Bayesian selection of graphical regulatory models

^✩

Silvia Liverani^a^,^∗,Jim Q. Smith^b

aDepartmentofMathematics,BrunelUniversityLondon,UK bDepartmentofStatistics,UniversityofWarwick,Coventry,UK

a r t i c l e i n f o a b s t r a c t

Articlehistory:

Received15October2015

Receivedinrevisedform5May2016 Accepted31May2016

Availableonline15June2016

Keywords:

Clustering Bayesianinference Causality

Time-coursemicroarrayexperiments

We define a new class of coloured graphical models, called regulatory graphs. These graphs have their own distinctive formal semantics and can directly represent typical qualitativehypothesesaboutregulatoryprocesseslikethosedescribedbyvariousbiological mechanisms.Theyadmitanembellishmentintoclassesofprobabilisticstatisticalmodels and sostandard Bayesian methodsofmodel selection canbeused tochoose promising candidate explanations of regulation. Regulation is modelled by the existence of a deterministicrelationshipbetweenthelongitudinalseriesofobservationslabelled bythe receivingvertexandthedonatingone.Thisclasscontainslongitudinalclustermodelsasa degenerategraph.Edgecoloursdirectlydistinguishimportant featuresofthemechanism likeinhibitionandexcitationandgraphs areoftencyclic.Withappropriatedistributional assumptions,becausetheregulatory relationshipsmapontoeachotherthroughagroup structure,it ispossible todefineaconditionalconjugate analysis.Thismeansthateven whenthe model spaceishuge itisneverthelessfeasible, usingaBayesian MAPsearch, to a discover regulatory network with a high Bayes Factor score. We also show that, liketheclassofBayesianNetworks,regulatorygraphsalsoadmitaformalbutdistinctive causalalgebra.Thetopologyofthegraphthenrepresentscollectionsofhypothesesabout thepredicted effectofcontrollingthe processbytearingoutmessagepassers orforcing themtotransmit certainsignals. We illustrateourmethodsonamicroarrayexperiment measuring the expression of thousands of genes as a longitudinal series where the scientificinterestliesinthecircadianregulationoftheseplants.
