Role of oxygen in surface segregation of metal impurities in silicon poly-and bicrystals

HAL Id: jpa-00245593

https://hal.archives-ouvertes.fr/jpa-00245593

Submitted on 1 Jan 1987

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are pub- lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

Role of oxygen in surface segregation of metal impurities in silicon poly-and bicrystals

E. Amarray, J.P. Deville

To cite this version:

E. Amarray, J.P. Deville. Role of oxygen in surface segregation of metal impurities in silicon poly-

and bicrystals. Revue de Physique Appliquée, Société française de physique / EDP, 1987, 22 (7),

pp.663-669. �10.1051/rphysap:01987002207066300�. �jpa-00245593�

Role of oxygen ⁱⁿ surface segregation ^{of metal} impurities in silicon poly-

and bicrystals

E.

Amarray

and J. P. Deville

(*)

Equipe

d’Etude des

Surfaces,

^{UA 795 du}

C.N.R.S.,

Université Louis-Pasteur, 4, ^rue

Blaise-Pascal,

⁶⁷⁰⁰⁰

Strasbourg, France (Reçu

le 6 octobre 1986, révisé le 25 mars

1987, accepté

^{le 9 avril}

1987)

Résumé. ²⁰¹⁴ Nous avons

caractérisé,

^au moyen des méthodes

d’analyse

^des

surfaces,

^les

impuretés métalliques

situées sur des rubans de silicium

polycristallin. L’oxygène

^et les traitements

thermiques

^{semblent une force}

motrice pour la

ségrégation superficielle

^{de ces}

impuretés.

Pour mieux étudier leur influence et leurs

possibilités

^{en terme d’effet} getter, nous avons initié des études de modélisation sur des bicristaux de type Czochralski. Nous avons étudié deux facteurs

principaux

^de

ségrégation superficielle :

le rôle d’une couche

d’oxyde

très mince et celui de traitements

thermiques.

^{Nous avons}

remarqué

que le maximum de

purification

des surfaces était obtenu

après

le recuit à 750 °C d’une surface

préalablement oxydée

^{à 450 °C. Nous avons}

relié cela à la formation d’amas de

SiO,

suivie d’une coalescence donnant des unités de type

SiO4

^entraînant

l’injection

d’auto-interstitiels de silicium dans le réseau.

Abstract. ²⁰¹⁴ Metal

impurities

^at surfaces of

polycrystalline

silicon ribbons have been characterized

by

^surface

sensitive methods.

Oxygen

^{and heat} treatments were found to be a

driving

force for surface

segregation

^of

these

impurities.

^{To better}

analyse

their influence and their

possible

incidence in

gettering,

model studies were

undertaken on Czochralski grown silicon

bicrystals.

Two main factors of surface

segregation

^{have been}

studied : the role of a ultra-thin oxide

layer

^{and the effect of heat} treatments. The best surface

purification

^was

obtained after an

annealing

process ^at 750 °C of a

previously

oxidized surface at 450 °C. This was related to the formation of SiO clusters, ^followed

by

^a coalescence of

SiO4

^units

leading

^{to the}

subsequent injection

^{of silicon}

self-interstitials in the lattice.

Classification

Physics

^Abstracts

61.70W - 66.30 ^- 68.60J

1. Introduction.

Polycrystalline silicon,

^{often referred to as}

«

polysilicon

^», is obtained either

by casting ingots

via a

Bridgman-like growth

process ^or

by setting

up ribbon

technologies

^{based on}

shaped crystal growth.

These

technologies

^are

developed

^{to reduce the}

cost of terrestrial solar cells

by minimizing

^silicon

consumption

^and/or

by using cheaper, degraded

silicon as

starting

material. Possible

applications

^to

microelectronics

should be also born in mind for the future.

Final materials obtained

by

such methods have a

large

^{amount of}

structural,

^chemical and electrical defects.

Thus,

^{the main}

objective

of research in the last decade has been to

identify

^and

classify

^these

defects,

^to

investigate

^{which ones are the most}

detrimental

in terms of

photovoltaic yield

^{and to find}

(*)

^{To whom}

correspondence

^{should be sent.}

REVUE DE PHYSIQUE APPLIQUÉE. - ^T. 22, N° 7, JUILLET 1987

out methods for

passivation

^{of the}

electrically

^active

ones.

