PST thin films for electrocaloric coolers

HAL Id: hal-00613273

https://hal.archives-ouvertes.fr/hal-00613273

Submitted on 4 Aug 2011

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are pub- lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

PST thin films for electrocaloric coolers

T M Correia, S Kar-Narayan, J S Young, J F Scott, N D Mathur, R W Whatmore, Q Zhang

To cite this version:

T M Correia, S Kar-Narayan, J S Young, J F Scott, N D Mathur, et al.. PST thin films for elec- trocaloric coolers. Journal of Physics D: Applied Physics, IOP Publishing, 2011, 44 (16), pp.165407.

�10.1088/0022-3727/44/16/165407�. �hal-00613273�

PST thin films for electrocaloric coolers

T. M. Correia^1,a), S. Kar-Narayan², J. S. Young², J. F. Scott³, N. D. Mathur², R. W. Whatmore⁴ and Q. Zhang^1,b)

1Department of Materials, Cranfield University Bedfordshire MK43 OAL, United Kingdom

2Department of Materials Science, University of Cambridge, Pembroke Street, Cambridge CB2 3QZ, United Kingdom

3Cavendish Laboratory, Department of Physics, University of Cambridge, Cambridge CB3 0HE, United Kingdom

4Tyndall National Institute, University College Cork, Lee Maltings, Dyke Parade, Cork, Ireland

Abstract

Relaxor behaviour in a thin film of partially ordered PbSc0.5Ta0.5O3 (PST) was confirmed via slim P-E loops and the frequency dependence of the temperature at which the dielectric constant is maximum. Indirect measurements of the electrocaloric effect suggest that removing a field of 774 kV cm^-1 yields a temperature change of -3.5ºC to -6.9ºC over a broad range of operating temperatures near room temperature (1 ºC-127 ºC), with a correspondingly large refrigerant capacity of 662 J kg^-1. In addition to low electrical hysteresis, there is negligible thermal hysteresis. PST thin films are therefore promising for EC cooling near room temperature.

Introduction

Electrocaloric (EC) coolers have stimulated great attention since the recent discovery of the giant EC effect in ferroelectric thin films [1-2]. This has sparked the desire to develop an environmentally friendly, powerful and low-cost EC refrigerator [3-7]. The EC effect is typically characterized by the entropy change, S, driven by the application/removal of an electric field, E, associated with a temperature change, T as follows:

a)tatiana.correia@npl.co.uk

Current address: National Physical Laboratory, Hampton Road, Teddington, Middlesex, TW11 0LW

b)q.zhang@cranfield.ac.uk

Confidential: not for distribution. Submitted to IOP Publishing for peer review 15 March 2011

T dE S P

E

E ∂∂

-=D ²

1

1

r ⁽¹⁾

and,

T dE P c T T

E

E ∂∂

-=D ²

1

1 (2)

where P is polarization, c is specific heat capacity, is density and E1and E2are the starting and final applied fields, respectively. These equations are not straightforward to apply if there is electrical or thermal hysteresis, e.g. near first-order phase transitions or within the “glassy” non- ergodic state of some relaxors [5].

Lead scandium tantalate, PbSc0.5Ta0.5O3 (PST), has a perovskite structure, A(B'B'')O3, in which B-site disorder leads to relaxor behaviour. Appropriate heat treatments promote B-site ordering, and so long-range ferroelectric order may be observed [8-10]. Relaxor PST undergoes a diffuse second-order phase transition whereas a first-order phase transition is found in highly ordered PST [8-10]. While a paraelectric (or relaxor)-ferroelectric phase transition is known to occur between 0 ºC and room temperature depending on the degree of PST ordering [8,10], dielectric measurements of PST thin films have indicated the existence of several anomalies at cryogenic temperatures [11]. The underlying mechanisms are unresolved but could involve structural phase transitions and domain-wall dynamics. Here we investigate the EC effect in a partially ordered PbSc0.5Ta0.5O3 thin film, which is expected to exhibit a high pyroelectric coefficient, a phase transition near room temperature and slim relaxor-like P-E loops [12-15].

