RELATION BETWEEN THE DAMPING SPECTRUM AND THE DISLOCATION MOTION IN MARTENSITIC ALLOYS

HAL Id: jpa-00221026

https://hal.archives-ouvertes.fr/jpa-00221026

Submitted on 1 Jan 1981

HAL is a multi-disciplinary open access

archive for the deposit and dissemination of

sci-entific research documents, whether they are

pub-lished or not. The documents may come from

teaching and research institutions in France or

abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est

destinée au dépôt et à la diffusion de documents

scientifiques de niveau recherche, publiés ou non,

émanant des établissements d’enseignement et de

recherche français ou étrangers, des laboratoires

publics ou privés.

RELATION BETWEEN THE DAMPING SPECTRUM

AND THE DISLOCATION MOTION IN

MARTENSITIC ALLOYS

R. Gotthardt, O. Mercier

To cite this version:

RELATION BETWEEN THE DAMPING SPECTRUM AND THE DISLOCATION MOTION I N MARTENSITIC ALLOYS

R. G o t t h a r d t and 0. ~ e r c i e r *

I n s t i t u t de Ge'nie Atomique, Swiss Federal I n s t i t u t e of Technology, EeubZens CH-1015 Lausanne, ~ w i t z e r t a n d

* ~ r o m Boveri Research Center, CH-5401 Baden, SwitzerZand

Abstract. - I n t e r n a l f r i c t i o n spectra measured on m a r t e n s i t i c a l l o y s a l l e x h i b i t a common f e a t u r e : t h e i n t e r n a l f r i c t i o n i s h i g h i n t h e m a r t e n s i t i c phase and low o r very low a t h i g h temperatures, when t h e m a t e r i a l has a B s t r u c t u r e . Transmission e l e c t r o n microscopy observations revealed a h i g h d e n s i t y o f new i n t e r f a c e d i s l o c a t i o n s i n t h e martensite. A q u a l i t a t i v e model i s proposed which explains t h e h i g h damping o f t h e m a r t e n s i t e by the movement o f these d i s l o c a t i o n s .

1. I n t r o d u c t i o n

-

The i n t e r n a l f r i c t i o n spectra measured i n d i f f e r e n t m a r t e n s i t i c a l l o y s , as e.g. N i T i o r CuZnAl

,

a l l reveal a r e l a t i v e l y h i g h i n t e r n a l f r i c t i o n i n t h e m a r t e n s i t i c phase and a low i n t e r n a l f r i c t i o n i n the m a t r i x o r 6 phase (1,2). I n an o p t i c a l micrograph o f t h e surface o f a completely transformed m a t e r i a l , a h i g h number o f elongated p l a t e s can be observed i n s i d e t h e o r i g i n a l g r a i n s (Fig.1).

F i g . 1 : O p t i c a l micrograph o f a CuZnAl a1 l o y showing t h e d i f f e r e n t m a r t e n s i t e p l a t e s and t h e o r i g i n a l B-grai ns

Transmission E l e c t r o n Microscopy (TEN) observations o f these m a r t e n s i t e p l a t e s show a complicated s t r u c t u r e c o n s i s t i n g o f i n t e r f a c e s , d i s l o c a t i o n s and s t a c k i n g f a u l t s i n the case o f CuZnAl and t w i n s i n t h e case o f N i T i . I n f i g u r e 2, a TEM micrograph o f a s t r e s s induced m a r t e n s i t e p l a t e growing i n s i d e the CuZnAl-matrix i s shown. A t i t s t i p a d i s l o c a t i o n i s seen, bowing i n a convex (Fig. 2a) and a concave form (Fig. 2b) under an i n c r e a s i n g o r decreasing a p p l i e d s t r e s s r e s p e c t i v e l y . I n s i d e t h e m a r t e n s i t i c phase many s t a c k i n g f a u l t s and d i s l o c a t i o n s

(P)

a r e seen, as shown i n t h e f i g u r e s 3 and 5. The i n t e r f a c e s , separating m a r t e n s i t i c and m a t r i x phase (Fig. 4) o r m a r t e n s i t e p l a t e s among each other, c o n s i s t o f many d i s l o c a t i o n s ( S ) .

C5-996 JOURNAL DE PHYSIQUE

Fig. 2: a b Fig. 3:

Fig. 2: Electron microscopy micrograph of a m a r t e n s i t i c p l a t e growing i n a matrix phase

B of a CuZnAl a l l o y , induced by an i n c r e a s i n g ( a ) and a decrea- s i n g ( b ) a p p l i e d s t r e s s . Fig

.

3 : Electron microscopy micrograph of t h e m a r t e n s i t i c phase

( M )

of a CuZnAl-alloy;

P : d i s l o c a t i o n s a t t h e s t a c k i n g f a u l t s end.

Fig. 4: I n t e r f a c e between a

6-

and a m a r t e n s i t i c phase of a CuZnAl a l l o y (S : I n t e r f a c e d i s l o c a - t i o n s , f o r more d e t a i l s , s e e t e x t ) .

-Fig. 5: Electron microscopy micrograph of a completely transformed CuZnAl a1 1 oy ( f o r d e t a i l s , s e e t e x t )

The observation of two s o r t s of d i s l o c a t i o n s , P and S , i n t h e micrographs of t h e f i g u r e s 3,4 and 5 can be understood with t h e a i d of f i g u r e s 6 .

t e x t .

thinning process f o r the preparation of

TEM

samples, such martensite plates can be

cut horizontally or v e r t i c a l l y . The figures 6a and 6c show f o r these two cases the

resulting thin samples. For them the dislocations

P

appear in a quite d i f f e r e n t way,

which i s seen i n the figure 5: the case of f i g . 6a i s shown in the l e f t p a r t , and

the one of f i g . 6c i n the r i g h t part. The habitplane with i t s interface-dislocations

S

can be seen i n figure 5 parallel t o

I-K

and with a higher magnification in figure

4.

