Plasmodium falciparum var Genes Are Regulated by Two Regions with Separate Promoters, One Upstream
of the Coding Region and a Second within the Intron
Amy Jost, Jianbing Mu, Michael Calderwood, Laila Gannoun-Zaki, Thomas Wellems, Kirk Deitsch
To cite this version:
Amy Jost, Jianbing Mu, Michael Calderwood, Laila Gannoun-Zaki, Thomas Wellems, et al.. Plasmod- ium falciparum var Genes Are Regulated by Two Regions with Separate Promoters, One Upstream of the Coding Region and a Second within the Intron. Journal of Biological Chemistry, American Society for Biochemistry and Molecular Biology, 2003, 278 (36), pp.34125-34132. �10.1074/jbc.M213065200�.
�hal-02281911�
Plasmodium falciparum var Genes Are Regulated by Two Regions with Separate Promoters, One Upstream of the Coding Region and a Second within the Intron*
Received for publication, December 20, 2002, and in revised form, June 27, 2003 Published, JBC Papers in Press, June 27, 2003, DOI 10.1074/jbc.M213065200
Michael S. Calderwood‡, Laila Gannoun-Zaki‡, Thomas E. Wellems‡, and Kirk W. Deitsch§¶ From the ‡Laboratory of Malaria and Vector Research, NIAID, National Institutes of Health, Bethesda, Maryland 20892 and §Weill Medical College of Cornell University, New York, New York 10021
Antigenic variation in Plasmodium falciparum ma- laria parasites results from switches in expression among members of the multicopy var gene family. This family is subject to allelic exclusion by which particular genes are expressed while the rest of the family remains transcriptionally silent. Evidence from reporter con- structs indicates that var gene silencing involves a co- operative interaction between the var intron and an upstream element and requires transition of the para- sites through S-phase of the cell cycle. These findings implicate chromatin assembly in the process of regulat- ing var gene expression and antigenic variation. Here we characterize the var intron and the elements within it that are necessary for var transcriptional silencing.
Alignments of var introns show a highly conserved structure that consists of three discreet regions with distinct base pair compositions. The middle region is highly AT-rich and is sufficient to silence an associated var promoter. Constructs that include a typical var in- tron upstream of a reporter gene or drug-selectable marker reveal that the intron also possesses promoter activity, presumably providing an explanation for the origin of the previously described var “sterile” tran- scripts. Deletions that disable the promoter activity of the intron also eliminate its ability to function as a si- lencer. These findings suggest that interactions between the regions of these two promoters and the generation of the sterile transcripts play a significant role in regulat- ing var gene expression.
The deadliest form of malaria is the result of infection by the protozoan parasite Plasmodium falciparum. The disease is characterized by recurrent waves of parasitemia in which each wave represents a population of infected red blood cells with distinct antigenic properties and cytoadherent phenotypes (1).
The parasites in these waves use a mechanism of antigenic variation to switch among major variable parasite-produced proteins (PfEMP1) that are placed on the surface of the infected host red blood cells. These switches allow parasites to escape
clearance by the host antibody response, leading to persistent infections of variable severity. Antigenic variation thus ensures against the elimination of P. falciparum by interfering with the development of complete anti-PfEMP1 immunity.
PfEMP1 is encoded by a multicopy gene family termed var (2– 4). About 60 different var genes are present within the haploid genome of each parasite (3, 5), encoding forms of PfEMP1 with unique antigenic and cytoadherent properties.
Switches in expression between individual members of the var gene family account for the antigenic variation in a P. falcipa- rum population over the course of an infection (4). A mecha- nism of allelic exclusion appears to control expression of the individual genes (6, 7), thus enabling the parasite population to survive. Without such exclusion, expression of all copies simul- taneously would result in premature expenditure of the anti- genic repertoire, whereas incomplete silencing of previously expressed copies would lead to clearance by antibodies gener- ated against them. The molecular mechanisms responsible for activating and silencing the genes within this family, and thus coordinating the process of antigenic variation, therefore rep- resent a process imperative for parasite survival.
Although gene duplications, deletions, and recombinations within the family are not uncommon, switches in expression were not found to be accompanied by promoter DNA sequence alterations (8). Silent promoters were shown to be rendered transcriptionally active when removed from the chromosome and placed on transfected episomes (8). These results indicated that switches in expression were probably not the result of changes in transcription factors. Silencing of episomal var pro- moters was restored, however, when a var intron was also incorporated into the transfected plasmid (9). Silencing be- cause of the presence of the intron was specific to var promoters and depended upon transition of the transfected parasite through S-phase of the cell cycle. These findings associate control of var expression with changes in chromatin structure and epigenetic mechanisms of regulation that may have some features in common with chromatin-mediated gene regulation in other organisms.