Furthermore, PST compositions with W < 0.82 [8] have demonstrated a second-order phase transition and so no thermal hysteresis is expected.

Experimental

A partially ordered PbSc_0.5Ta_0.5O₃ thin film was fabricated by sol-gel using precursors of lead acetate trihydrate Pb(OAc)2.3H2O, scandium acetate (Sc(OAc)3, and tantalum ethoxide Ta(OEt)5. The scandium acetate and tantalum ethoxide were mixed together, dissolved in 2- methoxyethanol (2ME) and refluxed for 10 hrs. Separately, lead acetate trihydrate was dissolved in 2ME, and the water was distilled out of the system. Both solutions were mixed and stirred at room temperature for 2 hrs. The final concentration of the synthesized PST sol was 0.3M. PST sol was spin-coated at 3000 rpm for 30 sec onto a Pt/Ti/SiO2/Si substrate. Each layer was

pyrolized at 350 ºC for 1 min. After the deposition of 5 layers, the film was annealed at 650 ºC via Rapid Thermal Annealing with a heating ramp of 18 ºC/sec. The thickness of each layer was 20 nm, and the above-mentioned process was repeated ten times to obtain the desired 200 nm.

350¥ 350m m²top electrodes of Cr/Au were deposited by thermal evaporation (Fig. 1). Dielectric constant measurements were carried out using a Wayne-Kerr impedance analyzer (Wayne Kerr Electronics, UK). P-E loops were obtained by means of a Radiant Technologies RT66A ferroelectric tester (Radiant Technologies Inc., USA). A Peltier element was used for temperature control.

Results and Discussion

X-Ray diffraction data (Fig. 2) suggest that the film adopts a single-phase perovskite structure and shows preferential {111} orientations. The degree of B-site chemical order was found to be = 0.32 from the relative intensities I of the ½ ½ ½ and 100 superlattice reflections, according to [16]:

1 , calculated 100

observed 100

) (

) (

2 1 2 1 2 1

2 1 2 1 2 1

=W

=W

I I

I I

.

(3)

The temperature dependences of the dielectric constant, e , and loss tangent, tan d , at different frequencies are illustrated in Fig. 3. Dielectric constant and loss tangent show maxima at Tm near room temperature, and the strong frequency dependence indicates a relaxor- ferroelectric phase transition. The similarity in de dT below and above Tmconfirms a second- order phase transition. The values of e in our PST thin film are smaller than those in previously reported partially ordered PST thin films (between 1000-6000) which were annealed at T >

700 ºC [10]. This may be due to the use of a lower annealing temperature here (650 ºC), resulting in a smaller average grain size.

In order to evaluate the EC effect in the PST thin film, P-E loops at 1 kHz were measured at different temperatures, as shown in Fig. 4. In addition to the frequency dependence of Tm

(Fig. 3), the slim P-E loops corroborate previously reported relaxor behaviour of partially ordered PST thin films [10]. The temperature dependence of the polarization at different fields, established from the upper branches of the hysteresis loops in E > 0 upon cooling and heating , is presented in Fig. 5. The PST thin film exhibits negligible thermal hysteresis. Given that we are

in an ergodic regime, unlike the relaxor polymer poly(vinylidene fluoridetrifluoroethylene- chlorofluoroethylene [P(VDF-TrFE-CFE)] for which direct and indirect measurements do not match [17], we may apply the indirect thermodynamic analysis to evaluate EC performance.

Using Equations (1) and (2), with c = 0.32 J K^-1 g^-1 and = 8.8 g cm^-3[18], we determined S vs T and T vs T for different E using the cooling data (Figs 5a & b, respectively). There is evidence for peak in both S = -6.3 J K^-1 kg^-1 and T = -6.2 ºC at 68 ºC, probably due to a field- induced relaxor-ferroelectric phase transition. In our PST thin film, | S| = 4.5 - 6.3 J K^-1 kg^-1 which does not exceed the values for e.g. PbZr0.95Ti0.05O3 and P(VDF-TrFE) 55:45 mol % copolymers (8 J K^-1 kg^-1 and 60 J K^-1 kg^-1, respectively) [1], as expected given that we are working near a second-order phase transition. However, a broad temperature range near room temperature may be exploited.

