MÖSSBAUER SPECTROSCOPY OF Fe IMPURITIES

IN LiNbO3

S. Date, W. Keune, H. Engelmann, U. Gonser, I. Dezsi

To cite this version:

JOURNAL DE PHYSIQUE Colloque C6, supplément au n° 12, Tome 37, Décembre 1976, page C6-117

MOSSBAUER SPECTROSCOPY OF Fe IMPURITIES IN LiNb0

3 S. K. DATE (*), W. KEUNE (**), H. ENGELMANN, U. GONSER and I. DEZSI (***)

Fachbereich Angewandte Physik, Universitat des Saarlandes, 6600 Saarbrucken, Germany

Résumé. — Nous avons étudié l'effet Môssbauer d'ions Fe3+ et Fe2+ dilués dans des

monocris-taux de LiNbOî. Pour Fe3+ nous observons à basse température des spectres possédant une

struc-ture hyperfine paramagnétique caractéristique d'une relaxation électronique lente. Il est possible de modifier réversiblement le rapport Fe2+/Fe3+ dans un cristal par un traitement thermique oxydant

ou réducteur. La relaxation électronique de Fe3+ à basse température reste lente même en présence

d'une large proportion d'ions Fe2+.

Abstract. — The Mossbauer effect of dilute Fe3+ and Fe2+ ions in LiNbo3 single crystals is

reported. For Fe3+ typical paramagnetic hyperfine spectra were observed at low temperature which

are characteristic of slow electronic relaxation processes. TheFe2+/Fe3+ ratio in a crystal can be

changed reversibly by oxidizing or reducing heat treatment. The spin relaxation for Fe3+ at low

temperature remains slow even in the presence of a large fraction of Fe2+ ions.

Iron doped LiNb03 is an axial ferroelectric material

which is of technological importance as a potential high-resolution holographic storage medium [1]. The rhombohedral crystal structure of L i N b 03 is closely

related to that of corundum (<x-Al203); it is obtained by

replacing two A l3 + ions by a Li1 + and a N b5 + ion

alternately in an ordered array along the crystallo-graphic c-axis [2]. Li1 + and N b5 + ions lie in slightly

distorted oxygen octahedra with trigonal site sym-metry C3. EPR studies by Herrington et al. [3]

indicat-ed that the Fe impurity can enter the lattice substitu-tionally as high-spin F e3 + on an axially symmetrical,

unique lattice site with the symmetry axis parallel to the c-axis. Previous Mossbauer results [4] obtained with L i N b 03 single crystals Fe57-doped by diffusion

indi-cated the presence of high-spin F e3 + and F e2 + valence

states their ratio depending on the thermal treatment of the samples. The F e3 + and F e2 + ion each was found to

be on a unique axial lattice site with the symmetry axis parallel to the c-axis.

In this communication we present further Mossbauer effect results for dilute Fe5 7 impurities in L i N b 03

single crystals. The samples were doped with 0.22 W % Fe2Os (91 % enriched in Fe57) by growing from the

melt (Czochvalsky technique), and thus have a more homogeneous impurity distribution than diffusion doped crystals used previously.

Quite similar to a-Al203 (corundum) LiNb03 is a

suitable host lattice for dilute Fe3 + impurities to study

the effect of electronic spin relaxation on the Fe5 7 (*) Tata Institute of Fundamental Research, Bombay, India. (**) Laboratorium fur Angewandte Physik, Gesamthoch-schule, 4100 Duisburg, Germany.

(***) Central Research Institute for Physics, Budapest, Hungary.

nuclear hyperfine structure. This is demonstrated in figure 1, where typical spectra of F e3 + in L i N b 03

(oxidized sample) are shown at different temperatures. At room temperature and above the spectrum exhibits a central non-Lorentzian absorption with wings extend-ing to about + 10 mm/s. At 77 K and 4.2 K the spectra clearly show the magnetic hyperfine patterns which arise because of an increase of the electronic spin-relaxation time at low temperatures. Our spectra are similar to those reported for F e3 + in <x-Al203 by

several authors [5,6]. The spectrum in figure \d (4.2 K) was analyzed following the criteria suggested by Wertheim and Remeika [6]. The crystalline field splits the 6S5 / 2 state of the F e3 + ion into three Kramers'

doublets | ± 5/2 > , | ± 3/2 > and | + 1/2 > . Each of them produces an effective hyperfine field at the Fe5 7 nucleus if the respective electronic relaxation

times are large compared to the nuclear Larmor pre-cession time. Neglecting off-diagonal elements for | + 5/2 > and | ± 3/2 > states in the hyperfine interaction tensor one expects, in the limit of long rela-xation times, one six-line pattern from each state. As off-diagonal terms for the | ± 1/2 > state are signifi-cant, a complicated pattern of eleven lines is expect-ed [6].

In the low-temperature spectra in figure 1 (top) clearly a superposition of two six-line patterns, one due to the | + 5/2 > state and one arising from the

| + 3/2 > state, is observed (indicated by the bar diagrams). Since the crystallographic c-axis was per-pendicular to the ^-propagation direction in this experi-ment, the relative intensities of the hyperfine lines in each six-line pattern which are expected if the c-axis and the principal axis of the EFG tensor (quantization axis) coincide, are 3 : 4 : 1 : 1 : 4 : 3 . The pronounced

C6-118 S. K. DATE, W. KEUNE, H. ENGELMANN, U. GONSER AND I. DEZSI

V e l o c i t y I m m I s ]

FIG. 1.

