INFLUENCE OF EXTRUSION PROCESS PARAMETERS ON THE MECHANICAL PROPERTIES OF Al-Li-EXTRUSIONS

(1)

HAL Id: jpa-00226552

https://hal.archives-ouvertes.fr/jpa-00226552

Submitted on 1 Jan 1987

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are published or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

INFLUENCE OF EXTRUSION PROCESS PARAMETERS ON THE MECHANICAL

PROPERTIES OF Al-Li-EXTRUSIONS

G. Tempus, G. Scharf, W. Calles

To cite this version:

G. Tempus, G. Scharf, W. Calles. INFLUENCE OF EXTRUSION PROCESS PARAMETERS ON THE MECHANICAL PROPERTIES OF Al-Li-EXTRUSIONS. Journal de Physique Colloques, 1987, 48 (C3), pp.C3-187-C3-193. �10.1051/jphyscol:1987322�. �jpa-00226552�

(2)

INFLUENCE OF EXTRUSION PROCESS PARAMETERS ON THE MECHANICAL PROPERTIES OF A1-Li-EXTRUSIONS

G. TEMPUS, G. SCHARF a n d W. CALLES

Vereinigte Aluminium-Werke AG, Leichtmetall-Forschungsinstitu~, B.P. 2 4 6 8 , 0-5300 Bonn, F.R.G.

ABSTRACT

The i n f l u e n c e o f t h e e x t r u s i o n process parameters and TMT on t h e mechanical p r o - p e r t i e s o f d i f f e r e n t L i t a l A (8090)-extrusions was i n v e s t i g a t e d . Strength was shown t o be i n f l u e n c e d l e s s by e x t r u s i o n temperature and r a t i o than by t h e ex- t r u s i o n aspect r a t i o (width/thickness) determining t e x t u r e . With i n c r e a s i n g ex- t r u s i o n aspect r a t i o t h e s t r e n g t h d e c l i n e s considerably. Depending on t h e homo- g e n e i t y o f s l i p d i s t r i b u t i o n t h e s t r e n g t h decrease can be c a l c u l a t e d w i t h excel- l e n t accuracy by t h e SACHS- o r the TAYLOR-model on t h e b a s i s o f a q u a n t i t a t i v e t e x t u r e a n a l y s i s .

1. INTRODUCTION

For t h e p r o d u c t i o n o f h i g h q u a l i t y A1-Li semiproducts ready f o r s e r v i c e i t i s e s s e n t i a l ca g e t knowledge o f t h e i n f l u e n c e o f t h e p r o d u c t i o n c o n d i t i o n s on t h e p r o p e r t i e s o f t h e semiproduct. As t h e r e a r e l i t t l e p u b l i c a t i o n s e s p e c i a l l y f o r e x t r u s i o n s [1,2], t h e purpose o f t h i s i n v e s t i g a t i o n i s t o determine t h e i n f l u e n c e o f t h e e x t r u s i o n process parameters on t h e t e n s i l e p r o p e r t i e s o f d i f f e r e n t l y shaped e x t r u s i o n s . As t h e s t r e n g t h o f AT-Li sheet and p l a t e m a t e r i a l i s known t o have a stronger s u s c e p t a b i l i t y towards t e x t u r e [3-61, t h i s t o p i c i s a p o i n t o f s p e c i a l i n t e r e s t i n t h i s i n v e s t i g a t i o n .

2. EXPERIMENTAL PROCEDURE

The e x t r u s i o n b i l l e t s ( 0 77 x 200 mm) were machined from r e c t a n g u l a r DC c a s t bars (300 x 900 x 2500 mm). The chemical composition o f t h e used L i t a l A - a l l o y (8090) i s given i n Tab.1.