Members of the var gene family are found in tandem arrayed clusters within the internal regions of chromosomes 4, 7, 8, and 12 and as individual genes within subtelomeric regions that also contain genes of the rifin and stevor families (1, 10). In both internal and subtelomeric regions, transcriptionally active var genes have been found adjacent to silent copies, indicating that chromosomal position does not dictate expression. Gene clusters appear to be partitioned into transcriptionally active and silent regions. Chromatin “boundaries” or “insulators” typ- ically separate such regions to prevent the spread of silent and active chromatin structure into adjacent regions and to prevent inappropriate “cross-talk” between the regulatory elements of
* This work was supported by National Institutes of Health Grant AI 52390. The Department of Microbiology and Immunology at Weill Med- ical College of Cornell University acknowledges the support of the William Randolph Hearst Foundation. The costs of publication of this article were defrayed in part by the payment of page charges. This article must therefore be hereby marked “advertisement” in accordance with 18 U.S.C. Section 1734 solely to indicate this fact.
¶A Stavros S. Niarchos Scholar. To whom correspondence should be addressed: Dept. of Microbiology and Immunology, Weill Medical Col- lege of Cornell University, 1300 York Ave., W-704, Box 62, New York, NY 10021. Tel.: 212-746-4976; Fax: 212-746-4028; E-mail: kwd2001@
med.cornell.edu.
Printed in U.S.A.
This paper is available on line at http://www.jbc.org
34125
This is an Open Access article under the CC BY license.
FIG. 1. Sequence alignments and nucleotide composition analysis of var introns from the subtelomeric and internal regions of different P. falciparum chromosomes. A, the intron sequences align into three distinct regions with prominent asymmetry in strand composition. Conserved repeats 5⬘-TGT(G/A)T(G/A)TG-3⬘ are found only in region 1, whereas copies of the complementary repeat 5⬘-ACA(C/T)A(C/
T)AC-3⬘ are found only in region 3 (shaded). Conserved GT and AG dinucleotides at the intron splice boundaries are highlighted in reverse.
Conserved repeat elements containing a putative initiator element are boxed, and the Inr-like initiator sequence (TCATA) is shaded. A similar conserved potential initiator element found on the opposite strand is underlined. GenBankTMsequence accession numbers (leading number of each label indicates the assigned chromosome): 1a, AL031747; 2a, AE001366; 2b, AE001434; 3a, AL034560; 3b, AL034559; 4a, AL035477; 7a, L40608;
7b and 7c, L40609; 12a, AC006279; 12b, AC006280. B, histograms showing base pair compositions of the forward strand of the three regions of the intron. Region 1 contains⬇20% G and 1% C content in the forward strand, whereas region 3 contains 2% G and 18% C. Contrasts are evident also in the T and A composition of these regions. Region 2 of the forward strand contains⬎70% A content.
Two Separate Promoters Control var Gene Expression
34126
genes in close proximity to one another (11, 12). As a result, DNA elements that function as silencers are frequently found to include boundaries so as not to influence the transcriptional activity of adjacent genes. A number of boundaries and insula- tors have been identified and studied in several eukaryotic organisms; they vary greatly in their sequence and structure.
Several of these elements have been shown to contain binding sites for characterized proteins, including transcription factors or RNA polymerase complexes (11). A few, including the scs and scs⬘ elements in Drosophila (13) and several elements described in yeast, have been shown to include functional pro- moters associated with active transcription (14, 15). Exactly how these binding sites and transcriptional activity relate to gene silencing or boundary/insulator activity is not yet fully understood.
Here we describe experiments indicating that each var gene contains two functional promoters, the first upstream of var exon I and the second within the intron. The upstream pro- moter contains an initiator element at a transcription start site similar to the metazoan Inr sequence that has also been found in Trichomonas vaginalis parasites. Comparative alignments show that var introns exhibit a conserved architecture consist- ing of three regions differing in base pair composition. Dissec- tion of a typical var intron demonstrates that these regions have different effects on var silencing, particularly the AT-rich central region, which alone is sufficient to silence the upstream var promoter. This central region is also necessary for the promoter activity of the intron, which presumably gives rise to the previously identified “sterile” transcripts associated with the intron and var exon 2 (3, 16). Deletions that remove the promoter activity of the intron also impair its ability to function
as a silencer. These results provide the first evidence that the intron promoter and sterile transcripts play a role in var gene regulation and allelic exclusion in P. falciparum.
EXPERIMENTAL PROCEDURES
Parasite Cultivation and Gradient Purification—The P. falciparum parasite line Dd2 was cultivated at 5% hematocrit in RPMI 1640 me- dium supplemented with 0.5% Albumax II (Invitrogen), 0.25% sodium bicarbonate, and 0.1 mg ml⫺1gentamicin. The cultures were kept under an atmosphere of 90% nitrogen, 5% oxygen, and 5% carbon dioxide at 37 °C. Percoll/sorbitol gradient purification (17) was performed by lay- ering 3 ml of 40% Percoll/6% sorbitol/RPMI 1640 medium over 3 ml of 70% Percoll/6% sorbitol/RPMI 1640 medium in a 15-ml centrifuge tube.
