvi.qxd. 12/14/09. 7:09PM. Page xi ntt 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Preface. General Approach. The seventh edition of Fluid Mechanics sees some additions and deletions but no philosophical change. The basic outline of eleven chapters, plus appendices, remains the same. The triad of integral, differential, and experimental approaches is retained. Many problem exercises, and some fully worked examples, have been changed. The informal, student-oriented style is retained. A number of new photographs and figures have been added. Many new references have been added, for a total of 435. The writer is a firm believer in “further reading,” especially in the postgraduate years.. Learning Tools. The total number of problem exercises continues to increase, from 1089 in the first edition, to 1675 in this seventh edition. There are approximately 20 new problems added to each chapter. Most of these are basic end-of-chapter problems, classified according to topic. There are also Word Problems, multiple-choice Fundamentals of Engineering Problems, Comprehensive Problems, and Design Projects. The appendix lists approximately 700 Answers to Selected Problems. The example problems are structured in the text to follow the sequence of recommended steps outlined in Sect. 1.3, Problem-Solving Techniques. The Engineering Equation Solver (EES) is available with the text and continues its role as an attractive tool for fluid mechanics and, indeed, other engineering problems. Not only is it an excellent solver, but it also contains thermophysical properties, publication-quality plotting, units checking, and many mathematical functions, including numerical integration. The author is indebted to Sanford Klein and William Beckman, of the University of Wisconsin, for invaluable and continuous help in preparing and updating EES for use in this text. For newcomers to EES, a brief guide to its use is found on this book’s website.. Content Changes. There are some revisions in each chapter. Chapter 1 has added material on the history of late 20th century fluid mechanics, notably the development of Computational Fluid Dynamics. A very brief introduction to the acceleration field has been added. Boundary conditions for slip flow have been added. There is more discussion of the speed of sound in liquids. The treatment of thermal conductivity has been moved to Chapter 4. xi.

(18) whi29346_fm_i-xvi.qxd. xii. 12/14/09. 7:09PM. Page xii ntt 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Preface. Chapter 2 introduces a photo, discussion, and new problems for the deep ocean submersible vehicle, ALVIN. The density distribution in the troposphere is now given explicitly. There are brief remarks on the great Greek mathematician, Archimedes. Chapter 3 has been substantially revised. Reviewers wanted Bernoulli’s equation moved ahead of angular velocity and energy, to follow linear momentum. I did this and followed their specific improvements, but truly extensive renumbering and rearranging was necessary. Pressure and velocity conditions at a tank surface have an improved discussion. A brief history of the control volume has been added. There is a better treatment of the relation between Bernoulli’s equation and the energy equation. There is a new discussion of stagnation, static and dynamic pressures, and boundary conditions at a jet exit. Chapter 4 has a great new opener: CFD for flow past a spinning soccer ball. The total time derivative of velocity is now written out in full. Fourier’s Law, and its application to the differential energy equation, have been moved here from Chapter 1. There are 21 new problems, including several slip-flow analyses. The Chapter 5 introduction expands on the effects of Mach number and Froude number, instead of concentrating only on the Reynolds number. Ipsen’s method, which the writer admires, is retained as an alternative to the pi theorem. The new opener, a giant disk-band-gap parachute, allows for several new dimensional analysis problems. Chapter 6 has a new formula for entrance length in turbulent duct flow, sent to me by two different researchers. There is a new problem describing the flow in a fuel cell. The new opener, the Trans-Alaska Pipeline, allows for several innovative problems, including a related one on the proposed Alaska-Canada natural gas pipeline. Chapter 7 has an improved description of turbulent flow past a flat plate, plus recent reviews of progress in turbulence modeling with CFD. Two new aerodynamic advances are reported: the Finaish-Witherspoon redesign of the Kline-Fogelman airfoil and the increase in stall angle achieved by tubercles modeled after a humpback whale. The new Transition® flying car, which had a successful maiden flight in 2009, leads to a number of good problem assignments. Two other photos, Rocket Man over the Alps, and a cargo ship propelled by a kite, also lead to interesting new problems. Chapter 8 is essentially unchanged, except for a bit more discussion of modern CFD software. The Transition® autocar, featured in Chapter 7, is attacked here by aerodynamic theory, including induced drag. Chapter 9 benefited from reviewer improvement. Figure 9.7, with its 30-year-old curve-fits for the area ratio, has been replaced with fine-gridded curves for the areachange properties. The curve-fits are gone, and Mach numbers follow nicely from Fig. 9.7 and either Excel or EES. New Trends in Aeronautics presents the X-43 Scramjet airplane, which generates several new problem assignments. Data for the proposed Alaska-to-Canada natural gas pipeline provides a different look at frictional choking. Chapter 10 is basically the same, except for new photos of both plane and circular hydraulic jumps, plus a tidal bore, with their associated problem assignments. Chapter 11 has added a section on the performance of gas turbines, with application to turbofan aircraft engines. The section on wind turbines has been updated, with new data and photos. A wind-turbine-driven vehicle, which can easily move directly into the wind, has inspired new problem assignments..

(19) whi29346_fm_i-xvi.qxd. 12/14/09. 7:09PM. Page xiii ntt 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Preface. xiii. Appendix A has new data on the bulk modulus of various liquids. Appendix B, Compressible Flow Tables, has been shortened by using coarser increments (0.1) in Mach number. Tables with much smaller increments are now on the bookswebsite. Appendix E, Introduction to EES, has been deleted and moved to the website, on the theory that most students are now quite familiar with EES.. Online Supplements. A number of supplements are available to students and/or instructors at the text website www.mhhe.com/white7e. Students have access to a Student Study Guide developed by Jerry Dunn of Texas A&M University. They are also able to utilize Engineering Equation Solver (EES), fluid mechanics videos developed by Gary Settles of Pennsylvania State University, and CFD images and animations prepared by Fluent Inc. Also available to students are Fundamentals of Engineering (FE) Exam quizzes, prepared by Edward Anderson of Texas Tech University. Instructors may obtain a series of PowerPoint slides and images, plus the full Solutions Manual, in PDF format. The Solutions Manual provides complete and detailed solutions, including problem statements and artwork, to the end-of-chapter problems. It may be photocopied for posting or preparing transparencies for the classroom. Instructors can also obtain access to C.O.S.M.O.S. for the seventh edition. C.O.S.M.O.S. is a Complete Online Solutions Manual Organization System instructors can use to create exams and assignments, create custom content, and edit supplied problems and solutions.. Electronic Textbook Options. Ebooks are an innovative way for students to save money and create a greener environment at the same time. An ebook can save students about half the cost of a traditional textbook and offers unique features like a powerful search engine, highlighting, and the ability to share notes with classmates using ebooks. McGraw-Hill offers this text as an ebook. To talk about the ebook options, contact your McGraw-Hill sales rep or visit the site www.coursesmart.com to learn more..