Tab. 1: Chemical composition o f t h e L i t a l A a l l o y i n v e s t i g a t e d

The b i l l e t s were homogenised f o r 24h a t 550°C i n a i r and d i r e c t l y extruded on a 3.15 MN-press w i t h a 80 mm d i a . conta,iner. W i t h i n 2 min. t h e b i l l e t s were heated t o t h e e x t r u s i o n temperatures o f 400°C o r 450°C, which were always equal t o those o f t h e container. C i r c u l a r rods (0 16 mm), and d i f f e r e n t f l a t shapes were ex- t r u d e d ( e x i t speed Zm/min.). A11 e x t r u d a t e s were s o l u t i o n t r e a t e d f o r 30 min. a t 535OC, quenched i n water (20°C) and then s t r e t c h e d ( 2 %) immediately. A f t e r pre-aging (5d, 20°C) t h e e x t r u s i o n s were aged a t 185OC. A d d i t i o n a l l y t h e c i r c u l a r r o d was aged w i t h o u t preceding s t r e t c h . The t e n s i l e p r o p e r t i e s were determined i n e x t r u s i o n d i r e c t i o n .

The t e x t u r e measurements were c a r r i e d o u t on a f u l l y automatic and computer-con- t r o l l e d t e x t u r e goniometer 171. For each specimen f o u r incomplete d i f f e r e n t p o l e f i g u r e s {Ill), (2001, 12203, {113) up t o a maximum t i 1 t i n g angle o f 85O were

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphyscol:1987322

(3)

C3-188 JOURNAL DE PHYSIQUE

measured, from which t h e three-dimensional o r i e n t a t i o n d i s t r i b u t i o n f u n c t i o n s (ODF) were c a l c u l a t e d [8]. By t h e means o f i s o t r o p i c Gaup-type d i s t r i b u t i o n func- t i o n s t h e ODF were separated i n t h e s i n g l e components o f t e x t u r e and q u a n t i - t a t i v e l y evaluated [9].

3. RESULTS

3.1 I n f l u e n c e o f S t r e t c h on t h e A r t i f i c i a l Aging Behaviour F i g . 1 shows t h e dependence o f t h e mecha-

n i c a l p r o p e r t i e s o f t h e c i r c u l a r rods from 6 M aging t i m e a t 185OC w i t h and w i t h o u t MPO

s t r e t c h ( e x t r u s i o n temperature 450°C). A t 2 t h e beginning o f aging t h e s t r e n g t h values w i t h o u t s t r e t c h a r e higher than those f o r _,o55m t h e s t r e t c h e d c o n d i t i o n . With i n c r e a s i n g

aging t i m e t h e s t r e n g t h f o r t h e unstretched Zbrn

c o n d i t i o n reaches a p l a t e a u f o l l o w e d by t h e R

peak s t r e n g t h . By s t r e t c h i n g , however, t h e s t r e n g t h i s c o n t i n u o u s l y i n c r e a s i n g t o i t s g3M

peak. Maximum s t r e n g t h i s achieved a f t e r

an aging time o f 30h f o r each treatment. zzoo _A

The y i e l d s t r e n g t h R is higher by

25 MPa and t e n s i l e s t r e n g t h Rm by '

10 MPa due t o s t r e t c h i n g . A t t h e ₁₀₀

beginning o f aging t h e e l o n g a t i o n values Trmted AGING TIME A drop f o r b o t h c o n d i t i o n s . Then f o r t h e

u k s t r e t c h e d r o d t h e e l o n g a t i o n remains F i g . 1: Age hardening curve (185OC) n e a r l y constant and then increases w i t h o f t h e c i r c u l a r r o d

overaging. For t h e s t r e t c h e d c o n d i t i o n

t h e e l o n g a t i o n e x h i b i t s a s l i g h t minimum and increases j u s t before t h e aging peak.

S t r e t c h i n g always r e s u l t s i n s l i g h t l y higher values of both s t r e n g t h and elonga- t i o n . Therefore i n t h e f u r t h e r i n v e s t i g a t i o n , a l l e x t r u s i o n s were s t r e t c h e d b e f o r e aging.

