DYNAMIC PROPERTIES OF DISORDERED SOLIDS AT LOW TEMPERATURES

(1)

HAL Id: jpa-00221141

https://hal.archives-ouvertes.fr/jpa-00221141

Submitted on 1 Jan 1981

HAL is a multi-disciplinary open access

archive for the deposit and dissemination of

sci-entific research documents, whether they are

pub-lished or not. The documents may come from

teaching and research institutions in France or

abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est

destinée au dépôt et à la diffusion de documents

scientifiques de niveau recherche, publiés ou non,

émanant des établissements d’enseignement et de

recherche français ou étrangers, des laboratoires

publics ou privés.

DYNAMIC PROPERTIES OF DISORDERED SOLIDS

AT LOW TEMPERATURES

S. Hunklinger

To cite this version:

(2)

JOURNAL DE PHYSIQUE

CoZZoque C5, suppZ6ment au nOIO, Tome 4 2 , octobre 1981 page c5-595

D Y N A M I C PROPERTIES O F DISORDERED

SOLIDS

A T LOW TEMPERATURES

S. Hunklinger

Max-PZanck-Institut fiir Festkiirperforschung, Heisenbergstr. 1, 0-7000 S t u t t g o t 80, F.R.G.

Abstract.

-

Disordered solids exhibit a variety of unusual low twrperature properties. They are caused by low-energy excitations whose physical nature is still not fully understood. In this review, mainly measurements of the acoustic and dielectric properties of disordered solids are discussed, since these experiments have turned out to be very useful in investigating the origin of these anomalies.

1. Introduction.- During the last ten years amorphous solids have moved from a fringe zone to the center of interest in solid state

science. In particular there have been intense efforts to understand the anomalous low temperature properties of glasses. These anomalies are unexpected for the following reason. At low temperatures the thermal behaviour of pure dielectric solids should be determined by acoustic phonons of long wavelength. Below 1 K the wavelength of the corresponding dominant phonons is larger than 1000

2

and therefore much larger than the scale of the microscopic disorder. As a consequence, at these temperatures and below there should be hardly any difference between the thermal properties of amorphous and crystallipe dielectrics. Although there is great regularity in the thermal proper ties of amorphous materials, their behaviour

-

in contrast to expecta- tion

-

is completely different from that of pure crystalline substances. This contradictory aspect has stimulated not only extensive work on thermal properties but also a new sequence of quite different investigations on the mechanical and dielectric properties of glasses below 1 K.

In this paper we will first describe the rather unexpected thermal and dynamic behaviour of nearly all glasses at low temperatures. Subsequently we will consider substances which are crystalline but contain defect states and finally a theoretical microscopic model is reviewed.

2. Specific Heat of Glasses at Low Temperatures.- As mentioned above the low temperature specific heat of pure dielectric solids was expect-

(3)

JOURNAL DE PHYSIQUE

ed to be determined by acoustic ghonons of long wavelength. Then, according to Debye's theory, the specific heat C should be proportion-

3

a1 to T

.

Incorporation of impurities should enhance the specific

heat, but only in a limited temperature range. About ten years ago Zeller and Pohl /I/ discovered that many insulating glasses show an unexpected linear term in the specific heat below 1 K. This linear term not only dominates the contribution of thermal phonons but is hardly influenced by the incorporation of impurities / 2 / . A t a temperature of 25 m K the measured specific heat of vitreous silica /3/ exceeds the Debye contribution of the phonons by more than a factor of

1000! More recently it has been demonstrated that superconducting

amorphous metals also behave in a similar way /4/ even well below the transition temperature where the electronic specific heat can be neg- lected. This result strongly indicates that electrons do not contribute to the extra specific heat but that instead atomic motions may be responsible in amorphous insulators as well as in amorphous metals. In this context it is interesting to mention that a linear specific heat

has also been found in crystalline ionic conductors (for example in D-

alumina /5/) or quenched single crystals (for example in NbZr / 6 / ) in- dicating that these materials are at least partially in a "glassy" state of disorder. We will discuss this point in more detail later.

