Structural composite laminate materials with low dielectric loss: Theoretical model towards dielectric

characterization

Maëlle Sergolle, Xavier Castel, Mohamed Himdi, Philippe Besnier, Patrick Parneix

To cite this version:

Maëlle Sergolle, Xavier Castel, Mohamed Himdi, Philippe Besnier, Patrick Parneix. Structural com- posite laminate materials with low dielectric loss: Theoretical model towards dielectric characteriza- tion. Composites Part C: Open Access, Elsevier, 2020, 3, pp.100050. �10.1016/j.jcomc.2020.100050�.

�hal-02971767�

ContentslistsavailableatScienceDirect

Composites Part C: Open Access

journalhomepage:www.elsevier.com/locate/jcomc

Structural composite laminate materials with low dielectric loss:

Theoretical model towards dielectric characterization

Maëlle Sergolle

, Xavier Castel

, Mohamed Himdi

, Philippe Besnier

, Patrick Parneix

aUniv Rennes, INSA Rennes, CNRS, IETR-UMR 6164, F-35000 Rennes, France

bNaval Group, Technocampus Océan, 44340 Bouguenais, France

a r t i c le i n f o

Keywords:

Composite materials Dielectric characterization Maxwell-Garnett model Microwaves

a b s t r a ct

Organicmatrixcompositematerialsexhibithighmechanicalpropertiesassociatedwithlightweight.Theyalso providetheabilitytoembedradiofrequencyfeatures,suchasmicrowaveantennas,forsmartload-bearingstruc- turesofvariousmeansoftransport.Antennasimplementationintocompositepanelsrequireselectricallyconduc- tivefabricsfortheradiatingelements,feedinglinesandgroundplanesembeddedintothestructuraldielectric compositematerialswithlowlossatmicrowaves.Accordingly,thepresentstudyinvestigatestheassessmentof thedielectriccharacteristics,namelytherelativepermittivity𝜀randthelosstangenttan𝛿ofcompositelaminate materialsmadeofE-glass,S2-glassandquartzfabricsinfusedwithepoxy,polyesterandurethaneacrylatether- mosettingresins.Therelateddielectriccharacteristics,measuredintwooperatingbands,namely100MHzto 1GHzand18–26GHz,arecomparedwiththetheoreticalvaluescomputedfromthe2DMaxwell-Garnettmodel thatwehaveadaptedtolaminatecompositematerials.Mechanicalcharacteristicsofsuchcompositelaminate materialsarealsoinvestigated.Eventually,thequartz/urethaneacrylatelaminateishighlightedasalowloss compositematerial,highlysuitableforthefabricationofantennasoperatingatmicrowaves.

1. Introduction

Organicmatrixcompositematerialsareincreasinglyusedintrans- port area. These materials are mainlymade of reinforcement fibers infused with thermosetting resins. They enable the fabrication of lightweightandmechanicallyresistantstructuralpanels.Moreover,they promoteembeddedelectronicapplications.ThevastareaofMultifunc- tionalStructures(MFS)[1]showstheinterestofcombiningthefunc- tionalcapabilities of oneor more subsystemswiththat of theload- bearingstructure,therebyreducingthemassandvolumeofthetotal system[2].Amongcleanenergyproductionstructures[3],integrated electronics[4]andsmartstructures[5],compositepanelsforradiofre- quencycommunicationshaveaprominentplaceinsuchmultifunctional structurefield.

Antennasimplementationintoload-bearingcompositepanelsis a majoraspectof thesmartcompositematerialsdevelopment.Various studies have already developed this innovative concept. Kim et al.

[6]fabricatedamultibandaero-vehiclesmartskinantenna (MASSA) madeofasinglehoneycombincludingtheradiatingelementstacked betweentwostructuralcompositefacesheets.Thisantennacanbein- tegratedin theairplaneload-bearingstructure andoperates closeto 300MHz.Manac’hetal.[7]demonstratedsimilarmicrowaveperfor- mancebetweenapurecompositelaminateantennaandacopperone

∗Correspondingauthor.

E-mailaddress:[email protected](M.Sergolle).

operatingbothinthe600MHzto2.1GHzfrequencyband.Youetal.

builtconformalload-bearingantennastructures(CLAS)byintegrating slots[8]andradiatingpatches[5]betweentwolayersofhoneycomb.

Thefirststructureresonatesat5.3GHzandthesecondoneoperatesat 12.2GHz.Intheseworks,atwofoldstudywascarriedout,(i)onthecon- ductivefabricstominimizetheohmiclossandtheskindepthloss[7], and(ii)onthedielectricmaterialstominimizethedielectricloss[5,6,8].

Themainobjectiveofsuchstudiesaimstodevelopembeddedcommu- nicatingsystemswithoptimalradiofrequencyefficiencyatmicrowaves.

Thepresentstudyfocuseswiththeframeworkofthecase(ii),namely thedielectriclossreductionof thedielectriccompositematerials. To date,thefibersreinforceddielectriclaminatesusedforantennaappli- cationsarebasedonthetwosomeformedbyE-glass/polyester[7],E- glass/vinylester[9,10],E-glass/epoxy[5,11,12],orS-glass/epoxy[13], asdisplayedinTable1.Therelativepermittivityofsuchcompositelam- inatesremainscloseto𝜀r≈4andthelosstangenttan𝛿higherthan0.01, relativelyhighvaluesforapplicationsatmicrowaves.

Thepresentpaperinvestigatestheoreticallyandexperimentallyvar- iousdielectriccompositelaminatesmadeofglass fabricsandorganic thermosettingresins,thatmaybeusedasload-bearingcompositepan- elswithlowdielectriclossforantennasubstrateand/orradomeappli- cations.Afterthedescriptionofthedielectricandmechanicalcharacter- izationtechniques,theglassfabricsused(namelyE-glass,S2-glassand

https://doi.org/10.1016/j.jcomc.2020.100050

Received10June2020;Receivedinrevisedform28September2020;Accepted29September2020

2666-6820/© 2020TheAuthor(s).PublishedbyElsevierB.V.ThisisanopenaccessarticleundertheCCBY-NC-NDlicense (http://creativecommons.org/licenses/by-nc-nd/4.0/)

M. Sergolle, X. Castel, M. Himdi et al. Composites Part C: Open Access 3 (2020) 100050

Table1

Dielectriccharacteristicsofthefibersreinforceddielectriclaminatesusedforantennaapplications.