3.2 I n f l u e n c e o f E x t r u s i o n Parameters and Shape on t h e T e n s i l e P r o p e r t i e s

The s t r e n g t h o f d i f f e r e n t shapes ( c i r c u l a r and f l a t ) extruded a t 450°C and aged f o r 30h a t 185'C does n o t s y s t e m a t i c a l l y depend on t h e e x t r u s i o n r a t i o R ( F i g . 2 ) . For n e a r l y equal e x t r u s i o n r a t i o s i n t h e range from 1 : 22.3 t o 1 : 25.8 e.g.

600

oz

4 550

tsa I C

B = + Srn

d

V) Z Y C 0 ₃= ⁴⁵⁰

W >

4 0 0 1 : ~ ~ 1:30 1:LO 1:50 1:60 1:70 1:80 1:90 EXTRUSION RATIO R

10 15 20 25

EXTRUSION ASPECT RATIO (WIDTH I THICKNESS) WIT Fig. 2: I n f l u e n c e o f e x t r u s i o n r a t i o F i g . 3: Strength Rp0.2, Rm VS.

R on s t r e n g t h Rp0.2, Rm e x t r u s i o n aspect r a t i o W/T

(4)

t r u s i o n aspect r a t i o W/T o f w i d t h W t o thickness T. From t h e minimum W/T-ratio o f 1 (axisymmetric shapes) ( F i g . 3 ) t h e s t r e n g t h s t r o n g l y drops and i s s t i l l being reduced f o r W/T-ratios g r e a t e r than 10. T h i s r e d u c t i o n i s approximately by two times g r e a t e r f o r t h e y i e l d than f o r t h e t e n s i l e s t r e n g t h . Y i e l d s t r e n g t h d i f f e r s most between t h e c i r c u l a r r o d (W/T = 1 ) and the 65 x 3 mm f l a t shape (W/T = 21.7).

I n F i g . 3 t h e s t r e n g t h values o f t h r e e shapes extruded a t 400°C a r e given a d d i t i o - n a l l y . On a l e v e l 10-26 MPa higher than by e x t r u s i o n a t 450°C t h e y show t h e same W/T-dependency. I n order t o v e r i f y t h e i n f l u e n c e o f t h e W/T-ratio a t one

e x t r u s i o n t h e L-shape shown i n F i g . 3 was extruded a t 450°C. I t can be d i v i d e d i n s e c t i o n A ( t h i c k n e s s 12 mm, W/T = 1 ) and s e c t i o n B ( t h i c k n e s s 2 mm, W/T = 16, i f t h e e n t i r e w i d t h o f t h e shape i s considered). The s t r e n g t h values o f t h e s e c t i o n s A and B f i t very good t o the dependency o f Fig. 3. The e l o n g a t i o n values ( F i g . 4) a r e n e a r l y independent from t h e W/T-ratio and do n o t d i f f e r s i g n i f i c a n t l y f o r t h e

R 1:27

0 ~ 1 5 10 15 2 0 25

EXTRUSION ASPECT RATIO (WIDTH / THICKNESS1 W I T

6 0 0 25

MP0 Ye

d ^{5 0 0} ^{2 0}

N 0 m mc

4 0 0

I 15 g

W

DL r

- ^e

"

7 ^bu

7 ^{3 0 0} 0

Z 10 g

w *

r)

9 200 ⁵

Y -

>

I

lo2 h 10)

Treated AGING TIME

F i g . 4: Elongation A5 vs. e x t r u - F i g . 5: Age hardening curve o f s i o n aspect r a t i o W/T s e c t i o n A and B (L-shape) two e x t r u s i o n temperatures. The i n f l u e n c e o f t h e s t a t e o f p r e c i p i t a t i o n on t h e W/T-dependency was determined by t h e age hardening curves o f t h e s e c t i o n s A and B ( F i g . 5 ) . As expected from t h e same W/T- r a t i o o f 1, s i m i l a r curves f o r s t r e n g t h and e l o n g a t i o n a r e observed f o r s e c t i o n A and t h e c i r c u l a r r o d ( F i g . 1 ) . I n s e c t i o n B, however, t h e peak s t r e n g t h i s reached 20h l a t e r and t h e s t r e n g t h i s always lower. There a r e a l s o considerable d i f f e r e n c e s i n t h e e l o n g a t i o n curves.

