On the Quaternary Assembly of Spinach Chloroplast Thioredoxin m

(1)

On the quaternary assembly of spinach chloroplast thioredoxin m

Guido Capitani

^1,∗

& Peter Schürmann

²

1Biochemisches Institut, University of Zürich, 8057 Zürich, Switzerland; ²Laboratoire de Biochimie V´eg´etale, University of Neuchâtel, 2007 Neuchâtel, Switzerland; ^∗Author for correspondence (e-mail:

[email protected]; fax:+41-1-6356834)

Key words: crystal dimer interface, crystallization, NMR, protein crystallography, quaternary assembly, thioredoxin m

Abstract

Thioredoxin m from spinach chloroplast has been structurally characterized both by X-ray crystallography and by NMR. Thioredoxin m is known to be monomeric, a finding which is confirmed by the NMR results. The crystal structure of this protein, however, contains two independent molecules per asymmetric unit. This fact was interpreted as contrasting with the NMR results [Neira et al. (2001) Biochemistry 40: 15246–15256]. Based on computational and biochemical considerations, we show that the presence of two thioredoxin m molecules per asymmetric unit bears no biological significance and does not contrast with the NMR results. The non-covalent arrangement of two monomers found in the crystals represents a ‘crystallization intermediate’ formed under the conditions for crystal growth.

Abbreviations: FPLC – fast protein liquid chromatography; Trx-m – thioredoxin m

Introduction

Thioredoxins are a large family of redox active proteins found in all living cells (Holmgren 1985). Many of the thioredoxin family members, both prokaryotic and eukaryotic, have been characterized structurally, by means of X-ray crystallography and NMR. For four members, both the crystal structure and the NMR structure are available. These are Escherichia coli thioredoxin (Katti et al. 1990; Jeng and Dyson 1994), human thioredoxin (Qin et al. 1994; Weichsel et al. 1996), thioredoxin h from Chlamydomonas reinhardtii (Mittard et al. 1997; Menchise et al. 2001) and thioredoxin m (Trx-m) from spinach chloroplasts (Capitani et al. 2000; Neira et al. 2001). In the case of Trx-m, two crystal structures of the protein, in the oxidized and in the reduced state (PDB codes 1FB6 and 1FB0, respectively), were published first (Capitani et al. 2000) and were followed one year later by the NMR structure of the oxidized protein (PDB code 1GL8) (Neira et al. 2001). Comparison of 1FB6 and

1GL8 showed that the two structures, albeit obtained using different techniques, are remarkably similar (Neira et al. 2001). The asymmetric unit of the Trx-m crystals contains two protein molecules, which form a non-covalent crystal dimer (Capitani et al. 2000). This feature of the Trx-m crystals was presented by Neira et al. (2001) as contrasting with NMR data, which pointed to a monomeric state of the protein in solution.

The goal of the present article is to clarify that the two techniques do not yield contrasting results on the qua- ternary state of Trx-m in solution. In fact, the presence of two molecules in the asymmetric unit is not ne- cessarily indicative of a dimeric state in solution. The analysis of the crystal packing shows that the arrangement of the two molecules in the crystal structure ex- hibits features typical of a crystallization dimer, with no biological significance. It is noteworthy that a similar situation, with two molecules per asymmetric unit and a monomeric biological form, had already been described for C. reinhardtii thioredoxin h (Menchise et al. 2001). In the case of type m thioredoxin from

(2)

Figure 1. Cartoon representation of the two Trx-mmolecules found in the crystal asymmetric unit. The direction of the view is along the non-crystallographic two-fold axis. Figure prepared with SETOR (Evans 1993).

C. reinhardtii, solved by NMR (Lancelin et al. 2000), analysis of the¹⁵N–¹H relaxation data had provided evidence for a monomeric state in solution.

Analysis of the crystal packing of thioredoxin m

The crystals of Trx-m belong to the space group P3121, with comparatively small unit-cell lengths (a=b=74.7 Å, c=74.0 Å) and two molecules per asymmetric unit, with a VM value of 2.6. Trx-m had long been known to be a monomeric protein (Schürmann et al. 1981). The presence of two molecules in the asymmetric unit was reported but not discussed in Capitani et al. (2000) since it was not considered to be a biologically relevant feature. Was this choice justified?

The interface area for the two Trx-m molecules in the asymmetric unit, as calculated with the Protein–

Protein Interaction Server (http://www.biochem.ucl.ac.

uk/bsm/PP/server/index.html) (Jones and Thornton 1996), is 1159 Å². How does this value compare to that of a typical crystal contact interface? Janin and Rodier (1995) studied 1320 pairwise interfaces formed by crystallographic symmetry in 152 crystal forms where the asymmetric unit contains a monomeric protein. The studied pairwise interfaces are therefore a result of the crystallization process and do not possess biological significance. Their average area was calculated to be 570 Å², and the bulk of the values was in the range of 200–1200 Å² (Janin and Rodier 1995). Thus, the value for Trx-m is in the normal range (albeit on the high side) for a crystal-contact interface.