The large extra specific heat clearly demonstrates the existence of a new type of low-energy states which is specific to the disordered state and does not exist in pure crystals. Surprisingly not only the temperature dependence of this extra specific heat is similar for all amorphous materials but also its magnitude. Frome these results one arrives at the conclusion that all these disordered solids contain

-

3

roughly l 0 I 7 low energy excitations per cm uniformly distributed in the energy interval from 0 to 1 K. The total number of excitations is, however, probably considerably higher, since the density of states extends to higher energies and seems to increase quadratically / 2 / .

Unfortunately no reliable estimate of this number can be given since at higher temperatures the extra specific heat is masked by the contribution of ordinary phonons.

Most of these low energy excitations interact

-

as we will see

-

stronqly with the amorphous network, i.e. with the phonon modes. But for an appreciable number the interaction time with the "lattice" is much longer than 1 us and extends to at least 1000 s. Consequently the specific heat depends on the time of measurement. Successful ob-

servations of such a time dependent heat capacity have recently been

(4)

3. Ultrasonic Properties of Insulating Glass=.- Attenuation / 8 / as well as velocity /9/ of an ultrasonic wave are strongly affected by the interaction with these low-energy excitations. As a typical

Q

TEMPERATURE

~ K I

Fig. 1 : Temperature dependence of the attenuation of longitudinal acoustic waves of two different intensities in vitreous silica. The full squares indicate the temperature independent attenuation in a pure quartz

crystal (from /lo/)

.

example, in Fig. 1 the attenuation of hypersonic waves is shown versus tem-

perature /lo/. Let us first focus

our attention to temperatures below

1 K. A characteristic dependence on the acoustic intensity J is observed: At higher intensities the ultrasonic

- -

loss vanishes with decreasing temperature; at very low power levels the absorption increases again. This observation immediately rules out harmonic oscillators being

responsible for the attenuation. It is compatible with the assumption

that the ultrasonic absorption is caused by resonant transitions between two energy levels: At higher acoustic intensities both levels reach eaual population because of the finite lifetime in the excited state (of the order of 10 us in our example) and consequently the absorption falls. The population also varies with increasing temperature. In fact, the temperature dependence of the absorption a at low intensities /11/ (a = cl~tanh h w / 2 k T ) and its intensity dependence /12/

(a Q 1/fi) strongly support that two level systems and not multi-level

systems are present in glasses /13/.

The two-level systems also cause the steep rise of the attenuation at higher temperatures / 1 4 / . The sound wave modulates the level splitting of the two-level systems and thus disturbs the thermal equilibrium. The systems try to relax into the new equilibrium via the emission or absorption of thermal phonons. The resulting absorption is intensity independent since all thermally populated two-level systems contribute to this process. At low temperatures ( T < 4 K) and hypersonic frequencies the condition W T >> 1 holds in silicate

glasses, where T is the relaxation time necessary for a two-level

(5)

C5-5 98 JOURNAL DE PHYSIQUE

dependence of the relaxation rate. Since a = T~ is observed experi- -3

mentally /15/ it follows that T E

.

This result is again in agree-

ment with the assumption that two-level systems are responsible for

the acoustic properties of glasses /13/. In summary, the ultrasonic

absorption observed in glasses at low temperatures is caused by the interaction of the sound wave with a broad distribution of low energy excitations which are best described by two-level systems.

1

3 0 R O I I L I C A T E GLASS B I O

i

2 +?" 30 MHz

+*

0 , y--- T

Fig. 2: Relative variation of longi- budinal and transverse sound velocity Av/v in borosilicate glass BK7,

plotted as a function of temperature. The dashed-dotted lines are theoretical fits taking into account both the resonant and the relaxation interaction. The solid squares show for comparison the variation of sound velocity in a quartz crystal

(from /13/).

