A new way of using positron-lifetime measurements to study lattice defects

HAL Id: jpa-00208882

https://hal.archives-ouvertes.fr/jpa-00208882

Submitted on 1 Jan 1979

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are pub- lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

A new way of using positron-lifetime measurements to study lattice defects

Ch. Janot, B. George, M. Boidron

To cite this version:

Ch. Janot, B. George, M. Boidron. A new way of using positron-lifetime measurements to study lattice defects. Journal de Physique, 1979, 40 (1), pp.39-45. �10.1051/jphys:0197900400103900�. �jpa- 00208882�

A

new way

of using positron-lifetime measurements

to

study lattice defects

Ch. Janot, ^B.

George

Laboratoire de Physique ^du Solide, Faculté des Sciences, C.O. n° 140, ⁵⁴⁰³⁷ Nancy Cedex, ^France

and M. Boidron

Centre d’Etudes Nucléaires, ^{B.P. n°} 6, ⁹²²⁶⁰ Fontenay ^aux Roses, ^France (Reçu ^{le 26} juin ^1978, accepté ^{le 21} septembre 1978)

Résumé. ²⁰¹⁴ Dans le but d’étendre les mesures de temps de vie des positons ^vers les hautes températures ^{et d’éviter}

les complications ^{dues aux} annihilations dans la source et à la surface de l’échantillon, ^des experiences ^{ont été}

réalisées à partir ^{de sources} intégrées ^{où les} isotopes émetteurs de positons ^{sont à l’état} d’impureté isolée dans le materiau étudié. Par ailleurs, ^{on montre} qu’il ^est possible, ^à partir ^{des mesures de} temps ^de vie, ^d’obtenir l’énergie

de formation des lacunes

EF1V,

^sans être tributaire des imperfections du modèle du piégeage. ^On explique ^aussi

les correlations observées précédemment ^entre

EF1V

^{et la} température Ti ^du point d’inflexion dans la courbe

03C4(1/T).

Abstract. ²⁰¹⁴ With the aim of extending positron-lifetime measurements to high temperature ^and avoiding ^surface

and source contributions, experiments ^{have been} performed ^with positron emitting isotopes ^{in a state of diluted}

solid solution in the material investigated. ^Further, it has been shown that the positron-lifetime ^{data can be used}

in a new way ^to obtain the vacancy formation energy

EF1V

without the many uncertainties of the trapping ^model.

The previously observed linear correlation between

EF1V

and the inflection temperature Ti ^{in the} 03C4(1/T) ^curve

has also been explained.

Classification Phvsics Abstracts

61.70 ^{- 78.70B}

1. Introduction. ^- Since the

pioneering

^{work of}

MacKenzie et al. [1] positron annihilation has become

a widely ^{used tool for} investigating ^the

properties

^of

vacancies in metals in thermal

equilibrium.

^The many

experimental

results that have been obtained and the many ways of

analysing

^{them have been} extensively

presented

^{in a number of review papers [2]-[7].}

1. 1. ^- Positron sources for lifetime measurements

were often

prepared by depositing

^{the source}

isotope

(commonly ^22Na in the form of sodium chloride)

either directly ^{on a surface, or} between thin

organic

(or metallic) foils sandwiched between two plates ^of

the material to be

investigated.

Measuring tempe-

ratures are then limited either by ^the

melting

point

or by ^the

evaporation

^{of the source} material. The method has the extra disadvantage ^{of a}

relatively

large fraction of

positrons

annihilating ^{either in the}

source-supporting

^{material or at the}

specimen

^surface,

giving

^{rise to serious} background

problems [8],

[9], [ 10]

and drastic limitations in the total activity ^{that can be} really ^used.

Integrated source-specimen

systems ^for

high temperature positron annihilation

experiments

have been recently

designed

[11]-[13]. ^In this so-called sealed-source

technique,

^{the source material} ( N ¹⁰

uCi

of carrier-free

22NaCl)

^is

hermetically

sealed between two discs of the material to be

investigated

^{which are}

electron-beam welded under

high

^vacuum.

Obviously,

this method has

proved

^{to be}

quite

^{effective at}

high

temperature ^{and has} brought ^some

improvements regarding

^the parasitic

intensity

^{of the} long-lived

source component. Limitations _are, the still present surface component ^{and a}

possible

break of the weld under the vapour pressure of the source material [11], [14].

