Structural effect of heavy ion irradiation on GdBaCuO ceramics

HAL Id: jpa-00246161

https://hal.archives-ouvertes.fr/jpa-00246161

Submitted on 1 Jan 1990

HAL is a multi-disciplinary open access

archive for the deposit and dissemination of

sci-entific research documents, whether they are

pub-lished or not. The documents may come from

teaching and research institutions in France or

abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est

destinée au dépôt et à la diffusion de documents

scientifiques de niveau recherche, publiés ou non,

émanant des établissements d’enseignement et de

recherche français ou étrangers, des laboratoires

publics ou privés.

Structural effect of heavy ion irradiation on GdBaCuO

ceramics

M.-O. Ruault, H. Bernas, M. Gasgnier, J.-C. Levet, H. Noel, P. Gougeon, M.

Potel

To cite this version:

Structural effect of

_heavy

ion irradiation

on

GdBaCuO ceramics

M.-O. Ruault

_(1),

H. Bernas

_(1),

M.

_Gasgnier

_(2),

J.-C. Levet

_(3),

H. Noel

_(3),

P.

_Gougeon

₍₃₎

and M. Potel

₍₃₎

(1)

Centre de

_{Spectrométrie}

Nucléaire et

_{Spectrométrie}

de Masse,

IN2P3,

91405

_{Campus Orsay,}

France

(2)

UPR210 CNRS Bellevue, 1

_place

A. _Briand, 92195 _Meudon, France

(3)

Laboratoire de Chimie Minérale B, LA254, Université de Rennes 1,

Campus

de Beaulieu, 35042 Rennes,

France

(Reçu

le 28 mai 1989,

accepté

le 24 août

₁₉₈₉₎

Résumé. - Nous _avons irradiés des cristaux GdBaCuO _avec des ions Kr de 480 keV à 40 et 300 K. L’évolution

d’un cristal

_présentant

une structure

_monoclinique

voisine de la structure

_{orthorhombique}

a montré

qu’une

petite

déformation initiale du réseau n’a _{pas d’influence} sur les _{défauts étendus induits par irradiation. Nous}

avons mis en évidence le rôle de

_puits

des

_joints

de macles sur les défauts créés. Un film vidéo montre en effet

l’interaction

_dynamique

des dislocations avec les

joints

de macles. Une

_{amorphisation progressive}

est ensuite observée pour des doses > 4 - 5 x

1012 Kr/cm2.

Dans tous les cas une occasionnelle transition vers la structure

tétragonale n’apparaît qu’après

le début de

_{l’amorphisation.}

Abstract.

- The influence of twin boundaries

as sinks on defects induced

_by

480 keV Kr ion irradiation in GdBaCuO

crystals

was observed in situ at 40 and 300 K. The interaction of the dislocations with the twin boundaries followed on a video

_recording.

A

_crystalline

to

_amorphous

transition was observed above a total fluence of ~ 4 - 5 x

1012 Kr/cm2.

A

_comparison

between orthorhombic

_(Os)

_crystals

and a monoclinic structure

(Ms) (close

to Os and whose _parameters were

_calculated)

shows that the behaviour of irradiation-induced

extended defects does not

_depend

on a small initial deformation of the orthorhombic cell. In both case, an

occasional orthorhombic

_{(or monoclinic)}

to

_{tetragonal phase}

transition

_only

occurs when the

_{amorphization}

process has

begun.

Classification

Physics

Abstracts 61.80J -

61.16D - 74.70V

Ion irradiation studies of the

_{high Tc}

superconduc-tors are

_{providing increasingly interesting}

infor-mation on their structural

_stability

_{(e.g. [1-8].}

The controlled introduction _{of defects may also lead} to

important applications

[9-11].

Understanding

the

nature of these

defects,

their evolution and their relation to structural and electronic

_property

_changes

Structural studies related to electrical

investi-gations

with various radiation fields

_(e.g.

120 keV to

1 MeV electrons

_{[3, 6, 12, 13],}

50 to 300 keV He ions

[2, 14],

or 400 to 2 MeV 0 ions

_[1,

_15,

_16])

have demonstrated that with the

_possible

_exception

of GeV-ion irradiations

_[17],

irradiation

_by

different ions at

_{varying energies, produced essentially}

ident-ical effects on the

_{superconducting}

critical

tempera-ture

_T,,

the critical current Jc or on the normal

conductivity

as

_long

as the

_displacement

_per atom

(dpa)

ratio was the same. An orthorhombic to

tetragonal

(OTT)

transition occurs due to a local

oxygen

disordering

and

_then,

at a level 5 to 10 times

higher, amorphization

occurs due to cation

disorder-ing

[2, 7].

