How to formulate image processing applications ?

Arnaud Renouf, R´egis Clouard, and Marinette Revenu GREYC Laboratory (CNRS UMR 6072)

6, Boulevard Mar´echal Juin 14050 CAEN cedex FRANCE [email protected]

Abstract. This paper presents an ontology-based system for helping in- experienced users formulate image processing applications. We propose models and their formalization through ontologies that identify and orga- nize the necessary and sufficient information to design such applications.

We also explain the interaction means that lead the user to give a good formulation of his/her application.

1 Introduction

In the last fifty years, a lot of image processing applications have been developed in many fields (medicine, geography, robotic, industrial vision, ...). Nevertheless, the problem of formulating such applications in image processing terms has been little studied. Image processing specialists develop their applications by trial- error cycles and do not define a real formulation of the problem they consider.

Thus, applications are merely formulated through their solution and not by a formal definition of the problem they solve.

However a complete and rigorous formulation of the application is essential towards the goal of designing more robust and more reliable vision systems, and in order to fix the limits of the application, to favor reusability and to enhance the evaluation. Such a formulation has to clearly specify the objective and to identify the range of the considered input data. Unfortunately, formulating an image processing application is a problem of qualitative nature that relies on subjective choices. Hence, an exhaustive or exact definition of the problem does not exist. Only an approximative characterization of the desired application be- havior can be defined [1].

Our approach tends to acquire the user’s business knowledge and map it to an image processing one in order to find a solution. Hence, we propose to study the formulation of image processing applications through the design of a system that allows inexperienced users to build their applications by interaction. In this paper, we present a brief state of the art on image processing application formu- lation (Section 2) and describe the global system we are developing (Section 3).

Then we propose a model for the formulation of image processing applications

and its formalization through an ontology (Section 4). Finally, the interaction

part of the system is explained (Section 5).

2 State of the Art

Attempts to formulate image processing applications were conducted around knowledge based systems such as LLVE [2], CONNY [3], OCAPI [4], MVP [5] or BORG [6]. A priori knowledge on the application context (sensor effects, noise type, lighting conditions, ...) and on the goal to achieve were more or less im- plicitly encoded in the knowledge base. The formulation of the application is reduced to the choice of a transformation objective in a list of predefined im- age processing tasks which are well known. Therefore they make the saving of a complete and explicit formulation of the image processing application.

Among these works, an original approach was proposed by J. Hasegawa et al. [7]. The formulation is given by the user through a sample figure as a sketch.

This kind of formulation is interesting because it is objective and its nature is quantitative. Nevertheless its scope is limited to a restrictive subset of segmenta- tion or detection goals and it does not really take into account the input images variability.

More recent approaches bring more explicit modelling [8][9][10][11] but they are all restricted to the modelling of business objects description for tasks such as detection, segmentation, image retrieval, image annotation or recognition appli- cations. They use ontologies that provide the concepts needed for this description (a visual concept ontology for object recognition in [9], a visual descriptor on- tology for semantic annotation of images and videos in [12] or image processing primitives in [8]) or they capture the business knowledge through meetings with the specialists (e.g. use of the NIAM/ORM method in [10] to collect and map the business knowledge to the vision knowledge). But they do not completely tackle the problem of the application context description (or briefly as in [9]) and the effect of this context on the images (environment, lighting, sensor, image format). Moreover they do not define the means to describe the image content when objects are a priori unknown or unusable (e.g. in robotic, image retrieval or restoration applications). They also suppose that the objective is unique and known beforehand (to detect, extract or recognize an object with a restrictive set of constraints) and therefore they do not address its formulation.

3 A System to Formulate Image Processing Applications

Our work is part of a global project which aims at developing a system that

automatically generates image processing softwares from user-defined problem

formulations. This system is composed of two sub-systems (Fig. 1): a formulation

system for image processing applications which is the focus of our work, and a

planning system for image processing tasks [6]. At the moment, the system han-

dles only one image processing task at a time. If a real application needs several

tasks, the system is used as many times as there are tasks. It is also restricted to

image processing tasks. It considers only image-to-image transformations with-

out any interpretation of the image content. The user defines the problem with

the terms of his/her domain by interaction with the user layer of the formula-

tion system. This part of the system is a human-machine interface which uses

How to formulate image processing applications ? 3

image processing plan

Construction of the Ontology Processing

Image BORG

Planning System for Image Processing Tasks

in an image processing problem Transformation of the user’s formulation

by interaction with the user Formulation of the application

Formulations Image Processing Applications

for Formulation System

HERMES

Domain Ontology

Layer User Layer

Images

Application

Fig. 1. The system architecture of the project.

a domain ontology to handle the information dedicated to the user. It groups concepts that allow the users to formulate their processing intentions and define the image class. Then the formulation system translates this user formulation into image processing terms taken from an image processing ontology. It uses a set of rules to ground the symbols given by the user which are terms of his/her domain and concepts of the domain ontology to image data which are concepts of the image processing ontology (see Section 5.3). This translation realizes the mapping between the phenomenological domain knowledge of the user and the image processing knowledge.

