INTERNAL FRICTION STUDY OF THE γ PEAK IN COLD-WORKED NIOBIUM

(1)

HAL Id: jpa-00220989

https://hal.archives-ouvertes.fr/jpa-00220989

Submitted on 1 Jan 1981

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are published or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

INTERNAL FRICTION STUDY OF THE γ PEAK IN COLD-WORKED NIOBIUM

F. de Lima, W. Benoit

To cite this version:

F. de Lima, W. Benoit. INTERNAL FRICTION STUDY OF THE γ PEAK IN COLD- WORKED NIOBIUM. Journal de Physique Colloques, 1981, 42 (C5), pp.C5-85-C5-90.

�10.1051/jphyscol:1981512�. �jpa-00220989�

(2)

JOURNAL DE PHYSIQUE

CoZZoque C5, supple'ment au nO1O, Tome 42, octobre 1981 page C5-85

INTERNAL FRICTION STUDY O F THE y P E A K IN COLD-WORKED NIOBIUM

I n s t i t u t de Ge'nie Atomique, Swiss Federal I n s t i t u t e o f Technology, EcubZens CH - 1015 Lausanne, SwitzerZand

A b s t r a c t . - The y peak due t o t h e double k i n k generation (DKG) along screw d i s l o c a t i o n s has been observed i n h i g h p u r i t y niobium. This peak appears a t 270K ( 1 Hz) and i s unstable. Some s p e c i a l thermomechanical treatments have been r e a l i z e d i n order t o develop and s t a b i l i z e t h i s peak.

The e v o l u t i o n o f t h e i n t e r n a l f r i c t i o n spectra has been s t u d i e d as a f u n c t i o n o f these treatments. The screw d i s l o c a t i o n s network c r e a t e d by low temperature deformation i s unstable and rearranges i n two stages: a W stage (180K-240K) and a X stage (280K-350K).

The t r a n s f o r m a t i o n accomplished i n t h e W stage and t h e e f f e c t o f t h e y peak s t a b i l i z a t i o n treatment have been observed by transmission e l e c t r o n

microscopy.

1. I n t r o d u c t i o n . - The p l a s t i c deformation o f a r e a l s o l i d i s t h e macroscopic consequence o f d i s l o c a t i o n motion. The m o b i l i t y o f these d i s l o c a t i o n s i s i t s e l f connected w i t h d i f f e r e n t microscopic processes. These processes t o overcome obstacles can occur simultaneously. Some s o l i d s , due t o t h e s p e c i a l c h a r a c t e r i s t i c s o f c e r t a i n defects, present a few processes t h a t occur almost i n an i s o l a t e d manner. I t i s t h e case of t h e bcc t r a n s i t i o n metals, i n which t h e s p e c i a l p r o p e r t i e s o f screw d i s l o c - a t i o n s (1) a r e r e s p o n s i b l e f o r an increase o f t h e c r i t i c a l shear s t r e s s (CSS) w i t h decreasing temperature (2). The temperature from which t h e CSS becomes athermal i s c a l l e d t r a n s i t i o n temperature (Tc). A t Tc t h e screw d i s l o c a t i o n s g e t m o b i l e under a low a p p l i e d s t r e s s through t h e t h e r m a l l y a c t i v a t e d DKG. During i n t e r n a l f r i c t i o n measurements such DKG along screw d i s l o c a t i o n s i s r e s p o n s i b l e f o r a r e l a x a t i o n phe- nomenon c a l l e d t h e y peak. This peak and i t s r e l a x a t i o n c h a r a c t e r i s t i c s have recent- l y been e x t e n s i v e l y s t u d i e d i n d i f f e r e n t bcc metals (3-6). The i n s t a b i l i t y o f t h i s peak i s r e l a t e d t o t h e rearrangement o f the screw d i s l o c a t i o n network, which i s t h e s u b j e c t o f t h i s study.

