MAGNETIZATION, ELECTRICAL RESISTIVITY AND THE NON-OCCURENCE OF SUPERCONDUCTIVITY IN NiH

(1)

HAL Id: jpa-00217610

https://hal.archives-ouvertes.fr/jpa-00217610

Submitted on 1 Jan 1978

HAL is a multi-disciplinary open access

archive for the deposit and dissemination of

sci-entific research documents, whether they are

pub-lished or not. The documents may come from

teaching and research institutions in France or

abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est

destinée au dépôt et à la diffusion de documents

scientifiques de niveau recherche, publiés ou non,

émanant des établissements d’enseignement et de

recherche français ou étrangers, des laboratoires

publics ou privés.

MAGNETIZATION, ELECTRICAL RESISTIVITY

AND THE NON-OCCURENCE OF

SUPERCONDUCTIVITY IN NiH

D. Mclachlan, I. Papadopoulos, T. Doyle

To cite this version:

(2)

JOURNAL DE PHYSIQUE Colloque C6, supplément au n" 8, Tome 39, août 1978, page C6-430

MAGNETIZATION/ ELECTRICAL RESISTIVITY AND THE NON-OCCURENCE OF SUPERCONDUCTIVITY IN NiH

D.S. McLachlan, I . Papadopoulos and T.B. Doyle.

University of the Wittiatersrand, Johannesburg, South Africa.

Résumé.- Les mesures d'aimantation montrent qu'à 4 K, NiH est un système continu à deux phases (a - B) pour tout x (x = H/Ni). Les résultats de la résistivité de phonon des échantillons NiH M 1

sont bien représentés par une fonction de GrUneisen avec 9p = 365 K. Aucune contribution à la résis-tivité de la part des phonons optiques de basse énergie n a été observée et l'on peut déduire que NiH n'est probablement pas un supraconducteur.

Abstract.- Magnetization measurements show that, at 4 K, NiH is a continuous two phase (a - 3) sys-tem for all x(x = H/Ni). The phonon resistivity results for NiH „j samples fit a GrUneisen function with 9JJ - 365 K. No contribution to the resistivity by low lying optical phonons is observed and it

is concluded that NiH is probably not a superconductor.

Previous magnetization measurements /l/ made at room temperature have shown that the ferromagne-tic saturation moment I„(x) for NiH (x = H/Ni) de-creases with x and vanishes for x in the range 0.6 < x < 0.85. The question then naturally arises whe-ther NiH , like PdH , may not also be a superconductor for sufficiently large x. In PdH it has been esta-blished that the superconducting exchange interac-tion primarily involves optical phonons /2,3/. It is therefore of some interest to investigate the possibility of a low lying optical phonon band in NiH . To this end and to investigate further the ma-gnetization of NiH resistivity measurements in the range 1.5 K < T < 200 K and magnetization measure-ments at 4 K were made on foil specimens of various x.

The specimens used in this work were produced by electrolytically charging 99.99+ pure Ni foils (= 10.0 Jim thick) with hydrogen at 0°C or room tem-perature. After preparation the samples were kept at 140 K or lower and stored, handled and mounted for experimental measurements under liquid nitrogen The hydrogen content x was determined from thermo-electric power measurements at approximately 140 K where it is known that the thermoelectric power va-ries linearly /4/ with x. These results were che-cked against chromotographic measurements in some of the specimens.

Magnetization measurements were made using a Foner (vibrating sample) magnetometer, which has the facility that suitably mounted specimens can be quenched to 4 K in the magnetometer within seconds. For each value of x, I(H,T = 4 K) measurements

(with H in the range H < ± 20 kOe) were made on the hydrogenated specimen and then again after the spe-cimen had been dehydrogenated. (Dehydrogenation was achieved by removing the specimen from the magneto-meter and annealing it in situ in its holder for

60 minutes at 110°C). Using the expansion 1(H) = Is[l " a/H - b/H^|, for H in the range 2.5 kOe < H

< 20 kOe to obtain I„, the reduced saturation mo-ment Ig(NiH )/I„(Ni) was calculated. These results

for I„(NiH )/I„(Ni) are shown as a function of x in figure 1 and it is apparent, within experimental error, that I<,(x) decreases with x as (1-x).

0.8- - \ N 5 06 - NO s \

02 '

v ^

0' I I 1 I ^^^N-0 ^^^N-0 2 ^^^N-0-« ^^^N-0-6 ^^^N-0-8 1-^^^N-0 X

Fig. 1 : The ratio Ig(NiH)/Ig(Ni) as a function of

hydrogen content (x).

The room temperature and 4 K Ig(x) results can be readily understood in terms of the nickel-hydri-de phase-diagram. It is known from X-ray /5/ and electrochemical /6/ measurements that at room tem-perature NiH can exist in three equilibrium phase states, viz ; with increasing x, an a phase, an

(3)

a + ~ phase m i x t u r e and a p u r e

B

phase. The a + a+B

phase boundary o c c u r s a t x < 0 . 0 3 I 6 1 and t h e a+B +

%

B

boundary f o r 0.65 x

2

0.85 / 5 , 6 / . As t h e tempe- r a t u r e d e c r e a s e s t h e a+B +

B

boundary can be expec- t e d t o move towards I , ( x . 9 a t T = 240 K 141). A t T = 4 K t h e a + mixed phase c o u l d t h e n , a s o b s e r - ved, e x t e n d o v e r t h e e n t i r e r a n g e 0 <

_{- -}

x

<

1 . I n prac- t i c e because of t h e reduced m o b i l i t y of the hydrogen a t low t e m p e r a t u r e s e q u i l i b r i u m c o n d i t i o n s w i l l pro- b a b l y n o t be o b t a i n e d . I n t h e p r e s e n t m a g n e t i z a t i o n e x p e r i m e n t s a t 4 K no s i g n of i n c i p i e n t superconduc- t i v i t y was d e t e c t e d even f o r x

=

1 where t h e

6

phase p r e d o m i n a t e s .

