Numerical simulation of dislocation dynamics in disordered crystals with high Peierls barriers

HAL Id: jpa-00210567

https://hal.archives-ouvertes.fr/jpa-00210567

Submitted on 1 Jan 1987

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are pub- lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

Numerical simulation of dislocation dynamics in disordered crystals with high Peierls barriers

I.R. Sagdeev, V.M. Vinokur

To cite this version:

I.R. Sagdeev, V.M. Vinokur. Numerical simulation of dislocation dynamics in disordered crystals with high Peierls barriers. Journal de Physique, 1987, 48 (9), pp.1395-1400.

�10.1051/jphys:019870048090139500�. �jpa-00210567�

1395

Numerical simulation of dislocation dynamics ⁱⁿ disordered crystals ^with high ^{Peierls barriers}

I.R. Sagdeev and V.M. Vinokur

Institute of Solid State Physics, ^U.S.S.R. Academy ^of Sciences, Chernogolovka, ^Moscow region,

U.S.S.R. 142 432

(Reçu ^{le 29 mai} 198 7, accept£ ^{le 8} juille t 1987)

Résumé.-Une simulation numérique ^{du mouvement} de dislocations dans des cristaux désordonnés avec de hautes barrières de Peierls est présentée. ^{Une chute} brutale de la mobilité des dislocations dans la région ^des champs

externes faibles est révélée. Quand ^la charge impulsionnelle ^est appliquée, ^{la mobilité} des dislocations décroît avec

l’accroissement de la fréquence ^des impulsions. ^{Il est montré} que la chute de mobilité des dislocations sous l’action des forces externes impulsionnelles ^et stationnaires résulte de sous-linéarités dans la propagation des marches dans un

champ ^{de force aléatoire.}

Abstract.-Numerical simulation of dislocation motion in disordered crystals ^with high Peierls relief is performed. ^A sharp drop in dislocation mobility ^{in the} region of weak external fields is revealed. When pulse loading ^is applied, ^the

dislocation mobility ^{decreases as the} pulse frequency increases. It is shown that the dislocation mobility drop ^under

the action of both stationary ^and pulse ^{external forces results from} sublinearity ^{in kink} propagation ^{in a} random force field.

J. Physique ⁴⁸ (1987) ^{1395-1400 SEPTEMBRE 1987,}

Classification

Physics ^Abstracts

61.70G

LE JOURNAL DE PHYSIQUE

The basic concepts of dislocation dynamics ⁱⁿ crystals ^with high Peierls barriers were formed by

Lothe and Hirth [1] and Kazantsev and Pokrovsky [2].

A dislocation is treated as an elastic string ^{in a} peri-

odic potential. ^{It is} assumed that initially ^{the entire}

dislocation lies in one of the valleys. Later, ^thermal

fluctuations create kink-antikink pairs ^{on the disloca-} tion, which then expand under the action of the _ap-

plied external force until they annihilate with kinks from other pairs. This results in a transverse displace-

ment of the dislocation. Experimental data show that dislocation mobility ^{is also} significantly ^effected by point defects, always present ^{in real} crystals. Specif- ically, it has been revealed [3-5] ^that doping ^of crys- tals can give ^{rise to an} increase in dislocation velocity.

This effect could be explained within the framework of the model [1,2] ^{as a} consequence of local lowering

of the Peierls barrier due to interaction between the dislocation and impurities (Petukhov [6,7,8]). ^Unfor-

tunately, ^{all the} attempts ^to compare quantitatively

theoretical and experimental data, which would make it possible to extract unambiguously ^the physical pa-

rameters, describing dislocations and defects, ^{so fair}

failed. One principal difficulty ⁱⁿ comparing ^theoreti-

cal and experimental data is that there are too many

parameters describing dislocation dynamics : ^Peierls

barrier height, kink creation _energy, concentration of

impurities ^{and the} energy of their interaction with the

dislocation, kink diffusion coeflicient along ^{the dislo-}

cation line, ^{etc. At the same time} virtually ^the only

measurable quantity ^{is the mean} (over ^an ensemble of

dislocations) dislocation displacement ^{under the ac-}

tion of an applied ^force.

