SPARE PARTS DIAGRAM FOR
First Choice Group
Blakeney Way, Kingswood Lakeside Cannock, Staffs, WS11 8LD
TEL: 01543 577778 FAX: 01543504141 Email: [email protected] Web: www.firstchoice-cs.co.uk
Convection Oven
CG102MX
GCM0102 CG102MX Revisione 02
POS. ITA CODICE VALID. SCAD.
1 Guarnizione 15364/p nera x vetro 7070167
2 Maniglia per porta forno completa 5900180 01/08/2006
3 Bussola interna maniglia d=36 2011212
4 Porta completa 2011958
5 Perno sup. Per porta d.19 2011881
6 Portalampada cablato completo 2012516
7 Lampada alogena 12v 20w 6061054
8 Nasello x chiusura 01.0218 5900122
9 Perno regolazione porta d.20 2011882
10 Bacinella s/condensa forno ass.ta 2011892 11 Vetro serigrafato x forno ass.to 2011965 12 Bacinella r/condensa vetro ass.ta 2011888 13 Portalampada completo lamp.vet.ca. 6063075
13A Vetro x lampada 6063077
14 Riscontro x perno micro porta 2011887
15 Vetro temp. per forno 5900808
16 Ventola forno 310x135 5901023
17 Ventilatore 120x120x38 classe f 6033175
18 Motore as.3ph 80/4 hp1,0 v380 6033155 31/01/2004
18 Motore as.3ph 100L hp1,0/0,35 6034348 01/02/2004
19 Guarnizione albero m. 9461-24x46x4 7070151
20 Micro bip. a pulsante VBR0004 6043088
21 Perno micro porta ass.to 2011886
22 Guarnizione 08716 nera x porta 7070166
23 Controllo di fiamma efd 0503xxx 7020085 24 Corpo valvola sit tandem 0830041 7020080 25 Filtro antidisturbo flcs270501 6090057 26 Sonda PT100 tubo 110x4 cavo 1400 6000083 27 Termostato 1f sic.350°c 5510562800 6010026 28 Ugello x elettrovalvola 0,25 l/1' 6042095 29 Elettrovalvola 1 via c/filtro v240 6042070
30 Guarnizione x flangia s.u. .58x46 2011777
31 Bruciatore polidoro 103.2598.10 7090101
32 Candela rilevazione fiamma 2012110
33 Candela accensione 2012111
34 Cruscotto compl.forno conv. 10gr gk 2012479 35 Manopola serigrafata per forno d=6 2012261 36 Pulsante unip. Bianco p12431200000 6032020 37 Cappuccio x pulsante p12 00580055 6032021 38 Controcornice nera p1 p12 00551950 6032022 39 Interruttore 2X16A 2pos.4922015700 6030007 40 Scheda controllo inversione marcia 6010084 41 Contattore trip. 25a/ac1 b.230v 1l 6046038 42 Trasformatore str105si-h 11,5/230v 6041065 43 Filtro antidisturbo 411.13.2210 6090050
44 Scheda termoregolatore base 6010096
45 Scheda termoregolatore display 6010095
46 Potenziometro con cavo 6010097
47 Scheda buzzer elet. Con squadrette 6010090 48 Temporizzatore 120'logarit. M8 65 6032047
Data ultima modifica: 13/11/2014
GCM0102-R2.xlsGCM0102 CG102MX Revisione 02
POS. GB CODICE VALID. SCAD.
1 Seal 15364/p black - for glass 7070167
2 Oven door knob (complete) 5900180 01/08/2006
3 Internal handle bushing d=36 2011212
4 Door (complete) 2011958
5 Suppoer spindle for door d.19 2011881
6 Wired lamp-holder (complete) 2012516
7 Halogen bulb 12v 20w 6061054
8 Whiting for closing 5900122
9 Adjustment spindle for door d.20 2011882
10 Condensation drain tray (oven) (assembly) 2011892 11 Silf-screened glass panel for oven (assembly) 2011965 12 Condensation collector tray (glass) (assembly) 2011888 13 Lamp-holder (complete) for glass lamp ca. 6063075
13A Glass for lamp 6063077
14 Counterplate for door microswitch spindle 2011887
15 Glass for oven 5900808
16 Oven fan 310x135 5901023
17 Fan 120x120x38 class f 6033175
18 Motor as.3ph 80/4 hp1,0 v380 6033155 31/01/2004
18 Motor as.3ph 100L hp1,0/0,35 6034348 01/02/2004
19 Shaft seal m. 9461-24x46x4 7070151
20 Two-pole microswitch to push button VBR0004 6043088 21 Door microswitch spindle (assembly) 2011886
22 Seal 08716 black - for door 7070166
23 Flame control efd 0503xxx 7020085
24 Valve body sit tandem 0830041 7020080
25 Suppressor flcs270501 6090057
26 Sensor pt100 tube 110x4 cable 1400 6000083 27 Thermostat 1f safety.350°c 5510562800 6010026 28 Nozzle for solenoid valve 0,25 l/1' 6042095 29 1-way solenoid valve with filter v240 6042070
30 Flange seal s.u. .58x46 2011777
31 Polidoro burner 103.2598.10 7090101
32 Flame detection spark plug 2012110
33 Ignition spark plug 2012111
34 Oven control panel (complete) con. gk. 10gr 2012479
35 Silk-screened knob for oven d=6 2012261
36 Single-pole button (white) p12431200000 6032020
37 Cap for button p12 00580055 6032021
38 Black surround p1 p12 00551950 6032022
39 Switch 2x16a 2pos.4922015700 6030007
40 Control/direction reversal board 6010084
41 Three-pole contactor 25a/ac1 b.230v 1l 6046038
42 Transformer str105si-h 11,5/230v 6041065
43 Suppressor 411.13.2210 6090050
44 Thermoregulation board 6010096
45 Display thermoregulation board 6010095
46 Potentiomener with cable 6010097
47 Electronic buzzer board with brackets 6010090
48 Timer 120'logarithmic m8 65 6032047
Data ultima modifica: 13/11/2014
GCM0102-R2.xlsGCM0102 CG102MX Revisione 02
POS. F CODICE VALID. SCAD.