I . L ... l . . ... I . .

Solution ' lo0 10'

T r w t e d AGING TIME

Fig. 6: Strength d i f f e r e n c e between F i g . 7: Grain s t r u c t u r e o f s e c t i o n A and B vs. aging time s e c t i o n A ( a ) and B ( b )

(5)

C3-190 JOURNAL DE PHYSIQUE

A t t h e begin o f aging t h e e l o n g a t i o n d e c l i n e s f o r t h e two sections. For s e c t i o n B i t remains n e a r l y constant up t o t h e overaged c o n d i t i o n . Section A e x h i b i t s lower e l o n g a t i o n values w i t h a minimum a f t e r 8h. Having reached i t s peak aged c o n d i t i o n t h e e l o n g a t i o n i s even s i g n i f i c a n t l y g r e a t e r than t h a t o f s e c t i o n B.

The d i f f e r e n c e o f y i e l d s t r e n g t h AR and t e n s i l e s t r e n g t h AR between s e c t i o n A and B changes w i t h aging t i m e ( F ~ B ? . ~ 6). A f t e r quenching andmin t h e overaged c o n d i t i o n the AR - and AR -values a r e lowest. With t h e begin o f agingAR increases r a p i d l Y 0 d d reache! i t s maximum (125 MPa) a f t e r 7h i n t h e underaggdm2 c o n d i t i o n . The d i f f e r e n c e s i n t e n s i l e s t r e n g t h AR a r e approximately h a l f o f those i n y i e l d s t r e n g t h . Compared w i t h t h e curve ?or AR the maximum i s l e s s pronounced and i s reached a f t e r a longer aging t i m e p0.2

(16h).

4.3 I n f l u e n c e o f M i c r o s t r u c t u r e

The m i c r o s t r u c t u r e s o f s e c t i o n A and B (30h 185OC) were examined by l i g h t and TEM microscopy i n order t o determine t h e reason f o r t h e s t r e n g t h d i f f e r e n c e s . I n t h e c e n t r e o f s e c t i o n A and B (Fig. 7 ) t h e r e i s an as-extruded m i c r o s t r u c t u r e w i t h pancake-shaped g r a i n s i n s e c t i o n B due t o t h e g r e a t e r W/T-ratio. A t t h e o r i g i n a l g r a i n boundaries a f i n e r e c r y s t a l l i s a t i o n has s t a r t e d w i t h t h e r e c r y s t a l l i s e d volume f r a c t i o n s l i g h t l y g r e a t e r i n s e c t i o n B. The r e s u l t s o f t h e TEM-examination show t h e subgrains t o be equal i n s t r u c t u r e and s i z e . There are a l s o no d i f f e r e n - ces i n t h e s t a t e o f p r e c i p i t a t i o n - T h e f l a t t e r g r a i n s i n p a r t B and t h e h i g h e r degree o f r e c r y s t a l l i s a t i o n a r e u n l i k e l y t o cause t h e remarkable d i f f e r e n c e i n s t r e n g t h .

4.4 I n f l u e n c e o f Texture

The { I l l ) - p o l e f i g u r e s taken from t h e c e n t r e o f s e c t i o n A and B d i f f e r consider- a b l y ( F i g . 8). According t o i t s axisymmetric deformation s e c t i o n A shows a pronounced <111>+<100> double f i b r e t e x t u r e .

