Contribution to the numerical
estimation of earthquake ground motions
Soutenu le 30 juin 2017, devant le jury compos´e de
• Hiroshi Kawase (Professeur, DPRI, Rapporteur)
• Donat F¨ah (Professeur, ETH Z¨urich, Rapporteur)
• Jean-Fran¸cois Semblat (Directeur de Recherches, IFSTTAR, Rapporteur)
• Michel Bouchon (Directeur de Recherches, CNRS, Examinateur)
Preamble
. . . .
3
I
Curriculum vitæ
4
I.1
Formation
. . . .
4
I.2
D´eroulement de carri`ere
. . . .
4
I.3
Synth`ese du parcours scientifique
. . . .
4
I.4
Responsabilit´es scientifiques et collectives
. . . .
5
I.5
Rayonnement
. . . .
5
I.6
Activit´es d’enseignement
. . . .
7
I.7
Bibliographie
. . . .
8
II Summary of research activity
12
II.1 Introduction
. . . .
12
II.2 Development and verification
. . . .
13
II.3 Validation and beyond
. . . .
27
III Perspectives
58
III.1 Better understanding EGM, its variability and its impact on man-made structures
58
III.2 Amplitude of H/V ratios
. . . .
58
III.3 Imaging absorption and seismic scattering
. . . .
60
IV Publications
66
IV.1 Development of numerical methods
. . . .
66
IV.2 Verification of numerical simulations
. . . .
140
IV.3 Validation of numerical simulations
. . . .
192
IV.4 Sensitivity analyses and variability of EGM predictions
. . . .
270
V Appendices
331
V.1 Towards Seismic Scattering and Absorption Mapping
. . . .
331
It is not useless to recall to a reader not aware of all the subtleties of the french system what the
“Habilitation `
a Diriger les Recherches” (HDR) stands for.
The HDR – litterally, habilitation to lead research – is a french national diploma which gives its
beneficiary the right (i) to officially supervise PhD students and (ii) to apply to professor-like
positions. The HDR diploma can only be delivered by a french university to a candidate who has
convinced an habilitation committee (HC) of his high-level scientific value, through an original
research activity, an autonomous scientific strategy and the capacity to guide younger researchers.
The HDR manuscript is one of the media – the other being the oral defense – used by the candidate
to convince the HC.
This HDR manuscript is made of 4 chapters:
— Chapter
I
presents my Curriculum Vitæ. It includes most of the elements of an
admin-istrative file which has already been successfully evaluated by a local committe of the
Grenoble Alpes University. Because the chapter is only informative and doesn’t have to
be re-evaluated by the members of the HC, it is written in french.
— Chapter
II
presents a summary of my research activity. I made the choice to write this
chapter as a digest of the articles I co-authored and of some unpublished work which either
stimulated my mind in early years, or still require some more time to be analyzed but are
worth being discussed.
— Chapter
III
presents some research perspectives for the next five years.
— Chapter
IV
is a collection of my scientific publications in the last decade. This makes a
huge chapter (more than 250 pages!), which should only be consulted for details about a
result presented in chapter
II
.