Since the ultrasonic absorption depends on temperature the same must be true also for the velocity of sound since both quantities are link- ed by the Kramers-Kronig relation. Fig. 2 shows the temperature depen- ence of the velocity of sound in a A

TEMPERATURE [K] _{borosilicate glass for both longitu-}

dinal and transverse sound waves /13/. In agreement with the Kramers- Kronig relation the sound velocity varies logarithmically with tempera-

ture below 1 K where the resonant absorption is dominant. At higher

temperatures the contribution of the relaxation process predominates and the velocity decreases again. From the slope of the curve at 0.3K we can directly determine the product, density of states of the two-

level systems times the coupling strength. This result is of im-

portance in the discussion of the thermal conductivity. Interestingly the velocity of sound or the corresponding elastic stiffness of

glasses decrease on cooling in contrast to that of crystalline materials which generally show no variation or the opposite behaviour at temperatures below 1 K.

4. Thermal Conductivity of Insulating Glasses.- In glasses thermal

phonons are also scattered by two-level systems. Thus the thermal conductivity is limited to values much lower than that one of the corresponding crystalline materials. The heat conduction is proportional to

(6)

3

classical T -dependence and the mean free path R of phonons at thermal

-

1

frequencies w

-

kT/'h. Since a a R a wtanh .hw/2kT a T (for details see ref./l3/) the thermal conductivity of glasses should vary as T~ in agreement with the observations /1-6/. Interestingly, the strength of the coupling hetween acoustic waves and two-level systems is of the same order of magnitude in all silicate and chalcogenide glasses. Con- sequently the heat conductivity of all these substances is almost identical below 1 K. Even glassy polymers and the lattice contribution of metallic glasses behave in the same way.

5. Dielectric Behaviour of Insulating Glasses.- If one places a sample of vitreous silica into a microwave cavity in order to investi- gate the interaction of electromagnetic waves with the two-level systems, observations almost identical with those in acoustic measurements become apparent. This is demonstrated by Fig. 3 where the di-

I I VITREOUS SILICA

-

e10-3k

A J = 0.7 mWlcm2 J=20 mWlrrm2 a \

.

CRYSTAL

Fig.:

Temperature dependence of the dielectric absorption in vitreous silica Suprasil I (1200 ppm OH) for microwaves of 10 GHz. As in the acoustic case the lower curve repre- sents the saturated absorption and the upper curve the attenuation in the unsaturated regime. The full squares show the negligible attenuation in a pure quartz crystal (from ref. /lo/).

P

i

Yl

electric absorption of microwaves of

W

>

Z - 10 GHz in vitreous silica Suprasil I

-

U

-

_a:

t,

W --r 0

f =10GHz is plotted versus temperature. The

complete analogy becomes obvious by comparing Fig. 1 and 3. Neverthe-

W

a 02 O L 1 2 L

TEMPERATURE

[KI

lo

less, there is an important difference. The magnitude of the dielectric loss depends on the amount of ionic or dipolar substances incor- porated in the matrix of the glass. Thus the loss in borosilicate

glass or Suprasil I (which contains roughly 1200 ppm of OH-impurities)

is much higher than in highly pure vitreous silica (Suprasil W) or in

As2S3. In short, the magnitude of the dielectric loss

-

in contrast

to the acoustic loss

-

is not a universal property.

Similar to the variation of the velocity of sound in the acoustic case, a temperature dependent velocity of light is observed. In Fig.

4 the variation of the dielectric constant E (which determines the

light velocity in the solid) is shown for vitreous silica (Suprasil W)

(7)

C5-600 JOURNAL DE PHYSIQUE

TEMPERATURE [ K1 I-

z

Fig. 4: Variation of the di-

liquids. Here again the temperature dependence, i.e.

2

Z

8

o

u

E I- -0.5

3 -

4

52

X 0 w - l

%

- 1 . 5 -

Q

I-

5

CK 6

the slope of the curve in Fig. 4 is steeper the higher the content of polar impurities. Clearly, of all the low-energy excitations present in the glass sample only those are "seen" by the electric field which carry electrical dipoles or charges.

