Piperidinol-Containing Molecules as New Mycobacterium abscessus Inhibitors
Jérôme Ruyck, Christian Dupont, Elodie Lamy, Vincent Le Moigne, Christophe Biot, Yann Guerardel, Jean-louis Herrmann, Mickael Blaise,
Stanislas Grassin-delyle, Laurent Kremer, et al.
To cite this version:
Jérôme Ruyck, Christian Dupont, Elodie Lamy, Vincent Le Moigne, Christophe Biot, et al.. Structure-
Based Design and Synthesis of Piperidinol-Containing Molecules as New Mycobacterium abscessus
Inhibitors. ChemistryOpen, Wiley, 2020, 9 (3), pp.351-365. �10.1002/open.202000042�. �hal-02988322�
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57
Structure-Based Design and Synthesis of Piperidinol- Containing Molecules as New Mycobacterium abscessus Inhibitors
Jérôme de Ruyck,
[a]Christian Dupont,
[b]Elodie Lamy,
[c]Vincent Le Moigne,
[c]Christophe Biot,
[a]Yann Guérardel,
[a]Jean-Louis Herrmann,
[c, d]Mickaël Blaise,
[b]Stanislas Grassin-Delyle,
[c, e]Laurent Kremer,
[b, f]and Faustine Dubar*
[a]Non-tuberculous mycobacterium (NTM) infections, such as those caused by Mycobacterium abscessus, are increasing globally. Due to their intrinsic drug resistance, M. abscessus pulmonary infections are often difficult to cure using standard chemotherapy. We previously demonstrated that a piperidinol derivative, named PIPD1, is an efficient molecule both against M. abscessus and Mycobacterium tuberculosis, the agent of tuberculosis, by targeting the mycolic acid transporter MmpL3.
These results prompted us to design and synthesize a series of
piperidinol derivatives and to determine the biological activity againstM. abscessus.Structure-activity relationship (SAR) studies pointed toward specific sites on the scaffold that can tolerate slight modifications. Overall, these results identified FMD-88 as a new promising active analogue againstM. abscessus.Also, we determined the pharmacokinetics properties of PIPD1 and showed that intraperitoneal administration of this compound resulted in promising serum concentration and an elimination half-life of 3.2 hours.
1. Introduction
Nontuberculous mycobacteria (NTM) are environmental bac- teral isolated from surface and tap water, soil, animals, milk and food products.[1,2] They are responsible for opportunistic infections in humans and are recognized as an increasing public health concern. NTM have been reported as a cause of diverse
infectious diseases in humans, livestock, and wildlife, such as pulmonary, extra-pulmonary, skin and soft tissue infections.[3]
The diseases caused by NTM are increasing on a worldwide scale.[4]In developed countries, NTM lung infections are more prevalent than TB.[5–7] Nearly 200 distinct NTM species have been reported so far, with the Mycobacterium avium-intra- cellulare complex (MAC) and the Mycobacterium abscessus as the major causative agents in Europe as well as in the United States.[8,9] Of particular concern, M. abscessus infects both immunocompromised or immunocompetent individuals and is often associated with cystic fibrosis (CF).[10–12] In CF patients, presence ofM. abscessus in the lungs correlates with a decline in the lung function and can be fatal.[13–15] In addition, recent studies suggested a transmission of M. abscessus complex between CF patients[10,16,17], although this transmission might be indirect, through fomites and dust.[18]
The current standardized antimicrobial treatment for M.
abscessus infections[10] combines three drugs, or more, for at least 12 months. Moreover it is aggressive and burdensome.[12]
The outcome of the treatment is also highly dependent on the inducible resistance to macrolides[19,20] (clarithromycin or azi- thromycin), leading to a treatment success rate below 40 %.[21]
Lung transplantation in CF patients, often representing the last therapeutic option, is currently being debated amongst clinicians in the case of pre-existing infection withM. abscessus.
However, most centers do not consider the presence of M.
abscessusas an absolute contra-indication since recent studies support the possibility of lung transplantation with favorable outcome in CF patients.[12,14,20,22–24]In light of the limited panel of available drugs active againstM. abscessus,treatments are often complex and challenging. In this context, it appears necessary to identify efficient, specific and less toxic compounds.
[a] Dr. J. de Ruyck, Prof. C. Biot, Dr. Y. Guérardel, Dr. F. Dubar Univ. Lille, CNRS
UMR 8576 – UGSF – Unité de Glycobiologie Structurale et Fonctionnelle 59000 Lille (France)
E-mail: faustine.dubar@univ-lille.fr [b] Dr. C. Dupont, Dr. M. Blaise, Dr. L. Kremer
IRIM Institut de Recherche en Infectiologie de Montpellier – UMR9004-CNRS/
UM
1919 route de Mende 34293 Montpellier (France)
[c] E. Lamy, Dr. V. Le Moigne, Prof. J.-L. Herrmann, Dr. S. Grassin-Delyle Infection et inflammation – Laboratoire 2I
UMD1173-INSERM/UVSQ
Versailles, 2 Avenue de la source de la Bièvres 78180 Montigny le Bretonneux (France) [d] Prof. J.-L. Herrmann
Université Paris-Saclay, UVSQ, INSERM, Infection et Inflammation (U1173), Montigny le Bretonneux, France
[e] Dr. S. Grassin-Delyle Hôpital Foch
Département des maladies des voies respiratoires 92150 Suresnes (France)
[f] Dr. L. Kremer
INSERM, Institut de Recherche en Infectiologie de Montpellier, Montpellier, France
Supporting information for this article is available on the WWW under https://doi.org/10.1002/open.202000042
© 2020 The Authors. Published by Wiley-VCH Verlag GmbH & Co. KGaA. This is an open access article under the terms of the Creative Commons Attri- bution Non-Commercial NoDerivs License, which permits use and distribu- tion in any medium, provided the original work is properly cited, the use is non-commercial and no modifications or adaptations are made.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57
The lack of therapeutic solutions prompted us to perform a phenotypic screen for bactericidal compounds against M.
abscessususing a library[25]of compounds formerly validated for their activity against M. tuberculosis.[26] Our study allowed identifying a new piperidinol-based compound, which we named PIPD1 (Figure 1) and which exhibits potent activity against clinical isolates ofM. abscessus in vitroand in infected human macrophages and zebrafish embryos.[26]
Importantly, M. abscessus-infected zebrafish embryos treated with PIPD1 showed an increased survival rate and a decreases bacterial burden, as compared to the infected but non-treated animals. Thanks to the selection of spontaneous resistant mutants and following whole-genome sequencing, single nucleotide polymorphisms (SNP) were identified inMAB_
4508. This gene encodes the mycolic acid transporter MmpL3 that was shown to be essential for Mycobacterium smegmatis andM. tuberculosissurvival.[27–29]Like other MmpL, MmpL3 is a transmembrane protein belonging to the Resistance-Nodula- tion-Cell division (RND) permeases.[30]MmpL proteins are known to participate in the export of lipid components across the cell envelope in mycobacteria. We demonstrated that PIPD1 does not affect de novo biosynthesis of mycolic acid but rather inhibits the transport of trehalose monomycolate (TMM) by blocking the flippase activity of MmpL3.[26,31]This results in the loss of trehalose dimycolate synthesis, the decrease of arabino- galactan mycolylation and bacterial death. Herein, with the aim to improve the activity of this new family of MmpL3 inhibitors against M. abscessus, we present the rational design and the structure-activity relationships of piperidinol derivatives.
