Ab Initio Study of Electronic, Structural, Thermal and

Mechanical Characterization of Cadmium Chalcogenides

Devi Prasadh P S, B K Sarkar

To cite this version:

Ab Initio Study of Electronic, Structural, Thermal and Mechanical

Characterization of Cadmium Chalcogenides

Devi Prasadh P.S.1, a, B.K. Sarkar2, b

1 – Department of Physics, Dr. Mahalingam College of Engineering & Technology, Pollachi, Coimbatore, India 2 – Department of Physics, Galgotias University, Greater Noida 201308, India

a – [email protected]

b – [email protected]

DOI 10.2412/mmse.32.38.817 provided by Seo4U.link

Keywords: density functional theory, chalcogenides, FP-LAPW+lo.

ABSTRACT. Based on Density Functional Theory, we have applied Full Potential Augmented Plane Wave plus local

orbital method (FAPW+lo)to study the electronic, structural, optical, thermal and mechanical properties of some semiconducting materials. In this paper we discuss the Zinc blende, CdX (X = S, Se and Te) compounds with the full-potential linear-augmented plane wave (FP-LAPW) method within the framework of the density functional theory (DFT) for electronic, structural, thermal and mechanical properties using the WIEN2k code. For the purpose of exchange-correlation energy (Exc) determination in Kohn–Sham calculation, the standard local density approximation (LDA) formalism is utilized. Murnaghan’s equation of state (EOS) is used for volume optimization by minimizing the total energy with respect to the unit cell volume. The calculated lattice parameters and thermal parameters are in good agreement with other theoretical calculations as well as available experimental data.

Introduction. Cadmium Chalcogenides family is one of the II-VI wide band gap compound

semiconductors. In that family CdS, CdSe and CdTe are some of the main materials. These materials have variousscientific applications, such as solar cells, high efficiency thin film transistors, high density optical memories, light emitting diodes, laser diodes, photovoltaic devices, etc. The recentinnovation of the blue-green laser diode based on the CdX compounds has changedconsideration in their physical properties. CdX compounds are having different phases or crystal structures (Zinc blende, wurtzite). For our convenience we have preferred the zinc blende phase for all three compounds. Because this structure has fewer atoms in unit cell so it is easier for computational treatment. In fact for CdTe, the zinc blende structure is the standard crystal structure or phase, but for the other two compounds CdS and CdSe have wurzite phase. In the past decades numerous experimental and theoretical investigations were carried out for CdX. Many computational methods based on DFT [1]have been studied. But the calculations carried out by using conventional DFT produce disagreeable electronic properties. There is a big variance between experimentally calculated and theoretical data. The variation in energy gap is completely based on the method to calculate the band structure. Some theoretical reports are in good agreement with the measured one. They were calculated based on Local Density Approximation (LDA). The modern ab-inito calculation solves the discrepancies. We have used FP-LAPW+lo to calculate the band structure. The band structure of CdX binary compounds have been calculated by using Full Potential Linearized Augmented Plane Wave method Plus local orbits (FP-LAPW+lo) within the Generalized Gradient Approximation (GGA). There are several methods and theoretical reports available to calculate the band structure and optical properties but some controversies are at there. But the FP-LAPW+lo gives the closer values with the experimental data.In this paper we have presented the structural, elastic, electronic and thermal properties of CdX binary compounds. FP-LAPW+lo is the method used to

investigate the properties and the values are compared with the experimental and other theoretical works for these compounds. Our values are in good agreement with the earlier reports.

Computational method: All the calculations of the structural, thermal and electronic properties were

performed in the frame work of Density Funtional Theory (DFT). To calculate these properties, we employed the full potential linearized augmented plane wave plus local orbitals (FP-LAPW+lo) as executed in the WIEN2k code [2-3].We have used the generalized gradient approximation (GGA) as parameterized by Perdew, Burke and Ernzerhof (PBE) to explain the exchange and correlation effects [4].CdX compounds crystallize in the zinc-blende structure with space group F-43 m. The Cd atom is set at (0, 0, 0) whereas the X atom is set at (0.25, 0.25, 0.25). We have employed Murnaghan’s equation of state [5] for the optimization of the total energy with respect to the unit cell volume. Thus the equilibrium structural parameters have been calculated. The calculations were done with RMTkmax = 9, to attain energy Eigen value convergence. RMT is the smallest radius of the muffin-tin (MT) spheres and kmax is the maximum value of the wave vector. The corresponding values of muffin-tin radii (RMT) for Cd, S, Se and Te were taken to be 2.37, 1.73, 1.91 and 2.35 a.u. (atomic units) for all the calculations. The Gmax parameter was taken to be 14.0 Bohr-1. The wave function has