One ml of parasitized erythrocytes at 50% hematocrit was layered on top of the gradient, the gradient was centrifuged at 12,000⫻ g for 20 min at 20 °C, and the cells at the gradient interface were recovered and washed twice with 10 volumes of complete media. Microscopic evalua- tion of the recovered cells verified that they were over 95% infected with late stage parasites, and these cells were reintroduced into culture.
For drug resistance assays, the parasite line 3D7 was transfected with pVLH/IDH as described above, then cultured in media containing 40 ng/ml pyrimethamine (18). Plasmid rescue experiments were per- formed by transforming Escherichia coli-competent cells with 100 ng of purified P. falciparum genomic DNA (19).
Luciferase Expression Constructs—The plasmids pVLH-1 (8) and pVLH/int (9) have been described. The sequence of the intron used in the pVLH/int construct is shown in Fig. 1A (labeled 2b). Various por- tions of this intron were amplified by using specific primers that had been modified to include a BamHI site on the 5⬘ end and a NotI site on the 3⬘ end. Such primers were used to amplify region 2 (bp 141–712 of the intron), region 3 (bp 687–762), regions 1 and 2 (bp 1–712), and regions 2 and 3 (bp 141–762). These fragments were cloned into BamHI/
NotI-digested pVLH-1 to create the plasmids pVLH/int⌬1⌬3, pVLH/
int⌬1⌬2, pVLH/int⌬3, and pVLH/int⌬1, respectively, where the ⌬ refers to the deleted intron region(s). pVLH/int⌬2⌬3 was created by cutting FIG. 1—continued
out region 1 of the intron from pVLH/int by restriction digestion with BamHI/DraI and cloning this fragment directly into BamHI/SmaI- digested pVLH-1. pVLH/int⌬2 was the result of a spontaneous deletion in pVLH/int that occurred while propagating the plasmid in E. coli. This plasmid was sequenced and found to be missing bp 161– 686 of the intron. The plasmid pILH-1 was made by digesting pVLH/int with SstI and SmaI. The intron fragment was then cloned upstream of the lucif- erase coding region of similarly digested pGL2-basic (Promega). The simian virus 40 polyadenylation site of pGL2-basic was then replaced with a BamHI/ClaI fragment containing the hrp2 3⬘ sequence from the plasmid pHLH-1. The various intron fragments were also cloned into BamHI/NotI-digested pILH-1 to generate plasmids in which the indi- vidual portions of the intron replaced the full-length intron to drive luciferase expression. Site-directed mutagenesis was performed by us- ing the QuikChange mutagenesis kit (Stratagene) and the manufactur- er’s protocols.
Parasite Transfection and Luciferase Assays—Parasites were trans- fected as described (20). Briefly, uninfected human erythrocytes were electroporated in the presence of 50g of plasmid DNA in incomplete cytomix using a Bio-Rad gene pulser, 0.2-cm cuvettes, and conditions of 0.31 kV and 960 microfarads. Erythrocytes from two such electropora- tions were combined for each 5-ml culture and inoculated with late stage parasites purified using a Percoll/sorbitol gradient. Luciferase assays were performed on 5-ml cultures at selected times after trans- fection (9). Error bars in graphs represent standard deviations of ex- periments done in triplicate.
Previous work has shown that plasmids containing an intron require passage through S-phase to silence an upstream var promoter (9).
However, because var promoters are only active during the ring stage (prior to S-phase), silencing is not detected after transfection until the ring stage of the following cycle, after which silencing is maintained through subsequent cell cycles. All transfection experiments described in this manuscript were performed by allowing parasites to invade DNA-loaded erythrocytes (20) and then separating the parasites from the DNA-loaded erythrocytes by Percoll/sorbitol gradients. Return of the purified parasites to culture with fresh, unloaded erythrocytes thus ensured that all transfected plasmids had been through at least one S-phase. Activity of the var7b promoter was always measured in ring- stage parasites unless otherwise stated.
RESULTS
Analysis of var Intron Structure—Typical var genes contain two exons separated by a 0.8 –1.2 kb intron (3). Fig. 1A shows an alignment of the sequences of introns from 11 different var sequences in the GenBankTMdata base. These sequences are from several different parasite lines and include genes from both subtelomeric and internal regions of chromosomes. All show similar structure with three distinct regions that are distinguished by their sequence similarity and nucleotide com- position (Fig. 1A). Several repeat sequence elements occur in these regions, including TGTATGTG in region 1 and the direct complement of this sequence (ACATACAC) in region 3.
Forward strand composition data, summarized by the histo- grams in Fig. 1B, show prominent asymmetry of the G versus C and A versus T contents of regions 1 and 3. The forward strand of region 2 consists of over 70% A with very little G or C. The differences among regions 1, 2, and 3 were found to be distinct without ambiguity of their borders in the alignments.
