Neutron scattering measurements of interdiffusion in amorphous Si/Ge multilayers

HAL Id: jpa-00210370

https://hal.archives-ouvertes.fr/jpa-00210370

Submitted on 1 Jan 1986

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are pub- lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

Neutron scattering measurements of interdiffusion in amorphous Si/Ge multilayers

Chr. Janot, A. Bruson, G. Marchal

To cite this version:

Chr. Janot, A. Bruson, G. Marchal. Neutron scattering measurements of interdiffu- sion in amorphous Si/Ge multilayers. Journal de Physique, 1986, 47 (10), pp.1751-1756.

�10.1051/jphys:0198600470100175100�. �jpa-00210370�

Neutron scattering measurements of interdiffusion in amorphous ^Si/Ge multilayers

Chr. Janot (+ ), ^{A. Bruson} (+ + ) ^{and G.} Marchal (+ + ) (+ ) ^Institut Laue-Langevin, ¹⁵⁶ X, 38042 Grenoble Cedex, ^France (+ + ) Physique ^du Solide, ^BP 239, 54506 Vand0153uvre Cedex, ^France (Requ ^{le 3} avril 1986, accept6 ^{le 13} juin 1986)

Résumé.

Des structures multicouches ont été obtenues en évaporant successivement des films de silicium et de germanium amorphes, ^{avec des} périodes allant de 80 à 100 Å. Le coefficient d’interdiffusion

D de Si/Ge a été déterminé en mesurant, ^en fonction des températures ^{et des} temps ^de recuit, l’intensité des réflexions satellites d’un faisceau de neutrons, liées ^à la modulation périodique ^du contraste. Dans l’intervalle T

620 - 720 K, D ^{varie comme} 6,34 ^x 10-3 _exp (- ^2,35 eV/kT) ^{cm2 s-1.}

Abstract.

Multilayered amorphous Si/amorphous Ge films with a periodicity ^{of 80 to 100 Å have been}

obtained using ^UHV evaporation techniques. The interdiffusion coefficient D of this system ^{was determined} by measuring ^the intensity ^{of the neutron} (000) ^forward scattering satellites arising ^{from the} modulation, ^{as a} function of annealing temperature ^{and time. The} temperature dependence ^{of D in the} range 620-710 ^{K is} described by D

^{6.34 x 10-3} exp (- ^2.35 eV/kT ) ^{cm2 s-1.}

Classification

Physics ^Abstracts

66.30

61.40

64.75

81.15

1. Introduction.

Atomic diffusion in amorphous semiconductors has

only been studied very recently. This includes impu- rity ^diffusion [1] and the diffusion of the covalent random network formers themselves [2, 3]. ^{In the}

latter case the main problem ^{to be overcome arises}

from unfavourable competition ^between diffusivity

and the thermal stability ^{of the} amorphous phase.

The most sensitive technique available for measu-

ring diffusivities makes use of multilayered ^films.

This technique, originally developed ^for crystalline

materials [4-6] has also been applied successfully ^to

measure diffusivities in amorphous alloys [7-11]. ^The multilayered samples ^{are made} by depositing ^thin

films of two materials in an alternating ^{sequence on}

a glass substrate. This makes ^a multilayer periodic ⁱⁿ

a direction perpendicular ^{to the} plane ^{of the} films,

with a d-spacing equal ^to the thickness of one

bilayer. ^{Neutrons or} X-rays ^of wavelength A ^incident

on a multilayer ^{are reflected at} angles 0 given by ^the Bragg relation 2 d sin 0

nA where n is the order of reflection. Annealing ^the multilayers ^{at different} temperatures for different times results in the layers flowing into each other thus relieving ^{contrast effects}

and producing ^a decay of the reflection intensity.