1 Joint 15364/p noir x vitre 7070167
2 Poignée pour porte four complète 5900180 01/08/2006
3 Douille interne poignée d=36 2011212
4 Porte complète 2011958
5 Pivot sup. Pour porte d.19 2011881
6 Douille câblée complète 2012516
7 Lampe halogène 12v 20w 6061054
8 Mentonnet de fermeture 5900122
9 Pivot réglage porte d.20 2011882
10 Bac s/condensation four assemblé 2011892
11 Vitre sérigraphiée x chambre assemblée 2011965 12 Bac r/condensation vitre assemblé 2011888
13 Douille complète lamp. Vitre ch. 6063075
13A Vitre por lampe 6063077
14 Butée x pivot microcontact porte 2011887
15 Vitre pour four 5900808
16 Ventilateur four 310x135 5901023
17 Ventilateur 120x120x38 classe f 6033175
18 Moteur as.3ph 80/4 hp1,0 v380 6033155 31/01/2004
18 Moteur as.3ph 100L hp1,0/0,35 6034348 01/02/2004
19 Joint arbre m. 9461-24x46x4 7070151
20 Microcontact bip. a button VBR0004 6043088
21 Pivot microcontact porte assemblé 2011886
22 Joint 08716 noir x porte 7070166
23 Contrôle de flamme efd 0503xxx 7020085
24 Corps vanne sit tandem 0830041 7020080
25 Filtre antiparasites flcs270501 6090057 26 Sonde pt100 tube 110x4 câble 1400 6000083 27 Thermostat 1f séc.350°c 5510562800 6010026
28 Buse x électrovanne 0,25 l/1’ 6042095
29 Électrovanne 1 voie + filtre v240 6042070
30 Joint x bride s.u. .58x46 2011777
31 Brûleur polidoro 103.2598.10 7090101
32 Bougie détection flamme 2012110
33 Bougie allumage 2012111
34 Bandeau de commande compl.four con. 10gr gk. 2012479
35 Bouton sérigraphié pour four d=6 2012261
36 Bouton-poussoir unip. Blanc p12431200000 6032020 37 Capuchon x bouton-poussoir p12 00580055 6032021
38 Contre-cadre noir p1 p12 00551950 6032022
39 Interrupteur 2x16a 2pos.4922015700 6030007
40 Carte contrôle inversion marche 6010084
41 Contacteur trip. 25a/ac1 b.230v 1l 6046038 42 Transformateur str105si-h 11,5/230v 6041065 43 Filtre antiparasites 411.13.2210 6090050
44 Carte thermorégulateur 6010096
45 Carte thermorégulateur afficheur 6010095
46 Potentiomètre avec câble 6010097
47 Carte avertisseur élect. + équerres 6010090 48 Temporisateur 120’ logarit. M8 65 6032047
Data ultima modifica: 13/11/2014
GCM0102-R2.xlsGCM0102 CG102MX Revisione 02
POS. D CODICE VALID. SCAD.