Identification of an INR Element in a var Promoter—Primer extension was previously performed by using mRNA from an expressed internal gene (var7b), and the transcription start site was mapped to a conserved A residue at the center position within the sequence TCATA (8). Interestingly, this 5-base pair sequence was recently identified as a promoter element of numerous genes in the parasite T. vaginalis (21). In all cases, the A at position 3 was the transcription start point, and certain specific point mutations within the sequence resulted in substantially reduced promoter activity. This element is very similar in function and sequence to a metazoan initiator ele- ment (Inr), suggesting that these elements were present in an ancestor early in eukaryotic evolution.
To test whether the TCATA sequence found at the transcrip-
tion start site of the var7b promoter has a similar function to this sequence in Inr, we performed site-directed mutagenesis on the construct pVLH-1, which incorporates the var7b pro- moter driving expression of a luciferase reporter gene (8).
Three specific mutations that reduce promoter activity in the T. vaginalis sequence were engineered into pVLH-1, and the resulting plasmids were transfected into P. falciparum para- sites. These mutations produced reductions in promoter activ- ity similar to those seen with experiments in T. vaginalis, suggesting the P. falciparum TCATA element has a function similar to that of the Inr in other organisms (Fig. 2B).
Promoter Activity within the Var Intron—Inspection of the intron sequence alignment shown in Fig. 1A identified several conserved copies of the putative Inr element described above.
Therefore, we considered whether the var intron might also have promoter activity, thus providing a possible explanation for the origin of the “sterile” or “aberrant” exon 2 containing transcripts previously described (3, 16). These transcripts were shown to include a portion of the intron and exon II. Although a case has been made for low level translation of a few of these transcripts (22), the majority have no consistent start methio- nine or other features indicative of translation.
To determine whether a var intron can act as a functional promoter, we excised the intron previously used as a silencer in the plasmid pVLH/int (intron 2b in Fig. 1B) and placed it upstream of a luciferase reporter gene. The resulting con- structs, pILH-1 and pVLH-1, were then transfected separately into P. falciparum parasites, which were then synchronized by Percoll/sorbitol gradient purifications (17). Luciferase expres- sion levels were measured in both ring-stage parasites and late trophozoites (Fig. 3). As expected, the var7b promoter activity in the construct pVLH-1 was ring-specific, with expression levels falling substantially in late trophozoites. var genes were previously shown to be expressed in the ring stages of asexual parasites, between 3 and 18 h after merozoite invasion (23). By contrast, the construct that included intron 2b as a promoter showed very little activity in rings and much higher levels of activity in late trophozoites. This activity period is in agree- ment with the timing of the sterile transcripts detected by RNA blot analysis (16, 24) and coincides with S-phase of the cell cycle (25). Trophozoite stage activity of the intron promoter may thus relate to the dependence of var gene silencing on the transition of the parasite through S-phase (9) and assembly of silent chromatin that occurs during this period of the cell cycle (26 –28).
FIG. 2. Effect on luciferase expression of nucleotide changes in an Inr-like element containing the var7b transcription start point. The transcription start point is located within the upstream var7b promoter region that resembles an Inr-like element also present in T. vaginalis. The transcription start point (A) is shown in bold.
Luciferase expression levels from constructs containing site-specific mutations in the var initiator element are shown in the histogram. The sequence of the mutations is shown below the horizontal axis. Lucifer- ase expression was detected from ring-stage parasites.
Two Separate Promoters Control var Gene Expression
34128
To further characterize the intron promoter and to deter- mine what portion or portions were necessary for promoter activity, we transfected parasites with constructs that included either the entire intron 2b in forward or reverse orientation, region 2 alone, or intron 2b with region 2 deleted. To determine the relative strength of the intron promoter, we compared the luciferase activity of these constructs to that of pVLH-1. Late trophozoites containing reporter constructs driven by intron 2b and ring-stage parasites transfected with pVLH-1 were as- sayed to allow a direct comparison of the peak activity of both promoters. The results (Fig. 4A) show that the intron can function as a promoter in either orientation, a characteristic previously described for several TATA-less promoters in other organisms (29 –31). Further, the luciferase levels from the var- ious constructs show that intron region 2, the region that includes putative Inr elements similar to that in the upstream var promoter, is necessary for intron promoter activity and is sufficient on its own for luciferase expression.
Constructs containing the intron 2b promoter gave signifi- cantly lower luciferase activity than those containing the var7b promoter (Fig. 4A). To determine whether this low level of promoter activity was indicative of a truly functional promoter and was not simply spurious, the plasmid pVLH/int was mod- ified to include the coding region of the human dhfr gene downstream of intron 2b (Fig. 4B). In this construct (pVLH/
IDH), the intron acts as a silencer of the upstream var7b promoter and as a promoter driving expression of the dhfr gene. As expected, parasites transfected with this construct demonstrated silencing of the luciferase gene similar to that seen with pVLH/int (data not shown). When grown in media containing pyrimethamine, drug resistant parasites were se- lected after 3 weeks of drug pressure, as is typical for parasites transfected with plasmids containing drug resistance markers.
