On Some Advanced Nickel-Based
Superalloys for Disk Applications
D. Locq, P. Caron (Onera)
E-mail: [email protected]
R
ecent work performed at Onera on nickel-based superalloys for disk
applications is presented. In the first section, disk characteristics and
metallurgical routes used to produce these specific aero-engine components
are reviewed. Then, two alloy development programs carried out to satisfy
the requirements of the industrial partners are detailed. Finally, the results
of studies aiming at identifying the complex relationships linking the
micros-tructure and the creep behaviour of disk superalloys are described: influence
of the strengthening γ’ precipitation on the deformation micromechanisms,
and effect of the microstructure on grain boundary sliding.
Introduction
Nickel-based superalloys are mainly used for static or rotating com-ponents of the hottest sections of aero engines. These rotating parts are the blades and the disks in the high-pressure compressor (HPC) and turbine (HPT) stages. As far as disks are concerned, nickel-based superalloys are selected for the last HPC (hot) stages while titanium-based alloys are used for the first (colder) compressor stages due to their lower density. In contrast, nickel-based superalloys are syste-matically used for the high- and low-pressure turbine (HPT or LPT) disks because of the thermal and mechanical requirements (figure 1).
Blade loss can be contained within the engine casing, while the catas-trophic failure of a turbine disk could cause puncture of the engine casing by its largest fragments [1]. This event represents a potential fatal hazard to the aircraft and its occupants. Therefore, it is essential to have the best understanding of the current relationships between the alloy chemistry, the production processes, the thermomechanical treatments, the heat treatments, the microstructure, the mechanical properties and finally the service behavior of the disk.
Figure 1 - Half cross section of the PW4000 engine (in red, nickel-based superalloy components and, in circles, nickel-based superalloy disks).
Al Aluminium Allay (c) Cast
Cer Ceramic CM Composite Material Co Cobalt Base Alloy NI Nickel Base Alloy
S Steel-Corrosion Resistant Alloy TI Titanium Base Alloy
Intermediate Case S(c), CM Fan CM Al TI Al S S TI NI NI NI(c) S/(c)
Issue 3 - November 2011 - On Some Advanced Nickel-Based Superalloys for Disk Applications
2 The operating conditions experienced by a typical HPT disk are [2]:
•a temperature within the 200-300°C range in the bore and up to 650°C in the rim;
•a rotational speed higher than 10,000 revolutions per minute (the mechanical stresses generated in the bore region may reach 1000 MPa during take-off);
•an oxidizing/corrosive environment.
In consequence, turbine disk alloys require the following properties: •high yield and tensile strengths to prevent yield and bursting (yield strength > 1000 MPa and ultimate tensile strength > 1200-1300 MPa in the 400-650°C range); •ductility and fracture toughness to prevent dramatic fracture and improve defect tolerance; •high resistance to fatigue crack initiation and low fatigue crack growth rate (in oxidizing environment); •high creep resistance to avoid creep strain in the rim; •and finally, a density as low as possible.
