Real-time image-based RGB-D camera motion tracking

and environment mapping

Tommi Tykkälä

To cite this version:

Tommi Tykkälä. Real-time image-based RGB-D camera motion tracking and environment map-ping. Other [cs.OH]. Université Nice Sophia Antipolis, 2013. English. �NNT : 2013NICE4058�. �tel-00933813�

(2)

É

COLE DOCTORALE

STIC

Sciences et Technologies de l’Information et de la Communication

THÈSE

pour obtenir le titre de

Docteur en Sciences

de l’Université de Nice - Sophia Antipolis Mention : INFORMATIQUE

présentée par

Tommi T

YKKÄLÄ

Équipe d’accueil : Autonomous Navigation and Mapping Systems, CNRS-I3S, UNS, France et Machine Vision and Pattern Recognition Laboratory, LUT, Finland

R

EAL

-

TIME

I

MAGE

-

BASED

RGB-D C

AMERA

M

OTION

T

RACKING AND

E

NVIRONMENT

M

APPING

Supervised by Dr. Andrew I. Comport1_{and Dr. Joni Kämäräinen}2

1_{Autonomous Navigation and Mapping Systems, CNRS-I3S, University of Nice Sophia-Antipolis} 2_{Machine Vision and Pattern Recognition Laboratory, Lappeenranta University of Technology}

Soutenue publiquement le 4 septembre 2013 devant le jury composé de

Andrew I. COMPORT Chargé de Recherche CR1 (CNRS) Directeur de thèse

Joni K. KÄMÄRÄINEN Lappeenranta University of Technology Directeur de thèse Shahram IZADI Microsoft Research, Cambridge Rapporteur

Eric MARCHAND INRIA, Rennes Rapporteur

José Maria Martinez MONTIEL Universidad de Zaragoza Rapporteur Christan BARAT Rechercher à I3S, Sophia-Antipolis Examinateur