2. I n t e r n a l f r i c t i o n . - 2.1.- hmpl$-p[epamaAon.- The niobium samples from M a t e r i a l s Research Co. have 100 atppm Ta as t h e main m e t a l l i c i m p u r i t y and 400 atppm o f i n t e r - s t i t i a l i m p u r i t i e s (H,O,C and N). The sample p u r i f i c a t i o n has consisted i n a decar- b u r i z a t i o n treatment ( 3 hours a t 2173K under an oxygen pressure o f T o r r ) f o l l o w - ed by a h i g h temperature annealing ( 3 hours a t 2500K under a vacuum pressure o f about 7x10-lo T o r r ) . A f t e r t h i s p u r i f i c a t i o n treatment t h e i n t e r s t i t i a l c o n c e n t r a t i o n

*On leave from IPEN, Sao Paulo, B r a z i l

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphyscol:1981512

(3)

C5-86 JOURNAL DE PHYSIQUE

should be about 100 atppm (3).

2.2. _Exewjmw_t.- The i n t e r n a l f r i c t i o n and frequency measurements were c a r r i e d o u t i n an i n v e r t e d t o r s i o n pendulum under a frequency o f 1.3 Hz and i n a temperature i n t e r v a l from 77K t o 347K. The maximum surface s t r a i n amplitude was and t h e h e a t i n g r a t e was 1°/min.

2.3. Results.- - - - - - - - 2.3.1. y, al anda2 peaks .- The y peak associated t o t h e t h e r m a l l y a c t i v a t e d DKG along t h e screw d i s l o c a t i o n s have been observed r e c e n t l y i n niobium

(3). I t appears a t 270K a t low frequency ( 1 Hz) according t o t h e p l a s t i c deformation observations (TC=230K).

A systematic study o f the e f f e c t o f deformation amplitude and deformation tem- p e r a t u r e has shown t h e optimum deformation c o n d i t i o n s t o observe an i m p o r t a n t r e l a x - a t i o n . They are: 160K < Tdef < 200K and E~~~ = 5%.

The y peak g e n e r a l l y anneals o u t i n a temperature range s i t u a t e d near t h e peak temperature. A s p e c i a l thermomechanical treatment has been performed i n order t o s t a b i l i z e the d i s l o c a t i o n network: a room temperature predeformation o f 3% i n t r a c t - i o n f o l l o w e d by a s e r i e s (about 15) o f successive 5% t o r s i o n d e f o r m a t i o r s a t 200K w i t h i n t e r c a l a t e d l i n e a r annealings up t o room temperature (RT) and t h e l a s t 5 a t 347K.

The r e l a x a t i o n c h a r a c t e r i s t i c s o f the peak have then been determined:

E = (0.61 +0.02) eV, -rm= l o - " sec and i t i s 1.3 times wider than a s i n g l e Debye peak.

The al and a2 peaks have been observed a t 150K and 120K, r e s p e c t i v e l y , a t 1.3

Hz. I t i s g e n e r a l l y accepted t h a t these peaks are due t o the i n t e r a c t i o n o f hydrogen w i t h d i s l o c a t i o n s (7) .

2.3.2. I n f l u e n c e o f deformation temperature.- To p u t i n evidence the i n f l u e n c e o f t h e deformation temperature on t h e i n t e r n a l f r i c t i o n spectra, two deformation temperatures have been chosen, below and above Tc. I n f i g u r e 1 a r e presented t h e curves o f i n t e r n a l f r i c t i o n as a f u n c t i o n o f the measurement temperature, corresponding t o d i f f e r e n t treatments r e p o r t e d on t h e f i g u r e . The fundamental d i f f e r e n c e i s t h a t t h e

low temperature deformation develops

Q-I 103 1 = I 3 H z m a i n l y t h e a2 and y peaks ( c u r v e c ) ,

a A l t e r drgasrlnp b A t f e r 3 % fraotmon R T

c r \ l t e r I % forrlan 160K w h i l e t h e RT deformation i s r e s p o n s i b l e

f o r t h e al peak. The p a r t i c i p a t i o n o f the screw d i s l o c a t i o n s i n t h e a 2 and y r e l a x a t i o n s and o f t h e 71° d i s l o c - a t i o n s i n t h e a, peak seems c l e a r (3).