(20) whi29346_fm_i-xvi.qxd. 12/14/09. 7:09PM. Page xiv ntt 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Acknowledgments. xiv. As usual, so many people have helped me that I may fail to list them all. Sheldon Green of the University of British Columbia, Gordon Holloway of the University of New Brunswick, Sukanta K. Dash of The Indian Institute of Technology at Kharagpur, and Pezhman Shirvanian of Ford Motor Co. gave many helpful suggestions. Hubert Chanson of the University of Queensland, Frank J. Cunha of Pratt&Whitney, Samuel Schweighart of Terrafugia Inc., Mark Spear of the Woods Hole Oceanographic Institution, Keith Hanna of ANSYS Inc., Elena Mejia of the Jet Propulsion Laboratory, Anne Staack of SkySails, Inc., and Ellen Emerson White provided great new images. Samuel S. Sih of Walla Walla College, Timothy Singler of SUNY Binghamton, Saeed Moaveni of Minnesota State University, and John Borg of Marquette University were especially helpful with the solutions manual. The following prereviewers gave many excellent suggestions for improving the manuscript: Rolando Bravo of Southern Illinois University; Joshua B. Kollat of Penn State University; Daniel Maynes of Brigham Young University; Joseph Schaefer of Iowa State University; and Xiangchun Xuan of Clemson University. In preparation, the writer got stuck on Chapter 3 but was rescued by the following reviewers: Serhiy Yarusevych of the University of Waterloo; H. Pirouz Kavehpour and Jeff Eldredge of the University of California, Los Angeles; Rayhaneh Akhavan of the University of Michigan; Soyoung Steve Cha of the University of Illinois, Chicago; Georgia Richardson of the University of Alabama; Krishan Bhatia of Rowan University; Hugh Coleman of the University of Alabama-Huntsville; D.W. Ostendorf of the University of Massachusetts; and Donna Meyer of the University of Rhode Island. The writer continues to be indebted to many others who have reviewed this book over the various years and editions. Many other reviewers and correspondents gave good suggestions, encouragement, corrections, and materials: Elizabeth J. Kenyon of MathWorks; Juan R. Cruz of NASA Langley Research Center; LiKai Li of University of Science and Technology of China; Tom Robbins of National Instruments; Tapan K. Sengupta of the Indian Institute of Technology at Kanpur; Paulo Vatavuk of Unicamp University; Andris Skattebo of Scandpower A/S; Jeffrey S. Allen of Michigan Technological University; Peter R. Spedding of Queen’s University, Belfast, Northern Ireland; Iskender Sahin of Western Michigan University; Michael K. Dailey of General Motors; Cristina L. Archer of Stanford University; Paul F. Jacobs of Technology Development Associates; Rebecca CullionWebb of the University of Colorado at Colorado Springs; Debendra K. Das of the University of Alaska Fairbanks; Kevin O’Sullivan and Matthew Lutts of the Associated.

(21) whi29346_fm_i-xvi.qxd. 12/14/09. 7:09PM. Page xv ntt 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Acknowledgments. xv. Press; Lennart Lu¨ttig and Nina Koliha of REpower Systems AG, Hamburg, Germany; Chi-Yang Cheng of ANSYS Inc.; Debabrata Dasgupta of The Indian Institute of Technology at Kharagpur; Fabian Anselmet of the Institut de Recherche sur les Phenomenes Hors Equilibre, Marseilles; David Chelidze, Richard Lessmann, Donna Meyer, Arun Shukla, Peter Larsen, and Malcolm Spaulding of the University of Rhode Island; Craig Swanson of Applied Science Associates, Inc.; Jim Smay of Oklahoma State University; Deborah Pence of Oregon State University; Eric Braschoss of Philadelphia, PA.; and Dale Hart of Louisiana Tech University. The McGraw-Hill staff was, as usual, enormously helpful. Many thanks are due to Bill Stenquist, Lora Kalb-Neyens, Curt Reynolds, John Leland, Jane Mohr, Brenda Rolwes, as well as all those who worked on previous editions. Finally, the continuing support and encouragement of my wife and family are, as always, much appreciated. Special thanks are due to our dog, Sadie, and our cats, Cole and Kerry..


(23) whi29346_ch01_002-063.qxd. 10/14/09. 19:57. Page 1 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Fluid Mechanics.

(24) whi29346_ch01_002-063.qxd. 10/14/09. 19:57. Page 2 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Hurricane Rita in the Gulf of Mexico, Sept. 22, 2005. Rita made landfall at the Texas-Louisiana border and caused billions of dollars in wind and flooding damage. Though more dramatic than typical applications in this text, Rita is a true fluid flow, strongly influenced by the earth’s rotation and the ocean temperature. (Photo courtesy of NASA.). 2.

(25) whi29346_ch01_002-063.qxd. 10/14/09. 19:57. Page 3 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Chapter 1 Introduction. 1.1 Preliminary Remarks. Fluid mechanics is the study of fluids either in motion (fluid dynamics) or at rest (fluid statics). Both gases and liquids are classified as fluids, and the number of fluid engineering applications is enormous: breathing, blood flow, swimming, pumps, fans, turbines, airplanes, ships, rivers, windmills, pipes, missiles, icebergs, engines, filters, jets, and sprinklers, to name a few. When you think about it, almost everything on this planet either is a fluid or moves within or near a fluid. The essence of the subject of fluid flow is a judicious compromise between theory and experiment. Since fluid flow is a branch of mechanics, it satisfies a set of welldocumented basic laws, and thus a great deal of theoretical treatment is available. However, the theory is often frustrating because it applies mainly to idealized situations, which may be invalid in practical problems. The two chief obstacles to a workable theory are geometry and viscosity. The basic equations of fluid motion (Chap. 4) are too difficult to enable the analyst to attack arbitrary geometric configurations. Thus most textbooks concentrate on flat plates, circular pipes, and other easy geometries. It is possible to apply numerical computer techniques to complex geometries, and specialized textbooks are now available to explain the new computational ufl id dynamics (CFD) approximations and methods [1–4].1 This book will present many theoretical results while keeping their limitations in mind. The second obstacle to a workable theory is the action of viscosity, which can be neglected only in certain idealized flows (Chap. 8). First, viscosity increases the difficulty of the basic equations, although the boundary-layer approximation found by Ludwig Prandtl in 1904 (Chap. 7) has greatly simplified viscous-flow analyses. Second, viscosity has a destabilizing effect on all fluids, giving rise, at frustratingly small velocities, to a disorderly, random phenomenon called turbulence. The theory of turbulent flow is crude and heavily backed up by experiment (Chap. 6), yet it can be quite serviceable as an engineering estimate. This textbook only introduces the standard experimental correlations for turbulent time-mean flow. Meanwhile, there are advanced texts on both time-mean turbulence and turbulence modeling [5, 6] and on the newer, computer-intensive direct numerical simulation (DNS) of fluctuating turbulence [7, 8]. 1. Numbered references appear at the end of each chapter.. 3.

