High Resolution Supply Chain Management - Resolution of the Polylemma of Production by Information
Transparency and Organizational Integration
Tobias Brosze, Fabian Bauhoff, Volker Stich
To cite this version:
Tobias Brosze, Fabian Bauhoff, Volker Stich. High Resolution Supply Chain Management - Resolu- tion of the Polylemma of Production by Information Transparency and Organizational Integration.
International Conference on Advances in Production and Management Systems (APMS), Sep 2009, Paris, France. pp.325-332, �10.1007/978-3-642-16358-6_41�. �hal-01055837�
High Resolution Supply Chain Management – Resolution of the polylemma of production by information transparency and organizational integration
Tobias Brosze1, Fabian Bauhoff1, Dr. Volker Stich1
1 Research Institute for Operations Management (FIR) at RWTH Aachen University, Pontdriesch 14/16, 52064 Aachen, Germany
Tobias.Brosze@fir.rwth-aachen.de, Fabian.Bauhoff@fir.rwth-aachen.de, Volker.Stich@fir.rwth-aachen.de
Abstract. High Resolution Supply Chain Management (HRSCM) aims to stop the trend of continuously increasing planning complexity. Today, companies in high-wage countries mostly strive for further optimization of their processes with sophisticated, capital-intensive planning approaches [3]. The capability to adapt flexibly to dynamically changing conditions is limited by the inflexible and centralized planning logic. Thus, flexibility is reached currently by expen- sive inventory stocks and overcapacities in order to cope with rescheduling of supply or delivery. HRSCM describes the establishment of a complete informa- tion transparency in supply chains with the goal of assuring the availability of goods through decentralized, self-optimizing control loops for Production Plan- ning and Control (PPC). By this HRSCM pursues the idea of enabling organiza- tional structures and processes to adapt to dynamic conditions. The basis for this new PPC Model are stable processes, consistent customer orientation, in- creased capacity flexibility and the understanding of production systems as vi- able, socio-technical systems [1, 2].
1 Introduction
Within today’s manufacturing business the ability to produce individualized goods for a price close to a mass product is one of the key challenges to keep production in high-wage countries. Additionally companies have to be able to adapt themselves and their processes to dynamic environment conditions like shifts in customer’s demand, reschedules in supply as well as turbulences in networks without loosing the high ob- jective synchronization enabled by today’s planning approaches. These two chal- lenges constitute the polylemma of production, which’s resolution is the goal of the German Cluster of Excellence on “Integrative Production Technology for High-Wage Countries” at Aachen University (RWTH) (www.production-research.de). “High Resolution Supply Chain Management“ is part of this national initiative funded by the German Research Foundation (DFG).
“High Resolution Supply Chain Management” focuses to solve the dilemma be- tween a high grade of adaptivity (value orientation) and a high objective synchroniza- tion (planning orientation). The final aim is to enable manufacturing companies to
produce efficiently and be able to react to order-variations at any time, requiring process structures to be most flexible.
2 Methodological Approach
To achieve a higher flexibility and a better value-orientation of inter- and in-company PPC processes, it is necessary to replace the present static arrangement of the central- controlled processes [1, 2]. In consequence, self-controlled and self-optimizing supply chains based on decentralized production control mechanisms must replace the classic approach of PPC. Goal of the decentralized PPC is a higher robustness of the system by distributed handling of complexity and dynamics [6].
Technological Preconditions: The higher the knowledge about the facts, the more sophisticated decisions can be made. Thus, a higher information transparency on all levels of the PPC is a precondition for the implementation of a decentralized planning system. The information transparency enables decision makers or intelligent objects to act adequately. Advantages in miniaturization, sensor systems and communication technology enable the paradigm shift of centralized information handling to intelli- gent objects with mobile capabilities (cp. Fig. 1) [5].
Shop Floor MES planning level
SCM planning level ERP planning level
Infomation
Shop Floor MES planning level
SCM planning level ERP planning level
Infomation
Fig. 1. HRSCM – Vertical and horizontal information transparency in production networks
Organisational Preconditions: Producing companies are complex organizational systems. They consist of sophisticated, technological subsystems, constitute a social structure with individuals having own values and goals, interact with a dynamic envi- ronment, and last but not least are adapting or are adapted.