The decay ^{of the} intensity I is related to the interdiffusion coefficient 15 by [5] :

Reported data have been mainly ^obtained through X-ray approaches ^{so far,} which limits the repeat length ^{of the} multilayered ^{films to a few nm in order}

to have acceptable 0 reflection angles ^{with the}

available X-ray wavelength ^as obtained from anode tubes. This technique has been used to measure

diffusivities in the Si/Ge amorphous system [2] ⁱⁿ

which the interdiffusion was found to be relatively rapid, ⁱⁿ complete disagreement with Raman ^measu- rements on hydrogenated multilayered ^films [12]. ^In

the Raman alternative the diffusion mixing ^{of the} layers is determined by the relative contributions to the spectra ^{of the} remaining pure amorphous ^{Si and}

Ge and of the diffusion induced Si-Ge mixture. In

special ^{cases, the diffusion} mixing ^{can also be}

measured via Mossbauer spectroscopy [13].

However, ^{as shown} by ^{Cook et al.} [5], ^when measuring interdiffusion coefficients in multilayers,

one has also to cope with the dependence ^of diffusivity ^{on the} repeat length ^{of the} composition

modulation. To avoid, ^{or at least} minimize, spurious

effects due to very sharp composition gradients ^{it is}

advisable to measure b with relatively ^thick layers ;

cold neutrons with longer wavelenghts ^{than the}

usual X-ray radiations have to be thought ^{of as an} interesting alternative to obtain the diffusion decay

of the reflection intensity.

The neutron technique ^{has been} previously ^used [3] ^with amorphous ^Si-Ge multilayers having ^{a d-} spacing ^of 200 A. In the investigated temperature

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphys:0198600470100175100

1752

range (400-600 K) ^the diffusivity happened ^{to be too}

slow to be observed. However, ^{evidence was obtai-} ned for a structural relaxation mechanism probably

related to a redistribution of compressed ^{and expan-}

ded small volumes resulting ^{in an} overall densitica- tion of the near interface regions of the materials.

In the present study, the sensitiveness to diffusion of the intensity decay ^I ( t ) has been increased with respect ^{to our} preliminary study by reducing ^{d to}

about 80 A. The annealing temperature range has also been moved to higher ^values (620-710 K) ^at

which measurable V coefficients ^were anticipated.

2. Sample preparation, experiments ^{and results.}

The amorphous ^Si-Ge multilayers ^{were made} by depositing ^thin films of pure Si and pure Ge ^on flat

glass substrate, kept ^{at the} liquid nitrogen tempera- ture, by ^{the vacuum} deposition technique. ^Germa-

nium and silicon were placed ⁱⁿ graphite ^{boats and}

were evaporated in succession by electron beam guns. The pressure during ^the evaporation ^process

was about 2 x 10-8 torr. The thickness of the films

was measured and monitored with two independent quartz oscillators (The frequency ^{of the} crystals changes linearly ^{with the mass} deposited ^{on the}

,

transducer). The oscillators actuated also a shutter

through ^an automatic control unit, thereby closing

and opening it between crucibles and substrates at

preset values. The quartz crystals ^were calibrated,

with respect ^{to film} thickness, using ^a Tolansky multiple ^beam interferometer. A good reproducibi- lity ^{in the} layer ^{thickness was} achieved within a few percent by keeping ^the evaporation ^rate fairly low, ^a typical ^value being 1 Á s- 1. ^{At low} evaporation

rates the films can be contaminated with some

oxygen and carbon. The composition of different sections of a multilayer ^were determined by Auger spectroscopy and the contamination _was, in general,

found to be less than 1 %. A slight distribution of thicknesses of the bilayers is thus unavoidable but limited to about 2 to 3 A for an average thickness of 100 A. These distribution in anyway ^out of the detection limits of most of the microanalytical

methods currently ^{used for thin films and/or} depth profile analysis [14] : Rutherford Backscattering Spectrometry gives information over 30 to 104 A, Secondary ^{Ion Mass} Spectrometry is reliable down to 5 A, ^{etc... In} fact, ^{there is not too} much inconve- nience in that since the chemical state of the ^as

prepared samples is well defined (pure layers ^{of Si}

and Ge in succession) ^{and the} initial diffraction

properties ^{of the} multilayer ^{are taken as a reference}

state for any changes ^induced by ^thermal treatments.

Each sample consists of 50 identical bilayers, ^each bilayer being ^{made of one Ge and one Si} amorphous

film of different thickness, ^{in order to} open the

possibility ^of measuring the second order along ^with

the first order satellites about the (000) ^neutron

scattered beam. It is indeed worth remembering ^that

for perfect multilayered material with equal

thickness of the Ge and Si films all ^even orders of reflection would be absent, ^as indeed observed in

our previous ^work [3] and which may be ^a further

test for the reliability ^{of the} deposition parameters.