Composite laminate materials L -band S -band X -band V -band

E-glass/Polyester [7] 𝜀 r= 4.5; tan 𝛿= 0.01 @ 1 GHz / / /

E-glass/Vinylester [ 9 , 10 ] 𝜀 r= 4.5; tan 𝛿≈0.015 @ 1.5 GHz / / /

E-glass/Epoxy [ 5 , 11 , 12 ] / 𝜀 r= 4.0; tan 𝛿= 0.03 @ 2.5 GHz 𝜀 r= 4.0; tan 𝛿= 0.03 @ 12 GHz 𝜀 r= 4.6; tan 𝛿= 0.035

@ 50-75 GHz

S-glass/Epoxy [13] / / 𝜀 r= 4.3; tan 𝛿= 0.02 @ 10 GHz /

Fig.1. Complexdielectriccharacterizationbyimpedancemeasurement.

fusedquartzfibers)andthethermosettingresinsused(namelyepoxy, polyesterandurethaneacrylate)aredescribed,aswellastheimplemen- tationprocess.Then,atwo-dimensionalMaxwell-Garnettmodelispre- sentedanddevelopedforourspecificcompositelaminatestocompute theirdielectriccharacteristics(relativepermittivity𝜀randlosstangent tan𝛿).Thedielectricmeasurementsarecarriedoutovertwofrequency bands(100MHzto1GHzand18–26GHz).Theoreticalandexperimen- talresultsarethencomparedanddiscussed.Themechanicalcharacter- izationofthecompositelaminates,throughtensiletests,completesthe study.Finally,conclusionsaredrawn.

2. Characterizationtechniques 2.1. Dielectriccharacterization

Relativepermittivity𝜀r=𝜀’_randlosstangenttan𝛿=𝜀”_r/𝜀’_raredis- playedfromthecomplexdielectricpermittivityexpression𝜀^∗=𝜀’_r – j 𝜀”_r . 𝜀^∗ is retrieved from two separate techniques, namely the impedancemeasurementandthefree-spacemeasurement.Foreachtype ofcompositelaminates,threedifferentsamplesmachinedfromthesame laminateareassessed.

2.1.1. Impedancemeasurement

Theimpedancemeasurement(Fig.1)retrieves𝜀r andtan𝛿values from100MHzto1GHz.Animpedanceanalyzerisconnectedtoamea- surementhead.Themeasurementheadacts asacapacitorof7mm- diameter.Priortomeasurements,astandardcalibrationwascarriedout throughanopen(non-contactcapacitorplates),short(face-to-facecon- tactcapacitorplates),andload(25mm×25mm×0.8mmTeflon^○R samplewith𝜀r=2.08overtheentirefrequencyband)sequentialsteps.

Thesamplesurfaceshavetobesmoothtopreventanyairgapbetween thesamplefaceandtherelatedcapacitorplate(whichwouldcausearti- facts).Themeasurementuncertaintiesareprovidedbythemeasurement accuracyoftheapparatus,asgivenbythesupplier[14].

2.1.2. Free-spacemeasurement

Thefree-space measurement(Fig.2)retrieves 𝜀r andtan𝛿 values from18to26GHz.Thistechniqueis basedonthesignalprocessing ofreflection/transmissionelectromagneticplanewavesilluminatingthe sampleundertest.Atransmittinghornantenna,connectedtoanetwork analyzer,radiatesanelectromagneticfieldwhichisfocusedasa(locally) planewaveonthesamplebytheuseoftwosuccessivereflectivemirrors.

Fig.2. Complexdielectriccharacterizationbyfree-spacemeasurement.

Theincidentplanewavesundergoreflectionandtransmissionthrough thesampleundertestaccordingtoitsdielectricproperties.Thesecond hornreceivestheoutgoingelectromagneticwavesaftertheirreflection ontotwo newsuccessivemirrors.Prior tomeasurements,calibration wasalsocarriedoutthroughastandardthru(nosample),reflect(metal plate),load(150mm×150mm×6.7mmTeflon^○Rsamplewith𝜀r=2.09 overtheentirefrequencyband)sequentialsteps.Forthistechnique,the measurementuncertaintiesaremostlyrelatedtothesamplethickness spreading.Asamesampleofcompositelaminatematerialfabricatedby thevacuuminfusionprocessmayexhibitathicknessvariationofabout

±0.2mmon150mm×150mmsamplearea.Duetothisuncertainty, resultsoffreespacemeasurementexhibitarelativepermittivityvaria- tionof8%andalosstangentvariationof11%at18GHz.

2.2. Mechanicalcharacterizationbytensiletests

Toevaluatethemechanicalcharacteristicsof thecompositelami- natematerials,tensiletestswereperformeduptothesamplerupture, accordingtothemechanicalstandard[15].ALloydInstrumentstesting machine(LR50KPlus)wasusedwithaconstantdisplacementrateof 2mm/minappliedon25mm-widthand250mm-lengthsamples.Re- sultingforcewasmeasuredwitha50kN-forcesensorandsampleelon- gationwasmeasuredthroughthevariationofarandomspecklepattern appliedoneachsamplesurfaceandmonitoredbyacamera.Therelated strain,definedas(L-L₀)/L₀whereListhelengthofthesampleduring thetestandL₀istheinitiallengthofthesample,wascomputedwiththe DigitalImageCorrelation(DIC)method[16].Theresultingtensileelas- ticmodulus(Youngmodulus)wasretrievedbetween100and200MPa (curveslope).Thebehaviorofeach typeof compositelaminateswas averagedfrom5samplesmeasurements.