(26) whi29346_ch01_002-063.qxd. 4. 10/14/09. 19:57. Page 4 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Chapter 1 Introduction. Thus there is theory available for fluid flow problems, but in all cases it should be backed up by experiment. Often the experimental data provide the main source of information about specific flows, such as the drag and lift of immersed bodies (Chap. 7). Fortunately, fluid mechanics is a highly visual subject, with good instrumentation [9–11], and the use of dimensional analysis and modeling concepts (Chap. 5) is widespread. Thus experimentation provides a natural and easy complement to the theory. You should keep in mind that theory and experiment should go hand in hand in all studies of fluid mechanics.. 1.2 History and Scope of Fluid Mechanics. Fig. 1.1 Leonhard Euler (1707– 1783) was the greatest mathematician of the eighteenth century and used Newton’s calculus to develop and solve the equations of motion of inviscid flow. He published over 800 books and papers. [Courtesy of the School of Mathematics and Statistics, University of St Andrew, Scotland.]. Like most scientific disciplines, fluid mechanics has a history of erratically occurring early achievements, then an intermediate era of steady fundamental discoveries in the eighteenth and nineteenth centuries, leading to the twenty-first-century era of “modern practice,” as we self-centeredly term our limited but up-to-date knowledge. Ancient civilizations had enough knowledge to solve certain flow problems. Sailing ships with oars and irrigation systems were both known in prehistoric times. The Greeks produced quantitative information. Archimedes and Hero of Alexandria both postulated the parallelogram law for addition of vectors in the third century B.C. Archimedes (285–212 B.C.) formulated the laws of buoyancy and applied them to floating and submerged bodies, actually deriving a form of the differential calculus as part of the analysis. The Romans built extensive aqueduct systems in the fourth century B.C. but left no records showing any quantitative knowledge of design principles. From the birth of Christ to the Renaissance there was a steady improvement in the design of such flow systems as ships and canals and water conduits but no recorded evidence of fundamental improvements in flow analysis. Then Leonardo da Vinci (1452–1519) stated the equation of conservation of mass in one-dimensional steady flow. Leonardo was an excellent experimentalist, and his notes contain accurate descriptions of waves, jets, hydraulic jumps, eddy formation, and both low-drag (streamlined) and high-drag (parachute) designs. A Frenchman, Edme Mariotte (1620–1684), built the first wind tunnel and tested models in it. Problems involving the momentum of fluids could finally be analyzed after Isaac Newton (1642–1727) postulated his laws of motion and the law of viscosity of the linear fluids now called newtonian. The theory first yielded to the assumption of a “perfect” or frictionless fluid, and eighteenth-century mathematicians (Daniel Bernoulli, Leonhard Euler, Jean d’Alembert, Joseph-Louis Lagrange, and Pierre-Simon Laplace) produced many beautiful solutions of frictionless-flow problems. Euler, Fig. 1.1, developed both the differential equations of motion and their integrated form, now called the Bernoulli equation. D’Alembert used them to show his famous paradox: that a body immersed in a frictionless fluid has zero drag. These beautiful results amounted to overkill, since perfect-fluid assumptions have very limited application in practice and most engineering flows are dominated by the effects of viscosity. Engineers began to reject what they regarded as a totally unrealistic theory and developed the science of hydraulics, relying almost entirely on experiment. Such experimentalists as Chézy, Pitot, Borda, Weber, Francis, Hagen, Poiseuille, Darcy, Manning, Bazin, and Weisbach produced data on a variety of flows such as open channels, ship resistance, pipe flows, waves, and turbines. All too often the data were used in raw form without regard to the fundamental physics of flow..

(27) whi29346_ch01_002-063.qxd. 10/14/09. 19:57. Page 5 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. 1.2 History and Scope of Fluid Mechanics. Fig. 1.2 Ludwig Prandtl (1875– 1953), often called the “father of modern fluid mechanics” [15], developed boundary layer theory and many other innovative analyses. He and his students were pioneers in flow visualization techniques. [Aufnahme von Fr. Struckmeyer, Gottingen, courtesy AIP Emilio Segre Visual Archives, Lande Collection.]. 5. At the end of the nineteenth century, unification between experimental hydraulics and theoretical hydrodynamics finally began. William Froude (1810–1879) and his son Robert (1846–1924) developed laws of model testing; Lord Rayleigh (1842–1919) proposed the technique of dimensional analysis; and Osborne Reynolds (1842–1912) published the classic pipe experiment in 1883, which showed the importance of the dimensionless Reynolds number named after him. Meanwhile, viscous-flow theory was available but unexploited, since Navier (1785–1836) and Stokes (1819–1903) had successfully added newtonian viscous terms to the equations of motion. The resulting Navier-Stokes equations were too difficult to analyze for arbitrary flows. Then, in 1904, a German engineer, Ludwig Prandtl (1875–1953), Fig. 1.2, published perhaps the most important paper ever written on fluid mechanics. Prandtl pointed out that fluid flows with small viscosity, such as water flows and airflows, can be divided into a thin viscous layer, or boundary layer, near solid surfaces and interfaces, patched onto a nearly inviscid outer layer, where the Euler and Bernoulli equations apply. Boundary-layer theory has proved to be a very important tool in modern flow analysis. The twentiethcentury foundations for the present state of the art in fluid mechanics were laid in a series of broad-based experiments and theories by Prandtl and his two chief friendly competitors, Theodore von Kármán (1881–1963) and Sir Geoffrey I. Taylor (1886–1975). Many of the results sketched here from a historical point of view will, of course, be discussed in this textbook. More historical details can be found in Refs. 12 to 14. The second half of the twentieth century introduced a new tool: Computational Fluid Dynamics (CFD). The earliest paper on the subject known to this writer was by A. Thom in 1933 [47], a laborious, but accurate, hand calculation of flow past a cylinder at low Reynolds numbers. Commercial digital computers became available in the 1950s, and personal computers in the 1970s, bringing CFD into adulthood. A legendary first textbook was by Patankar [3]. Presently, with increases in computer speed and memory, almost any laminar flow can be modeled accurately. Turbulent flow is still calculated with empirical models, but Direct Numerical Simulation [7, 8] is possible for low Reynolds numbers. Another five orders of magnitude in computer speed are needed before general turbulent flows can be calculated. That may not be possible, due to size limits of nano- and pico-elements. But, if general DNS develops, Gad-el-Hak [14] raises the prospect of a shocking future: all of fluid mechanics reduced to a black box, with no real need for teachers, researchers, writers, or fluids engineers. Since the earth is 75 percent covered with water and 100 percent covered with air, the scope of fluid mechanics is vast and touches nearly every human endeavor. The sciences of meteorology, physical oceanography, and hydrology are concerned with naturally occurring fluid flows, as are medical studies of breathing and blood circulation. All transportation problems involve fluid motion, with well-developed specialties in aerodynamics of aircraft and rockets and in naval hydrodynamics of ships and submarines. Almost all our electric energy is developed either from water flow or from steam flow through turbine generators. All combustion problems involve fluid motion as do the more classic problems of irrigation, flood control, water supply, sewage disposal, projectile motion, and oil and gas pipelines. The aim of this book is to present enough fundamental concepts and practical applications in fluid mechanics to prepare you to move smoothly into any of these specialized fields of the science of flow—and then be prepared to move out again as new technologies develop..