To confirm this indication, the packing of 1FB6 was analyzed using the PQS server (http://pqs.ebi.ac.uk/) (Henrick and Thornton 1998). PQS uses an empir- ical, weighted score of several factors to determine whether the protein contacts are specific (a true macro- molecular oligomer) or non-specific (crystal packing).

The contributing factors are the size of the solvent- accessible surface area buried in the oligomeric

(3)

interaction (asa), the number of buried residues at the interface and the difference in solvation energy of folding (Eisenberg and McLachlan 1986) between the complete assembly and that for each chain, and the number of interchain salt and disulfide bridges (Henrick and Thornton 1998). The PQS prediction for 1FB6 was that the presence of two molecules in the asymmetric unit resulted from a non-specific interaction (OLIGOMER of two independent molecules).

An interesting feature of the Trx-m dimer interface is that it possesses a point-group symmetry, as the two molecules are related by a non-crystallographic two-fold axis (Capitani et al. 2000) (Figure 1). The residues participating in the molecular contacts do not correspond to those found in the asymmetric unit of the C. reinhardtii thioredoxin h crystals (Menchise et al. 2001). In a systematic study of protein–protein interactions at crystal contacts, Wang and Janin (1993) showed that some unexpectedly large interfaces oc- cur in crystals of monomeric proteins, and are nearly always associated with point-group symmetry. The same phenomenon was observed for crystals of monomeric proteins having more than one molecule per asymmetric unit (Wang and Janin 1993; Menchise et al. 2001). Janin and Rodier (1995) pointed out that such comparatively large interfaces, with point-group symmetry, may result from dimeric (or multimeric) intermediates in the crystallization process. Since the interface between the two molecules in the asymmetric unit of Trx-m crystals is on the high side of the range for a non-specific interaction and it does possess two- fold symmetry, we decided to investigate whether a significant percentage of Trx-m dimer could be detec- ted in solution at a concentration and ionic strength similar to those of crystallization.

Biochemical evidence for monomeric state

Trx-m, prepared as described in Schürmann (1995), was analyzed for oligomeric state by analytical gel filtration on a Superdex 75 HR 10/30 FPLC (Amersham Pharmacia Biotech, UK) column (Figure 2). Three different concentrations of the protein (8.4, 27.4 and 55.6 mg/ml) were used, with 100 mM Tris-HCl buffer pH 7.3, 200 mM (NH4)2SO4 and 0.02% (w/v) NaN3 (buffer 1). As a comparison, Trx-m had been crystallized by mixing 1µl of protein (50 mg/ml in 50 mM Tris-HCl buffer pH 7.3 and 0.02% (w/v) NaN3) with 1µl of precipitating solution containing 200 mM (NH4)2SO4, 0.1 M sodium acetate pH 4.6

Figure 2. Analytical gel filtration of recombinant thioredoxin m by FPLC on a Superdex 75 HR 10/30 column. Sample volume: 25µl.

Flow rate: 1.0 ml/min. Buffer 1: 100 mM Tris-HCl buffer pH 7.3, 200 mM (NH₄)₂SO₄ and 0.02% (w/v) NaN₃. Buffer 2: 50 mM Tris-HCl pH 8.0 and 0.02% (w/v) NaN₃. The peak areas were in- tegrated using the FPLC manager software. A – dimer peak; B – monomer peak.

and 30% (w/v) PEG monomethylether 2000 (Capitani et al. 2000). Trx-m crystals formed at a concentration higher than 25 mg/ml, due to the equilibration process in the vapor diffusion method. Buffer 1 provides conditions of comparatively high ionic strength, similar to those of the Trx-m crystallization experiment. Trx- m solutions at the same concentrations as above (8.4, 27.4 and 55.6 mg/ml) but in 50 mM Tris–HCl pH 8.0 and 0.02% (w/v) NaN3(buffer 2) were also prepared and analyzed.

The results of the gel filtrations, as obtained by peak integration, are summarized in Table 1 and

(4)

Table 1. Percentage of Trx-m dimer in different conditions.

Trx-m conc (mM, mg/ml) % dimer, % dimer, buffer 1 buffer 2

0.63 mM, 8.4 mg/ml 12 2

2.00 mM, 27.4 mg/ml 10 5

4.17 mM, 55.6 mg/ml 24 9

clearly indicate that there is a small percentage of dimer, rising with protein concentration, both in buffer 1 and in buffer 2. Thus, there is evidence of a monomer–dimer equilibrium, in which the dimer is a minor species. The amount of dimer is larger (even though still small in absolute terms) in buffer 1 than in buffer 2 (Figure 2), probably due to hydrophobic interactions promoted by the higher ionic strength of buffer 1. Neira et al. (2001) carried out preparative gel filtration on their Trx-m samples in the range of con- centrations 50–200µM (no buffer details were given).