A technique

using

^metal

specimens containing positron

^source

isotopes

^{as bulk}

impurities

^is

presented

in this _paper.

1.2. - Data on positron annihilation near ther-

mally generated vacancies in metals are conven-

tionally

analysed by ^a trapping ^{model which is}

generally recognized

^{to contain}

questionable approxi-

mations and too many

adjustable

parameters [ 15], [16] ;

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphys:0197900400103900

40

factors such as thermal expansion, temperature

depen-

dence of the

trapping

^rate,

detrapping

mechanisms,

self-trapping

^or

phonon-assisted trapping

[17], pre-

sence of other defects

(impurities,

dislocations...)

have influences that cannot be taken into account as

they should be. This usually

produces

^{values of the}

monovacancy formation _energy

E ;,

^{which are some-}

what low when

compared

^with results from established

techniques, ^{or are not} intemally consistent [18], [19], [3]. There is additional concern arising from the fact that for instance, ^{data on Al can be}

analysed

equally

well [20] ^{in terms of a}

temperature-independent

^{or a} strongly

temperature-dependent Eiv

^{of the} type

suggested

by Popovic et ^al. [21] ; ^{moreover, when}

the model is used with metals

of higher

melting

points,

such as the noble metals [22], [13] ^the agreement ^with

other methods is far from

satisfactory. Consequently,

it has often been

suggested

[23], [6],

[24], [12]

^that,

until the _many uncertainties of the

trapping

^model

have been clarified, ^it may be

preferable

^to analyse

positron

^data through ^{a more}

phenomenological approach,

using ^the

empirical

^linear correlations between

Eiv

^{and some} characteristic temperatures :

1.1.1. ^-

T;

which is the temperature of the inflec- tion

point

^{in the} plot ^{of i} (mean lifetime of

positrons)

against 1/T :

E’

(eV) ^{= 1.13 x 10-3} Ti (K) [6].

1.1. 2. ^- The threshold temperatures

Tt

^{at which} thermally

generated

^vacancies

produce

^measurable

positron trapping.

^{This has} the additional

advantage

of

giving

^a

precise

determination of

Eiv

^without

approaching

^the melting

point

^{- a}

major

^{one in}

dealing

with refractories [12], ^{with metals}

having high

vapour pressure in the solid state [24], [13], ^{or with} alloys [6].

It will be the main _purposes of this _paper to show that :

a)

positron

annihilation data can be fruitfully analysed ^{without the} need of the

trapping

^model formalism,

b) the linear correlation between

E F

^and Ti ^{is not}

fortuitious but derived from the trapping ^{model and}

must be used carefully because of a

possible

crystallo- graphic ^structure

dependence

^{of the}

proportionality

factor,

c) computer ^simulated

r(I/T)

^{curves as derived}

from the

trapping

^{model are} strongly ^affected by

changes

ⁱⁿ

trapping

rates,

detrapping

process, ^etc.

except for the value

of E1v

^{that can} be calculated from the characteristics of the inflection

point

Both the new source technique ^{and the new method}

of analysis ^{will be tested on} aluminium metal.

2.

Expérimental

procédure ^{and results. - The} electronic apparatus ^{used to measure the}

positron-

annihilation lifetimes is basically ^a high-resolution timing ^{device with fast and slow} coincidence circuits, plastic scintillators, ^a

time-to-amplitude

^conversion capacitor ^{and an} energy discriminator. The data are

accumulated in a multichannel analyser ^{in the form}

of a

histogram

^{of the number of events as a function}

of time. In a metal this is the sum of exponential components ^folded with the resolution of the instru- ment and a constant

background

^{due to random}

coincidence. The mean lifetime as a function of temperature ^{is obtained} by ^a computer ^fit

analysis

as described elsewhere [25], [14]. ^A

good

estimate of the resolution _may be obtained

by

substituting ^{a 6°Co}

source in

place

^{of the}

sample.

^{Since 6°Co emits two}

y-rays within - _{5 ps} of each other, ^the measured time spectrum ^{will be} essentially the resolution of the instrument. Such a prompt coincidence curve has been found to have a half width of 300 ps. In the lifetime

region ^{studied here} ( 150 ⁱ

300 ps) the uncertainty

will be of about _{2 ps.}

A new type ^of

positron-lifetime

^{source has been} tested,

using

^{5 sCo}

positrons emitting isotope

^{in a}

state of diluted solid solution in the material to be

investigated.

