Optical and radio observations of a sample of 52

powerful ultra-steep spectrum radio sources

C. Ledoux, J. Melnick, E. Giraud, Vainatey Kulkarni, B. Altieri

To cite this version:

(2)

A&A 436, 457–464 (2005) DOI: 10.1051/0004-6361:20052682 c ESO 2005

Astronomy

&

Astrophysics

Optical and radio observations of a sample of 52 powerful

ultra-steep spectrum radio sources

,

Gopal-Krishna

1

, C. Ledoux

2

, J. Melnick

2

, E. Giraud

3

, V. Kulkarni

1

, and B. Altieri

4

1 _{National Centre for Radio Astrophysics, TIFR, Post Bag 3, Ganesh Khind, Pune 411 007, India}

e-mail: [email protected]; [email protected]

2 _{European Southern Observatory, Alonso de Córdova 3107, Casilla 19001, Vitacura, Santiago, Chile}

e-mail: [email protected]; [email protected]

3 _{GAM, Univ. Montpellier II, Place E. Bataillon, 34095 Montpellier Cedex, France}

e-mail: [email protected]

4 _{European Space Agency, Villafranca del Castillo, Apartado 50727, 28080 Madrid, Spain}

e-mail: [email protected]

Received 12 January 2005/ Accepted 22 February 2005

Abstract.We present the results of radio (VLA) and optical (ESO/La Silla) imaging of a sample of 52 radio sources having an ultra-steep radio spectrum withα mostly steeper than −1.1 at decimetre wavelengths (median α = −1.22). Radio-optical overlays are presented to an astrometric accuracy of∼1. For 41 of the sources, radio spectral indices are newly determined using unpublished observations made with the 100-m Eﬀelsberg radio telescope. For 14 of the sources identified with relatively brighter optical counterparts, spectroscopic observations were also carried out at La Silla and their redshifts are found to lie in the range 0.4 to 2.6. These observations have revealed three distant clusters of galaxies with redshifts of 0.55, 0.75 and 0.79, and we suggest that, together with an ultra-steep radio spectrum and relaxed radio morphology, the presence of a LINER spectrum in the optical can be used as a powerful indicator of rich clusters of galaxies. Additional candidates of this type in our sample are pointed out. Also, sources exhibiting particularly interesting radio-optical morphological relationships are highlighted. We further note the presence of six sources in our sample for which the optical counterpart (either detected or undetected) is fainter than R∼ 24 and the radio extent is small (<10). These ultra-steep spectrum radio sources are good signposts for discovering massive galaxies out to very large redshifts.

Key words.cosmology: observations – galaxies: active – cooling flows – galaxies: clusters: general – quasars: general – radio continuum: galaxies

1. Introduction

The discovery of a correlation between the output of radio galaxies in optical emission lines and the radio band (e.g., Rawlings & Saunders 1991; McCarthy 1993) led to the recog-nition of using radio source samples as a means to detect galax-ies located at very large distances. Indeed, radio surveys backed up with optical spectroscopy provided the first detections of objects beyond a redshift of two (e.g., Spinrad 1986). A ma-jor technical breakthrough came with the demonstration of a statistical correlation between radio spectral index and distance (Chambers et al. 1987; McCarthy et al. 1987), as already hinted in some earlier studies (e.g., Tielens et al. 1979; Blumenthal & Miley 1979; Gopal-Krishna et al. 1980; Gopal-Krishna & Steppe 1981). This correlation is now understood to be largely

_{Based on observations carried out at the European Southern}

Observatory (ESO) on Cerro La Silla, Chile.

_{Tables 1–3 and full Fig. 1 are only available in electronic form at}

http://www.edpsciences.org

the result of a radio K-correction operating on the integrated spectrum which usually has a downward curvature arising from radiative losses (Laing & Peacock 1980). Consequently, the ra-dio spectrum in a given frequency range appears increasingly steeper with redshift. The most distant radio galaxy found so far using the clue of ultra-steep radio spectrum has a redshift

z= 5.2 (Venemans et al. 2004).

(3)

an eventual discovery of radio sources beyond z = 6 would provide a direct probe of the “re-ionization era”, via H



spectroscopy (e.g., Djorgovski et al. 2001). In this context, finding USSRS whose optical counterparts remain undetected down to fairly deep magnitudes (“empty fields”) is particularly important. Moreover, from the astrophysical perspective, it is also of great interest to detect optical emission associated with the lobes and hot spots of radio galaxies at high redshifts where inverse Compton losses against the intense cosmic microwave background would severely limit the range of the electrons capable of optical synchrotron radiation (e.g., Brunetti et al. 2003; Gopal-Krishna et al. 2001).

In this paper, we present radio and optical imaging data for a sample of 52 USSRS (Sects. 2 and 3). Redshift measurements for the brighter subset of 14 sources are also presented. The ra-dio maps are based on our Very Large Array (VLA) observa-tions while the optical data were obtained using the telescopes of the European Southern Observatory (ESO) at La Silla.

2. Observations

2.1. The USSRS sample and radio imaging

The present sample of 52 USSRS withα < −1.05 (but mostly

<−1.1; see Table 1) is an assortment derived from the following

four data-sets:

– The lists six to ten of the Ooty lunar occultation survey at 327 MHz (Subrahmanya & Gopal-Krishna 1979; Singal et al. 1979; Venugopal & Swarup 1979; Singal 1987): these are marked with “(oo)” in Table 1. Following Kühr et al. (1981), we have increased the published 327 MHz flux densities by 9%. To determine the radio spectral indices we have used these readjusted 327 MHz flux densities, but, if the source also appears in the 408 MHz Molonglo Reference Catalogue (MRC; Large et al. 1981) we instead used the 408 MHz flux from MRC. At high frequency, the fluxes are determined from the “cross-scan” observations of the Ooty sources at 2.7 GHz with the 100-m Eﬀelsberg ra-dio telescope (Kulkarni et al. 2005, in prep.). Note that for the source 2222−057 the Ooty flux at 327 MHz (Table 1) is only about half of the 1.03 Jy given in the 365 MHz Texas survey (Douglas et al. 1996). In view of this unusu-ally large discrepancy, we have used in Table 1 the average of the two spectral indices determined using the Ooty and the Texas flux densities. This metre-wavelength flux aver-aging still leaves a large uncertainty of ±0.2 in the com-puted spectral index of−1.16 (Table 1).