(28) whi29346_ch01_002-063.qxd. 6. 10/14/09. 19:57. Page 6 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Chapter 1 Introduction. 1.3 Problem-Solving Techniques. Fluid flow analysis is packed with problems to be solved. The present text has more than 1700 problem assignments. Solving a large number of these is a key to learning the subject. One must deal with equations, data, tables, assumptions, unit systems, and solution schemes. The degree of difficulty will vary, and we urge you to sample the whole spectrum of assignments, with or without the Answers in the Appendix. Here are the recommended steps for problem solution: 1. Read the problem and restate it with your summary of the results desired. 2. From tables or charts, gather the needed property data: density, viscosity, etc. 3. Make sure you understand what is asked. Students are apt to answer the wrong question—for example, pressure instead of pressure gradient, lift force instead of drag force, or mass flow instead of volume flow. Read the problem carefully. 4. Make a detailed, labeled sketch of the system or control volume needed. 5. Think carefully and list your assumptions. You must decide if the flow is steady or unsteady, compressible or incompressible, viscous or inviscid, and whether a control volume or partial differential equations are needed. 6. Find an algebraic solution if possible. Then, if a numerical value is needed, use either the SI or BG unit systems, to be reviewed in Sec. 1.6. 7. Report your solution, labeled, with the proper units and the proper number of significant figures (usually two or three) that the data uncertainty allows. We shall follow these steps, where appropriate, in our example problems.. 1.4 The Concept of a Fluid. From the point of view of fluid mechanics, all matter consists of only two states, fluid and solid. The difference between the two is perfectly obvious to the layperson, and it is an interesting exercise to ask a layperson to put this difference into words. The technical distinction lies with the reaction of the two to an applied shear or tangential stress. A solid can resist a shear stress by a static deflection; a ufl id cannot . Any shear stress applied to a fluid, no matter how small, will result in motion of that fluid. The fluid moves and deforms continuously as long as the shear stress is applied. As a corollary, we can say that a fluid at rest must be in a state of zero shear stress, a state often called the hydrostatic stress condition in structural analysis. In this condition, Mohr’s circle for stress reduces to a point, and there is no shear stress on any plane cut through the element under stress. Given this definition of a fluid, every layperson also knows that there are two classes of fluids, liquids and gases. Again the distinction is a technical one concerning the effect of cohesive forces. A liquid, being composed of relatively close-packed molecules with strong cohesive forces, tends to retain its volume and will form a free surface in a gravitational field if unconfined from above. Free-surface flows are dominated by gravitational effects and are studied in Chaps. 5 and 10. Since gas molecules are widely spaced with negligible cohesive forces, a gas is free to expand until it encounters confining walls. A gas has no definite volume, and when left to itself without confinement, a gas forms an atmosphere that is essentially hydrostatic. The hydrostatic behavior of liquids and gases is taken up in Chap. 2. Gases cannot form a free surface, and thus gas flows are rarely concerned with gravitational effects other than buoyancy..

(29) whi29346_ch01_002-063.qxd. 10/14/09. 19:57. Page 7 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. 1.4 The Concept of a Fluid Free surface. Static deflection. A. A Solid. A Liquid. Gas. (a). (c) p. σ1 θ. θ. τ1. 0. τ=0. p 0. A. p. A. –σ = p. –σ = p. Fig. 1.3 A solid at rest can resist shear. (a) Static deflection of the solid; (b) equilibrium and Mohr’s circle for solid element A. A fluid cannot resist shear. (c) Containing walls are needed; (d ) equilibrium and Mohr’s circle for fluid element A.. τ. τ. (1) 2θ. σ. –p. (b). 7. Hydrostatic condition. σ. –p. (d ). Figure 1.3 illustrates a solid block resting on a rigid plane and stressed by its own weight. The solid sags into a static deflection, shown as a highly exaggerated dashed line, resisting shear without flow. A free-body diagram of element A on the side of the block shows that there is shear in the block along a plane cut at an angle through A. Since the block sides are unsupported, element A has zero stress on the left and right sides and compression stress p on the top and bottom. Mohr’s circle does not reduce to a point, and there is nonzero shear stress in the block. By contrast, the liquid and gas at rest in Fig. 1.3 require the supporting walls in order to eliminate shear stress. The walls exert a compression stress of p and reduce Mohr’s circle to a point with zero shear everywhere—that is, the hydrostatic condition. The liquid retains its volume and forms a free surface in the container. If the walls are removed, shear develops in the liquid and a big splash results. If the container is tilted, shear again develops, waves form, and the free surface seeks a horizontal configuration, pouring out over the lip if necessary. Meanwhile, the gas is unrestrained and expands out of the container, filling all available space. Element A in the gas is also hydrostatic and exerts a compression stress p on the walls..