^{In the case of} interest, ^the specimen ^was

a

cylinder

^{of 99.999}

%

purity aluminium, ^{3 mm thick} and 10 mm in diameter in which about 50

yci

^{of S8Co}

were diffused by

annealing

^{near the}

melting

tempe- rature, ^after

electrodeposition

^{of 58CO from} chloride ;

undiffused cobalt and

possible

^corrosion

products

were carefully removed from the

sample

^surface by

polishing. Although

^{the two} y-photons ^{emitted at}

birth and annihilation of

positrons

^{are less} easily

discriminated here than with a 22Na source (0.511,

1.28 MeV for 22Na and 0.511, 0.81 ^{MeV for}

58Co),

the

improvement regarding

^the

intensity

^{of the}

long-

lived source and surface components is obvious

(Fig.

1). ^In addition such a

diffused

^source is very suitable for

high

temperature work and lifetime measurements after thermal or mechanical treatments.

Aluminium has been chosen as a test material because of the abundance of good data available

regarding

^the vacancy formation _energy

(see

^for

instance [6] ^table

II).

^{To obtain}

reproducible

^{data in}

the low temperature part ^{of the} 7(T) curve, the _spe- cimen has to be

carefully

^{annealed near the}

melting

temperature ^{in order to} stabilize the dislocations in the material.

Table 1

gives

^some

typical

^{values of the mean}

lifetime i of the

positrons

^{as a function}

of temperature.

Table I.

Fig. ^{1. -} Positron-lifetime spectra in aluminium : (a) ^with 22Na conventional source; (b) ^{with 58CO} diffused ^source.

Fig. ^{2. -} Temperature dependence ^{of the mean lifetime in alumi-}

nium : (a) i( T) ^{full line :} best fit from a trapping ^model (upper scale) ; (b) 77(l / T)

(lower

^scale).

(c)- dr-/d(I/T)1

This is

pictured

ⁱⁿ figure ²

(curve (a))

along ^{with two}

other curves : the variation of ? with the

reciprocal

temperature

(curve (b))

and the derivative curve

d’f/d(I/T) (curve (c))

^{whose maximum}

^gives

^the

coordinates of the inflection

point

ⁱⁿ 7(1/T), ^{that is :}

Let us remark that

using T;

⁼ 653.6 K in the

empirical

^formula

proposed

by Doyama [6]

(Efv

^{= 1.13 x 10 - 3}

rj

^{results in}

E F

^{= 0.73 eV}

which is in

good

agreement with the other available data [26].

3. An

original

^{method to calculate}

Eiv

^from 1(T)

data. ^- In this section the

trapping

model will be

fully criticized. In particular, ^{it will be} shown that a

direct

fitting procedure

^{of the} 7(T) ^{curve on the}

trapping

^{model formula cannot lead to the} proper value of the _vacancy formation _energy

Efv.

^The

drastic influence of factors such as the

positron

trapping rate, the

detrapping

occurrence, the thermal

expansion

^{of the} lattice, the presence of other defects,

a proper choice for the asymptotic ^{lifetime in the}

lattice iL

^and in the vacancy trap i 1 v will be systema- tically analysed. Incidentally, ^the empirical ^formula

E’(Ti)

^{will be shown to be} contained in the

trapping

model.

Eventually, ^{we will} demonstrate that the many uncertainties of the

trapping

^{model can be} easily

bypassed

^if

E’

^is calculated from the coordinates of the inflection

point

^{in the} i(1/T) ^curve.

3.1 THE TRAPPING MODEL

(see

for instance Ref. [6], [19],

[27]).

^{- Let the} number of free positrons ^{in the}

lattice and those

trapped

by ^vacancies

be nL

^and n 1 v

respectively.

^{Then the rate} equations ^are given by :

where :

. Jll v’ the

specific

positron trapping ^{rate is} usually

written

concentration at température ^T [26],

is the

detrapp-

ing ^rate expressed ^{in terms} ’of a

vacancy-positron

binding

energy eB, the positron ^{mass m and the radius a}

of the

trapping

^volume.