6 .

-

Coherent Excitation of Two-Level Systems at Ultra Low Temperatures.

I I- -& . *'t: A : ^.AA A52 S3 A

*.

A . - A A A A A A ~ ~

7.

. SUPRASIL W • l

.*

*...

So far we have discussed the interaction of the two-level systems with external elastic or electric fields. But an interaction also exists among the two-level systems which is probably elastic in origin. This additional aspect is taken into account by using the Bloch equations in order to describe the dynamical behaviour of the two-level systems

I . In analogy to paramagnetic ions in a magnetic field we have to

distinguish between TI and T2, the longitudinal and transverse relaxation time, respectively. T I is the spontaneous lifetime caused by the emission or absorption of thermal phonons and is identical with the relaxation time we have discussed so far. T2 is determined by the interaction between the two-level systems.

In principle both quantities can be measured by applying more than one acoustic or electric pulse to the sample. The analysis of such experiments is, however, complicated by the fact that spectral diffusion plays an important role in glasses / 1 8 / . A more convenient way is to cool down the sample to the Millikelvin range. There the

relaxation times are lonq enough to exceed the duration of applied acoustic or electromagnetic pulses. Under this condition the two- level systems can be excited coherently, i.e. a macroscopic elastic or electric polarization is generated in the sample and different techniques are available to study this quantity. Here we only want to

electric constant with temperature in vitreous silica Suprasil W ( < 5 ppm OH) and vitreous As2S3 at 1 0 G H Z

(from / 1 6 / ) .

the resonant interaction predominates and the lower the temperature the higher the dielectric constant or electric polarizability. This is quite contrary to the standard bchaviour of

>

05 1 2 5 10 '

(8)

mention the measurement of its decay ("free induction decay"), the generation of echoes (spontaneous as well as stimulated echoes), and the investigation of self-induced transparency (in sound propagation)

/ I 9/-

Echoes in glasses have been studied in many experiments /20/. Thus T I and T2 have been measured in vitreous silica down to temperatures

of

4 mK /21/. Here we want to discuss another aspect: It is well-known that the dipole moment of the interacting system can be deduced from the maximum in the amplitude of the spontaneous echo, which is obtained by varying the applied field strength. In Fig. 5

the result of such an experiment at 19 mK is shown for vitreous Fig. 5: Amplitude of the spontaneous echo (arbitrary scale) versus 0.72 GHz electric field amplitude for four different silica glasses. OH-free glasses

(Suprasil W and Infrasil) show a single maximum but OH-containing glasses (Herasil and Suprasil I)

show a second echo maximum proportional to OH-content (from /22/).

silica containing different impurities /22/. All samples exhibit a maximum at a relative field amplitude of 0.3. A second maxi-

ReIative Electric FieId AmpIitude _mum_at_{0.04 is present if the}

sample contains OH-impurities. This result supports the interpreta- tion of measurements of the dielectric properties. Obviously the two- level systems in vitreous silica exhibit an electrical dipole moment which is enhanced if they carry a polar impurity.

7. Glassy Metals.- As already mentioned above, amorphous superconducting metals exhibit a linear specific heat well below Tc /5,23/. Since its magnitude is comparable to that in ordinary glasses it seems that two-level systems are present also in amorphous metals in roughly the same number as in vitreous silica. Below 1 K the heat conduction

2

(9)

JOURNAL DE PHYSIQUE

But there is a basic difference: The saturation effect is observed at much lower temperatures and, even more important, saturation occurs at completely different acoustic intensities. While in vitreous silica the resonant absorption at 1 GHz and 0.5 K becomes saturated at

an intensity of w/cm2 one needs an intensity which is three

orders of magnitude higher in PdSi at 0.06 K /26/. This demonstrates

that in normal conducting metals the relaxation times are

-

probably

by the presence of the conduction electrons

-

shortended by several

orders of magnitude relative to ordinary glasses, where the two-level system can only relax via phonons.