Neutron scattering from these samples ^was perfor-

med using ^{the small} angle ^neutron scattering ^diffrac-

tometer D17 at the Institut Laue-Langevin (Greno- ble), ^{with a cold neutron beam} monochromatized at a wavelength ^{of 10} A. The scattered neutrons are

collected on a large ^two dimensional multidetector

(64 ^{x 64} cm) , ^{with an} angular resolution of 1/10 deg., which allows 0-2 0 measurements to be carried

out by simply rotating ^the sample ^with respect ^{to the} incident beam. A typical ^{« 0-2 0 scan » is shown in} figure 1 for the first order reflection on a sample

which was supposed ^to be made of 60 A Si/20 ^{A Ge} bilayers. The total accumulation time corresponding

to the picture is of the order of one hour. The display gives ^a view of the 2D-multidetector with the third dimension used for intensity ^{in each} counting ^cell.

Remnants of the direct beam can be seen on the

right-hand ^{side of the} picture.

The main experimental parameters ^{which are} obtained here are :

-

a signal ^to background ^{ratio of 1W at the}

maximum of the reflection ;

-

a measured reflectivity in the first order satel- lite equal ^{to about 6} % ;

-

the angular position of the maximum reflection

which, ^{in the} present example ^of figure ^{1, has been}

found at 2 0 ⁼ 6.04 ° ( 6 ⁼ 3.02 ° ) corresponding ^to

a d-spacing ^{of 94.7} A ;

Fig. ^1.

Typical ^{( 0 - 2 8 » neutron scan of the first}

order reflection on a Si/Ge amorphous multilayer sample.

a) ^3D representation of intensities measured on the 2D multidetector of D17 (ILL). b) Regrouped ^{data and}

Gaussian fit used to calculate the integrated intensity.

- the measured full width at half maximum for the first order satellite is A( 2 0 ) ^{= 0. 17}

^which

could correspond ^to d-spacing ^{spread over}

5 A (~ 5 %) between 92 and 97 A.

The second order satellite is less easily ^measured

but still visible as examplified ⁱⁿ figure ^{2 which}

shows the result of _{a 0 scan,} including ^{a small} part ^of

the large angle side of the first order reflection. The

noisy background ^now amounts to about 1/50 ^{of the}

reflection signal. The measured reflectivity ^{in this}

second order satellite is only ^{0.03 %} (the intensity

scale of the Figs. 1 ^{and 2 are in a ratio of} 200).

Fig. ^2.

Typical ^{« 0 - 2} 0 >> neutron scan of the second order reflection. Same representation ^{as in} figure ^{la but}

with an intensity ^scale expanded by ^a factor of 200 and a

different position of the detector (distance ^to sample ^and angular position).

As the geometrical reproducibility ^{of the measure-}

ment lay-out happened ^to be very critical, ^the decay

of the integrated intensity of the first order satellite

as a function of annealing time for different tempera-

tures was measured in situ by keeping ^the sample ⁱⁿ

a furnace ^on the diffractometer during ^{the whole}

time of the experiment. ^{Once the} temperature ^had been set at the desired value by ^a controller system, spectra accumulated over 5 min were then recorded every hour ^{or so at a} fixed 0 position corresponding

to the maximum reflectivity ^{and with a resolution} AA/A ^{limited to} 10 %. The weak point ^{of these}

neutron in situ measurements is that in line characte- rization during ^thermal treatments are made impossi-

ble.

As already explained [3], ^the decay ^{law is} expected

to follow the equation

Figure 3 shows the time dependence ^{of the « diffu-}

sion mixing» 15t = - dB 1 n [I ( t ) / I (0)] for _81T

two different samples ^{annealed at 410 °C and 400 °C} respectively. Very partial ^data corresponding ^{to a}

second order peak ^are also shown. Then the sample

first annealed at 410 ’C-was successively ^submitted

Fig. ^3.

