EBIC MEASUREMENTS ON LOW ANGLE GRAIN BOUNDARIES A. BARY and G. NOUET

Laboratoire d l E t u d e s et de Recherches sur les Materiaux,

ISMRa-Universite, Boulevard du Marechal Juin, F-14032 Caen Cedex, Prance

The largest grains in Polix ingots contain several low-angle grain boundaries. The electrical properties of high angle grain boundaries have extensively been studied by EBIC/TEM techniques (1) but comparatively less attention has been paid to those of low-angle grain boundaries. However for Polix materials, in the regions of large grains, the total length of low-angle grain boundaries can be much greater than that of high-angle grain boundaries. Moreover, in general the low-angle grain boundaries exhibit strong EBIC contrasts suggesting that their electrical activity is at least of the same order of magnitude than the electrical activity of high-angle grain boundaries.

In this paper, EBIC measurements were performed on several low-angle grain boundaries. The samples are cut in as-grown Polix ingots doped with boron at the doping level 2.10'~

at.cm-' .

From the EBIC contrast profiles the recombination velocity of the minority carriers at the boundary plane is determined (2).

It is found that the majority of the low-angle grain boundaries are of tilt type, i.e. the rotation axis is located in boundary plane, parallel to the dislocations lines.

For the low rotation angles (8 c 0.5") the boundaries lie in (110) planes which are straight on a very long distance. There is

* 1 only one family of edge dislocations with a Burgers vectors b = - (110) normal to the boundary plane. In general, these low-angle 2

grains boundaries are free of precipitates.

For the middle range rotation angles (0.5" S 8 S 2") the boundaries are facetted. The dominant facet planes are (110) or (111) and in some cases (211). In the (110) facets there is one fa-

* 1

mily of edge dislocations b =

-

^(110). The (111) facets contain

2

either one family of identical Frank partial dislocations b 1 =

-

₃

-3 1

(111) or a distribution of three different families b = - ^(110).

These boundaries often contain small precipitates located on the 2 dislocations.

For the high range rotation angles (2" S 8 < 7 " ) , in addi- tion to these configurations more complicated ones are observed in- volving (331), (431) facets. These boundaries contain a high concen- tration of precipitates.

The observed boundaries show recombination velocities V, in the range 1.8 lo4 cm s-

'

^to¹⁵^{lo4 cm s-}

' .

For the low and middle range rotation angles, V

,

increases linearly with the density of dislocations ; V, is roughly constant for the high range rotation angles. EBIC measurements have also been performed on low-angle grain boundaries intersecting at a triple junction. It has been no- ticed that in the range of low rotation angles, the EBIC contrasts and recombination velocities V, show an additive behaviour at the junction. This fact supports also the idea that V, is roughly pro- portionnal to the dislocation density for low rotation angles.

These observations suggest that there are different mecha- nisms of minority carrier recombination. One of the parameters'on which depend the actual mechanism playing a role is the dislocation density.

1

-

A. Bary and G. Nouet, J. Appl. Phys., 1988, 63, 2.

2

-

^C.^Donolato,^J.Appl. Phys., 1983, 54, 1314.