HRSCM aims not only for the technological advantages in production systems, but chiefly for the efficient organization of production systems. In order to understand production systems as socio-technical systems methods of management cybernetic are used to establish a new model of the PPC widening the current perspective and leav- ing beaten tracks [7,10]. One of the most proven corporate-cybernetic approaches which orientates itself explicitly towards the living organism is the „Viable Systems Model“ by Stafford Beer [2] (cp. Fig. 2).
System 3* Functions:
• Real-time acquisition of controlling relevant data:
- Early detection of disturbances - Monitoring of resources
System 2 Functions:
• Standardized routines to react to defined disturbances:
- Adaption of resource allocation - Adjustment of target system
• React to rapid congestions
1a 1b 1c 1d 1e 1f
Process Offer Projecting Design Product
Execute Order Procure Parts Produce Parts Assemble Parts
Ship Product Provide Service
2 3*
5 4 3
Environment
System 5 Functions:
• Normative guidelines regarding classic conflicts of objectives (e.g. lead time vs. work load and minimization of inventory level vs. service level)
• Definition of corporate culture and values System 4 Functions:
• Connection betwe en top level management (system 5) and autonomous management (system 3)
• Reception and processing of information regarding the company environment and forwarding of relevant information to both top level and autonomous management
• Alert filter and forwarding to system 5 via special information channels System 3 Functions:
• Maintenance of inner balance
- Synchronization of subordinate target systems
- Strategic and reactive (unknown disturbances) adjustment of objectives - Specification of escalation levels
- Adjustment of autonomy levels of subordinate systems 1
• Resource allocation according to current target system
• Forwarding of strategic guidelines from system 4 and information about the inner status to system 4
• Definition and update of standard routines for system 2
• Detection and realization of synergy potentials System 1 Functions::
• Accomplish single steps of order management process
Customer, Supplier, Competitors, Service Provider
Customer, Supplier Customer, Supplier Customer, Supplier, Service Provider Supplier
Supplier (Market) Service Provider, 3rd Party Manufacturer, extended Workbench
Logistic- and IT- Service Provider
Logistic Service Provider Customer, Supplier,
Service Provider 1i
1h 1g
System 3* Functions:
• Real-time acquisition of controlling relevant data:
- Early detection of disturbances - Monitoring of resources
System 2 Functions:
• Standardized routines to react to defined disturbances:
- Adaption of resource allocation - Adjustment of target system
• React to rapid congestions
1a 1b 1c 1d 1e 1f
Process Offer Projecting Design Product
Execute Order Procure Parts Produce Parts Assemble Parts
Ship Product Provide Service
2 3*
5 4 3
Environment
System 5 Functions:
• Normative guidelines regarding classic conflicts of objectives (e.g. lead time vs. work load and minimization of inventory level vs. service level)
• Definition of corporate culture and values System 4 Functions:
• Connection betwe en top level management (system 5) and autonomous management (system 3)
• Reception and processing of information regarding the company environment and forwarding of relevant information to both top level and autonomous management
• Alert filter and forwarding to system 5 via special information channels System 3 Functions:
• Maintenance of inner balance
- Synchronization of subordinate target systems
- Strategic and reactive (unknown disturbances) adjustment of objectives - Specification of escalation levels
- Adjustment of autonomy levels of subordinate systems 1
• Resource allocation according to current target system
• Forwarding of strategic guidelines from system 4 and information about the inner status to system 4
• Definition and update of standard routines for system 2
• Detection and realization of synergy potentials System 1 Functions::
• Accomplish single steps of order management process
Customer, Supplier, Competitors, Service Provider
Customer, Supplier Customer, Supplier Customer, Supplier, Service Provider Supplier
Supplier (Market) Service Provider, 3rd Party Manufacturer, extended Workbench
Logistic- and IT- Service Provider
Logistic Service Provider Customer, Supplier,
Service Provider 1i
1h 1g
Fig. 2. The order management process as a socio-technological, viable production system
3 Findings
The Viable System Model (VSM) is conceived in analogy to the human nervous sys- tem which has proven its reliability due to the evolutionary process of billions of years to be the most reliably organized and most adaptable system. The VSM speci- fies the necessary and sufficient constraints for the viability of complex organizations.
