Fire Hazard Classification Tests of Interior Finish Materials
Rose, A.
https://publications-cnrc.canada.ca/fra/droits
L’accès à ce site Web et l’utilisation de son contenu sont assujettis aux conditions présentées dans le site LISEZ CES CONDITIONS ATTENTIVEMENT AVANT D’UTILISER CE SITE WEB.
NRC Publications Record / Notice d'Archives des publications de CNRC:
https://nrc-publications.canada.ca/eng/view/object/?id=3cf9238e-9290-4c55-9af7-c959eb4228c6 https://publications-cnrc.canada.ca/fra/voir/objet/?id=3cf9238e-9290-4c55-9af7-c959eb4228c6
DIVISION OF BUILDING RESEARCH
No.
NATIONAL RESEARCH COUNCIL OF CANADA
Nセ
.li
e'
'IrE
C
1HI N ][ CAlL
558
NOTlE
PREPARED BY
A. Rose CHECKED BY G. W. S. APPROVED BY
A.G.W.
PREPARED FOR The Fire Test Board.
February 1971.
SUBJECT
FIRE HAZARD CLASSIFICATION TESTS OF INTERIOR
FINLSH MATERIALS
The National Building Code 1970 and CSA Preliminary Standard Z 240.2-1970(1) require a maximum flame spread rating
(ASTM E84-68) of 150 for interior finishes in certain cases. Supplement No. 2 to the National Building Code 1965(2), which is
slated for revision this year, lists generic flame spread ratings (Table 3.1. 1) for typical interior finish materials with conventional surface treatments, including wallpaper and burlap.
In the light of previous work (3, 4) by the Fire Section a few of these generic ratings, particularly for painted fibreboard. raw and painted hardboard, and raw particleboard. should be
revised. This Note presents the results of recent work on types
of interior finish materials not specifically covered by our earlier publications or by Supplement No.2. such as prefinished decorative
plywoods and hardboards. In addition, several unfinished hardboards
and particleboards were rechecked because of their inherent variability and because of improvements in the NRC/DBR tunnel furnace in the interim. particularly in the measurement of "Smoke Developed" (SD). The smoke rating is important now because of the inclusion of
maximum SD values for certain occupancies in the 1970 NBC. Because of the high flame spread ratings of some of the
materials, the effectiveness of a well-known UL-listed fire-retardant varnish system of the chlorinated alkyd type in reducing the
flamma-bility of a few of these materials was studied. A number of inquiries
2
-investigations of fires involving varnished particleboards in basement corridors of apartments.
MATERIALS, SAMPLING AND METHOD OF TESTING
All materials were purchased on the open market as 4- by
8-ft panels. The prefinished hardboards and plywoods were grooved.
with the exception of the PVC -surfaced hardboard (Sample 113). Sampling. conditioning and testing were carried out as described
in Fire Study No. 22. (3) The ignition time IT (in seconds) is not
required by ASTM E84-68 but is usually recorded by most operators. Where rechecks of certain materials are involved, the
alphabetical coding used in Tables II and III of Fire Study No. 22 is repeated to facilitate comparison, and the numbers in brackets in the descriptions of materials in this report are those of the corresponding samples in the above-mentioned Tables.
The low-gloss chlorinated alkyd varnish (V -1) mentioned above adhered poorly to most of the prefinished plywoods and
hardboards. A "tie coat" of a compatible fire-retardant semi-gloss varnish (V -2) was applied in such cases to improve adhesion to the
substrate. In the case of the prefinished elm plywood (Samples 124
and 125), V -Z was also used as a topcoat. All varnishes were
applied by roll coater at the coverages indicated in Tables I and II, which are the averages for the two 4- by 8 -ft panels required for
each tunnel test. The oil-modified satin urethane varnish (V -3)
used on particleboard samples 139-146 was applied at 350-400 sq ft/gal.
In one case (Sample 130) the fire-retardant varnish coatings
were UL-listed two-component urethane types. The gloss topcoat
(V -5) was used as a sealer on sanded particleboard B. and the intumescent semi-gloss varnish V -4 was applied in two coats at a total coverage of 200 sq ft/gal.
RESULTS
Agreement between ratings obtained with the DBR/NRC tunnel furnace and that of Underwriters' Laboratories of Canada at Scarborough, Ontario, has been shown to be satisfactory in
thickness. Flame spread ratings in the critical 150 range reported
here may thus be accepted with some confidence. Agreement on
"fuel contributed" and "smoke developed" values was also satisfactory,
probably because they were relatively low. The maximum obscuration
recorded on our smoke curves was about 40 per cent for these
particleboard runs, and comparisons in this range (SD of 150 -200)
are probably valid.
When the obscuration exceeds 40 per cent for a substantial portion of the test or 100 per cent obscuration occurs for brief intervals, inter lab comparisons or rejection of a material on the
basis of its SD value may be less arguable.
In this report a few SD values are recorded as > X. This
indicates that a high peak or total obscuration occurred briefly during the test, and that these values should be considered as semi-quantitative.