The result of this translation is an image processing request which is sent to the planning system to generate the program that responds to this request. This cooperation needs the two sub-systems to share the image processing ontology.

Then the formulation system executes the generated program on test images and presents the results to the user for evaluation purposes. The user is respon- sible for modifying the request. This process is repeated until the results are validated.

4 Formulation Model for Image Processing Applications

We propose a complete model for the formulation of image processing applica-

tions [13]. This model allows to identify and organize the relevant information

which are necessary and sufficient for the planning system (or an image process-

ing specialist) to develop a convenient solution. It covers all image processing

tasks and is independent from any application domain. In this section, we present

a brief review of this model formalization through an image processing ontology

(notice that this ontology tackles the problem of the formulation from the image

processing experts point of view). This ontology is composed of two parts: the

objectives specification and the image class definition. It is written in OWL DL

which is based on description logics, defines 300 concepts, 23 roles and 183 re-

strictions. During the translation step, the formulation system instantiates this

* *

*

*

*

*

0..1

0..1

0..1 constraint

Control Constraint

Performance Criteria

Quality Criteria

has

value Value

Numeric Value

Symbolic Value

has

task task _criteria Criteria

to Optimize has−

error

has−

error Level of

Detail has

level

Elements to include include

exclude Elements

to exclude

has object

Acceptable Error has

1 Objective

Object Business has

Fig. 2. CML representation of the objective specification model.

ontology and sets their properties using an OWL API in order to represent the formulation of the user at the image processing level.

4.1 The Objective Specification

This specification relies on the teleological hypothesis [13]. This hypothesis leads us to define an image processing application through its finalities. Hence, an application objective is represented by a list of tasks with related constraints (criteria to optimize with acceptable errors, levels of detail with acceptable er- rors, elements to be excluded and included in the result) and a list of control constraints. We present on Fig. 2 the formalization of this model using the CML formalism of CommonKADS which covers the ontologies specification [14]. This figure represents the highest abstraction level of the objective specification part of the image processing ontology and does not show all its concepts. A concept like Task is the root of a hierarchic tree where nodes are processing categories and leaves are effective tasks. Processing categories belong to reconstruction, segmentation, detection, restoration, enhancement and compression objectives.

Effective tasks are extract object, detect object, enhance illumination, ...

To illustrate the use of this model, we take the example of a cytological ap-

plication [15] where the user wants to extract serous cell nuclei. In Table 1, we

present the formulation of the application objective which is obtained from the

instances (and their properties) created by the formulation system in the image

processing ontology. The terms (task, extract object, criteria to optimize, ...) are

concepts of the ontology and terms in italic are instances created by the system

(object1 is an instance of the concept business object, num1 is an instance of the

concept interval ).

How to formulate image processing applications ? 5 Table 1. Formulation of the application objective for the cytologic application.

Task: Extract object

Criteria to optimize: Boundaries localization Acceptable error: Prefer boundaries inside Level of detail: Separate just-touching Acceptable error: Prefer not to separate Business object: object1 (“Serous Cell Nucleus”) Elements to be excluded: Touching borders

Control constraints Quality criteria Processing time: num1([0,2] secs) Performance criteria Application quality: Reliability

* * *

* 0..1

1

* Description

Level

Physical Level

Perceptive Level

Business Object

Image Format

Acquisition System

Description Element

Noise

Visual Primitive

Background Edge Region Noise Descriptor

Composition Distribution Descriptor

Colour Descriptor

Luminance

Shape Descriptor

Convexity Circularity Hue

Value

Numeric Value

List Patch

Interval Symbolic Value

Relative Comparison

Predefined Term

Level

Comparison Term Length

Unit Surface

Unit Unit

Value Part

Linguistic Variable {more_than,less_than,equal_to}

has term has unity

has has

value has

descriptor has

element

has term

{very_low, low, medium, high,very_high}

compared

Fig. 3. CML representation of the image class definition model.

