CHARACTERIZATION OF SMALL SEDIMENTARY STRUCTURES IN ROCKS OF THE GLEN TORRIDON REGION (GALE CRATER, MARS) USING PHOTOGRAMMETRY. G. Caravaca1*, N. Man- gold1, S. Le Mouélic1, L. Le Deit1, O. Gasnault2, F. Rivera-Hernandez3, C. M. Fedo4, K.S. Edgett5, R.C. Wiens6
1UMR CNRS 6112 LPG, Université de Nantes, France, 2IRAP, Toulouse, France, 3Dartmouth College, Hanover, NH,
4Dept Earth & Planetary Sciences, University of Tennessee, Knoxville, TN. 5Malin Space Science Systems, San Diego, California, USA, 6LANL, Los Alamos, USA. *gwenael.caravaca@univ-nantes.fr.
Introduction: The Glen Torridon (GT) region in Gale crater, Mars, has been explored by the Mars Sci- ence Laboratory Curiosity rover since ~Sol 2300 (Feb.
’19), seeking traces of the clay-bearing minerals ini- tially detected from orbiter data [1]. The lowermost lo- cations of the GT trough are dominated by the Jura member mudstones, and fine-grained sandstones of the Knockfarril Hill member above it. The latter exhibit multi-scale laminations and cross-bedding. The precise characterization of these sedimentary structures is criti- cal for understanding the stratigraphic relationships be- tween the GT members, but also the hydrodynamical conditions that prevailed during deposition of these sed- iments. Some of the smallest structures encountered by Curiosity were observed using the Mars Hand Lens Im- ager (MAHLI) instrument which can resolve coarse silt (62.5 μm) at a distances of ~2 to 4 cm. In this study, we use MAHLI images and Structure-from-Motion (SfM) photogrammetry to reconstruct 3D micro Digital Out- crop Models (DOM) of GT rocks for interpreting small- scale 3D sedimentary structures.
Micro-DOM Reconstruction using Structure- from-Motion Photogrammetry: To image outcrops and/or individual rocks from a closer perspective, we can use MAHLI, a color micro-imager on the rover’s robotic arm [2]. MAHLI images are critical to charac- terize grain size distribution and sub-mm- to cm-scale sedimentary structures in rocks. However, 2D photo mosaics are sometimes tricky to interpret and can lead to difficulties in discriminating 3D structures from mo- saicking artifacts. To overcome this issue, a 3D repre- sentation of the outcrops encountered by Curiosity can be useful. We thus use SfM photogrammetry to recon- struct high-resolution 3D micro-DOMs of rock outcrops imaged by MAHLI (e.g. Fig. 1) when the images allow it [3]. Using these 3D outcrop models can help us deter- mine 1) whether specific structures appearing on the 2D mosaics are real or not (e.g. due to parallax) and 2) whether the surficial shapes of outcrops are a product of erosion or original sedimentary structures that can be used to interpret depositional conditions. Three-dimen- sional models also enable us to observe the outcrop from varying points of view. Line-drawing of the 3D geome- try of the strata (e.g., laminae) in an outcrop also helps us to identify and characterize structures that would be difficult to distinguish in planar images (Figs. 1b-c, 2b).
This is especially important in the GT area due to the very fine-grained nature of the observed sandstones, with cm-scale variations in the sedimentary architecture potentially indicative of rapid shifts in laterally evolving depositional settings.
Characterization of 3D Small-scale Sedimentary Structures: The Stack_Of_Glencoul target (Sol 2444) is part of the Teal Ridge outcrop, a ~1.5 meter-high out- crop consisting of cross-laminated sandstones. The out- cropping conditions of the Stack_Of_Glencoul target and its complex 3D shape makes it difficult to assess whether the cross-stratifications observed in the 2D mo- saic are original structures or due to differential erosion.
The 3D micro-DOM of this target (Fig. 1a) helps us con- firm the original nature of these cross-stratifications (Fig. 1b). Line-drawing of these mm-scale laminations (blue lines, Fig. 1c) show the presence of at least four sets of low angle (<15°) cm-scale cross-stratifications, separated by sharp truncation surfaces (red lines, Fig.
1c). These truncations and multiple/alternating direc- tions of propagation in 3D (Fig. 1c) suggest that these sediments were deposited in a dynamic setting such as a fluvial environment. This target also records a com- plex post-depositional history indicated by a network of diagenetic veins (Fig. 1), identified by ChemCam as cal- cium sulfate veins (these have been identified through- out the Murray formation) [4]. Some of the veins cross- cut the laminations, while others occur in-between lay- ers.
The Strathdon target (Sol 2462) shows sub-cm-scale undulating laminations, highlighted by differential ero- sion of the outcrop (Fig. 2). These undulations could be ripple marks but burial can also create similar structures [e.g. 5]. Nevertheless, these laminations are character- ized by cm-scale cross-stratifications with varying di- rections of propagation (green lines on figs. 2b-c), sug- gesting that these sediments were deposited in an ener- getic fluvial setting. In the lower part of the outcrop, un- dulated laminations (possibly ripples) are emplaced un- conformably above a more massive bed as highlighted by the red line on Fig. 2c. This contact hints at poten- tially rapid variations of the hydrodynamical regime be- tween quieter and more energetic settings. This target also records a complex post-depositional history and shows a similar network of calcium sulfate veins as those observed in the Stack_Of_Glencoul target.
1455.pdf 51st Lunar and Planetary Science Conference (2020)
Fig. 1 a) 3D micro-DOM of the Stack_of_Glencoul target (Sol 2444) reconstructed using 15 MAHLI images (https://skfb.ly/6P7zS). b) Close-up view of cross-stratifica- tion structures from a different point of view. c) Interpretation of the same view as (b); blue lines: cross-stratifications; red lines: truncations.
Summary and conclusions: High-resolution photo- grammetric 3D micro-models reconstructed using MAHLI images are useful for accurately identifying and characterizing sedimentary structures on Martian out- crops. Analyses of these 3D structures are important to understand the lateral and vertical variations of the pale- oenvironments in the GT region. While the lowermost part of the GT area contains mudstones deposited in a quiet lacustrine environment, the Knockfarril Hill mem- ber shows a progressive shift toward a more dynamic depositional setting as evidenced by its sedimentary structures. Further additional work will be carried out to integrate composition data from the ChemCam instru- ment in order to assess potential geochemical variations in line with observed variations of the sedimentary structures. These sedimentary facies changes (through
time and space) might have critical implications regard- ing the deposition and/or in situ formation of the clay- bearing minerals observed in the GT region.
Fig. 2 a) 3D micro-DOM of the Stathdon target (Sol 2462) reconstructed using 18 MAHLI images (https://skfb.ly/6P7tz).
b) and c) Close-up views of different sets of cross-stratifica- tions from varying points of view. Green lines: cross-stratifi- cations; red line: unconformable contact (dashed lines denotes parts of the contact hidden under an overlying lamination).
Acknowledgments: EU H2020 PlanMap project.
References: [1] Milliken, R.E. et al. (2010) Ge- ophys Res Lett, 3, L04201. [2] Edgett, K. S. et al. (2015) MSL MAHLI Technical Report 0001, Version 2. [3]
Caravaca, G. et al. (in press) Planet Space Sci. [4] L’Ha- ridon et al. (2018) Icarus, 311, 69-86. [5] Alexander, J.
(1987) Geol. Soc. SP, 29, 315-324