Currently, this set of requirements is only met in the case of the nickel (or some nickel-iron)-based superalloys. The high mechanical resis-tance of the nickel-based superalloys is essentially due to the pre-sence of hardening precipitates in a matrix phase. The matrix phase denoted γ exhibits the face-centered cubic (FCC) structure of the nic-kel and can contain significant amounts of elements in solid solution such as cobalt, chromium, molybdenum, etc. The structural harde-ning is provided by precipitates of the coherent stable intermetallic compound denoted γ’ (cubic L12 structure – Ni3Al). The properties of γ’-strengthened alloys are mainly dependent on:
•volume fraction and size of the different populations of γ’ preci-pitates;
•and solid-solution strengthening of both γ and γ’ phases. Inconel 718 is the most widely used superalloy for the production of compressor and turbine disks. This «old» alloy (1959) is a nickel-iron superalloy (principally strengthened by precipitation of the γ’’ phase – Ni3Nb) and is produced by the conventional cast-and-wrought (C&W) route. For more severe applications, γ’-hardened nickel-based supe-ralloys are used. These supesupe-ralloys usually hold between 40 and 60 volume % of γ’ phase and are processed either by the C&W route or by the powder metallurgy (PM) route. The PM route allows pro-cessing of large dimension disks made of superalloys with higher γ‘ fraction and/or with higher content of refractory metals (Mo, W, Nb, Ta). By this specific processing route, chemical segregations in the disk are minimized and the more uniform deformability of the PM billet allows forging of disks made of highly strengthened superalloys. PM disks were first installed in turbines of military aero engines (Pratt & Whitney F100 engine in 1974). They are now also used in large com-mercial engines (René 88 alloy in General Electric CF6 and GE90-94B engines [3] and René 104 in Engine Alliance GP7200 engine [4]). At Onera, investigations on PM disk superalloys started in the late 1970’s. In the early 1980’s, the French manufacturer of aircraft en-gines Snecma (now Safran Snecma) launched the development pro-ject of the military engine M88 intended to power the Rafale fighter aircraft from Dassault. To meet the severe requirements for several disks of the M88 engine, Snecma wished to use a new PM superalloy. A program of alloy development was therefore conducted in coopera-tion with Snecma, Imphy S.A., École des Mines de Paris and Onera. This program led to patent application of the N18 superalloy and its use for the production of HPC and HPT disks of the M88 engine [5].
This paper presents two investigations performed at Onera on PM nickel-based superalloys for disk applications. The first one focuses on alloy design studies considering the industrial requirements. The second one is related to the relationship between the microstructure of the superalloy and its high-temperature creep behavior.
Alloy design
Increase of the operating temperature
The N18 alloy is the first French PM superalloy for aero engine ap-plications. This superalloy is designed to withstand high stresses at intermediate temperatures. The maximum temperature of the HPT disk rim of the M88 engine was predicted in the 600-650°C range with possibly short incursions at 700°C. From the late 1980’s, the Délégation Générale de l’Armement (DGA: the Defence Procurement Agency) proposed a further research direction for new disk superal-loys operating at temperature higher than 700°C (up to 750°C). For disk superalloys, the rise of 100°C in the maximum operating tempe-rature globally results in:
• an appreciable drop in mechanical resistances; • faster microstructural evolutions;
• stronger interactions with environment.
The chemistry and the standard microstructure of the N18 alloy are designed for applications up to 600-650°C. In this temperature range, fine-grain (5-15 µm) microstructure is globally favorable for high mechanical resistance and microstructural evolutions are rather slow. Initial studies on N18 rapidly showed that this alloy was not a suitable candidate for higher temperature applications. Firstly, this alloy is prone to precipitation of deleterious topologically close-packed (TCP) phases during long-term exposure above 650°C [6,7]. Secondly, the grain size is not easily adjustable in this alloy. Increasing the grain size is one way to improve some time-dependent mechanical properties at high temperature such as creep or crack propagation resistance. The grain growth in these superalloys requires a supersolvus heat treatment (i.e. above the γ’ solvus temperature of the alloy). The appli-cation of such heat treatments evidenced some problems for the N18 alloy:
• depending on isothermal forging conditions, the supersolvus heat treatment can lead to abnormal grain growth (growth of a few grains to very large sizes up to several millimeters) [8],
• at industrial cooling rates, quench cracking occurred on disk preforms. The propensity for quench cracking in superalloys is rela-ted to high γ’ volume fractions (higher than 45 % [9]) and N18 alloy is in the 50-55 vol % range which is a high value for disk alloys. To meet the DGA’s objective, a series of experimental superalloys was designed, processed and evaluated at Onera [10]. From the chemical composition of N18 alloy, modifications were made to design alloys free of TCP phases and nevertheless having equal or higher mecha-nical properties than those of N18. The common features of these experimental alloys and the N18 alloy are:
• Co content maintained close to 15 wt. %;
• Cr content close to 25 at. % in the γ matrix to retain a good environmental resistance at high temperature especially during crack propagation;
• minor elements contents (C, B, Zr and Hf) close to those of N18 alloy. The compositions of NR3 and NR6 alloys are compared with the N18 chemistry in table 1.