For

example,

it has been demonstrated that im-

plantation

of molecular or atomic

hydrogen improves

the electrical

properties

^{such as} the diffusion

length

in both

ingots

^{and ribbons}

[1-5].

^{Diffusion at low}

temperature

of selected

impurities

^{such as Cu and Al}

into

polycrystalline

^{Si was} also found to

improve

^the

minority

^{carrier diffusion}

length [6].

In the case of ribbon

technologies,

^{it has been also}

shown that thermal treatments

could,

in certain cases,

improve

^{the diffusion}

length [4, 7].

^{The im-}

provements

^have been related to intrinsic

gettering

effects in which

fast-diffusing species

^{are offered}

energetically

favorable sites outside the

electrically

active

region

^of the material.

Surface

physics

methods have been

thought

^{to be}

useful in this

perspective

since the active area of

photovoltaïc

^{devices are} located in the

top

^few micrometers. Is it

possible

^to draw detrimental

45

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/rphysap:01987002207066300

664

impurities

^out of the active

region ?

Is it relevant to use some of the classical

gettering

processes in

polysilicon technology ?

^{To answer these}

questions

we

applied

^{surface science}

techniques

^{to understand}

particularly

^{the role} of oxygen and heat ^treatments in the

segregation

^{of metal}

impurities

towards the surface of silicon

samples.

In this paper, after

having briefly

recalled the RAD

growth

process and the

experimental set-up,

we shall sum up the

early

^surface

analytical

^results

found on RAD

ribbons,

^{then we shall}

present

^recent

investigations

^{on model}

systems (silicon bicrystals).

No

attempt

^{has been}

made, however,

to measure differences in electrical

properties during

^these

model studies

since ultra-high

^vacuum is needed for surface

analysis

^and

prevent

^{one to realize}

easily

reliable electrical measurements.

2.

Experimental.

2.1 SAMPLES. ^- RAD silicon ribbons were obtained

by

^a

shaped crystal growth

^{in which a carbon}

support

is

continuously pulled through

^a

p-doped

silicon melt via a slot located at the bottom of a RF induction heated

quartz

crucible. Details about the various technical

requirements

^and achievements of the process ^can be found in

[8].

^After

growth,

^the

carbon

support

is burnt-off in a

dry

oxygen ^atmos-

phere

^at

temperatures ranging

^{from 1000 °C to}

1200 °C

during

¹

hour, resulting

^{in two}

self-support- ing

^{Si sheets} less than 100 _03BCm thick. The outside faces are oxidized and the inner faces are covered with a discontinuous SiC

layer.

^The thicknesses of the oxide

layers

range from 0.2 ^to 1 _03BCm. These two

overlayers

^are

chemically

etched off before

making N+ /p homojunctions by

^a

classical POCl3

^diffusion

process ^at 850 °C. In most cases, ^we studied

samples

as obtained after the burnt-off process.

As model

materials,

^{we used CZ}

bicrystals (n -10 ^03A9.cm-1

^and

p -1 03A9.cm-1),

grown ^at the LETI

(Grenoble). Oxygen

and carbon concen-

trations are in the

1017 at.cm-3 range

^{and can}

locally

exceed the limit of

solubility

^at

equilibrium [9].

^Bar-

like

samples (4

^{x 4 x 10}

mm3),

^{cut from the}

ingots,

were oriented

by back-reflection

^Laue

techniques ;

two

kinds

of orientations were chosen :

i)

^the

grain boundary plane being perpendicular

to the

long

axis of the

bar,

ii)

^the

easily

^cleavable

(111) plane, perpendicular

to this axis.

Grooves were made either

right along

^{the intersec-}

tion of the

grain boundary plane

with the bar or

along

^a

(111) plane.

^{It was then}

possible

^{to cleave}

our

samples

^{in UHV and to}

get

^clean

virgin

^silicon

surfaces

and, sometimes,

^the

boundary plane

^itself.