Example ^{of time} dependence of the diffusion

mixing during ^{the first} annealing ^of multilayers.

to diffusion treatments at 418 °C, ^{436 °C and} finally

at 447 °C. The corresponding ^{« diffusion} mixing »

curves are shown in figure ^4.

A certain amount of non-linearity, ^most likely

caused by structural relaxation [3, 8] is observed in

figure ^{3 for the} early part (2 ^{to 4} hours) of the first anneal after which the behaviour becomes linear.

Initial non-linearity is absent for the second, third,

etc... anneals of ^a given sample (Fig. 4). Finally ^for annealing times between 10 and 20 hours, ^the

diffusion mixing again departs drastically from linea-

rity ^and saturates to values of the order of 20 - 30 x 10- 16 CM2 corresponding ^to diffusion pene- tration of about 10 A (given by

(Z2) ^{= 2 Dtmax [3]). It is finally worth mentioning}

that the multilayer d-spacing significantly ^{shrinks as}

diffusion mixing proceeds. ^For example, sample ³

Fig. ^4.

^Time dependence of the diffusion mixing ^{for the}

same sample ^annealed successively ^at increasing tempera-

tures.

1754

had an initial real d of 90.1 A which successively

reduces to 88.6 A, ^86.8 A, ^{85.2 A and 80.4 A after}

diffusion mixing ^at 410, 418, 436 ^{and 447 °C} respecti- vely. ^It is difficult to say if these shrinking ^effects

occur progressively during ^{the whole} annealing ^treat-

ment at a given temperature. As the total thickness reductions observed are of the order of ^a few A only, partial ^{reduction between two annealed states would}

be anyhow beyond the detection limit of the ^measu- rement. As explained later, samples ^{annealed at}

447 °C are partially crystallized and thus it is ^reasona- ble to think that crystallization contributes to the

shrinking ^{effects observed at this} temperature. ^Simi-

lar partial crystallization contributions cannot be

completely ^{ruled out} for thermal treatments at lower

temperatures ^{even if} they ^{have not been observed at}

such temperatures ⁱⁿ preparatory ^{studies to the} present ^neutron experiment, using resistivity ^measu-

rements, high angle X-ray diffraction and electron

microscopy. ^{The weak} point ^is obviously ^that checking the absence of crystallization ^{at a} given

temperature ^on samples ^{suitable for} X-rays, ^electron microscopy ^or resistivity measurements in not an

unquestionable proof ^{for no} crystallization ^{in sam-} ples made suitable for neutron scattering experi-

ments (different thicknesses, geometries ^{and subs-} trate). ^{But the} problem ^{cannot be} easily bypassed.

The interdiffusivities b were determined for each temperature ^{from the} slopes ^{of the} intermediate linear parts ^{of the} plots ⁱⁿ figures 3 and 4. The results are listed in table I and illustrated by ^an

Arrhenius plot ^on figure ⁵ (continuous line).

At 447 °C, ^{the diffusion} mixing ^is stopped very

quickly ^after only ^a very brief annealing time and the maximum atomic displacements remain short range.

Thus the diffusion coefficient given in table I for this temperature although quite consistent with the other

data, ^should only be considered as a reasonable

estimate, determined from a very reduced data ^set

(see Fig. 4).

The reported ^value of 1) at 350 °C might ^{be also} questioned ^{since it was not} measured in situ. Indeed diffusion is very ^{slow at this} temperature ^and signifi-

cant decay ^{of the} reflection intensity requires very

long annealing times which are not compatible ^with

allocated time on a neutron beam !. Again ^the 1) value obtained is consistent with the whole data

set and also agrees very well with ^our previous X-ray

determination [3].

3. Discussion and conclusion.

3.1 INITIAL REFLECTIVITY OF THE MULTILAYERS.

- According ^to the kinematical theory, ^{the neutron} reflectivity ^{of a} multilayer for odd order is given by [15]

where N is the total number of bilayers (here

N

50) ^and f l, f2 ^{are neutron} scattering amplitude

densities for the two materials (fsi ^{= 3.64 x}

1010 cm- 2 and f Ge

^{2.14 x 1010 cm- 2 in their crys-}

talline states).