To avoid the precipitation of TCP phases, the molybdenum content is lowered to decrease a stability criterion Mdγ . This phase stability parameter is defined as follows:
1 ( ) n i i i Mdγ X Mdγ = =
∑
where Xiγ is the atomic fraction of the element i in the γ matrix and
(Md)i is the Md value for element i. The Md is the average energy level of d orbitals of alloying transition metals (in eV). These Md levels correlate with the electronegativity and with the metallic radius of each element. The Md values used for the calculation are those given by Morinaga in the New Phacomp method [11]. When the Mdγ value of one alloy becomes larger than a critical value, the matrix phase instability takes place and a second phase precipitates in the γ matrix. This critical value for TCP phase precipitation was determined to be 0.915 by previous experiments.
To counterbalance the loss of solid solution strengthening of the γ matrix resulting from lower Mo content, the Ti/Al (concentrations in at. %) ratio is increased to 0.8 (vs. 0.56 for N18 alloy). This Ti for Al partial substitution is carried out to increase the strength of the γ’ phase. For NR6 alloy, the γ’ volume fraction is lowered to the 40-45 % range (to avoid quench cracking) and the resul-ting decrease in mechanical strength is compensated both by Ti/ Al ratio increase and by W to Mo partial substitution (W/Mo ~ 1, concentrations in at. %). W partitions in both γ and γ’ phases while Mo is mainly present in the γ phase. So, in spite of the higher Md value for W, the addition of this element leads to a lower increase of the alloy Md than the same addition of Mo (in at. %). However, substantial W content has a detrimental effect on the alloy density Table 1 - Nominal compositions of disk superalloys developed at Onera (wt. %).
because of its very high atomic weight (almost twice as much as the one of Mo).
The chemistries of the NR3 and NR6 alloys were balanced by using an Onera program based on the method developed by Watanabe for calculation of the fraction of γ’ phase and the composition of the γ and the γ’ phases from the alloy chemistry [12].
After a laboratory-scale screening, NR3 and NR6 alloys were cha-racterized in comparison with N18 alloy. All alloys were processed by the industrial PM route:
• vacuum induction melting; • argon atomization; • hot extrusion; • isothermal forging;
• supersolvus solution treatment.
The final sequence of heat treatments leads to a medium grain size (GS) microstructure (20 < GS < 100 µm) and a bimodal distri-bution of γ’ precipitates: the secondary γ’ (or cooling γ’) with a mean size of a few hundreds of nanometers and the tertiary γ’ (or ageing γ’) with a mean size of a few tens of nanometers (figure 2). Tensile and creep-rupture tests showed that NR3 and NR6 alloys have mechanical properties close to or slightly higher than those of N18 alloy [10]. Samples of the three alloys were aged in the 700-850°C range for times up to 10,000 hours to confirm the stability of the γ matrix in relation to the TCP phase precipita-tion. Scanning electron microscopy (SEM) or transmission elec-tron microscopy (TEM) observations show that intragranular TCP
Alloy Ni Co Cr Mo W Al Ti Nb Hf C B Zr N18 Bal. 15.7 11.5 6.5 - 4.35 4.35 - 0.50 0.015 0.015 0.03 NR3 Bal. 14.7 12.3 3.5 - 3.80 5.50 - 0.30 0.020 0.010 0.05 NR6 Bal. 15.1 13.8 2.1 4.0 3.20 4.50 - 0.30 0.020 0.010 0.05 SMO43(N19) Bal. 12.2 13.3 4.6 3.0 2.90 3.60 1.5 0.25 0.015 0.010 0.05 SMO48 Bal. 14.9 12.3 3.6 4.0 3.20 4.40 0.8 0.30 0.030 0.010
-Figure 2 - Typical microstructure of a PM disk superalloy after a supersolvus heat treatment. On the left, grain structure and on the right, the secondary and tertiary γ’ precipitates within the grains (SEM images).