In this paper, ^we shall discuss

only incidentally

^the

role of the

grain boundary which

^{is not the}

major parameter

of interest.

The

samples

^were etched in dilute HF and no

thermal treatment

applied prior

their introduction in the UHV chamber

3.

Analytical

^methods.

Impurity

concentration

profiles

^{of RAD}

samples

were determined

by

^{means of}

X-Ray

Photoelectron

Spectroscopy (XPS)

^{in a VG ESCA III}

apparatus.

Depth profiles

^{down to 1} )JLm ^were obtained

by argon-ion sputter etching

^the

sample step by step (about

¹⁰⁰

^Â

^{per ion}

bombardment).

^The

sputtered

area had a

larger

diameter than the

analyzed

^one.

Silicon

bicrystals

^were

analysed by Auger

^Electron

Spectroscopy (AES) using

^{a RIBER CMA in a}

UHV chamber fitted with several

accessories (argon

ion

bombardment, cleavage system,

Knudsen cells for

metal evaporation, ...).

^{The diameter of the}

spot

is 10 _{03BCm ;} too

large

^to

investigate

^the

grain

^bound-

aries,

it allows to

study

^{surface domains about}

30 _03BCm

large.

Since

the low-energy Auger peaks

of metal im-

purities

^are

superimposed

^to the silicon

Auger

^LVV

fine structure, ^we used the LMM

peaks

^of

Cr,

^Fe

and Ni at

respectively 529, 703,

^{and 848 eV to derive} concentrations. Of _course, the differences in mean

free

paths

between the various

Auger

transitions have been taken into account in these calculations.

Concentrations are

given

^{in atom} per ^cent and are

averaged

^over thicknesses of about 8

Â.

The ratioes between the

high-

^and

low-energy peak

intensities have been also studied to

precise

^the

location of

given impurities

^with

respect

^{to the} surface.

4. Results on RAD

polycrystalline

^ribbons.

4.1 GENERAL OUTLINE OF THE IMPURITY DISTRI- BUTION IN RAD RIBBONS. ^- We

previously

^de-

scribed

depth profiles

^of

impurities

^{in RAD ribbons}

and we summarize here the main results

[10].

^{At that}

time

burning

off the carbon

support

^{was not}

yet

ⁱⁿ

use. On the

samples

^{received as} grown, surface

analysis

^showed

^oxide layers

thicknesses of which

were

ranging

^{from 200 to 1 000}

A, depending

^{on the}

growth

conditions. The oxide was

generally

^not

three-dimensional silica as observed

by

^{AES and}

XPS

[11,12].

Impurities

^could

be

classified in two

catégories : i)

^carbon and oxygen, which ^were

always present

at concentrations

equal

^or

higher

^{than their}

solubility

limit at the

melting point

^of

silicon, respectively

5 x

1017

and

1018

^at.

cm-3 [9].

Their concentration

profiles

^were identical in all

samples. Oxygen

^{is a}

by- product

^of the reaction between the silicon melt and the

quartz crucible ;

^{carbon comes}

mainly

^{from the}

support

^{but also from the}

decomposition

^{of the}

residual carbon monoxide

present

^{in the furnace.}

ii)

^metal

impurities,

^{which were not}

always

pre- sent at the same

places

^{of the ribbon but}

which,

when

they

^were

observed,

^{were not}

randomly

^dis-

tributed. Their

position by respect

^to the surface was

always

^the same, i.e.

Cu, Na, Bi, Zn,

^{Ni and Sn are}

in the

top

²⁰

A,

^{Ca and}

Mg

^are

just

^{above the}

Si/Si02 interface,

Fe and Cr are

just

^{under this}

interface and in the bulk. Bulk concentrations have been measured

by

^neutron activation

analysis (NAA)

^{and found to be} in the range of

1012

to

1014

at.

cm-3 showing

^effective

partition

coefficients between the melt and the ribbon in the range

10-1

^to

10-3 [13].

^{In our}

experiments,

^surface

concentrations can be estimated to

1012

to

1014

at.

cm-2 _which, averaged

in the volume

probed by

^the

method,

^would

correspond

^to

1015

to more

than

1017

at. cm-

3.

