THÈSE
Pour obtenir le grade de
DOCTEUR DE L’UNIVERSITÉ DE GRENOBLE ALPES
Spécialité :Sciences de la Terre et Univers, EnvironnementArrêté ministériel : 7 aout 2006
Présentée par
Raphaël MAURIN
Thèse dirigée parPhilippe FREY
et co-encadrée parJulien CHAUCHAT et Bruno CHAREYRE préparée àIrstea Grenoble
dans l’Ecole DoctoraleTerre, Univers, Environnement
Étude du comportement
granu-laire en transport par charriage
basée sur un modèle
Eulérien-Lagrangien
Thèse soutenue publiquement le11/12/2015, devant le jury composé de :
M. Alexandre VALANCE
Directeur de recherche, CNRS, Institut de Physique de Rennes, Président Mme. Kimberly HILL
Associate Professor, University of Minnesota, Rapporteur M. Hervé CAPART
Professor, National Taiwan University, Rapporteur M. Philippe CLAUDIN
Directeur de recherche, CNRS, ESPCI, Examinateur M. Éric BARTHÉLÉMY
Professeur des Universités, LEGI, Grenoble INP, Examinateur M. Philippe FREY
Chercheur HDR, IRSTEA Grenoble, Directeur de thèse M. Julien CHAUCHAT
Maître de Conférence, LEGI, Grenoble INP, Co-encadrant de thèse M. Bruno CHAREYRE
VERI TAS LIBE RABIT
SI
G
IL
L
U
M
U
N
IV
E
R
SI
TATIS GR
A
T
IA
N
O
P
O
L
IT
A
N
Æ
1339
Pour obtenir le grade de
DOCTEUR DE L’UNIVERSITÉ DE GRENOBLE ALPES
Spécialité :Sciences de la Terre et Univers, EnvironnementArrêté ministériel : 7 aout 2006
Présentée par
Raphaël MAURIN
Thèse dirigée parPhilippe FREY
et co-encadrée parJulien CHAUCHAT et Bruno CHAREYRE préparée àIrstea Grenoble
dans l’Ecole DoctoraleTerre, Univers, Environnement
Investigation of granular
behav-ior in bedload transport using an
Eulerian-Lagrangian model
Thèse soutenue publiquement le11/12/2015, devant le jury composé de :
M. Alexandre VALANCE
Directeur de recherche, CNRS, Institut de Physique de Rennes, Président Mme. Kimberly HILL
Associate Professor, University of Minnesota, Rapporteur M. Hervé CAPART
Professor, National Taiwan University, Rapporteur M. Philippe CLAUDIN
Directeur de recherche, CNRS, ESPCI, Examinateur M. Éric BARTHÉLÉMY
Professeur des Universités, LEGI, Grenoble INP, Examinateur M. Philippe FREY
Chercheur HDR, IRSTEA Grenoble, Directeur de thèse M. Julien CHAUCHAT
Maître de Conférence, LEGI, Grenoble INP, Co-encadrant de thèse M. Bruno CHAREYRE
Résumé : Le transport solide par charriage représente la contribution principale dans l’évolution morphologique du lit des cours d’eau, et se situe donc au coeur d’enjeux majeurs liés aux risques d’inondations. Il est caractérisé par l’interaction entre des comportements collectifs granulaires non-triviaux et un écoulement fluide turbulent. À ce titre, sa compréhension représente à la fois un défi scientifique et une problématique sociétale. L’approche numérique présentée met l’accent sur la description de la phase granulaire et se concentre sur des configurations idéalisées de trans-port solide par charriage en conditions stationnaires et uniformes, considérant des échantillons de particules sphériques monodisperses dans un écoulement fluide unidirectionnel. Cette configura-tion simplifiée permet d’étudier en détail les mécanismes granulaires sous-jacents au phénomène. Un modèle numérique couplé minimal pour la description du transport par charriage est présenté, associant une modélisation par éléments discrets tri-dimensionnelle à une résolution fluide unidi-rectionnelle moyennée en volume. Le modèle est comparé à l’expérience en considérant à la fois la courbe du débit solide adimensionné en fonction du nombre de Shields en trois dimensions, et des profils moyens verticaux de vitesse particulaire, fraction volumique et densité de débit solide dans une configuration quasi-bidimensionnelle. L’étude de la sensibilité aux paramètres a mis en évidence l’importance du couplage entre phases granulaire et fluide, et la robustesse de l’accord entre simulations et expériences. Fort de cette validation expérimentale, le modèle est utilisé pour analyser la structure verticale granulaire en transport par charriage. En étudiant l’effet de la pente et de la densité spécifique, il est montré que les formulations classiques du nombre de Shields et du débit solide adimensionné ne prennent pas en compte de manière appropriée les effets de ces deux paramètres. À partir d’une analyse des équations continues moyennées diphasiques, la contribu-tion manquante est identifiée comme résidant dans l’effet de l’écoulement fluide à l’interieur