The above expression ^{is valid} only for low reflecti-

vity. ^For higher reflectivities one has to take dynami-

cal effects into account to obtain

which reduces to the first equation in the limit when the argument of tanh is small. When applied ^{to the} multilayers ^{of the} present study ^{the two} equations give 7? ⁼ 0.13 in the firs order reflection. Sinusoidal rather than square modulation results in different reflectivities given by

which would produce Rsin = 0.08 in the first order for the samples ^{of the} present ^work.

As already said measured data are in the range of

ReXP = 0.06 for the first order and the second order

reflectivity (3 ^x 10- 4 ) is about 10 times smaller than the 0.06/16 ^value expected ^from 7? ^equati6nb.

Thus, despite of the fact that the d-spacing appears to be constant (within ^{about 5} %) through ^{the whole} sample, ^the layer profiles ^{have an obvious} tendency

to be sinusoidal rather than abruptly square. Irregu-

larities or « roughness ^» in the surface of the layers

may also be suspected since the first order reflectivity

is ^even below the lower theoretical estimation by

about 2 % (6 ^{% vs. 8 % for} sinusoidal modulation)!

Table I.

Diffusion coefficients ^obtained from least-square fits ^on data shown on figures ^{3 and 4} (X2 given ^{in the}

table). The last column gives the nominal thickness of ^the Si/Ge films respectively (in A).

Finally ^{it seems} possible ^to make almost perfect

mirrors orland monochromators with amorphous

Si/Ge multilayers since, ^after all, the first order

reflectivity ^would have reached unity ^{with 200} bilayers instead of 50. Furthermore, these multi-

layers ^are very stable even at temperatures ^{of the} order of 200 °C at which the intensity decay ^{in first}

order would be only ^{about 1 % for} annealing ^{time as} long ^{as 1013 seconds} (one million years !) according

to the diffusion law discussed below.

3.2 DIFFUSION PLATEAU.

As clearly ^{shown in} figures ^{3 and 4, diffusion} stops ^{after a certain} annealing ^{time at} any temperature. For diffusion

mixing ^at 350, 400, ^{410 and 418° C the} plateau corresponds ^to Dt =:::: 20 x 10-16 cm2 and to Dt =z 30 x 10-16 cm2 at 436 °C which can be expres- sed in terms of a mean square diffusion penetration

9 (Z2) ^{1/2 : 11 A [3].} Remembering ^{that, accor-} ding ^{to table} I, ^the corresponding samples ^{are made}

of 20 A Ge films squeezed ^between significantly

thicker Si films, ^{such a 10} A limit for atomic

displacements suggests ^{that a} planar growth ^{of a Ge-}

Si alloy proceeds ^{from each} interface, ^{thus consu-} ming ^{the Ge} layers. ^{The true} composition ^{of the} generated ^Ge-Si alloys depends slightly ^{on the} annealing temperature ^{and can be} estimated, ^from

the contrast loss/reflectivity decay ^{relation, to corres-} pond ^to Geo.9 Sio and Geo.83 Sio.17 after diffusion at

400 °C and 436 °C respectively. Given that the

diffusivity ⁱⁿ crystalline Si is many orders of magni-

tude below that in crystalline Ge, it may be ^{not so}

surprising that diffusion of Si into Ge, ^{even in their} amorphous ^states, results in D going ^{to zero} quite abruptly. Again, ^as already mentioned, partial ^crys-

tallization effect cannot be completely ^{ruled out.}

The existence of linear parts in the diffusive beha- viour (Fig. ^{3 and} 4) gives evidence that 1) remains constant for a certain time and suggests that there is

a concentration threshhold for 1) starting ^to

decrease.

The very low diffusion plateau ^{observed at 447 °C}

is obviously ^{of a different nature and can} easily ^be interpreted ^as resulting ^{from the} crystallization ^of

the Ge films. Amorphous germanium ^{is known to} crystallize between 445 and 450 °C [16, 17] ^while amorphous silicon is stable up ^to about 600 °C [17].

Thus, annealing ^the multilayers ^{at 447 °C transforms}

the samples ^into amorphous Si/crystalline ^{Ge films}

after an ultimate very short diffusion stage (Fig. 4).