0

TL( T) and r, 1v(T)

^are usually

naively

supposed

to vary only through the lattice thermal expansion,

that is :

and

iL

^and

To

^are merely deduced from the extrapolated

values of the 7(T) experimental ^{curve at low and} high temperature (a ^{= 8.4 x} 10- 5 K-1 in Al).

Solution of eq. (1) ⁱⁿ steady ^state conditions gives

the mean lifetime of positrons i(T) :

42

Table II.

When there are many kinds of trapping centres, M1v

Ci v

^{must be}

replaced

in eq. (1) by ^a

sum 03A3

^mi

Ci

i over all the different

trapping

^{centres. In metals for} instance, ^{there is} always ^a contribution from the so-

called Frank lattice dislocations which is

equivalent

^to

a concentration of

Cd

^vacancies whatever the tempe-

rature.

By

using

^{a standard} least-square

procedure,

eq. (2)

has been fitted as usual to the present

experimental

data on the assumption ^{that no}

detrapping

^of

positrons

occurs. The values for best fit are given ^{in table II}

and have been used to draw the full line in figure ^2a.

In addition to a too low value of

E’V,

the results are

unrealistic in

particular

because of an overestimate of the

trapping

^{rate. Indeed, from} eq. (1) ^the

expected

order of magnitude ^for

lilv is

^{about 200}

ps-1,

^10’

smaller than the fitted value. We will see later that the

discrepancy

^comes mainly ^{from the} opposite ^influences

of

detrapping

^{and thermal} expansion ^{which are}

difficult to take into account with their true values in the

trapping

^model.

3.2 THE ORIGINAL « INFLECTION POINT » METHOD.

-

If detrapping

might ^be neglected, eq. (2) ^{could be}

rewritten :

where t(T),

yl,(T)

^and

C1v(T)

^are supposed ^{to be} temperature

dependent

^{as described in 3.1. In the}

following,

7(T) ^as given by eq. (3) ^will be referred to

as the

simple

trapping ^{model. A}

straightforward

^calcu- lation,

stating

^that

d2t/d(I/T)2

^{= 0 for the} particular temperature Ti, shows that at the inflection point ^of the curve t(I/T), ^the fraction of

positrons annihilating

in a

perfect region

of the lattice is equal ^{to the fraction}

annihilating

^at vacancies, ^and consequently :

or

which is

just

^an expression ^of

Efv

equivalent ^{to the}

so-called empirical formula of Doyama [6].

The reason

why

^Ln

[.LI v 1:L ex p slv k ]

^{i s a cons-}

tant, ^{is not} very clear and might vary from ^a f.c.c.

structure, ^to b.c.c. or h.c.p.... because of the influence of the

crystallographic

^{order on}

sBfv

and of the

influence of the packing ^{fraction on}

iL(T). In

^any

case, eq. (4) ^{cannot be used} directly ^{to calculate}

Efv

since

J1v(Ti}

^and

SF1v

^{are not} given by

positron

annihilation experiments.

However,

calculating 1

^{dI at the} inflection point

dT

temperature

Ti,

^and using eq. (4) ^with

results in a new

expression

^for

El,

^{that is :}

It is easy ^to show by numerical estimates that the two first terms in the right ^{hand side}

of eq.

(5) ^account

for about 10-’ in

Eiy

^of vacancies in metals; ^this contribution will be neglected ^{in the}

following

^because

of its irrelevance to experimental accuracy in

E ;,

measurements. The x term contribution is

relatively

small as well (about ^{4 x}

10- 2)

^{but will be} kept ^{so far.}

Then,

Eiy

^{can be}

expressed

^from eq. (5) :

Tl, î5(T;)

^and

dT/d(I/T)i

^are directly obtained from the derivative curve

of i(1/T)

(Fig. 2c) ;

iL(T;)

^{has to}

be calculated by ^{a thermal}

expansion

formula from the 7(T) ^curve

extrapolated

^{at low} temperature

(iL

^{= 165 ps at 20 °C). There is no need to know}

,rlv(Ti)

and this is _very fortunate as it will be shown in a

moment.

Although

^{the true value of x does not} really

matter for the

E F

calculation, ^{it is} sometimes of interest to determine the temperature

dependence

^of

the

trapping

^{rate. It will be seen} further that x ⁼ 0.5,

as found by ^the

trapping

^model fitting

procedure

(Table II), ^{is the more} reasonable.

