Numerical simulation of vertical solar collector under turbulent natural convection
R. Bennacer 1*, E.H. Kadri 1 and M. El Ganaoui 2
1 LEEVAM/GC, Université Cergy, 5 Mail Gay Lussac, Neuville sur Oise 95031, France 2 Université de Limoges, SPCTS UMR 6638 CNRS, France
Abstract - This concept of PV-T hybrid collector is developed to find the best integration strategy; to make the most efficient use of solar energy collecting surface in terms of both electrical conversion and air heating. This new concept takes into account the fact that thermal effects help maintaining the PV module operating temperature at an optimal level for photovoltaic electric-conversion. The considered turbulent natural convection (chimney effect) flow in a moderately heated vertical solar collector (finite length channel) was simulated using low Reynolds number k−ε model. The numerical results validation was compared to the existing experimental results and to the chimney effect Benchmark exercise. The collector is supposed to receive solar radiation only on part of his height. The heated size and its location on the obtained flow intensity and the position of the transition from laminar to turbulent flow are analyzed. The partially heated collector and heating level affects such transition point location on the vertical hot wall.
1. INTRODUCTION
In industrialized countries, buildings are great energy consumers (before transport and industrial sectors). The integration of renewable energy systems will become one of the solutions to the key issues of economizing fossil resources, whose world reserves are limited, and reducing the earth global warming effects. Solar energy represents the best renewable, environmentally- friendly source of energy that can be used for the heating and cooling of houses. Facing international engagement, the new targeted challenge is that the buildings become energy producer and not any more a simple consumer of energy, thus taking part in their autonomy. In previous work we study the turbulent flow of natural convection in a vertical two-dimensional channel (slot) formed by two parallel plates differentially heated. We focused on the radiative transfer on such coupled system and the humidity effect on the flow was also studied. In the present work we have investigated the performance of hybrid collector included in double skin wall and the effect of its position on the inducing air flow.
2. PROBLEM DEFINITION
In the present work we have investigated the performance of a hybrid collector included in a double skin wall and the effect of its position on the air flow. The last two decade witnessed some major works concerning the turbulent natural convection the most of which concerned the flow of boundary layers or closed cavities but not many studied opened channel. One the pioneer experiment with measurement of turbulent values is Miyamoto et al. [1] who investigated air flow in a channel with one adiabatic plate and the other submitted to an uniform flux for a range of Grashof number from 7×108 to 1.2×1010. Daffa’Alla and Betts [2] conducted measures in tall air filled cavities (Ra = 8.3×105) in turbulent regime with one side kept at a constant heat flux and the other at a constant temperature. The Direct Numerical Simulation (DNS) is a reference numerical experience and provides viable validation data. We cite some simulations of