As diffusivities of Si or Ge in crystalline Ge would be at least 100 times smaller than the ^one measured in the present ^{work a new} strong stability ^{of the} multilayer interfaces is induced by ^this crystallization stage. Actually, ^the plateaus ^{must be} considered ^as

corresponding ^to diffusivities below the detection limit of the present ^method.

3.3 THE MEASURED DIFFUSION LAW.

The diffu- sion data listed in table I and illustrated by figure ⁵

can be described by ^an Arrhenius law with an

activation energy Ea

2.35 eV and a pre-exponen-

tial factor Do

^{6.34 x} 10- 3 cm2 S- ^I (within X 2 ^{= 0.993 of a} least square fit).

The interdiffusivities measured in the present

work are about 3 orders of magnitude slower than the one deduced from X-ray ^{data obtained} by

Prokes et al. [2] (Fig. 5). There is also a significant disagreement ^with Do ^and Ea ^values proposed by

Persans et al. [12] from Raman spectroscopy ^investi- gations, ^as clearly pictured ⁱⁿ figure ^{5. It is} probably significant that Prokes et al. prepared ^their samples using ^{an ion beam} sputtering system ^{instead of our} electron-gun ^crucible evaporation technique, ^while

the data of Persans et al. refer to hydrogenated multilayered films. In both cases residual _argon and/or hydrogen might ^be responsible for the diffusi-

vity enhancement.

Comparison ^{of the} present data with diffusivities in crystals is also very interesting [18]. Self-diffusion

or germanium diffusion in crystalline ^{silicon corres-} ponds ^-to Do :-- 1()3 CM2 s-1 ¹ and EA ^{= 5 eV which} gives very small diffusivities of the order of

10- 33 CM2 s-1 ¹ when extrapolated ^{down to}

T ⁼ 700 K. Self-diffusion in crystalline Ge is much

faster, ^with Do!= 10 ^{cm2 s-1 1 and} Ea ³ eV, ^and

diffusivities extrapolate ^{down to 0.3 x 10- 20 CM2 s-1 1}

at 700 K i.e. only ^{one or two orders of} magnitude

below the diffusivities measured in the present ^work

(see Fig. 5).

Fig. ^5.

Temperature dependence ^{of the} interdiffusivity 1) measured in the present ^work (-) : Do

^{6.34 x} 10- 3 cm2 s-1 and Ea

2.35 eV. Other Arrhe- nius plots correspond ^{to :}

Self diffusion in crystalline

Ge (-.-) : Do =10 cm2 s-1, Ea = 3 eV.

Interstitial diffusion of oxygen in crystalline ^Ge (...) : Do

^{0.17 cm2} s-1, E.

^{2.54 eV.}

Interdiffusion ^mea- sured in multilayers ^Si/Ge using ^Raman spectroscopy [12]

(- - -) : Do ^{= 106 cm2} s-1, E.

^{3.3 eV.}

Interdiffu- sion measured in Si-Ge amorphous multilayers using ^X-

ray reflection (---) [2] : Do ^{= 1.07 x 10- 6} CM2,

Ea =1.b eV.

1756

A more fruitful comparison apparently ^involves

diffusion of ^« big » interstitials in a bond-centered

configuration [18]. ^{The most famous} example ^is probably oxygen interstitially ^{dissolved in silicon,}

which diffuses according ^{to the law D} (cm 2S- 1) =

0.17 exp ( - ^2.54 eV/kT ) ^{not too} far indeed from the interdiffusion law measured in the present ^work

as evidenced in figure ^{5. The two} diffusion laws have in common a point corresponding ^{to 676 K and have} slightly ^different slopes.

It is probably ^{worth to} point ^out that the activation energy obtained in the present ^work might ^be suspected ^{to be some sort of a lowest limit, on the} ground ^{that the} composition dependance ^{of D is}

strong and that the same sample has been used to

successively ^{measure D at 410, 418 and 436 °C.}

In conclusion, ^{we observed :}

(i) saturation of the diffusion mixing ⁱⁿ plateau stages, (ii) stopping ^{of the diffusion} mixing ^after crystallization of the Ge films and (iii) ^{a diffusion}

law similar to that of big interstitials in crystalline

silicon. It is thus conceivable that the interdiffusion process in amorphous Ge/amorphous ^Si multilayers