Issue 3 - November 2011 - On Some Advanced Nickel-Based Superalloys for Disk Applications
4 phase particles precipitate in the N18 after 1000 hours at 700°C.
No intragranular TCP phases are observed in NR3 or NR6 alloys even after long-term exposure at high temperature (10,000 hours at 750°C). These results confirm the expected stability of the NR3 and NR6 alloys. The detrimental effect of TCP phase precipitation on mechanical properties was also evidenced by impact tests on samples with or without severe ageing heat treatment (500 hours at 800°C). The micrographs presented in figure 3 show the TCP phase precipitation (light gray particles) within N18 alloy while such phenomenon does not occur within NR3 alloy. The signifi-cant drop of impact strength related to this unwanted precipitation is also clearly highlighted in figure 3.
This study led to a Snecma-Onera patent application [13]. Till today, the NR3 and NR6 alloys have not been industrialized by Snecma for disk applications but they were intensively used for long-duration creep studies at high temperatures where the ab-sence of TCP phase precipitation makes easier the analysis of creep deformation mechanisms, as detailed in the following.
Increase of service life
In the late 1990’s, a cooperative program (Snecma-Onera-Centre des Matériaux de l’École des Mines de Paris) was launched to develop a new PM superalloy grade with these main specifications [14]: •capability of significant grain size evolutions through thermome-chanical and heat treatments,
•metallurgical stability for long term exposures up to 750°C, •higher creep and fatigue resistance as compared to N18 alloy up to 700°C,
•increased strain hardening ability, •and a density lower than 8.35 g.cm-3.
To meet these requirements, the target γ’ fraction of the new N19 superalloy was in the 40-45 % range. This drop in γ’ amount in com-parison with the value of 55 % in alloy N18 is counterbalanced by both γ and γ’ strengthening increases. The γ matrix chemistry is optimized through a careful balance between the Cr, Mo and W elements. The goals are to:
•increase the solid solution hardening of the γ matrix;
•maintain oxidation and corrosion resistances by means of suffi-cient Cr addition;
•avoid or limit the precipitation of TCP phases; •and, limit the increase in alloy density.
A special attention is paid to Co content because of its effects on high temperature creep resistance and, above all, on the γ’ solvus tem-perature which generally decreases when the Co level increases. To strengthen the γ’ phase, the [Ti+Nb+Ta]/Al ratio (concentrations in at. %) is increased to about 0.85 (vs. 0.56 for alloy N18). Here again, excessive addition of Ti and/or Nb and/or Ta can have detrimental effects on the microstructure and the mechanical properties. A too high [Ti+Nb+Ta]/Al ratio can lead to the presence of undesirable acicular plates of intermetallic phases such as η-Ni3Ti, δ-Ni3(Nb,Ta). Although Nb has a higher strengthening effect than Ti, excessive Nb content is likely to be deleterious to crack propagation resistance and ductility [15]. Lastly, no particular study is dedicated to the effects of minor elements. For all the experimental alloys, carbon is kept within the 150-320 wt. ppm range and boron is in the 150-200 wt. ppm range, hafnium content is about 0.3 wt. % and zirconium, when added, is in the 600-630 wt. ppm range.
22 experimental alloys and the two reference alloys N18 and René 88 [9] were processed by laboratory PM route. Two out of the experimental alloys were selected for further studies on their mechanical and metallurgical features in comparison with N18 alloy [14]:
•higher tensile properties between room temperature and 700°C and 700°C creep resistance;
•lower γ’ fraction and solvus temperature and higher solution window (gap between the incipient melting temperature and the γ’ solvus temperature) which are key factors for improving thermal and thermomechanical treatment capabilities;
•higher γ matrix stability (no or little TCP phase precipitation); •high γ’ phase stability (no η or δ phase precipitation).