These constraints can be subsumed as completeness and recursivity of the system structure. This leads to the requirements of the basic model:
First, all specified managerial and operative functions must be present and net- worked in a way that every function has access to the necessary information. Second, every viable system has to be subsystem of a superior viable system and has subordi- nate viable subsystems itself. Preconditions for this recursive structure are integrated, synchronized target systems, which can be concretized top-down consistently.
The application of the VSM to the order process in manufacturing companies con- stitutes the structure of the reference model for a Viable Production System (VPS).
The reference model is characterized by an explicit process orientation and comprises the whole order processing from the processing of an offer, over the PPC- control loop to the production and delivery of the final product [9]. Within this scope the
model incorporates the organizational view and the process view in one holistic en- terprise modeling method.
Figure 2 shows the top level of the reference model applied to the case of a project producer including exemplary tasks of the different systems. Together with the fol- lowing explanations it outlines the general structure of the model:
Semi-autonomous operative units (systems 1) are embedded in a superordinate multi- level managerial structure. The operative units plan, carry out and control the as- signed tasks based on a given target system and act autonomously within defined boundaries. In cases exceeding the usual grade of dynamics the coordinating system (system 2) is taking action. The central control system of the operative units (system 3) defines the objectives and boundaries of autonomy to obtain the maximal synergy between the assigned units. It is triggered by the coordinating system as well as the monitoring system (system 3*) and hierarchically superior systems. The duties of these superior systems deal with more strategic issues like the consideration of rele- vant future developments (system 4) and the definition of the general orientation of the overall target system. Systems 4 and 5 therefore determine requirements and tar- get values for the operative management (systems 3, 3* and 2) as well as for the op- erative units (systems 1).
To be able to cover all different perspectives on the order processing the structural model is concretized in 4 separate views: The task view, the process view, the infor- mation view and the objective and control view. The task view describes the specific tasks of the different systems. In the process view the sequence of the single process steps to perform both operative and control tasks are defined. Within the information view the flow of information between the systems is characterized. The establishment and sustainment of the synchronized target system is outlined in the objective and control view. Thereby the first and fourth view define the information items and the control logic to be supported by a production management system, while the second and third view support management activities.
To get a more precise impression of the design of such a cybernetic based enter- prise model, exemplarily the process and information view are concretized within a use case. Object of the described case is the process “Inventory Management” as a representative process to be performed and controlled within a semi-autonomous op- erative unit (system 1).
Ensuring the self-optimizing character of the operative units they are designed con- sisting of two elements: A process designed according to the logic of a control loop (cp. Fig. 3) is embedded in an organization for process control (cp. Fig. 4). The con- trol loop character enables the process to cope with a certain level of dynamics by adapting the respective process parameters. In the case of consumption-driven inven- tory management the whole control loop consists of the three sub-loops forecasting, inventory control and procurement. The first control loop forecasting minimizes the forecasting error by an appropriate parameterization of the applied forecasting method. The highly accurate forecast enables the inventory control loop to determine a dynamic reorder level taking the replenishment time and the required internal ser- vice level into account. Initiated by an inventory level lower than the reorder level the optimal order quantity is calculated and compared to the economic order quantity.
Based on this calculation the order is placed.
Forecast
As-Is inventory As-Is service level -
- Orders (t) Procurement
Inventory Control
Forecast error
As-Is service level
As-Is order quantity
To-be service level
Economic Order Quantity Demand (t+1)
Forecast (t+1)
Reorder level (t)
Parameterization -
k-factor
Adjustment Order quantity
- -
- - -
Historical Demand (1,…t)
Forecast
As-Is inventory As-Is service level -
- Orders (t) Procurement
Inventory Control
Forecast error
As-Is service level
As-Is order quantity
To-be service level
Economic Order Quantity Demand (t+1)
Forecast (t+1)
Reorder level (t)
Parameterization -
k-factor
Adjustment Order quantity
- -
- - -
Historical Demand (1,…t)
Fig. 3. Control loop for dynamic, consumption-driven inventory management
The process internal absorption of dynamics (e.g. variations of replenishment time or shifts in customers demand) avoids an overload within the organization of process control. In times of normal dynamics the organization of process control’s activities can be limited to the calculation and monitoring of performance indicators, the supply of the process with the relevant information as well as forwarding of performance in- formation to other processes (cp. Fig. 5). Thus a cross-process transparency is assured and the process owner (e.g. material planner) is able to focus on critical products which are for example subject to a high level of dynamics.