Thus, using eqs. (6) ^and (4) along ^{with the data of}

the present ^work (see ^section 2) ^{and the} entropy coefficient

SF Ik

^{= 1.8 in} aluminium obtained else- where [26], gives :

E F

^{= 0.70 + 0.03 eV}

,Mu°v

^{= 164}

ps -1

which are indeed reasonable values.

3.3 ADVANTAGES ^{OF THE «} INFLECTION POINT » METHOD COMPARED TO THE FITTING PROCEDURE. ^-

As eq. (6) giving

Eiv

^{in the} inflection point ^{method is}

deduced from a trapping ^model formula, ^{it could be}

thought

^{that the same} uncertainties could still influence the result. To show that it is not the _case, i(1/T)

behaviours have been simulated by computer ^calcu- lations and the influence of the various factors has been

analysed.

^{The main} conclusion is that the

inflection

point keeps ^on

giving

^{the same}

Efv

^value

(within

experimental

accuracy) ^even when drastic

changes ^{are observed in the}

i( 1 / T)

^curve.

3.3.1 Specific trapping ^rate influence. ^- Using

eqs. (3) ^and (4), ^sets

of 7(T)

^{values can} be calculated with arbitrary though reasonable parameters

(Efv

^{= 0.70}

eV, TO

^{= 170 ps,}

T1v

^{= 260}

ps)

^and

different temperature

dependence

^{of the}

specific trapping

^rate [x ^{= -} 0.5, 0, ^{0.5 and 1 in a}

J1.1v(T) = MIVO T x law .

^Then,

^T-,,(I/T)

^{curves are}

Mlv(T ) iv T 0 _vo/

^law

J

^Then

^(I/T)

^{curvcs are}

drawn and

compared

^{to each other} (see

Fig.

3).

Fig. ^{3. -} Computer simulation for different specific trapping ^rate

functions _{Jl1V =} u’v(TITO)’ : ^{: (a) x = - 0.5 ; (b) x = 0 ;} (c) x=0.5;(d) x= 1.

The main features are the

following :

e all the calculated curves are

quite

^similar except in the

high

temperature

region

e the recalculated value

E F (X)

^{obtained from the}

inflection

points

^{of all the}

ix( 1 / T)

^{curves and with}

eq. (6) ^{are all the same} within reasonable _accuracy range, ^as evidenced in table III

Table III.

e in addition x ⁼ 0.5 seems to be the best value to fit the experimental ^{data at}

high

temperature ;

Tx> 0.5(I/T) slopes

^are

slightly

^{too low}

and Tx 0.5(I/T)

slopes ^are

slightly

^too large ^at

high

temperature.

3.3.2 Influence

of

^other

defects.

^{- The simulation}

will be limited here to the influence of dislocations, that will be considered as equivalent ^{to an extra}

concentration

Cd

^of vacancies, kept ^{constant with}

changing

temperature. ^The

TD(1/T)

^{curves have to be}

calculated from _eq. (3) ^with

C,v(T)

substituted by

Clv(T)

⁺

Cd. Again,

^all calculated curves are very similar within realistic values of

Cd ( 104

^{to 106 cm - 2}

in well annealed aluminium) and recalculated

E’(Cd)

values by the inflection point ^{method are all the same} (Table IV). Incidentally, ^{the rather}

unexpected

large

values of

7,,.P(I/T)

^{below 280 OC appear as not due to}

dislocations (within reasonable concentrations) ^and

cannot so far be interpreted

by

^{a coherent}

trapping

model (Fig. 2a).

Table IV. ^- (same units as in table III).

3.3.3 Influence of the thermal expansion. ^{- In}

eq. (3),

Ta(T)

^can be calculated with the parameter

set as given ^{in section} 3.3.1, with rlv and _iL either

kept

^{constant or} being temperature

dependent

The

-=taCT),

^{for a} ranging ^{from 0 to the thermal} expan- sion coefficient in aluminium (a ^{= 8.4 x 10- 5}

K-1),

are quite ^{similar at low} temperature, ^but

diverge drastically

^at

high

temperature. ^But

again,

^{the recal-}

culated values of

Eiv(rx)

given by ^the inflection

point

method (eq. 6) ^{are not} really

changed.