– The Molonglo surveys MC 1 and MC 2 at 408 MHz (Davies et al. 1973; Sutton et al. 1974), marked with “(ml)” in Table 1: the spectral indices are derived by combin-ing these Molonglo observations with the 2.7 GHz ob-servations made with the Eﬀelsberg telescope (Steppe & Gopal-Krishna 1984), or in two cases of positive declina-tions (MC 2), using the Green-Bank 300-ft dish (Murdoch 1976).

– The MIT-Green Bank (MG) survey (Lawrence et al. 1986): these sources are marked with “(mg)” in Table 1. For all these sources, the low-frequency flux densities are taken from the 408 MHz Molonglo Reference Catalogue (MRC). At high frequency, the flux densities are taken from the 4.8 GHz measurements reported in the MG survey using the Green-Bank 300-ft telescope. For one source, 1523−017, the spectral index is−1.04, which is slightly flatter than the nominal limit of our sample,α = −1.05.

– Finally, a small number of the sources, marked with “(gb)”, were picked by comparing the Molonglo Reference Catalogue at 408 MHz with A 1400 MHz Sky Atlas dis-tributed by NRAO (USA; J.J. Condon & J.J. Broderick). On the high frequency side, we have used the 4.8 GHz mea-surements made with the Green-Bank 300-ft dish (Becker et al. 1991, or Gregory & Condon 1991). For three of the sources, which are not covered in these 4.8 GHz surveys, we have used the 1.4 GHz flux values either from the NVSS (Condon et al. 1998) or the Green-Bank Survey (White & Becker 1992).

It may be noted that since the sizes of practically all sources in our sample are well within one arcmin, any underestimation of their flux densities should be negligible, given that the measure-ments are based either on lunar occultation records, or made using pencil beams of size∼5 arcmin, to within a factor of two (see the comments in Sect. 3 for 1005−046 which is the only source in our sample whose size is larger than one arcmin).

For all sources in our sample, except those few for which VLA maps at 4.8 GHz (A-array) were available in Bennett et al. (1986), we took five to ten minutes snapshots using the VLA at 4.8 GHz. The majority of these observations were made in the BnC hybrid configuration while the DnC array was used in the remaining cases. The data restoration was done using the AIPS package (details will be given in Kulkarni et al. 2005, in prep.). The derived radio images are shown as overlays in Fig. 1 while the main structural parameters are given in Table 1.

2.2. Optical imaging

The optical observations were taken during several observing runs between 1989 and 1996 using telescopes at La Silla. The bulk of the data was obtained in the period 1989–1991 us-ing EFOSC 1 at the La Silla 3.6 m telescope. Standard Bessel

BVRI filters were used at all observing runs, and both

(4)

Gopal-Krishna et al.: A new sample of powerful ultra-steep spectrum radio sources 459

Fig. 1. Radio-optical overlays. The insets show the optical counterparts without radio contour. The radio contours are based on VLA snapshots

taken at 4.8 GHz.

fields is only around R∼ 23. The optical and radio images are shown in Fig. 1 when not already published elsewhere.

2.3. Astrometry

We began by determining positions for three to five secondary reference stars near the radio positions using stars from the SAO catalogue. To do this, we prepared contact glass plate copies of the fields from the Red POSS prints. The positions of the primary and secondary reference stars on these contacts were measured using a Zeiss X-Y measuring machine. This al-lowed us to determine the positions of the secondary reference stars to a typical accuracy of 1or better using a least-squares solution of the transformation equations. Then, for each pair of secondary reference stars visible on the CCD frames, we determined the scale and orientation of the image and the posi-tion of the radio source. The final posiposi-tion of the radio source was determined by averaging the positions estimated using all the available pairs of secondary reference stars in each image. The scatter in the derived positions was typically between one and 2; hence, the expected astrometric accuracy is∼1 rms. For about 40% of the sample, however, only two reference stars were present on the CCD frames. For these objects, we estimate the positional accuracy to be within one and 2rms based on our experience for the rest of the sample. If the two stars are lo-cated on opposite sides of the radio position and neither is satu-rated, the astrometric accuracy is∼1.5 rms (class “b” in the last column of Table 1). Otherwise, the astrometry has∼2rms er-ror (class “c”). The remaining∼60% of the sample has at least three reference stars and the astrometric accuracy is∼1 rms (class “a”).

We emphasize that, by itself, the astrometric error class can be treated as the principal reliability indicator of optical iden-tification only provided the radio source is compact (smaller than∼5), or it contains a compact central radio component. For extended radio sources larger than∼10and lacking a cen-tral component, oﬀsets of up to ∼25% of the size of the radio

source, between the optical identification and the radio cen-troid, can be accepted.

2.4. Photometry

Direct imaging observations were not always obtained under photometric conditions, although, due to the faintness of the sources, rather good transparency was always required. Not all observations, therefore, were photometrically calibrated. On photometric nights, calibrations were done using several stars from the Landolt (1992) CCD fields. Given the excellent pho-tometric stability of the EFOSC instruments, we were able to determine the magnitudes of the objects observed under non-photometric conditions using the standard zero points given in the User’s Manuals. Due to the unknown atmospheric ex-tinction, however, these magnitudes carry rather large observa-tional errors (in some cases even up to 0.5 mag).