If the conduction electrons are condensed to Cooper-pairs by cooling a supexconducting amorphous metal well below Tc one would pre- dict /27/ that the relaxation time should increase by several orders of magnitude finally reaching the value of ordinary glasses. There- fore a drop in the relaxation absorption is expected at Tc since below these temperatures the condition w~ >> 1 should hold. In Fig. 6 we

P d 3 o Z r 7 a Longitudinal 13CO MHz o 7&0 MHz A

*

H

=

8

Tesla - 0.3 1 3 10 30 100 T E M P E R A T U R E

[KI

Fig. 6: Ultrasonic absorption of longitudinal acoustic waves in Pd30Zr70 versus temperature. The triangles re- present the observed attenuation under magnetic field

(from /28/)

.

show the ultrasonic absorption in amorphous PdZr /38/. The most striking feature is that at Tc there is no change of the absorption. It only falls well below Tc. This result demonstrates how effective free electrons are in reducing the relaxation time of two-level systems: Although the number of unpaired electrons

drops rapidly below Tc those which are left over, are still capable of

shortening the relaxation time to such an extent that the condition w~ > 1 is not fulfilled until T = Tc/2 is reached. At the lower temperatures phonons determine the relaxation rate. Applying a magnetic field of 8 Tesla makes this sample normal conducting and the unpaired electrons give rise to a strong absorption down to the lowest temperatures.

(10)

amorphous materials. We have already mentioned that the fast ionic conductor a-alumina and quenched crystals of NbZr also show a linear specific heat / 5 , . 6 / . These materials also show a thermal conductivity and acoustic properties very similar to those of ordinary glasses. Here we want to discuss briefly two experimental results, namely the velocity anomaly of the fast ionic conductor Li3N and of quenched NbZr.

In Fig. 7 the variation of the sound velocity with temperature is shown for Li3N / 2 9 / . Qualitatively the behaviour is the same as that

Li3N Fig. 7: Relative velocity change Av/v

of

a

longitudinal sound wave propa- gating perpendicular to the c-axis of Li3N (from / 2 9 / )

.

,

1

of glasses (see Fig. 2 ) , but there

r> are quantitative differences: the

%

2

position of the maximum is shifted to

LU

o

2 - lower temperatures by a factor of

W

0 five and the slope of the logarithmic

z

2

rise is considerably smaller than in

0 0 ' _{glasses. It seems that the density}

0.03 0.1 0.3 1

TEMPERATURE

CK]

of states of the two-level systems is

considerably smaller than in ordinary amorphous substances. In Fig. 8 the velocity is plotted for rapidly quenched NbZr / 3 0 / . For the first time the variation of the velocity

of sound was observed in a superconducting material exhibiting the low

temperature anomalies. Below 1 X' two remarkable features are found: The absolute value of the velocity as well as the slope of the rise depends on the state of the sample, normal or superconducting. This is a consequence of the relaxation process whose contribution to the

2

-

'

,

t != U w

9

0 > 0 -1 z 3 o 0.4 LL. 0

y

0.2 z 5 SO

0.4 1 2 4 20 tively strong in the normal

TEMPERATURE [KI state since unpaired elec- Fig. 8: Relative velocity

- 2

-

change of longitudinal sound at 30 MHz in rapidly quench-

ed Nb20Zr80. A magnetic

field of 8 Tesla was applied

0 to reach the normal conduct-

ing state. For the inset the

-,

values of the superconduct-

ing state arz shifted by

-

0.85 x 10- (from /30/).

-2

velocity is negligible in

-3

the superconducting state - - 4 (since w-c >> 1 ) but is rela-

(11)

JOURNAL DE PHYSIQUE

trons enhance the relaxation rate.