This was true, at

_least,

as

_long

as the

deposited

energy

density

(i.e.

the instantaneous concentration of

_displaced

atoms

_along

the incident ion

_trajectory)

remained

_{comparatively}

low such as

for MeV Ar+ or keV He+ 18 .

In _{this paper} we show

_dynamical

transmission electron

_microscopy

_(TEM)

observations of the irradiation-induced defect evolution in GdBaCuO

crystals

under

_heavy

ion irradiation

_(Kr

ions at

480

_keV).

Such

_heavy

ions

_produce

_{high deposited}

energy densities in an individual cascade and hence

large

localized defect concentrations. This leads to

dislocation

_(or

dislocation

_loop)

formation as well as

visible clusters creation

_{(yield *}

_0.1,

mean size

- 10 to 20

nm).

As the cluster

density

increases,

amorphization progressively

occurs

(threshold

50

ence = 9 x

1012

Kr/cm2).

Occasionally

we observed in

_parallel

an orthorhombic to

_tetragonal

_(OTT)

transition

_(no

_phase

transition was observed below

the

_{amorphization}

threshold

_dose).

A second

import-ant

_point

is the

_{high mobility}

of the irradiation induced defects which

_gives

rise to a

_spectacular

interaction with the twin boundaries at 40 K as well as at room

_temperature.

This

effect,

observed for the first time to our

_knowledge,

leads to both the dislocation motion and twin

_boundary

deformation. All these observations are still valid in the case of

a monoclinic structure

_{(Ms) corresponding}

to a

deformation of the basic orthorhombic

_(Os)

lattice. The lattice

_parameters

are calculated and some

information relative to _{the space group of the}

monoclinic structure are obtained.

Experimental.

1. SAMPLE CHARACTERISATION. - Small

GdBaCuO

_single

_{superconductor crystals}

_{[19, 20]}

were crushed and

_deposited

on carbon-coated

_grids

for

_{microscopy investigations.}

Some of the

_deposited

small

crystals

exhibit a monoclinic structure

_(Ms)

close to the Os. The determination of this structure

is

_reported

below. In this work we

_mainly

followed

the structural evolution at 40 and 300 K of Os

crystals

with the c axis both

_{perpendicular}

and

parallel

to the free surfaces which exhibit twin boundaries. At 40 K a monoclinic

_crystal

was also

studied.

2. IRRADIATION CONDITIONS. - The 480 keV Kr

ion irradiations were

_{performed in}

situ in a

_Philips

EM400 electron

_microscope

on line with the ion

implantor

[21].

We have used a standard double tilt

sample

holder for the 300 K irradiation and a

custom-built

_single-tilt

helium-cooled

_sample

holder

[22]

for the 40 K

_{investigations.}

To avoid a

_sample

temperature

increase

_during

irradiation,

the dose

rate was

_kept

down to - 2 - 4 x

109

Kr

cm- 2

s-1.

The maximum fluence reached was 2.5 x

1013

Krlcm2,

so that even the maximum fluence

_only

leads to a Kr

doping

level of a _{few ppm in the matrix}

and the induced

_damage

is

_essentially

due to ir-radiation effects.

Results.

1. MONOCLINIC STRUCTURE DETERMINATION.

-Electron diffraction

_patterns

_(EDP)

taken

_prior

to

irradiation show a deformed

[111]

zone axis of the

Os structure

_(i.e.

the

_angle

between the

₍₁₀₁₎

and

(011)

directions is not 90° but 86.5°

_(Fig.1)).

From such

_pattern

we deduced a monoclinic structure with the

_following

_parameters

am = 0.403 ± 0.02 _nm,

bm

= 0.384 _± 0.002 _nm,

cm = 2.350 ± 0.05 nm and

f3

= 75° _± 1°.

Comparing

with the orthorhombic

Fig.

1. - EDP from _a GdBaCuO

crystal showing

a

monoclic structure

_{([1 l 1]}

_{zone axis).}

parameters

the

_{corresponding}

ratios are

amlbos

=

1.055,

bm -

aos,

cm - 2

cos. The

interplanar

distances between Os and Ms structures are close :

During

irradiation an

_apparent

defor-mation/rotation of this structure leads to the obser-vation of three successive zone axes

(Fig. 2)

[521 ],

[121

]

and

_[411]

_]

_{(respectively}

above - 3 x 1011,

1.2 x

1013

and 1.7 x

1013

Kr/cmz).