These two alloys (SMO43 and SMO48) were processed by the indus-trial PM route and were heat treated to obtain a medium grain size. The mechanical properties of these materials were compared with those of N18 alloy with its reference microstructure as used in the M88 engine, i.e. a fine-grain microstructure (5-15 µm). This compari-son allows it to be noted that, in spite of their coarser grain size, these new alloys exhibit tensile strengths and low cycle fatigue (LCF) beha-viors close to that of N18 alloy. Moreover, partly due to their coarser grain sizes, SMO alloys show a significantly higher creep resistance (figure 4). Lastly, some fatigue crack growth tests were performed at 550°C and 650°C. It emerges from these tests that SMO alloys present fatigue crack propagation behaviors close to that of N18 alloy. SMO43 was finally chosen for further assessments because of its Figure 3 - Effect of long-term ageing treatment (500 hours at 800°C) on microstructure and on impact strength at room temperature for three disk superalloys.
5µm N18 NR3 NR6
Alloy
N18 alloy after ageing NR3 alloy after ageing
5µm as-heat-treated +800°C/500h ageing Impact strength (10 -4 J.m -2) 50 45 40 35 30 25 20 15 10 5 0
slightly higher LCF resistance and its expected better process suitabi-lity thanks to its low γ’ solvus temperature [14]. Complementary stu-dies are in progress to optimize its mechanical properties (especially through thermomechanical and/or heat treatments).
YDOT/AL03-01_fig4.xls/0,2 % (aerospaceLab) 22/07/2011
100 1000 10000
1,E+01 1,E+02 1,E+03
SMO43 / 650 °C SMO48 / 650 °C
DMD0464-3002A / Moyenne
SMO43 / 750 °C SMO48 / 750 °C
Figure 4 - Time for 0.2 % creep strain of SMO alloys compared with results on N18 alloy.
Microstructure – creep behavior relationship
As for the United States HSCT (High-Speed Civil Transport) research program, the ATSF (Avion de Transport Supersonique Futur: Future Supersonic Transport Plane) program was launched in France in the mid-1990’s (200 seats/ 10,000 km range/ Mach 2). The ATSF should be equipped with a MTF (Mid-Tandem Fan) engine developed by Rolls-Royce and Snecma (with a turbine inlet temperature closed to 1650 K during cruise). For subsonic civil missions, the more intensive phases for the engine are the take-off and the landing. For supersonic civil appli-cations, engines are highly stressed during the whole cruise duration (several hours). This point means that microstructural modifications and creep phenomenon in turbine disks have to be taken into account. Long duration creep studies were mainly carried out on the NR3 and NR6 alloys for the reasons previously mentioned. These studies led to the achievement of numerous creep tests in the 650-850°C range and in a large stress range (150 to 1000 MPa depending of the tem-perature). For these creep tests, the minimum creep rate was in the range 10-7-10-11 s-1.
Figure 5 - Influence of the microstructure on creep behavior of NR3 alloy.
This work allows clarification of the typical influence of the grain size on the creep behavior. A small grain size superalloy has a higher mini-mum creep rate and experiences an earlier increase of the creep rate than a coarser grain size one (figure 5). These phenomena are even more significant when the creep temperature is high and/or the creep stress is low [16].