There are several additional examples which demonstrate that a distribution of two-level systems can exist in crystalline materials. In all cases these crystals exhibit either disordered sub-structures

(as for example 13-alumina), randomly distributed defects (as in the case of neutron irradiated quartz crystals /31/) or contain metastable

phases (as in quenched NbZr). Although disorder is a necessary condi-

tion, it is not sufficient: Recent experiments on the one-dimensional ionic conductor Hollandite show no linear specific heat /32/. In summary, low temperature anomalies similar to those in amorphous materials can also occurs in crystalline materials, but the exact pre- suppositions are not yet known.

9. On the Nature of the Low Energy Excitations.- The universality of these low temperature anomalies suggests that the two-level systems in amorphous solids must be a natural consequence of the metastable state of glassy materials, which have many configurational minima of the free energy, which are almost but not exactly equivalent. In a simple approximation it has been proposed / 3 3 / that in amorphous solids cer- tain atoms or groups of atoms are able to move in a double well poten-

cannot

tial. At low temperatures these particles jump over the barrier between the two wells. Instead they are thought to be able to go from one well to the other by quantum mechanical tunneling. Because of the randomness of the amorphous network the parameters of the different tunneling systems are expected to vary slightly. The basic assumption /33/ is now, that the asymmetry in depth of the minima as well as the

resulting t~nnel~splitting, are uniformly distributed. This assump-

tion leads to good agreement with all the experiments described above. The nature of the tunneling particles, however, is not yet known. In vitreous silica it is likely /34/ that the rotary motion of a Si04- tetrahedron is responsible. This motion is probably made feasible by the bending softness of the hridging oxygen bonds. In other materials one can find clusters of similar size which can rotate from one mini- mum position to the next without an excessive energy barrier between both positions. In this view it is not surprising that in amorphous silicon and germanium where cluster formation does not seem to be possible two-level systems apparently do not exist either /35/.

(12)

usually be attributed to well-defined defects. However, it is completely unclear why under such circumstances a broad distribution of tunneling splitting exists.

10. Summary.- In summary we want to say that disordered solids at low

temperatures exhibit many properties that are fundamentally different from those of perfect crystals. In amorphous materials thermal and acoustic properties are insensitive to the chemical composition to a large extent and seem to be a characteristic of the glassy state. In disordered crystals the magnitude of the anomalies can in generally be varied by varying the content of impurities, the duration of irradia- tion etc. Dielectric measurements, however, are very sensitive to specific impurities and provide additional information on the nature

of low-energy excitations. Although the formal phenomenological

description of the observations in terms of "two-level systems" has been very successful, we have to admit that we are still far from a complete understanding of the low temperature properties of disordered solids on an atomic scale.

Acknowledgements.- The author is grateful to T. Baumann, K. Dransfeld, M. v. Schickfus, and G. Weiss for many stimulating discussions.

References

.

-

/

I/ R.C. Zeller, R.O. Pohl: Phys. Rev. B?, 2029 (3971)

/

2/ R.B. Stephens: Phys. Rev. Bg, 2896 (1973)

/

3/ J.C. Lasjaunias, A. RaveY, M. Vandorpe, S. Hunklinger: Solid State C m u n .

17,

1045 (1975)

/

4/ J.E. Graebner, B. Golding, R.J. Schutz, F.S.L. Hsu, H.S. Chen: Phys. Rev. Lett.

2,

1480 (1977)

/

5/ D.B. McWhan, C.M. Vanna, F.L.S. Hsu, J.P. Faneika: Phys-Rev. B15, 553 (1977)

_-

/

6/ L.F. Lou: Solid State Ccanrmn.

19,

335 (1976)

/

7/ M.T. Loponen, R.C. Dynes, J.P. Garno, V. Narayanamurti: Phys. Rev. Lett. 45, 457 (1980); M. Meissner, K. Spitzmann: Phys. Rev. Lett.

5,

265 (1981);

JF

Z ~ G. Weber: Phys. ~ Rev. , Lett.