(30) whi29346_ch01_002-063.qxd. 8. 10/14/09. 19:57. Page 8 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Chapter 1 Introduction. In the previous discussion, clear decisions could be made about solids, liquids, and gases. Most engineering fluid mechanics problems deal with these clear cases—that is, the common liquids, such as water, oil, mercury, gasoline, and alcohol, and the common gases, such as air, helium, hydrogen, and steam, in their common temperature and pressure ranges. There are many borderline cases, however, of which you should be aware. Some apparently “solid” substances such as asphalt and lead resist shear stress for short periods but actually deform slowly and exhibit definite fluid behavior over long periods. Other substances, notably colloid and slurry mixtures, resist small shear stresses but “yield” at large stress and begin to flow as fluids do. Specialized textbooks are devoted to this study of more general deformation and flow, a field called rheology [16]. Also, liquids and gases can coexist in two-phase mixtures, such as steam–water mixtures or water with entrapped air bubbles. Specialized textbooks present the analysis of such multiphase ofl ws [17]. Finally, in some situations the distinction between a liquid and a gas blurs. This is the case at temperatures and pressures above the so-called critical point of a substance, where only a single phase exists, primarily resembling a gas. As pressure increases far above the critical point, the gaslike substance becomes so dense that there is some resemblance to a liquid and the usual thermodynamic approximations like the perfect-gas law become inaccurate. The critical temperature and pressure of water are Tc 647 K and pc 219 atm (atmosphere2) so that typical problems involving water and steam are below the critical point. Air, being a mixture of gases, has no distinct critical point, but its principal component, nitrogen, has Tc 126 K and pc 34 atm. Thus typical problems involving air are in the range of high temperature and low pressure where air is distinctly and definitely a gas. This text will be concerned solely with clearly identifiable liquids and gases, and the borderline cases just discussed will be beyond our scope.. 1.5 The Fluid as a Continuum. We have already used technical terms such as ufl id pressure and density without a rigorous discussion of their definition. As far as we know, fluids are aggregations of molecules, widely spaced for a gas, closely spaced for a liquid. The distance between molecules is very large compared with the molecular diameter. The molecules are not fixed in a lattice but move about freely relative to each other. Thus fluid density, or mass per unit volume, has no precise meaning because the number of molecules occupying a given volume continually changes. This effect becomes unimportant if the unit volume is large compared with, say, the cube of the molecular spacing, when the number of molecules within the volume will remain nearly constant in spite of the enormous interchange of particles across the boundaries. If, however, the chosen unit volume is too large, there could be a noticeable variation in the bulk aggregation of the particles. This situation is illustrated in Fig. 1.4, where the “density” as calculated from molecular mass m within a given volume is plotted versus the size of the unit volume. There is a limiting volume * below which molecular variations may be important and above which aggregate variations may be important. The density of a fluid is best defined as 2. lim. S*. One atmosphere equals 2116 lbf/ft2 101,300 Pa.. m . (1.1).

(31) whi29346_ch01_002-063.qxd. 10/14/09. 19:57. Page 9 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. 1.6 Dimensions and Units ρ. Elemental volume. ρ = 1000 kg/m3. ρ = 1200. Fig. 1.4 The limit definition of continuum fluid density: (a) an elemental volume in a fluid region of variable continuum density; (b) calculated density versus size of the elemental volume.. Microscopic uncertainty Macroscopic uncertainty. ρ = 1100. δ. 9. 1200. ρ = 1300 0. δ * ≈ 10-9 mm3. δ. Region containing fluid (a). (b). The limiting volume * is about 109 mm3 for all liquids and for gases at atmospheric pressure. For example, 109 mm3 of air at standard conditions contains approximately 3 107 molecules, which is sufficient to define a nearly constant density according to Eq. (1.1). Most engineering problems are concerned with physical dimensions much larger than this limiting volume, so that density is essentially a point function and fluid properties can be thought of as varying continually in space, as sketched in Fig. 1.4a. Such a fluid is called a continuum, which simply means that its variation in properties is so smooth that differential calculus can be used to analyze the substance. We shall assume that continuum calculus is valid for all the analyses in this book. Again there are borderline cases for gases at such low pressures that molecular spacing and mean free path3 are comparable to, or larger than, the physical size of the system. This requires that the continuum approximation be dropped in favor of a molecular theory of rarefied gas flow [18]. In principle, all fluid mechanics problems can be attacked from the molecular viewpoint, but no such attempt will be made here. Note that the use of continuum calculus does not preclude the possibility of discontinuous jumps in fluid properties across a free surface or fluid interface or across a shock wave in a compressible fluid (Chap. 9). Our calculus in analyzing fluid flow must be flexible enough to handle discontinuous boundary conditions.. 1.6 Dimensions and Units. A dimension is the measure by which a physical variable is expressed quantitatively. A unit is a particular way of attaching a number to the quantitative dimension. Thus length is a dimension associated with such variables as distance, displacement, width, deflection, and height, while centimeters and inches are both numerical units for expressing length. Dimension is a powerful concept about which a splendid tool called dimensional analysis has been developed (Chap. 5), while units are the numerical quantity that the customer wants as the final answer. In 1872 an international meeting in France proposed a treaty called the Metric Convention, which was signed in 1875 by 17 countries including the United States. It was an improvement over British systems because its use of base 10 is the foundation of our number system, learned from childhood by all. Problems still remained because 3. The mean distance traveled by molecules between collisions (see Prob. P1.5)..

(32) whi29346_ch01_002-063.qxd. 10. 10/14/09. 19:57. Page 10 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Chapter 1 Introduction. Table 1.1 Primary Dimensions in SI and BG Systems. Primary dimension Mass {M} Length {L} Time {T} Temperature {}. SI unit. BG unit. Kilogram (kg) Meter (m) Second (s) Kelvin (K). Slug Foot (ft) Second (s) Rankine (R). Conversion factor 1 1 1 1. slug 14.5939 kg ft 0.3048 m s1s K 1.8R. even the metric countries differed in their use of kiloponds instead of dynes or newtons, kilograms instead of grams, or calories instead of joules. To standardize the metric system, a General Conference of Weights and Measures, attended in 1960 by 40 countries, proposed the International System of Units (SI). We are now undergoing a painful period of transition to SI, an adjustment that may take many more years to complete. The professional societies have led the way. Since July 1, 1974, SI units have been required by all papers published by the American Society of Mechanical Engineers, and there is a textbook explaining the SI [19]. The present text will use SI units together with British gravitational (BG) units.. Primary Dimensions. In fluid mechanics there are only four primary dimensions from which all other dimensions can be derived: mass, length, time, and temperature.4 These dimensions and their units in both systems are given in Table 1.1. Note that the kelvin unit uses no degree symbol. The braces around a symbol like {M} mean “the dimension” of mass. All other variables in fluid mechanics can be expressed in terms of {M}, {L}, {T}, and {}. For example, acceleration has the dimensions {LT 2}. The most crucial of these secondary dimensions is force, which is directly related to mass, length, and time by Newton’s second law. Force equals the time rate of change of momentum or, for constant mass, F ma From this we see that, dimensionally, {F} {MLT. The International System (SI). (1.2) 2. }.. The use of a constant of proportionality in Newton’s law, Eq. (1.2), is avoided by defining the force unit exactly in terms of the other basic units. In the SI system, the basic units are newtons {F}, kilograms {M}, meters {L}, and seconds {T}. We define 1 newton of force 1 N 1 kg # 1 m/s2 The newton is a relatively small force, about the weight of an apple (0.225 lbf). In addition, the basic unit of temperature {} in the SI system is the degree Kelvin, K. Use of these SI units (N, kg, m, s, K) will require no conversion factors in our equations.. The British Gravitational (BG) System. In the BG system also, a constant of proportionality in Eq. (1.2) is avoided by defining the force unit exactly in terms of the other basic units. In the BG system, the basic units are pound-force {F}, slugs {M}, feet {L}, and seconds {T}. We define 1 pound of force 1 lbf 1 slug # 1 ft/s2 4 If electromagnetic effects are important, a fifth primary dimension must be included, electric current {I}, whose SI unit is the ampere (A)..