-

Fe3+ Mossbauer spectra of single crystal LiNb03 - 0.22 W % Fe57O3, oxidized in air at 800 C, (a) at 970 K, c-axis parallel to y-ray, (b) at 295 K, c-axis parallel to y-ray, (c) at 77 K, c-axis perpendicular to y-ray, ( d ) at 4.2 K,

c-axis perpendicular to y-ray (source : C027 in Rh).

(Am = 0)-lines observed in each six-line pattern demonstrate that the principle EFG axis is approxima- tely colinear with the c-axis, as for Fe3+ in a-A1203. The resulting hyperfine fields are 529 kOe and 317 kOe for the

I

f

512

>

and

I

f 312

>

levels, respectively, i. e. a value of 212 kOe/spin is obtained which is somewhat smaller than 220 kOe/spin obtained for Fe3+ in a-A1203 [6, 73. The quadrupole interaction constant e2 qQ = eVzz Q for Fe3

*

was determined from the measured difference of the two outer lines to the right (S,) and the difference of the two outer lines to the left (S,) of the

I

f 512

>

pattern :

assuming axial site symmetry

(r

x

0) and C Sz

>

and V,, parallel to the c-axis (8 = 0). We obtained a value e2 qQ =

+

1.04 f 0.08 mm/s, which is equal in sign and magnitude to that of Fe3* in corundum [6].

Thus, the local environment of Fe3+ in LiNbO, is similar to that of Fe3+ in a-A1203, i. e. an oxygen

octahedron, and a possible charge-compensating defect, e. g. an oxygen vacancy, is remote. The center shift at 4.2 K with respect to a-Fe at room temperature was found from the

I

+

512

>

spec- trum to be

+

0.47 f 0.05 mm/s.

As for Fe3+ in a-A1203 [6] the theoretically predicted eleven absorption lines caused by the

1

+

112

>

level also could not be observed down to 4.2 K for Fe3+ in LiNbO,. The effect of the

I

f 112

>

state in the mea- sured low-temperature spectra apparently is an unresolved background smear extending up to higher velocities and the appearance of two most central absorption peaks (Fig. Id) which cannot be explained by the I $- 512

>

and

I

f 312

>

patterns. The influence of various reducing thermal treatments on the iron valence state in LiNbO, is demonstrated in figure 2.

V e l o c i t y [ m m l s l

RG. 2. - Mossbauer spectra of a LiNb03 - 0.22 W % Fe2703 absorber measured at 77 K after various annealing procedures at 1 000 C : (a) as grown, (b) 760 tom argon atmosphere, 50 h, (c) 760 torr Ar, additional 50 h, ( d ) 50 torr Ar, additional 10 h, (e) 0.2 torr Ar, additional 20 h (c-axis always perpendicular

to y-ray).

MOSSBAUER SPECTROSCOPY O F Fe IMPURITIES IN LiNb03 C6-119

reported earlier [4], and which is caused by a small fraction of high-spin Fez+ ions. Starting from the as-grown state of the sample continued annealing at 1 000 C in Ar atmosphere results in an increasing Fe2+/Fe3+ ratio, since in figure 2a-e the line intensity of the Fez+-doublet is seen to increase relative to the Fe3+ intensity, indicating the enhanced conversion of Fe3+ to Fez'. For the different reduction' stages (described in detail in the caption of figure 2) the rela- tive amount of Fez+ increases from about 15 % (Fig. 2a) to m 90

% (Fig. 2e).

As can be seen from figure 2 the Fe3 + electronic rela-

xation time remains sufficiently long even in the pre- sence of Fez+ ions to produce the paramagnetic Fe3+ hyperfine pattern. This observation is in contrast to results for Fe3+ in u-A1203 where the Fe3 + relaxation

time is decreased by the presence of Fez+ impurities [6], presumably by cross-relaxation.

Annealing the samples at 800 C in 1 atm. of Ar atmosphere for 24 hours results in 100 % reduction to Fez+ impurities [4], i. e. no trace of Fe3+ ions has been detected in Mossbauer spectra of such samples. The line intensity ratio of the Fez+ doublet indicates axial symmetry at the Fez+ site along the c-axis, and a negative quadrupole coupling constant 141.

Further experimental evidence for this result is given in another contribution at this conference [8]. In figure 3 measured values of AEp = 112 eVZz Q for

Fez' are plotted versus temperature. A strong tempe- rature dependence of AEQ is evident. The negative sign

Temperature IKI

FIG. 3. - Temperature dependence of AEQ = 112 ez qQ for Fez+ in LiNbO3.

of YZZ indicates that the electronic ground state is an orbital singlet, which appears together with an energe- tically higher-lying doublet because of removal of degeneracy of the T,, level by the trigonal crystal field. Acknowledgments. - This work was supported by the Deutsche Forschungsgemeinschaft under SFB 130. One of the authors (SKD) wishes to thank the Alexander von Humboldt Foundation for the award

of postdoctoral fellowship.