been expanded inside the atomic spheres with the maximum value of the angular momentum lmax as 10. The irreducible Brillouin zone (BZ) of the zinc-blende structure has been decomposed into a matrix of 10×10×10 Monkhorst–Pack k-points [6]. The iteration procedure is continued with total energy and charge convergence to 0.0001Ry and 0.001e, respectively.

Results & discussions

Structural and elastic properties: To find the elastic constants of CdX compounds with cubic

structure we have used the numerical firstprinciple calculation by calculating the compounds of the stress tensor δ for small stains. Proper strains δ (-0.02-0.02) have been arranged to prevent primitive lattice vectors and then appropriately strained states were analysed. It is well known that for a cubic crystal it has only three independent elastic constants C11, C12 and C44 as we have studied the theory

in a detailed manner in previous chapter. With the Murnaghan’s equation of state [5],the variation of the total energy versus unit cell volume yields to the equilibrium lattice parameter (a0), bulk modulus

B0, and the pressure derivative of the bulk modulus B0′. The values of a0, B0 and B0′ for the ZB

structure of the binary CdX at zero pressure are presented in table 1. For CdS, CdSe and CdTe, the energy minima take place for a0 = 5.805, 6.305 and 6.350 Å, our results are in good agreement with

the experimental values of 5.830, 6.084 and 6.480 Å, respectively with the maximal error of 3.63% with respect to experimental values. It is clear that well defined structural properties are helpful for further study of electronic and thermal properties. The elastic constants of CdX compounds with cubic structure have been determined using the method developed by Charpinincorporated in WIEN2k code[7]. By applying appropriate lattice distortions in a cubic lattice, three independent elastic constants C11, C12, and C44 are determined. Table 1 displays the calculated values of elastic

modulus. Our calculated lattice parameters values are in good agreement with experimentally calculated and other theoretical measured values. The bulk modulus B0 represents the resistance to

fracture while the shear modulus G represents the resistance to plastic deformation. Ductility of the material can be characterized by B0/G ratio. The B0/G ratio for all CdX are greater than 1.75 (table

1) which tells that the compounds are ductile in nature. The peak value of B0/G ratio is 5.2334for

CdSetelling it most ductile among all the CdX compounds. There is a correlation between the binding properties and ductility. The bond character of cubic compounds is expressed in terms of their Cauchy pressure (C12–C44). With increase in positive Cauchy pressure, compound is likely to form metallic

compressibility for CdX compounds are between 0.39 and 0.41 which predict that all the compounds are compressible. Also the Poisson’s ratios having values between 0.25 and 0.5 represent central force solids. In our case, the Poisson’s ratios are around 0.4, which reveals that the interatomic forces in the CdX compounds are central forces.The structural properties results are compared with other theoretical results [13].

Calculation of Debye Temperature. The Debye temperature (D) is considered as a fundamental

parameter for many physical properties of solids, such as specific heat, elastic constants and melting temperature. At low temperature, only the acoustic branches of phonons are active and the vibrational excitations take place exclusively from acoustic vibrations. Hence, the estimate of Debye temperature based on elastic constants at low temperature is consistent with the same as that determined from specific heat measurements. Once we have determined the elastic constants, we may obtain the Debye temperature (D) by using the average sound velocity Vm.We have calculated the density, sound

velocities and Debye’s temperature by using the calculated elastic constants which are produced in table 1.

Electronic Properties. The electronic band structure of Cd chalcogenides has been calculated. The

calculated band structure for CdX at equilibrium is shown in Fig. 1. The band profiles are almost similar for all the three components, with some minute difference.

Fig. 2. Shows the Band Structure and Density of States of CdTe.