46,

661 (1981)

/

8/ S. Hunklinger, W. Arnold, S. Stein, R. Nava, K. Dransfeld: Phys. Lett. A s , 263 (1972); B. Golding, J.E. Graebner, B.I. Halperin, R.J. Schutz: Phys. Rev. Lett. 30, 223 (1973)

/ 9/ L. pic=, R. Maynard, S. Hunklinqer, J. Jkickle: Phys.Rev.Lett.32, 1426 (1974) /lo/ S. Hunklinger: Festkijqerprobleme (Adv. Solid State Phys.) 17, 1 (1 977) /11/ B. Golding, J.E. Graebner, R.J. Schutz: Phys. Rev. B s , 166F(1976)

/12/ W. Arnold, S. Hunklinger, S. Stein, K. Dransfeld: J. Non Cryst. Solids

14,

192 (19741

/13/ S. ~unkl&ger, W. Arnold: In physical Acoustics, ed. by W.P. Mason, R.N. Thurston (Academic, New York 1976)

,

Vol. X I I , p. ,155

/14/ J. Jackle: Z. Phys. 257, 212 (1972)

/15/ J. Jackle, L. ~ i c ~ e , X Amold, S. Hunklinger: J. Non Cryst. Solids

20,

365 (1976)

/16/ S. Hunklinger, M.v. Schickfus: In Topics in Current Physics, ed. by. W.A. Phillips (Springer, Berlin-Heidelberg), Vol. 24, p. 81

/17/ J. Joffrin, A. Levelut: J. Phys. Paris Lett.

36,

811 (1975)

/18/ W. Amold, C. Ma-rtinon, S. Hunklinger: J. Phys. Paris 39, C6-961 (1978) /19/ B. Golding, J.E. Graebner: Phys. Rev. Lett.

2,

852 (1976)

(13)

C5-606 JOURNAL DE PHYSIQUE

/21/ L. Bernard, L. Pichg, G. Schmacher, J. J o f f r i n , J. Graebner: J. Phys. P a r i s Lett.

2,

126 (1978)

/22/ B. Golding, M.v. Schickfus, S. Hunklinger, K. Dransfeld: Phys. Rev. Lett.

43,

1817 (1979)

/23/ H.v. khn&sen, M. P l a t t e , W. S d e r , H . J . Schink, G.v. Minnigercde, K. Samwer: J. Phys. P a r i s

41,

C8-745 (1980)

/24/ J.R. Matey, A.C. Anderson: Phys. Rev. B E , 3406 (1977) /25/ G. Bellessa: J. Phys. P a r i s

41,

C8-723 (1980)

/26/ B. Golding, J.E. Graebner, A.B. Kane, J.L. Black: Phys. Rev. Lett.

41,

1487 (1978); P. Doussineau, P. Legros, A. Levelut, A. Fobin: J. Phys. P a r i s Lett.

39, 265 (1978)

/27/

ZL.

Black, P. FUlde: Phys. Rev. Lett.

43,

453 (1979)

/28/ G. W e i s s , W. Arnold, K. Dransfeld, H . J . Giinthercdt: Solid S t a t e C m u n .

2,

11 (1980) ; G. Weiss, thesis, Konstanz (1981)

/29/ T. Baumann, M.v. Schickfus, S. Hunklinqer, J. Jzckle: Solid S t a t e Cannun.

35,

587 (1980)

/30/ G. Weiss, S, Hunklinger, H.v. Uhneysen: Phys. Lett. A (1981) t o be published

/31/ C. Laemans: Phys. Rev. L e t t . 42, 250 (1979)

/32/ H.v. Ghneysen, H.J. Schink, ~ Y A r n o l d , H.U. Beyeler, L. Pietronero, S. Strass-

ler: Phys. Rev. Lett.

46,

1213 (1981)

/33/ P.W. Anderson, B.I. Halperin, C. Vanna: Phil. Mag.

2,

1 (1972); W.A. Phillips:

J. Icw Tap. Phys.

1,

351 (1972)
