A. C. Stark effect on the 4713 A line emitted by a helium glow discharge
in the field of a multimode T.E.A. CO2 laser (*)
B. Dubreuil, P. Pignolet, A. Catherinot and P. Davy
Groupe de Recherches sur l’Energétique des Milieux Ionisés (**), U.E.R. de Sciences Fondamentales et Appliquées,
Université d’Orléans, 45046 Orléans Cedex, France
(Reçu le 4 novembre 1981, révisé le 1er février 1982, accepté le 10 fevrier 1982)
Résumé.
2014Nous avons étudié le déplacement Stark dynamique de la transition radiative 43S1 ~ 2 3P0,1,2
(03BB
=4 713 Å) de l’hélium dû à l’interaction non résonnante des états 4 3S et 4 3P avec le rayonnement d’un laser à CO2 multimode.
Cette étude réalisée en fonction de l’intensité laser dans le domaine IL 35 MW/cm2 montre que pour
IL > 2 MW/cm2 le déplacement Stark dynamique de l’énergie du niveau 4 3S ne suit plus la dépendance linéaire
en IL donnée par la théorie des perturbations au second ordre. Un modèle à trois niveaux tenant compte de l’inter- action à tous les ordres permet de rendre compte globalement des résultats expérimentaux. Cependant, pour
IL > 1 MW/cm2, nous obtenons un élargissement important de la raie 4 713 Å accompagnant le déplacement
Stark dynamique. Cet élargissement croit avec IL et conduit à la formation d’un pseudo-continuum s’étendant
sur 50 Å pour IL
=33 MW/cm2.
Nous interprétons cet effet comme étant dû aux fluctuations d’amplitude et de phase des modes du champ laser pendant l’interaction. L’enregistrement de la raie 4 713 Å nécessitant un très grand nombre de tirs laser, le profil expérimental reflète dans ces conditions la distribution statistique de l’amplitude des modes du champ laser.
Abstract
2014In a helium glow discharge, the A. C. Stark shift of the 4 3S1 ~ 2 3P0,1,2 transition (03BB ~ 4 713 Å)
induced by nonresonant interaction of the 4 3S and 4 3P levels with a multimode CO2 laser field is measured as a function of laser intensity in the range IL 35 MW/cm2. Departure from the linear intensity dependence given by second order perturbation theory is observed for IL > 2 MW/cm2. A three-level atom model taking into account
the interaction with the laser field in a non perturbative way agrees with the experiment. Strong broadening is
also detected for IL > 1 MW/cm2. This broadening grows with IL until a quasi-continuum spreading over 50 Å
is observed for IL
=33 MW/cm2.
This broadening results from amplitude and phase fluctuations of the laser field modes during interaction. For
IL
=33 MW/cm2 the recorded 4 713 Å spectral line shape reflects the statistical distribution of the mode ampli-
tudes.
Classification
Physics Abstracts
32.70J
-32.90
1. Introduction.
-Nonresonant irradiation of an
atomic system by a laser field leads to a shift of the
quasistationary energy values usually referred as
nonresonant A.C. Stark effect or light-shift [1, 2].
Standard second order perturbation theory gives
the following formula for the energy shift of a state
I n> :
(*) Work partly supported by D.R.E.T. under contract no 79/151.
(**) Equipe de Recherche Associ6e au C.N.R.S.
In equation (1), all the quantities are in atomic
units except for IL, the laser intensity, which is expressed in MW/cm2. En, En, are respectively the
energy of the n ) and n’ > states, hWL is the laser photon energy and ( n’ E. r I n > is the electric dipole
matrix element with s, the polarization vector of the
laser field.
According to the definition of light-shift [1, 2], equation (1) is valid only for laser intensities such that
Calculation of equation (1) for the n
=2,..., 7 states
of helium was performed in reference [3] for the CO2
laser and the neodymium laser wavelengths.
Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphys:01982004306087500
876
Particularly the 4 3S and 4 3P states were shown
to be shifted as much as AE,3s
=1.95 cm-1 and AE43p (averaged over the magnetic quantum num-
bers) = -0.64cm’’ for 1 MW/cm2 of the CO2
laser field (1iWL
=944cm-’) due to the relatively
small detuning (64 3S,43p= 25 cm-1) from the allowed 4 3S --+4 3 P transition (Fig. 1). Experimentally the
shift of the 4 713 A line starting from the 4 3 S state
was investigated in reference [3] in the laser intensity
range IL 50 kW/cm2 and was found in quantitative agreement with the value deduced from equation (1).