Plasmid rescue experiments showed that the resistant para- sites were carrying the construct pVLH/IDH. The strong re- pression of luciferase expression indicates that dhfr expression is unlikely to be the result of “read-through” transcription initiating from the var7b promoter. In addition, control cul- tures of untransfected parasites or parasites transfected with a
modified pVLH/IDH where the intron had been deleted failed to select any drug-resistant parasites. These results indicate that the promoter activity of the intron was sufficient to alter the phenotype of the parasite and, combined with previously published Northern blots that show significant transcription of the “sterile” transcripts (3, 16), strongly support the conclu- sion that var introns are functionally active promoters in P. falciparum.
FIG. 3. Luciferase expression levels showing activity of the var7b upstream and intron 2b promoters at different times in the cell cycle. Synchronized parasites were transfected with either pVLH-1 or pILH-1. Histograms indicate the luciferase levels of ring stages 12 h after invasion and of late trophozoite stages 36 h after invasion.
FIG. 4. Luciferase expression levels from parasites transfected with plasmids containing either the var7b upstream region or portions of intron 2b as a promoter. A, luciferase levels are indi- cated for parasites transfected with the following constructs: pVLH-1;
pILH-1; pILH-1(⫺) in which intron 2b is placed upstream of the luc coding region in the reverse orientation; p2LH-1 in which region 2 of the intron is placed upstream of the luc coding region; and pILHint⌬2 in which region 2 has been deleted from the intron. Luciferase assays were done on ring-stage parasites for pVLH-1 and on late trophozoites for all other constructs, thus comparing peak promoter activity for all con- structs. B, plasmid map for the construct pVLH/IDH.
Relative Effects of Intron Regions 1, 2, and 3 on var Gene Silencing—To explore the role of intron regions 1, 2, and 3 on var gene silencing, we constructed modified pVLH/int plasmids in which the full-length intron 2b was replaced by each indi- vidual region separately and in combination with one another.
Luciferase expression levels from transfected parasites were then measured to determine the effects of the various regions of the intron on silencing of the associated var7b promoter. The expression assays were performed on ring stages after all the transfected parasites had passed through S-phase.
All constructs that included region 2, including constructs where region 2 was the only portion of the intron included, showed levels of var promoter silencing equivalent to that obtained from the complete intron (Fig. 5A). Constructs that included only regions 1 or 3, or both regions 1 and 3 but excluding region 2, showed partial repression of luciferase ex- pression (50 –70%) but were not able to fully silence var7b promoter activity. To further demonstrate association between the intron’s promoter activity and its ability to function as a silencing element, each combination of intron 2b fragments was placed upstream of luciferase to test for promoter activity (Fig. 5B). These experiments show a direct association between the intron’s promoter activity and its ability to silence the associated var promoter. In particular, these results highlight the importance of region 2 for both the silencing ability of the intron as well as its inherent promoter activity.
DISCUSSION
Silencing and selective expression of var genes have vital roles in the antigenic variation that is central to the pathogen- esis of P. falciparum malaria. Models for var transcriptional control, however, are undeveloped, and only limited analogies can be drawn to the regulatory mechanisms of multigene fam- ilies in other eukaryotes. Systems that show some analogies (for example, the vsg genes of African trypanosomes (32), the vsp genes of Giardia (33), and the odor receptor genes of mam- mals (34)) are controlled by mechanisms that remain unclear and appear to differ considerably from those in P. falciparum.
A mechanism in which regions containing two separate pro- moters co-operate to control gene silencing has not been de- scribed for these other multicopy gene families and may be unique to var genes.
Reports differ on the number of var genes expressed at one time in a single parasite. Nuclear run-on experiments using parasites selected for their cytoadherence phenotype showed a single var gene transcribed in trophozoites (7). Single-cell re- verse transcriptase-PCR experiments identified transcripts from multiple var genes in early ring-stage parasites, but only a single transcript remained in trophozoites (6). Detection of only a single transcript band on RNA blots is consistent with proposals that multiple transcripts in early rings are low level and transient, possibly because they are truncated or unstable (24). In contrast, other experiments using single-cell reverse transcriptase-PCR have described multiple var transcripts in trophozoites, suggesting that more than one var gene can be transcribed at this stage of the cell cycle (35). Nevertheless, it is clear that progression through the cell cycle has an impor- tant effect on the regulation and detection of var gene tran- scripts. One manifestation of this effect is the co-operative S-phase-dependent silencing of episomal constructs carrying var promoters in cis with var introns. The transcription from var introns occurs later in the cell cycle than the ring-stage peak of upstream var promoter activity and may relate to the S-phase dependence of silencing.