2. Results and Discussion
2.1. Chemistry
In the present study, a first series of piperidinol-based compounds with potent antibacterial activity against M.
abscessuswas synthesized. The initial hit compound, PIPD1, was derived in order to identify the pharmacophores and to explore a preliminary structure-activity relationship (SAR). The new derivatives were evaluated against theM. abscessusCIP104536T reference strain. In addition, toxicity of the most potent compounds was evaluated in order to determine the selectivity
index. Moreover, all analogues were subjected to molecular modeling studies using MmpL3 in order to rationalize, at a molecular level, the in vitro results. Previously, PIPD1 was synthesized according to a reported method.[26]
However, the synthetic method used (Figure 2) includes a deprotection step (Figure 2, step b), which is not complete and causes a degradation of the product of interest. Another deprotection condition using trifluoroacetic acid (TFA) was therefore evaluated, but degradation of the final product was still observed and the yield obtained forstep bwas insufficient to pursue the complete synthesis. In order to circumvent these limitations, another synthetic pathway was developed, as out- lined in Figure 3.
First, N-benzylation was achieved by means of benzyl bromide in DCM in the presence of an excess of potassium carbonate, resulting in high yields of the piperidone product.
Total consumption of the starting aldehyde was monitored by thin layer chromatography (TLC) using dichloromethane as eluent. Second, bromine lithium exchange reaction was fol- lowed by a nucleophilic substitution reaction on the carbonyl of piperidinone to form the final compound. The final products were purified on silica gel chromatography. 1H-NMR,13C-NMR and mass spectrometry were performed to confirm the synthesized compound structures. Synthesis of all presented analogues was between 30–60 % yield. Thus, this new synthetic route with limited reaction steps is associated to a significant improvement in the total yields of the analogues.
2.2. Biology and Structure Activity Relationship Study (SAR)
We first aimed at designing PIPD1 analogues to identify common pharmacophores in the first series of compounds
Figure 1.Chemical structure of PIPD1.
Figure 2.Three-step chemical synthesis of PIPD1 and related analogues.
Figure 3.Two-step chemical synthesis of PIPD1 analogues.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57
(Series I). Among these compounds, each organic function, (designated A and B, see Figure 1) of PIPD1 were removed or modulated and the in vitro antimycobacterial activity of prod- ucts against the M. abscessus smooth (S) reference strain CIP104536Twas assayed to attest for their contribution to the activity. The minimal inhibitory concentration (MIC) expressed in μg/ml (and μmol/L) was determined using Cation-adjusted Mueller-Hinton (CaMHB; Sigma-Aldrich), according to CLSI guidelines.[32] The evaluation of the toxicity of the newly synthesized compounds was evaluated on mammalian cells in order to establish a selectivity index. Toxicity assays on Vero cells were performed in RPMI supplemented with 10 % FBS based on cell viability using resazurin as a cell survival indicator.
The half maximal inhibitory concentration (IC50) corresponds to the drug concentration that reduces cell viability by 50 % and is expressed in percentage of cell survival.
The selectivity index (SIMabs), corresponding to the IC50/MIC ratio was determined for the 12 most active compounds against M. abscessus.IC50and SI were not determined for compounds with unsatisfactory biological activity (MIC99>0.5μg/ml). Ta- ble 1 summarizes the structures and inhibition activities of the designed PIPD1-analogues of the series I.
Results in Table 1 indicate that the aromatic parts A and B and the tertiary alcohol function of the piperidinol moiety are essential for the inhibitory activity againstM. abscessus.More- over, the methyl group of the ring B participates to the antimycobacterial effect since the activity of FMD-15 was lower than the one of PIPD1. The donor inductive effect of methyl group may impact the inhibitory effect. With respect to ring A, the removal of the trifluoromethyl group (FMD-32) clearly impacted on the biological activity as compared to the removal of the chlorine atom (FMD-33).
Although the dataset of compounds tested is limited, important SAR elements have been unravelled and subse- quently utilized for guiding the design of the series II compounds (Table 2).
From these data, one can deduce that the aromatic moieties are key to the biological activity. The nature of the aromatic substituent was modulated to determine if steric effect influences the activity. The steric occupancy of the aromatic ring A appeared significant, nevertheless the lack of the trifluoromethyl and methyl groups on naphthalene could explain the decrease of activity for naphthalene (FMD-102). The steric hindrance was also an important feature in ring B since the introduction of a bulky substituent (such as ferrocene in FMD-6 or an aromatic-substituted piperidine in FMD-62) caused a decrease in bactericidal activity against M. abscessus. Addi- tionally, the modification of the methyl group of ring B was investigated in relation to their position and electronic proper- ties. The presence of a substituent in ring B with a consistent steric hindrance appears essential to biological activity. Indeed, PIPD1 with a methyl substituent and FMD-88 with an iodo substituent were more active than FMD-3 that carries a fluorine atom. Additionally, the position of the substituents on ring B also appears important since the presence of group in theortho position (PIPD1, FMD-88 or FMD-93) initiates a potent anti- mycobacterial activity, whilst the presence of methyl group at
meta (FMD-63) or para (FMD-66) positions decreases the activity. Noteworthingly, these results are similar to those reported againstM. tuberculosis,[31]which strongly suggests that the mechanism of inhibition and/or binding site of these compounds in MmpL3 are conserved inM. tuberculosisandM.
abscessus. To further rationalize these experimental data, the synthesized derivatives were subjected to in silico docking analyses using a 3D homology model of MmpL3 from M.
abscessus to address how the different SAR elements interact with MmpL3 at a molecular level.
Table 1. Structures and biological evaluation (MIC99, CC50and SI; N.D., not determined) of the PIPD1-derivatives of the series I. MIC99(M. abscessus) data result from three independent experiments and CC50(Vero cells) from two independent experiments.
Analogues Formula MIC99
M.abs [μg/
ml]
MIC99
M.abs [μmol/
L]
CC50
[μg/
ml]
SIMabs
PIPD1 0.125 0.3 25 200
FMD-37 128 350.6 N.D. N.D.
FMD-16 128 623.9 N.D. N.D.
FMD-32 2 6.3 N.D. N.D.
FMD-33 1 2.9 N.D. N.D.
FMD-15 1 2.7 N.D. N.D.
FMD-99 4 14.2 N.D. N.D.
FMD-0 128 458.7 N.D. N.D.
FMD-46 64 261.1 N.D. N.D.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57
2.3. Molecular Modelling
Previously, several mutations inM. abscessusstrains resistant to PIPD1 were identified in MAB_4508, that encodes the TMM transporter MmpL3.[26,31] Moreover, we recently demonstrated that PIPD1 alters the mycolic acid transport inM. abscessus[26]by directly inhibiting the TMM flippase activity of MmpL3 in M.
tuberculosis.[31]Finally, Zhang et al. solved the crystal structure ofMycobacterium smegmatisMmpL3 by X-ray crystallography at a resolution of 2.8 Å (PDB : 6AJJ) which unravelled a cavity in the transmembrane region of MmpL3 accommodating several MmpL3 inhibitors.[33]Since MmpL3 and its orthologues are well conserved across mycobacteria, comparative modelling of M.
abscessus MmpL3 using the crystal structure of M. smegmatis MmpL3 as a template (sharing 65 % identity with its M.
abscessus orthologue) was performed (Figure 4a and 4b).
Quality of theM. abscessusMmpL3 model was then evaluated according to classical geometric parameters (See SI for full report). The RMSD calculated on the Cα of the template is around 0.4 Å and 96 % of the residues are within the Ramachandran criteria. The superimposition of theM. abscessus MmpL3 model onto theM. smegmatisMmpL3 structure showed that the drug binding site formerly described[33]was conserved in the transmembrane domain of theM. abscessusMmpL3 (gold sphere in Figure 4). Interestingly, this cavity is in the vicinity of residues previously reported to participate to the proton relay.[26,31,33] This binding pocket is composed of two hydro- phobic cavities, designated Up- and Bottom-pockets (U and B in Figure 4c) and comprises also a more polar cavity, designated Middle-pocket (M in Figure 4c). Of note, the residues contouring the M- and B-pockets are well conserved amongst all mycobac- teria (see sequence alignment Figure S1).
Docking simulations and energy minimization were next conducted using the M. abscessus MmpL3 predictive model with different analogues: the reference compound PIPD1, one analogue with a higher inhibitory effect (FMD-89), one with a lower inhibitory effect (FMD-61), one truncated ligand (FMD-0).