This

gives

enrichment factor of about 1 000 for RAD ribbons. These

impurities

^were

incorporated

from the silicon melt and came

initially

from the carbon ribbon.

3.2 GETTERING OF IMPURITIES IN BURNT-OFF AND

POCI3

^DIFFUSED RAD. - When the burn-off _pro-

cess of the carbon

support

^is

used,

^{an oxide}

layer

^less

than 1 _jim thick covers the bulk silicon film

[14].

This

layer

^is

always

three-dimensional stoichiometric silica as evidenced

by

AES and EELS

[12,15].

^We

did not find metal

impurities

^{in this}

layer,

^{within the}

limits of detection of XPS which are somewhat poor if the

impurity

^is

equally

distributed in a

large volume (10 ppm).

If the silica

layer

^{is dissolved in diluted HF and the}

sample quickly

^{returned to} the XPS UHV

chamber,

a

layer

of native oxide 10 to 20 A thick

forms,

covered with a

monolayer

^of carbonaceous con-

tamination. In and under this

layer,

^metal

impurities (Bi, Cu, Fe, Cr, Ni)

^{have been found with the same}

profiles

^{as described}

in §

1. Control

samples,

^made

of FZ

single-crystalline silicon,

^{do not show} these

impurities

after heat treatments

equivalent

^{to the}

burn-off process. It is thus clear that

during

^this

process, surface

segregation

^{of metal}

impurities

occurs in RAD ribbons.

We also studied some

samples

^{where a}

N+ /p junction

^had been formed

(details

^{on the}

procedure

can be found in Ref.

[27]).

^The

depth

^{of the}

junction

is 0.6 _03BCm.

Impurities (Cu, ^Fe, Cr)

^were found with a

profile looking

^{much alike the one described}

above,

viz. copper ^near the

surface,

^chromium and iron in the

vicinity

^{of the}

junction.

^{In this} case, the

gettering

effect is

probably

^{due to the}

POCl3

^diffusion

(extrin-

sic

gettering)

^since

impurities

^are located within the

junction.

^This

type

^of

gettering,

^{like the intrinsic one}

leads to lattice strain and to the

injection

^{of silicon}

interstitials,

^{believed to be}

responsible

^{for the}

getter

effect

[16, 17].

5. Model studies on silicon

bicrystals.

It seems clear from the results obtained on RAD

polysilicon

^{ribbons that} oxygen

plays

^an

important

role on the surface

segregation

^of

impurities

^{since a}

clear relation between their presence and ^concen- trations in oxygen has been evidenced

[10].

^{It has}

also been shown that heat treatments could

improve

some of the electrical

properties [7].

^{So there are}

some

analogies

^{with the}

so-called getter

^{effect used} in microelectronics and reviewed

recently by

^Richter

[18].

To test the

role

of oxygen in

gettering (or

^{in surface}

segregation)

^we studied the model materials de- scribed in the

experimental

section. These

crystals,

grown

especially

^{to offer an} alternative material to

polysilicon

in fundamental

investigations

^are

simpler

to

study

since there is

only

^one

grain boundary.

Metalloïdic

impurities (carbon, oxygen)

^{have about}

the same bulk concentrations as in

polysilicon,

^i.e.

between

1017

and

1018

at.

cm-3

as measured

by

^IR

spectrometry [9] ; ^metals, analysed by

^NAA

[19],

have lower concentrations than in

ribbons,

_e.g.

1.8 x

1013

at.

cm-3

for Na and below detection limits for

Cr, Cu, Fe,... (below 1012-1013 at. cm-3).

For this _purpose, we measured

by Auger

^Electron

Spectroscopy (AES)

surface concentration

profiles

of

impurities

^after isochronous

annealing

processes at 450 °C

(1 hour),

^{750 °C}

(1 hour), ^{950 °C} (1 hour)

and 1 250 °C

(5 min)

^{on :}

- clean

surfaces,

- surfaces oxidized at room

temperature

ⁱⁿ

UHV or in

air,

- surfaces oxidized at 450 °C in UHV.