A function or explanation for the existence of the var sterile transcripts has been lacking since they were first described along with the discovery of the var gene family (3). Recent work
on chromatin-mediated gene silencing in other organisms may provide some suggestions. The boundary elements scs and scs⬘ in Drosophila (13) and several boundaries described in yeast (14) are actively transcribed. Promoter activities found in these boundaries are important for their ability to prevent the spread FIG. 5. The silencing and promoter activities of intron 2b both require region 2. A, luciferase activity from parasites transfected with plasmids containing the var7b promoter driving luc expression along with different portions of the intron. Control plasmid pVLH-1 contains no intron and demonstrates full activity. Plasmid pVLH/int has the entire var intron 2b and demonstrates complete silencing. “⌬” in the names of the other plasmids indicates the region of the intron that has been deleted. B, luciferase activity from constructs that contain differ- ent portions of intron 2b driving luciferase expression. Control plasmid pXLH-1 contains the luciferase coding region with no promoter. Plas- mid pILH-1 has the entire intron driving luciferase expression. The remaining plasmids are labeled as described for A, with⌬ indicating the portion of the intron that has been deleted.
Two Separate Promoters Control var Gene Expression
34130
of silent chromatin outside the silenced locus (36). It has also been shown that several yeast transcription factors can act as boundaries when bound to DNA, suggesting that certain pro- moters may behave as insulators and partition genomes into functionally independent domains (14, 15). This behavior is pronounced in the human -globin locus where non-coding transcripts precisely delineate transcriptionally active and si- lent domains (37). Similar to the transcripts from the var intron, the-globin non-coding transcripts are expressed dur- ing early S-phase at the time when the globin locus is repli- cated and chromatin assembly and modification occurs. Dis- ruption of the production of these transcripts interferes with chromatin remodeling and proper gene regulation. Thus, the promoter activities of var introns could be functioning in a manner that likewise separates the transcriptionally active and silent chromatin domains of the chromosome neighbor- hoods in which var genes reside. Alternatively, the intron pro- moter could function directly in silencing of the upstream var promoter through promoter competition. This has also been proposed as a model for regulating expression of the-globin locus in vertebrates (38 – 40). In this system, cis-linked promot- ers compete for a single shared enhancer, with a developmental switch in expression resulting from one promoter out-compet- ing the other. An effect of promoter competition has recently been described for an insulator element in Drosophila (41). If such a mechanism applies to var genes, both promoters would be competing for a single enhancer element, and silencing of the upstream var promoter would be accompanied by the cor- responding up-regulation of the intron promoter. This model would explain the apparent weakness of the intron promoter in the construct pILH-1 where it has been separated from any activator sequences that it may be competing for.
The luciferase assays described in Fig. 4A show that the intron has bi-directional promoter activity. This is in agree- ment with previous work showing that the intron can function as a silencer in either orientation (9). The bi-directionality of the silencing and promoter functions of the intron may be related to the symmetry displayed graphically in Fig. 1B, as inversion of the intron produces no overall change in the strand asymmetries of the DNA. We also note that a conserved se- quence matching the Inr element is present on the opposite strand of the introns aligned in Fig. 1A and could function as a transcription start site for the inverted intron. Several other bi-directional promoters have been described previously in other organisms (29 –31). Interestingly, the human hGMFG promoter is active in a single orientation; if the upstream regulatory regions are deleted, however, the core promoter func- tions bi-directionally (31). In the plasmid pILH-1, the intron may likewise be separated from the influence of upstream regulatory sequences, thus behaving as a bi-directional core promoter.
Although the non-coding regions of the P. falciparum genome are known for being extremely AT rich, the base composition of the intron is unique in that all three regions display distinct strand asymmetries (Fig. 1B). In region 2, the forward strand is over 70% A, with the remaining base pairs made up mostly of T residues, whereas the reverse strand of region 1 and the forward strand of region 3 contain A, T, and C but show an almost total absence of G. The function of this asymmetry is unknown; however, sequences with such asymmetric composi- tion are easily unwound (42) and may function as binding sites for DNA or chromatin-binding proteins (43). DNA-binding pro- teins containing AT-hooks recognize the base pair composition of AT-rich target sites similar to region 2 (44) and can regulate gene expression through the modification of chromatin struc- ture (45). AT-hook-containing proteins have been shown to play a role in the attachment of DNA to the nuclear matrix or
scaffold (46, 47) and are found encoded in the P. falciparum genome. Such attachment is predicted to lead to the formation of chromatin loops (48) with the attachment sites acting as boundaries between regions of the genome that are packaged into separate loops of chromatin representing different do- mains (49, 50). Such a role would be consistent with a model in which the intron serves as both a silencer and a boundary element that separates each var gene from the neighboring chromatin environment.
