triptych QoS, QoE, QiS
Jean-Philippe Georges
To cite this version:
Jean-Philippe Georges. Performance evaluation & network automation. For a triptych QoS, QoE, QiS. Networking and Internet Architecture [cs.NI]. Université de Lorraine, 2019. �tel-02419132�
´
Evaluation de performances &
automatisation de r´
eseaux.
Pour un triptyque QdS, QdE, QdI
M´
emoire de recherche
pr´esent´ee et soutenue publiquement le 6 mai 2019
pour l’obtention de
l’Habilitation `
a Diriger des Recherches
de l’Universit´
e de Lorraine
(mention G´enie Informatique, Automatique)
par
Jean-Philippe Georges
Composition du jury
Rapporteurs : V´eronique V`eque Professeur, Universit´e Paris Sud (Paris Saclay)
Jean-Jacques Loiseau Directeur de Recherches CNRS, ´Ecole Centrale Nantes Colin Patinson Professor, Leeds Beckett University (Royaume-Uni) Examinateurs : Thierry Divoux Professeur, Universit´e de Lorraine
´
Eric Rondeau Professeur, Universit´e de Lorraine Fran¸cois Spies Professeur, Universit´e de Franche-Comt´e
Invit´e : Philippe Miramont Ing´enieur, Centre National des ´Etudes Spatiales
Centre de Recherche en Automatique de Nancy UMR 7039 CNRS – Universit´e de Lorraine
This dissertation is entitled: “Performance evaluation & network automation. For a triptych QoS, QoE, QiS”. The focus is on telecommunication networks (telephony, data, computer, embed-ded, real-time, Internet, Internet of Things, mobile, etc.). As Robert M. “Bob” Metcalfe points out in [Met73b], such networks require both structures to organise computers in highly communicative networks and “best-effort” strategies (at least for error recovery and reliability purposes). This notion of effort hence refers to the performance of the rendered service/effort. In telecommunication networks, it is actually a set of performance that can characterise the service, and this set is called Quality of Service (QoS).
“
QoS is the collective effect of service performances that determine the degree of satisfaction of a user of this service. [. . . ] [It] refers to the manner in which packet delivery is provided. This service is described by parameters such as bandwidth, packet delay and packet loss rate. [. . . ] QoS can be characterized by different performance criteria that include basicavailability, error rate, response time, the time of connection establishment, data rate, the loss of connection or data due to congestion of the network and the speed of detection and correction of errors.
— Union Internationale des Télécommunications (Recommendation E.800 approuvée le 23 septembre 2008) [UIT08]
The importance of performance evaluation consists in providing a quantitative analysis of the service delivered to the customer. It is even more important for protocols and architectures that do not provide QoS guarantees (i.e. only best or differentiated efforts) or that are simply based on an over-provisioning strategy as detailed in the following document. This is typically the case for one of the protocols I considered in my activities, namely Ethernet (to be noted that Bob Metcalfe PhD dissertation was only accepted in 1973 after he attached an analysis part, even if it still offers a best-effort scheme). In this document, the performance will be eval-uated according to the metrics defined by the IPPM working group of the IETF, considering additive metrics like one-way delay [RFC2679] of a path, multiplicative metrics like packet loss ratio [RFC2680] and concave metrics like end-to-end bandwidth. The performance evaluation (computer engineering) related studies introduced in Chapter 5 are based on deterministic
analysis (mostly through the network calculus theory), simulation and experimentation. While QoS measurements are objective, it remains network-oriented and does not able to qualify the service perceived by the customer/user (QoSE, QoS experienced) named
Qual-ity of Experience (QoE). QoE performance indicators are user-centric and measurements are
often subjective since the qualitative component may depend on the user expectations, envi-ronmental conditions, psychological factors, application context, etc.
As member of a research centre for control engineering, I have considered an intermediate level of QoE called Quality of Control (QoC). It aims at analysing the performance of real-time systems / networked control systems from the controller point of view. Experience could be described here objectively, for instance in terms of overshoot, response time or stability. Chap-ter 6 introduces research activities I leaded with specialists of the control theory, focusing
on control over network and control of network. The latter introduces network automation where networks parameters (like routing or scheduling) are dynamically configured and al-gorithms are orchestrated in order to match the QoC requirements. A special attention has been paid regarding the orthogonal experience needs and objectives between end users and network provides. Considering Ethernet networks, I showed how a protocol not designed for such relative QoS and QoE needs, could be from moved from the islands (where it was born), to the enterprise office, to workshops in industry and finally embedded in the space [Ascl.1]. At the end, we introduced (in a similar manner as M. Jourdain) the software-defined networking paradigm for real-time systems.