It has been suggested [19,20] that one may compare magnetocaloric materials by evaluating refrigerant capacity (RC), and by extension EC materials. From [19] we have:

D= ²

1

) (

T

T

dT T S

RC , (4)

where T1 and T2 are the cold and hot temperatures accessed via the EC effect. Within the temperature range studied, S varies by less than 27% (Fig. 6a) and contributes significantly to RC. We estimate RC = 695 J kg^-1 in the limits T1= 1 ºC and T2= 127 ºC for E = 774 kV cm^-1. The maximum hysteresis loss, determined from P-E loop area for E > 0 at 9 ºC, could at most reduce the RC by just 4.8% to 662 J kg^-1. Hence the RC we predict from Equation (1) is a reasonable estimate for our relaxor films. The fact that, the estimated RC value in PST thin film is much higher than that in magnetocaloric Gd-based materials (360 J kg^-1) [20], indicates that electrocaloric PST thin films may be used as a media in a cost-efficient refrigeration system operating near room temperature.

Conclusions

A relaxor thin film of PbSc0.5Ta0.5O3 with partial B-site order ( = 0.32) was fabricated by sol- gel, and subjected to rapid thermal annealing. Its relaxor nature near room temperature was confirmed by slim loops and the frequency dependence of T_m. PST thin films could be promising for EC refrigeration, as they combine a set of remarkable properties: 1) a large EC effect below and above room temperature of S ~ -5 J K^-1 kg^-1 for under 774 kV cm^-1, 2) no thermal

hysteresis, 3) low electrical losses of 4.8% and 4) a small variation of S within 1 ºC -127 ºC which yields a large RC = 662 J kg^-1 for E = 774 kV cm^-1.

Acknowledgements

The authors thank the Engineering and Physical Sciences Research Council (EPSRC) for the financial support granted to this work under contract EP/E035043 (Cranfield) and EP/E03389X (Cambridge).

References

[1] A. S. Mischenko, Q. Zhang, J. F. Scott, R. W. Whatmore, and N. D. Mathur, Science 311, 1270 (2006)

[2] A. S. Mischenko, Q. Zhang, R. W. Whatmore, J. F. Scott, and N. D. Mathur, Appl. Phys.

Lett. 89, 242912 (2006)

[3] B. Neese, B. Chu, S.-G. Lu, Y. Wang, E. Furman, Q. M. Zhang, Science 321, 821 (2008) [4] H. Chen, T. L. Rent, X. M. Wu, Y. Yang, L. T. Liu, Appl. Phys. Lett. 94, 182902 (2009) [5] T. M. Correia, J. S. Young, R. W. Whatmore, J. F. Scott, N. D. Mathur, and Q. Zhang, Appl.

Phys. Lett. 95, 182904 (2009)

[6] P. F. Liu, J. L. Wang, X. J. Meng, J. Yang, B. Dkhil, J. H. Chu, Huge electrocaloric effect in Langmuir–Blodgett ferroelectric polymer thin films, New J. Phys., Vol. 12: 023035-023043, 2010.

[7] H. Chen, T. L. Rent, X. M. Wu, Y. Yang, L. T. Liu, Giant electrocaloric effect in leadfree thin film of strontium bismuth tantalite, Appl. Phys. Lett., Vol. 94: 182902/1-3, 2009.

