RECONSTRUCTION OF THE DEFECT GEOMETRY BY SIMULTANEOUS EBIC/CL MEASUREMENTS ;

THEORY AND EXPERIMENTAL RESULTS

A. Jakubowicz, M. Bode, H.-U. Habermeier

To cite this version:

A. Jakubowicz, M. Bode, H.-U. Habermeier. RECONSTRUCTION OF THE DEFECT GEOMETRY BY SIMULTANEOUS EBIC/CL MEASUREMENTS ; THEORY AND EXPERIMENTAL RESULTS.

Journal de Physique Colloques, 1989, 50 (C6), pp.C6-167-C6-167. �10.1051/jphyscol:1989624�. �jpa-

00229655�

R E W E DE PHYSIQUE A P P L I Q U ~ E

Colloque C6, Suppl6ment au n 0 6 , Tome 24, Juin 1989

RECONSTRUCTION OF THE DEFECT GEOMETRY BY SIMULTANEOUS EBIC/CL MEASUREMENTS ; THEORY AND EXPERIMENTAL RESULTS

A. J A K U B O W I C Z ( ~ ) , M. BODE and H.-U. HABERMEIER

Max-Planck-Institut fiir Festk6rperforschung, Heisenbergstrasse 1 , 0-7000 Stuttgart 80, F . R . G .

Electron beam induced current (EBIC) as well as Cathodoluminescence (CL) are widely used to investigate defects in semiconductor materials. A quantification of these methods, however, is difficult, since several possible effects may contribute to the observed contrasts (e.g. geometrical changes of the defect or a varying recombination along the defect).

Recently a new model was proposed [I] to overcome these problems for luminescent materials such as GaAs by a simultaneous measurement of EBIC and CL. The different effects due to the diffusion length L of the minority carriers and the absorption coefficient a of the photons on the two signals allow to determine the local depth of a defect from these measurements. In this way the geometry of the defect can be reconstructed.

Together with the EBIC- or CL-contrast this allows to separate the geometrical contributions to the contrast from the contributions due to a varying recombination strength.

We will present the theory for this new method, together with experimental results on known defects in GaAs to show the excellent agreement between real structure and reconstruction.

[I] A. Jakubowicz : Defects in Semiconductors, Proc. 1 4 ~ ~ Int. Conf. Def. Semicond. (ed. H.

Bardeleben, Trans Tech Publ., Switzerland) Mat. Sci. Forum Vol. 1 0

-

(''present address : Weizmann Institute of Science. Department of Structural Chemistry, IL-Rehovot 76100, Israel

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphyscol:1989624