Process
2 1
7 6
3 3A
5 5A
C 4 A B
Process-related Directorate
Process-related Regulatory
Center Metasystemic Functions
A Directoral Function to receive coporate instructions B Directoral Function to report back C Normative Planning Funktion
(process-related Systems 4 and 5) Operations Control
(process-related System 3) 1 Sensory Tranduction 2 Input Synapse 3 Achievement Monitor 4 Directoral Function to Respond 5 Continuous Planning and Programming
Generator 6 Output Synapse 7 Motor Transduction
3A Information Relay to other Processes 5A Information Relay to Corporate
Regulatory Centre Process
2 1
7 66
3 3A
3 3A
5 5A
C 4 A B
Process-related Directorate
Process-related Regulatory
Center Metasystemic Functions
A Directoral Function to receive coporate instructions B Directoral Function to report back C Normative Planning Funktion
(process-related Systems 4 and 5) Operations Control
(process-related System 3) 1 Sensory Tranduction 2 Input Synapse 3 Achievement Monitor 4 Directoral Function to Respond 5 Continuous Planning and Programming
Generator 6 Output Synapse 7 Motor Transduction
3A Information Relay to other Processes 5A Information Relay to Corporate
Regulatory Centre
Fig. 4. Organization of process control
In those cases when the level of dynamics is exceeding the absorption capability of the process, the organizational process control detects deviations between the per- formance indicators and the target values. As a consequence countermeasures like an external adjustment of the process are necessary. This could mean the adjustment of one or more process parameters or even the necessity to reconfigure the whole proc- ess. Concerning the case of inventory management this dynamics could be caused for example by a planned marketing action.
Figure 5 subsumes on a general and exemplarily concretized level the flow of infor- mation which is necessary to assure the required transparency and enable the self- optimization within the target system.
Process- Related Directorate Process-Related Regulatory Centre
Input Spots External Output
Confirmation of Instructions, Information about Compliance of Planning Strategies and general Behavior of
Controlling Process Activities
Target System/ Strategies (e.g. Priorization: Service Level vs. Costs)
Boundaries of Autonomy (e.g. thresholds) Corrective Measures (e.g. Increase Inventory Level)
Ressource Allocation (e.g. Staff, Warehouse Capacity)
Technological Innovations, Service Provider, Cooperation Concepts,
ISO Standards
Interaction with the Environment Process Performance Indicators,
Notifiction of Malfunctions + Plans and Programms
of other Processes Raw Data, Malfunction Descriptions
Synchronized Transmission Of Raw Data and Malfunctions
Synchronized released Operations Analysed and Processed
Information (e.g. Transformation to concrete Instructions)
Programms/ Plans Information concerning Optimization (e.g. continuous improvement)) Process Performance Indicators
ÆInformation about Deviations (e.g. Costs of Inventory, Service Level)
Process Performance Indicators, Fault Reports, Plans and Programs of other Processes (e.g. Marketing Activities, Production downtimes)
Information about Changes of Plans and Diviations other Measures/
Instructions (e.g. Adjustment of Inventory level)
Adjustment of general Principles (e.g. Consumption Driven vs.
Deterministic)
Standards of Behavior, Model of Process (e.g. causal dependancies, Control Loops of Process) Information Relay to
other Processes Sensory Transduction
Input Synapse
Output Synapse
Motor Transduction Continuous Planning
and Programming Generator
Measures (e.g.