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphys:019870048090139500

1396

In this context one can view as a major ^advance

the series of works by Nikitenko, ^{Farber and Iunin}

[9,10], ^who investigated ^{motion of} dislocations in Peierls relief under the action of a pulse ^{force. The} technique employed ^{made it} possible ^not only ^{to track}

the displacement ^of individual dislocations, ^{but to}

trace (independently) diffusion of kinks along ^{the dis-}

locations line. A sharp drop ⁱⁿ dislocation mobility

was reported, ^{as the} frequency of the external pulse

force increases (for ^constant period-to-pulse ^duration ratio), ^{as well as} considerable slowing ^{down of dislo-}

cation motion as the spacing ^between pulses ^increases (their ^duration being unchanged). Furthermore, ^in- terpretation ^{of the} experimental data, ^{obtained in}

[9,10] corroborated the notion that dislocations in

crystals ^with high Peierls barriers move by ^successive

transitions from one valley ^to another. The principal

aim of our work was to simulate numerically ^dislo-

cation dynamics ^{in the} presence of defects. We have tested the commonly accepted ^{view on the character}

of dislocation dynamics ^{in the} presence of defects. In the work of one of the authors [111 ^{it was shown that}

moderate external forces impurities and defects can

play ^the leading part ⁱⁿ forming dislocation mobility.

Specifically, if the external force is such that the quan-

tity q ⁼ 2TujcV2 ¹ ( T is ^the temperature, ^{a is the} external applied strain, ^{V is the} energy of interaction of a defect with the dislocation, ^c is the concentration of defects), then drift of kinks along the dislocation becomes nonlinear in time (sublinear law) : ^{w - tq} (x

is the displacement ^{of a kink over time} t), ^{and, as a}

consequence, the mobility of the dislocation sharply

decreases. We have studied, among things, ^disloca-

tion dynamics ^under the action of a pulse force, ^and

found that the decrease in mobility with the increase in pulse frequency might really ^{be a} consequence of the IIX _ tqll -effect.

As a model of a dislocation for numerical simula- tion we chose that of an elastic string, ^whose equation

of motion is of the form (we believe the friction in the system ^{to be} large, ^{so that we can} neglect the inertial

term) :

It is assumed here that the dislocation initially ^lies along ^{the x} axis, u ^{is its} transverse displacement, ^{x is}

the elastic constant, Uo ^{is the} height of the Peierls

barrier, ^{r is} the kinetic coefficient, -fez) ^{is external}

force _per unit lenght ^of dislocation, U1(x, u) ^{is a ran-}

dom quantity, describing distortion of the Peierls bar- rier by defects, is the lattice parameter. ^{The last term} in the rhs of (1) ^{is a} Langevin force, ^{which is a source}

of thermal fluctuations of the dislocation line. The

angular ^brackets (...) ^denote thermodynamical ^aver- aging. The values of the coefficients in (1) ^{were chosen}

close to their actual experimental ^values.

Discretizing the dislocation into N elements (each ^of

them _may be viewed as a lattice site), ^we bring equa- tion (1) ^{to a finite} difference form :

where u(i) ^{is the} displacement of the itch element at the time instant t, u’(i) ^{is its} displacement ^{at the time}

t + At, At is the discrete time step, ci ^{= x} .r, f ⁼ F.r, u(u(i)) ⁼ r.(gU/au. The external field is either

stationary ^{or a train of} square pulses ^{with the} period

T and duration tp.

The thermal force £ ^was approximated by ^{a se-}

quence of pulses ^{of random} amplitude with normal distribution and dispersion - ^{T. The} spacing ^between

the pulses ^{had an} exponential distribution with the mean Tf .

The lattice potential ^{U was} chosen in the form U ⁼ Uo ^sin (y/27ra). ^{Defects were placed in} randomly

chosen sites with the probability ^{i = ac} (where ^{a is}

the lattice parameter, c, the volume concentration of

defects) and where assumed to be short-range (acting withing ^{one lattice} spacing).

In the course of our numerical experiment ^we

simulated motion of dislocations of length ^{N =1000}

-

4000 lattice parameters, ^{in the} absence, ^{as well}

as in _presence of defects, and both in stationary ^an pulse external fields. We computed ^mean dislocation

velocity, ^{v, kink} concentration, Nk, ^{and kink} mobility,

u.