REFERENCES
1. Kyes, S., Horrocks, P., and Newbold, C. (2001) Annu. Rev. Microbiol. 55, 673–707
2. Baruch, D. I., Pasloske, B. L., Singh, H. B., Bi, X., Ma, X. C., Feldman, M., Taraschi, T. F., and Howard, R. J. (1995) Cell 82, 77– 87
3. Su, X., Heatwole, V. M., Wertheimer, S. P., Guinet, F., Herrfeldt, J. V., Peterson, D. S., Ravetch, J. V., and Wellems, T. E. (1995) Cell 82, 89 –100 4. Smith, J. D., Chitnis, C. E., Craig, A. G., Roberts, D. J., Hudson-Taylor, D. E., Peterson, D. S., Pinches, R., Newbold, C. I., and Miller, L. H. (1995) Cell 82, 101–110
5. Gardner, M. J., Hall, N., Fung, E., White, O., Berriman, M., Hyman, R. W., Carlton, J. M., Pain, A., Nelson, K. E., Bowman, S., Paulsen, I. T., James, K., Eisen, J. A., Rutherford, K., Salzberg, S. L., Craig, A., Kyes, S., Chan, M. S., Nene, V., Shallom, S. J., Suh, B., Peterson, J., Angiuoli, S., Pertea, M., Allen, J., Selengut, J., Haft, D., Mather, M. W., Vaidya, A. B., Martin, D. M., Fairlamb, A. H., Fraunholz, M. J., Roos, D. S., Ralph, S. A., McFadden, G. I., Cummings, L. M., Subramanian, G. M., Mungall, C., Venter, J. C., Carucci, D. J., Hoffman, S. L., Newbold, C., Davis, R. W., Fraser, C. M., and Barrell, B. (2002) Nature 419, 498 –511
6. Chen, Q., Fernandez, V., Sundstrom, A., Schlichtherle, M., Datta, S., Hagblom, P., and Wahlgren, M. (1998) Nature 394, 392–395
7. Scherf, A., Hernandez-Rivas, R., Buffet, P., Bottius, E., Benatar, C., Pouvelle, B., Gysin, J., and Lanzer, M. (1998) EMBO J. 17, 5418 –5426
8. Deitsch, K. W., del Pinal, A., and Wellems, T. E. (1999) Mol. Biochem. Para- sitol. 101, 107–116
9. Deitsch, K. W., Calderwood, M. S., and Wellems, T. E. (2001) Nature 412, 875– 876
10. Hall, N., Pain, A., Berriman, M., Churcher, C., Harris, B., Harris, D., Mungall, K., Bowman, S., Atkin, R., Baker, S., Barron, A., Brooks, K., Buckee, C. O., Burrows, C., Cherevach, I., Chillingworth, C., Chillingworth, T., Christodoulou, Z., Clark, L., Clark, R., Corton, C., Cronin, A., Davies, R., Davis, P., Dear, P., Dearden, F., Doggett, J., Feltwell, T., Goble, A., Goodhead, I., Gwilliam, R., Hamlin, N., Hance, Z., Harper, D., Hauser, H., Hornsby, T., Holroyd, S., Horrocks, P., Humphray, S., Jagels, K., James, K. D., Johnson, D., Kerhornou, A., Knights, A., Konfortov, B., Kyes, S., Larke, N., Lawson, D., Lennard, N., Line, A., Maddison, M., McLean, J., Mooney, P., Moule, S., Murphy, L., Oliver, K., Ormond, D., Price, C., Quail, M. A., Rabbinowitsch, E., Rajandream, M. A., Rutter, S., Rutherford, K. M., Sanders, M., Simmonds, M., Seeger, K., Sharp, S., Smith, R., Squares, R., Squares, S., Stevens, K., Taylor, K., Tivey, A., Unwin, L., Whitehead, S., Woodward, J., Sulston, J. E., Craig, A., Newbold, C., and Barrell, B. G.
(2002) Nature 419, 527–531
11. West, A. G., Gaszner, M., and Felsenfeld, G. (2002) Genes Dev. 16, 271–288 12. Gerasimova, T. I., and Corces, V. G. (2001) Annu. Rev. Genet. 35, 193–208 13. Avramova, Z., and Tikhonov, A. (1999) Trends Genet. 15, 138 –139 14. Donze, D., and Kamakaka, R. T. (2001) EMBO J. 20, 520 –531
15. Fourel, G., Boscheron, C., Revardel, E., Lebrun, E., Hu, Y. F., Simmen, K. C., Muller, K., Li, R., Mermod, N., and Gilson, E. (2001) EMBO Rep. 2, 124 –132 16. Kyes, S., Christodoulou, Z., Raza, A., Horrocks, P., Pinches, R., Rowe, J. A.,