^{Table V} presents the main features of the

rL(T) and rlv(T)

influences.

Table V.

3.3.4 Influence of ^the

detrapping

occurrence. -

Going

^{back now to the full} eq. (2) ^{we will now simu-}

late the influence of

positron detrapping

^before

annihilation. In this calculation,

rL and

’t 1 v will be

kept

^{constant in a first} stage. ^{The data} presented ⁱⁿ

table VI show that, opposite ^to the influence of thermal

44

expansion,

detrapping

results in

lowering

^the high temperature ^{values of}

t"b(T).

^Again, the recalculated values of

Eiv(h)

^{are not} really ^af’ected by

changes

ⁱⁿ

the binding energy of the vacancy-positron pair.

Just for the sake of it, ^an attempt ^{has been made to} compensate the thermal expansion ^influence by ^allow- ing detrapping ^{to occur so that}

1/2(ia(T)

⁺

:t"b(T»)

would be equal ^{to the}

experimental

^data

Texp(T)’

This resulted in a surprisingly ^{low value of}

f.b=0.67

eV, compared with the theoretical estimate of Hodges [28].

This is

pictured

ⁱⁿ

figure

^4.

Fig. ^{4. -} Influence of thermal expansion ^and detrapping ^occurrence (a) computer simulation of the thermal expansion influence ; (b) computer simulation of the detrapping influence ; (c) : experimental data, full line : computer simulation of a compensation

between thermal expansion ^and detrapping.

Table VI.

4. Discussion and conclusion. ^- This _paper has

reported

^new

experimental

and theoretical approaches

to positron-lifetime

experiments

^{for the} measurement

of the _vacancy formation _{energy in} metals.

It has been shown that

diffused

sources, with the

positron active material as impurities in the investi-

gated metal, ^are very suitable for high temperature work, ^{and that} they ^reduce quite

obviously

^the long

lived source and surface components ^{in lifetime} spectra and permit ^{direct thermal or} mechanical treatment of the specimen.

A direct analysis ^{of the lifetime data} by ^a trapping

model formula has been shown to be quite ^hazardous

without a perfect

knowledge of many physical

^{factors :}

e temperature

dependence

^{of the} specific trapping

rate,

e

binding

energy of the

vacancy-positron

pair ^which might ^{be less tied to each} other than previously

expected,

. presence of other defects,

. and last but not least, ^{the true} temperature

dependence

^{of the}

positron-lifetime

^{in the} perfect

lattice and at vacancy trap. The lattice thermal

expansion approximation

that has been commonly

used until now

might

^{be a} very crude _one,

especially

because of a

possible phonon-assisted trapping

^of

positrons

[17] ^{before the} occurrence of a vacancy.

This

point

^is

supported

by ^the observation of a syste- matic difference in the lifetime obtained in the tran-

sition region ( T ³⁰⁰ OC) ^when measurements carried out at

equilibrium

temperature ^are

compared

^{to data}

obtained in

cooled-samples

containing quenched-in

vacancies [29].

Although derived from the

trapping

model, ^the inflection point method which allows one to calculate

Efy

^{from the} coordinates of the inflection

point

^{in the} T( 1 /T) curve, does not suffer the same uncertainties and

gives

always ^{the same value}

(expected

^{to be}

accurate !) ^of the vacancy formation energy. In fact,

this is not very

surprising.

^{First of all, this} method does not need to know

’t"ly(T)

^{which, on the} contrary, interfers in the

trapping

^model formula and is

impos-

sible to determine from

experimental

data because of the influence of both thermal expansion ^and

detrapping

processes.

Secondly,

^the inflection point

of the :r(I/T) ^{curve is} equally far from the

high

^and

low temperature

regions

and, ^{as a} consequence, is

expected

^to be insensitive to high temperature detrapp- ing ^{and low} temperature

phonon-assisted trapping.

Finally,

^this

inflection

point method has one

impor-

tant advantage

because T;

^{occurs at}

approximately

0.7

T. ( Tm

⁼

melting temperature).

^{In the case of}

refractories or metals with

high

vapour pressure ⁱⁿ the solid state, ^{it will} be

possible

^{to evaluate}

E F

without measurements near the melting

point.