In order to test the numerical model and the program, ^we studied dislocation dynamics ^{in a} per- fect crystal ^and compared ^our numerical results at the temperature ^{T = 0.15} Uo ^{with the} analytical ^re- sults, ^obtained by Buttiker and Landauer [12], ^who

had studied the model (1) without defects. Figure

1 presents ^the dislocation velocity ^{as a} function of external force according to [12] (dashed curve) ^and

our numerical result. We also obtained the disloca- tion velocity ^v and kink concentration Nk ^{as func-}

tions of a stationary external force (the ^{solid curves}

in Fig. 2). ^The commonly accepted view is that at

large forces the kink concentration and dislocation ve-

locity ^should depend ^{on force} exponentially [1]. ^For

force F Uo kink concentration is almost force-

independent ^{and the} dislocation velocity ^{should be} simply proportional ^{to F} (linear law). ^{Our numer-}

ical results are in fairly good agreement ^{with these} predictions, the transition from exponential ^{to linear}

law taking place ^at FIUO c-- 0.12, confirming ^{the the-}

Fig. 1.-Comparison ^{of our numerical data and} analytical ^results [12] (dashed line). Dislocation velocity ^{as a} function of applied

force.

Fig.2.-Kink concentration Nk (per thousand lattice _parame-

ters), dislocation velocity ^{v and kink} mobility p ⁼ v / Nk / F ^as

functions of exernal force F in perfect crystals (solid curves).

a ⁼ 0.5, Ud ^{= 0.5} Uo. ^The force is in units of Peierls barrier.

Units of mobility ^and velocity ^{are their values at F = 0.1} Uo.

T ⁼ 0.5 Uo.

oretical estimates of [1]. Furthermore, ^we studied the

dependence ^{of v and} Nk ^{on the} frequency ^{of a} pulse

external force (in the nonlinear region), ^{for a constant} period-to-duration ration 2:1 (Fig.2). ^{It is clear that}

the dislocation velocity ^{under the action of a} high- frequency force should be approximately equal ^{to that}

under the action of a half-amplitude low-frequency

force. Our numerical results (Fig.2) ^{agree well with}

this idea. Note that in the case under consideration

(nonlinear ^{region, no} defects) ^the frequency depen-

dence of dislocation velocity ^is completely ^determined by that of kink concentration.

Kink concentration, dislocation velocity ^{and kink} mobility ^as functions of external force in a crystal

with defects ^are depicted ⁱⁿ figure ² (dashed lines).

In the _range of external forces 0.15 Uo ^0.4 Uo ^the

dislocation velocity in disordered crystals ^is larger,

while outside of this _range, smaller, ^{than in a} crys- tal without defects (Fig.2b). ^{Such a} behaviour of the

velocity ^{could be} easily explained within the frame- work of the model [111. ^{At forces 0.4 Uo F Uo}

the kink creation _energy is sufficiently small, ^{and the}

contribution of defects to generation of kinks is in-

significant. ^{In this case} the defects only slightly ^slow

down the motion of kink along the dislocation line. At F 0.4Uo ^a majority ^{of kinks are created} by ^clusters

of defects, locally lowering the Peierls barrier. Thus,

at F 0.4 Uo ^defects promote generation ^{of kinks}

(Fig.2a), while their braking of kink motion is still

insignificant and the dislocation velocity ^is greated

than in a perfect crystal. As the external force fur- ther decrease, ^an abrupt change in the character of kink motion along the dislocation takes place ^{in disor-}

dered crystals, according ^to [11] (at ^a threshold force F ⁼ Fo, ^when q ⁼ 2 FoT/cUd =1) : the law of kink motion becomes sublinear. The sharp drop ^{in dis-}

location mobility (and, therefore, velocity) ^observed

at F 0.15 Uo ⁱⁿ disordered crystals (Fig.2c), ^{is a}

consequence of the above-mentioned slowing ^{down of}

kink spreading ^{at F 0t15} Uo. ^The experimental

value of the parameter q =1.2 agrees well with that

predicted ⁱⁿ [111 (q ⁼ 1). ^{It is easy to see that the} mobility drop ^takes place within the force _range, in which the kink concentration Nk depends ^{no more on}

the applied ^force i.e., within the linear _range.

In order to study ^{the influence} of defects on dislo- cation dynamics under the action of a nonstationary

force in the nonlinear region, ^we applied ^{to the dis-}

location a train of _square pulses ^{with the} amplitude

F ⁼ 0.5 Uo. ^The period-to-pulse ^{duration ratio was}

chosen to be 2:1. This was exactly ^{the same kink of}

pulse ^{force as} that used in [9,10]. ^The temperature

T was chosen to be T = 3 ^Uo, the concentration of

defects and their potential ^{c =0.3 and Ud± O.lx} Uo,

respectively (the ^{sign is} random). It turned out that

the frequency dependence ^of dislocation velocity ⁱⁿ

1398

the _presence, as well as in the absence of defects, ^ac- tually copies that of kink concentration Nk. ^What’s

more, in the _presence of defects the kink concentra-

tion, and, therefore, dislocation velocity ^{are 1.5 times} greater ^{than in a} perfect crystal. ^Our results show that the role of defects in the nonlinear region ^{is re-}

stricted to increasing ^the nucleation rate : it is ^eas- ier for kink-antikink pairs ^{to be born at} clusters of

barrier-lowering ^defects. However, ^the defects do not

change ^the general character of the frequency depen-

dence of dislocation velocity.