CONCLUSIONS
Prefinished hardboards from all four Canadian sources, thin prefinished plywoods from two major Canadian and two foreign sources, and most of the unfinished particleboards tested have given flame
spread ratings above 150.
Earlier work (3, 4) has shown that cellulosic fibreboard
tiles and panels from all four Canadian sources, when factory-finished or subsequently coated with conventional latex- or solvent-based
4
-REFERENCES
1. Canadian Standards Association. Preliminary Standard
Z 240.2-1970. Structural requirements for mobile housing.
Section 6. 3. 1.
2. Fire Performance Ratings 1965. National Research Council
of Canada. Associate Committee on the National Building
Code of Canada, 1965. Ottawa. NRC No. 8330.
3. Rose A. Comparison of Flame Spread Ratings by Radiant
Panel, Tunnel Furnace and Pittsburgh Corning Apparatus. National Research Council of Canada. Division of Building Research,
Fire Study No. 22. June 1969. NRCC 10788.
4. Rose. A. Flammability of Fibreboard Interior Finish
Materials. National Research Council of Canada, Division
of Building Research, Building Research Note No. 68, October 1969.
Hardboards and Plywoods
Sample Description Coatings Applied ASTM E84-68 Results
No. 1 2 3 FSC FC SO IT
110 Hardboard Y, l'Iominal 1/4 (0.230 in .)
---
---
---
135 94 210 60unfinished [72 ]
111 Y, printed paper surface, 0.185 in.
---
---
---
209 135 >262 61caliper
112 Y, III with F .R. coatings V-2 (580 ) V-I (161)
---
103 76 332 71113 Y, 0.175 in., with embossed PVC
---
---
---
188 120 343 50film overlay
114 Hardboard Z, nominal 1/4 (0.215 in. )
---
---
---
138 100 336 65unfinished (75]
115 Z, 0.180 in. caliper,
---
---
---
182 119 >400 65lithographed woodgrain finish
116 Z, 115 with F.R. coatings V-2 (580) V-I (157)
---
120 88 381 85117 Hardboard P, nominal 1/4 (0.230 in. )
---
---
---
153 112 >265 63lithographed woodgrain finish
118 P, 117 with F.R. coatings V-2 (580 ) V-I (153)
---
88 52 381 96119 Hardboard Q, 0.185 in.
---
---
---
216 98 >190 55lithographed woodgrain finish
120 Q, 0.230 in., lithographed
---
---
---
190 110 217 67woodgrain finish
121 Plywood V, 4 mm (0.150 In.)
---
---
---
239 59 75 36preflnlshcd birch, pine core
I?? V with F.R. coatings V-2 (580) V-I (162)
---
167 57 240 28123 Plywood W, 4 mm (0.145 in. )
---
---
---
240 91 241 33pre finished elm, lauan core
124 W with F.R. coatings V-2 (1200) V-I (250) V-2 (610 ) 70 22 114 10
125 W with heavier F.R. coating V-2 (1210) V-I (144) V-2 (570) 38 20 215 25
126 Plywood L, 4 mm (0.150 in. )
---
---
---
243 41 84 26prefinished lauan
127 Plywood M, 4 mm (0.150 in. )
---
---
---
239 47 68 42,"
Table II Particleboards
Sample Description Coatings Applied ASTM E84-68 Results
No. 1 2 3 PSC FC SD IT
128 Particleboard B (82] 0.625 in.,
---
---
---
217 123 126 40aspen flakes, phenolic binder
129 B, later production (1969)
---
---
---
242 131 149 43130 129 with F.R. coatings V-5 (535 ) V-4 (204)
---
129 106 355 38131 Particleboard K(48], 0.500 in.
---
---
---
169 116 147 57cedar chips, urea resin binder
132 K, duplicate of 131
---
---
---
165 119 153 75133 Particleboard R (46, 47, 85 ]
---
---
---
184 125 101 400.500 in. mixed
hardwood-softwood chips, urea resin binder
134 R, 0.500 in. , later production
---
---
---
165 111 95 63 (1969)135 134 with F.R. coatings V-? HUVセI V-I" (163)
---
70 30 258 120136 R, 1970 production
---
---
---
131 109 161 51137 R, 1970 production
---
---
---
141 114 164 54138 R, 0.250 in.
---
---
---
176 103 83 43139 R, 138 with satin varnish V-3 (328)
---
---
168 79 105 35140 R, 139 plus F.R. coatings V-3 (65) V-I (140)
---
75 38 352 57141 R, 0.375 in.
---
---
---
217 125 85 52142 R, 141 with satin varnish V-3 (83)
---
---
117 115 128 41143 R, 142 plus F.R. coatings V-3 (405) V-I (150)
---
75 36 350 55144 R, 0.500 in.
---
---
---
184 119 84 53145 R, 144 with satin varnish V-3 (408)
---
---
200 116 82 37146 R, 145 plus F.R. coatings V-3 (400) V-I (137)
---
73 46 246 52Abbreviations Used (E84-68)
FSC - flame spread classification FC - fuel contributed
SD - smoke developed IT - ignition time (sees.)