adjustment of process internal service level, definition minimum level
of stockl) Changes and Measures relating to Plans and Programms Information Relay to
Corporate Regulatory Centre Achievement Monitor
Directoral Function to Receive over-riding Corporate Instructions
Directoral Function to Respond
Directoral Function to Report Normative Planning Function 1
2
6
7 A
B C 3A
5
5A 3
4
Process Performance Indicators, Malfunction Warnings,
Inventory Level Process Performance Indicators,
Notifiction of Malfunctions + Plans and Programms
of other Processes, Instructions of the process-related
Coordination Centre (e.g. changes of replenishment time)
Output within System One
Process- Related Directorate Process-Related Regulatory Centre
Input Spots External Output
Confirmation of Instructions, Information about Compliance of Planning Strategies and general Behavior of
Controlling Process Activities
Target System/ Strategies (e.g. Priorization: Service Level vs. Costs)
Boundaries of Autonomy (e.g. thresholds) Corrective Measures (e.g. Increase Inventory Level)
Ressource Allocation (e.g. Staff, Warehouse Capacity)
Technological Innovations, Service Provider, Cooperation Concepts,
ISO Standards
Interaction with the Environment Process Performance Indicators,
Notifiction of Malfunctions + Plans and Programms
of other Processes Raw Data, Malfunction Descriptions
Synchronized Transmission Of Raw Data and Malfunctions
Synchronized released Operations Analysed and Processed
Information (e.g. Transformation to concrete Instructions)
Programms/ Plans Information concerning Optimization (e.g. continuous improvement)) Process Performance Indicators
ÆInformation about Deviations (e.g. Costs of Inventory, Service Level)
Process Performance Indicators, Fault Reports, Plans and Programs of other Processes (e.g. Marketing Activities, Production downtimes)
Information about Changes of Plans and Diviations other Measures/
Instructions (e.g. Adjustment of Inventory level)
Adjustment of general Principles (e.g. Consumption Driven vs.
Deterministic)
Standards of Behavior, Model of Process (e.g. causal dependancies, Control Loops of Process) Information Relay to
other Processes Sensory Transduction
Input Synapse
Output Synapse
Motor Transduction Continuous Planning
and Programming Generator
Measures (e.g.
adjustment of process internal service level, definition minimum level
of stockl) Changes and Measures relating to Plans and Programms Information Relay to
Corporate Regulatory Centre Achievement Monitor
Directoral Function to Receive over-riding Corporate Instructions
Directoral Function to Respond
Directoral Function to Report Normative Planning Function 1
2
6
7 A
B C 3A
5
5A 3
4
Process Performance Indicators, Malfunction Warnings,
Inventory Level Process Performance Indicators,
Notifiction of Malfunctions + Plans and Programms
of other Processes, Instructions of the process-related
Coordination Centre (e.g. changes of replenishment time)
Output within System One
Fig. 5. Information flow within the organization of process control
4 Findings and Practical Implications
In order to assure the practical relevance of HRSCM several industry workshops have been accomplished. Within these workshops branch-specific problems have been de- rived and are further analyzed within use cases. These use cases as well as best prac- tices of the participating companies are incorporated in the HRSCM approach [8]. As one example implications for the process and process control of inventory manage-
ment have been derived by applying the reference model for a Viable Production Sys- tem. Configuring the process and its control according to the principles of the refer- ence model leads to a better handling of dynamics and thereby higher process stability and efficiency. Furthermore the definition of escalation levels stops the continuous firefighting of the organization of process control. In practice the process owner e.g.
material planner is enabled to use the saved time to deal with critical issues and the continuous improvement of the operative unit. The establishment of the flow of rele- vant information between the processes improves the planning quality and enables process control to take anticipatory measures.