3. Fabrics,thermosettingresinsandtheirimplementation 3.1. Reinforcementfibersandtherelatedfabrics

Amongthefamiliesofinorganicreinforcementfibersandtherelated fabrics,fibersofE-glass,S2-glassandfusedquartz(commonlyknown as“quartz”)wereselectedhereaccordingtotheirattractivedielectric characteristicsandtheircommonuseinthefieldofcompositemate- rials. E-glass fibers arethemost popularreinforcements used in the transportationarea.Theyaremainlymadeofsilica(55%wt.SiO₂)and

Table2

Dielectriccharacteristics(𝜀f;tan𝛿f)at100MHzand1GHzof theselectedreinforcementfibers,estimatedfrom[18].

Fibers 𝜀 f tan 𝛿f

100 MHz 1 GHz 100 MHz 1 GHz Quartz 3.7 3.7 1.0 ×10 ⁻⁴ 1.1 ×10 ⁻⁴ S2-glass 5.3 5.3 2.0 ×10 ⁻³ 2.5 ×10 ⁻³ E-glass 6.4 6.4 3.0 ×10 ⁻³ 3.1 ×10 ⁻³

calciumoxide(19%wt.CaO).Theremaining26%wt.arecomposedof othersoxides,mainlyAl₂O₃,B₂O₃andMgO.S2-glasscontainsahigh contentofsilica (65%wt.),alumina(25%wt. Al₂O₃)andmagnesium oxide(10%wt.MgO),andisknownforitslowerrelativepermittivity (Table2)anditsgoodmechanicalstrength[17].Quartzfiber,madeof 99.99%wt.puresilica,exhibitshightemperatureresistanceaswellas lowdielectriccharacteristicsvalues(Table2,[18]).Therelativepermit- tivity𝜀fandlosstangenttan𝛿fofthethreetypesoffibersaredisplayed inTable2.

Inthisstudy, aquadriaxialfabricof E-glassfibers (2.8 yarns/cm inthewarpdirectionwithanareadensityequalto618g/m²,refer- enceQX618from Sicomin,France), aplainweave of S2-glassfibers (2.1yarns/cminthewarpdirectionwithanareadensityof516g/m², reference 6000 from CTMI, France) and a 4H-satinof quartzfibers (11yarns/cminthewarpdirectionwithanareadensityof180g/m², reference5903fromCTMI,France)wereused.Thequadriaxialweave isastackoffourlayersofunidirectionalyarns:afirstlayerorientedat +45° tothewarpdirection,asecondlayerorientedat90°,athirdlayer orientedat−45° andthetoplayerparalleltothewarpdirection(0°).The plainweavecorrespondstoaperiodicinterlacingofyarns,alternatively oneover,oneunder.Finally,4H-satin(four-harnesssatin)isathreeby oneinterlacingpattern.Accordingtothesupplierdata,theYoungmod- ulusoftheE-glassandofthequartzfibersisequalto72GPa,andthat oftheS2-glassfibersisequalto87GPa.Literaturereportsanelongation atbreakof4.5–5%forE-glassfibers[18],5.4–5.8%forS2-glassfibers [18]and8.7%forquartzfibers[19].

3.2. Thermosettingresins

Inordertoinfusethepreviousreinforcementfabricstofabricatethe compositelaminatematerials,threetypesofthermosettingresinswere selectedinthepresentstudy:thepolyester,theepoxyandtheurethane acrylateresins.

Polyesteristhecheapestthermosettingresinandthemostusedin thefieldofcompositematerials,mainlyinthefabricationofmainstream ships,carsandindustrialparts.Itisproducedbyacondensationreac- tionbetweenaglycolandanunsaturateddibasicacid.Thepolyester resinpolymerizesafteraddingacatalyst(anorganicperoxide)anda cobaltaccelerator[17].Inthisstudy,thepolyesterresinusedisapre- acceleratedNorester^○R823(NordComposites,France)andwascatalyzed with2%wt.ofcatalyst(PMECfromNordComposites,France).Theresin waspolymerizedfirstatroomtemperaturefor24h,andthenwascured at40°Cfor16h.

Epoxyisa two-componentresin.This thermosettingresinis well knowntoachievehighmechanicalandtemperatureresistanceperfor- manceofcompositelaminatesforhighvalue-addedproductsinvarious meansoftransport:ships,vehiclesandaircraft[17].Inthisstudy,epoxy resin(SR8100fromSicomin,France),afteraddinghardener(SD8824 fromSicomin,France)witha27:100(v/v) ratio,waspolymerizedat roomtemperaturefor24h,followedbyacuringstepat80°Cfor6h.

Urethaneacrylateresinismadeofamonomercontainingurethane groupswith chain extenders.This resin is mainlyused in the auto- motivesector,forthebumpersfabricationforexample.Inthisstudy, aspolyesterresin,theurethaneacrylateresin(Crestapol^○R 1261from ScottBader,UK),afteraddingfirst2%wt.ofcobaltaccelerator(NL49P

Table3

Measureddielectriccharacteristics(𝜀m;tan𝛿m)at100MHzand1GHz oftheselectedthermosettingresins(retrievedfromimpedancemea- surement)

Resin

𝜀 m( ± 0.5) tan 𝛿m( ± 0.5 ×10 ⁻³) 100 MHz 1 GHz 100 MHz 1 GHz Urethane acrylate 2.7 2.7 5 ×10 ⁻³ 5 ×10 ⁻³ Polyester 2.7 2.6 1.4 ×10 ⁻² 1.1 ×10 ⁻² Epoxy 3.3 3.1 3.0 ×10 ⁻² 2.5 ×10 ⁻²

Fig.3.Compositelaminatematerialduringitsfabricationbyvacuuminfusion process.

fromAkzoNobelFunctionalChemicals,Netherlands)andthen2%wt.of specificcatalyst(Trigonox239fromAkzoNobelFunctionalChemicals, Netherlands),waspolymerizedatroomtemperaturefor24h,followed byacuringstepat40°Cfor16h.

Thethreethermosettingresinsusedinthisstudyareinfusionresins.

Furthermoreatroomtemperature,theseresinsareglassypolymers.Ac- cordingtothesupplierdata,theYoungmodulusofthepolyester,epoxy andurethaneacrylateresinsisequalto3GPa,2.4GPaand3.6GPa, respectively.