Concerning t h e i n t e r p r e t a t i o n o f these

T(K)

c

⁴⁰ ^zw ³⁰⁰ peaks, some r e c e n t observations a r e

F i g . 1 : I n t e r n a l f r i c t i o n s p e c t r a o f 3 s i g n i f i c a t i v e . R i t c h i e e t a1. (4) i n a- degassed samples: a) a f t e r degassing; i r o n and Yaul e t a1 . (7) i n niobium b ) a f t e r cold-work 3% i n t r a c t i o n a t

RT and c ) a f t e r cold-work 1% i n t o r s i o n a t 160K

(4)

have observed an internal f r i c t i o n peak a t 30K (0.5 Hz) and 70K (1 KHz), respective- l y . They have been interpreted by a DKG along 71° dislocation. Moreover, Ritchie e t a1 . (4) observed a frequency variation a t 4K t h a t i s associated t o the geometrical kink migration. The connection between the influence of hydrogen on the ul and a2 peaks, and these l a s t i n t e r p r e t a t i o n s have lead us t o the following conclusion: the hydrogen i n t e r a c t s with DKG along the 71° dislocations f o r al and with geometrical kink migration in screw dislocations f o r a,. The y peak i s due t o the thermally activated DKG along the screw dislocations (3) .

2.3.3. Recovery stages.- The difference of mobility between 71° and screw dislocations i n bcc metals favours the study of the evolution of the internal f r i c t i o n spectrum as a function of the annealing treatments. As mentioned before, the screw dislocations g e t mobile under a low applied s t r e s s a t temperatures near Tc, while the 71' get mobile a t much lower temperature ( ~ 4 0 K ) . Then i t i s i n t e r e s t i n g t o inserl screw dislocations i n t h e i r "froze-in" s t a t e ( T < Tc) and follow t h e i r evolution

def

with anneal ings a t temperatures near Tc . The 1 i near anneal i ngs real ized between 180K and 350K showed two recovery stages, t h a t i s , two annealing temperature ranges durinI which the internal f r i c t i o n spectrum changes: W stage (180K-240K) and X stage (280K- 350K). Figure 2 shows the r e s u l t s obtained with a degassed sample deformed 1% i n torsion a t 160K (curve a ) and then submitted t o the l i n e a r annealings indicated on

f = 1.3 H z

Q-1 . 1 03 a : r i t e r cola-work 1% 16011 b. After annealing 200K

3 0 ^{C :}~ i t e r annealmg 240K

d ' After annealing 260 6

the figure. The arrows under the curves show the position and evolution of the u2

1 0 -

0.0

and a1 peaks during the W stage. The curve a of figure 3 has been obtained with Fig. 2: Internal f r i c t i o n spectra

?.'-y

^of^{t h e}^{1% a}^torsiontreatments: degassed a t sample 160K a ) a f t e r and submitted a f t e r cold-work anneal t o ings a t : b) 200K; c ) 240K and

d ) 260K.

- ¹ ^I ^I ^T(K) *

a degassed sample submitted to the y peak s t a b i l i z a t i o n treatment (para.2.3.1.) and

100 200 300

then deformed 5% in torsion a t 200K. After a l i n e a r annealing until 347K, t h a t i s , i n the temperature corresponding t o the X stage the curve b has been obtained. The temperature i n t e r v a l s corresponding t o the W and X stages are shown. The dashed curves marked a ' and a" show the influence of the W stage while the X stage induces the t r a n s i t i o n from curve a t o curve b. The i n s e t shows the creep stage t h a t takes place simultaneously with the W stage (curve c ) .

(5)

JOURNAL DE PBYSIQUE

A _0-1. ¹⁰³

mi

1 0 -

. lo5 a . After cold-work 5 % 200K

b Aner annealing 347K

T(K)

C

100 200 300 400

F i g . 3: I n t e r n a l f r i c t i o n s p e c t r a o f a specimen cold-worked a t RT and then submitted t o t h e y peak s t a b i l i z a t i o n treatment (para.2.3.1.). The i n s e t shows t h e creep stage ( c r = r o t a t i o n deformation measured a t t h e specimen s u r f a c e ) t h a t accompanies always t h e M stage.