F i g . 8: { 1 1 l ) - ~ o l e f i g u r e s o f s e c t i o n A ( a ) and B ( b )

Due t o t h e predominantly plane deformation t h e t e x t u r e o f s e c t i o n B i s s i m i l a r t o t h a t achieved by r o l l i n g . The volume f r a c t i o n s o f each t e x t u r e component and t h e background were determined from t h e ODF's (Tab. 2 ) . The double f i b r e t e x t u r e ( s e c t i o n A) i s composed o f 75 % i n <Ill> d i r e c t i o n and o f 22 % i n <loo> d i r e c - t i o n . I r r e s p e c t i v e o f s l i g h t d e v i a t i o n s from t h e given i d e a l o r i e n t a t i o n , i n s e c t i o n B t h e t h r e e t y p i c a l r o l l i n g t e x t u r e s S, Bs and Cu predominate w i t h a t o t a l amount o f 65.9 %. For each t e x t u r e component t h e o r i e n t a t i o n f a c t o r s Ms and Mt resp. were c a l c u l a t e d , which r e l a t e y i e l d s t r e s s a and c r i t i c a l r e s o l v e d

shear s t r e s s rc : ^Y

(6)

TAYLOR-factor. According t o t h e SACHS-model [ l o ] p l a s t i c deformation occurs as s i n g l e s l i p i n t h e {Ill} <110> s l i p system w i t h t h e minimum f a c t o r Ms, i .e. t h e maximum SCHMID-factor m. The TAYLOR- model [Ill, however, i s v a l i d f o r m u l t i - s l i p i n a t l e a s t f i v e independent {Ill} <110> s l i p systems. I n Tab. 2 t h e f a c t o r s Ms

Section A Section B

<uvw> Mi% Mt Ms Component { h k l } <uvw> Mi% Mt Ms

Background 3 3.07 2.24 Cu {112} <Ill>

Goss/Bs { O l l ) <511>

- {138} <751>

- (111) <112>

cube^^ {025} <loo>

Background

-- - - .-

Mean-Value

Mt, Ms 3.38 3.36

Tab. 2: Volume f r a c t i o n M i , TAYLOR-factors Mt and SACHS-factors Ms f o r t h e t e x - t u r e components.

and Mt are given f o r l o a d i n g i n e x t r u s i o n d i r e c t i o n <uvw>. Except f o r the <Ill>

and <loo> o r i e n t a t i o n s t h e M t - f a c t o r s a r e g r e a t e r than t h e Ms-factors, because i n t h e case o f m u l t i - s l i p l e s s favoured s l i p systems must be a c t i v e t o m a i n t a i n c o m p a t i b i l i t y a t t h e g r a i n boundaries. The Mt and Ms f a c t o r s a r e equal f o r t h e

<Ill> and <loo> o r i e n t a t i o n s , because 6 and 8 s l i p systems resp. have t h e same Ms-factor, thus s u f f i c i e n t e q u i v a l e n t s l i p systems-being a c t i v e f o r t h e v a l i d i t y o f t h e TAYLOR-model. The mean o r i e n t a t i o n f a c t o r s Ms and mt -balanced-with t h e volume f r a c t i o n - a r e n e a r l y equal f o r s e c t i o n A. I n s e c t i o n B Ms and Mt d i f f e r considerabl and t h e y a r e lower than i n s e c t i o n A,especial l y f o r t h e SACHS-model .

The higher #t and As values o f s e c t i o n A a r e due t o t h e h i g h volume f r a c t i o n (75 %) o f <Ill> o r i e n t a t i o n s w i t h t h e h i g h e s t M t and Ms f a c t o r s a t a l l . For t h e same c r i t i c a l resolved shear s t r e s s i n both s e c t i o n s t h e d i f f e r e n c e o f t h e y i e l d s t r e n g t h AR PO. 2 r e l a t e d t o t h e y i e l d s t r e n g t h o f s e c t i o n A [R p0.2 ( A ) ] can be

30

% 25

=? - 2 0

d E? -+

=qs a

10

3

Treoted AGING TIME

F i g . 9: Strength d i f f e r e n c e r e l a - Fig. 10: S l i p d i s t r i b u t i o n ( a ) t e d t o "A" vs. aging t i m e and p r e c i p i t a t i o n ( b )

o f s e c t i o n B (2h 185OC)