(33) whi29346_ch01_002-063.qxd. 10/14/09. 19:57. Page 11 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. 1.6 Dimensions and Units. 11. One lbf 4.4482 N and approximates the weight of four apples. We will use the abbreviation lbf for pound-force and lbm for pound-mass. The slug is a rather hefty mass, equal to 32.174 lbm. The basic unit of temperature {} in the BG system is the degree Rankine, R. Recall that a temperature difference 1 K 1.8R. Use of these BG units (lbf, slug, ft, s, R) will require no conversion factors in our equations.. Other Unit Systems. There are other unit systems still in use. At least one needs no proportionality constant: the CGS system (dyne, gram, cm, s, K). However, CGS units are too small for most applications (1 dyne 105 N) and will not be used here. In the USA, some still use the English Engineering system, (lbf, lbm, ft, s, R), where the basic mass unit is the pound of mass. Newton’s law (1.2) must be rewritten: F. ma , gc. where gc 32.174. ft # lbm lbf # s2. (1.3). The constant of proportionality, gc, has both dimensions and a numerical value not equal to 1.0. The present text uses only the SI and BG systems and will not solve problems or examples in the English Engineering system. Because Americans still use them, a few problems in the text will be stated in truly awkward units: acres, gallons, ounces, or miles. Your assignment will be to convert these and solve in the SI or BG systems.. The Principle of Dimensional Homogeneity. In engineering and science, all equations must be dimensionally homogeneous, that is, each additive term in an equation must have the same dimensions. For example, take Bernoulli’s incompressible equation, to be studied and used throughout this text: 1 p V 2 gZ constant 2 Each and every term in this equation must have dimensions of pressure {ML1T 2}. We will examine the dimensional homogeneity of this equation in detail in Ex. 1.3. A list of some important secondary variables in fluid mechanics, with dimensions derived as combinations of the four primary dimensions, is given in Table 1.2. A more complete list of conversion factors is given in App. C.. Table 1.2 Secondary Dimensions in Fluid Mechanics. Secondary dimension. SI unit. BG unit. Area {L2} Volume {L3} Velocity {LT 1} Acceleration {LT 2} Pressure or stress {ML1T 2} Angular velocity {T 1} Energy, heat, work {ML2T 2} Power {ML2T 3} Density {ML3} Viscosity {ML1T 1} Specific heat {L2T 21}. m2 m3 m/s m/s2 Pa N/m2 s1 JNm W J/s kg/m3 kg/(m s) m2/(s2 K). ft2 ft3 ft/s ft/s2 lbf/ft2 s1 ft lbf ft lbf/s slugs/ft3 slugs/(ft s) ft2/(s2 R). Conversion factor 1 1 1 1 1 1 1 1 1 1 1. m2 10.764 ft2 m3 35.315 ft3 ft/s 0.3048 m/s ft/s2 0.3048 m/s2 lbf/ft2 47.88 Pa s1 1 s1 ft lbf 1.3558 J ft lbf/s 1.3558 W slug/ft3 515.4 kg/m3 slug/(ft s) 47.88 kg/(m s) m2/(s2 K) 5.980 ft2/(s2 R).

(34) whi29346_ch01_002-063.qxd. 12. 10/14/09. 19:57. Page 12 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Chapter 1 Introduction. EXAMPLE 1.1 A body weighs 1000 lbf when exposed to a standard earth gravity g 32.174 ft/s2. (a) What is its mass in kg? (b) What will the weight of this body be in N if it is exposed to the moon’s standard acceleration gmoon 1.62 m/s2? (c) How fast will the body accelerate if a net force of 400 lbf is applied to it on the moon or on the earth?. Solution We need to find the (a) mass; (b) weight on the moon; and (c) acceleration of this body. This is a fairly simple example of conversion factors for differing unit systems. No property data is needed. The example is too low-level for a sketch.. Part (a). Newton’s law (1.2) holds with known weight and gravitational acceleration. Solve for m: F W 1000 lbf mg (m)(32.174 ft/s2), or m . 1000 lbf 31.08 slugs 32.174 ft/s2. Convert this to kilograms: m 31.08 slugs (31.08 slugs)(14.5939 kg/slug) 454 kg. Part (b). The mass of the body remains 454 kg regardless of its location. Equation (1.2) applies with a new gravitational acceleration and hence a new weight: F Wmoon mgmoon (454 kg)(1.62 m/s2) 735 N. Part (c). Ans. (a). Ans. (b). This part does not involve weight or gravity or location. It is simply an application of Newton’s law with a known mass and known force: F 400 lbf ma (31.08 slugs) a Solve for a Comment (c):. 400 lbf ft m m 12.87 2 a0.3048 b 3.92 2 31.08 slugs s ft s. Ans. (c). This acceleration would be the same on the earth or moon or anywhere.. Many data in the literature are reported in inconvenient or arcane units suitable only to some industry or specialty or country. The engineer should convert these data to the SI or BG system before using them. This requires the systematic application of conversion factors, as in the following example. EXAMPLE 1.2 Industries involved in viscosity measurement [27, 36] continue to use the CGS system of units, since centimeters and grams yield convenient numbers for many fluids. The absolute viscosity () unit is the poise, named after J. L. M. Poiseuille, a French physician who in 1840 performed pioneering experiments on water flow in pipes; 1 poise 1 g/(cm-s). The kinematic viscosity () unit is the stokes, named after G. G. Stokes, a British physicist who.

(35) whi29346_ch01_002-063.qxd. 10/14/09. 19:58. Page 13 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. 1.6 Dimensions and Units. 13. in 1845 helped develop the basic partial differential equations of fluid momentum; 1 stokes 1 cm2/s. Water at 20C has 0.01 poise and also 0.01 stokes. Express these results in (a) SI and (b) BG units.. Solution Part (a). • Approach: Systematically change grams to kg or slugs and change centimeters to meters or feet.. • Property values: Given 0.01 g/(cm-s) and 0.01 cm2/s. • Solution steps: (a) For conversion to SI units,. Part (b). 0.01. g g(1 kg/1000g) kg 0.01 0.001 # cm # s cm(0.01 m/cm)s m s. 0.01. cm2(0.01 m/cm)2 m2 cm2 0.01 0.000001 s s s. Ans. (a). • For conversion to BG units 0.01. g g(1 kg/1000 g)(1 slug/14.5939 kg) slug 0.01 0.0000209 # cm # s (0.01 m/cm)(1 ft/0.3048 m)s ft s. 0.01. cm2 cm2(0.01 m/cm)2(1 ft/0.3048 m)2 ft2 0.01 0.0000108 s s s. Ans. (b). • Comments: This was a laborious conversion that could have been shortened by using the direct viscosity conversion factors in App. C. For example, BG SI/47.88.. We repeat our advice: Faced with data in unusual units, convert them immediately to either SI or BG units because (1) it is more professional and (2) theoretical equations in fluid mechanics are dimensionally consistent and require no further conversion factors when these two fundamental unit systems are used, as the following example shows. EXAMPLE 1.3 A useful theoretical equation for computing the relation between pressure, velocity, and altitude in a steady flow of a nearly inviscid, nearly incompressible fluid with negligible heat transfer and shaft work5 is the Bernoulli relation, named after Daniel Bernoulli, who published a hydrodynamics textbook in 1738: p0 p 12 V2 gZ where p0 p V Z g 5. . stagnation pressure pressure in moving fluid velocity density altitude gravitational acceleration. That’s an awful lot of assumptions, which need further study in Chap. 3.. (1).

