Structure of Ba2 YCu3O6.26 at 20 and 298K by single-crystal neutron diffration

HAL Id: jpa-00210569

https://hal.archives-ouvertes.fr/jpa-00210569

Submitted on 1 Jan 1987

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are pub- lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

Structure of Ba2 YCu3O6.26 at 20 and 298K by single-crystal neutron diffration

A. Renault, G.J. Mcintyre, G. Collin, J.-P. Pouget, R. Comes

To cite this version:

A. Renault, G.J. Mcintyre, G. Collin, J.-P. Pouget, R. Comes. Structure of Ba2 YCu3O6.26 at 20 and 298K by single-crystal neutron diffration. Journal de Physique, 1987, 48 (9), pp.1407-1412.

�10.1051/jphys:019870048090140700�. �jpa-00210569�

Structure of Ba2 YCu3O6.26 at ^{20 and 298K} by single-crystal ^{neutron diffration}

A. Renault*, ^G.J. McIntyre+, ^G. Collin++, ^J.-P. Pouget ^{and R. Comes}

Laboratoire de Physique ^{des Solides} (LA02), ^{Bâtiment 510,} Université de Paris-Sud, ⁹¹⁴⁰⁵ Orsay, ^France +Institut Laue-Langevin, 156X, 38042 Grenoble Cedex, ^France

++UA200, Université René Descartes, ^{4 Avenue de} l’Observatoire, ⁷⁵⁰⁰⁶ Paris, ^France (Reçu ^{le 17 juin 198?’,} accepti ^{le 8} juillet 1987)

Résumé.- La structure cristalline de Ba2YCu3O8-03B4 (6=1,74) ^{a été} déterminée _par diffraction des neutrons sur

monocristal à 20 K et 298 K. Par opposition à ^la phase orthorhombique supraconductrice pour laquelle 6 ~1,1,

ce composé cristallise dans le _groupe d’espace tétragonal P4/m ^{m m} avec 03B1

3,8573(4)Å ^{et c}

11,7913(10)Å.

L’augmentation du nombre de lacunes d’oxygène, ^par rapport ^à Ba2YCu3O8-03B4 (03B4 ~1,1), ^est entièrement située dans le plan médiateur des pairs ^d’atomes de barium les plus proches. ^Aucune différence notable n’a été observée entre les structures à 20 K et 298 K.

Abstract.- The crystal ^{structure of} Ba2YCu3O8-03B4 (03B4=1.74) ^{at 20K and 298K has been} determined by single-crystal

neutron diffraction. In contrast to the superconducting orthorhombic phase for which 6 ~ 1.1, ^this phase crystallizes

in the tetragonal space group P4/MMM ^{wtih 03B1}

3.8573(4)Å ^{and c}

11.7913(10)Å. ^The increase in _oxygen vacancies

compared ^to Ba2YCu3O8-03B4 (6 ~1.1.) ^{is confined} entirely ^to the sites in the plane midway ^between pairs ^{of closest}

barium atoms. No significant differences were observed between the structures at 20K and 298K.

Classification

Physics ^Abstracts

74.70 - 61.12

1. Introduction

The observation by ^{Wu et al.} [11 ^of superconduc- tivity ^{at 93K in a} mixed-phase compound ^{of the Ba-}

Y-Cu-0 system ^has sparked ^frenetic activity ⁱⁿ many laboratories to identify ^and characterize the specific phase responsible ^{for the} high-temperature supercon-

ductivity. ^From studies of the Ba-Y-Cu-0 phase ^di-

agram using powder diffraction and transport ^mea- surements, ^{Rao et al.} [2] ^{and Hinks et al.} [3] ^{have in-} dependently concluded that the superconducting ^ma-

terial is single phase ^with compositionBa2YCu3 . ^The exact oxygen stoichiometry ^determines

the ratio Cu2+ /Cu3+ ^{which in turn seems to govern}

the occurrence of high-temperature superconductiv- ity [4].