1. The first structure in the total DOS is small and centered at around -10.8 eV for CdTe. This structure arises from the chalcogen s states and it corresponds to the lowest lying band with the dispersion in the region around the ᴦ point in the Brillouin zone. The next structure appears at -8.6 eV. It is an attribute of Cd d states with some p states of the chalcogen atoms.

Table 1. Calculated lattice constant (in A˚), bulk modulus B0 (in GPa), pressure derivative B0′, elastic

constants (Cij in GPa), elastic modulus (in GPa), Sound velocities, Debye temperatures and energy

gap (Eg) in eV for CdX compounds.

Properties CdS CdSe CdTe

a0 (Present Study) 5.805 6.305 6.350 a0 (Other works) 5.820 a_{, 5.840}b_, 5.948c_{, 5.810}d 6.050a, 6.201c, 6.050d 6.480a, 6.624c, 6.480d B0 (Present Study) 64.90 58.93 42.70 B0 (Other works) 62.00 a_{, 61.69}b_, 53.838c, 72.42d 53.00a_{, 54.948}c_, 65.12d 42.00a_{, 37.44}c_, 48.94d B0′ (Present Study) 4.25 4.13 4.39 B0′ (Other works) 4.57a, 4.72c, 4.31d 4.67a, 1.584c, 4.20d 3.00a, 3.87c, 4.47d C11 (Present Study) 92.3 81.2 59.9 C11 (Other works) 75.2 e_{, 104.62}b_{, 67.6}f_, 97.8d 65.0e, 55.4f, 88.1d 56.5e, 53.2f, 68.1d C12(Present Study) 51.2 47.8 34.1 C12 (Other works) 55.0 e_{, 46.25}b_{, 46.3}f_, 59.7d 49.0e_{, 37.7}f_{, 53.6}d _32.1e_{, 23.2}f_{, 39.3}d C44 (Present Study) 26.3 22.9 20.1 C44 (Other works) 39.1 e_{, 77.28}b_{, 29.5}f_, 30.6d 36.8e, 18.9f, 27.4d 31.8e, 13.01f, 22.1d

G (GPa) (Present Study) 13.48 11.26 9.18 G (GPa) 21.25b

B0/G (Present Study) 4.8145 5.2334 4.6514

C12-C44 (GPa)

(Present

Study)

24.9 24.9 14.0

Y (GPa) (Present Study) 55.76 45.77 35.15 Y (GPa) (Other works) 25.68b

σ (Present Study) 0.4029 0.4102 0.3997 σ (Other works) 0.34b A (Present Study) 1.2798 1.3713 1.5581

ρ(Kg/m

)

4870

5655

5860

Vt(m/s)

2219

1900

1714

Vl(m/s)

4460

3903

3347

Vm(m/s)

2490

2137

1920

θD(K)

255

210

177

Eg (eV) (Present Study) 1.35 0.77 0.80

Eg (eV) (Other works) 2.55a, 1.45d, 2.66c 1.90a, 1.08d, 1.89c 2.55a, 1.88d, 1.56c

a_{Madelung O}8_, b_{Al Shafaay}9_,c_HakanGurel10_, d_Deligoz11_, e _Kitamura12_, f _Ouendadji13

they subsidize to the upper valance band. Above the Fermi level, the feature in the DOS create mainly from the s and p states of Zn somewhat mixed with little of chalcogen d states. Band width of valence band as determined from the width of the peaks in DOS dispersion below Fermi level equal to 11.5 eV. The results showing valence band width minimum for CdTe, clearly indicate that the wave function for CdTe is more localized than that for CdS. This is in consistence with the fact that when the atomic number of the anion increases, a material becomes non-polar covalent with valence band states being more localized.

Summary. This chapter reports a systematic study of the structural, electronic, elastic and thermal

properties of zinc blende Cd-chalcogenides (CdS, CdSe and CdTe) have been studied with FP-LAPW+ lo method in the framework of density functional theory (DFT). The quantities such as elastic constant and band structure were obtained. The generalized gradient approximation (GGA) was considered for the exchange and correlation effects calculations. The results from FP-LAPW + lo method were generally satisfactory with the experimental data in comparison to other calculation methods. The calculated lattice parameters, bulk modulus, Young’s modulus and Poisson’s ratio of binary compounds CdX are in good agreement with the experimental data. The elastic constants maintain all conditions to be satisfied for mechanical stability of the compound. The profound ductility in CdX compound was observed with the increase in chalcogen atomic number. The metallic character in their bonds is well demonstrated from the positive Cauchy pressure (C12–C44) values.