The effect of the tertiary γ’ precipitates and of their evolution on the long duration creep behavior at temperatures above 700°C was also examined. The size and fraction of these very fine particles (a few nanometers to a few tens of nanometers) have a significant influence on the deformation micro-mechanisms and therefore on the macroscopic behavior of the material [17, 18]. This study was carried out closely with the CEMES Toulouse (Centre d’Élabora-tion de Matériaux et d’Études Structurales) [19, 20, 21]. The TEM observations allow it to be established that the absence of tertiary γ’ precipitates leads to bypassing mechanism of the secondary γ’ precipitates by matrix dislocations (figure 6). On the other hand, the presence of these particles in the γ matrix channels induces different shearing mechanisms depending on the local distribution of the tertiary γ’ precipitates in front of the dislocations (figure 7). A new shearing configuration of γ’ precipitates has been observed and analyzed during this study (decorrelation of the movement of two partial dislocations in the narrowest matrix channels) [22]. The in-fluence of the tertiary γ’ precipitate distribution was studied in small grain size microstructure [23] as well as in coarser grain size one [20]: this effect decreases as the creep rate diminishes too (lower creep temperature and/or stress).
Figure 6 - Microstructure of over-aged NR3 alloy (without tertiary γ’ precipi-tates) and associated bypassing mechanism (TEM images).
SMO43/650°C SMO48/650°C Mean value N18/650°C SMO43/750°C SMO48/750°C 10 100 1000
Time for 0.2% strain (h)
Stress (MPa)
grain size: 5-10 µm
grain size: 30-50 µm
test stopped before failure
0 1000 2000 3000 4000 5000 Time (h) NR3 alloy 750°C/300 MPa Creep strain (%) 16 14 12 10 8 6 4 2 0 200 nm 200 nm 10000 1000 100
Issue 3 - November 2011 - On Some Advanced Nickel-Based Superalloys for Disk Applications
6 Figure 7 - Microstructure of standard NR3 alloy (with tertiary γ’ precipitates)
and associated shearing mechanisms (TEM images).
According to these results and those obtained by Dubiez-Le Goff [24] and Raujol [19], it was inferred that grain boundary sliding (GBS) contribution to the overall strain could not be neglected. To quantify the GBS strain during high-temperature creep tests, a specific micro-grid extensometry technique was developed [25]. Hafnia micromicro-grids (318 x 318 µm2 with a 5 µm pitch) were deposited on flat creep
specimens of the NR6 superalloy which were creep tested in the 700-850°C temperature range for a few hours to a few hundred hours. The creep tests were conducted under high vacuum (~10-4 Pa) to avoid
excessive oxidation of the superalloy. High resolution SEM images
of the grids were recorded before and after the creep tests. Specific image correlation tools were developed to calculate local strain and GBS. These deformation maps were superimposed on EBSD (Elec-tron Backscatter Diffraction) maps to merge the grain boundary para-meters with the deformation data [26, 27] (figure 8).
The development of these tools allowed study of the effect of the creep parameters (temperature, stress and deformation ratio) on the GBS contribution to the overall deformation of the superalloy. The ex-perimental results globally show that the GBS contribution increases as the temperature and/or the stress are lowered. In other words, the lower the creep rate, the higher the GBS contribution (Figure 9).
Figure 9 - Dependence of GBS contribution and mean amplitude on creep rate. The influence of the grain boundary parameters (crystallographic nature using the Coincidence Site Lattice (CSL) model [28], length, orientation with respect to the tensile axis) on the ability to undergo GBS was also assessed. For instance, this analysis brings out the fact that random grain boundaries are more prone to GBS than CSL grain boundaries (especially twin boundaries which are the most resistant to GBS). However, this trend tends to decrease as the creep tempera-ture increases (figure 10).
Creep tests at various temperatures (700-850°C) and stresses (350-700 MPa) were carried out on NR6 specimens and interrupted after 1 % creep strain. For each creep conditions, analyses of the defor-mation maps completed with TEM observations of the microstruc-ture and of the dislocation strucmicrostruc-tures allow linking microstructural changes to different deformation micro-mechanisms (as previously
10-9 10-8 10-7 10-6 10-5
Minimun Creep Rate (s-1)
0.50 0.45 0.40 0.35 0.30 0.25 0.20 0.15 0.10 0.05 0 GBS contribution 125 100 75 50 25 0 GBS mean amplitude (nm) 200 nm 500 nm
Figure 8 - Microgrid, deformation maps and EBSD map used to study the GBS contribution.