It also _appears that the structure is _very sensitive to the _oxygen stoichiometry. ^{Of the numerous diffrac-}

tion structural determinations published ^so far, ^the majority (e.g. Siegrist ^et al., [5] ; Capponi ^et al., [6] ;

Beno et al., [7] ; ^{Beach et al.,} [8]) ^{have reported an}

orthorhombic structure for 6 -1.1. However Hazen et al. [9] ^and LePage ^{et al.} [10] ^{observed tetragonal}

structures for 8 -1.5 and 6 -1.0 respectively. ^{In the} X-ray ^studies [5,9,10] ^the reliability ^{of the} oxygen po- sitions and occupations ^is relatively poor due to the low scattering power of X-rays by oxygen compared

to barium, yttrium ^and copper. The neutron pow- der diffraction studies [6-8,11] ^{overcome this in part,}

but main give unreliable thermal parameters. ^{In view} of the subtle role believed to be played by ^the oxy- gen atoms in the occurrence of superconductivity ⁱⁿ

this system, single-crystal ^neutron diffraction is the

preferred technique. Unfortunately the dimensions of the single crystals grown have until now been _pro-

hibitively ^{small for neutron} diffraction.

We have been able to grow good quality crystals

of a number of compounds ^{in the Ba-Y-Cu-0} system with volumes approaching ^{1 mm’. In this} paper ^we

report the first determination by single crystal ^neu-

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphys:019870048090140700

1408

tron diffraction of the ^structure of the non supercon-

ducting phase ^with oxygen content 6.26 per formula

weight. ^This oxygen content, determined by ^refine-

ment of the neutron diffraction data, is less than the value (6.5) ^{which gives an average Cu charge state of}

2+. Determination of this ^structure should elucidate the role played by ^{the oxygen and oxygen} sites in the

superconducting.

2. Experimental

A powder sample ^{with Y:Ba:Cu} composition ^ra-

tio 1:2:3 was prepared by reaction in air of stoichio- metric proportions ^of Y203, BaC03 ^{and CuO at}

950° C. It was checked that the treated material corre-

sponds ^{to the} Ba2YCu30$_b phase by X-ray ^diffrac-

tion on a Guinier-Laine camera. Small single crystals

were obtained by ^a long annealing ^{of the} powder ^{in air}

at about 900°C, ^then quenched ^{at room} temperature.

It should be noticed that under these conditions the material does not exhibit superconductivity ^{even at}

low temperature (no ^Meissner effect). ^{In the} batch,

an approximately rectangular single crystal ^{with di-}

mensions 1.0x0.3x0.25 mm3 and ^a number of well- defined faces was selected for the neutron diffraction measurements.

The diffraction data were collected on the four- circle multidetector diffractometer D19 on the Hll thermal neutron beam at the Institut Laue-Langevin

[12]. ^The wavelength ^{used was 1.3188A obtained} by

reflection form the (311) ^{planes of a} vertically-focus- sing ^Ge monochromator. Although ^the detector,

which subtends 4° horizontally ^{and 64°} vertically ^at

the sample, permits observation of reflections out of the equatorial plane, the small ratio of unit cell di- mensions to wavelength ^would only permit ^observa-

tion of two reflections simultaneously and under less favourable resolution conditions than in equatorial- plane geometry. ^{The data were} therefore collected in

equatorial-plane geometry. ^All reflections in a quad-

rant of reciprocal space ^to sinO/A

0.68A ^were

scanned at 20K and 298K. For the 20K data collection the crystal ^{was mounted in an Air Products} two-stage Displex cryorefrigerator. The three-dimen-sional ar-

rays of counts observed around each scanned reflec- tion were corrected for background and reduced to

squared ^structure amplitudes using the three-dimen- sional integration method of Wilkinson & Khamis

[13]. Because of the _very small crystal size corrections for sample absorption and extinction were unneces-

sary. At both temperatures ^the integrated intensities

were averaged according ^to the Laue class 4/mmm.

The merging ^{indices are} given in table I.

Optimization ^{of the} accuracy of the structure

factors was essential in this study ^{since the} very small

crystal ^size by ^{normal neutron} diffraction standards meant that for over half the reflections a(F 2) IF 2 ^>

0.1. In the method of Wilkinson and Khamis the limit to the peak extend for strong reflections is found by

reference to the ellipsoidal surface for which cr(7)/7,

where I is the background-corrected ^{sum of the}

counts within the ellipsoid, ^{is a minimum. The} shape

and orientation of the ellipsoid ^are found from the mo-

ment-of-inertia tensor of the stronger peak ^counts.