Fig.3.-Kink concentration (triangles) and dislocation velocity (circles) ^{as functions of the} period ^of pulse ^{external force in} perfect crystal ^{at T = 0.5} Uo, F ^{= 0.5} Uo (all ^{units same as}

in Fig.2, except ^{for the} pulse period, normalized by ^{time of} displacement ^of dislocation by ^{1 lattice} parameter ^{under sta-} tionary ^external force).

In the linear region, ^{as noted} above, ^{a more} sig-

nificant role is played by braking ^{of kink motion} by

defects. We expect this effect to be particularly ^im- portant ^{in the case of a} dislocation, moving ^under

the action of pulse ^force in the linear region, ^{as in}

the experiments [9,10]. ^{Depicted in figure 4 are the}

kink concentration and dislocation velocity ^{as func-}

tions of the period ^of constant-amplitude ^{and con-}

stant period-to duration ratio pulses ^{in a} crystal ^with

defects. The amplitude ^{of the} pulse ^{force was chosen} slightly higher ^{than its threshold value for a station-}

ary force (F ⁼ O.lC/o)’ ^{One can see that at low pulse} frequencies the kink concentration and dislocation ^ve-

locity ^{are the same as in the case of} stationary ^force (when normalized to active time). ^{However, as the}

Fig.4.-Kink concentration (triangles) ^and dislocation velocity (circles) ^{as functions of} external force pulse period ⁱⁿ crystal

with defects (E ⁼ 0.5, Ud ⁼ 0.5 Uo).

pulse ^force frequency increases, ^a sharp drop ^{of dislo-}

cation velocity ^{is observed. A} peculiarity ^{of this} drop

is that it is not accompanied (as ^{was the case in the}

linear region) ^{by a} decrease in the kink concentra- tion. On the contrary, ^{the latter even} grows ^as the

frequency increases. Thus, the above data show that the decrease in dislocation velocity ^{is due to} braking

of kink motion by defects, rather than to suppression

of kink generation ^at high frequencies.

In addition to the frequency dependences ^{of dis-}

location velocity ^{and mean kink} concentration, ^we

also obtained the dependences ^{of these} quantities ^on

the period-to pulse ^{duration of the} force, ^{for constant}

duration of the pulses. ^These dependences (not ^nor-

malized to active time) ^{are shown in} figure ^{5 and are}

in qualitative agreement ^{with the} experimental ^re-

sults of [9,10].

Fig.5.-Kink concentration (triangles) and dislocation velocity (circles) ^as functions of spacing ^between pulses, normalized to constant pulse duration in crystal with defects (E ⁼ 0.5, Ud ⁼

0.5 Uo).

We have studied, by ^means of numerical simula-

tion, ^{the influence} of defects on dislocation dynam-

ics in Peierls relief under both stationary ^and pulse loading. ^{It was} demonstrated that in the case of sta-

tionary ^and pulse loading. ^{It was} demonstrated that

in the case of stationary external force defects lower

dislocation mobility in the linear region (F ^0.2 Uo),

by braking ^kink propagation, ^{while at} greater ^forces

(F > 0.2 !7o) clusters of barrier-lowering defects rise nucleation rate, ^there by increasing dislocation mobil-

ity ^and plasticity ^{of the} crystal. The threshold force

value, ^{at which a} sharp drop in dislocation mobility

is observed was found to be close to the critical force

Fo, ^{at which} the transition from linear x N t to sub- linear x N t7, q 1 law, predicted ⁱⁿ [111, ^{takes place.}