These zone axes were indexed

_according

to the Ms structure

par-ameters found above. We

_specifically

checked that

Fig.

2. - Same

crystal

as in

figure

1

_during

480 keV Kr ion irradiation. EDP

_showing

different zone axes

_{(see text).}

As

_crystal

thickness varies

_through

the area

studied,

little information can be obtained from the

_spot

intensities. In addition no

_ring

_pattern

from a

polycrystalline

area is

_available,

so that the

_missing

planes

cannot be determined. This does not allow an

rules can be deduced

_(e.g.

reflexions are allowed for

(hhf )

with f odd,

(mi)

with f

even,

(h0f )

and

(hk0 )

with h odd and

_{(OkQ )}

with k

_odd).

2. DEFFECT EVOLUTION. - At both 40 and 300

K,

the sequence of observation as a function of

increas-ing

fluence is as follows.

i)

Both in orthorhombic and monoclinic

_crystals,

defect clusters are observed above fluences - 3 x

1011

Kr/cm2.

These clusters

_{(or dislocations)}

interact

immediately

with the twin boundaries : the

_moving

and

_pinning

of dislocations on the twin boundaries are observed on a video

_recording

[23].

Above a

fluence of - 5 x

1011 Kr/cm2

the

_trapping

of defect

clusters on the twin boundaries is observed. At

higher

fluences we observe

_{inhomogeneous}

contrast

and

_{(at -}

1012

_Kr/cm2)

the formation of

_separate

clusters inside the twin boundaries. Defect cluster

trapping

and dislocation

_pinning

on the twin bound-aries thus lead to the deformation of the twin boundaries

_(see

_Figs.

3,

4).

Detailed

_analyses

of this process will be

reported

elsewhere

[24].

These observations show that the defects created in a

_high

damage

cascade

_(i.e.

with

_heavy

_ions)

are _very

mobile

_(even

at low

_temperature)

when the ir-radiation level reaches the cascade

_overlapping

re-gime.

At this

_stage

of

irradiation,

no evidence of an

orthorhombic to

_tetragonal

transition was found in

the Os

_phase

and in Ms

_only

an

_apparent

defor-mation/rotation is observed.

ii)

Above 4 - 5 x

1012 Kr/cm2

the

_heavily

dam-aged

twin boundaries

_{progressively disappear}

as

diffuse

_rings

characteristic of an

_amorphous

structure

appear and are

_{progressively}

enhanced.

-Fig.

3. -

Bright

fields of the same

_crystal

as in

figure

1 : defect evolution

_during

480 keV Kr ion irradiation at

40 K. Doses

_(Krlcm2)

are

_reported

on the

_pictures.

At this

stage

a new

_apparent

deformation/rotation

occurred in the one Ms structure observed and

finally

we observed a Ms to

_tetragonal

transition

(above -

1.7 x

1013

Kr/cm2).

Occasionally

the OTT

transition also occurs in Os

_crystals.

Discussion and conclusion.

i)

From the above results we conclude that a

defor-mation in the Cu-0 basal

_plane

of the orthorhombic

structure

_leading

to a monoclinic structure has no

drastic influence on the structural evolution of the

crystal during heavy

ion irradiation. Whether or not

this deformation _{has any influence} on the

supercon-ducting properties

is still an _open

_question.

ii)

Previous He ion irradiation studies led us to

propose that at least two

types

of defects were

involved in the structural

_changes

observed

during

light

ion irradiation.

First,

very mobile anionic defects _{associated with oxygen} are

_responsible

for the cluster formation at low

temperature

and for the OTT transition.

_Secondly

less mobile cationic defects

are related to

_{amorphization}

_[8].

For

_heavy

ion irradiation OTT occurs at the same level of disorder

as for

light

ion irradiation

( -

0.1

displacement

per

atom ratio :

_dpa).

For reasons discussed in reference

[8],

it is

_univocally

related to sublattice

_disordering.

The results obtained here

_strongly

indicate that there is no difference in the process

leading

to the OTT between

_light

and

_heavy

ion irradiation. The

amorphization

process is

simply sufficiently

efficient in the

_heavy

ion irradiation case to

_partially

mask the OTT.

iii)

In the case of

_heavy

ion

irradiation,

the

amorphization

occurs at fluences which are more

than 3 orders of

_magnitude

lower than for He irradiation

_(above

4 - 5 x

1012 Kr/cm2

instead of

10 16

_He/CM2).