A shape function of the intensity fraction contained within the ellipsoid ^{as a} function of the ellipsoid ^vol-

ume is also found. For our sample ^{and resolution}

function an enlargement by ^{a factor 4} of the volume which _gave the minimum u(1)/ I ^{was found to contain}

all the peak ^{counts for the} strong peaks. To increase the _accuracy of the structure factors for weak peaks,

their ellipsoid parameters ^and shape ^{functions are de-}

duced by interpolation amongst the values for strong peaks ^{at the same 20. The} peak ^{counts are then}

summed in the statistically optimum volume and a

correction factor to the inegrated intensity ^{is deduced}

from the interpolated shape ^function.

For the weak peaks ^the accuracy of the reduction to structure amplitudes depends very much on an ac-

curate knowledge ^{of the} crystal orientation, ^{since the} integration ellipsoid is centred on the calculated in- strumental reflection coordinates, ^{and on an} accurate ,

knowledge ^{of the} shape functions. With multidetec-

tor data we observe the coordinates of the centre of every strong reflection that is scanned during ^{the data}

collection. Therefore at each temperature ^{the scans}

were analysed ^{in two} passes. The peak ^{centres ob-}

served for the stronger peaks in the first _pass were

used to redetermine the orientation matrix for the second _pass. The first _pas also makes the library ^of shape ^{functions as} complete ^as possible. ^{At both tem-} peratures ^the merging indices after the second _pass

were some 20% smaller than after the first _pass. We also observed a similar improvement in the R factor of the structure refinement against ^the amplitudes ^af-

ter the second _pass compared ^to the refinement after the first _pass.

The _accuracy of the weak-peak reduction also of

depends ^{on the} crystal quality ^{since the} ellipsoid pa- rameters and shape ^functions applied ^{to a} particular

weak peak ^{will in} general ^{be based on} strong peaks

that are not necessarily ^{close in} reciprocal space ^to the weak peak ^nor scanned around the same axis.

Anisotropic ^mosaic broadening ^or spitting ^{of the re-}

flections due to twinning would decrease the _accuracy of the weak-peak ^{reduction more or less} randomly.

The excellent goodness-of-agreement ^{in the} merging

of the reflections at both temperatures implies ^that

neither phenomenon ^{occurs to an} observable extent

in this samples.

Table L- Lattice parameters, ^and refined fractional ^atomic coordinates, occupation factors ^{and thermal} pa- rameters for Ba2YCu307 J61 ^{and the} corresponding parameters ⁱⁿ Ba,2YCu307 [6]. ^{The units of both the}

isotropic ^and anisotropic ^thermal parameters are )L2 . The anisotropic temperature factor, defined for F, ^has The residuals ^are defined as

where Fo ^and F, ^{are the} observed and calculated structure factors, F> is the _average of ^{the set} of equivalents

to Fo, ^{n is the number} of observations and _p is the numbers of parameters, (g.o.a.

goodness of agreement ; g.o.f.

goodness of fit). ^The parameters of this table are for anisotropic refinement. ^{We present the} isotropic

thermal parameters for comparison ^with Ba2yCU307-

1410

3. Structure

The observed cell parameters ^and comparison ^of

the intensities indicated clearly ^a tetragonal ^diffrac-

tion pattern. ^The tetragonal ^cell parameters ^refined from the observed instrumental coordinates of the centres of the N200 _stronger reflections scanned at each temperature ^are given in table I. Refinement of

an orthorhombic cell _gave a and b values that differed

by ^{no more than} 0.002Á, ^{much less than the differ-}

ence of 0.06Å observed for -I. 1 [6,7,8]. ^{The c axis at}

room temperature ^is significantly larger than that ob- served for the superconducting phase (8 -1.I) ^which

is in agreement with the reduced oxygen content of

our sample.

There are five space groups with no systematic

absences in the tetragonal Laue class 4/mmm. ^Of

these, ^three (PA/mmm, ^{P42m and} P422) ^are equiva-

lent for the subsets of special positions that describe the structure ofBa2 YCU3 08-6. Refinements were

therefore performed ^{in the most} symmetric ^{of these} (P4/mmm) and in the remaining ^two groups. P4mm and P4m2, using ^the program UPALS [15]. ^{Since dif-}

ferent ordering ^{of the} oxygen ^on the various sites over

distances comparable ^{to or} larger than the extinction distance could _occur, refinements were also carried out in the orthorhombic space groups Pmm2, ^P222

and Pmmm, allowing ^for twinning ^{of the orthorhom-}

bic cell to give ^a tetragonal diffraction pattern. ^The refinements in all space groups ^were well behaved but

even with larger numbers of adjustable parameters they ^{did not} significantly improve ^the agreement ^com- pared with refinement in the highest-symmetry space group. We therefore report the results of the final refinement in P4/mmm, ^Z