Fig. 1.
-Partial energy diagram of the 4 3S-43P-2 3p
states of helium.
Extrapolation of these results to higher CO2 laser
intensities indicates that, for IL > 10 MW/cm2, ð.E43S- > 20 em - 1 so that relation (2) is not fulfilled
and equation (1) is no longer valid.
In this case, the A.C. Stark effect on the 4 713 A
fluorescence line (4 Si - 2 3Po,1,2 transition) can
be described in the frame of a three-level model
including the 4 3 S, 4 3 P laser perturbed states and
the 2 3P detection level. This problem was investi- gated theoretically using the density matrix forma- lism [4, 5]. The equations of motion for the off-diagonal
elements in the rotating wave approximation are given by :
In (3) the subscripts 1, 2, 3 stand respectively for
the states 4 ’P, 4 3S, 2 3p of helium,
is the Rabi frequency in the laser field
where E is the polarization vector and OL(t) a complex
function taking into account amplitude and phase
fluctuation. Furthermore, T, and 72 are the damping
constants of levels 1 and 2 and W12
=(El - £2)/n.
The spectrum of all transitions terminating in level 3
is connected to the Fourier transform of the dipole
moment operator
where W23 = (E2 - £3)/1i and d23 is the dipole
moment of the allowed 2 -+ 3 transition (the transition
1 - 3 is forbidden).
Resolution of equation (3) in the case of a well-
stabilized monomode laser field (ØL
=0) indicated [4, 5] that the spectrum consists of a doublet centred at W23 + Am/2 (Am
=WL - W12) and separated by
-
the one-photon component (emission process)
centred at
-
the two-photon component (two photon process)
centred at
Respective intensities of these two lines are.given by
and
In the low laser intensity regime : (OR, 7 1, 7 2 I Aw 1,
the shift of the one-photon component bw/2 reduces to
the quadratic Stark shift of the two-level system 1, 2 (eq. 1) and the two-photon component intensity is negligibly small. In the high field intensity regime a)R >> I ð.w I, T 1, Y 2 ðw /2 WR, the shift of the doublet becomes linear in Eo and we obtain the well-known
optical Autler-Townes effect [5, 6, 7] in a three-level
system.
In the more realistic case of multimode lasers under-
going amplitude, phase and frequency fluctuations such as free-running high energy pulsed lasers, the complex phase OL(t) must be taken into account in
equation (3).
Several papers have dealt with this theoretical
problem in the case of phase fluctuations in resonance
fluorescence [8], phase and amplitude fluctuations in
multiphoton ionization processes [9, 10] (see refe-
rences [11, 12, 13] for experimental studies), in double
resonance and resonance fluorescence [4, 14, 15], and
in two-photon transitions [16].
In most of these papers, the multimode laser with a
large number of nearly independent modes fluctuating
from shot to shot is described by a non-monochro- matic chaotic field [9, 10, 12, 14, 15, 16]. In this model, E(t) is a stochastic function of time obeying Markov
process, so that equations (3) are stochastic differen- tial equations.
The numerical results for the A.C. Stark effect in double resonance and fluorescence resonance [14, 15]
indicate that the chaotic field tends to broaden the shifted fluorescence lines. This broadening can be
understood in terms of the amplitude fluctuations of the laser field inducing fluctuations in DR and in the Stark shift bco/2. At high intensities when the two levels 1 and 2 are completely driven by the laser field,
the amplitude fluctuations tend to suppress the
« natural » line structure and determine the spectrum of the fluorescence line. The observed spectral line shape reflects the amplitude distribution function of the laser modes. In this regime, the characteristic time of interaction ’rR - 2 n/(OR is much shorter than the coherence time of the laser field and the atomic system is very sensitive to the fast fluctuations of the field,
that is, to the instantaneous value of the field amplitude
and not to its mean value as in the low intensity case.