The

annealing temperatures

^{were chosen}

because they

^are characteristic

respectively

^{of the formation}

of the first thermal

donor,

of the second

(new) donor,

^{of the}

precipitation

^{of silica}

and, finally,

^{of its}

dissolution

[20].

5.1 SEGREGATION AT CLEAN SURFACES. ^- In

figure

^{1 are shown surface} concentrations of im-

purities

^{on cleaned} surfaces. In this _case, the surface is cleaned

by

argon

ion-bombardment

after _every heat treatments.

Oxygen

and carbon concentrations reach a maxi-

mum at 750 °C and then decrease. At 750 °C the silicon

Auger

^{fine structure is}

characteristic

of silica.

The thickness of the oxide

layer

is evaluated at about 5

Á. Potassium,

^{not shown in the}

figure, present

after the first

annealing

process is dissorbed before 750 °C.

Chromium and iron concentrations increase stead-

ily

^with

temperature

^{above 750 °C and the}

Auger

spectra

^{of these}

impurities

^{show that}

they

^{are not}

oxidized. Since their local concentration is

higher

than the limit of

solubility

^{it is}

possible

^{that these}

666

Fig.

^{1. -} AES surface concentrations on cleaned silicon surfaces at the initial ^state i and after heat treatments.

a)

^Silicon concentrations,

b) impurity

concentrations.

Fig.

^{2. - AES}

in-depth

concentration

profile

^{of a room-} temperature ^{oxidized silicon}

sample.

The time scale is related to the time of

argon-ion

bombardment ; ^the distance scale

gives

the eroded thickness.

interface. There are still noticeable concentrations in iron as far as 60

 deep.

In

figure

^{3 are} shown the surface concentrations of

impurities, respectively

before and after a room-

impurities

^are

present

^as silicides.

Up

^{to now we do}

not have evidence of this silicide formation

by

^AES.

These results look very much alike those obtained

on RAD ribbons. Potassium is on the

top

^{of the}

segregated layer present

after the heat treatment at 450

°C ;

^{chromium and iron are}

just

below the ultra- thin oxide

layer

^and

they

reach the surface when the

temperature

^is

large enough

^{to allow the} outdiffusion of oxygen ^atoms.

5.2 SEGREGATION AT ROOM-TEMPERATURE OX- IDIZED SURFACES. ^- Two kinds of room

tempera-

ture oxidation have been

investigated :

^{one in am-}

bient

atmosphere (native

oxide obtained after about 20 min in air after

cleaning),

the other in UHV

|p(O2) :

^{2 x}

^{10- 5} Torr,

³

houris 1. They

gave identi- cal results.

A

typical in-depth

concentration

profile

^{of im-}

purities

^{taken on a}

room-temperature

^{oxidized sam-}

ple having

^{a native oxide}

layer

is shown in

figure

^2.

For sake of

clarity,

the concentrations of oxidized silicon are not shown.

Auger spectroscopy

^shows that this oxide is not silica but

SiOx ;

^{this is evidenced}

both

by

^the

Auger

^{fine structure} and the stoichiomet- ry calculated from the

height

of the oxidized silicon

peak

and the oxygen

peak.

^{Nickel is}

present

^{on the}

top

^{of the}

layer ;

chromium and iron reach their maximum concentration at the silicon/silicon oxide

Fig.

^{3. -} AES surface concentration before

(i),

^after

(ox)

a

room-temperature

oxidation in UHV and after heat treatments at

given

temperatures.

a)

^{Silicon concen-}

trations

(left scale)

and thickness of the oxide

(right scale),

b) impurity

concentrations.

temperature ^oxidation

ⁱⁿ

UHV,

^{and after each heat}

treatment. One can see that RT oxidation indeed

brings impurities

^near the surface. In this case,

subsequent

^heat treatments do not

modify drastically

the

impurity

concentrations and the final state, ^after the whole

annealing cycle,

^is

nearly

^{the same as the}

initial _one, before oxidation.