References

[1] MACKENZIE, ^I. K., KHOO, ^T. L., McDoNALD, ^{A. B. and} McKEE, ^{B. T.} A., Phys. Rev. Lett. 19 (1967) ^946.

[2] GOLAND, ^A. N., ^B.N.L. Report (1970), ^{n° 16517.}

[3] SEEGER, A., ^J. Phys. ^{F : Metal} Phys. ³ (1973) ^248.

[4] WEST, ^R. N., ^Adv. Phys. ²² (1973) ^263.

[5] JANOT, Ch., ^J. Phys. ¹¹ (1976) ^89.

[6] DOYAMA, M., ^In Progress ^{in the} study of point defects.

Doyama M. and Yoshida S. Eds. (University ^of Tokyo Press) 1977, p. 3.

[7] HALL, ^T. M., Phys. ^{Rev. B 10} (1974) ^3062.

[8] WEISBERG, ^{H. and} BERKO, S., Phys. ^{Rev. 154} (1967) ^249.

[9] CAMPBELL, J. L., JACKMAN, T. E., MACKENZIE, I. K., SCHULTE, C. W. and WHITE, C. G., ^{Nucl. Instrum. Methods 116} (1974) 369.

[10] ^{CAMPBELL, J.} L., SCHULTE, C. W. and DIETERTY, ^D. K., Appl. Phys. ⁶ (1975) ^327.

[11] HERLACH, ^{D. and} MAIER, K., Appl. Phys. ¹¹ (1976) ^197.

[12] MAIER, K., METZ, H., HERLACH, D., SCHAEFER, ^H. E. and SEEGER, A., Phys. ^Rev. Lett. 39 (1977) ^484.

[13] HERLACH, D., STOLL, H., TROST, W., METZ, H., ^JACK-

MAN, T. E., MAIER, K., SCHAEFER, ^{H. E. and} SEEGER, A., Appl. Phys. 12 (1977) ^59.

[14] HALL, T. M., GOLAND, ^A. N., SNEAD, ^{C. L.} Jr., Phys. ^{Rev. B}

10 (1974) ^3062.

[15] CRISP, ^{V. H.} C., LOCK, ^{D. G. and} WEST, ^R. N., ^J. Phys. ^{F :}

Metal Phys. ⁴ (1974) ^830.

[16] FRANK, ^{W. and} SEEGER, A., Appl. Phys. ³ (1974) ^61.

[17] SEEGER, A., Appl. Phys. ⁷ (1975) ^85.

[18] MCKEE, ^{B. T.} A., TRIFTSHAUSER, W. and STEWART, ^A. T., Phys. ^{Rev. Lett. 28} (1972) ^358.

[19] CONNORS, ^D. C., CRISP, V. H. C. and WEST, ^R. N., ^J. Phys.

F : Metal Physics ¹ (1971) ^355.

[20] KIM, S. M. and BUYERS, W. J. L., Phys. ^{Lett. 49A} (1974) ^181.

[21] POPOVIC, Z., CARBOTTE, ^{J. P. and} PIERCY, ^G. R., ^J. Phys. ^{F :}

Metal Physics ⁴ (1974) ^351.

[22] MCGERVEY, ^{J. D. and} TRIFTSHAUSER, W., Appl. Phys. ⁶ (1975) 177.

[23] KURIBAYASHI, K., TANIGAWA, S., NANAO, ^{S. and} DOYAMA, M., Solid State Commun. 12 (1973) ^1179.

[24] MACKENZIE, I. K. and LICHTENBERGER, P. C., Appl. Phys. ⁹ (1976) 331.

[25] KIRKEGAARD, P., ELDRUP, M., Comput. Phys. ^{Commun. 7} (1974) 401.

[26] BIANCHI, G., MALLEJAC, D., JANOT, Ch., CHAMPIER, G., C. R. Hebd. Séan. Acad. Sci. 263 (1966) ^1404.

[27] BERGERSEN, ^{B. and} SCOTT, M. J., Solid State Commun. 7

(1969) ^1203.

[28] HoDGES, ^C. H., Phys. Rev. Lett. 25 (1970) ^284.

[29] COTTERILL, ^R. M., PETERSEN, K., TRUMPY, G. and TRAFF, J.,

J. Phys. ^{F : Metal} Physics ² (1972) ^459.