4.2 The Image Class Definition

This definition relies on two hypotheses: the semiotic and the phenomenologi- cal hypotheses [13]. The semiotic hypothesis leads us to define the image class considering three levels of description:

1. the physical level (i.e. sign level in semiotic) focuses on the characterization of the acquisition system effects on the images.

2. the perceptive level (i.e. signifiant) focuses on the description of the visual primitives (regions, lines, ...) without any reference to business objects.

3. the semantic level (i.e. signified) focuses on the identification of the business objects visualized in the images.

The phenomenological hypothesis states that a visual characterization of the

images and the business objects are sufficient to design image processing appli-

cations. Hence, we do not need a complete description of the objects given by

the user but only a description of its visual manifestation. The system asks the

user to describe how an object appears in the images but not what it is. For

example, in the case of aerial images, cars are simply defined as homogeneous

rectangular regions. We present on Fig. 3 the formalization of this model using

the CML representation. Here again, this representation is only a part of the

image processing ontology and does not show all the concepts: the descriptors

Table 2. A part of the definition of the image class at the physical level.

Element Descriptors Values Range of values

Lighting

Lighting Conditions {stable, non-uniform} {under-exposed, over-exposed stable, varying, ...}

Lighting Model lighting.bmp image file

Image Width 512 pixels Z

Height 512 pixels Z

Format

Color Space RGB {binary, grey level, RGB, ...}

Quantification 24 bits per pixel Z

Noise

Composition additive {additive, multiplicative}

Distribution Gauss {Gauss, Poisson, Rayleigh, ...}

Mean 0 R

Standard Deviation [0 , 4] R

Table 3. A part of the definition of the image class at the semantic level for the business concept serous cell nucleus.

Visual Primitives Descriptors Values Range of values Region

Luminance [0 , 0.8] [0 , 1]

Hue [9π/8 , 3π/2] [0 , 2π]

Convexity high,very high {very low,low,average, high,very high}

Edge

Type step {step,roof}

Contrast very low,low {very low,low,average, high,very high}

(color, texture, shape, geometric, photometric descriptors), the visual primitives (region, edge, background, point of interest, points cloud) and the types of val- ues (symbolic and numeric). This part of the ontology is also instantiated by the formulation system to construct the image class definition. In Table 2, we show a representation of this definition at the physical level, and in Table 3 the definition at the semantic level for the business object Serous Cell Nucleus.

Only the terms in italic result from an instantiation of the system, the others are concepts or individuals that are part of the image processing ontology.

5 The System

In this section, we present how the system can lead the user to specify the

objective and define the image class definition. We propose an interaction model

which is formalized through a domain ontology. This ontology is very close to

the image processing one: its structure is the same, some concepts are shared

(e.g. width, color, size, ...), some are just transformed in other words (the visual

primitive “line” in the domain ontology is an “edge” in the image processing

ontology ) and some are added with new properties to suit the interaction model

requirements.

How to formulate image processing applications ? 7

5.1 The interaction model

The role of the system is to help the user to give a formulation which is:

- compact: it is reduced to essential information;

- representative: it keeps a strong correspondence to the real objects;

- discriminative: it contains enough information to discriminate the objects;

- precise: it allows a good identification of objects;

- dense: all foreseen image content variability of the scene is modelled.

We consider that the user is inexperienced in the image processing field. Hence the system has to propose interfaces that lead this user to construct the formula- tion using terms and representations easily understandable (these terms are part of the domain ontology). Nevertheless, we also consider the user as a specialist of his/her domain. Hence he/she is able to specify the set of tasks to achieve, describe the effects of the acquisition system on the produced images, give a rel- evant description of the images and objects visualized, and evaluate the results of the processing plan produced. Therefore, he/she is responsible for giving a formulation which is both representative and discriminative.

Consequently, the role of the formulation system is to help users to produce a formulation that is compact, dense and precise. We know that the formulation is essentially of qualitative nature because it results from subjective user’s choices.

To make these choices as most objective as possible, we propose an interaction model which leans on different principles:

- the specification of the objective is initiated from the post-processing tasks;

- the definition of the image class at the physical level is guided by the char- acterization of the acquisition system;

- the definition of the image class at the semantic level is based on the con- struction of a business objects tree.

5.2 The Interaction Means

The Objective Specification: The system firstly proposes to specify the image processing objectives from the specification of the post-processing tasks. These tasks are not part of the formulation of the image processing application but they are used as a mean of interaction (part of the domain ontology). They give information on the way the results of the application are going to be used (size or shape, position, orientation, radiometric, topological measurements, artistic visualization, visualization of details, counting) and thus, on its desired behavior.