Thesingleresinswerecastinsiliconmoldsandcuredfortherelevant time.Impedancemeasurementson2-mmthicksampleswerecarriedout (Table3).Urethaneacrylateresinexhibitsthelowestvaluesofdielectric characteristicsinthe100MHzto1GHzfrequencyrange:𝜀m=2.7±0.5 andtan𝛿m=5.0×10⁻³±0.5×10⁻³.

3.3. Fabricationofthecompositelaminatematerials

Samplesfabricationwasdonebystandardvacuuminfusionprocess, widely usedin industrialenvironment.Itconsistsininfusingafabric byathermosettingresinundervacuum.Inthisway,dryfabricswere stackedontoawaxedglassslab.Placedundervacuum(−0.6bar)with aplasticbagasshowninFig.3,fabricswereinfusedjointlywiththe liquidthermosettingresin.After24hofpolymerizationatroomtem- peraturefollowedbythesuitablecuringstep,thecompositelaminate materialswerecuttotherequiredsizestoundergothedielectricchar- acterizations(25mm×25mm×2mmfortheimpedancemeasurement;

150mm×150mm×2mmforthefree-spacemeasurement)andthe mechanicalcharacterizations(250mm×25mm×2mm).

ThefibervolumefractionV_fofeachsamplewascomputedasfol- lows:

𝑉_𝑓= 𝑛×𝑚_𝑜𝑓

𝜌×ℎ (1)

wherenisthenumberofpliesofthedryreinforcementfabrics,m_ofisthe areadensityofthedryfabrics(kg/m²),𝜌fistheglassfibervolumeden- sity(kg/m³),andhisthemeasuredthicknessofthecompositelaminate sample(m).

Nineseparatecompositelaminates(Table4)werefabricatedandin- vestigatedhere,eachmadeofspecificreinforcementfabrics(E-glass,S2-

M. Sergolle, X. Castel, M. Himdi et al. Composites Part C: Open Access 3 (2020) 100050

Table4

FibervolumefractionV_fofthefabricatedcompositelaminatematerialscom- putedfromEq.(1)with𝜌quartz=2200kg/m³and𝜌E-glass=𝜌S2-glass=2600kg/m³, nisthenumberofpliesofthereinforcementfabricineachlaminate,andhis thethicknessofthecompositelaminatesample.

Composite laminate materials n h ± 0.2 (mm) V _f(%)

Quartz / Epoxy 12 2.3 42

Quartz / Polyester 12 2.4 42

Quartz / Urethane acrylate 12 2.4 41

S2-glass / Epoxy 5 2.1 46

S2-glass / Polyester 5 2.3 44

S2-glass / Urethane acrylate 5 2.3 43

E-glass / Epoxy 5 2.7 45

E-glass / Polyester 5 2.6 46

E-glass / Urethane acrylate 5 2.7 45

glassandquartz)infusedwithaspecificthermosettingresin(polyester, epoxyandurethaneacrylate).

4. Mixingrulesinthe100MHzto1GHzfrequencyrange

Sincethelastcentury,researchersdeveloptheoreticalmodels,called effectivemediumapproximations(EMA),topredictandcomputetheo- reticallythemacroscopicrelativepermittivity𝜀effofcompositemateri- alsmadeofahostmedium(characterizedbytherelativepermittivity 𝜀handvolumefractionV_h)andinclusions(characterizedbytherelative permittivity𝜀iandvolumefractionV_i=1–V_h).

4.1. Mixingruleswithoutloss

From the Maxwell equations, Maxwell-Garnett built a theory of homogenization[20]basedon amedium containingsphericalinclu- sions,stillwidelyusedtoday[21–23].Basedonthistheory,athree- dimensionalmixingrulewasdevelopedtocomputetheeffectiveper- mittivity(orthe macroscopicrelative permittivity)of thecomposite mediumaccordingtotherelativepermittivityofeachcomponentand itsrelatedvolumefraction[24],asfollows:

𝜀𝑒𝑓𝑓=𝜀ℎ+3𝑉𝑖𝜀ℎ 𝜀_𝑖−𝜀_ℎ 𝜀_𝑖+2𝜀_ℎ−𝑉_𝑖(

𝜀_𝑖−𝜀_ℎ) (2)

Fromatheoreticalpointofview,Bruggemansolvedtheproblemof non-symmetryoftheMaxwell-Garnettmixingrule(theresultsdiffered when𝜀iandV_iweresubstitutedby𝜀handV_h)[25].Otherstudiesleaded toaneffectiverelativepermittivityvaluecoveredbylowerandupper boundstotakeintoaccountthephasedistributioninfluence[26],or arelativepermittivityvaluedependinguponthefibersdirectioninre- lationwiththatoftheappliedelectricfield[27–29].Nevertheless,all thepreviousmodelsconsideredthecompositemediaaslosslessmate- rials.Accordingly,thepresentstudyadaptsaMaxwell-Garnettmodel consideringcompositemediawithdielectricloss.

4.2. 2DMaxwell-Garnettmodelofcompositematerialswithdielectricloss

SihvoladevelopedaMaxwell-Garnettmixingrulewhichcomputed thecomplexdielectricpermittivity𝜀^∗=𝜀r –j𝜀”_rofcompositemedia withoutneglectingtheloss,wheretheinclusiondimensionsremained largecomparedwiththemoleculardimensions[30].Inthecaseoffiber reinforcedcompositelaminates,thisconditionisobviouslycompletely fulfilled.Moreoverthefiberswereconsideredastwo-dimensionalin- clusions,asdonebyBalandKotharitopredicttherelativepermittivity ofnon-infusedpolyethylenefabrics[28].Accordingtotheseconsider- ations,theMaxwell-Garnettmodelwas extendedtotwo-dimensional compositemedia,namelythecompositelaminatematerials,wherethe fibersofthereinforcementfabricswereconsideredas2Dcylinderdi- electricinclusionsembeddedintoadielectric matrix.Becauseof the dielectricnatureofthe2Dcylinderfiberinclusionsandofthematrix

[31],weassumethatthecomplexpermittivity𝜀^∗compofthecomposite laminatematerialscanbeexpressedasfollows[32]:

𝜀^∗_{𝑐𝑜𝑚𝑝}=𝜀^∗_𝑚+2𝑉_𝑓𝜀^∗_𝑚 𝜀^∗_𝑓−𝜀^∗_𝑚 𝜀^∗_𝑓+𝜀^∗_𝑚−𝑉_𝑓(

𝜀^∗_𝑓−𝜀^∗_𝑚) (3)

where𝜀^∗misthecomplexpermittivityoftheresinhostmedium,𝜀^∗fis thecomplex permittivityofthefibers(2Dinclusions),V_f isthefiber volumefraction,andV_m=1–V_fisthematrixvolumefractioninthe compositelaminatematerial.Eq.(3)compliestheboundaryconditions, namely𝜀^∗comp=𝜀^∗mwhenV_f=0and𝜀^∗comp=𝜀^∗fwhenV_f=1.Itis worthnotingthatporosity(with𝜀^∗air=1)intothecompositelaminate samplesisneglected,whichisclosetorealitywhenthevacuuminfusion processisimplementedtofabricatesuchsamples.Moreoverthemodel describedaboveremainssuitableifthewavelengthoftheelectromag- neticfieldusedtocharacterizethecompositematerialislargeenoughin comparisonwiththedispersionanddimensionsoftheinclusions.These conditionsthenenablethemodellingofthediffusioneffectsascoming fromanequivalenthomogeneousmaterial.At3GHz,theworkingwave- lengthoftheelectromagneticfieldequals10cm.Thebiggestfabricyarn usedis0.5cm-wide(S2-glass– 2.1yarns/cm)witharepeatweaveunit of 1cm-wide. Thereforetoconsiderthecompositelaminatematerial asahomogeneousmaterialforanelectromagneticpointofview,the presentmodelisnolongersuitablebeyondthe3GHzlimit-frequency.

Accordingly,themixingrulehasbeenappliedinthe100MHzto1GHz frequencyrange.

4.3. Applicationofthe2DMaxwell-Garnettmodeltothecomposite laminatematerials

The2DMaxwell-Garnettmodelwasusedtocomputethecomplex dielectricpermittivity𝜀^∗comp(Eq.(3))ofthecompositelaminatemateri- alsfromthecomplexdielectricpermittivityvaluesofthereinforcement fibers𝜀^∗f(Table2)andofthesinglethermosettingresins𝜀^∗m(Table3), andbytakingintoaccountthefibervolumefractionV_finthecompos- itelaminatesamples(Table4).ResultsaredisplayedinTable5atboth endsofthestudiedfrequencyband,namely100MHzand1GHz.

Ontheonehand,therelativepermittivityvaluesofthesinglether- mosettingresinsrangefrom2.6–2.7(polyesterandurethaneacrylate resins)to3.1–3.3(epoxyresin)inthe100MHzto1GHzfrequencyband, inducinganamplitudedeviationΔ𝜀m=0.6at100MHzandΔ𝜀m=0.5 at1GHz(Table3).Fortherelativepermittivityvaluesofthereinforce- mentfibers,theyrangefrom3.7(quartzfibers)to6.4(E-glassfibers)in theworkingfrequencyband,inducinghighervaluesandlargerampli- tudedeviation(Δ𝜀f=2.7)(Table2).Accordinglythecomputedrelative permittivityvalues𝜀rcompofthecompositelaminatematerialsarecon- trolledbythetypeofreinforcementfibersusedandtheycanbegrouped inthreefamilieswhatevertheworkingfrequency(Table5):theE-glass fiberreinforcedlaminateswith𝜀rcomprangingfrom3.9to4.5;theS2- glassfiberreinforcedlaminateswith𝜀rcomprangingfrom3.5to4.1;and thequartzfiberreinforcedlaminateswith𝜀r comprangingfrom3.0to 3.5.Withineachfamily,thecompositelaminateswithepoxyresinhost mediumalwaysexhibittherelativehigher𝜀rcompvalueswhiletheones withpolyesterandurethaneacrylatehostmediaareclosetogether(in agreementwiththeirrelated𝜀mvalues).

Ontheotherhand,losstangenttan𝛿mvaluesofthesinglethermoset- tingresinsrangefrom5×10⁻³(urethaneacrylate)to25–30×10⁻³ (epoxy)witharatioequalto6(Table3)andthoseofthereinforcement fibers from0.1×10⁻³ (quartz)to3×10⁻³(E-glass,Table2)in the 100MHzto1GHzfrequencyband.Despitetheratiovariationofthere- inforcementfibertan𝛿fvalues,losstangentofthecompositelaminates iscontrolledbythetypeofthethermosettingresinusedduetotheirrel- ativehighvalues,andcanalsobegroupedinthreefamilies(Table5):

laminateswithepoxyhostmedium(tan𝛿comphigherthan10⁻²);lami- nateswithpolyesterhostmedium(6×10⁻³<tan𝛿comp<10⁻²);and laminates with urethane acrylate host medium (tan𝛿comp lower than 5×10⁻³).Foreachfamily,thetheoreticallosstangentvaluesincrease

Table5

Theoreticalcomplexpermittivity𝜀^∗compandlosstangenttan𝛿compofthecompositelaminatematerialscomputedfromthe2DMaxwell-Garnettmodelat100MHz and1GHz.