(36) whi29346_ch01_002-063.qxd. 14. 10/14/09. 19:58. Page 14 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Chapter 1 Introduction (a) Show that Eq. (1) satisfies the principle of dimensional homogeneity, which states that all additive terms in a physical equation must have the same dimensions. (b) Show that consistent units result without additional conversion factors in SI units. (c) Repeat (b) for BG units.. Solution Part (a). We can express Eq. (1) dimensionally, using braces, by entering the dimensions of each term from Table 1.2: {ML1T 2} {ML1T 2} {ML3}{L2T 2} {ML3}{LT 2}{L} {ML1T 2} for all terms. Part (b). Ans. (a). Enter the SI units for each quantity from Table 1.2: {N/m2} {N/m2} {kg/m3}{m2/s2} {kg/m3}{m/s2}{m} {N/m2} {kg/(m s2)} The right-hand side looks bad until we remember from Eq. (1.3) that 1 kg 1 N s2/m. 5kg/(m # s2)6 . 5N # s2/m6 5N/m2 6 5m # s2 6. Ans. (b). Thus all terms in Bernoulli’s equation will have units of pascals, or newtons per square meter, when SI units are used. No conversion factors are needed, which is true of all theoretical equations in fluid mechanics.. Part (c). Introducing BG units for each term, we have {lbf/ft2} {lbf/ft2} {slugs/ft3}{ft2/s2} {slugs/ft3}{ft/s2}{ft} {lbf/ft2} {slugs/(ft s2)} But, from Eq. (1.3), 1 slug 1 lbf s2/ft, so that 5slugs/(ft # s2)6 . 5lbf # s2/ft6 5lbf/ft2 6 5ft # s2 6. Ans. (c). All terms have the unit of pounds-force per square foot. No conversion factors are needed in the BG system either.. There is still a tendency in English-speaking countries to use pound-force per square inch as a pressure unit because the numbers are more manageable. For example, standard atmospheric pressure is 14.7 lbf/in2 2116 lbf/ft2 101,300 Pa. The pascal is a small unit because the newton is less than 14 lbf and a square meter is a very large area.. Consistent Units. Note that not only must all (fluid) mechanics equations be dimensionally homogeneous, one must also use consistent units; that is, each additive term must have the same units. There is no trouble doing this with the SI and BG systems, as in Example 1.3, but woe unto those who try to mix colloquial English units. For example, in Chap. 9, we often use the assumption of steady adiabatic compressible gas flow: h 12V2 constant.

(37) whi29346_ch01_002-063.qxd. 10/14/09. 19:58. Page 15 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. 1.6 Dimensions and Units. 15. where h is the fluid enthalpy and V2/2 is its kinetic energy per unit mass. Colloquial thermodynamic tables might list h in units of British thermal units per pound mass (Btu/lb), whereas V is likely used in ft/s. It is completely erroneous to add Btu/lb to ft2/s2. The proper unit for h in this case is ft lbf/slug, which is identical to ft2/s2. The conversion factor is 1 Btu/lb 25,040 ft2/s2 25,040 ft lbf/slug.. Homogeneous versus Dimensionally Inconsistent Equations. All theoretical equations in mechanics (and in other physical sciences) are dimensionally homogeneous; that is, each additive term in the equation has the same dimensions. However, the reader should be warned that many empirical formulas in the engineering literature, arising primarily from correlations of data, are dimensionally inconsistent. Their units cannot be reconciled simply, and some terms may contain hidden variables. An example is the formula that pipe valve manufacturers cite for liquid volume flow rate Q (m3/s) through a partially open valve: Q CV a. Table 1.3 Convenient Prefixes for Engineering Units Multiplicative factor 1012 109 106 103 102 10 101 102 103 106 109 1012 1015 1018. Prefix tera giga mega kilo hecto deka deci centi milli micro nano pico femto atto. Convenient Prefixes in Powers of 10. Symbol T G M k h da d c m n p f a. p 1/2 b SG. where p is the pressure drop across the valve and SG is the specific gravity of the liquid (the ratio of its density to that of water). The quantity CV is the valve flow coefficient, which manufacturers tabulate in their valve brochures. Since SG is dimensionless {1}, we see that this formula is totally inconsistent, with one side being a flow rate {L3/T} and the other being the square root of a pressure drop {M1/2/L1/2T}. It follows that CV must have dimensions, and rather odd ones at that: {L7/2/M1/2}. Nor is the resolution of this discrepancy clear, although one hint is that the values of CV in the literature increase nearly as the square of the size of the valve. The presentation of experimental data in homogeneous form is the subject of dimensional analysis (Chap. 5). There we shall learn that a homogeneous form for the valve flow relation is Q Cd Aopeninga. p 1/2 b . where is the liquid density and A the area of the valve opening. The discharge coefficient C d is dimensionless and changes only moderately with valve size. Please believe—until we establish the fact in Chap. 5—that this latter is a much better formulation of the data. Meanwhile, we conclude that dimensionally inconsistent equations, though they occur in engineering practice, are misleading and vague and even dangerous, in the sense that they are often misused outside their range of applicability. Engineering results often are too small or too large for the common units, with too many zeros one way or the other. For example, to write p 114,000,000 Pa is long and awkward. Using the prefix “M” to mean 106, we convert this to a concise p 114 MPa (megapascals). Similarly, t 0.000000003 s is a proofreader’s nightmare compared to the equivalent t 3 ns (nanoseconds). Such prefixes are common and convenient, in both the SI and BG systems. A complete list is given in Table 1.3..