A study ^{of the} dependence ^{of the} velocity ^{of an in-}

dividual kink on a stationary external force showed that in crossing ^{the threshold f = Fo} the charac- ter of the kink motion undergoes ^{a radical} change,

and in the case of low forces a kink spends ^{most of}

the time in traps (formed by ^defect clusters). ^{It was}

demonstrated that defects do not alter the character of dislocation dynamics ^{in the case of} pulse loading

with large amplitudes, corresponding ^to the nonlin-

ear region. However, ^{at small} amplitudes of external

force, ^{close to} Fo (the sublinear kink motion thresh-

old), ^{a sharp drop} in dislocation velocity ^as frequency

increases is observed. The results obtained enable us

to come to the conclusion that the sharp drop ^{in dis-}

location mobility, ^observed experimentally [9,10] ^at

high frequencies ^{of the} pulse loading, might ^{be a con-}

sequence of braking ^{of kink} propagation by defects,

rather than of suppression ^{of kink} generation ^at high frequencies. The latter effects is altogether ^{absent in}

the linear region. Indeed, dislocation velocity ^{in a} perfect crystal ^is [1,2]

where u is the kink propagation velocity, W(F) ^{is the}

energy of creation of a kink-antikink pair, depending

on the stationary external force F. If the frequency

of the external force is much lower than the mean

nucleation frequency, corresponding ^{to a} stationary

force of the same amplitude, ^then

where the angular brackets denote averaging ^{over a} period. ^{In the} opposite limiting ^{case of} high (i.e.,

much higher that the nucleation frequency) frequen-

cies

The transition from vlif to vl f should be sufficiently gradual, ^as illustrated by figure ^3. In the linear regime

the nucleation _energy W is virtually independent ^of

the applied force, ^{so that vi.f m Vh. f. In other} words,

in a perfect crystal ^{in linear} region ^{one should not ex-} pect ^a significant change in dislocation velocity during

the transition from high (in ^{the above} sense) ^{to low}

frequencies ^{of the external} pulse ^force.

Note that in the linear region, as one can see

from (4) ^and (5), ^the following ^{relation must hold} (after normalization to the active time) :

where v(F) is the dislocation velocity ^{in a} stationary

external field F, equal ^{to the} amplitude ^{of the} applied pulse ^force. Comparing ^the results, obtained for the

case of stationary loading ^{in the absence of defects}

with those shown in figure 3, one can see that relation

(6) ^{holds to a} good accuracy.

All the values of parameters, ^{used in our numer-} ical simulation were close to actual experimental ^val-

ues for semiconductor crystals ^with high ^{Peierls bar-} riers, ^{with the} exception ^of temperature, ^{which was} by ^far higher ^{than in} laboratory experiment. ^Such

a choice of T was dictated by the limitations of the computers ^available.

Summing up, ^we would like to point ^{out that our}

results show that point defects in crystal lattice have

an extremely profound ^{effect on} dislocation dynamics.

One might expect ^{that at lower} temperatures, ^closer

to actual experimental values, the effects we have ob- served (dislocation mobility threshold, frequency ^de- pendence of dislocation velocity in nonlinear region, nonlinearity ^{in kink} motion) would be much sharper

and more pronounced.

Acknowledgements

We are grateful ^{to V.I.} Nikitenko, B.Ya. Farber and V.Ya. Kravchenko for useful discussions of the model and results.

References

[1] ^{LOTHE, J., and HIRTH, J.P., Phys. Rev. 115} (1959) ^543.

[2] KAZANTSEV, P.A., ^and POKROVSKY, V.L.,

ZhETF 58 (1968) ^677.

1400

[3] ^{PATEL, J.R. and} CHANDHURI, A.R., Phys. ^Rev.

143 (1966) ^601.

[4] ^EROFEEV, V.N., NIKITENKO, ^V.I. and OSVENS- KII, V.B., Phys. ^{Status Solid 35} (1969) ^79.

[5] ^EROFEEV, V.N.; ^and NIKITENKO, V.I., ^{Fiz. Tv.}

Tela 13 (1971) ^146.

[6] PETUKHOV, B.V., Fiz. Tv. Tela 13 (1971) ^1445.

[7] PETUKHOV, B.V., ^and SUKHAREV, V.Ya., ^Fiz.

Tv. Tela 22 (1980) ; ^{Fiz. Tv. Tela 23} (1981)

1093.

[8] ^{PETUKHOV, B.V.,} Fiz. Tv. Tela 25 (1983) ^1822.

[9] NIKITENKO, V.I., FARBER, B.Ya., ^and LUNIN,

Yu.L., ^{Pis’ma ZhETF 41} (1985) ^103.

[10] ^FARBER, B.Ya., LUNIN, Yu.L., ^and NIKITENKO, V.I., Phys. Status Solid a 97 (1986) ^469.

[11] ^VINOKUR, V.M., ^J. Physique ⁴⁷ (1986) ^1425.

[12] ^BUTTIKER, M., ^and LANDAUER, R., Phys. ^Rev.

A23 (1980) ^1397.