Table 2. Structures and biological evaluations (MIC99, CC50and SI; N.D., not determined) of the series II PIPD1-analogues. MIC99(M. abscessus) data are from three independent experiments and CC50(Vero cells) are from two independent experiments.
Analogues Formula MIC99
M.abs [μg/ml]
MIC99
M.abs [μmol/
L]
CC50
[μg/
ml]
SIMabs
FMD-88 0.125 0.25 25 200
FMD-93 0.125 0.3 50 400
FMD-96 0.125 0.3 25 200
FMD-89 0.125 0.3 50 400
PIPD-1 0.125 0.3 25 200
FMD-91 0.25 0.6 25 100
FMD-10 0.25 0.7 50 200
FMD-94 0.5 1.1 50 100
FMD-3 1 2.6 N.D. N.D.
FMD-61 2 4.8 N.D. N.D.
FMD-63 2 5.2 N.D. N.D.
FMD-66 2 5.2 N.D. N.D.
FMD-6 4 8.4 N.D. N.D.
FMD-103 4 9.6 50 12.5
FMD-9 4 9.7 N.D. N.D.
Table 2. continued
Analogues Formula MIC99
M.abs [μg/ml]
MIC99 M.abs [μmol/
L]
CC50 [μg/
ml]
SIMabs
FMD-92 4 9.9 N.D. N.D.
FMD-102 4 12.1 N.D. N.D.
FMD-64 16 36.6 N.D. N.D.
FMD-62 32 70.8 N.D. N.D.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57
In order to consider protonated or unprotonated states of piperidinol tertiary amine at physiological pH, docking simu- lations were performed on both structures for each compound.
Results were similar after the two runs and, thus, only unprotonated ligands are presented in this article.
After minimization of the simulated PIPD1 complex, the best binding pose was retrieved and further analysed (Figure 5A and 5B). On one side, PIPD1 is hydrogen-bound to the carboxylic acid group of D618 through its amino moiety. On the other side, its hydroxyl group is H-bound to the hydroxyl of Y219. Additionally, a potent interaction with the carboxylic acid group of D258 can occur. Thanks to these two strong interactions, the ligand appears perfectly anchored into the proposed proton channel of the transporter. Additional stabili- zation occurred throughπ-πinteractions between the toluene moiety of PIPD1 and phenyl rings of F262 and F622 (B-pocket).
However, the U-pocket does not appear to be optimally filled.
Regarding FMD-89, due to the electron-releasing effect of the chloride moiety grafted on the phenyl ring, the π-π interactions with the phenyl rings of F262 and F622 are increased, which likely explains the change in antimicrobial properties (Figure 5C). Chlorobenzyl group perfectly fits the B- pocket while the central core of the compound is well stabilized by the hydrogen bonds. The presence of a second ortho chlorine substitution on ring B (FMD-94) causes a decrease in the biological activity, as compared to FMD-89 (Table 2). This could be explained by a reduction ofπ-πstacking interactions with the phenyl rings of F262 and F622 (Figure 5D) since the aromatic ring B is no longer in a favourable position, due to the presence of the chlorine atom in the twoorthopositions of ring B. These results demonstrate that the additional chloride group alters the binding in the B-pocket inducing a change in conformation of the central core.
We next simulated a lower affinity complex by studying the replacement of the chlorobenzene ring of FMD-89 with a naphthalene group in FMD-61 (Figure 5E and 5F), which was designed to keep the aromatic property of the substitution as compared to PIPD1. In Figure 5E, the nitrogen atom is located towards the U-pocket and the hydroxyl located towards the B- pocket. In addition, no more residues are involved in hydrogen bonds. As expected, the ligand is now located upside-down (Figure 5F) in the binding pocket, as compared to PIPD1. This drastic change in conformation could explain the loose of antimicrobial activity due to absence of the two key interactions (H-bonds) between the PIPD1 hydroxyl group and Y219 and between the PIPD1 ammonium group and D258, as illustrated in Figure 5B. Indeed, neither the hydrogen bonds nor theπ-π interactions are observed. Only small hydrophobic or van der Waals interactions can explain these binding modes. It can therefore be speculated that the B-pocket is too narrow, therefore only accommodating small aromatic moieties.
Finally, the truncated ligand FMD-0 is obviously not well adapted to the binding site. Nevertheless, this last binding pose (Figure 5G) clearly explains why the hydroxyl group of the central ring of any inhibitors is required. Here, only the important hydrogen bond between D258 and the hydroxyl moiety is conserved. Moreover, the lack of interaction in the B- pocket seems to induce large changes in the conformation of the putative inhibitors. These poor interactions may contribute to the low antimicrobial properties of the inhibitor.
Furthermore, the nature of the ortho group in ring B appears important too. Even though the electronic effects do not have a significant influence to the binding capacity of the PIPD1 analogues, the size of the substituents, however, seems to have a great impact to their biological activity. Indeed, the methyl group (2.00 Å) in PIPD1 or the iodine atom (1.98 Å) in FMD-89 are associated with a more pronounced activity than the fluorine atom (1.47 Å) in FMD-3. To get insights into these differences, the steric hindrance of the ortho substituent for FMD-89 and FMD-3 within the binding site of MmpL3 were modelled (Figure 6).
As shown in Figure 6A the iodine atom of FMD-89 is blocked in the binding cavity of the active site and allows to increase the capability of the aromatic group to be stabilized by π-πinteractions (Figure 6B).In contrast, the ring B ring of FMD- 3 adopts a slightly different orientation than the B ring of FMD- 89 due to smaller size of the fluorine atom. These observations confirm that FMD-3 displays a weaker interaction than FMD-89, particularly for theπ-πstacking of ring B.
2.4. Toxicology and Pharmacokinetics Studies
To evaluate the preclinical pharmacokinetic profiles of PIPD1, survival curves were assessed for 96 h in BALB/c mice, following intraperitoneal (IP) injection with increasing concentrations of PIPD1, ranging from 10 mg/kg to 250 mg/kg. Whereas IP administration of the higher dose led to rapid death after 48 h, injection of 100 mg/kg was associated with a 67 % survival rate and administration of 50 mg/kg led to 100 % survival after 96 h Figure 4.A) Comparative model ofM. abscessusMmpL3 lacking its C-
terminal region. The binding pocket (Gold Sphere) is located inside the transmembrane channel. B) 90°rotation of Figure 5A clearly showing the channel. C) Focus on the putative binding site surrounded by three regions, two hydrophobic pockets (U and B) and a more polar pocket (M).
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57
post-injection. According to these results, a dose of 50 mg/kg was used as the working concentration for all subsequent pharmacokinetics studies after IP administration or oral gavage.
The concentrationvstime profiles in the serum and tissues are shown in Figure 7.
Following IP injection, the serum concentration was meas- ured at 600 ng/mL after 5 min and the drug distribution was found to be greater in the lungs, the kidney, the spleen and the heart, as compared to the brain and the liver. The concen- trations obtained after IP administration were 6.9 mL/min for clearance, 1.9 L for the central volume of distribution, 4.9 mL/
min for inter-compartmental clearance and 2.0 L for the peripheral volume of distribution. The elimination half-life was about 3.2 h. On the other hand, serum concentrations after oral administration remained below 100 ng/mL and the relative oral bioavailability of the compound was estimated to be lower than 10 % (when compared to the IP route). Since PIPD1 is a lipophilic compound (log P=4.9), the digestive absorption is expected to be important and the low oral bioavailability rather suggests a strong hepatic first-pass effect, although other mechanisms such as efflux by active transporters (P-glycopro- tein or multidrug resistance proteins) cannot be excluded at this stage. The hypothesis of hepatic first-pass effect is reinforced by the observation of a second peak in serum concentration occurring after 8 h, suggesting the existence of an entero-hepatic cycle. PIPD1 exhibited a good organ distribu- tion after IP administration and was rapidly eliminated with a half-life of about 3 h.