To determine the magnitudes of the optical counterparts of the radio sources, we followed two procedures. For most ob-jects, we carried out circular aperture photometry with ade-quate aperture size (using the MIDAS software) whereas for objects located in crowded/confused regions we additionally employed the SExtractor algorithm (Bertin & Arnouts 1996) to deblend the diﬀerent close-by objects. Each of these pro-cedures gives a magnitude estimate with an associated error. These values are reflected in the estimates given in Table 1. It should be stressed that additional uncertainties can be expected due to systematic eﬀects, mainly non-photometric conditions (see above). For blank fields, a 3σ lower limit to the magnitude was determined by circular aperture photometry taking the ra-dius to be equal to the mean FWHM of several stars on the same CCD frame.

2.5. Redshifts

(5)

images to place the slit on the objects. Otherwise, we per-formed the source identifications oﬀ-line, and carried out spec-troscopy subsequently on any available nights. In spite of con-siderable eﬀorts, however, the number of sources for which we were able to obtain redshifts remains rather small and for several sources the spectroscopy did not yield redshift (these sources are marked with an asterisk in the last column of Table 1). Plausibly, this is due to the fact that, due to the high read-out noise and low blue sensitivity of the CCDs of those days, our ability to detect Lyα emission in the range 1.8 < z < 2.3 was rather limited, while powerful radio sources tend to cluster at redshifts between one and two (see, e.g., Condon 2003).

3. Comments on individual systems

3.1. 0001

+

058

The optical identification is a fuzzy object close to the detection limit situated between the two radio lobes. An object of R = 22.7 ± 0.3 is located about 4 to the SW of the western lobe. Another close-by, much fainter object (R= 23.2 ± 0.4) is seen about 5North of the eastern lobe.

3.2. 0018

+

052

It cannot be entirely excluded that the optical identification of this radio source is not located on a bad CCD column. For this reason, the source remains undetected down to R= 23.

3.3. 0030

+

061

This is a clear empty field since no optical object is visible within a radius of 6from the radio source.

3.4. 0048

+

072

The optical field without radio contours is shown in the inset of the overlay in Fig. 1. A faint object with R= 21.9 ± 0.1 seen at the centre of the inset, which coincides with the mid-point of the two radio lobes, is a likely identification. Another candidate is the brighter object with R= 20.8 ± 0.1 situated ∼4NW of the radio centre.

3.5. 0127

−

195

This radio source is located in a clear empty field.

3.6. 0321

−

042

The R-band overlay image shown in Fig. 1 has been taken with EFOSC 2 at the NTT which has a higher resolution than the

B-band image used for the photometry (see Table 1). The

opti-cal identification, more clearly seen in the inset of the overlay, is a QSO with redshift z= 2.53 based on prominent broad Lyα and C



lines.

3.7. 0348

+

013

The hint of a wide-angle-tail radio morphology signifies the presence of a cluster. Interestingly, the optical counterpart is a QSO with redshift z= 1.12 based on several emission lines visible in our spectra. About 9to the SW of the quasar, a fore-ground elliptical galaxy is seen for which we find a redshift

z = 0.27. The R-band image shown in Fig. 1 has been taken

with EFOSC 2 at the NTT which has a higher resolution than the R-band image used for the photometry.

3.8. 0355

−

037

The R-band overlay image shown in Fig. 1 resulted from a 30 min exposure taken with EFOSC 2 at the NTT which has a higher resolution than the R-band image used for the pho-tometry (see Table 1). The optical ID lies closer to the eastern lobe of the radio source. It has a fuzzy appearance, roughly ex-tended along the radio axis. It has a northward extension of 5, which is also seen on the EFOSC 1 image used for the photom-etry. It could possibly be a chain of fainter galaxies, or even a tidal tail resulting from a merger event.

3.9. 0410

−

198

Our results for this source are published in Giraud et al. (1996a). It is identified with the dominant galaxy of a z = 0.79 cluster. A remarkable optical extended emission-line re-gion (EELR) of low excitation and size, ∼100 kpc, was found associated with the radio galaxy. The EELR bears a close morphological relationship to the radio lobes which ex-hibit Z-shaped symmetry. The EELR appears to consists of three cones associated with the radio galaxy and a neighbour-ing galaxy also located at the same redshift and connected to the former by a long stellar filament.

3.10. 0423

−

199

The optical counterpart is clearly extended along the two ra-dio lobes (see inset in Fig. 1). Our low-dispersion spectra yielded a redshift z= 1.12 based on three (narrow?) emission lines (C



]λ1909, Mg



λ2800, [O



]λ3727).

3.11. 0424

−

197

An almost point-like object lies at the position of this barely resolved radio source.

3.12. 0430

−

197

Only a pointing optical image (3 min exposure) is available for this small diameter radio source which remains unidentified down to R= 22.7. A deeper image is needed.

3.13. 0441

+

049

(6)

3.14. 0449

−

195

The optical counterpart of this marginally resolved radio source is not visible in our 3 min pointing image. A deeper image is needed for this source.

3.15. 0551

−

196

A galaxy of R = 22.3 ± 0.2 which is seen at the cen-tre of the overlay is situated roughly midway between the two widely separated radio “lobes”. This is a possible identifi-cation. However, since the southern lobe is itself resolved into two components, it is possible that the two lobes are in fact independent radio sources. In that event, their optical counter-parts are undetected down to R= 23.7.

3.16. 0634

−

196

This barely resolved radio source is a clear empty field located towards the Galactic anticentre (b= −12.4◦).

3.17. 0852

+

124

Our results for this source are published in Gopal-Krishna et al. (1995). A giant cloud of Lyα emission at z = 2.468 extended over∼100 kpc is associated with the southern radio lobe. The equivalent width of Lyα is exceptionally large (∼1000 Å in the rest-frame) and the line profile indicates expansion at a velocity of∼550 km s−1, probably driven by the radio lobe from within. The Lyα emission shows a sharp cut-oﬀ near the radio galaxy indicative of a dusty disc around the galaxy, oriented roughly perpendicular to the radio axis.