2.3.4. Conclusion.- Concerning t h e thermomechanical treatments these experiments have shown t h a t the a2 and y peaks evolve l i k e w i s e even when a 1 peak presents t h e opposite o f t h i s e v o l u t i o n , w i t h samples predeformed a t RT. Then i t seems t o e x i s t one connection between the t h r e e peaks and t h e i r e v o l u t i o n .

Two d i f f e r e n t phenomena may be r e s p o n s i b l e f o r t h e e x i s t e n c e o f t h e two recovery stages, and as consequence f o r t h e y peak e l i m i n a t i o n . The f i r s t one c o u l d be a r e - arrangement o f the screw d i s l o c a t i o n s network and t h e second one, a p i n n i n g o f these d i s l o c a t i o n s by the i n t r i n s i c p o i n t d e f e c t s c r e a t e d a l s o by t h e low temperature deformation. We b e l i e v e t h a t the rearrangement i s t h e more probable process because a d i s l o c a t i o n p i n n i n g cannot be r e s p o n s i b l e f o r : a) t h e creep stage t h a t occurs simultaneously w i t h the W stage, and which i s due t o a d i s l o c a t i o n movement, and b ) the increase o f t h e a, peak amplitude w i t h annealings i n t h e temperature range corresponding t o the X stage. A screw d i s l o c a t i o n rearrangement may be an a n n i h i l a t - i o n o f screw d i s l o c a t i o n s o r a screw network change w i t h l o s t o f the screw character (8). We w i l l t r y t o r e p l y t o t h i s q u e s t i o n by transmission e l e c t r o n microscopy (TEM) observations .

3. E l e c t r o n microscopy.- 3.1. CIbJeAjye.- The main o b j e c t i v e o f t h e TEM observations was the v e r i f i c a t i o n o f t h e W stage i n t e r p r e t a t i o n : p a r t i a l a n n i h i l a t i o n o f the screw d i s l o c a t i o n s network. The i n t e r n a l f r i c t i o n measurements w i t h s p e c i a l l y t r e a t e d samples (para.2.3.1.) show a screw d i s l o c a t i o n network s t a b i l i t y ( f i g u r e 3, curve b).

The second o b j e c t i v e o f t h e TEM observations was t o v e r i f y t h i s s t a b i l i t y .

3.2. S?mplg-prwpayg_tjon.- C y l i n d r i c a l samples ( g = 3 mm, R = 5 0 mm) have been degassed by magnetic i n d u c t i o n h e a t i n g i n vacuum c o n d i t i o n s mentioned i n s e c t i o n 2.1. Some samples have been prepared a f t e r t h i s p u r i f i c a t i o n t r e a t m e n t (A), w h i l e o t h e r s were submitted t o t h e y peak s t a b i l i z a t i o n treatment (para.2.3.1.)(B). A f t e r e l e c t r o n e r o s i o n c u t t i n g we have obtained some p l a t e s (7x3x0,2 mm3) p r e s e n t i n g a <110> normal t o the surface. A f t e r t h i n n i n g treatment t h e samples thickness was about 1500 t o

(6)

2000 A i n a r e g i o n s i t u a t e d a t 3 t o 6 pm away from t h e h o l e

3.3. Results-ayd-discujslon.- The experiment has c o n s i s t e d i n t h e c r e a t i o n o f a d i s - l o c a t i o n network by " i n s i t u " deformation a t low temperature i n t h e e l e c t r o n microscope and i n observation o f i t s e v o l u t i o n d u r i n g t h e h e a t i n g r u n . F i g u r e 4 shows

q "W -m

1

'L* 4

. ^*a

F i g . 4: D i s l o c a t i o n arrangements observed d u r i n g 1 ow temperature

" i n s i t u " deformation i n t h e e l e c t r o n microscope .

c d

f o u r photographies t h a t have been taken from a f i l m which presents more d e t a i l s . This sequence has been chosen between 40K and 222K. The f i g u r e 4a shows t h e d i s l o c a t i o n network a t 40K a f t e r two s e r i e s (deformation a t 40K and l i n e a r annealing a t 245K).