[8] C. Stenger and A. Burggraaf, Phys. Status Solidi A 61, 275 (1980) [9] N. Setter and E. Cross, J. Appl. Phys. 51, 4356 (1980)

[10] K. Brinkman, Y. Wang, D. Su, A. Tagantsev, P. Muralt, and N. Setter, J. Appl. Phys. 102, 044110 (2007)

[11] M. Dawber, S. Rios, J. F. Scott, Q. Zhang and R. W. Whatmore, AIP Conf. Proc. 582, 1 (2001)

[12] N. M. Shorrocks, R. W. Whatmore, P. C. Osbond, Ferroelectrics 106, 387 (1990) [13] T. Takeishi, R.W. Whatmore, Ferroelectrics 228, 53 (1999)

[14] A.Patel, R. W. Whatmore, GB Patent 9025547 (1992) [15] R. Watton, M. A. Todd, Ferroelectrics 118, 279 (1991)

[16] J. R. Giniewicz, A. S. Bhalla, L. E. Cross , Ferroelectrics 21, 281 (1998)

[17] S. G. Lu, B. Roži , Q. M. Zhang, Z. Kutnjak, R. Pirc, M. Lin, X. Li, L. Gorny, Appl.

Phys. Lett. 97, 202901 (2010)

[18] Y. V. Sinyavsky, V. M. Brodyansky, Experimental testing of electrocaloric cooling with transparent ferroelectric ceramic as a working body, Ferroelectrics 131, 321 (1992)

[19] K. A. Gschneidner Jr, V. K. Pecharsky and A. O. Tsokol1, Rep. Prog. Phys. 68 1479 (2005) [20] V. Provenzano, A. J. Shapiro, R. D. Shull, Nature 429, 853 (2004)

Figure Captions

Fig. 1 Schematic of the PST thin film structure.

Fig. 2. XRD patterns for the PST thin film.

Fig. 3. Temperature dependence of dielectric constant e (upper curves) and loss tand (lower curves) at different frequencies. Dashed lines represent cubic-spline interpolation of raw data.

Fig. 4. P-E loops at selected temperatures measured upon cooling.

Fig. 5. Polarization as a function of temperature at selected electric field values, as deduced from the depolarizing branch of P-E loops (E > 0) taken on cooling and heating. The inset shows the temperature evolution of polarization at low field (29 kV cm^-1) in order to identify the field- induced relaxor-ferroelectric phase transition temperature (TC=68∞ C).

Fig. 6. EC (a) entropy change, S, and (b) temperature change, T, as a function of starting temperature, for different E (E₁= 0), predicted using Equations 1 and 2 respectively with the averaged cooling data shown in Fig. 5.

Fig. 1

Intensity(a.u.)

50 45

40 35

30 25

20 15

2θ(º)

(1/21/21/2) (100) (110) (111)

PtCuKβ

Si (200) (211)

Pt

Ω= 0.32

Fig. 1

1000 950 900

ε

60 40 20 0

T (ºC) f 1000

900

800

700

600

ε

140 120

100 80

60 40

20 0

T (ºC)

0.20

0.15

0.10

0.05

0.00

tanδ

0.5 kHz 1 kHz 5 kHz 10 kHz 50 kHz 100 kHz

Fig. 2

-40 -20 0 20 40

P(µCcm-2 )

-1000 -500 0 500 1000 E (kV cm^-1)

21ºC

-40 -20 0 20 40

P(µCcm-2 )

-1000 -500 0 500 1000 E (kV cm^-1)

9ºC

-40 -20 0 20 40

P(µCcm-2 )

-1000 -500 0 500 1000 E (kV cm^-1)

59ºC

-40 -20 0 20 40

P(µCcm-2 )

-1000 -500 0 500 1000 E (kV cm^-1)

80ºC

Fig. 3

32 28 24 20 16 12 8 4 0 P(µCcm-2 )

140 120

100 80

60 40

20 0

T (ºC)

201 296 583 774

392 E (kV cm^-1)

FC FH

2.2 2.0 1.8 1.6

-2 P(µCcm) 1.4

120 100 80 60 40 20

T (ºC) T_C

29 kV cm^-1

Cooling Heating

-8

-6

-4

-2

0

∆S(JK-1 kg-1 )

140 120 100 80 60 40 20 0

T (ºC) 583 774

201 296 392

∆E (kV cm^-1)

a) -8

-6

-4

-2

0

∆T(K)

140 120 100 80 60 40 20 0

T (ºC) 583 774

201 296 392

∆E (kV cm^-1) b)

Fig. 5