For

_heavy

ion

irradiation,

the

aver-age energy transferred per collision is

significantly

larger

so that cation

_{displacements}

are

_definitely

enhanced. Also the

_deposited

energy

density

is about two orders of

_{magnitude larger}

than in the

light

ion irradiation

_(according

to TRIM calculation

[25]

the average numbers of

displaced

cations for He and Kr ion irradiation are

_{respectively -}

60 and

1 600).

iv)

In order to

_analyze

the

_{amorphization}

_process,

e o _{owmg ques} ion anses. or r irra ia

_ion,

could

_amorphous

zones be created

directly by the

individual cascades so that

_{amorphization}

would

proceed by simple

cascade

_{overlap ?}

From our

results,

we obtain the

following

information

regard-ing

this

_question.

1)

The threshold fluence of

_{amorphization}

is at

least an order of

magnitude higher

than the

threshold fluence for the cascade

_overlap

( - 1010 Kr/cm2).

This value does not take into

52

Fig.

4. - Defect evolution of

an orthorhombic GdBaCuO

crystal

(with

c axis

parallel

to the zone

_axis)

irradiated at

300 K with 480 keV Kr ions.

cascades as we consider the

_overlap

of the whole

extension of the cascade

_(i.e.

both

_light

and

_high

damage density

zones)

instead of

_only

subcascade

overlap

(high

damage density

zones).

This result indicates that

_{amorphization}

does not

_{proceed by}

the

_overlap

of

_{light damage}

_density

zones. However

amorphous

zones could be created

_directly

inside subcascades

_(i.e.

_{large damage}

_{density zones).}

2)

The clusters observed

_{( >}

1011

_Kr/cm2)

below the threshold fluence for subcascade

_overlap

5 x

1011

_Krlcm2)

are

_directly

formed inside subcascades.

However cluster interaction which leads to the formation of dislocations and their interaction with twin boundaries

_imply

that the clusters involved in this interaction _{process do} not have an

_amorphous

structure.

3)

Although

most of the visible clusters are

cer-tainly

not

_{amorphous, they}

_represent

less than 10 % of the

_high

_{density damaged}

zones created

_directly

in

partially amorphous

is still an unresolved

_question

[23, 26],

but in any case the

_{amorphization}

is not

induced

_by

the

_overlap

of visible

_amorphous

clusters. This leads us to _{propose that}

_amorphized

zones are created inside an individual cascade but are

either relaxed or _{very small in size}

₍

2

_nm)

and do

not lead to visible strained

_amorphous

clusters. The

overlap

of these

_amorphous

zones induces

amorphi-zation. Therefore two

_types

of extended defects are

probably

formed

_{during heavy}

ion irradiation :

i)

unresolved dislocation

_loops

which leads to dislo-cation formation and interaction with twin

bound-aries ;

ii)

amorphous

zones,

presumably

invisible

by

TEM,

which induce

_{amorphization.}

Acknowledgments.

We thank 0. Kaïtazov for

_help

with the irradiations. This work was

_{partially supported by}

the PIRMAT

(ARC

«

Microstructure »)

CNRS,

France.

References

[1]

CLARK G.J., LE GOUES F. K., MARWICK A. D.,

LAIBOWITZ R. B. and KOCH R. H.,

Appl. Phys.

Lett. 51

₍₁₉₈₇₎

1462.

[2]

RUAULT M.-O., BERNAS H., LESUEUR J.,

DUMOULIN L., NICOLAS M., BURGER J.-P.,

GASGNIER M., NOËL H., GOUGEON P., POTEL M. and LEVET J. C.,

Europhys.

Lett. 7

₍₁₉₈₈₎

435.

[3]

KIRK M. A., BAKER M. C., LIU J. Z., LAM D. J. and WEBER H. W.,

High

temperature

Superconduc-tors, Eds.

Brodsky

M. _B.,

_Dynes

R. C.,

Kitaza-wa K. and Tuller H. L., Mater. Research

Society

Proceedings

(Pittsburgh Pa)

99

₍₁₉₈₈₎

p. 209.

[4]

KATO T., AIHARA K., KUNIYA _J., KAMO T. and MATSUDA S.,

Jpn

J.

_{Appl. Phys.}

27

₍₁₉₈₈₎

L564.

[5]

XIONG G. C., LI H. _C., LINKER G. and MEYER O. ,

Phys.