GB parameters CSL character, length angle to the tensile axis, ... HfO2
microgrid detail
EBSD map GBS map
Local stain εxx map
seen for NR3 alloy) and also linking these modifications to the GBS contribution. These results are summarized in figure 11.
Figure 10 - Influence of creep temperature at 350 MPa on the mean GBS amplitude of two classes of grain boundaries. (3 ≤ Σ ≤ 29 = CSL grain boundaries and Σ > 29 = random grain boundaries).
When the microstructure is stable (a bimodal distribution of γ’ preci-pitates is preserved (blue area in figure 11)), γ’ precipitate shearing mechanisms are mainly observed in the grains. The deformation is localized into slip bands and heterogeneously distributed within grains and between adjoining grains. On the other hand, when the precipita-tion microstructure rapidly changes (to a monomodal distribuprecipita-tion of γ’ precipitates) because of long exposure at high temperature (800-850°C (red area in figure 11)), a bypassing mechanism is observed and is more homogeneously distributed within grains and between adjoining grains.
For the NR6 superalloy, creep parameters can lead to microstructural changes that can affect deformation micro-mechanisms. The more heterogeneous deformation within grains and between adjoining grains, the higher the GBS contribution. In that case, the local stresses induced by deformation incompatibilities between neighboring grains and by dislocation pile-up at grain boundaries are assumed to assist the GBS phenomenon.
The aim of these studies is to contribute to the understanding of the deformation mechanisms controlling high-temperature creep of
poly-crystalline nickel-based superalloys. This better knowledge is expec-ted to provide solutions to increase disk superalloys resistance (to creep or other mechanical loadings) through grain engineering (opti-mization of γ’ precipitate distribution) and through grain boundary engineering (GBE) (improvement of CSL grain boundary distribution). Concerning the GBE, the challenge consists in finding deformation and thermal cycles compatible with the industrial processing of disk superalloys. Once this issue is solved, the mechanical properties in-volving the grain boundary environmental and mechanical resistance should be improved (in particular, creep and dwell crack growth resis-tances).
Conclusion
This article reports studies conducted at Onera in the field of nickel-based superalloys for disk applications. Two research topics are here presented. The first one deals with superalloy design and the second issue concerns the analysis of the microstructure/mechanical pro-perty relationships.
Alloy design studies were carried out in collaboration with industrial or research laboratory partners and were mainly based on mutual theoretical and experimental knowledge. The NR3 and NR6 PM supe-ralloys were developed with the aim to increase the high temperature capability of such alloys above that of the N18 alloy today used in the M88-2 engine of the Rafale fighter. More recently, the N19 PM alloy was designed to improve the LCF strength as compared to N18 in order to increase the disk life. A specific alloy design methodology has been developed to meet the industrial application requirements. In house laboratory-scale equipments allowed production of experimen-tal superalloy grades by the PM route. Microstructural studies and basic mechanical assessment were carried out on these materials to screen the most promising ones. The selected alloys were then processed by our industrial partners using the industrial PM route. Further studies were finally undertaken to optimize the microstructure (and so the mechanical behavior) of the materials by adjustment of the last processing step parameters (thermomechanical and/or heat treatments). At this stage, studies on the relationships between the process parameters, microstructure and mechanical behavior gives helpful information to reach the objectives more efficiently.
Figure 11 - Relationships between microstructure, straining micro-mechanisms and the GBS contribution ξ as a function of creep temperature and stress.
GBS contribution increases as creep temperature or stress decreases
Stress (MPa) Temperature (°C) 700 750 800 850 700 600 500 400 1µm 200 nm 400 nm 200 nm 200 nm 400 nm 400 nm 350MPa/800°C 350MPa/850°C 3 ≤ ∑ ≤ 29 ∑ > 29 200 150 100 50 0 Mean GBS (nm) 0.34 0.32 0.30 0.28 0.26 0.24 0.22 0.20 ξ