(7)

C3-192 JOURNAL DE PHYSIQUE

c a l c u l a t e d from Rs and i t w i t h eqn. ( 1 ) :

SACHS: A RpO. 2/Rp0. (A) = 26.2 % TAYLOR: D RpO. 2/Rp0. (A) = 7.7 %

These models d e s c r i b e extreme c o n d i t i o n s w i t h t h e SACHS-model as t h e upper and t h e TAYLOR-model as t h e lower l i m i t f o r t h e r e l a t i v e d i f f e r e n c e i n y i e l d s t r e n g t h P r i n c i p a l l y t h e r e l a t i v e s t r e n g t h d i f f e r e n c e ( F i g . 9 ) shows t h e same dependency from aging time as t h e mere s t r e n g t h d i f f e r e n c e ARp0.2.

I n t h e underaged c o n d i t i o n (2h aging t i m e ) t h e maximum o f 27 % i s achieved. A f t e r quenching o r overaging t h e values a r e lowest (12 %, 15 % resp.).

F i g . 11: S l i p d i s t r i b u t i o n ( a ) F i g . 12.: S l i p d i s t r i b u t i o n o f

and p r e c i p i t a t i o n ( b ) s e c t i o n B ( s o l u t i o n t r e a t e d ) o f s e c t i o n B (150h 185OC)

5. DISCUSSION

The a p p l i c a b i l i t y o f e i t h e r t h e SACHS- o r t h e TAYLOR-model depends on t h e pre- dominant slip-mode, which was determined by TEM-analysis o f deformed and n o t deformed s e c t i o n s o f t h e f a i l e d t e n s i l e specimens ( s e c t i o n B ) .

For t h e underaged c o n d i t i o n (2h 185OC) s l i p occurs on s i n g l e , v e r y pronounced s l i p bands (Fig. 10a). T h i s inhomogeneous s l i p d i s t r i b u t i o n i s a t t r i b u t e d t o t h e s p h e r i c a l , ordered and coherent 6 ' (A13Li)- p r e c i p i t a t e s ( F i g . l o b ) e a s i l y shear- a b l e by d i s l o c a t i o n s . Once s l i p i n t h e system w i t h t h e lowest SACHS-factor has s t a r t e d and c u t 6 ' - p r e c i p i t a t e s , t h i s p r i m a r y s l i p plane i s weakened and f u r t h e r s l i p i s b e i n g concentrated on i t l e a d i n g t o t h e observed f o r m a t i o n o f s l i p bands [12]. Therefore t h e r e l a t i v e s t r e n g t h d i f f e r e n c e i n t h i s c o n d i t i o n must be c a l c u l a t e d by SACHS, which i s c l e a r l y confirmed by t h e experiment. A f t e r overaging (150h 185OC) t h e s l i p d i s t r i b u t i o n i s completely homogeneous ( F i g . l l a ) due t o t h e p a r t l y coherent S'(A1 CuMg) l a t h s besides 6 ' - p r e c i p i t a t e s a c t i n g as obstacles t o d i s l o c a t i o n movgment ( F i g . l l b ) . They a r e bypassed on o t h e r (secondary) s l i p systems w i t h t h e n e c e s s i t y o f m u l t i - s l i p [4,13].

A f t e r quenching s l i p i s a l s o homogeneous ( F i g . 12), as t h e 6 ' - p r e c i p i t a t e s a r e t o o small t o be d e t e c t e d and t o cause inhomogeneous s l i p [14]. The homogeneous s l i p i s o b v i o u s l y caused by m u l t i - s l i p . For t h e quenched and t h e overaged condi- t i o n t h e low r e l a t i v e d i f f e r e n c e i n s t r e n g t h t h e r e f o r e agrees w e l l w i t h t h e c a l - c u l a t i o n according t o t h e TAYLOR-model.