The a p p l i c a t i o n o f an i n c r e a s i n g f o r c e u n t i l 1.4N creates t h e screw d i s l o c a t i o n n e t - work shown on f i g u r e 4b. The h e a t i n g r u n has been r e a l i z e d a t constant small force ( F = O.1N) i n order t o keep t h e specimen f l a t and w i t h a h e a t i n g r a t e o f 1°/min.

Figures 4c and 4d show t h e d i s l o c a t i o n network a t temperatures i n the temperature range corresponding t o t h e W stage. We can note t h a t the l o n g screw d i s l o c a t i o n s created by the low temperature deformation have disappeared. I n t h e f i l m we observe t h a t some screw d i s l o c a t i o n s are n o t e l i m i n a t e d by t h e l i n e a r annealing a t 245K. We b e l i e v e t h a t these d i s l o c a t i o n s are r e s p o n s i b l e f o r t h e y peak.

F i g u r e 5 shows t h e e x i s t i n g d i s l o c a t i o n network a t 270K i n a sample submitted t o the y peak s t a b i l i z a t i o n treatment. We can observe a d i s l o c a t i o n network composed

F i g . 5: D i s l o c a t i o n arrangement o f a sample submitted t o t h e y peak s t a b i l i - z a t i o n t r e a t - ment (para.2.3.1.) observed i n t h e e l e c t r o n microscope a t 270K.

(7)

C5-90 JOURNAL DE PHYSIQUE

by long and medium d i s l o c a t i o n s anchored i n some d i s l o c a t i o n agglomerations.

The TEM observations have shown t h a t : a ) some screw d i s l o c a t i o n s created by the 1 ow temperature deformation disappear a t the temperature range corresponding t o t h e W stage and, b ) a s t a b l e d i s l o c a t i o n network t h a t contains some screw d i s - l o c a t i o n s e x i s t s a t 270K. The p o s s i b i l i t y o f p i n n i n g may be excluded, b u t i t i s very d i f f i c u l t t o d e f i n e t h e rearrangement process.

4. Conclusion.- The i n t e r n a l f r i c t i o n r e s u l t s which have been confirmed by TEM observations are: a ) t h e W recovery stage corresponds t o a screw d i s l o c a t i o n n e t - work rearrangement and b ) t h e thermomechanical treatment t h a t c o n s i s t s i n a s e r i e s

(about 15) o f low temperature (200K) deformation i n t e r c a l a t e d by l i n e a r annealings a t RT and t h e l a s t 5 a t 347K, i s e f f i c i e n t t o s t a b i l i z e t h e screw d i s l o c a t i o n n e t - work.

References

(1) A.Seeger and C.Wuthrich, I 1 Nuovo Cimento g , 38 (1976) (2) J.E.Dorn and S.Rajnak, Trans. Met. Soc. AIME - 230, 1052 (1964) (3) F.De Lima and W.Benoit, submitted t o Phys. S t a t . S o l .

(4) 1 .G.Ritchie, J.F.Dufresne and P.Moser, Phys. S t a t . Sol. ( a ) 52, ³³¹(1979) (5) P.Asti&, J.P.Peyrade and P.Groh, S c r i p t a M e t a l l . 3, 611 (1980)

(6) H.Schultz, U.Rodrian and M.Mau1, i n : Proc. 3 r d European Conf. on I n t . F r i c t i o n and U l t r a s o n i c Attenuation, Manchester, J u l y 1979

(7) M.Maul and H.Schultz, t o be published

(8) P.Asti@, J.P.Peyrade and P.Groh, t o be published

The authors want t o thank Ph.Buffat, A.Steiner and R.Gotthardt f o r t h e TEM observations which have been made i n " I n s t i t u t Interdepartemental de M e t a l l u r g i e "

of t h e Swiss Federal I n s t i t u t e o f Technology.

This work has been supported by t h e "Fonds N a t i o n a l Suisse de l a Recherche S c i e n t i f i q u e " , subsidy n r . 2.472-0.79.