They used a Superdex 75 (26/60) column and did not detect dimerization in the 50–200µM concentration range, which was much lower than that described in this work (0.63–4.17 mM). It is conceivable that, under the conditions explored by Neira et al. (2001), the amount of Trx-m dimer is so low that it is undetectable.

Conclusions

In conclusion, the non-covalent dimeric arrangement in the asymmetric unit of the Trx-m crystals possesses the features defined by (Janin and Rodier 1995) as indicative for a ‘crystallization intermediate’. In fact, the two Trx-m molecules have an interface area in the normal range, but on the high side, for a crystal contact interface. Thus, bioinformatic tools, like the PQS server, recognize this arrangement to be a non-specific dimer, which also possesses point-group symmetry (a two-fold axis). In solution, at high concentration and ionic strength, a monomer–dimer equilibrium is detectable, with small but significant percentages of dimer. It is conceivable that the crystals of Trx-m have assembled from the small amount of dimer present in solution. The dimeric arrangement observed in the asymmetric unit appears, therefore, not to be biologically significant but rather to be a possible

‘crystallization’ intermediate under the conditions for crystal growth. In Capitani et al. (2000), the discussion about the structural and functional properties of Trx-m

assumed that the protein was monomeric in solution.

The presence of two molecules per asymmetric unit was described, but not discussed, since it was considered to bear no biological relevance. That choice appears to be justified in the light of the considerations and results described above.

Acknowledgements

G.C. would like to thank Prof. Markus G. Grütter for support, as well as the Swiss National Center of Competence in Research (Structural Biology) and the Baugarten Foundation, Zürich. Research in the laboratory of P.S. is supported by the Swiss National Science Foundation (Grant no. 3100-67934.02).

References

Capitani G, Markovic-Housley Z, DelVal G, Morris M, Jansonius JN and Schürmann P (2000) Crystal structures of two function- ally different thioredoxins in spinach chloroplasts. J Mol Biol 302: 135–154

Eisenberg D and McLachlan AD (1986) Solvation energy in protein folding and binding. Nature 319: 199–203

Evans SV (1993) SETOR: hardware-lighted three-dimensional solid model representations of macromolecules. J Mol Graph 11:

134–138, 127–128

Henrick K and Thornton JM (1998) PQS: a protein quaternary structure file server. Trends Biochem Sci 23: 358–361 Holmgren A (1985) Thioredoxin. Annu Rev Biochem 54: 237–271 Janin J and Rodier F (1995) Protein–protein interaction at crystal

contacts. Proteins 23: 580–587

Jeng M-F and Dyson HJ (1994) High-resolution solution structures of oxidized and reduced Escherichia coli thioredoxin. Structure 2: 853–868

Jones S and Thornton JM (1996) Principles of protein–protein interactions. PNAS 93: 13–20

Katti SK, LeMaster DM and Eklund H (1990) Crystal structure of thioredoxin from Escherichia coli at 1.68 Å resolution. J Mol Biol 212: 167–184

Lancelin JM, Guilhaudis L, Krimm I, Blackledge MJ, Marion D and Jacquot JP (2000) NMR structures of thioredoxin m from the green alga Chlamydomonas reinhardtii. Proteins 41:

334–349

Menchise V, Corbier C, Didierjean C, Saviano M, Benedetti E, Jacquot JP and Aubry A (2001) Crystal structure of the wild-type and D30A mutant thioredoxinhof Chlamydomonas reinhardtii and implications for the catalytic mechanism. Biochem J 359:

65–75

Mittard V, Blackledge MJ, Stein M, Jacquot JP, Marion D and Lancelin JM (1997) NMR solution structure of an oxidised thioredoxinhfrom the eukaryotic green alga Chlamydomonas reinhardtii. Eur J Biochem 243: 374–383

Neira JL, Gonzalez C, Toiron C, de Prat-Gay G and Rico M (2001) Three-dimensional solution structure and stability of thioredoxin mfrom spinach. Biochemistry 40: 15246–15256

Qin L, Clore GM and Gronenborn AM (1994) The high-resolution three-dimensional solution structures of the

(5)

oxidized and reduced states of human thioredoxin. Structure 2:

503–522

Schürmann P (1995) The Ferredoxin/Thioredoxin System. In:

Packer L (ed) Biothiols, Part B, Vol 252, pp 274–283. Academic Press, Orlando, Florida

Schürmann P, Maeda K and Tsugita A (1981) Isomers in thioredoxins of spinach chloroplasts. Eur J Biochem 116: 37–45

Wang X and Janin J (1993) Orientation of non-crystallographic symmetry axes in protein crystals. Acta Crystallogr D Biol Crystallogr D49: 505–512

Weichsel A, Gasdaska JR, Powis G and Montfort WR (1996) Crystal structures of reduced, oxidized, and mutated human thioredoxins: evidence for a regulatory homodimer. Structure 4:

735–751