Rev. 38

₍₁₉₈₈₎

240.

[6]

NASTASI M., PARKIN D. M., ZOCCO T. G., KOIKE J. and OKAMOTO P. R.,

Appl.

Phys.

Lett. 53

(1988)

1326.

[7]

PARKIN D. M. and NASTASI M., Abstacts proc. of Mat. Res. Soc. Fall

_Meeting

_{(Nov. 1988)}

Boston

(unpublished).

[8]

RUAULT M.-O., BERNAS H. and GASGNIER M., to

be

_published

in Philos.

_Mag.

[9]

KOCH R. H., UMBACH C. P., CLARK G. J.,

CHAUDHARI P. and LAIBOWITZ R. _B.,

_Appl.

Phys.

Lett. 51

₍₁₉₈₇₎

200.

[10]

MARWICK A. D. and CLARK G. J., 7e Int. Conf. on

« Ion

Implantation Technology

ITT’88 »

(Kyoto

1988),

to be

_published

Nucl. Inst. Meth. B.

[11]

WHITE A. E., SHORT K. T., DYNES D. C., LEVI A.

F. _J., ANZLOWAR _M., BALDWIN K. W.,

DUNKLEBERGER L.,

Appl.

Phys.

Lett. 53

₍₁₉₈₈₎

1010.

[12]

MITCHELL T. _E., ROY T., SCHWARZ R. B., SMITH J. F. and WOLHLLEBEN D., J. Electron Microsc. Tech. 8

₍₁₉₈₈₎

317.

[13]

CLARK G. J., MARWICK A. _D., LE GOUES F. K.,

LAIBOWITZ R. B., KOCH R. and MADAKSON P.,

Nucl. Instrum. Methods B 32

₍₁₉₈₈₎

405.

[14]

EGNER _B., GEERK J., LI H. _C., LINKER G., MEYER O. and STRELHAU B.,

Jpn

J.

Appl.

Phys.

26

(supp. 26-3) (1987)

2141.

[15]

LE GOUES F., RUAULT M.-O., CLARK G. J., BERNAS H. and GASGNIER M., Philos.

_Mag.,

_{in press}

(1989).

[16]

MURAKAMI K., ERYER O., TAKITA K. and MASUDA

K.,

Jpn

J.

Appl.

Phys.

26

₍₁₉₈₇₎

L1731.

[17]

STUDER F., PROVOST J., GROULT D., RAVEAU B.,

BOUFFARD S., TOULEMONDE _M., JOUSSET J. C. and RULLIER-ABENQUE F., Mater. Res. Soc. Fall

_{Meeting : Sympos.}

Proc. 99

₍₁₉₈₈₎

p. 877.

[18]

CHEN C. H., WHITE A. E., SHORT K. T., DYNES R.

C., POATE J. M., JACOBSON D. C., MAN-KIEWICH P. M., SKOCPOL W. J. and HOWARD R.

E.,

Appl. Phys.

Lett. 54

₍₁₉₈₉₎

1178.

[19]

THOLENCE J. L., NOEL H., LEVET J. C., POTEL M.

and GOUGEON P., Solid State Commun. 65

(1988)

1131.

[20]

GASGNIER M., RUAULT M.-O., TREMBLAY P., GOU-GEON P., POTEL M., LEVET J. C. and NOËL H.,

J. Solid State Chem. 74

₍₁₉₈₇₎

74.

[21]

RUAULT _M.-O., CHAUMONT J., BERNAS H., Nucl. Instrum. Methods 209-210

₍₁₉₈₃₎

351.

[22]

SALOMÉ M., RAYNAUD B., SHACK M., CHAUMONT

J., RUAULT M.-O. and BERNAS H., J.

Phys.

E 18

₍₁₉₈₅₎

331.

[23]

RUAULT M.-O. and BERNAS H., Int.

_Workshop

on

« Ion Beam modification and

_processing

of

High

Tc superconductor: Physics

and Devices

(Mins-ter

_Lovell)

_April

1989,

unpublished.

24 RUAULT M.-O. and BERNAS B. submitted to

Europhys.

lett.

[25]

ZIEGLER J. F., BIERSACK J. P. and LITTMARK V.,

The

_stopping

and range of ions in solids, I and II

(Pergamon

Press, N.

_Y.)

1986.

[26]

KIRK M. A., Int.

_Workshop

on « Ion Beam

modifi-cation and

_processing

of

_{High Tc}