Insufficient structural process design
High waste
High internal dynamics within the order processing
Information gaps between process steps
Fault liability of the order processing
High grade of waste within the value-adding processes
Information gaps between the system levels
Insufficient exchange of information between the levels of management
Incorrect decisions Insufficient system integration,
Responsibility assignment
frequent „firefighting“ because of a missing failure management and escalation plans
Insufficient creation of target and controlling values
Asynchronous target systems on the different system levels of the order processing
Local optimization and system oscillations 1
2
3
4
Order recording Offer
creation
Offer Processing
Final Inspection
After Sales
Planning of Commissioning
Horizontal ProcessHarmonization
System Architecture
Information Barriers Vertical Synchronisation
3
4 2
Process
Coordination Internal stability and synergy Adjustment to external dynamics Normative managment
Target System Inheritance 5
1
5
Insufficient structural process design
High waste
High internal dynamics within the order processing
Information gaps between process steps
Fault liability of the order processing
High grade of waste within the value-adding processes
Information gaps between the system levels
Insufficient exchange of information between the levels of management
Incorrect decisions Insufficient system integration,
Responsibility assignment
frequent „firefighting“ because of a missing failure management and escalation plans
Insufficient creation of target and controlling values
Asynchronous target systems on the different system levels of the order processing
Local optimization and system oscillations 1
2
3
4
Order recording Offer
creation
Offer Processing
Final Inspection
After Sales
Planning of Commissioning
Horizontal ProcessHarmonization
System Architecture
Information Barriers Vertical Synchronisation
3
4 2
Process
Coordination Internal stability and synergy Adjustment to external dynamics Normative managment
Target System Inheritance 5
1
5
Fig. 6. Solution competences of the reference model for a Viable Production System
Figure 6 systematizes the solution competences of the reference model for a Viable Production System to horizontal process harmonization and vertical synchronization.
Widely spread practical problems are related to these two dimensions and thus can be solved by benchmarking with the proposed reference model. While the horizontal process harmonization is mainly enabled by adaptive processes and cross-process in- formation transparency, the key factors to improve the vertical synchronization are synchronized target systems. A methodology to synchronise target systems in decen- tralised organizations is currently being developed as the next steps towards the viable production system.
5 Conclusion
In this paper the application of Stafford Beer’s Viable System Model (VSM) on the order process has been discussed as a holistic regulation framework for production systems. The technological and organizational preconditions as well as the general structure of such a cybernetic based production management model have been de-
scribed. Within a practical use case a self-optimizing control unit based on informa- tion transparency, escalation levels and adaptive processes has been implemented.
The resulting benefits are an increased level of adaptability and stability leading to a higher efficiency of the process. The establishment of a synchronized target system over the whole order processing avoids the nullification of these effects on both hori- zontal and vertical level. Thus it can be stated that the application of HRSCM will contribute to the resolution of the polylemma of production by reducing the dilemma between planning and value orientation. Thereby high-wage countries will be sup- ported in keeping a competitive edge.
References
1. Fleisch, E. et. al.: High Resolution Production Management – Auftragsplanung und Steuerung in der individualisierten Produktion. In: Wettbewerbsfaktor Pro- duktionstechnik: Aachener Perspektiven, pp. 451—467. Apprimus Verlag, Aachen (2008)
2. Beer, S.: Brain of the Firm. A Development in Management Cybernetics. Herder and Herder, New York (1972)
3. Meyer, J., Wienholdt, H: Wirtschaftliche Produktion in Hochlohnländern durch High Resolution Supply Chain Management. In: Supply Chain Management, 7 (2007) III, pp. 23--27.
4. Scholz-Reiter, B.; Höhns, H.: Selbststeuerung logistischer Prozesse mit Agenten- systemen. In: Schuh, G. (eds.), Produktionsplanung und -steuerung – Grundlagen, Gestaltung und Konzepte. 3. edition, pp. 745—780. Springer Verlag, Berlin (2006)
5. Fleisch, E.: High Resolution Management, Konsequenz der 3. IT-Revolution auf die Unternehmensführung. Schäffer-Poeschel Verlag (2008)
6. Espejo, R., et al.: Organizational Transforming and Learning. A Cybernetic Ap- proach to Management. John Wiley & Sons, Chichester (1996)
7. Malik, F.: Strategie des Managements komplexer Systeme. Haupt Verlag, Bern (2002)
8. Meyer, J., Wienholdt, H: High Resolution Supply Chain Management, Ergebnisse aus der Zusammenarbeit mit Industrieunternehmen. In: Unternehmen der Zukunft, 1/2008, pp. 11--13. Aachen (2008)
9. Balve, P., Wiendahl, H.-H., Westkämper, E.: Order management in transformable business structures – basics and concepts. In: Robotics and Computer Integrated Manufacturing 17 (2001), pp. 461--468
10. Thiem, I.: Ein Strukturmodell des Fertigungsmanagements: Soziotechnische Strukturierung von Fertigungssystemen mit dem “Modell lebensfähiger Systeme”.
Shaker Verlag, Aachen (1998)