100 MHz Quartz S2-glass E-glass

Epoxy 𝜀 ^∗comp 3.48 –j 6.0 ×10 ⁻² 4.11 –j 7.2 ×10 ⁻² 4.43 –j 8.3 ×10 ⁻²

tan 𝛿comp 17.2 ×10 ⁻³ 17.4 ×10 ⁻³ 18.6 ×10 ⁻³

Polyester 𝜀 ^∗comp 3.09 –j 2.0 ×10 ⁻² 3.62 –j 3.2 ×10 ⁻² 3.96 –j 3.7 ×10 ⁻²

tan 𝛿comp 8.1 ×10 ⁻³ 8.9 ×10 ⁻³ 9.4 ×10 ⁻³

Urethane

acrylate 𝜀 ^∗comp 3.10 –j 1.0 ×10 ⁻² 3.61 –j 1.4 ×10 ⁻² 3.94 –j 1.7 ×10 ⁻²

tan 𝛿comp 3.1 ×10 ⁻³ 3.9 ×10 ⁻³ 4.3 ×10 ⁻³

1 GHz Quartz S2-glass E-glass

Epoxy 𝜀 ^∗comp 3.36 –j 2.5 ×10 ⁻² 3.97 –j 5.9 ×10 ⁻² 4.27 –j 6.7 ×10 ⁻²

tan 𝛿comp 14.3 ×10 ⁻³ 14.9 ×10 ⁻³ 15.8 ×10 ⁻³

Polyester 𝜀 ^∗comp 3.04 –j 2.0 ×10 ⁻² 3.55 –j 2.7 ×10 ⁻² 3.88 –j 3.1 ×10 ⁻²

tan 𝛿comp 6.6 ×10 ⁻³ 7.7 ×10 ⁻³ 7.9 ×10 ⁻³

Urethane acrylate

𝜀 ^∗comp 3.07 –j 0.9 ×10 ⁻² 3.57 –j 1.4 ×10 ⁻² 3.90 –j 1.7 ×10 ⁻²

tan 𝛿comp 3.1 ×10 ⁻³ 4.0 ×10 ⁻³ 4.3 ×10 ⁻³

Fig.4. 100MHzto1GHzfrequencyvariationsoftherelativepermittivity𝜀rcomp(a)andlosstangenttan𝛿comp(b)ofthecompositelaminatesamplesmeasuredby impedancetechnique.

slightlyaccordingtothetypeoffibers(inagreementwiththeirrelated losstangentvalues),butwithoutreallyaffectingtheirrelatedabsolute value.

5. Characterizationsofthecompositelaminatesamples 5.1. Dielectriccharacterizations

5.1.1. Impedancemeasurement

Impedancemeasurementfrom 100MHzto1GHzwasperformed ontheninestudiedcompositelaminatesamples(E-glass,S2-glass,and quartzfibers,infusedonebyonewithepoxy,polyesterandurethane acrylatethermosettingresins).Fig.4presents(𝜀r comp;tan𝛿comp)vari- ationsversusfrequencyofthecompositelaminatesamples.𝜀^∗compand tan𝛿compat100MHzand1GHzaregiveninTable7.Asexpected,therel- ativepermittivity𝜀rcompmeasurementidentifiesthreecompositelami- natefamilies,namelytheE-glassreinforcedlaminateswiththehighest 𝜀rcompvalues(𝜀rcomp≈4.1–4.4),theS2-glassreinforcedlaminateswith themiddle𝜀rcompvalues(𝜀rcomp≈3.6–3.7),andthequartzreinforced laminateswiththelowest 𝜀r comp values (𝜀r comp ≈ 3.1–3.2)in good agreementwiththetheoreticalbehaviorresultingfromthe2DMaxwell- Garnettmodelapplication.Therelativepermittivityvaluesslightlyde- creasefrom100MHzto1GHz,asexpectedforstandarddielectricma- terials[33].

Focusingonthedielectricloss,Fig.4.bpresentsarelativelymoder- atevariationoftan𝛿compversusfrequencyforallthesamples;itmaybe assumedasaconstantforpracticalapplications.Thecompositelaminate samplesinfusedwithepoxyresinexhibitsalwaysthehighestlossvalues (tan𝛿comphigherthan10⁻² overthefrequency band).E-glassandS2- glass/polyesterlaminatesamplesshowhigherlossthanthatoflaminates infusedwithurethaneacrylateresin.Losstangentofquartz/polyester laminates remainsclose tothat of theE-glassandS2-glass/urethane acrylatelaminates.Accordingly,combinationofmiddlelossreinforce- mentfiberswithalowlossthermosettingresinissimilartothecombi- nationoflowlossreinforcementfiberswithmiddlelossthermosetting resin.Therefore,thecombinationoflowlossreinforcementfiberswitha lowlossthermosettingresin,namelyquartz/urethaneacrylatelaminate sample,mustexhibitthelowestdielectriclossovertheentirefrequency band:tan𝛿comp=2.8×10⁻³at100MHzandtan𝛿comp=3.1×10⁻³at 1GHz.

5.1.2. Free-spacemeasurement

The dielectric characterizations weresupplemented byfree-space measurementfrom18to26GHzonthesamecompositelaminatesam- ples(Fig.5).

Asatlowerfrequencies(100MHzto1GHz),theresultsfromfree- spacemeasurementspecifythreecompositelaminatefamilies,regard- lessoftheresinsused:theE-glassfiberreinforcedlaminateswith𝜀rcomp

rangingfrom4.3to5.0;theS2-glassfiberreinforcedlaminateswith

M. Sergolle, X. Castel, M. Himdi et al. Composites Part C: Open Access 3 (2020) 100050

Fig.5.18-26GHzfrequencyvariationsoftherelativepermittivity𝜀rcomp(a)andlosstangenttan𝛿comp(b)ofthecompositelaminatesamplesmeasuredbyfree-space technique.

Table6

Youngmodulus(GPa)ofthecompositelaminatematerials.

Young modulus Quartz S2-glass E-glass Epoxy 18.1 ± 0.7 21.1 ± 0.9 12.9 ± 1.2 Polyester 17.4 ± 0.5 20.6 ± 0.7 12.4 ± 0.4 Urethane acrylate 16.5 ± 0.5 19.5 ± 0.5 12.1 ± 1.1

𝜀rcomprangingfrom3.6to4.0;andthequartzfiberreinforcedlaminates with𝜀rcomprangingfrom3.1to3.4.Comparisonoftheabsoluterela- tivepermittivityvaluesfromfree-spacemeasurementwiththosefrom impedancemeasurementexhibitsanincreasing𝜀rcompvaluefrom1GHz to18GHz.Thisincreaseisascribedtotheownuncertaintiesofthetwo separatetechniquesusedtocharacterizethesamplesintwodifferentfre- quencybands.Asareminder,theimpedancemeasurementisbasedona capacitivemethodwhilefree-spacemeasurementisbasedonanelectro- magneticreflection/transmissionwavesmethod.Nevertheless,theex- pecteddecreaseof𝜀rcompvaluesisnoticedfrom18GHzto26GHz.