(8)

Compared w i t h e x t r u s i o n temperature and r a t i o t h e s t r e n g t h o f L i t a l A-shapes s t r o n g l y depends on t h e e x t r u s i o n aspect r a t i o ( w i d t h / t h i c k n e s s ) W/T which

- changes t e x t u r e

- reduces s t r e n g t h w i t h shapes g e t t i n g f l a t t e r ( i n c r e a s i n g W/T)

- b r i n g s about a s t r e n g t h d i f f e r e n c e between axisymmetric and f l a t shapes, which i s g r e a t a t t h e begin o f aging and low a f t e r quenching and i n t h e overaged c o n d i t i o n .

As t h e t e x t u r e - s t r e n g t h r e l a t i o n s h i p i s described by t h e SACHS-model f o r s i n g l e s l i p and by TAYLOR f o r m u l t i - s l i p , t h e s t r e n g t h d i f f e r a n c e can be c a l c u l a t e d on t h e b a s i s o f a q u a n t i t a t i v e t e x t u r e a n a l y s i s w i t h good agreement

- by SACHS f o r t h e inhomogeneous s l i p d i s t r i b u t i o n - a t t h e begin o f a g i n g

- by TAYLOR f o r t h e homogeneous s l i p d i s t r i b u t i o n a f t e r quenching and i n t h e overaged c o n d i t i o n .

ACKNOWLEDGEMENTS

T h i s work was sponsored by t h e BMFT. The t e x t u r e a n a l y s i s by J. H i r s c h ( I n s t i t u t f u r Metallkunde, RWTH Aachen) i s g r a t e f u l l y acknowledged.

REFERENCES

[ 11 N.C. Parson and T. Sheppard i n : "Aluminium-Lithium A l l o y s 11", ed.: T.H.

Sanders, J r . and E.A. Starke, TMS-AIME, Warrendale, PA (1984) 53.

[ 21 N.C. Parson and T. Sheppard i n : "Aluminium-Lithium A l l o y s I I I M , e d . : C.Baker e t a l . , The I n s t i t u t e o f Metals, London (1986) 222.

[ 31 M. Peters, K. Welpman and T.H. Sanders, J r . , Proc. 3 r d Conf. o f E-MRS on Advanced M a t e r i a l s R & D f o r Transport, ed.: R.J.H. Wanhill e t a l . , Les B d i t i o n s de physique, Les U l i s (1986) 63.

[ 41 P.J. Gregson and H.M. Flower, Acta M e t a l l , 2 (1985) 527.

[ 51 M. Peters, J. Eschweiler and K. Welpmann, S c r i p t a Met., 20 (1986) 259.

[ 61 S. Fox, D.S. Mc Darmaid and H.M. Flower, Conf. Aluminium Technology 1986, The I n s t i t u t e o f Metals, London (1986) 72.1.

[ 71 J. Hirsch, G. Burmeister, L. Hoenen and K. Lucke i n : 'Experimental Techniques o f Texture Analysis", ed. : H. J . Bunge, DGM-Verlag (1986) 63.

[ 81 H.J. Bunge "Mathematische Methoden der Texturanalyse" Akademie Verlag B e r l i n (1969).

[ 91 J. H i r s c h and K. Lucke i n : " T h e o r e t i c a l Techniques o f Texture Analysisl',ed.:

H. J. Bunge, DGM-Verlag (1987).

[ l o ] E. Sachs, Z . Verein Deutsch. Ing. 72 (1928) 734.

[ll] G . I . T a y l o r , J. I n s t . Met. 62 ( 1 9 3 q 307.

[12] K . Welpmann, M. Peters, T.H. Sanders, J r . , Aluminium 60 (1984) 735 and 846.

[ I 3 1 W.S. M i l l e r , M.P. Thomas, D.J. L l o y d and D. Creber, Mater. S c i . and Techn. 2

(1986) 1210.

[14] K. V.- J a t a and E.A. Starke, J r . , M e t a l l . Trans. A. Z A (1986) 1011.