Figure 5.A) Interaction diagram of PIPD1 in the binding pocket of MmpL3. Residues contouring the active site are represented in green while H-bounded residues to ligands are highlighted in red. B) Molecular representation of the interaction of PIPD1 and MmpL3 pocket. C) Binding mode of the FMD-89 compound. D) Comparison of FMD-89 (purple sticks) and FMD-94 (turquoise sticks). E) Interaction diagram of FMD-61 in the binding pocket of MmpL3. F) Molecular representation of FMD-61 and MmpL3 pocket. G) Binding mode of the truncated derivative (FMD-0).
Figure 6.Steric hindrance oforthosubstituent in ring B for FMD-89 (A) and FMD-3 (B). Spheresradiiare directly proportional to the Van der Waalsradii of each atoms.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57
3. Conclusions
In the present report, SAR studies emphasize the contribution of the two aromatic moieties (ring A and ring B) as well as the importance of the steric hindrance of the substituent on ring B.
Based on molecular modeling studies, we propose that the size of ring B in the binding cavity is limited and could explain poor biological activity of the PIPD1-analogues comprising a large group. Nevertheless, the stability of the analogues/MmpL3 complexes is enhanced when the ring B is totally blocked in the active site. Moreover, we demonstrated that PIPD1 exhibits a good organ distribution after IP administration in mice and was rapidly eliminated with a half-life of about 3 h. Drugs with short half-live that are totally cleared within a few hours only are usually easier to manipulate, especially if they present toxicity issues. With respect to oral administration, the low relative bioavailability could be explained either by a poor intestinal absorption or a strong metabolic clearance. Thus, investigation of these processes for the newly synthesized analogues is warranted by the advantages and ease of oral administration in patients. In a forthcoming work PIPD1 will be modified in order to increase polarity and to minimize phase I metabolism, based on the PK study. Altogether, these results pave the way for the development of a new generation of anti-MmpL3 inhibitors with improved activity againstM. abscessus.
Experimental Section
Chemistry
Nuclear magnetic resonance (1H, 13C, and 19F NMR) spectra were recorded at room temperature on a Brüker AC 300 spectrometer.
TMS was used as an internal standard and CDCl3as the solvent.1H NMR analyses were obtained at 300 MHz (s: singlet, br s: broad singlet, d: doublet, t: triplet, dd: double doublet, td: double triplet);
13C NMR analyses were obtained at 75.4 MHz; and19F NMR analyses were obtained at 282 MHz. The chemical shifts (δ) are given in parts
per million relative to TMS (δ=0.00). Mass spectra were recorded by means of a Waters Micromass Quattro II triple quadrupole LC mass spectrometer equipped with electrospray ionization (ESI) and atmospheric pressure chemical ionization (APCI) sources. Column chromatography, carried out on silica gel (Merck Kieselgel 60) was used for the purification of compound. Reactions were monitored by thin-layer chromatography (TLC) coated silica gel plates and detection by UV lamp. The purity degree of compound was checked by NMR and MS analysis and proved to be higher than 95 %.
All chemicals reagents were purchased at Sigma-Aldrich. Dry THF was obtained from a solvent purification system (Innovative Technology Inc. MA, USA, Pure-Solv)
General Procedure for the Synthesis of PIPD1-Derivatives First step: 4-Piperidinone monohydrate hydrochloride (1 g, 6.5 mmol) is suspended in dichloromethane (DCM, 120 ml, 1.9 mol) and methanol (4 ml, 0.09 mol). Then K2CO3(2 g, 0.01 mol) is added.
The mixture is stirred during 30 min then of α-Bromo-O-xylene (0.86 ml, 6.5 mmol) is added. The mixture is stirred during 12 h at room temperature. The mixture is quenched with distillated water (100 ml, 5.5 mol) then the aqueous layer is extracted by DCM (2 × 100 ml, 3.2 mol). The organic layer is dried on NaSO4 before filtration. Solvents are removed under reduce pressure. The residue is purified on flash chromatography (silica gel) with a gradient eluent (DCM: 100 to DCM/MeOH: 95/5)..
Second step: Under N2, bromine derivative (1 eq) is dissolved in anhydrous THF (5 ml, 0.06 mol for 1 eq of bromine derivative). The solution is cooled at 78°C before the slow addition of n-Butyl Lithium solution (2,5 M in hexane ; 1 eq). The mixture is stirred during 1 h at 78°C. Under N2, the compound obtained in the first step is dissolved in anhydrous THF (5 ml, 0.06 mol for 1 eq of bromine derivative), then the reaction is stirred during 2 h at 78°C. The reaction is quenched by saturated solution of NH4Cl (at 78°C) then the mixture is abandoned at room temperature before adding of of distillated water (50 ml, 2,8 mol). The mixture is extracted by ethyle acetate (3 × 50 ml, 1.5 mol). The organic layer is dried on Na2SO4 .before filtration. Solvants are removed under reduce pressure. The residue is purified on flash chromatography (silica gel) with a gradient eluent (DCM: 100 to DCM/MeOH: 95/5).
1-(2-methylbenzyl)piperidin-4-one
1H NMR (300 MHz, CDCl3)δ7.18 (dd, J=9.5, 7.8 Hz, 4H, H9, H10, H11 and H12), 3.68 (m, 2H, H7), 2.92 (m, 2H, H2 and H4), 2.68 (m, 4H, H1 and H5), 2.67 (m, 2H, H2 and H4, 2.37 (m, 3H, H14).13C NMR (75 MHz, CDCl3) δ205.7 (C6), 138.1 (C8), 136.5 (C13), 130.3 (C12), 128.1 (C9), 126.6 (C10), 125.3 (C11), 61.6 (C7), 51.0 (C2 and C4), 39.7 (C1 and C5), 19.4 (C14). M/Z=203.13 g/mol. Colorless oil. Yield= 95 %
