HAL Id: jpa-00225318
https://hal.archives-ouvertes.fr/jpa-00225318
Submitted on 1 Jan 1985
HAL is a multi-disciplinary open access
archive for the deposit and dissemination of
sci-entific research documents, whether they are
pub-lished or not. The documents may come from
teaching and research institutions in France or
abroad, or from public or private research centers.
L’archive ouverte pluridisciplinaire HAL, est
destinée au dépôt et à la diffusion de documents
scientifiques de niveau recherche, publiés ou non,
émanant des établissements d’enseignement et de
recherche français ou étrangers, des laboratoires
publics ou privés.
THE TEMPERATURE DEPENDENCE OF
DISLOCATION MOBILITY IN NaCl SINGLE
CRYSTALS UNDER IMPACT STRESSES
V. Kisel
To cite this version:
THE TEMPERATURE DEPENDENCE OF DISLOCATION MOBILITY IN NaCl SINGLE
CRYSTALS UNDER IMPACT STRESSES
V . P . K I S E L
Institute of Solid State Physics, Academy of Sciences of the
USSR, Chernogolovka, Moscow district 142432, U.S.S.R.
Abstract
-
T h e dislocation mobility in NaCl a t temperaturesT
= 4.2, 77 a n d 298 K under impact s t r e s s e s i s d i s c u s s e d in terms of con- servative and non-conservative motion of jogs on s c r e w components.T h e standard dislocation theory s u g g e s t s that high-velocity dislocation motion /1 to 121 i s principally different from that with low velocity V 112 to 1 5 both
in the dependence on temperature, 9, and on resolved s h e a r s t r e s s
&
.
It i s characterized by the dislocation v i s c o u s d r a g coefficientdetermined by the interaction of mobile dislocations with electrons and pho- n o n s
(
b i s the B u r g e r s vector modulus)/l to 121. T h e numerous experiments, however, indicate d e p a r t u r e s £ r o m the principal tenets of the theory:1. At high velocites often
v ~ / Z ; ~ ,
where 0 . 9 6 m g 4.7 /2,4,5,14/.2. E v e n if (1) i s fuifilled and the s t r e s s amplitudes a r e maximal c m a x - ( 1 . 5 to 600)
Tp
with the maximai duration t m- ^1(
1 0 - ~ toIO-^)
S. d B / d T a Oi s the yield point or the proportionality limit)
11
to 7,10,12,14,15/. 3: V in ( 1 ) i s still dependent on the concentration and the s t a t e of impu- rities, point defects /4,5,7/, the dislocation density /1 to 31, the type of mobile dislocations /2,4,12/ a n d the crystai orientations /IO/, the dislocation-loop s i z e s /2/ and the v a l u e s of/I;
a n d tm 171, T h e metals exhibit sensitivitymax
of V to magnetic field a n d its orientation with r e s p e c t to the vector
b
191. 4. T h e starting s t r e s s e sEst
/2,12,14/ a n d the delay times td 17,131 a r en
always characteristic of the dislocation motion. T h e mean dislocations always grow with up to the uitimate v a l u e s of starting with which a t -
a/C,,,
dislocations begin to multiply /5,7/.I V 1
-4
5. An i n c r e a s e of the strain rate
&
= 10 to 104 s-' d o e s not actually affect the c h a r a c t e r of the dislocation structure / l 6 / and i s , normally, foiiowed by a n increasing formation of v a c a n c i e s 117,181.T h u s , 1 to 5 and, a l s o /1,12 to 15,19/ indicate similarity of the mechanisms controiiing V ( ~ , T ) a t al1
/Z
a d T in different crystals. T h e effect of impact s t r e s s e s on mean pathlength z ( ~a n d mean number ) ~ and, d s o d Z/de(% ,T), rst(T),
gmax(c
,T)
andCM(*)
of mobile s c r e w disloca- tions in pure(c
= 0.5 M P ~ ) a n d impure(/i.
= 2 M P ~ ) NaCl singleP P
c r y s t a l s h a s been studied a t T = 298,77 and 4.2 K ( ~ i g s 1 to 4 ) using the
CIO-530 JOURNAL
DE PHYSIQUE
Fi0.1. Change of mean pathlength
e
(
)
,
the number of mobile dislocations n ( c
)
in pure NaCl at different fali heights H (mm) =2 0 0 ( 2 ) , 5 0 0 ( 3 ) , 1 0 0 0 ( 5 ) , 2000(7).
Tp
i s the proportionality limit, T = 298 K.techniques described in detail /6,7,13/. t
m z ~ - O ' l
( H i s the sample or the anvil fail height) and i s approximately constant along the length of the loaded samples/6,7/. At the loading end of the sample m - - ~ 0 ' 6(+
20%)
and i s decreasing linearly to zero a t the free end /6,7/. In pure NaCle s c r e w a t dl ?\ and
% ,
the s p r e a d of data points from sample to sample 121 increased with decreasing T . F i g s 1 to 2 presente ( ~ )
,
n ( / t ) T of mobile dislocations a tT = 29%, 4.2 K,
/C-
averaged a t H, t =m
const up to the beginning of multiplication a t
Z N I ( ~ ) .