du lit granulaire. Cette contribution prend une importance fondamentale proche de la transition vers un régime de type lave torrentielle granulaire. Une modification du nombre de Shields est proposée et apparaît réunir les données sur une courbe maîtresse en considérant le débit solide adimensionné en fonction du nombre de Shields modifié. Dans un deuxième temps, la rhéologie de la phase granulaire en transport par charriage est caractérisée en évaluant localement le tenseur des con-traintes particulaires en fonction de la profondeur. Ceci est réalisé pour une série de simulations en faisant varier le nombre de Shields, le diamètre des grains et la densité spécifique. Sur l’ensemble des résultats, la partie quasi-statique de l’écoulement met en évidence un régime de creeping avec la présence de signatures caractéristiques d’effets non-locaux. Au-dessus de cette zone, la partie d’écoulement granulaire dense est bien décrite par la rhéologie µ(I) et persiste jusqu’à des nombres inertiels inhabituellement élevés. Ce régime est caractérisé par la co-existence des contributions collisionelle et frictionelle. La transition entre le régime granulaire dense et gazeux dépend du nombre de Shields, de la pente et de la densité spécifique. La partie granulaire supérieure suit un comportement de type balistique. Ces résultats améliorent la compréhension des mécanismes granulaires en transport solide par charriage et représentent également un défi pour les théories granulaires existantes.
Mots clés :Transport de sédiments, charriage, milieux granulaires, méthode par éléments discrets,
fluid flow. Therefore, its description is both a scientific challenge and a societal issue. The present numerical approach focuses on the granular phase characterization, and considers idealized steady uniform bedload transport, with monodisperse spherical beads and a unidirectional fluid flow. This simplified configuration allows to study the underlying physical mechanisms.
A minimal coupled numerical model is proposed, associating a three dimensional discrete element method with a one-dimensional volume-averaged fluid momentum balance. The model is compared with classical experimental results of dimensionless sediment transport rate as a function of the Shields number. The comparison is extended to granular depth profiles of solid volume fraction, solid velocity and sediment transport rate density in quasi-2D bedload transport configurations. Parameter sensitivity analysis evidenced the importance of the fluid-particle phase coupling, and showed a robust agreement of the model with the experiments. The validated model is further used to analyze the granular depth structure in bedload transport. Varying the channel inclination angle and the specific density, it is shown that the classical Shields number and dimensionless sed-iment transport rate formulations do not take appropriately into account the effects of these two parameters. Analyzing the solid depth profiles and the continuous two-phase flow equations, the neglected fluid flow inside the granular bed is identified as the missing contribution. Its importance is enhanced near the transition to debris flow. A rescaling of the Shields number is proposed and is shown to make all the data collapse onto a master curve when considering the dimensionless sediment transport rate as a function of the modified Shields number. In addition, the bedload transport granular rheology is characterized by computing locally the stress tensor as a function of the depth, for a serie of simulation varying the Shields number, particle diameter and specific density. Overall, the lowermost part is shown to follow a creeping regime and exhibits signature of non-local effects. The dense granular flow on the top of it, is well described by the µ(I) rheology and is observed to persist up to unexpectedly high inertial numbers. It is characterized by the co-existence of frictional and collisional contributions. The transition from dense to dilute granular flow is controlled by the Shields number, the slope and the specific density. Saltation is observed in the uppermost granular layer. These findings improve the understanding of bedload transport granular mechanisms and challenge the existing granular rheologies.
Keywords: Sediment transport, bedload, granular media, Discrete Element Method, two-phase