Figure 7.Pharmacokinetic analysis of PIPD1 in female BALB/c mice after intraperitoneal injection (A, C) or oral gavage (B, D). (A) Concentration in sera and (C) concentration in organs following a single 50 mg/kg dose
administered using the IP route. (B) Concentration in sera and (D) concentration in organs following a single 50 mg/kg dose administered orally.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57
FMD-88
1H NMR (300 MHz, CDCl3)δ7.84(s, 1H, H18), 7.80 (d,J=9.0 Hz, 1H, H3), 7.58 (d,J=8.3 Hz, 1H, H6), 7.42 (d,J=8.3 Hz, 2H, H5 et H16), 7.31 (t,J=7.2 Hz, 1H, H17), 6.94 (t,J=7.3 Hz, 1H, H15), 3.59 (s, 2H, H13), 2.81 (d,J=10.6 Hz, 2H, H10 and H11), 2.58 (t,J=11.5 Hz, 2H, H10 and H11), 2.13 (d, J=2.8 Hz, 2H, H9 and H12), 1.69 (d, J=
13.4 Hz, 2H, H9 and H12).13C NMR (75 MHz, CDCl3)δ 147.9 (C14), 140.6 (C19), 139.6 (C5), 131.3 (C15), 130.6 (C1), 130.4 (C6), 129.4 (C17), 128.8 (C18), 128.1 (C3), 124.9(C2), 124.2 (q, C16), 121.2 (C4), 100.8 (C7), 71.1 (C8), 66.6 (C13), 49.1 (C10 and C11), 38.5 (C9 and C12). M/Z=495.01 g/mol. Yellow oil. Yield=35 %
FMD-93
1H NMR (300 MHz, CDCl3)δ7.87 (s, 1H, H18), 7.83 (d,J=9.0 Hz, 1H, H3), 7.59 (d,J=8.3 Hz, 1H, H6), 7.52 (d,J=8.3 Hz, 2H, H5 et H16), 7.28 (t,J=7.2 Hz, 1H, H17), 7.10 (t,J=7.3 Hz, 1H, H15), 3.59 (s, 2H, H13), 2.81 (d,J=10.6 Hz, 2H, H10 and H11), 2.58 (t,J=11.5 Hz, 2H, H10 and H11), 2.13 (d, J=2.8 Hz, 2H, H9 and H12), 1.69 (d, J=
13.4 Hz, 2H, H9 and H12).13C NMR (75 MHz, CDCl3)δ 147.8 (C14), 137.6 (C19), 132.8 (C5), 131.3 (C15), 130.8 (C1), 130.7 (C6), 129.4 (C17), 128.5 (C18), 127.9 (C3), 127.3 (C2), 124.8 (q, C16), 124.2 (C4), 121.2 (C7), 71.1 (C8), 61.9 (C13), 49.2 (C10 and C11), 38.5 (C9 and C12). M/Z=447.02 g/mol. Dark yellow oil. Yield=72 %
FMD-96
1H NMR (300 MHz, CDCl3)δ7.83 (s, 1H, H18), 7.79 (d,J=9.0 Hz, 1H, H3), 7.60 (d,J=8.3 Hz, 1H, H6), 7.44 (d,J=8.3 Hz, 2H, H5 et H16), 7.21 (t,J=7.2 Hz, 1H, H17), 7.10 (t,J=7.3 Hz, 1H, H15), 3.72 (s, 2H, H13), 2.75 (d,J=10.6 Hz, 2H, H10 and H11), 2.61 (t,J=11.5 Hz, 2H, H10 and H11), 2.48 (s, 3H, CH3), 2.03 (d,J=2.8 Hz, 2H, H9 and H12), 1.70 (d, J=13.4 Hz, 2H, H9 and H12).13C NMR (75 MHz, CDCl3) δ 147.8 (C14), 141.0 (C19), 135.7 (C5), 134.32 (C15), 131.28 (C1), 129.35 (C6), 129.1 (C17), 128.1 (C18), 127.1 (C3), 124.8 (C2), 124.2 (q, C16), 121.2 (C4), 71.2 (C7), 56.3 (C8), 48.9 (C13), 38.7 (C10 and C11), 20.0 (CH3). M/Z=417.87 g/mol. Brown oil. Yield=62 %
FMD-89
1H NMR (300 MHz, CDCl3)δ7.86 (s, 1H, H18), 7.81 (d,J=9.0 Hz, 1H, H3), 7.60 (d,J=8.3 Hz, 1H, H6), 7.48 (d,J=8.3 Hz, 2H, H5 et H16), 7.34 (t,J=7.2 Hz, 1H, H17), 7.22 (t,J=7.3 Hz, 1H, H15), 3.69 (s, 2H, H13), 2.81 (d,J=10.6 Hz, 2H, H10 and H11), 2.53 (t,J=11.5 Hz, 2H, H10 and H11), 2.12 (d, J=2.8 Hz, 2H, H9 and H12), 1.67 (d, J= 13.4 Hz, 2H, H9 and H12).13C NMR (75 MHz, CDCl3)δ 147.9 (C14), 136.0 (C19), 131.4(C5), 130.8 (C15), 130.7 (C1), 129.6 (C6), 129.4 (C17), 128.3 (C18), 128.0 (C3), 126.7 (C2), 124.9 (q, C16), 124.3 (C4), 121.3 (C7), 71.1 (C8), 59.4 (C13), 49.3 (C10 and C11), 38.6 (C9 and C12). M/Z=404.24 g/mol. Brown oil. Yield=50 %
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57
FMD-91
1H NMR (300 MHz, CDCl3)δ7.84(s, 1H, H18), 7.80 (d,J=9.0 Hz, 1H, H3), 7.40 (d,J=8.3 Hz, 1H, H6), 7.58 (d,J=8.3 Hz, 2H, H5 et H16), 7.46 (t,J=7.2 Hz, 1H, H17), 7.28 (t,J=7.3 Hz, 1H, H15), 3.53 (s, 2H, H13), 2.75 (d,J=10.6 Hz, 2H, H10 and H11), 2.45 (t,J=11.5 Hz, 2H, H10 and H11), 2.10 (d, J=2.8 Hz, 2H, H9 and H12), 1.70 (d, J=
13.4 Hz, 2H, H9 and H12).13C NMR (75 MHz, CDCl3)δ 147.9 (C14), 136.6 (C19), 132.9 (C15), 131.3 (C1), 130.7 (C6), 130.5 (C17), 129.3 (C18), 128.4 (C3), 124.8 (C2), 124.1 (q, C16), 121.1 (C4), 100.8 (C7), 71.0 (C8), 62.27 (C13), 49.1 (C10 and C11), 38.4 (C9 and C12). M/Z= 404.24 g/mol. Brown oil. Yield=80 %
FMD10
1H NMR (300 MHz, CDCl3)δ7.84 (s, 1H, H13), 7.55 (d,J=9 Hz, 1H, H17), 7.46 (d,J=9 Hz, 1H, H18), 7.16 (t,J=9 Hz, 1H, H3), 6.98 (d,J= 9 Hz, 1H, H5), 6.78 (d,J=9 Hz, 21H, H2 and H4), 3.75 (s, 2H, H7), 2.89 (d, J=12 Hz, 2H, H9 and H9’), 2.61 (t,J=12 Hz, 2H, H9 and H9’), 2.08 (t,J=12 Hz, 2H, H10 and H10’), 1.75 (d,J=12 Hz, 2H, H10 and H10’).13C NMR (75 MHz, CDCl3)δ157.69 (CIV, C1), 147.26 (CIV, C16), 131.53 (CHarom, C18), 131.08 (CIV, C14), 128.91 (CIV, C17), 124.78 (CIV, C15), 124.22 (CHarom, C13), 121.26 (CIV, C6), 119.43 (CHarom, C4), 116.08 (CHarom, C2), 70.69 (CIV, C11), 61.51 (CH2, C7), 48.68 (2CH2, C9 and C9’), 38.24 (2CH2, C10 and C10’). M/Z=385.11 g/mol. Brown oil.
Yield=41 %
FMD-94
1H NMR (300 MHz, CDCl3)δ7.84(s, 1H, H18), 7.58 (d,J=9.0 Hz, 1H, H3), 7.43 (d,J=8.3 Hz, 1H, H6), 7.30 (d,J=8.3 Hz, 2H, H5 et H16), 7.15 (t,J=7.2 Hz, 1H, H17), 3.82 (s, 2H, H13), 2.85 (d,J=10.6 Hz, 2H, H10 and H11), 2.68 (t,J=11.5 Hz, 2H, H10 and H11), 2.06 (d, J=
2.8 Hz, 2H, H9 and H12), 1.70 (d,J=13.4 Hz, 2H, H9 and H12).13C NMR (75 MHz, CDCl3)δ147.8 (C14), 137.0 (C19), 134.5 (C15), 131.3 (C1), 130.6 (C6), 129.4 (C17), 128.9 (C18), 128.4 (C3), 128.3 (C2), 124.8 (q, C16), 124.1 (C4), 121.2 (C7), 71.1 (C8), 56.6 (C13), 49.1 (C10 and C11), 38.5 (C9 and C12). M/Z=438.68 g/mol. Brown oil. Yield= 32 %
FMD-3
1H NMR (300 MHz, CDCl3)δ7.86 (s, 1H, H12), 7.60 (d,J=9.0 Hz, 1H, H2), 7.43 (m, 2H, H3 et H15), 7.23 (m, 1H, H5), 7.08 (m, 2H, H4 et H16), 3.65 (s, 2H, H7), 2.81 (d,J=9.0 Hz, 2H, H8 et H8’), 2.52 (t,J= 12 Hz, 2H, H8 et H8’), 2.14 (t,J=9 Hz, 2H, H9 et H9’), 1.68 (d, J= 12 Hz, 2H, H9 et H9’). 13C NMR (75 MHz, CDCl3)δ163.19 (CIV, C1), 159.93 (CIV, C14), 148.04 (CIV, C13), 131.77 (CHarom, C3), 131.38 (CHarom, C15), 129.41 (CIV, C11), 129.08 (CHarom, C2), 128.97 (CHarom, C5), 124.31 (CIV, C6), 124.24 (CIV, C4), 124.17 (CIV, C12), 123.97 (CIV, C17), 115.40 (CHarom, C16), 71.02 (CIV, C10), 55.44 (CH2, C7), 48.99 (2CH2, C8 et C8’), 38.52 ( 2CH2, C9 et C9’). M/Z=387.10 g/mol.