The band structure of all Cd-chalcogenides confirms the direct energy gap between the top of the valence band and the bottom of conduction band at Γ point.

References

[1] P. Hohenberg, W. Kohn, Inhomogeneous electron gas. Phys. Rev. 136, B864–B871 (1964). doi: 10.1103/PhysRev.136.B864

[2] G. K. H. Madsen, P. Blaha, K. Schwarz, E. Sjöstedt, L. Nordström, Efficient linearization of the augmented planewave method. Phys. Rev. B 64, issue 19, 195134 (2001). doi: 10.1103/ PhysRevB.64.195134

[3] K. Schwarz, P. Blaha, G.K.H. Madsen, Electronic structure calculations of solids using the WIEN2k package for material science, Comp. Phys.Commun., Vol. 147, Issue 1, pp. 71–76 (2002). doi: 10.1016/S0010-4655(02)00206-0

[4] J. P. Perdew, K. Burke, M. Ernzerhof, Generalized gradient approximation made simple. Phys. Rev. Lett. 77, 3865–3868 (1996). doi: 10.1103/PhysRevLett.77.3865

[5] F.D. Murnaghan, On the Theory of the Tension of an Elastic Cylinder, Proc. Natl. Acad. Sci., Vol. 30, No. 12, pp. 382–384 (1944), USA. PMID:16588670 PMCID:PMC1078732

[6] H.J. Monkhorst, J. D. Pack, Special points for Brillouin-zone integrations, Phys. Rev. B. 13, No. 12, pp. 5188–5192 (1976). doi: 10.1103/PhysRevB.13.5188

[7] P. Blaha, K. Schwarz, G.K.H. Madsen, D. Kvasnicka, J. Luitz, WIEN2k, An augmented plane wave plus local orbitals program for calculating crystal properties, (User’s Guide), Inst. of Physical and Theoretical Chemistry, Vienna University of Technology, Austria, pp. 1-205, (2001).

[8] O. Madelung, H. Weiss, and M. Schultz, eds. Landolt-Börnstein: Numerical Data and Functional

Relationships in Science and Technology. Group III: Crystal and Solid State Physics. Vol. 17, Subvolume A: Physics of Group IV Elements and III-V Compounds. Berlin: Springer (1982).

[9] B. Al Shafaay, Structural, electronic, mechanical and thermodynamic properties of CdS compound, J. Che., Bio. And Phy. Sci., Vol. 4, No. 4; pp. 3606–3618 (2014).

[11] E. Deligoz, K. Colakoglu and Y. Ciftci, “Elastic, Elec tronic, and Lattice Dynamical Properties of CdS, CdSe, and CdTe,” Physica B: Physics of Condensed Matter, Vol. 373 (2006), pp. 124-130. doi:10.1016/j.physb.2005.11.099

[12] M. Kitamura, S. Muramatsu & W. A. Harrison, "Elastic properties of semiconductors studied by extended Hückel theory", Physical Review B, Vol. 46, No. 3, (1992), pp. 1351-1357. doi: 10.1103/PhysRevB.46.1351

[13] S. Ouendadji, S. Ghemid, H. Meradji, F.El Haj Hassan, Theoretical study of structural, electronic, and thermal properties of CdS, CdSe and CdTe compounds, Comp. Mat. Sci., Vol. 50, pp. 1460–1466 (2011). doi: 10.1016/j.commatsci.2010.11.035

[14] M. Dadsetani, A. Pourghazi, Optical properties of strontium monochalcogenides from first principles, Phys. Rev. B, Vol. 73, No. 19, pp. 195102, (2006). doi: 10.1103/PhysRevB.73.195102

Cite the paper Devi Prasadh PS, B.K. Sarkar, (2017). Ab initio Study of Electronic, Structural, Thermal and Mechanical Characterization of Cadmium Chalcogenides. Mechanics, Materials Science & Engineering, Vol 9. doi