5.3 SEGREGATION AT SURFACES OXIDIZED AT

450 °C. ^-

Figure

^{4 shows the} concentration of

impurities respectively

before and after

oxidation at

450 °C

|p(O2) :

^{2 x}

^10-5 Torr,

³

houris 1 ^and

^after

each heat treatment. The

starting

^{surface was, in this}

case, rather rich in

impurities.

It is

clear, however, that

^oxidation favours the

segregation

^{of more}

impurities

towards the surface.

But as soon as this

surface,

^{covered now with a silica}

layer

¹⁴

 thick,

^{is annealed there is an}

important

decrease of the

impurity

^content. Its minimum is reached at 750 °C.

Fig.

^{4. -} AES surface concentrations before

(i),

^aftei

(ox)

^an oxidation made in UHV at 450 °C and after heal treatments at

given

temperatures.

a)

Silicon and oxyger concentrations

(left scale)

and thickness of the oxide

(righ1 scale), b) impurity

concentrations.

6. Discussion.

Two

points

appear ^{worth to be}

discussed,

^the

segregation

^{of metal}

impurities

^{toward the surface in}

polycrystalline

RAD ribbons or

bicrystals

^{and the}

role of oxygen ^{as a}

driving

^{force for}

gettering.

i)

It is clear from the results that metal

impurities

are

present

^{at much}

higher

concentrations in the

top layers

^{of RAD}

polycrystalline

^ribbons than in the bulk. In

bicrystals,

^surface

segregation

^{of metal}

impurities, probably incorporated

from the melt

during

^the

growth

process, is

observed

after oxida- tion

showing

^also

large

concentrations. It should be

pointed

^{out that the}

spatial

distribution of these

impurities

^{is the same} whatever the oxidation ^tem-

perature

^{is and} whatever the oxide thickness is.

In our

experiments,

^surface concentrations can be estimated to

1012

to

1014

at.

cm-2 which, averaged

ⁱⁿ

the volume

probed by

^{AES or}

XPS,

^{would corre-}

spond

^to

¹⁰¹⁵

^{to more than}

¹⁰¹⁷

^{at. cm-}

^3.

^This

gives enrichment

factors of about 1 000 for RAD ribbons and

about 105

for

bicrystals.

Even if classical diffu- sion or

segregation

coefficients could

explain

^{such a}

large segregation

^{for RAD}

ribbons,

^{it is not the case}

for oxidation of

bicrystals,

^at

room-temperature

^or 450 °C. Intrinsic

gettering

is thus believed to occur in both cases.

It is indeed well known that oxygen

plays

^an

important

role in this

type

^of

gettering

^effect

[18]

and several mechanisms have been described to

explain

the enhanced

diffusion

of oxygen in silicon

[21, 23].

Some of these

authors

^{think that the}

precipitation

^{of oxygen}

injects

^silicon self-intersti- tials

which

^{are able to make}

complexes

^with oxygen and which have a

large diffusivity. ^Then,

^these

complexes

^should

trap

^metal

impurities.

^Model

studies show in fact that the surface structure of the oxide

layer

^is

important

^{in the}

segregation

process.

They

^{are not able to describe}

yet

^{the exact}

mechan-

isms of this enhanced

diffusivity.

We have shown that if

room-temperature

^ox-

idations, leading

^{to a}

SiO,, layer,

^{were able to draw}

impurities

^{out of the}

^bulk, giving

^{rise to a kind of}

intrinsic

getter effect, subsequent

^{heat treatments}

did not

modify

^{the surface}

concentration

of metal

impurities.

^{On the}

contrary,

if there is a ultra-thin

layer

of silica

(Si02 )

^{instead of}

SiOx,

^{the heat}

treatments draw back the

impurities

in the bulk.

This could be related to the

injection

of silicon self- interstitials which would be

possible only

^{because of}

the strain induced

by

the misfit between silica and silicon.

How the final

step (i.e.