From the l a t t e r the distance

A

between the i n t e r f a c e dislocations can be determined

0

as about 45

A .

TEM

studies of i n s i t u deformation of a specimen containing martensite plates

revealed t h a t the i n t e r f a c e dislocations are mobile and migrate 'under the influence

of an applied s t r e s s a l l together i n a block; as a consequence the p l a t e width in-

creases. That means t h a t the phase transformation has created a high number of mo-

b i l e dislocations.

2.

Damping model

-

In order t o understand i f the observed dislocations can contri-

bute t o a large degree t o the high damping of the martensite, the damping f o r both

phases i s discussed i n general terms in order t o find which parameters change d r a s t i -

c a l l y from one phase t o the other and can therefore explain the sharps increase in

damping

.

The damping D(R) of a unit element of a dislocation segment

R

js

:

C5-998 JOURNAL DE PHYSIQUE

due t o a viscous f r i c t i o n w i t h t h e l a t t i c e , Bv, o r due t o t h e i n t e r a c t i o n o f segment R w i t h p o i n t defects, which leads t o a given m o b i l i t y M o f a.

For low frequency measurements, an !L2-dependence o f

D

i s the most g e n e r a l l y accepted one, when t h e f r i c t i o n i s due t o non a t t r a c t i v e obstacles o r t o depinning processus (3)(then R i s t h e d i s t a n c e between s t r o n g p i n n i n g p o i n t s ) , thus

The t o t a l damping D i s then :

CO

D = (a)

a

D ( R ) ~ R

i

where p(R) dR i s t h e d i s t r i b u t i o n o f segments

a,

which has t o be d e f i n e d f o r each phase.

3. Damping o f t h e 8-phase

-

With t h e assumption t h a t 8 d i s l o c a t i o n s a r e random and t h a t t h e s t r o n g p i n n i n g p o i n t s a r e t h e i n t e r s e c t i o n s o f d i s l o c a t i o n s (N p e r u n i t volume), t h e average segment l e n g t h LN i s :

The d e n s i t y o f d i s l o c a t i o n

X

i s

where a i s t h e average number o f segments p e r i n t e r s e c t i o n p o i n t (1

<

a

<

3)

_(4).

For a random network, t h e d i s t r i b u t i o n i s from reference (5):

I n r e p l a c i n g ( 4 ) - (6) i n (3), we g e t

I n t h i s case, D i s independant o f

X

and R.

t h e segment l e n g t h i s L, and p(R)dR = - 6(R-L2)dR 3 ( 9 )

L 2

where 6 i s t h e d e l t a f u n c t i o n . By r e p l a c i n g (8) and ( 9 ) i n ( 3 ) , we g e t :

The values L1, Lp and W, as w e l l as n can be measured i n t h e o p t i c a l and e l e c t r o n microscope micrographs.

5. Discussion

-

The d i s l o c a t i o n damping o f t h e two phases i s made o f 2 terms, a p r e f a c t o r m u l t i p l i e d by t h e damping o f a u n i t element o f d i s l o c a t i o n . The l a t t e r (D ₀

₈

and DOM) a r e n o t easy t o compute w i t h o u t a more d e t a i l e d model o f t h e d i s l o c a - t i o n motion and o f t h e d i s l o c a t i o n i n t e r a c t i o n w i t h i t s surrounding. However, i t i s reasonable t o assume t h a t t h e i r v a l u e ( f o r one u n i t element o f d i s l o c a t i o n ) i s about t h e same, since t h e b a s i c o r d e r o f the a l l o y and the number o f p i n n i n g p o i n t s are n o t changed by t h e t r a n s f o r m a t i o n . From t h e change o f t h e e l a s t i c l i m i t however, which decreases by a f a c t o r o f about 2-5 f o r t h e CuZnAl a l l o y s (6)and by a f a c t o r o f about 5-10 f o r t h e FiiTiCu a l l o y s (7), i t can be deduced t h a t t h e d i s l o c a t i o n s a r e probably more m o b i l e i n t h e m a r t e n s i t e than i n t h e 6-phase, and thus

JOURNAL DE PHYSIQUE

o r t h e d i s l o c a t i o n m o b i l i t y have some e f f e c t on t h e l e v e l o f t h e damping; b u t we b e l i e v e t h a t t h e i r e f f e c t s a r e l e s s i m p o r t a n t and would r a t h e r e x p l a i n t h e v a r i a - t i o n i n temperature o f t h e damping i n each phase. The c a l c u l a t e d model p r e d i c t s t h a t t h e h i g h e s t m a r t e n s i t e damping w i l l be f o r m a r t e n s i t e w i t h t h e h i g h e s t number o f s t a c k i n g f a u l t s and w i t h an elongated shape such as L22>>L,W.

References

(1) B. Tirbonod, S. Koshimizu, t o be published i n t h e Froc. o f t h e 7 t h ~ ~ ~ ~ ~ ~ ~ (2) 0. Mercier, K.N. Melton, Y. De P r e v i l l e , Acta Met.

3,

1467 (1979)

(3) R.B. Schwarz, Acta Met.

29,

311 (1981)

(4) a = 1 f o r a l i n e a r chain o f d i s l o c a t i o n s and a = 3 f o r a t h r e e dimensional network o f d i s l o c a t i o n s .

(5) J.S. Koehler, Imperfections i n Nearly P e r f e c t C r y s t a l s , ed. by W. Shockley and a l . , p. 197, W. Ley, New York 1952
