network-scale dynamics of flow regimes
presented to the Faculty of Science of the University of Neuchˆatel to satisfy the requirements of the degree of Doctor of Philosophy in Science
by
Behnam Doulatyari
Supervisory Committee:
Prof. Dr. Mario Schirmer, Universit´e de Neuchˆatel (Director of the thesis) Prof. Dr. Daniel Hunkeler, Universit´e de Neuchˆatel (Co-director of the thesis) Prof. Dr. Gianluca Botter, Universit`a degli Studi di Padova (Technical supervisor)
Prof. Dr. Alberto Bellin, Universit`a degli Studi di Trento (External reviewer)
Defended : 03.11.2015
Universit´e de Neuchˆatel 2015
Secrétariat-décanat de Faculté Rue Emile-Argand 11 2000 Neuchâtel - Suisse Tél: + 41 (0)32 718 2100 E-mail: secretariat.sciences@unine.ch
IMPRIMATUR POUR THESE DE DOCTORAT
La Faculté des sciences de l'Université de Neuchâtel
autorise l'impression de la présente thèse soutenue par
Monsieur Behnam DOULATYARI
Titre:
“Analytical modeling of reach-scale and
network-scale dynamics of flow regimes”
sur le rapport des membres du jury composé comme suit:
- Prof. ass. Mario Schirmer, Université de Neuchâtel, directeur de thèse
- Prof. Daniel Hunkeler, Université de Neuchâtel, co-directeur de thèse
- Prof. Gianluca Botter, Università degli Studi di Padova, Italie
- Prof. Alberto Bellin, Università degli Studi di Trento, Italie
Neuchâtel, le 1
erdécembre 2015
Le Doyen, Prof. B. Colbois