T h e data a t 77 K a r e the same a s for 298 K. T h e data treatment in(
1)
yields B
(
4.2 K ) 7 B ( 298K)
7 B (77K ) ,
like in 13 to 71, however, ordy for one of 11 samples tested at 4.2 K B (4.2 K ) ( ( B ( ~ ? K ) , like in /2,8/. At al1 T c s t ~ b ( Z N I (O(=const) and
&(
) T
gr0wS synchronously withn
('ZJ
leTt
like it i s observed atZ
( T )113; Klsel, to b e published/. It i s ccara-P cteristîc that even if ( 1 ) i s fulfilled, there a r e usually revealed the regions of weak and strong sensitivi of
e
,
n to2
a t aii 'T', charaîterined by two different dependences d c / d % ( r , 'T') a t aii T and in crystals of different impurity content T h e dislocation c r o s s slip i s often observed, a s well as the motion of dislocations in the direction opposite to the acting force i s manifested 1131. Under impact s t r e s s e s the crystals a r e frectured a t 4.2 K, sometimes without the observable motion of dislocations. T h e s t r e s s of the .crack formationCF
i n c r e a s e s with a growth of the defor-d C
ming s t r e s s rate
6
(
insert in ~ i . g . 2 ) . Inasmuch as B % the data of F i g s 1 to 4 demonstrate al1 the diversity of the values and dependencesB
(
T ) in different NaCL. With a n increase of H ( o r6 )
dc/de
i n c r e a s e s monotonically with growing2:
irrespective of T for the weak-sensitivity region off ( <
),
whereas for the strong-sensitivity region of t f ( 2)
it initially increases, and then drops at all T. An increase of &max(c)'T' ( a n d of n) and increase-
then d e c r e a s e of d c / d i with growing.%
for individuai diçlo- cations ( ~ i g s 1,2) a r e anaiogous to crystal softening a t the 1 s t a g e of macro- deformation /15,20,21/ or to a negative rate sensitivity of the plastic flow at a n i n c r e a s e of&
( a n d dl T). In macroscopic c a s e d Z / d i i s analogous to the hardening coefficient. S u c h discrimination between the types of dislocation drag a t ultrasound loading w a s performed in 181, and the data of /9,13,22/ confirm the similarity of the mechanisms controiiing the mobility of dislocations a t different types of loading.3 2 8 0 ( 9 ) . Insert: the s t r e s s
TF
ofs
ming s t r e s s rate
6
.
c r a c k formation asafunction of defor-
Fi 3 Ultimate v a l u e s of the mean
*
dislocation pathlengths&
max
( b e f o r emultiplication) a s a function of s t r e s s ,
.
temperature, strain r a t e s a n d impuritycontent in different NaCl. c ~ 0 . 1 5 M P a
a
-6 1W - points 1,3-
tm- ( 2 02
5 ) 1 0 s , 2- t m 2 5 * 1 0 - ~ s 171;.Zp-
0.4 MPa: 4,5-
g t i 9 . 2 - 1 0 ' ~ s 171; ~ 0 . 5 M P a:
m 6,8,10-
t m ~ ( 2 5 ~ 7 ) 1 F 6 s ; c P z 2 MPa: -51 2
-
tm& ( 6 + 1 ) 1 0 s-
this work. 1 ' ( ~ ) ~ 3 0 0 ( 1 , 2 , 4 , 6 , 1 2 ) , 77 (3,5,8) a n d4.2 ( 1 0 ) .
r r
of the introduced dislocations a t
L
%L
M113; Kisel, to b e publishedl, a n d c s t r k
&
M, this means that unpinning,motion, d r a g a n d multiplication of dislo- cations, determining the plastic fiow d o n g the hardening curve, like in the region of smailer S a n d /12,13,15 to 211, a r e closely interconnected a n d a r e controlled by the s a m e mechaniçms. T h i s conclusion a g r e e s with
I l l /
too y h e r e it w a s shown that e v e n a t small S dislocations move a n d multiply along the deformation c u r v e a t times compa- rable with t(
H)
in this work. Only conset%ative a n d non-conserva- tive motion of jogs 1161 formed a t c r o s s s l i p s of s c r e w components 119,231 c a nZ,M~CI
b e the mechanismî providing hardening and softening of a wide c l a ç s ofthe
materials a t ail temperatures, s t r e s s e s , impurity concentrations as a function of5
1131. Intensification of the c r o s s s l i p with growing impurity content o r with d e c r e a s i n g T /13,19/ a g r e e s with a n appropriate i n c r e a s e of the dislocation d r a g from the data of Fig.3.Softening ( o r facilitation of the dislocation motion) c a n o c c u r d u e to a change of the height a n d concentration of jogs 1131 on dislocations with a change of
?'