^{1 with Ba on the sites} 2h(1/2, 1/2,z), ^{Y on ld} (1/2, 1/2, 1/2), ^{Cul on la} (0,0,0), ^{Cu2 on 2g} (0,0,z), ^{01 on 2g} (0,0,z), ^{02 on}

4i (1/2, ^0, ;?) ^{and 04 on 2f} (0, 1/2, 0). ^{Here we}

have adopted the atomic nomenclature of reference

[5] (Fig.l). ^In P4/mmm, ^{02 and 03} crystallographi- cally equivalent, ^and similarly ^{04 and 05. No} signifi-

cant differences were observed between the structures at 20K and 298K.

Since the _oxygen occupations appear ^to play a key role in the superconductivity, ^and may be deter- mined to relatively high precision ^{from neutron} data,

we allowed them all to vary. The refinement con-

verged rapidly ^to complete occupation of the sites oc-

cupied by ^{01 and 02 and to} complete absence of oxy- gen in the 2r=l/2 plane. ^{This agrees with the observa-}

tions of Capponi ^{et al.} [6] ^and Siegrist ^{et al.} [5]. ^Our

results do not however support ^{the recent} proposition

of Reller et al. [14] ^{that in} Ba2 YCu308-6 ^{all the} per- ovskite _oxygen sites in the z--1/2 plane ^are occupied.

The refined _occupancy of the 04 and equivalent ⁰⁵

Fig.l.- ^{Unit cell of} tetragonal Ba2 YCU30G.2Û. ^The striped ^cir-

cles show the partly occupied ^{oxygen sites.}

sites in the z=0 plane ^was g--13(2)% , corresponding

to the composition Ba2YCu30c.26’ ^{Even refinement}

of the twinned orthorhombic structures gave ^essen-

tially ^{the same} occupations g=13(2)% ^{for both 04 and}

05. This equal ^occupancy constrasts with the 100%

and 0% ^{found for the 04 and 05 sites} respectively by

neutron powder diffraction in the oxygen-richer ^com- pound Ba2YCu307 [6,7,8]. ^{Our data show clearly}

that it is the sites of the z=0 plane ^{that are} gradu- ally ^{filled as the} proportion ^of oxygen is increased in this system. ^The oxygen occupation ^{of the 04 sites is} probably accompanied by ^{a local} orthorhombic dis- tortion but the diffraction patterns ^show clearly ^that

the average structure remains tetragonal ^{for low} oxy-

gen concentrations.

The temperature factors for all atoms were al- lowed to be anisotropic ^{in the final} refinement. Par-

ticularly high value of the thermal parameters ^were observed for Ba, Cul, ^{01 and 04.} A further remark

concerning ^the thermal vibration of 04 should also be made. Refinement of an isotropic ^thermal parameter

gave ^an estimated error comparable ^{to the} parame- ter itself, ^{while the} anisotropic refinement _gave a very

large ^{value of} Bl1 ^{and a} slightly negative ^{value of} B33.

We interpret ^{this as} indication of disorder in the _po- sition of 04, ^{however we have not been able to obtain} satisfactory convergence for a structure with disor- dered 04 positions. ^{A similar} problem ^{also occurred in}

refinements of the orthorhombic phase Ba2YCu307

[6], ^{except that} large values of both Bll ^and B33 ^are

observed for 04 (see ^Table I).

The final refined atomic coordinates at both 20K and 298K are given in table I. For comparison ^{we also}

include in table I the cell parameters and atomic coor-

dinates observed at room temperature ^for Ba2YCu3 07. ^{Since all} structures reported ^for the orthorhom- bic form (with ^{the exception of the equal 04 and 05}

occupations noted’by Siegrist ^{et al.} [5]) are essen-

tially ^{the same we list} just the results of Capponi ^et

al. [6]. ^Two (X-ray) studies have been performed

on supposedly tetragonal crystals by ^{Hazen et al.} [9]