and Newbold, C. (2003) Mol. Microbiol. 48, 1339 –1348
17. Aley, S. B., Sherwood, J. A., and Howard, R. J. (1984) J. Exp. Med. 160, 1585–1590
18. Wu, Y., Kirkman, L., and Wellems, T. E. (1996) Proc. Natl. Acad. Sci. U. S. A.
93, 1130 –1134
19. Fidock, D. A., and Wellems, T. E. (1997) Proc. Natl. Acad. Sci. U. S. A. 94, 10931–10936
20. Deitsch, K. W., Driskill, C. L., and Wellems, T. E. (2001) Nucleic Acids Res. 29, 850 – 853
21. Liston, D. R., and Johnson, P. J. (1999) Mol. Cell Biol. 19, 2380 –2388 22. Bischoff, E., Guillotte, M., Mercereau-Puijalon, O., and Bonnefoy, S. (2000)
Mol. Microbiol. 35, 1005–1016
23. Kyes, S., Pinches, R., and Newbold, C. (2000) Mol. Biochem. Parasitol. 105, 311–315
24. Taylor, H. M., Kyes, S. A., Harris, D., Kriek, N., and Newbold, C. I. (2000) Mol.
Biochem. Parasitol. 105, 13–23
25. Arnot, D. E., and Gull, K. (1998) Ann. Trop. Med. Parasitol. 92, 361–365 26. Miller, A. M., and Nasmyth, K. A. (1984) Nature 312, 247–251 27. Kirchmaier, A. L., and Rine, J. (2001) Science 291, 646 – 650
28. Li, Y. C., Cheng, T. H., and Gartenberg, M. R. (2001) Science 291, 650 – 653 29. Ikeda, S., Mochizuki, A., Sarker, A. H., and Seki, S. (2000) Biochem. Biophys.
Res. Commun. 273, 1063–1068
30. Liao, W. C., Geng, Y., and Johnson, L. F. (1994) Gene (Amst.) 146, 183–189 31. Kawai, Y., Asai, K., Miura, Y., Inoue, Y., Yamamoto, M., Moriyama, A.,
Yamamoto, N., and Kato, T. (2003) Biochim. Biophys. Acta 1625, 246 –252 32. Borst, P. (2002) Cell 109, 5– 8
33. Nash, T. E. (2002) Mol. Microbiol. 45, 585–590
34. Serizawa, S., Ishii, T., Nakatani, H., Tsuboi, A., Nagawa, F., Asano, M., Sudo, K., Sakagami, J., Sakano, H., Ijiri, T., Matsuda, Y., Suzuki, M., Yamamori, T., Iwakura, Y., and Sakano, H. (2000) Nat. Neurosci. 3, 687– 693
35. Duffy, M. F., Brown, G. V., Basuki, W., Krejany, E. O., Noviyanti, R., Cowman, A. F., and Reeder, J. C. (2002) Mol. Microbiol. 43, 1285–1293
36. Bi, X., and Broach, J. R. (2001) Curr. Opin. Genet. Dev. 11, 199 –204 37. Gribnau, J., Diderich, K., Pruzina, S., Calzolari, R., and Fraser, P. (2000) Mol.
Cell 5, 377–386
38. Sabatino, D. E., Cline, A. P., Gallagher, P. G., Garrett, L. J., Stamatoyannopoulos, G., Forget, B. G., and Bodine, D. M. (1998) Mol. Cell Biol. 18, 6634 – 6640
39. Wijgerde, M., Grosveld, F., and Fraser, P. (1995) Nature 377, 209 –213 40. Milot, E., Strouboulis, J., Trimborn, T., Wijgerde, M., de Boer, E., Langeveld,
A., Tan-Un, K., Vergeer, W., Yannoutsos, N., Grosveld, F., and Fraser, P.
(1996) Cell 87, 105–114
41. Cai, H. N., Zhang, Z., Adams, J. R., and Shen, P. (2001) Development 128, 4339 – 4347
42. Dickinson, L. A., Joh, T., Kohwi, Y., and Kohwi-Shigematsu, T. (1992) Cell 70, 631– 645
43. Bode, J., Kohwi, Y., Dickinson, L., Joh, T., Klehr, D., Mielke, C., and Kohwi- Shigematsu, T. (1992) Science 255, 195–197
44. Reeves, R. (2000) Environ. Health Perspect. 108, Suppl. 5, 803– 809 45. Reeves, R., and Beckerbauer, L. (2001) Biochim. Biophys. Acta 1519, 13–29 46. Girard, F., Bello, B., Laemmli, U. K., and Gehring, W. J. (1998) EMBO J. 17,
2079 –2085
47. Morisawa, G., Han-Yama, A., Moda, I., Tamai, A., Iwabuchi, M., and Meshi, T.
(2000) Plant Cell 12, 1903–1916
48. de Belle, I., Cai, S., and Kohwi-Shigematsu, T. (1998) J. Cell Biol. 141, 335–348
49. Bell, A. C., West, A. G., and Felsenfeld, G. (2001) Science 291, 447– 450 50. Mongelard, F., and Corces, V. G. (2001) Nat. Struct. Biol. 8, 192–194