Brown oil. Yield=44 %
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57
FMD-15
1H NMR (300 MHz, CDCl3)δ7.86 (s, 1H, H12), 7.60 (d,J=9.0 Hz, 1H, H2), 7.45 (m, 2H, H3 et H15), 7.37–7.30 (m, 1H, H1 and H5), 7.21 (m, 2H, H4 et H5), 3.65 (s, 2H, H7), 2.81 (d,J=9.0 Hz, 2H, H8 et H8’), 2.52 (t,J=12 Hz, 2H, H8 et H8’), 2.14 (t,J=9 Hz, 2H, H9 et H9’), 1.68 (d, J=12 Hz, 2H, H9 et H9’).13C NMR (75 MHz, CDCl3)δ 147.9 (C14), 139.6 (C5), 131.3 (C15 and C19), 130.6 (C1), 130.4 (C6), 129.4 (C17), 128.8 (C16 and C18), 128.1 (C3), 124.9(C2), 121.2 (C4), 100.8 (C7), 71.1 (C8), 66.6 (C13), 49.1 (C10 and C11), 38.5 (C9 and C12). M/Z= 369.11 g/mol. Brown oil. Yield=55 %
FMD-33
1H NMR (300 MHz, CDCl3)δ7.56 (s, 1H, H3), 7.49 (s, 1H, H1), 7.32 (d, J=33.1 Hz, 1H, H5), 7.28–7.28 (m, 1H, H6), 7.20 (m, 1H, H16), 7.18 (dd,J=9.3, 8.3 Hz, 3H, H17, H18 and H19), 3.96 (s, 2H, H13)„ 2.68–
2.63 (m, 2H, H11 and H10), 2.46 (m, 2H, H11 and H10), 2.36 (s, 3H, CH3), 2.14 (m, 2H, H9 and H12), 1.87 (m, 2H, H9 and H12).13C NMR (75 MHz, CDCl3) δ139.9 (C4), 138.1 (C14), 136.5 (C19), 135.9 (C2), 130.3 (C18), 130.0 (C5), 129.9 (C6), 128.1 (C15), 126.6 (C16), 126.2 (C1), 125.3 (C17), 125.2 (C3), 124.1 (C7), 73.7 (C8), 61.6 (C13), 49.2 (C10 and C11), 37.5 (C9 and C12), 19.4 (CH3). M/Z=349.17 g/mol.
Black oil. Yield=27 %
FMD-61
1H NMR (300 MHz, CDCl3)δ7.77 (d,J=18.5 Hz, 1H, H17), 7.71 (s, 1H, H22), 7.61 (s, 1H, H3), 7.59 (s, 1H, H15),7.44 (d,J=18.5 Hz, 1H, H15), 7.42 (m, 2H, H18 and H19), 7.28 (s, 1H, H6), 7.21 (d,J=36.3 Hz, 1H, H5), 3.63 (s, 2H, H13), 2.67 (m, 2H, H10 and H11), 2.49 (m, 2H, H10 and H11), 2.14 (m, 2H, H9 and H12), 1.87 (m, 2H, H9 and H12).13C NMR (75 MHz, CDCl3) δ 139.1 (C4), 138.1 (C14), 136.1 (C2), 134.4 (C16), 134.2 (C1), 134.0 (C21), 131.3 (C5), 129.7 (C6), 128.9 (C17), 128.8 (C22), 128.8 (C15), 128.4 (C23), 128.3 (C20), 127.0 (C18), 125.6 (C19), 124.4 (C3), 124.0 (C7), 73.7 (C8), 64.2 (C13), 49.2 (C10 and C11), 37.5 (C9 and C12). M/Z=419.30 g/mol. Light brown oil.
Yield=19 %
FMD-63
1H NMR (300 MHz, CDCl3)δ7.48 (s, 1H, H5), 7.28 (s, 1H, H6), 7.23 (m, 1H, H18), 7.20 (m, 1H, H5), 7.16 (m, 2H, H15 and H19), 7.09 (s, 1H, H17), 3.60 (s, 2H, H13), 2.67 (m, 2H, H10 and H11), 2.35 (s, 3H, CH3), 2.32 (m, 2H, H10 and H11), 2.13 (m, 2H, H9 and H12), 1.93 (m, 2H, H9 and H12). 13C NMR (75 MHz, CDCl3)δ 139.1 (C14), 139.1 (C4), 138.4 (C16), 136.1 (C2), 134.2 (C1), 131.3 (C5), 129.7 (C6), 128.4 (C18), 127.7 (C15), 127.5 (C17), 125.9 (C19), 124.4 (C3), 124.0 (C7), 73.7 (C8), 64.0 (C4), 49.2 (C10 and C11), 37.5 (C9 and C12) 21.2 (CH3). M/Z=383.13 g/mol. Brown oil. Yield=49 %
FMD-66
1H NMR (300 MHz, CDCl3) δ 7.48 (s, 1H, H3), 7.23 (dd, J=25.6, 14.4 Hz, 1H, H6), 7.22 (s, 1H, H5), 7.20 (m,2H, H15 and H19), 7.16
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57
(m, 2H, H16 and H18), 3.56 (s, 2H, H13), 2.67 (m, 2H, H10 and H11), 2.34 (s, 3H, CH3), 2.32 (m, 2H, H10 and H11), 2.13 (m, 2H, H9 and H12), 1.93 (m, 2H, H10 and H11).13C NMR (75 MHz, CDCl3)δ139.1 (C1), 136.1 (C2), 135.2 (C17), 134.4 (C14), 134.2 (C1), 131.3 (C5), 129.8 (C16 and 18), 129.7 (C6), 129.5 (C15 and C19), 124.4 (C3), 124.0 (C7), 73.7 (C8), 63.7 (C13), 49.2 (C10 and C11) 37.5 (C9 and H12), 21.1 (CH3). M/Z=383.13 g/mol. Brown oil. Yield=68 %
FMD-32
1H NMR (300 MHz, CDCl3)δ7.30 (s, 1H, H6), 7.27 (s, 1H, H2), 7.18 (m, 2H, H3 and H5), 7.17 (s, 1H, H14), 7.15 (s, 1H, H17), 7.14 (s, 1H, H16), 7.13 (s, 1H, H15), 3.98 (s, 2H, H12), 2.65 (m, 2H„ H9 and H10), 2.35 (m, 5H, H9, H10 and CH3), 2.13 (m, 2H, H8 and H13), 1.93 (m, 2H, H8 and H13).13C NMR (75 MHz, CDCl3)δ142.1 (C4), 138.1 (C13), 136.5 (C18), 136.2 (C1), 130.3 (C17), 129.4 (C2 and C6), 128.1 (C3 and C5), 128.1 (C3 and C5), 126.6 (C15), 125.3 (C16), 73.6 (C7), 61.6 (C12), 49.2 (C9 and C10), 37.5 (C8 and C11), 19.4 (CH3). M/Z=315.14 g/
mol. Yellow oil. Yield=57 %
FMD-6
1H NMR (300 MHz, CDCl3) δ7.83 (s, 1H, H7), 7.52 (d,J=9 Hz, 1H, H10), 7.41 (d,J=9 Hz, H11), 4.10 (s, 2H, Cp), 4.08 (s, 5H, Cp’), 4.06 (s, 2H, Cp), 3.38 (s, 2H, H1), 2.7 (d,J=12 Hz, 2H, H3 et H3’), 2.39 (t,J= 12 Hz, 2H, H3 et H3’), 2.06 (t,J=9 Hz, 2H, H4 et H4’), 1.59 (d,J= 9 Hz, 2H, H4 et H4’).13C NMR (75 MHz, CDCl3)δ131.20 (CHarom, C11), 130.36 (CIV, C9), 129.36 (CHarom, C10), 128.00 (CIV, C8), 124.82 ((CIV, C6), 124.23 (CHarom, C7), 121.20 (CIV, C12), 70.52 (CIV, C5), 70.39 (2CHarom, Cp), 68.54 (5CHarom, Cp’), 68.18 (2CHarom, Cp), 58.18 (CH2, C1), 48.33 (2CH2, C3 et C3’), 37.96 (2CH2, C4 et C4’). M/Z=477.08 g/