1 Dichtung 15364/p schwarz x scheibe 7070167
2 Griff für ofentür komplett 5900180 01/08/2006
3 Buchse innen griff d=36 2011212
4 Komplette tür 2011958
5 Stift ober für tür d.19 2011881
6 Verkabelte lampenfassung komplett 2012516
7 Halogenlampe 12v 20w 6061054
8 Verschluss 5900122
9 Einstellstift tür d.20 2011882
10 Zus gebauter schale l/kondenswasser ofen 2011892 11 Zus gebauter serigraphiertes glas für ofen 2011965 12 Zus gebauter schale r/kondenswasser glas 2011888
13 Lampenfassung komplett 6063075
13A Lampenglas 6063077
14 Anschlag x stift türmikroschalter 2011887
15 Gehärtetes glass 5900808
16 Gebläse ofen 310x135 5901023
17 Gebläse 120x120x38 klasse f 6033175
18 Motor as.3ph 80/4 hp1,0 v380 6033155 31/01/2004
18 Motor as.3ph 100L hp1,0/0,35 6034348 01/02/2004
19 Dichtung welle m. 9461-24x46x4 7070151
20 Microschalter zweipolig mit drukknopf VBR0004 6043088 21 Zus gebauter stift türmikroschalter 2011886
22 Dichtung 08716 schwarz x tür 7070166
23 Flammenkontrolle efd 0503xxx 7020085
24 Ventilkörper sit tandem 0830041 7020080
25 Entstörfilter flcs270501 6090057
26 Sonde pt100 schlauch 110x4 kabel 1400 6000083 27 Thermostat 1f sic.350°c 5510562800 6010026
28 Düse x magnetventil 0,25 l/1' 6042095
29 1-wegiges magnetventil mit filter v240 6042070
30 Dichtung x flansch s.u. .58x46 2011777
31 Brenner polidoro 103.2598.10 7090101
32 Flammenerkennungskerze 2012110
33 Zündkerze 2012111
34 Kompl. Bedienblende ofen kon. gk.10gr 2012479
35 Serigraph. Griff für ofen d=6 2012261
36 Einpoliger weisser knopf p12431200000 6032020
37 Kappe x knopf p12 00580055 6032021
38 Schwarzer gegenrahmen p1 p12 00551950 6032022
39 Schalter 2x16a 2pos.4922015700 6030007
40 Steuerplatine umsteuerung 6010084
41 Dreif. Schaltschütz 25a/ac1 b.230v 1l 6046038 42 Transformator str105si-h 11,5/230v 6041065
43 Entstörfilter 411.13.2210 6090050
44 Platine wärmeregler 6010096
45 Platine wärmeregler display 6010095
46 Potentiometer mit kabel 6010097
47 Platine elekt. Buzzer mit winkeln 6010090
48 Zeitgeber 120'logarit. M8 65 6032047
Data ultima modifica: 13/11/2014
GCM0102-R2.xlsGCM0102 CG102MX Revisione 02
POS. E CODICE VALID. SCAD.
1 Junta 15364/p negra x cristal 7070167
2 Asa para puerta horno completa 5900180 01/08/2006
3 Forro interno asa d=36 2011212
4 Puerta completa 2011958
5 Perno sup. Para puerta d.19 2011881
6 Portalámparas cableado completo 2012516
7 Luz alógena 12v 20w 6061054
8 Codillo para cierre 5900122
9 Perno regulación puerta d.20 2011882
10 Cubeta v/agua condens. Horno ens.da 2011892 11 Cristal serigrafiado para horno ens.do 2011965 12 Cubeta r/agua condens. Cristal ens.da 2011888 13 Portalámparas completo lamp.vet.ca. 6063075
13A Cristal para lámparas 6063077
14 Alojamiento para perno micro puerta 2011887
15 Cristal templado para horno 5900808
16 Ventilador horno 310x135 5901023
17 Ventilador 120x120x38 clase f 6033175
18 Motor as.3ph 80/4 hp1,0 v380 6033155 31/01/2004
18 Motor as.3ph 100L hp1,0/0,35 6034348 01/02/2004
19 Junta eje m. 9461-24x46x4 7070151
20 Micro bip. a pulsador VBR0004 6043088
21 Perno micro puerta ens.do 2011886
22 Junta 08716 negra x puerta 7070166
23 Control de llama efd 0503xxx 7020085
24 Cuerpo válvula sit tandem 0830041 7020080 25 Filtro antiparásito flcs270501 6090057 26 Sonda pt100 tubo 110x4 cavo 1400 6000083 27 Termostato 1f seg.350°c 5510562800 6010026 28 Boquilla para electroválvula 0,25 l/1' 6042095 29 Electroválvula 1 via c/filtro v240 6042070
30 Junta para brida s.u. 58x46 2011777
31 Quemador polidoro 103.2598.10 7090101
32 Bujía medición llama 2012110
33 Bujía encendido vap. 2012111
34 Tablero compl.horno conv. gk 10gr cl2 2012479
35 Llave serigrafiada para horno d=6 2012261
36 Tecla unip. Blanca p12431200000 6032020
37 Capucha para tecla p12 00580055 6032021
38 Contramarco negro p1 p12 00551950 6032022
39 Interruptor 2x16a 2pos.4922015700 6030007
40 Circuito control inversión sentido 6010084
41 Contactor trip. 25a/ac1 b.230v 1l 6046038
42 Transformador str105si-h 11,5/230v 6041065 43 Filtro antiparásito 411.13.2210 6090050
44 Circuito termorregulador 6010096
45 Circuito termorregulador display 6010095
46 Potenciómetro con cable 6010097
47 Circuito buzzer eléct. Con escuadras 6010090
48 Temporizador 120'logarit. M8 65 6032047