-
Fig.3 ( 7 7 K ) a n d 113,231, deforming r a t e-
Fig.1, /15,20,21,23/, impurity concentration /13,15,20/ a n d crystal type 119,241.CIO-532
JOURNAL
DE
PHYSIQUE
with the conduction electrons a n d external magnetic field in this mode1 h a s to b e sensitive to the field magnitude a n d i t s orientation with r e s p e c t to the
+
vector b 191. T h e dislocation motion a n d multiplication in normal a n d super- conducting c r y s t a l s of Zn ( a n d ~ b confirms this 1261. )
REFERENCES
/1/ Kumar, A., High S p e e d Testing, N.-Y., Interscience _? (1969 /2/ Vreeland, S. et al, Scr. M e t
18
( 1 9 8 4 ) 645; Phil. Mag.2
J. Appl. Phys.3
( 1 9 6 9 ) 884./3/ Victoria, M.P. e t al, J. Appl. Phys.
41
(1970) 674./4/ Weertman, J. e t al, J. Appl. Phys.
43
(
1972) 2982; Metall. T r a n s .2
( 1 9 7 1 ) 1233; Mater. Sci. Eng.18
( 1 9 7 5 ) 41./5/ Ney, H., Labusch, R., H a a s e n , P., Acta Met.
25
( 1 9 7 7 ) 1257./6/ Boiko, Yu.F., Lubenets, S.V. e t al, Izvestia Vusov, Fizika
2
(1978) 129./7/ Darinskaya, E.V., Urusovskaya, A.A., Al'shits, V.I. e t al, Fiz. Tverd. T e l a 23
(
1981) 1751; Ibid.2
( 1 9 8 2 ) 940; Ibid.24 ( 1 9 8 2 ) 1564; Ibid.
a
( 1 9 8 3 )-
1892; Ibid. 25 ( 2 9 8 3 ) 3636.
/8/ ~ o b e l e v y ~ . ~ . , Soifer, Ya.M., Altçhits, V.I., Fiz. Tverd. T e l a
2
( 1 9 7 9 ) 1172./9/ Galligan, J.M., S c r . Met.
18
( 1 9 8 4 ) 653./IO/ Durgaryan, A.A., S a k a n y a n , M.S., Fiz. Tverd. T e l a
26
(
1984) 1855./II/
Golovin, Yu.1. e t al, Fiz. ~ T v e r d . 'Pela21
( 1 9 8 5 ) 555. 1121 Klyavin, O.V. e t al, Fiz. Tverd. T e l a 1 4 (1972) 163.1131 Kisel, V.P., Phys. Stat. Sol. ( a ) 36 (1976) 297; p r e s e n t Conference Proceedings.
1141 Nikitenko, V.I. e t al, Zh. Eksp. Teor. Fiz. ( 1 9 7 1 ) 1780; Phys. Stat.
S O L
( a ) 7 3 ( 1 9 8 2 ) K 141.1151 ~ a v i d s o n , D.L., Lindholm, U.S., Mater. Sci. Eng.
13
( 1 9 7 4 ) 29. /16/ Edington, J.W., Phil. Mag.19
( 1 9 6 9 ) 1189.1171 Klein, M.J., G a g e r , W.B., J. Appl. Phys.
37
( 1 9 6 6 ) 4112. 1181 s o b , M., Buchar, J., Bucki, M., Mater. S c i Eng.65
( 1 9 8 4 ) L9.1191 Smirnov, B.I., Dislokatçionnaya struktura i uprochenie kristallov, Lenin- grad, Nauka
(
1981).1201 H e s s e , J., Phys. Stat. Sol.
9
( 1 9 6 5 ) 209; Ibid.21
(1967) 495. /21/ Argon, A.S. e t al, Phil. Mag.25
( 1 9 7 2 ) 1095.1221 K a r d a s h e v , B.K., Lebedev, A.B., Nikanorov, S.P., Cryst. Res. a n d
0
+
*'
@
=
Reciprocai value of mean pathlength sensitivity to s t r e s sd T / d
e
-
as a function of mean--.
-.
-.
s t r e s s
%
a n d i t s duration, T ina
--.
--
-
different NaCI. Designations of
2
---.
-.
-.
Fig.3 a n d additional points 7, 1 3 ( ~ o o K ) , 9 ( 7 7 ~ ) a n d 11 ( 4 . 2 ~ ) belong to the g r o u p s 6 to 11 and 12,13. C u w e 1 c o r r e ponds to the
weak-sensitivity of