^{the diffusion} of silicon- metal

complexes)

^{occurs is not}

yet fully

^understood

even if metal

impurities

^{have been} characterized in the

vicinity

^of

Si02 precipitates [24].

ii)

On another

hand,

^{one can} argue that ^a 12 A

Si02 layer

^is

probably

^{not able to}

inject enough

^Si

self-interstitials in the bulk and it would seem that the role of oxygen is ^not

only

^{to induce intrinsic}

gettering

^{after its}

precipitation,

it is also a chemical

driving

force. We have indeed the evidence

that,

ⁱⁿ

silicon

bicrystals, impurity

diffusion toward the sur-

668

face occurs even if the surface is oxidized at low

temperature (450 °C

^{and even room}

temperature).

Which kind of mechanism is

possible ?

If it is the

affinity

^{of a}

given

^metal

impurity

^to oxygen ^as it was

postulated

ⁱⁿ

[10], why

^{is these}

impurity

^{not bound}

to oxygen ^{as it is} evidenced

by

^{AES ?}

A

possible explanation

^{could be}

^that

^{metal im-}

purities,

^{such as iron and chromium are}

only catalysts

for silicon oxidation :

they

^{would favour an}

oxygen

dissociative

adsorption

process ^on silicon surfaces.

Viefhaus and Rossow

[25]

^{have found that in a Fe-}

Si 6 at. %

alloy,

^surface

segregated ^silicon

^{is more}

easily ^oxidized

than pure silicon. The same obser- vation has been made

by Mosser,

Srivastava and Carrière

[26]

^{who noticed that} Fe-Si oxidation at

temperatures higher

^{than 500 °C would lead to a}

silicon dioxide

segregated overlayer topping

^unox-

idized iron. The formation of silicides has been also evidenced in similar

experiments

^{as in the}

POCl3

getter

process

[27].

^{In our} case, ^we could not show

by

^{AES or XPS that} these silicides

really

^exist.

7. Conclusion.

Surface

analytical

methods have been used to investi-

gate

^{the diffusion and}

segregation

^{of metal}

impurities

at the surface of RAD

polysilicon

^{ribbons and silicon}

bicrystals. High

^surface concentrations of chro-

mium,

copper,

iron, potassium,

^iron and nickel have been evidenced. We believe that this

segregation

^is

possible through

^{intrinsic and extrinsic}

getter

pro-

cesses induced

by

^the

precipitation

^{of the dissolved}

oxygen atoms

during

^{the burn-off} process of the carbon

support

^and

during

^the

POCl3

^diffusion

cycle

for RAD ribbons. These effects have been demon- strated for silicon

bicrystals

when the surface is oxidized at

temperatures higher

^{than 450 °C and}

then annealed at 750 °C.

However,

^{it is}

thought

^that

oxygen does not act

only

^{as a nucleus for}

giving straining Si04 ^units, leading

^{to the}

injection

^{of fast-}

diffusing silicon

self-interstitials

but

also as a chemi- cal

driving

^{force able to} induce the

segregation

^of

metal

impurities

^{in the area rich in} oxygen

through

^a

catalytic

^{mechanism in which} oxygen, silicon and metal

impurities

^are

strongly cooperative.

We have shown that intrinsic and extrinsic

getter

effects or surface

segregation

may be effective in

polysilicon technology.

^{It is thus}

possible ^to

^take

advantage

^{of the thermal} treatments

occurring

^either

during

^the

growth

^or

during

^{the diffusion} process ^to

improve

the electrical

properties

^of

polysilicon

^solar

cells.

Acknowledgments.

The authors wish to thank Dr. Belouet from C.G.E.

for the

supply

^{of the}

polysilicon

^RAD

samples

^and

the ^«

Groupe

^Silicium

Polycristallin »

for the many

enlighting

discussions that it has initiated.

The work was made under the financial

support

^of PIRSEM and COMES.

References

[1] SEAGER,

^{C. H. and}

GINLEY,

^D. S., ^J.

Appl. Phys.

⁵²

(1981)

^1050.

[2] MULLER,

^J.

C., ABADOU, Y., BARHDADI, A.,

^COUR-

CELLE,

E., UNAMUNO, S., SALLES,

D.,

SIFFERT,

P. and

FALLY, J.,

^{Solar Cells}

(in press).