and LePage ^{et al.} [10]. ^The differences in refined a

and b _axes, the c axis and the Ba z coordinate ob- served by ^{Hazen et al. and} LePage ^{et al. lie} partway between our tetragonal values and the values of Cap- poni ^{et al..} However Hazen et al. and LePage ^et

al. observed slight orthorhombic distortions of the cell parameters, and both noted particularly ^broad

or irregular diffraction peak profiles. As noted above this was not the case in our study. This would _sug- gest ^{that the} crystals ^{of Hazen et al. and} LePage ^et

al. were domain crystals, possibly partly tetragonal

and partly twinned orthorhombic. In fact Izumi et al. [11] ^{have reported a} similar domain effect in ^a

powder study ^of Ba2YCu308_x. They ^{observed two} phases ^{in their} sample ; ^a tetragonal phase ^{of com-} position Ba2YCu30e.32 ^whose structure agrees with ours, and on orthorhombic phase ^with composition Ba2YCu30e.64’ Bearing in mind the uncertainty ⁱⁿ determining 6, particularly by refinement of the _oxy- gen occupations ^from X-ray data, ^we suggest ^{that for} 6>1.5 ^a single-phase crystal ^will adopt ^the tetrago- nal structure reported here, ^{while for ê 1.5 the or-}

thorhombic structure is obtained.

The distances between the heavy ^{atoms and the}

oxygen ^atoms for both Ba2yCU30r,.26 (our work) ^and

Ba2YCu307 [6] ^are given in table II.

The structure of Ba2YCu30e 20 may be descri- bed as an oxygen-deficient perovskite, ^{where the} oxy- gen plane ^at z--1/2 ^{is missing,} and with the cations

Ba2+ and Y3+ ordered along ^{the c} axis in the se-

quence -Ba-Y-Ba-Ba-Y-Ba-. The atom Cul can be

envisaged ^{to lie at the centre of an} octahedron formed

by ^{the 01 sites and the} partially occupied ⁰⁴ sites,

while the atom Cu2 lies at the centre of a nearly ^flat

square pyramid whose base corners are at the sites 02. In these aspects ^{the structure is the same as} Ba2YCu307. ^{The distance} of the Ba from the z=0

plane (2.29A) ⁱⁿ Ba2YCu30e.24 ^{however is} signifi- cantly longer ^{than the distance} observed in Ba2YCu3 07 (2.15Å). The result is that the plane containing

the Ba and 01 atoms is less puckered ^{in the} tetragonal

structure than in the orthorhombic. The increase in the Ba -Ba separation arises from an increase in the

Ba2+ -Ba2+ repulsion by emptying ^{the 04 sites. In}

fact the partial occupancy of the 04 (05) sites in the

tetragonal ^{structure leads to a} considerable disorder

as shown by ^the high Debye-Waller factors for the Ba,

01 and Cul atoms. The difference in the interatomic

separations ^{Cul - 01 and Cu2 - 01 in} Ba2YCu30e.26 implies ^a stronger interaction between 01 and Cul than between 01 and Cu2. This difference is larger

than that observed in Ba2YCu307 (see ^table I). ^As

Table IL- Selected interatomic ’distance (Å) ⁱⁿ tetragonal Ba YCu306.26 ^{and the} corresponding ^{distances in}

orthorhombic Ba2YCu307 [6].

1412

well as an increase in the Ba - Ba distance, ^{we also}

observe an increase in the Cul - Cu2 distance from

4.14A in Ba2YCu307 ^to 4.24Á in Ba2 YCu306.26.

The Cu2 - Cu2 distance decreases slightly ^from 3.39A

to 3.3lA ; ^{in both} structures it is clearly ^{too short to}

accomodate an oxygen atom ^at 2r=l/2 ^{as proposed by}

Reller et al. [14].

4. Conclusion

The structure of the tetragonal phase Ba2YCu3 06.26 has been determined for the first time by single- crystal neutron diffraction. Comparison ^{with the}

structure of the orthorhombic superconducting ^phase Ba2YCuo3r ^{allows us to identify the oxygen sites}

whose occupations adjust ^{to the} proportion ^{of oxy-}

gen and which play a key ^role in the existence of su-

perconductivity ^{in this} system. ^This study ^indicates

unambiguously ^{that these are the sites on the} plane midway ^between pairs ^{of closest Ba atoms.} Although

there _may be local orthorhombic distortions due to the partial ^{but still} significant (13% ) occupation ^of

these sites, ^the average structure is clearly tetragonal.