mol. Yellow oil. Yield=46 %
FMD103
1H NMR (300 MHz, CDCl3)δ7.80 (s, 1H, H1), 7.66 (m, 2H, H3 and H5), 7.20 (m, 1H, H15), 7.18 (dd,J=10.5, 4.7 Hz, 1H, H18), 7.17 (m, 2H, H16 and H17), 3.72 (s, 2H, H13), 2.65 (m, 1H, H10 and H11), 2.45 (m, 2H, H10 and H11), 2.38 (s, 3H, CH3), 2.15 (m, 2H, H9 and H12), 1.89 (m, 2H, H9 and H12).13C NMR (125 MHz, CDCl3)δ143.0 (C4), 139.0 (C2 and C6), 138.1 (C14), 136.5 (19), 130.3 (C18), 128.6 (C3 and C5), 128.1 (C15), 126.6 (C16), 125.3 (C1 and 17), 124.4 (C7 and C20), 73.7 (C8), 61.6 (C13), 49.2 (C10 and C11), 37.5 (C9 and C12) 19.4 (CH3). M/
Z=417.15 g/mol. Brown oil. Yield=62 %
FMD-9
1H NMR (300 MHz, CDCl3)δ 7.81 (s, 1H, H6), 7.52 (d,J=9 Hz, 1H, H21), 7.40 (d,J=9 Hz, 1H, H20), 6.83 (s, 2H, H3 and H7), 3.49 (s, 2H, H10), 2.71 (d,J=9 Hz, 2H, H11 and H11’), 2.36 (d,J=9 Hz, 6H, H8 and H9), 2.24 (d, J=6 Hz, 3H, H1), 1.95 (d, J=9 Hz, 2H, H12 and H12’), 1.61 (d,J=9 Hz, 2H, H12 and H12’).13C NMR (75 MHz, CDCl3) δ148.0 (C5), 137.4 (C2, C4 and C6), 136.5 (C19), 132.1 (C17), 132.1 (C21), 129.4 (C20), 129.1 (C3 and C7), 124.9 (C15), 124.2 (C16), 121.3 (C18), 71.4 (C13), 59.1 (C10), 48.93 (2CH2, C11 and C11’), 38.85 (2CH2, C12 and C12’), 20.97 (CH3, C1), 20.17 (2CH3, C8 and C9). M/
Z=411.16 g/mol. Brown oil. Yield=28 %
FMD-92
1H NMR (300 MHz, CDCl3)δ7.74 (s, 1H, H1), 7.59 (m, 2H, H3 and H5), 7.32 (s, 1H, H15), 7.21 (t,J=15.1 Hz, 3H, H17, H18 and H19), 3.67 (s,
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57
2H, H13), 2.64 (m, 2H, H10 and H11), 2.46 (m, 2H, H10 and H11), 2.15 (m, 2H, H9 and H12), 1.95 (m, 2H, H9 and H12). 13C NMR (75 MHz, CDCl3)δ143.0 (C4), 141.2 (C14), 139.0 (C2 and C6), 133.3 (C16), 129.2 (C18), 128.6 (C15), 128.6 (C3 and C5), 127.1 (C19), 126.7 (C17), 125.3 (C1), 124.4 (C7 and C20), 73.67, 64.0 (C13), 49.2 (C10 and C11), 37.5 (C9 and C12). M/Z=403.07 g/mol. Dark yellow oil.
Yield=41 %
FMD-102
1H NMR (300 MHz, CDCl3)δ7.82 (m, 1H, H3), 7.79 (m, 2H, H6 and H10), 7.78 (s, 1H, H7) 7.48–7.40 (m, 3H, H1, H2 and H9), 7.22–7.14 (m, 4H, H21, H22, H23 and H24), 3.64 (s, 2H, H18), 2.69 (m, 2H, H14 and H16), 2.44 (m, 2H; H14 and H16), 2.34 (s, 3H, H25), 2.16 (m, 2H, H13 and H17), 1.89 (m, 2H, H13 and H17).13C NMR (75 MHz, CDCl3) δ142.3 (C8), 138.1 (C19), 136.5 (C20), 134.5 (C5), 134.0 (C4), 130.3 (C21), 130.2 (C10), 129.7 (3), 128.2 (C6), 128.1 (C24), 127.0 (C1), 126.6 (C23 and C9), 126.5 (C2), 125.3 (C22), 123.4 (C7), 73.5 (C11), 61.6 (C18), 49.2 (C14 and C16), 37.5 (C13 and C17), 19.4 (C25). M/
Z=331.19 g/mol. White oil. Yield=71 %
FMD-99
1H NMR (300 MHz, CDCl3)δ7.29 (m, 2H, H1 and H6), 7.25 (m, 2H, H3 and H5), 7.21 (m, 2H, H2 and H20), 7.18 (m, 1H, H19), 7.17 (m, 1H, H18), 7.16 (m, 1H, H16), 3.67 (s, 2H, H14), 2.72 (m, 2H, H10 and H12), 2.50 (m, 2H, H10 and H12), 2.34 (s, 3H, H21), 2.18 (m, 2H, H9 and H13), 1.91 (m, 2H, H9 and H13).13C NMR (75 MHz, CDCl3)δ143.4 (C4), 138.1 (C15), 136.5 (C16), 130.3 (C17), 128.5 (C1 and C6), 128.2 (C2), 128.1 (C20) 126.6 (C19), 126.3 (C3 and C5), 125.3 (C18), 73.6 (C7), 61.6 (C14), 49.2 (C10 and C12), 37.5 (C9 and C13), 19.4 (C21).
M/Z=281.18 g/mol. Colorless oil. Yield=52 %
FMD-64
1H NMR (300 MHz, CDCl3)δ7.56 (d,J=1.5 Hz, 2H, H5 and H17), 7.34 (s, 1H, H19), 7.30 (m, 1H, H1), 7.24 (m, 2H, H3 and H20), 7.21 (m, 1H, H18), 3.87 (s, 2H, H14), 2.78 (m, 2H, H10 and H12), 2.46 (m, 2H, H10 and H12), 2.18 (m, 2H, H9 and H13), 1.91 (m, 2H, H9 and H13).13C NMR (75 MHz, CDCl3) δ 139.1 (C4), 136.1 (C6), 134.7 (C15), 134.2 (C2), 132.0 (C19), 131.3 (C3), 129.9 (C20), 129.7 (C1), 128.0 (C16), 126.7 (C18), 126.6 (C17), 125.0 (C22), 124.4 (C5), 124.0 (C26), 73.7 (C7), 61.7 (C14), 49.2 (C10 and C12) 37.5 (C9 and C13). M/Z= 437.10 g/mol. Yellow oil. Yield=34 %
FMD-62
1H NMR (300 MHz, CDCl3)δ7.55 (s, 1H, H5), 7.30 (s, 1H, H1), 7.21 (s, 1H, H3), 7.05 (m, 2H, H16 and H20), 6.68 (m, 2H, H17 and H19), 3.44 (s, 2H, H14), 3.41 (m, 2H, H23 and H27), 3.14 (m, 2H, H23 and H27), 2.65 (m, 2H, H10 and H12), 2.42 (m, 2H, H10 and H12), 2.13 (m, 2H, H9 and H13), 1.90 (m, 2H, H9 and H13), 1.68 (m, 4, H24 and H26), 1.62 (m, 2H, H25). 13C NMR (75 MHz, CDCl3) δ 148.7 (C18), 139.1 (C4), 136.1 (C6), 134.2 (C2), 131.3 (C3), 129.7 (C1), 129.4 (C16 and C20), 128.6 (C15), 124.4 (C5), 124.0 (C28), 114.1 (C17 and C19), 73.7 (C7), 63.7 (C14), 49.7 (C23 and C27), 49.2 (C10 and C12), 37.5 (C9 and C13), 25.1 (C24 and C26), 23.4 (C25). M/Z=452.18 g/mol.