For example, if one wants to perform size measurements on the regions extracted by a segmentation task, one can deduce that a criteria to optimize will be the boundaries localization. Moreover, if one wishes to achieve other measurements like radiometric ones on the pixels color for example, one can deduce that an acceptable error on the boundaries localization will be to place the border inside the region (to avoid taking background pixels in the measurements).

With such a specification, in a first step the user chooses the post-processing tasks; then he/she specifies the task to be performed to reach the objective.

The interface proposes a list of processing tasks which are part of the domain

ontology. Thanks to the post-processing specification, the system is now able to propose default values for the constraints associated to the task (by realizing inferences using first order production rules). However, in fine, it is always the user that defines the values of these constraints, either by validating the default values or by setting them directly.

The Image Class Definition: The system helps the user in the definition of the image class. At the physical level, a database of classical acquisition sys- tems (CCD camera, MRI, PET, Infrared, ...) allows to propose default values for noise or defects description. We know for example that images produced by ultrasound sensors are perturbed by speckle noise. Such a database can easily be updated by image processing specialists. Nevertheless, we consider that the user, as a specialist of his/her domain, can also directly give the effects produced on the images (often the case in fields like astronomy or robotics).

At the semantic level, the description is initiated by the construction of a business objects tree. This choice leans on the hypothesis that domain specialists share a taxonomy of their objects. Thus, they are able to identify and organize them hierarchically using inheritance relations. This first step aims at represent- ing their differences like in the differential paradigm proposed by B. Bachimont for the design of ontologies [16]. Then, they specify the composition relations that links these objects and describe their spatial organization. According to the phenomenological hypotheses, a new object has to be created for each way it can appear in the images. These information obtained by interaction with the user give a part of objectivity in the user’s formulation and leads him/her to give a dense representation of the objects. Based on the tree, the system asks the user to give a phenomenological characterization of the objects from the visual primitives that compose them.

When the task is a global one (e.g. enhance illumination) or when the ob- jects are a priori unknown, the description is completed at the perceptive level.

Hence the user describes “syntaxically” the images content with visual primitives chosen in the domain ontology (contour, region, line, ...).

5.3 The Anchoring Problem

Once a user formulation has been done, the system has to translate it into an image processing formulation. The terms of the user’s domain (which he/she uses to qualify the objects) have to be associated to image data or to terms of the image processing field (concepts of the image processing ontology). This as- sociation is a problem as such and known as the symbol grounding or anchoring problem [17][18]. We explain here how the system handles this problem for the different modalities of description given to the users.

The Anchoring of the User’s Domain Terms: One of the problem to be

tackled with visual descriptions is the users’ subjectivity. A color for example is

not perceived in the same way by different users: for example a same color can be

described as rather blue or rather green by different persons. Hence we decided

that the users have to name themselves the colors. Then they have to give values

to the associated descriptors either by setting the values of the descriptors (e.g.

How to formulate image processing applications ? 9

hue, saturation, luminance) or by giving patches that surround image areas as examples and counter-examples of the given description. While other systems calculates a set of values from these patches [17], our system sends directly the patches to the planning system and let it extract by itself the needed values.

Actually, we do not aim at solving completely the symbol grounding problem with the formulation system but we give the planning system the means to do it.

The Linguistic Variables: Linguistic variables allow the user to keep im- precision on descriptors that characterize imprecise nature properties (e.g. cir- cularity, compactness, ...) [17]. This is also very useful when the user wants to introduce an important variability on features of the image class. The user chooses a term in a predefined list (e.g. null, very low, low, average, high, very high) to give a value to a descriptor. These values are kept in the formulation at the image processing level because resolution can be done from these linguistic variables. They can also be associated with patches as described previously.

The Comparison Values: The user can also choose to valuate a descriptor by comparison. This is very useful in the image processing field to express that some features are used directly to discriminate two elements (object or visual primitives already described). Two types of comparison are possible: relative ones (e.g. the size of A is greater than the size of B) or superlative ones (e.g. the size of the background is the greatest).

We need the two types of values (the symbolic and numerical values) for the formulation of the image processing application. The symbolic values (linguistic variables, ontology terms, comparison values) are necessary in the first step of the resolution which is the construction of the processing plan. Then numer- ical values (image patches, image file, descriptor values) are used to tune the parameters of the operators selected in the previous step of the resolution.