According to the Global e-Sustainability Initiative (GeSI), by 2030, Information & Commu-nication Technologies (ICT) will provide benefits across the triple bottom line, from reducing related CO2 emissions and resource use, to generating additional revenues, cost savings and wider societal benefits [GeS15]. The concept is simple and its effect will be exponential as quoted by Jaafar Elmirghani (co-chair of the IEEE Green ICT Initiative).
“
Although ICT currently has an unsustainable carbon footprint, it has the potential to reduce the carbon footprint of other domains by a factor approximately equal to ten times its own carbon footprint as predicted by GeSI. So, for instance, ICT can help smart cities or smart manufacturing to reduce their carbon footprint by 10x ICT’s own carbon footprint. And one of the key technologies needed to achieve this favourable impact is IoT, because it is the mechanism for making cities and other domains smarter. So, in a sense, ICT is both a problem and a solution.Studies have revealed that ICT today generates approximately 2 percent of global CO2 emissions and is forecast to account for 4 percent of global CO2 emissions by 2020. Internet use (particularly with the advent of the Internet of Things), which relies on ICT, is forecast to grow 30 percent to 40 percent per year, which results in 30 times its current traffic in 10 years and 1,000 times current traffic in 20 years. At this rate, in ten years ICT will consume about 60 percent of global energy resources, with concomitant emissions and environmental damage. That is the very picture of unsustainability.
The sheer scale of IoT, in terms of the number of connected devices, will create a large draw on electrical power. Projections vary, but guesstimates range between 50 billion to 100 billion active devices. Clearly, we’ll need to look at reducing every device’s need for power. There’s an obvious need for greening in this area.
— Jaafar Elmirghani (htttp://www.energycentral.com/c/iu/how-internet-things-impacts-ict-and-green-ict-efforts)
Nevertheless, much remains to be done on greening ICT itself, which currently has its own unsustainable carbon footprint. In that field, environmental impacts of information and ICT goods, networks and services are going to be assessed thorough novel standards: ITU-T SG5/Q18, ETSI TC EE TS 103 199 (DTS/EE-00014), ISO greenhouse gas standards comprised ISO 14064-2006; ISO 14065-2013, ISO 14066-2011, or ISO/TR 14069-2013. IEEE Green ICT
for instance, for a method for calculating anticipated emissions caused by virtual machine migration and placement and for a method to calculate near real-time emissions of ICT infras-tructures.
To overcome the strict issue of the energy consumption, I participated to the development (whether in research or in teaching) of the concept introduced by Francis Lepage called
Qual-ity in SustainabilQual-ity (QiS)[RL10]. Even not yet commonly accepted, QiS (translated as QdI in
French – Qualité d’Intégration environnementale), it encompasses the three pillars of sustainable development: environmental, economical and ethical contexts. QiS parameters are energy dis-sipation, CO2emission and other greenhouse gases, waste generation (mass of total wastes or
hazardous waste mass), visual pollution (not directly measurable) or electromagnetic distur-bances (EMF and SAR measurements). While there are metrics and measurements for GHG and radiation, it should be noted that the ethical dimension is still an outstanding issue. A joint metrology would therefore aim at a scientific approach to evaluate both the performance of communication infrastructures and their environmental impact.
Hence, we are convinced that efforts have to be paid to evaluate and control the QiS in a similar way as QoS and QoE. Such green networking will require as will be discussed in Chapter7 metrics (and measures of effectiveness) to characterise a communication network
with respect to environmental problems. Once again I considered the Ethernet protocol and models of the energy consumption of switches. Such metrics will be essential to answer how future networking technologies (e.g. fog/cloud computing, network virtualisation, 5G) will impact ICT and green networking efforts. In addition to the energy consumption / carbon footprint, my research also considers the network architecture life-cycle, bio-mimicry or cradle-to-cradle principles and network automation gathering QoS, QoE and QiS.
The document includes also an activity notice (PartI) and a research project (PartIII). This last part develops the short/mid-term research perspectives and opportunities that will form the backbone of my research activities for the next few years. The list of my publications is given in Chapter4and is coded differently from the other references listed in the Bibliography
chapter.