[3] MAUTREF, M., LACROIX, C., BELOUET, C., FAGES, C., BIOTTEAU,

^{B. and}

ARNOULT, F.,

Revue

Phys. Appl.

¹⁹

(1984)

^333.

[4] BELOUET,

^{C. in :}

Poly-micro-crystalline

^and

amorph-

ous

semiconductors,

Eds. P. Pinard and S.

Kalbitzer

(Editions

^de

Physique, Paris) 1984,

p. 53.

[5] AMZIL,

H.,

MATHIAN,

^{G. and}

MARTINUZZI,

S., ibid.

p. 69.

[6] ZEHAF,

M.,

MATHIAN, G., PASQUINELLI,

^{M. and}

MARTINITZZI,

S., ^ibid.

p. 137.

[7] WALD,

F. V., ibid. p. 33.

[8] BELOUET, C., TEXIER-HERVO, C.,

MAUTREF, M.,

BELIN, C., PAULIN,

^{J. and}

SCHNEIDER,

J., ^J.

Crystal

^{Growth 61}

(1984)

^615.

[9] PAJOT, B., Rapports PIRSEM, 1984

^{et 1985}

(Editions

du

C.N.R.S., Paris).

[10]

DEVILLE, ^J. P.,

QUESADA,

J. and

SOLTANI,

^M. L., J.

Physique Colloq.

⁴³

(1982) C1,

^193.

[11] CARRIÈRE,

B.,

DEVILLE,

J. P.,

BRION,

^{D. and}

ESCARD,

J., ^{J. Electron}

Spectrosc.

^Relat.

Phenom. 10

(1977)

^85.

[12] CARRIERE,

B.,

DEVILLE,

J. P. and

HUMBERT,

P., J.

Microsc.

Spectros.

^{Electr. 10}

(1985)

^29.

[13] REVEL, G., DESCHAMPS, N., DEVILLE, J. P.,

^TE-

XIER-HERVO,

^{C. and}

BELOUET, C.,

^{Proc. 4th}

E.C. Photovoltaic

Energy Conf., Stresa, (1982) p. 970.

[14] Graphs

of the oxide thickness on various silicon surfaces can be found in

L’oxydation

^du

silicium,

B.

Leroy (1985) (Publications

IBM, Corbeil-Es-

sonnes).

[15] ELMAACHI,

A., Thèse de Doctorat de l’Université

Louis-Pasteur, Strasbourg,

^1985.

[16] OURMAZD,

A. and SCHROTER, W.,

Appl. Phys.

^Lett.

45

(1984)

^781.

[17] GÖSELE,

^{U. and} FRANK, in :

Defects in

Semiconduc- tors, Eds. J.

Narayan

and T. Y. Tan

(North

Holland, ^New

York)

^1981,

p. 55.

[18] RICHTER,

in: Proc. 1st International Autumn School,

Gettering

^{and Defect}

Engineering

^{in the}

Semiconductor

Technology,

^{Ed. H.} Richter

(Garzau)

1985,

p.1.

[19]

^REVEL,

^G., unpublished

^results.

[20]

^{CAZCARRA, V. and} ZUNNINO, P., ^J.

Appl. Phys.

⁵¹

(1981)

^4206.

[21]

^{KAISER, W., FRISCH,} H. L. and REISS, H.,

Phys.

Rev. 112

(1958)

^1546.

[22]

^{GÖSELE, U. and} TAN, ^T. Y.,

Appl. Phys.

^28A

(1982)

79.

[23]

OURMAZD, A., SCHRÖTER, ^{W. and} BOURRET, A., ^J.

Appl. Phys.

⁵⁶

(1984)

^1670.

[24]

^{BOURRET, A. and SCHRÖTER, W.,}

Ultramicroscopy (1984).

[25]

^{VIEFHAUS, H. and Rossow, W.,}

Surface

^{Sci. 141}

(1984)

^341.

[26]

MOSSER, A., SRIVASTAVA, ^{S. C. and} CARRIÈRE, B.,

Surface

^{Sci. 133}

(1983)

^L-441.

[27]

^{MOUDDA AZZEM, T., Thèse de} Doctorat, Université de Paris 6

(Paris, 1985).