Focusing now on the loss tangent variations versus frequency, tan𝛿compvaluesexhibitingbytheninesamplesarelesssplitfromeach otherthanatlowerfrequencies.However,thesametrendsareobserved:

first,thedirectimpactoftheresintypeonthedielectriclossofthecom- positelaminates,andsecond,theslightinfluenceofthereinforcement fiberstypeontheirdielectricloss.Accordingly,E-glass/epoxylaminates exhibitthehighestdielectriclosswithtan𝛿comphigherthan2×10⁻² overtheentire18–26GHzfrequencybandwhilequartz/urethaneacry- latelaminatesexhibitoncemorethelowestdielectriclosswithtan𝛿comp

lowerthan8×10^-3.

5.2. Mechanicalcharacterization

Thestress-straincurves(Fig.6)highlightapureelasticbehaviorof theninecompositelaminates.Moreovertheuseofquartzfiberreinforce- mentshowsanincreaseoftheelongationatbreak(upto3.6%),while thecompositelaminatesreinforcedwithS2-glassandE-glassfibersex- hibitasimilar elongationatbreak(closeto2.7%).This resultisex- plainedbytheintrinsicelongationatbreakofthepureglassfibers(asa reminder,8.7%forquartzfibers,5.4–5.8%forS2-glassfibersand4.5–

5%forE-glassfibers). Regardingthestiffnessof thesamplesstudied (Table6),thecompositelaminatesreinforcedwithS2-glassfibersex- hibitaYoungmoduluscloseto20GPa,thosereinforcedwithquartz fiberscloseto17GPa,andthosereinforcedwithE-glassfiberscloseto

Fig.6. Stress-straincurvesofthecompositelaminatesamplesmeasuredfrom tensiletest.

12GPa.Itisworthnotingthat,eventhoughepoxyresinprovidesaslight increaseinstiffnessofthecompositelaminates,theimpactoftheresin usedisnotrelevantontheirabsoluteYoungmodulusvalue.Thisresult stemsfromthesimilarmechanicalcharacteristicsofthepureresinsused (asareminder,Youngmodulusequals2.4GPaforepoxyresin,3GPa forpolyesterresinand3.6GPaforurethaneacrylateresin).

6. Comparisonofthe2DMaxwell-Garnettmodelwiththe microwavemeasurements

(𝜀rcomp;tan𝛿comp)valuesretrievedfromimpedancemeasurementare comparedwiththosecomputedfromEq.(3)ofthetailored2DMaxwell- Garnettmodelat100MHzand1GHz(Table7).Theoretical𝜀rcompval- uesalwaysfitwiththemeasuredonesintheuncertaintyrangeofmea- surement.Thetheoreticaltan𝛿compvaluesoftenexhibitslightlyhigher levelsthanthemeasuredones.Nevertheless,theoreticalandmeasured values remain very close toeach other. Therefore,theproposed 2D Maxwell-Garnettmodelprovidesfair(𝜀rcomp;tan𝛿comp)theoreticalval- ues ofthelowlosscompositelaminatematerials,conditionallyupon theelectromagneticwavelengthusedislarge enoughcomparedwith thedispersionanddimensionscalesofthereinforcementfibers.

Table7

Comparisonofthecomputedandmeasured(𝜀rcomp;tan𝛿comp)dielectriccharacteristicsofthecompositelaminatematerialsat100MHzand1GHz.

Composite laminate materials Theoretical 𝜀 _rcomp Measured 𝜀 _rcomp Theoretical tan 𝛿_comp Measured tan 𝛿_comp 100 MHz