is dominated by non-substitutional jumps ^{of Si}

atoms into the Ge films using ^the pre-existing locally expanded volumes which are normal features in the structure of a random continuous network. The diffusion of Si into Ge being non-substitutional has not to be compensated by jumps ^{of Ge atoms into}

the Si films. Thus the Ge layers ^are progressively

consumed by ^the previously ^invoked planar growth

of a Ge-Si alloy ^which proceeds ^from interfaces and

seems to stop when the available free volume has been filled up. It would be very interesting ^{indeed to}

confirm these assumptions through direct observa- tions using cross-sectional transmision electron

microscopy.

Acknowledgments.

We gratefully acknowledge the Institut Laue-Lange-

vin for allocation of beam time (experiment ^number 6-14-90).

References

[1] ^{ELLIMAN, R. G.,} GIBSON, ^J. M., JACOBSON, ^D. C., PORTE, ^{J. M. and} WILLIAMS, ^J. S., Appl. Phys.

Lett. 46 (1985) ^478.

[2] PROKES, S. M. ^and SPAEPEN, F., Appl. Phys. ^Lett.

47 (1985) ^234.

[3] JANOT, Chr., ROTH, M., MARCHAL, G., PIECUH, ^M.

and BRUSON, A., ^J. Non-Cryst. ^{Solids 81} (1986)

41-51.

[4] ^{DUMOND, J. and} YOUTZ, J. P., ^J. Appl. Phys. ¹¹ (1940) ^357.

[5] COOK, ^{H. E. and} HILLIARD, ^J. E., ^J. Appl. Phys. ⁴⁰ (1969) ^2191.

[6] CAHN, ^{J. W. and} HILLIARD, ^J. E., ^J. Chem. Phys. ²⁸ (1958) ^258.

[7] ROSENBLUM, ^M. P., SPAEPEN, F. ^{and TURN-}

BULL, D., Appl. Phys. ^{Lett. 37} (1980) ^184.

[8] GREER, ^A. L., LIN, C. J. and SPAEPEN, F., ^{Proc. 4th} Int. Conf. ^on Rapidly ^{Quenched Metals} (T. Masumoto and K. Suzuki, eds)., Japan ^Insti-

tute of Metals, Sendai (1982) p. 567.

[9] CAMMARATA, ^{R. C. and} GREER, ^A. L., ^{J. Non-} Cryst. Solids 61/62 (1984) ^889.

[10] GREER, ^A. L., ^J. Non-Cryst. ^{Solids 61/62} (1984) ^737.

[11] BRUSON, A., PIECUCH, M. ^and MARCHAL, G., ^J.

Appl. Phys. ⁵⁸ (1985) ^1229.

[12] ^{PERSANS, P. D., RUPPERT, A. F.,} ABELES, B., TIEDJE, T. ^and STASIEWSKI, H., ^J. Physique

Coll. 46 (1985) ^{C8-597 and} private ^communica-

tion.

[13] BRUSON, A., DELCROIX, ^{P. and} PIECUCH, M., ^Proc.

Int. Conf. on Mössbauer Spectroscopy, ^Louvain (1985).

[14] ^{WERNER, H. W. in Thin} films ^and depth profile analysis, ^Ed by ^H. Oechsner, Topics ^{in Current} Physics, Springer Verlag. ^{Vol 37} (1985) p. 5.

[15] SAXENA, ^{A. M. and} SCHOENBORN, ^B. P., ^Acta Cryst.

A 33 (1977) ^805.

[16] CHEN, H. ^{S. and} TURNBULL, D., ^J. Appl. Phys. ⁴⁰ (1969) ^4214.

[17] ^{DONOVAN, E.} P., SPAEPEN, F., TURNBULL, D., POATE, J. M. ^and JACOBSON, D. C., ^J. Appl.

Phys. ⁵⁷ (1985) ^1795.

[18] FRANK, W., GÖSELE, U., MEHRER, H. ^and SEEGER, ^{A. in} Diffusion in Crystalline Solids, (Murch ^{G. E. and} Nowick A. S. eds)., ^Materials

Science Series (Academic Press, ^New York)

1984, p. 63.