The e l e c t r i c a l r e s i s t i v i t y measurements P(T) were made, u s i n g a f o u r probe t e c h n i q u e and D.C. cur-

r e n t of 100 mA, i n a t e m p e r a t u r e r a n g e 1 . 5 K

$

T

<

200 K, a f t e r i n i t i a l l y quenching t h e specimens f o r 77 K t o 4 K. Temperature measurements were made u s i n g a g o l d (0.06 % I r o n ) - c o n s t a n t a n thermocouple (which had been c a l i b r a t e d a g a i n s t a p l a t i n u m r e s i s t a n c e

thermometer) i n c l o s e thermal c o n t a c t w i t h t h e specimen. The p(T) r e s u l t s shown i n f i g u r e 2 f o r a specimen w i t h x = 0.985 a r e s i m i l a r t o t h o s e f o r a s p e cimen w i t h x = 0.933. The upper c u r v e shows t h e p(T) b e h a v i o u r a f t e r t h e i n i t i a l quench. At a p p r o x i m a t e l y 110 K, where t h e hydrogen becomes s i g n i f i c a n t l y mo- b i l e , t h e r e i s a p p a r e n t l y some c o n f i g u r a t i o n a l r e d i s - t r i b u t i o n of t h e hydrogen

-

p r o b a b l y towards e q u i l i - brium. A f t e r c o n t i n u i n g t o h e a t t h e specimen t o 180 K and then requenchcng t o 4 K t h e lower c u r v e i s ob- t a i n e d f o r i n c r e a s i n g t e m p e r a t u r e s . The b e s t f i t s t o t h e e x p e r i m e n t a l r e s u l t s u s i n g t h e GrUneisen func- t i o n ( s o l i d l i n e ) were o b t a i n e d w i t h s-d and o p t i c a l ban phonon s c a t t e r i n g terms i n s i g n i f i c a n t l y s m a l l o r n e g l e c t e d . The Debye t e m p e r a t u r e s

BD

f o r t h e two so-

l i d c u r v e s a r e a p p a r e n t l y d i f f e r e n t , w i t h t h a t o f t h e lower c u r v e (OD

-

366 K) lower t h a n OD f o r p u r e N i (OD

=

390 K), t e n d i n g towards OD f o r Cu (310 K ) . The u p p e r , p r o b a b l y n o n - e q u i l i b r i u m c u r v e , h a s a OD of 345 K. The most s i g n i f i c a n t a s p e c t of t h e p r e s e n t r e s u l t s i s however t h e a p p a r e n t absence, f o r T

$

180 K, of a marked c o n t r i b u t i o n t o p(T) i n N i H due t o o p t i c a l phonon s c a t t e r i n g . I n PdH t h e c o n t r i b u - - 9 9 5 t i o n t o t h e r e s i s t i v i t y by t h e o p t i c a l phonons becomes n o t i c e a b l e between 80 K and 100 K 2 . I n N i H t h e p o i n t s a t a b o u t 200 K, may i n d i c a t e t h e s t a r t of a c o n t r i b u t i o n by t h e o p t i c a l phonons, t h i s a l l o w s us

t o s a y BE(NiH)

>

1.8 BE(PdH)2

>

990 K. Thus i f o n l y

t h e dominant o p t i c a l phonon-electron exchange i n t e r - a c t i o n / 2 , 3 / i s c o n s i d e r e d we c a n t a k e Tc = eEexp

( - l / A e f f ) where

Xeff

= h-u*

=

N ( O ) I ~ / ( M B ; ) .

F i g . 2 : shows t h e b e s t f i t of t h e Gruneisen func- t i o n t o t h e e x p e r i m e n t a l r e s i s t i v i t y p o i n t s f o r a sample w i t h x = .985. The dashed l i n e s show t h e t e m p e r a t u r e dependent r e s i s t i v i t y of p u r e n i c k e l .

Assuming N ( O ) I ~ / M i s t h e same i n N i H and PdH t h e n Tc(NiH) = Tc(PdH) (BE(NiH) /BE(PdH)) exp

-

( B ~ ( N ~ H ) 18;

(PdH)), which t a k i n g T = 10 K f o r PdH g i v e s Tc(NiH)

< 0.01 K. A more a c c u r a t e c a l c u l a t i o n b a s e d on t h e e q u a t i o n s of r e f e r e n c e 161, which i n c l u d e t h e acou- s t i c phonon c o n t r i b u t i o n , g i v e s Tc(NiH) < 0.003 K.

R e f e r e n c e s

/ I / See f o r i n s t a n c e : Kozlowski, L., and Kubiak, S.T., Phys. S t a t . S o l .

2

(1963) K177.

121 McLachlan, D.S., M a i l f e r t , R., Burger, J.P. and S o u f f a c h e , B., S o l i d S t a t e Comun

17

(1975) 281 131 Burger, J.P. and McLachlan, D.S., J . P h y s i q u e

( P a r i s )

37

(1976) 1227.

141 Skoskiewicz, T., Phys. S t a t . S o l .

5

(1971) 29 151 See f o r i n s t a n c e : Boniszewski, T. and Smith,

G . C . , J. Phys. Chem. S o l i d s

2

(1961) 115. I 6 1 Baranowski;B., and Szlarska-Smialowska, Z . ,