6 Conclusion

Our formulation model for image processing applications identifies and organizes the necessary and sufficient information for a specialist, or an automatic resolv- ing system, to develop a solution. The formalization of this model through an ontology specifies the grammar and the vocabulary of the formulation.

We defined interaction means that lead the user to give a compact, dense and precise formulation by trying, on one hand, to reduce the semantic gap between business knowledge and image processing knowledge and, on the other hand, to objectify as much as possible his/her formulation.

This work is a contribution to the image processing field because the for- malization of the problems allows to give prominence to the knowledge used in such applications development. It defines a guideline on the way to tackle such applications and defines the formulation elements of image processing problems.

The explicitness of these elements is very useful to acquire the image process-

ing knowledge used by the planning system: they are used to justify the choice

of the algorithms regarding the application context and therefore to define the

conditions of applicability of the image processing techniques. It also favors the reusability of solution parts.

References

1. Clouard, R.: Une m´ethode de d´eveloppement d’applications de traitement d’images. Traitement du signal 21(4) (2004) 277–293

2. Matsuyama, T.: Expert systems for image processing: knowledge-based composi- tion of image analysis processes. CVGIP 48(1) (1989) 22–49

3. Liedtke, C., Bl¨omer, A.: Architecture of the Knowledge Based Configuration Sys- tem for Image Analysis ”Conny”. In: ICPR’92. (1992) 375–378

4. Cl´ement, V., Thonnat, M.: A knowledge-based approach to integration of image procedures processing. CVGIP: Image Understanding 57(2) (1993) 166–184 5. Chien, S., Mortensen, H.: Automating image processing for scientific data analysis

of a large image database. IEEE PAMI 18(8) (1996) 854–859

6. Clouard, R., Elmoataz, A., Porquet, C., Revenu, M.: Borg : A knowledge-based system for automatic generation of image processing programs. IEEE PAMI 21(2) (1999) 128–144

7. Hasegawa, J., Kubota, H., Toriwaki, J.: Automated construction of image process- ing procedures by sample-figure presentation. ICPR 86 (1986) 586–588

8. Nouvel, A., Dalle, P.: An interactive approach for image ontology definition. In:

13`eme Congr`es de Reconnaissance des Formes et Intelligence Artificielle, Angers, France (2002) 1023–1031

9. Maillot, N., Thonnat, M., Boucher, A.: Towards ontology based cognitive vision.

In: ICVS. Volume 2626 of LNCS., Springer (2003) 44–53

10. Bombardier, V., Lhoste, P., Mazaud, C.: Mod´elisation et int´egration de connais- sances m´etier pour l’identification de d´efauts par r`egles linguistiques floues. Traite- ment du Signal 21(3) (2004) 227–247

11. Town, C.: Ontological inference for image and video analysis. Mach. Vision Appl.

17(2) (2006) 94–115

12. Bloehdorn, S., Petridis, K., Saathoff, C., Simou, N., Tzouvaras, V., Avrithis, Y., Handschuh, S., Kompatsiaris, Y., Staab, S., Strintzis, M.G.: Semantic annotation of images and videos for multimedia analysis. In: ESWC. Volume 3532 of LNCS., Springer (2005) 592–607

13. Renouf, A., Clouard, R., Revenu, M.: Un mod`ele de formulation d’applications de traitement d’images. In: ORASIS’05, Fournols, France (2005)

14. Schreiber, G., Wielinga, B., Akkermans, H., Van de Velde, W., Anjewierden, A.:

CML: The CommonKADS Conceptual Modelling Language. In: EKAW 94. Volume 867 of LNCS., Hoegaarden, Belgium, Springer Verlag (1994) 1–25

15. Lezoray, O., Cardot, H.: Cooperation of color pixel classification schemes and color watershed : a study for microscopic images. IEEE Trans. on Image Processing 11(7) (2000) 783–789

16. Bachimont, B. In: Engagement s´emantique et engagement ontologique : conception et r´ealisation d’ontologies en ing´enierie des connaissances. Eyrolles (2000) 305–323 17. Hudelot, C., Maillot, N., Thonnat, M.: Symbol grounding for semantic image interpretation : from image data to semantics. In: Proceedings of the Workshop on Semantic Knowledge in Computer Vision, ICCV, Beijing, China (2005) 18. Coradeschi, S., Saffiotti, A.: An introduction to the anchoring problem. Robotics

and Autonomous Systems 43(2-3) (2003) 85–96