The main purpose of this paper is to present an
experimental study of these effects on the 4713 A (4 Si - 23PO,I,2) line (one-photon component) in
the field of a multimode T.E.A. CO2 laser for time
averaged intensities IL up to 35 MW/cm2. In this
« intermediate » intensity range (transition from qua- dratic to linear A.C. Stark shift) [17] intensity of the two-photon line is smaller by more than one order of magnitude than the one-photon line and was not
detected.
Observation of this two-photon line was performed
in a helium plasma by D. Prosnitz et al. [18] with CO2
laser flux in the range 100-500 MW/CM2.
2. Experiment
-The experimental set-up was des- cribed in a paper dealing with A.C. Stark effect in
hydrogen [19]. Let us just recall that the partially polarized beam of a multimode T.E.A. CO2 laser operating at 10 Hz and producing 1 J distributed in a
main peak of 150 ns F.W.H.M. and in a 3 JlS tail at WL = 944 cm - 1 (P.20 line) is slightly focused along
the axis of a helium 20 mm length capillary glow
discharge. The fluorescence light is analysed with and
without laser irradiation by a 1.15 m grating mono-
chromator connected to a photomultiplier. The syn- chronization of the detection system with the laser
pulse is monitored by a clock which switches on the
discharge at 20 Hz and triggers the laser at 10 Hz.
A two channel (A and B) gated integrator synchronized by this clock analyses the photomultiplier signal. Gate A, 100 ns wide, is positioned on the laser pulse, the discharge being on; alternately, gate B is opened only
when the discharge is on and laser off. Output of gate A
gives the laser-perturbed signal whereas gate B gives
the unperturbed (reference) signal. Perturbed and reference line profiles are displayed simultaneously
on a two channel strip chart recorder by slowly rotating the grating of the spectrometer (speed
0.08 A/min).
In the present experiment, the spectral resolution is about 0.05 A in the vicinity of the 4 713 A line. Each point on the profile corresponds to a summation over
100 laser shots, that is an accumulation time of 10 s
and a scanned spectral range of 0.013 A.
Focusing of the laser beam in the discharge is per- formed so that the whole volume inside the capillary
tube is irradiated. Consequently, the available time-
averaged laser intensity IL (MW/cm2) depends on the capillary radius. According to the desired laser inten-
,
sity range, a 4 mm diameter capillary tube for X 15 MW/cm2 and a 2.5 mm diameter one for
IL 35 MW/CM2 are used.
Measurement of the pulse energy is performed at
the output of the discharge tube taking into account
transmission of the KBr windows, whereas temporal
evolution and adjustment with respect to gate A are
continuously controlled by a 1 ns time resolution photondrag detector connected to a 7844 dual beam Tektronix oscilloscope. This permits accurate deter-
mination of IL and E(t) the normalized temporal
distribution function of the laser pulse. However, the radiation of the multimode T.E.A. C02 laser
contains about 30 longitudinal modes in the 3 GHz
spectral bandwidth, corresponding to a typical cohe-
rence time of ;:t 330 ps. Measurement of the time
development of these modes cannot be performed and
we observe only interaction (beating) between these modes leading to a slight modulation of the time-
envelope function C(t). The measured quantity IL
represents the averaged intensity
where Em is the complex amplitude of the mth mode of the field (IL corresponds to the r.m.s. value of the field amplitude Eo = JIL) and differs from the actual instantaneous intensity IL(t) o probed » by
atoms. IL(t) is given by and can
be connected to the measured parameters IL and E(t)
in the form [11] : IL(t)
=7L t(t) m(t) where m(t) is a
nearly periodic modulating function (period - 10 ns)
878
taking into account the mode interaction. IL and E(t)
are quasi-reproducible within 5 % from shot to shot,
but as the mode distribution fluctuates in phase and amplitude, m(t) is a quasi-stochastic function which cannot be easily characterized due to the 1 ns detector risetime.
_
Change in IL values cannot be achieved by varying
the voltage of the laser discharge without large
uncontrolled alterations in the discharge and in the laser pulse. On the other hand, the use of calibrated neutral filters at 10.6 Jlm with incident energy of 1 J is rather difficult so that we make use of the possibi- lity to set the gate A at different times along the
whole laser pulse shape E(t). Defining the mean laser intensity IL averaged over the time duration of the observation gate :
where
is the gate function, this experimental procedure permits quasi-continuous tuning of IL when the gate A
is positioned along the 3 ps tail (variation of C(t) 5 % during the 100 ns of the gate g(tl, t)), whereas higher IL values are obtained when gate A is positioned on the
main peak (with a variation of E(t) 25 %). With this operating mode, all experiments for a given capillary
tube are performed in the same laser irradiation condi-
tions. Particularly, the total laser energy passing through the discharge remains constant.