Brown oil. Yield=41 %
FMD46
1H NMR (300 MHz, CDCl3)δ7.50 (s, 1H, H5), 7.44 (s, 1H, H2), 7.27 (d, J=12.4 Hz, 2H, H1 and H3), 3.11 (s, 1H, H8), 2.85 (m, 2H, H10 and H12), 2.75 (m, 2H, H10 and H12), 2.11 (m, 2H, H9 and H13), 1.90 (m, 2H, H9 and H13).13C NMR (75 MHz, CDCl3)δ140.0 (C4), 135.9 (C6),
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57
130.0 (C3), 129.9 (C1), 126.2 (C2), 125.2 (C5), 124.1 (C14), 72.9 (C7), 44.1 (C10 and C12), 37.8 (C9 and C13). M/Z=245.10 g/mol. Light brown oil. Yield=53 %
FMD-0
1H NMR (300 MHz, CDCl3)δ 7.50 (s, 6H), 7.29 (s, 2H), 7.24 (d, J=
38.3 Hz, 10H), 2.88–2.81 (m, 12H), 2.78–2.71 (m, 12H), 2.35 (s, 6H), 2.12–2.08 (m, 9H), 1.92–1.86 (m, 11H), 1.71 (s, 6H).13C NMR (75 MHz, CDCl3)δ139.1 (C4), 136.1 (C6), 134.2 (C2), 131.3 (C3), 129.7 (C1), 124.4 (C5), 124.0 (C15), 72.9 (C7), 44.1 (C10 and C12), 37.8 (C9 and C13). M/Z=279.06 g/mol. Brown oil. Yield=25 %
FMD-16
1H NMR (300 MHz, CDCl3)δ7.22 (s, 1H, H10), 7.16 (m, 3H, H11, H12 and H13), 3.67 (s, 2H, H8), 3.61 (m, 1H, H6), 2.65 (m, 2H, H2 and H4), 2.35 (s, 3H, H15), 2.31 (m, 2H, H2 and H4), 1.94 (m, 2H, H1 and H5), 1.75 (m, 2H, H1 and H5). 13C NMR (75 MHz, CDCl3)δ 138.1 (C9), 136.5 (C14), 130.3 (C13), 128.1 (C10), 126.6 (C11), 125.3 (C12), 65.6 (C6), 61.6 (C8), 51.1 (C2 and C4), 34.5 (C1 and C5), 19.4 (C15). M/Z= 205.15 g/mol. Yellow oil. Yield=74 %
FMD-37
1H NMR (300 MHz, CDCl3)δ7.50 (s, 1H), 7.23 (d,J=1.1 Hz, 2H, H19 and H20), 7.18 (m, 2H, H10 and H11), 7.15 (m, 1H, H12), 7.12 (m, 1H, H13), 6.31 (s, 1H, H5), 4.07 (s, 1H, H8), 3.56 (m, 2H, H4), 3.18 (s, 1H, H8), 2.80 (s, 1H, H2), 2.56 (s, 1H, H2), 2.51 (m, 2H, H1), 2.33 (m, 3H, H15).13C NMR (75 MHz, CDCl3)δ140.7 (C7), 138.1 (C9), 136.5 (C14), 132.3 (C17), 132.3 (C20), 130.9 (C19), 130.8 (C6), 130.4 (C18), 130.3 (C13), 128.1 (C10), 126.6 (C11), 125.3 (C12), 124.4 (C16), 124.0 (C22), 119.2 (C5), 60.0 (C8), 52.3 (C4), 51.2 (C2), 28.7 (C1), 19.4 (C15). M/Z= 365.12 g/mol. Brown oil. Yield=19 %
Biology
Cytotoxicity assay. Cell viability was determined using Vero epithelial cells which were grown in RPMI medium containing 10 % fetal bovine serum (RPMI FBS) and differentiated with 20 ng/ml phorbol myristate acetate (PMA) and incubated for 48 h at 37°C, under a 5 % CO2atmosphere. Cells were seeded in 96-well plates at a density of 2 × 104cells/well in 160μl medium and incubated overnight at 37°C to allow cells to adhere. Compounds (dissolved in DMSO) were freshly diluted in RPMI starting at a concentration of 100μg/ml up to a concentration of 0.048μg/ml (serial dilution of factor 2), and 20μl of those dilution were added in corresponding wells. The maximum final concentration of DMSO was 1 % (v/v).
After 24 h incubation at 37°C with 5 % CO2, 20μl of 1 mg/ml resazurin (Sigma, Germany) was added to each well and the cells incubated for an additional 2 hours at 37°C in the presence of 5 % CO2. Fluorescence was then measured in a Polarstar Omega fluorometer using appropriate filters (590 nm emission and 540 nm excitation wavelength). Percentage survival was determined by dividing fluorescence values obtained in the compound containing wells by values obtained for control wells containing cells incubated with a dilution series of DMSO (serial dilution of factor 2 from 1 % to 0.000488 % v/v). Experiments were complete in triplicate on three independent events.
Drug susceptibility testing. To determine the MICs, broth micro- dilution method in CaMHB using an inoculum containing 5 × 10 CFU/ml in the exponential-growth phase were achieved follow- ing the CLSI guidelines.[28]Briefly, 100μl of bacteria were seeded in 96-well plates, and 2μl of drug at its highest concentration in a maximum of 1 % of DMSO (v/v) was added to the first wells containing 200μl of bacterial suspension and a twofold serial dilutions were then done out. Incubation with drugs was performed at 30°C for 3 to 5 days. MICs were recorded by visual inspection and by absorbance at 560 nm to confirm visual recording. Experi- ments were done in triplicate on three independent occasions.
Molecular Modelling
Comparative modelling of MAB_4508 was performed using Modeller[35] and the crystal structure (2.8 Å, PDB ID: 6AJJ) of a mycolic acid transporter from M. smegmatis (Sequence identity:
64.9 %) as template. Quality of the model was assessed using MolProbity.[36]Subsequent energy minimization of the global model was performed using AMBER forcefield in order to remove putative steric clashes between side chains. Simulation of the binging modes of the target and the designed compounds was performed using GOLD docking program.[37] GOLD is based on a genetic algorithm and considered the ligand as flexible, while side chains of most residues are kept rigid. For the search procedure, a sphere of 10 Å was centred on the X, Y and Z coordinates of our identified binding centre. Then, all the different binding poses were scored with the ChemPLP scoring function. Subsequent energy minimiza- tion was performed using the AMBER forcefield. Finally, all the molecular representations were sketched using PyMOL.[38]
Toxicologic and Pharmacokinetics Studies; Mouse Blood and Tissue Sampling
Experimental compound PIPD1 was administered either intraper- itoneally, intraveinously or by oral gavage. For toxicologic studies, PIPD1 was diluted in DMSO at different concentrations in order that mice receive either intraperitoneally or intraveinously the doses of 250 mg/kg, 100 mg/kg, 50 mg/kg and 10 mg/kg in a total volume of 50μl corresponding respectively to 5 mg, 2, 1 and 0.2 mg/mice.
Control groups were administered with the equivalent volume of