Quartz / Epoxy 3.48 3.2 ± 0.5 17.2 × 10 ⁻³ 14.0 ×10 ⁻³± 0.5 ×10 ⁻³

Quartz / Polyester 3.09 3.2 ± 0.5 8.1 × 10 ⁻³ 6.4 ×10 ⁻³± 0.5 ×10 ⁻³

Quartz / Urethane acrylate 3.10 3.1 ± 0.5 3.1 × 10 ⁻³ 2.8 ×10 ⁻³± 0.5 ×10 ⁻³

S2-glass / Epoxy 4.11 3.7 ± 0.5 17.4 × 10 ⁻³ 13.7 ×10 ⁻³± 0.5 ×10 ⁻³

S2-glass / Polyester 3.62 3.6 ± 0.5 8.9 × 10 ⁻³ 7.6 ×10 ⁻³± 0.5 ×10 ⁻³

S2-glass / Urethane acrylate 3.61 3.7 ± 0.5 3.9 × 10 ⁻³ 4.8 ×10 ⁻³± 0.5 ×10 ⁻³

E-glass / Epoxy 4.43 4.2 ± 0.6 18.6 × 10 ⁻³ 14.6 ×10 ⁻³± 0.5 ×10 ⁻³

E-glass / Polyester 3.96 4.4 ± 0.6 9.4 × 10 ⁻³ 8.4 ×10 ⁻³± 0.5 ×10 ⁻³

E-glass / Urethane acrylate 3.94 4.3 ± 0.6 4.3 × 10 ⁻³ 5.0 ×10 ⁻³± 0.5 ×10 ⁻³

1 GHz

Quartz / Epoxy 3.36 3.1 ± 0.5 14.3 × 10 ⁻³ 11.1 ×10 ⁻³± 0.5 ×10 ⁻³

Quartz / Polyester 3.04 3.1 ± 0.5 6.6 × 10 ⁻³ 5.2 ×10 ⁻³± 0.5 ×10 ⁻³

Quartz / Urethane acrylate 3.07 3.1 ± 0.5 3.1 × 10 ⁻³ 3.1 ×10 ⁻³± 0.5 ×10 ⁻³

S2-glass / Epoxy 3.97 3.6 ± 0.5 14.9 × 10 ⁻³ 12.3 ×10 ⁻³± 0.5 ×10 ⁻³

S2-glass / Polyester 3.55 3.6 ± 0.5 7.7 × 10 ⁻³ 7.6 ×10 ⁻³± 0.5 ×10 ⁻³

S2-glass / Urethane acrylate 3.57 3.6 ± 0.5 4.0 × 10 ⁻³ 6.6 ×10 ⁻³± 0.5 ×10 ⁻³

E-glass / Epoxy 4.27 4.1 ± 0.6 15.8 × 10 ⁻³ 12.9 ×10 ⁻³± 0.5 ×10 ⁻³

E-glass / Polyester 3.88 4.3 ± 0.6 7.9 × 10 ⁻³ 8.0 ×10 ⁻³± 0.5 ×10 ⁻³

E-glass / Urethane acrylate 3.90 4.2 ± 0.6 4.3 × 10 ⁻³ 5.7 ×10 ⁻³± 0.5 ×10 ⁻³

Boththeoreticalandexperimentalinvestigationsdemonstratethat thereinforcementfibers typeimpactstherelativepermittivity ofthe compositelaminatematerials,andtheorganicresintypeimpactstheir dielectricloss.Inthatway,thequartz/urethaneacrylatecompositelami- nateexhibitsthemostattractivedielectriccharacteristicsformicrowave applications,namelylowrelativepermittivityvalue(𝜀rcomp=3.1±0.5) andverylowlossvalue(tan𝛿comp≈2.9×10⁻³±0.5×10⁻³)inthe 100MHzto1GHzfrequencyband.Thiscompositelaminatecanthere- forebeusedasradomeand/ordielectricsubstrateforantennaapplica- tions.

Todate,cyanateesterresinwasthemostattractiveresinintheaero- nauticalareadue toitshighdielectric andmechanical performance.

This resin is an epoxy-like processing, but more difficult to imple- ment due to its strong exothermic behavior, high vacuumwith ad- ditionallyautoclave processing andhighcuring temperature(higher than200°C)requirements.Recentopenliteratureprovidesthemea- sureddielectriccharacteristicsofquartz/cyanateestercompositelam- inatematerialsat300MHz(𝜀rcomp=3.42andtan𝛿comp=5.8×10⁻³ [34]).Thequartz/urethaneacrylatecompositelaminatesstudiedhere exhibithigherdielectricperformanceatthesameoperatingfrequency:

𝜀rcomp=3.1andtan𝛿comp≈2.8×10⁻³.Athigheroperatingfrequency, astudypresents thequartz/cyanate estercompositelaminatesasthe combinationprovidingthelowestlossachievablefromcommercialoff- the-shelfaerospacematerialswithtan𝛿comp=3×10^-3at10GHz[13]. Forcomparison,ourquartz/urethaneacrylatecompositelaminatesex- hibitalossvaluetan𝛿comp= 6×10⁻³at18 GHz,demonstratingthe relevanceofsuchcompositematerialsoverawideoperatingfrequency band,from100MHzupto26GHz.

7. Conclusions

Dielectriccharacteristics, namely relative permittivity 𝜀rcomp and losstangenttan𝛿comp,of low losscompositelaminate materialswere theoretically and experimentally studied at microwaves. The two- dimensionalMaxwell-Garnettmixingruledevelopedforsuchamate- rialprovidesfair(𝜀rcomp;tan𝛿comp)theoreticalvalues,whichfitstrongly withthemeasuredonesinthe100MHzto1GHzfrequencyband(in theuncertaintyrangeof measurement).Mechanical characteristicsof thecompositelaminateswerealsomeasuredthroughtensiletests.

This study highlighted the quartz fabric/urethane acrylate type resin composite laminate materials which exhibit (𝜀r comp = 3.1;

tan𝛿comp=3.1×10⁻³)and(𝜀r comp=3.2;tan𝛿comp =6×10⁻³)mea-

suredvaluesat1GHzand18GHz,respectively.Suchcompositelami- natematerialsarethereforerelevantforlowlossload-bearingantenna compositestructuresformicrowaveapplications,indirectcompetition withthequartzfabric/cyanateestertyperesincompositelaminates.In- deed,thiswell-knowncompositematerialremainsmoreexpensiveand difficulttoimplement.Urethaneacrylatecouldthereforebeconsidered asthepromisingthermosettingresinforsubstratesand/orradomesof antennasembeddedintoload-bearingcompositepanels.

DeclarationofCompetingInterest

Theauthorsdeclarethattheyhavenoknowncompetingfinancial interestsorpersonalrelationshipsthatcouldhaveappearedtoinfluence theworkreportedinthispaper.

Funding

This workwas supportedinpartbytheDGA,in partbytheRé- gions Pays-de-la-LoireandBretagne, inpartbytheDépartement des Côtesd’Armor,theSaint-BrieucArmorAgglomération,andtheLannion- TrégorCommunauté,throughtheFUI’23STARCOMproject.Thiswork wasalsosupportedinpartbytheEuropeanUnionthroughtheEuropean RegionalDevelopmentFund,inpartbytheMinistryofHigherEduca- tionandResearch,inpartbytheRégionBretagne,andinpartbythe DépartementdesCôtesd’ArmorandSaint-BrieucArmorAgglomération, throughtheCPERProjects2015-2020MATECOMandSOPHIE/STIC&

Ondes.

Acknowledgements

TheauthorswarmlyacknowledgeF.BoutetfromIETRandIDCom- positeteamfortheirtechnicalsupports.

References

[1] A.D.B.L. Ferreira, P.R.O. Nóvoa, A.T. Marques, Multifunctional mate- rial systems: a state-of-the-art review, Compos. Struct. 151 (2016) 3–35 https://doi.org/10.1016/j.compstruct.2016.01.028 .

[2] K.K. Sairajan, G.S. Aglietti, K.M. Mani, A review of multifunctional struc- ture technology for aerospace applications, Acta Astronaut. 120 (2016) 30–42 https://doi.org/10.1016/j.actaastro.2015.11.024 .

[3] T. Pereira, Z. Guo, S. Nieh, J. Arias, H.T. Hahn, Embedding thin-film lithium en- ergy cells in structural composites, Compos. Sci. Technol. 68 (2008) 1935–1941 https://doi.org/10.1016/j.compscitech.2008.02.019 .