(38) whi29346_ch01_002-063.qxd. 16. 10/14/09. 19:58. Page 16 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Chapter 1 Introduction. EXAMPLE 1.4 In 1890 Robert Manning, an Irish engineer, proposed the following empirical formula for the average velocity V in uniform flow due to gravity down an open channel (BG units): 1.49 2/3 1/2 R S n where R hydraulic radius of channel (Chaps. 6 and 10) S channel slope (tangent of angle that bottom makes with horizontal) n Manning’s roughness factor (Chap. 10) V. (1). and n is a constant for a given surface condition for the walls and bottom of the channel. (a) Is Manning’s formula dimensionally consistent? (b) Equation (1) is commonly taken to be valid in BG units with n taken as dimensionless. Rewrite it in SI form.. Solution • Assumption: The channel slope S is the tangent of an angle and is thus a dimensionless ratio with the dimensional notation {1}—that is, not containing M, L, or T.. • Approach (a): Rewrite the dimensions of each term in Manning’s equation, using brackets {}: 5V6 e. 1.49 f 5R2/3 6 5S1/2 6 n. or. L 1.49 f 5L2/3 6 516 e f e n T. This formula is incompatible unless {1.49/n} {L1/3/T}. If n is dimensionless (and it is never listed with units in textbooks), the number 1.49 must carry the dimensions of {L1/3/T}. Ans. (a). • Comment (a): Formulas whose numerical coefficients have units can be disastrous for engineers working in a different system or another fluid. Manning’s formula, though popular, is inconsistent both dimensionally and physically and is valid only for water flow with certain wall roughnesses. The effects of water viscosity and density are hidden in the numerical value 1.49. • Approach (b): Part (a) showed that 1.49 has dimensions. If the formula is valid in BG units, then it must equal 1.49 ft1/3/s. By using the SI conversion for length, we obtain (1.49 ft1/3/s)(0.3048 m/ft)1/3 1.00 m1/3/s Therefore Manning’s inconsistent formula changes form when converted to the SI system: SI units: V . 1.0 2/3 1/2 R S n. Ans. (b). with R in meters and V in meters per second.. • Comment (b): Actually, we misled you: This is the way Manning, a metric user, first proposed the formula. It was later converted to BG units. Such dimensionally inconsistent formulas are dangerous and should either be reanalyzed or treated as having very limited application..

(39) whi29346_ch01_002-063.qxd. 10/14/09. 19:58. Page 17 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. 1.7 Properties of the Velocity Field. 17. 1.7 Properties of the Velocity Field. In a given flow situation, the determination, by experiment or theory, of the properties of the fluid as a function of position and time is considered to be the solution to the problem. In almost all cases, the emphasis is on the space–time distribution of the fluid properties. One rarely keeps track of the actual fate of the specific fluid particles.6 This treatment of properties as continuum-field functions distinguishes fluid mechanics from solid mechanics, where we are more likely to be interested in the trajectories of individual particles or systems.. Eulerian and Lagrangian Descriptions. There are two different points of view in analyzing problems in mechanics. The first view, appropriate to fluid mechanics, is concerned with the field of flow and is called the eulerian method of description. In the eulerian method we compute the pressure field p(x, y, z, t) of the flow pattern, not the pressure changes p(t) that a particle experiences as it moves through the field. The second method, which follows an individual particle moving through the flow, is called the lagrangian description. The lagrangian approach, which is more appropriate to solid mechanics, will not be treated in this book. However, certain numerical analyses of sharply bounded fluid flows, such as the motion of isolated fluid droplets, are very conveniently computed in lagrangian coordinates [1]. Fluid dynamic measurements are also suited to the eulerian system. For example, when a pressure probe is introduced into a laboratory flow, it is fixed at a specific position (x, y, z). Its output thus contributes to the description of the eulerian pressure field p(x, y, z, t). To simulate a lagrangian measurement, the probe would have to move downstream at the fluid particle speeds; this is sometimes done in oceanographic measurements, where flowmeters drift along with the prevailing currents. The two different descriptions can be contrasted in the analysis of traffic flow along a freeway. A certain length of freeway may be selected for study and called the field of flow. Obviously, as time passes, various cars will enter and leave the field, and the identity of the specific cars within the field will constantly be changing. The traffic engineer ignores specific cars and concentrates on their average velocity as a function of time and position within the field, plus the flow rate or number of cars per hour passing a given section of the freeway. This engineer is using an eulerian description of the traffic flow. Other investigators, such as the police or social scientists, may be interested in the path or speed or destination of specific cars in the field. By following a specific car as a function of time, they are using a lagrangian description of the flow.. The Velocity Field. Foremost among the properties of a flow is the velocity field V(x, y, z, t). In fact, determining the velocity is often tantamount to solving a flow problem, since other properties follow directly from the velocity field. Chapter 2 is devoted to the calculation of the pressure field once the velocity field is known. Books on heat transfer (for example, Ref. 20) are largely devoted to finding the temperature field from known velocity fields. 6 One example where fluid particle paths are important is in water quality analysis of the fate of contaminant discharges..

(40) whi29346_ch01_002-063.qxd. 18. 10/14/09. 19:58. Page 18 Debd 208:MHDQ176:whi29346:0073529346:whi29346_pagefiles:. Chapter 1 Introduction. In general, velocity is a vector function of position and time and thus has three components u, , and w, each a scalar field in itself: V(x, y, z, t) iu(x, y, z, t) jv(x, y, z, t) kw(x, y, z, t). (1.4). The use of u, , and w instead of the more logical component notation Vx, Vy, and Vz is the result of an almost unbreakable custom in fluid mechanics. Much of this textbook, especially Chaps. 4, 7, 8, and 9, is concerned with finding the distribution of the velocity vector V for a variety of practical flows.. The Acceleration Field. The acceleration vector, a dV/dt, occurs in Newton’s law for a fluid and thus is very important. In order to follow a particle in the Eulerian frame of reference, the final result for acceleration is nonlinear and quite complicated. Here we only give the formula: a. dV V. V. V. V u v w dt. t. x. y. z. (1.5). where (u, v, w) are the velocity components from Eq. (1.4). We shall study this formula in detail in Chap. 4. The last three terms in Eq. (1.5) are nonlinear products and greatly complicate the analysis of general fluid motions, especially viscous flows.. 1.8 Thermodynamic Properties of a Fluid. While the velocity field V is the most important fluid property, it interacts closely with the thermodynamic properties of the fluid. We have already introduced into the discussion the three most common such properties: 1. Pressure p 2. Density 3. Temperature T These three are constant companions of the velocity vector in flow analyses. Four other intensive thermodynamic properties become important when work, heat, and energy balances are treated (Chaps. 3 and 4): 4. 5. 6. 7.. Internal energy û Enthalpy h û p/ Entropy s Specific heats cp and cv. In addition, friction and heat conduction effects are governed by the two so-called transport properties: 8. Coefficient of viscosity 9. Thermal conductivity k All nine of these quantities are true thermodynamic properties that are determined by the thermodynamic condition or state of the fluid. For example, for a single-phase.