Analysis ^{of a similar} experiment ^on single crystals ⁱⁿ

which the _oxygen content has been increased is in progress.

We gratefully acknowledge ^the particular sup-

port ^{of the directors of the} I.L.L. for this work. We

especially thank Prof. J. Lajzerowicz-Bonneteau ^for

sage counsel on all aspects of the refinements. We also wish to thank Dr Sax Mason for his considerable

advice, ^Mr Michel Berneron for technical assistance

during ^the experiment, ^{and Dr R. Moret for construc-}

tive discussions.

References

[1] WU, M.K., ASHBURN, J.R., TORNG, C.J., HOR, P.H., MENG, R.L., GAO, L., HUANG, Z.J., WANG, W.Q., ^and CHU, C.W., Phys. ^Rev. Lett.,

58 (1987) ^908.

[2] RAO, C.N.R., GANGULY, P., RAYCHAUDHURI, R.K., ^MOHAN RAM, R.A., ^and SREEDHAR, ^K.

Nature, ³²⁶ (1987) ^856.

[3] HINKS, D.G., SODERHOLM, L., CAPONE, D.W., JORGENSEN, J.D., SCHULLER, I.K., SEZGRE, C.U., ZHANG, K., ^and GRACE, J.D., Appl. Phys.

Lett., (1987) ^{in press.}

[4] BEDNORZ, G., ^and MULLER, K.A., ^Z. Phys.,

B64 (1986) ^189.

[5] ^SIEGRIST, T., SUNSHINE, S., MURPHY, D.W., CAVA, ^{R.J. and} ZAHURAK, S.M., Phys. Rev.,

B35 (1987) ^7137.

[6] CAPPONI, J.J., CHAILLOUT, C., HEWAT, A.W., LEJAY, P., MAREZIO, M., NGUYEN, N., ^RA-

VEAU, B., SOUBEYROUX, J.L., THOLENCE, J.L.,

and TOURNIER, R., Europhys. ^{Lett. 3} (1987)

1301.

[7] BENO, M.A., SODERHOLM, L., CAPONE, D.W., HINKS, D.G., JORGENSEN, J.D., SCHULLER, I.K., SEGRE, C.U., ZHANG, K., ^and GRACE, J.D., Appl. Phys. Lett., (1987) ^{in press.}

[8] ^BEECH, F., MIRAGLIA, S., SANTORO, A., ^and

ROTH, R.S., Phys. Rev. Lett. (1987) ^{in press.}

[9] HAZEN, R.M., FINGER, L.W., ANGEL, R.J., ^PRE-

WITT, C.T., Ross, N.L., MAO, H.K., ^HADIDIA-

cos, C.G., HOR, P.H., MENG, R.L., ^and CHU, C.W., Phys. ^{Rev. B35} (1987) ^7238.

[10] LEPAGE, Y., MCKINNON, W.R., TARASCON, J.M., GREENE, L.H., HULL, G.W., ^and HWANG, D.M., Phys. ^{Rev. B35} (1987) ^7245.

[11] IZUMI, F., ASANO, H., ISHIGAKI, T., ^TAKAYA- MA-MUROMACHI, E., UCHIDA, Y., WATANABE, N., ^and NHISHIKAWA, T., Japan ^J. Appl. Phys.

(1987) ^{in press.}

[12] THOMAS, M., STANSFIELD, R.F.D., BERNERON, M., FILHOL, A., GREENWOOD, G., JACOBE, ^J.

FELTIN, D., ^and MASON, S.A., ⁱⁿ Position-Sensi- tive Detection of ^Thermal Neutrons, ^edited by ^P.

CONVERT and J.B. FORSYTH (Academic ^Press, New-York) ^{1983, p 344.}

[13] WILKINSON, C., ^and KHAMIS, H.W., in ^Posi-

tion-Sensitive Detection of ^Thermal Neutrons,

edited by ^{P. CONVERT and} J.B. FORSYTH (Aca-

demic Press, New-York) ^{1983, p. 358.}

[14] RELLER, A., BEDNORZ, J.G., ^and MULLER, K.A., ^Z. Phys. (1987) ^{in press.}

[15] ^LUNDGREN, J.O., Crystallographic Computer Programms, Report UUIC-B13-04-04, ^Institute

of Chemistry, ^{Univers. of} Uppsala (1979).