3. Results and interpretation.
-Figures 2 and 3
show the experimental recordings of the 4 713 A line
Fig. 2.
-Experimental recordings of the laser perturbed
and unperturbed 4 713 A line for It
=0.1, 0.3, l.1 MW jcm2.
Fig. 3.
-Same as figure 2 for IL
=1.9, 2.8, 6.2 MW/cm2.
obtained for increasing values of IL. As expected [3], the
shift of the 4 ’S, -+ 2 3P0,1,2 transition towards the blue wavelengths increases with IL, but a strong
broadening is also observed for IL > 1 MW/cm2.
As discussed in part 1, this broadening results from fluctuations of the phase and amplitude of the laser modes, inducing fluctuations in the A.C. Stark shift
bw/2. Due to this asymmetric broadening, two line
shifts can be defined : the shift AA’ of the 4 713 A line peak value and the shift ðÀ of the line gravity centre.
These two measured shifts are reported in figure 4 as a
function of 79L. Error bars on 79L correspond only to the
measured extreme variations of E(t) g(tl, t) during
the 100 ns of a measurement and do not result from
noisy signal.
Fig. 4.
-Plots of the 4 713 A line A.C. Stark shifts LBÀP, AA as a function of IL : M experiment with the 4 mm
inner diameter discharge tube; CJ experiment with the
2.5 mm inner diameter discharge tube, and the theoretical
curves corresponding to second order perturbation theory
and to the non perturbative three-level atom model.
The curve AA
=f(I[) shows a deviation from
linearity for IL > 2 MW/cm2, (bw/2 Am > 0.2) and
tends to the square-root limit of the optical Autler-
Townes effect at higher intensities. Drawn with these data are also theoretical curves deduced from equa- tion (1) and equations (4-5) taking into account coupling of the 4 3 S (M
=0) and 4 3p (M
=± 1) magnetic sublevels by the laser field propagating along
the quantization axis z - with polarization vector
e
=(x + y)/, ,,,/2 [3]. For IL9 2 MW/cm2 the fit by equation (1) is in broad agreement with experiment so
that second order perturbation theory can be used in
this intensity range. Fit of the data by equation (4) (non perturbative three-level atom) is also rather good
in the whole explored intensity range provided the
laser field amplitude Eo is taken as Eo
=To = JIL.
On the contrary, the shifts of the peak value AA’ are
found lower in a ratio - 1.2-1.3 than the mean values
A/L for Ig > 2 MW/cm2, and cannot be fitted by equation (4) using the mean laser intensity IL. This
effect is indeed connected to amplitude fluctuations of the laser modes and the relevant difficulty of measur- ing the actual laser intensity « seen » by atoms. Theo-
retical investigations of the A.C. Stark effect induced
by monochromatic chaotic field [14, 15] discussed in part 1 indicate that the Stark shift AA’ caused by a strong chaotic field (phase and amplitude fluctuations)
is less than that caused by a phase-fluctuating field
with the same average intensity IL. For higher values
of IL, AA’ tends to the limit AA/,y2 where AA is the
mean Stark shift. This limit corresponds to the ratio
between the r.m.s. field amplitude value and the most
probable value. The measured ratio AAP A/L/1.25
for IL > 2 MW/cm2 agrees with this theoretical result.
Such an effect was also observed in resonant multi-
photon processes [20].
_Recordings of the 4 713 A line for 79L > 6 MW/cm2 (Fig. 2) show that the line structure tends to disappear
in a large pseudo continuum. In this regime (the shift
becomes nearly proportional to the amplitude of the
laser field) iR 48 ps is much shorter than the cohe-
rence time of the laser field so that the atoms follow the time development of the mode structure. The
« instantaneous» Stark shift becomes very sensitive to fluctuations of the mode amplitudes and phases.
Experiments were performed in this direction up to
h
=33 MW/cm2. As shown in figure 5, the perturbed
4 713 A line is now a broad continuum lying on the
blue side of the unperturbed line and spreading over
-