3.18. 0918

−

194

The only optical object detected between the two radio lobes is a galaxy atα = 09h₂₁m₁₅_.7s_,_{δ = −19}◦₃₇₄₃_{(J 2000).}

3.19. 0946

+

077

The optical counterpart of this small diameter (3) radio source is below the detection limit in our image, R> 23.3. There is a bright object about 7West of the radio position.

3.20. 1005

−

046

Since our VLA map shows the size of this source to be 100, its flux density given in the Molonglo Reference Catalogue at 408 MHz (MRC does not give integrated flux) might be signif-icantly underestimated. Hence we have computed the spectral index using the flux densities estimated from the NVSS map (353 mJy at 1.4 GHz) and the Parkes survey (87 mJy at 4.85 GHz; Griﬃth et al. 1995). We further note that our VLA map shows a prominent radio core in this triple source, which contributes∼9 mJy at 4.85 GHz.

The optical identification is a bright, narrow emission-line radio galaxy (NELG) at a redshift z= 0.618. A close inspection of the image shows that the optical counterpart could be a tight

chain of three objects. The southern radio hot spot coincides with a point-like optical object with R= 19.7 ± 0.1.

3.21. 1048

+

002

The optical identification lies closer to the northern radio lobe and is seen more clearly near the centre of the inset. After 4 h of integration, the optical spectrum shows two narrow faint emis-sion lines that we tentatively identify with Mg



λ2800 and [O



]λ3727 at z = 0.71. Note also that a faint optical object is coincident with the outer edge of the southern radio lobe.

3.22. 1059

+

107

The optical ID is a galaxy that coincides with the central radio component and is elongated along the radio axis. A relatively bright star is located 6to the SE of the galaxy.

3.23. 1132

+

112

The optical ID of this radio source is a point-like object with

R= 22.0 ± 0.1.

3.24. 1146

+

052

The best candidate for optical identification is a R= 22.6 ± 0.1 galaxy situated atα = 11h₄₈m₄₇_.9s_,_{δ = +04}◦₅₅₂₅_{(J 2000).} It could be the dominant member of a distant cluster. Our 2 h spectrum of this galaxy shows a strong [O



]λ3727 emission line and a rich Balmer absorption spectrum, reminiscent of other cluster sources (Melnick et al. 1997). Unfortunately, our B 300 spectra cuts oﬀ just where we would expect to see the [O



] emission lines at z = 0.42, so we cannot be certain of the LINER nature of this source.

3.25. 1224

−

085

The identified optical structure consists of a R = 23.5 ± 0.3 point-like object and a faint, 6 long wisp to SW coincident with the southern radio lobe and elongated along the radio axis. The entire structure has R∼ 22.

3.26. 1238

−

074

The radio structure is poorly resolved in our low-resolution VLA map. The only object within 5of the radio peak is a R∼ 23 fuzzy object situated atα = 12h₄₀m₄₈_.0s_,_{δ = −07}◦₄₃₁₈ (J 2000).

3.27. 1245

+

115

(7)

3.28. 1246

−

081

The optical counterpart of this slightly resolved (∼1) radio source is a R= 22.8 ± 0.4 object. A fainter object is also seen 2NE of it.

3.29. 1248

−

108

The central radio component lies within 1.5 of a pair of opti-cal objects which are themselves separated by 2 and have an integrated R = 22.7 ± 0.3. One of these objects is the likely optical ID.

3.30. 1317

−

194

An object of R = 24.4 ± 0.2 is seen 1.5 NE of the central component of this extended radio source. The astrometry has been independently checked using a 10 min exposure taken with EFOSC 1 at the ESO 3.6 m telescope. This image is less deep but includes five reference stars and confirms the astrom-etry as shown in the overlay.

3.31. 1324

−

104

The likely optical ID is close to the north-eastern radio lobe and appears to be extended.

3.32. 1329

−

195

An optical object is seen about 2.5 oﬀset from the radio peak towards NE. Within the astrometric uncertainties for this case, this object is the likely identification. Faint and narrow emis-sion lines of [C



]λ2326 and Mg



λ2800 are visible in our 2 h spectrum of this object indicating that the radio source is prob-ably a NELG at a redshift z= 0.98.

3.33. 1411

−

192

Our results for this source are published in Gopal-Krishna et al. (1992). An EELR of size∼100 kpc and z = 0.477 is associated with this double radio source. Its [O



]λ3727 emission line has a very large rest-frame equivalent width (350 Å), consistent with the high radio luminosity. Intriguingly, we found that its optical spectrum is ultra-soft, with [O



]λ3727/[O



]λ5007 = 10, nearly 30 times the typical value for distant 3CR ra-dio galaxies (van Breugel & McCarthy 1990). Together with Hydra A, this source thus provides an outstanding example of extremely low-ionization optical emission-line spectra being associated with powerful radio galaxies (Melnick et al. 1997). Unfortunately, the object is seen very close to a bright star, so it is diﬃcult to say whether it is a cluster source like Hydra A.

3.34. 1443

−

198

Deep multi-color optical observations of this source have been reported by us (Giraud et al. 1996b). The source was identified with a z= 0.753 elliptical galaxy in the process of formation by accreting material from neighbouring galaxies, all members of

a group. The radio source has a central core and two relatively relaxed lobes consistent with its being in a cluster.

3.35. 1509

−

158

The peak of this unresolved radio source lies just∼15 from a pair of bright stars. No optical identification is visible above a detection limit of R ∼ 24. The radio flux measurement at 2.7 GHz (Eﬀelsberg) contains a significant contribution from a 10double radio source located 2.8 to the NW of 1509−158. Due to this, the true spectral index of this source is probably even steeper than the−1.24 value given in Table 1. The param-eters of the confusing source, estimated from our VLA obser-vations, areα = 15h₁₂m₂₂_.7s_,_{δ = −15}◦₅₈₀₅_{(J 2000), with} a flux density equal to 36 mJy at 5 GHz (Kulkarni et al. 2005, in prep.).

3.36. 1523

−

017

The radio map of this triple source is taken from the VLA 5 GHz observations by Bennett et al. (1986). The redshift of the optical counterpart, z= 0.93, was derived from a 3 h low-dispersion (B 1000) spectrum taken with EFOSC 1. The spec-trum shows prominent, probably narrow, Mg



and [O



] emis-sion lines. The presence of H+K in absorption and the lack of strong [O



] emission lines indicate that this object may be a LINER.

3.37. 1612

−

208

The optical counterpart of this unresolved radio source is quite bright and point-like. The blue spectrum of this object obtained from 2 h integration with EFOSC 1 is typical of an elliptical galaxy at z = 0.31. The lack of emission lines and the com-pactness of the object, however, are rather puzzling.

3.38. 1621

−

196

Although this object has a large radio size, its optical identifi-cation remains uncertain. The nearest object to the radio centre is a R= 21.6 ± 0.2 point-like object, which we suggest as the possible identification. However, it is oﬀset by 4to the South of the faint radio peak seen between the two radio lobes. In ad-dition to the R-band photometry, we also took a 15 min V-band exposure using EFOSC 1 from which we get V = 21.2 ± 0.1 and V− R = −0.4 assuming that the object did not vary over the 11 months time interval between the two observations. If a higher resolution radio map confirms the faint, central peak to be the radio nucleus then its separation from the suggested optical ID would be four times the rms astrometric error. Any other optical ID would have to be below the detection limit of the image (R∼ 25 for a point source).

3.39. 1623

−

194

(8)

3.40. 1631

−

222

The source lies in a crowded field close to the Galactic plane (latitude+16◦). The only detected object within 2 is a R = 25.5 ± 0.4 object located about 2 North of the radio peak. This is the likely optical ID for this unresolved radio source.

3.41. 1632

−

199

This compact steep spectrum radio source lies in a clear empty field.

3.42. 1859

−

187

This extended radio source lies in a crowded field close to the Galactic plane (latitude−10.7◦). The inset shows five bright ob-jects near the mid-point between the two radio lobes. Of these, the western-most object, which is slightly extended, is the most likely optical identification.

3.43. 2011

−

169

The optical counterpart of this compact steep spectrum radio source is undetected down to a very deep level (R= 25.6).

3.44. 2023

−

156

There is a hint of a central radio component. The NS extended optical object is oﬀset from this component by 1.5 to the North, which is within the astrometric error, and is therefore the likely optical counterpart.

3.45. 2057

−

179

The suggested optical ID partially overlaps with the image of a 1.6 mag brighter elliptical galaxy located about 3 to the South. A 2 h spectrum obtained with EFOSC 2 at the ESO/MPI 2.2 m telescope shows a rich emission-line spectrum at z = 0.92. The adjacent elliptical galaxy is at z = 0.6.

3.46. 2105

−

119

The best candidate appears to be the slightly extended object located about 1.3 West of the radio position. A very faint fuzz is coincident with the radio peak.

3.47. 2222

−

057

The spectral index of this radio source has a large uncertainty of±0.2 (see Sect. 2.1). No object is seen within the radio con-tours above the detection limit of the image (R∼ 23).

3.48. 2232

−

062

A tight clustering of bright stars is seen within 20 West of this radio source. This considerably degrades the quality of de-tection of the faint (R ∼ 23.5) optical counterpart observed between the two radio lobes.

3.49. 2236

−

039

This compact steep-spectrum radio source coincides with a barely detected fuzz with R∼ 23 situated in a crowded field.

3.50. 2236

−

047

The results of our detailed optical observations of this source have been reported by Melnick et al. (1993). The distorted dou-ble radio source is identified with a z= 0.552 cD galaxy which is member of a cluster (Kulkarni et al. 2005, in prep.). Between this galaxy and another similarly bright galaxy to the NE, which is a member of the same cluster, an unusually bright and straight arc-like feature was found by Melnick et al. (1993). We interpreted it as the image of a pair of merging galaxies at

z= 1.116, highly magnified due to gravitational lensing by the

foreground cluster (see also Kneib et al. 1994).

3.51. 2245

−

037

On the assumption that the two radio components of this source are physically associated, the most likely optical identification is the bright (R = 20.8 ± 0.1) object roughly located midway between them. On the other hand, it is quite possible that the two radio components are independent radio sources (particu-larly since the western component is itself a 6double). In that case, the optical features detected towards each of them would be their likely optical IDs. The magnitudes of these objects are

R= 22.7 ± 0.2 for the western lobe and R = 20.8 ± 0.1 for the

source close the eastern lobe.

3.52. 2347

+

015

More sensitive radio imaging is needed to confirm if this source is a wide-angle tail. The likely optical identification is coinci-dent with the radio peak.

4. Conclusions

We have presented a catalogue of 52 powerful radio sources with very steep spectra at decimetre wavelengths (medianα =

−1.22). For ∼15% of the sources, the observing conditions

were poor or the optical fields are confused, so even if the opti-cal counterparts may not be very faint, they could not be identi-fied with the available material. Out of the 41 (i.e.,∼80%) iden-tified sources, in spite of considerable eﬀorts, we were also able to obtain redshifts for only about a third of them. This is most likely due to the fact that the CCDs of those days had rather high read-out noise and poor blue sensitivity. We are confident that using modern detectors on the same telescopes we should be able to do a lot better.

(9)

Finally, we note that, even though optical spectroscopy has been completed for only about a quarter of the sam-ple (14 sources), already this small subset is found to con-tain two powerful ultra-steep spectrum radio sources having LINER-type ultra-soft emission-line spectra (0410−198 and 1411−192 at, respectively, z = 0.79 and 0.48) plus at least one good candidate (1523−017 at z = 0.93). Another three can-didates, namely, 0423−199 (z = 1.12), 1146+052 (z = 0.42) and 2057−179 (z = 0.92), show strong [O



] emission but since their existing spectra do not extend to the region of the [O



] line, spectral softness based on the strengths of these two emission lines remains to be confirmed. Our observations indicate that the former two sources are associated with dis-tant (z >_{∼ 0.5) galaxy clusters having a dense intra-cluster} medium, as is the case for the nearby massive cooling flow cluster Hydra A (Melnick et al. 1997; also, McNamara 1995). Thus, together with an ultra-steep radio spectrum and relaxed radio morphology, the presence of a LINER spectrum in the optical can be used as a powerful indicator of high-z clusters which are not merely concentrations of galaxies, but have ac-quired an intra-cluster medium dense enough to sustain cooling flow activity.

Acknowledgements. G.K. thanks ESO for the hospitality in Chile dur-ing a visit when this project was started. JM thanks NCRA, Pune, for their hospitality when this project was finished. We also thank Samir Dhurde and Alok Gupta for their invaluable help with data handling. This work made use of the MIDAS and AIPS data reduction and analysis packages as well as the NASA/IPAC extragalactic database (NED). VLA is operated by Associated Universities, Inc., under con-tract with the National Science Foundation.

References

Becker, R. H., White, R. L., & Edwards, A. L. 1991, ApJS, 75, 1 Bennett, C. L., Lawrence, C. R., Burke, B. F., Hewitt, J. N., &

Mahoney, J. 1986, ApJS, 61, 1

Bertin, E., & Arnouts, S. 1996, A&AS, 117, 393 Blumenthal, G., & Miley, G. 1979, A&A, 80, 13

Brunetti, G., Mack, K.-H., Prieto, M. A., & Varano, S. 2003, New A Rev., 47, 501

Chambers, K. C., Miley, G. K., & van Breugel, W. 1987, Nature, 329, 604

Condon, J. J. 2003, in Radio Astronomy at the Fringe, ed. J. A. Zensus, M. H. Cohen, & E. Ros, San Francisco, CA, ASP Conf. Proc., 300, 243

Condon, J. J., Cotton, W. D., Greisen, E. W., et al. 1998, AJ, 115, 1693 Davies, I. M., Little, A. G., & Mills, B. Y. 1973, Aust. J. Phys.

Astrophys. Suppl., 28, 1

De Breuck, C., van Breugel, W., Stanford, S. A., et al. 2002, AJ, 123, 637

Djorgovski, S. G., Castro, S., Stern, D., & Mahabal, A. A. 2001, ApJ, 560, L5

Douglas, J. N., Bash, F. N., Bozyan, F. A., Torrence, G. W., & Wolfe, C. 1996, AJ, 111, 1945

Giraud, E., Melnick, J., Gopal-Krishna, Mendes de Oliveira, C., & Kulkarni, V. K. 1996a, A&A, 309, 733

Giraud, E., Melnick, J., Gopal-Krishna, & van Drom, E. 1996b, A&A, 311, 446

Gopal-Krishna, Giraud, E., Melnick, J., & della Valle, M. 1995, A&A, 303, 705

Gopal-Krishna, Giraud, E., Melnick, J., & Steppe, H. 1992, A&A, 254, 42

Gopal-Krishna, & Steppe, H. 1981, A&A, 101, 315

Gopal-Krishna, Steppe, H., & Witzel, A. 1980, A&A, 89, 169 Gopal-Krishna, Subramanian, P., Wiita, P. J., & Becker, P. A. 2001,

A&A, 377, 827

Gregory, P. C., & Condon, J. J. 1991, ApJS, 75, 1011

Griﬃth, M. R., Wright, A. E., Burke, B. F., & Ekers, R. D. 1995, ApJS, 97, 347

Kneib, J. P., Melnick, J., & Gopal-Krishna 1994, A&A, 290, L25 Kühr, H., Witzel, A., Pauliny-Toth, I. I. K., & Nauber, U. 1981,

A&AS, 45, 367

Laing, R. A., & Peacock, J. A. 1980, MNRAS, 190, 903 Landolt, A. U. 1992, AJ, 104, 340

Large, M. I., Mills, B. Y., Little, A. G., Crawford, D. F., & Sutton, J. M. 1981, MNRAS, 194, 693

Lawrence, C. R., Bennett, C. L., Hewitt, J. N., et al. 1986, ApJS, 61, 105

Lilly, S. J., & Longair, M. S. 1984, MNRAS, 211, 833 McCarthy, P. J. 1993, ARA&A, 31, 639

McCarthy, P. J., Spinrad, H., Djorgovski, S., et al. 1987, ApJ, 319, L39

McNamara, B. R. 1995, ApJ, 443, 77

Melnick, J., Altieri, B., Gopal-Krishna, & Giraud, E. 1993, A&A, 271, L5

Melnick, J., Gopal-Krishna, & Terlevich, R. 1997, A&A, 318, 337 Murdoch, H. S. 1976, MNRAS, 177, 441

Rawlings, S., & Saunders, R. 1991, Nature, 349, 138 Singal, A. K. 1987, A&AS, 69, 91

Singal, A. K., Gopal-Krishna, & Venugopal, V. R. 1979, Mem. Astron. Soc. India, 1, 14

Spinrad, H. 1986, PASP, 98, 269

Steidel, C. C., Giavalisco, M., Pettini, M., Dickinson, M., & Adelberger, K. L. 1996, ApJ, 462, L17

Steppe, H., & Gopal-Krishna 1984, A&A, 135, 39

Subrahmanya, C. R., & Gopal-Krishna 1979, Mem. Astron. Soc. India, 1, 2

Sutton, J. M., Davies, I. M., Little, A. G., & Murdoch, H. S. 1974, Aust. J. Phys. Astrophys. Suppl., 33, 1

Tielens, A. G. G. M., Miley, G. K., & Willis, A. G. 1979, A&AS, 35, 153

van Breugel, W. J. M., & McCarthy, P. J. 1990, in Evolution of the Universe of Galaxies, San Francisco, CA, ASP Conf. Ser., 10, 359 Venemans, B. P., Röttgering, H. J. A., Overzier, R. A., et al. 2004,

A&A, 424, L17

(10)

Gopal-Krishna et al.: A new sample of powerful ultra-steep spectrum radio sources, Online Material p 1

(11)

Table 1. Overall properties of the sample galaxies.

Radio properties Optical properties

IAU name1 _RA2 _Dec2 _Morphology3 _α _Flux4 _Magnitude _z _Observations5

[J 2000] [J 2000] (Size) [Jy] 0001+058 (oo) 00 04 01.48 +06 07 31.0 D (∼7) –1.16 1.28 R∼ 24 ... I3, c 0018+052 (oo) 00 20 56.29 +05 33 25.4 T (12) –1.38 1.78 R> 23.0 ... I2, c 0030+061 (mg) 00 33 15.28 +06 28 18.0 R (3) –1.20 3.09 R> 23.0 ... I2, b 0048+072 (oo) 00 51 28.03 +07 28 55.4 D (20) –1.12 1.96 R= 21.9 ± 0.1 ... I3, a 0127−195 (ml) 01 30 00.38 −19 17 11.1 SR (∼1) –1.41 0.30 R> 23.0 ... I2, b 0321−042 (gb) 03 24 21.03 −04 05 03.8 SR (∼1) –1.20 0.87 B= 22.4 ± 0.1 2.53 I1, S3, S4, S6, a 0348+013 (gb) 03 50 57.37 +01 31 04.6 D (∼8) –1.20 1.02 R= 18.9 ± 0.1 1.12 I1, S1, S2, S3, a 0355−037 (gb) 03 57 47.91 −03 34 07.9 D (12) –1.27 1.05 R= 23.3 ± 0.3 ... I1, a 0410−198 (ml) 04 12 29.21 −19 42 08.8 D (11) –1.18 2.23 R= 20.9 ± 0.2 0.79 published 0423−199 (ml) 04 25 44.33 −19 50 25.2 D (3) –1.25 0.92 R= 23.1 ± 0.2 1.12 I2, S3, S6, a 0424−197 (ml) 04 26 37.62 −19 37 48.2 SR (∼1) –1.20 0.38 R= 22.0 ± 0.3 ... I2, a,∗ 0430−197 (ml) 04 32 28.30 −19 40 45.2 R (2) –1.20 0.47 R> 22.7 ... I2, a 0441+049 (gb) 04 44 17.94 +05 01 25.6 D (12) –1.10 0.83 R∼ 23 ... I1, b 0449−195 (ml) 04 51 13.15 −19 29 11.3 SR (∼1) –1.22 0.24 R> 23.3 ... I1, a 0551−196 (ml) 05 53 11.06 −19 36 53.4 D? (34) –1.31 0.48 R= 22.3 ± 0.2 ... I2, a,∗ 0634−196 (ml) 06 36 28.68 −19 38 47.2 SR (∼1) –1.24 0.60 R> 24 ... I2, a 0852+124 (oo) 08 55 21.37 +12 17 26.3 D (15) –1.28 1.05 V= 23.3 ± 0.4 2.47 published 0918−194 (ml) 09 21 15.49 −19 37 37.4 D (29) –1.20 0.30 R= 22.7 ± 0.3 ... I2, a 0946+077 (mg) 09 48 55.25 +07 28 09.2 R (5) –1.14 1.99 R> 23.3 ... I2, a 1005−046 (gb) 10 07 49.30 −04 53 42.0 T (100) –1.13 1.08 R= 20.2 ± 0.1 0.62 I4, S1, a 1048+002 (gb) 10 50 40.35 −00 03 53.9 D (7) –1.22 3.46 R= 22.3 ± 0.2 0.71 I2, S1, S4, a 1059+107 (gb) 11 02 17.42 +10 29 07.5 T (6) –1.42 3.50 R= 21.9 ± 0.1 ... I4, b 1132+112 (ml) 11 35 21.10 +10 56 19.3 D (8) –1.26 0.97 R= 22.0 ± 0.1 ... I6, a 1146+052 (mg) 11 48 47.78 +04 55 25.2 D (41) –1.13 2.65 R= 22.6 ± 0.1 0.42 I4, S1, S3, S5, b 1224−085 (oo) 12 27 03.73 −08 48 26.7 D (7) –1.20 1.23 R∼ 22 ... I4, c,∗ 1238−074 (oo) 12 40 47.82 −07 43 13.9 SR (∼2) –1.12 (0.6) R= 23.3 ± 0.3 ... I6, a 1245+115 (ml) 12 48 17.16 +11 17 22.9 SR (∼2) –1.48 1.15 R= 21.3 ± 0.1 ... I6, b 1246−081 (oo) 12 48 51.32 −08 22 27.7 SR (∼1) –1.37 (1.0) R= 22.8 ± 0.4 ... I2, a 1248−108 (oo) 12 50 40.00 −11 05 34.1 T (10) –1.36 (0.8) R= 22.7 ± 0.3 ... I2, a 1317−194 (ml) 13 20 11.83 −19 42 29.0 T (24) –1.22 0.23 R= 24.4 ± 0.2 ... I4, a 1324−104 (oo) 13 26 47.77 −10 40 50.6 D (6) –1.28 (0.55) R= 22.3 ± 0.2 ... I2, b 1329−195 (ml) 13 31 47.13 −19 47 26.3 SR (∼2) –1.28 0.35 R= 22.3 ± 0.2 0.98 I2, S1, b 1411−192 (oo) 14 14 22.97 −19 27 54.8 D (∼12) –1.27 1.33 R∼ 22.6 0.48 published 1443−198 (ml) 14 46 48.31 −20 03 38.0 D/T (7) –1.27 0.95 R∼ 20.9 0.75 published 1509−158 (oo) 15 12 31.02 −16 00 04.1 U (<5) –1.24 1.03 R> 24 ... I2, b Notes:

_{Detailed information about each source is given in Sect. 3.}

1_{The characters in parenthesis after the IAU names codify the radio survey from where the object was selected as follows:}

(oo) Ooty lunar occultation survey at 327 MHz; (ml) Molonglo surveys (MC 1 and MC 2) at 408 MHz; (mg) MIT (365 MHz) – Green-Bank (4.8 GHz) survey; (gb) Green-Bank (1.4 GHz) – Molonglo (408 MHz) survey.

2_{The positions refer to the radio peak for unresolved sources and to the central radio component if detected. For the remaining sources, the}

mid-point between the lobes is adopted (see Fig. 1).

3_{Radio morphology: D (Double), T (Triple), SR (Slightly Resolved), R (Resolved), U (Unresolved).} 4_{The radio fluxes are given at 408 MHz, except the values in parenthesis that correspond to 327 MHz.}

5_{The codes for the optical observations (I, S) are as defined in Tables 2 and 3. Exposure times for imaging ranged between ten and 30 min}

(12)

Gopal-Krishna et al.: A new sample of powerful ultra-steep spectrum radio sources, Online Material p 3 Table 1. continued.

Radio properties Optical properties

IAU name1 _RA2 _Dec2 _Morphology3 _α _Flux4 _Magnitude _z _Observations5

[J 2000] [J 2000] (Size) [Jy] 1523−017 (mg) 15 26 30.99 −01 54 13.8 T (12) –1.04 2.07 R= 21.9 ± 0.2 0.93 I2, S1, S3, b 1612−208 (oo) 16 15 56.00 −20 58 09.3 U (<5) –1.22 (0.35) R= 22.0 ± 0.2 ... I2, a,∗ 1621−196 (oo) 16 24 35.55 −19 47 15.6 T (19) –1.37 (0.55) R= 21.6 ± 0.2 ... I2, a,∗ 1623−194 (oo) 16 26 24.90 −19 35 04.8 D (11) –1.12 0.98 R= 22.5 ± 0.2 ... I2, a,∗ 1631−222 (oo) 16 34 49.82 −22 22 11.5 U (<5) –1.46 4.28 R= 25.5 ± 0.4 ... I2, b 1632−199 (oo) 16 35 45.45 −20 04 18.0 SR (∼3) –1.05 0.96 R> 23.4 ... I2, b 1859−187 (oo) 19 02 05.59 −18 43 31.6 D (26) –1.39 (0.65) R= 22.9 ± 0.2 ... I2, b 2011−169 (oo) 20 14 38.28 −16 48 21.7 SR (∼1) –1.05 (0.60) R> 25.6 ... I2, a 2023−156 (oo) 20 26 42.31 −15 30 04.3 D (9) –1.44 (0.9) R= 23.6 ± 0.3 ... I2, b,∗ 2057−179 (oo) 21 00 15.18 −17 45 50.7 D (10) –1.15 3.04 R= 21.5 ± 0.3 0.92 I5, S7, a 2105−119 (oo) 21 08 18.83 −11 41 56.2 D (∼4) –1.20 0.87 R= 24.3 ± 0.3 ... I2, b 2222−057 (oo) 22 25 03.91 −05 29 56.0 D (8) –1.16 (0.55) R> 23 ... I5, a 2232−062 (oo) 22 35 07.87 −05 58 37.5 D (11) –1.10 (0.8) R∼ 23.5 ... I3, b 2236−039 (oo) 22 39 03.60 −03 38 57.9 R (3) –1.26 0.99 R∼ 23 ... I3, b,∗ 2236−047 (oo) 22 39 32.73 −04 29 32.0 D (15) –1.42 2.94 R∼ 22.3 0.55 published

2245−037 (oo) 22 47 37.16 −03 31 37.7 see text –1.05 (0.35) see text ... I3, a

2347+015 (oo) 23 49 42.00 +01 50 55.2 R (∼4) –1.16 (0.30) R= 22.8 ± 0.4 ... I2, a,∗

Table 2. Optical imaging observations.

Run Telescope Instrument Time span CCD Pixel size No. of pixels

[yrs] []

I1 NTT 3.5 m EFOSC 2 1989 #05 0.2578 512× 320 I2 ESO 3.6 m EFOSC 1 1989–1991 #08 0.3375 1024× 640 I3 ESO 3.6 m EFOSC 1 1991–1993 #26 0.6094 512× 512

I4 ESO/MPI 2.2 m EFOSC 2 1991 #05 0.3500 512× 320

I5 ESO/MPI 2.2 m EFOSC 2 1991 #19 0.3340 1024× 1024

I6 Danish 1.5 m DFOSC 1996 Loral 0.3800 2052× 2052

Table 3. Optical spectroscopy observations.

Run Telescope Instrument CCD Grism Pixel size Wavelength range

(nm) (nm) S1 ESO 3.6 m EFOSC 1 #08 B 300 0.48 350–700 S2 ESO 3.6 m EFOSC 1 #08 R 300 0.52 500–900 S3 ESO 3.6 m EFOSC 1 #08 B 1000 1.3 350–1050 S4 ESO 3.6 m EFOSC 1 #26 B 300 0.96 350–700 S5 ESO 3.6 m EFOSC 1 #26 R 300 1.04 500–900 S6 NTT 3.5 m EMMI #18 #2 0.44 400–700

(13)

Fig. 1. Radio-optical overlays. The insets show the optical counterparts without radio contour. The radio contours are based on VLA snapshots

(14)

(15)

(16)

(17)

(18)

(19)

(20)

(21)
