The analysis of complex motion patterns in primate cortex

(1)

The Analysis of Complex Motion Patterns

in Primate Cortex

By

Bard J. Geesaman

A. B. Neurobiology, University of California at Berkeley 1989

Submitted to the Department of Brain and Cognitive Sciences in

Partial Fulfillment of the Requirements for the Degree of

Doctor of Philosophy

LIBRIE

at the

k

Massachusetts Institute of Technology

September 1995

© Massachusetts Institutute of Technology 1995

All Rights Reserved

Signature of Author

Bard J. Geesaman

Department of Brain and Cognitive Sciences

June 29, 1995

Certified by

Richard A. Andersen

Thesis Supervisor

James G. Boswell Professor of Neuroscience

Accepted by

rofessor Gerald E. Schneider

Chairman, Department Graduate Committee

MASSACHUSETTS INSTITUTF

:JUN

2

9 1995

(2)

To My Friends:

Sandra Lee and Mai-khanh Tran for Caring

Andrew Karson and Hoang Tran for Your Kindness

Paul Loh and Glenn Yamagata for Shared Beliefs

George Daley and Edward Renwick forYour Company

(3)

The Analysis of Complex Motion Patterns in Primate Cortex

by

Bard J. Geesaman

Submitted to the Department of Brain and Cognitive Sciences on June 29,

1995 in partial fulfillment of the requirements for the degree of Doctor of

Philosophy in Neuroscience

Abstract

I have been interested in how the nervous system processes complex

motion patterns such as expansion, rotation, and contraction. The analysis

of these types of stimuli is thought to be important for the analysis of

self-motion and the self-motion of objects in the environment. Anatomical,

physiological, and psychophysical approaches were all used in an attempt

to understand these processes. The four chapters break down as follows:

Chapter 1) This is a review of the literature on cortical area MSTd, a

region of the brain thought to be important in the analysis of complex

motion patterns. This article starts with an overview of the anatomy and

physiology of this area before a discussion of the possible roles this region

may play in visual motion processing. The view taken in this discussion is

that MSTd is likely to be involved in a number of different functions, possibly

including egomotion, object motion, vection, and retinal slip.

Chapter 2) Our lab has proposed that MSTd is important in the analysis

of object motion in the environment. Our hypothesis is that this region

extracts information about motion pattern from the visual scene and

largely ignores the features and cues which define this motion. To test this

idea, we recorded from single units in MSTd and obtained tuning curves

using motion patterns defined by different features and cues. I found that

the preferred complex motion for a particular neuron was independent of

the features and cues (i.e. form) of the inducing stimulus.

Chapter 3) Multiple single-unit recording studies in both MT and MSTd

have reported clustering of neurons according to preferred tuning. I

decided to explore this organization using the double-label 2-deoxyglucose

method. The evidence supports a columnar functional organization to both

MT and MSTd, with units tuned for expansion and contraction maximally

separated in a mosaic of columns of altering specificity.

Chapter 4) There are many more units in MSTd tuned to expansion than

to rotation. To see if this anisotropy in response distribution had perceptual

consequences, we compared perceived average dot speeds in random-dot

complex motion patterns. We found that dots in expansion stimuli appeared

to move about 25% faster than the same speed dots in a rotating pattern. The

magnitude of this illusion in various variations of this experiment

compared well with reported response characteristics of MSTd cells.

(4)

Acknowledgments

I thank Richard Andersen and Ning Qian for their support and

guidance over the last four years.

I would like to thank the members of the Andersen laboratory for

creating such a friendly and stimulating surrounding. I doubt if I will ever

work with such a brilliant group of people again, especially if I decide to

explore a career in medicine. Special thanks to Catherine Cooper, Steve

Marchetti, and Gail Robertson for their technical assistance. Stefan Treue

and Ning Qian proved ideal mentors in the area of systems neuroscience. I

would also like to thank Pietro Mazzoni for his help and for filling the lab

with refined choices of music. David Bradley was invaluable for his patient

explanations of statistical issues and overall good taste.

The last four months of my thesis work, I had the privilege to work with

Richard Born. If it wasn't for his generous outlay of time and support,

Chapter 3 would not have been completed. Thanks Rick for being such a

good guy.

I thank Peter Schiller, Ken Nakayama, Ning Qian, and Mriganka Sur

for serving on my thesis committee. Also I am indebted to Jan Ellertsen and

Jerry Schneider for piloting me through my final year without a local

advisor.

I would also like to extend my thanks to my students and colleagues at

Quincy House, my home for the past three years. In particular I would like

to express my appreciation to George Daley and William Bennett, who have

shared their wisdom and friendship. A special thanks to Michael Shinagel,

Master of Quincy House, for providing me with a free roof over my head and

introducing me to Single Malt Scotch.

Finally, I would like to thank my parents for their continuing support.

They instilled in me a love for knowledge and education that has kept me in

(5)

A b stract ...

3 A cknow ledgm ents

...

4 Chapter 1 ...

6 Cortical Area MST and Optical Flow: A Review

Bard J. Geesaman and Richard A. Andersen

C hapter 2

...

86 The Representation of Motion Pattern in Form/Cue

Invariant MST Neurons of the Macaque

Bard J. Geesaman and Richard A. Andersen

C hapter 3

...

155 Functional Organization in Macaque Superior Temporal

Sulcus with Regards to Complex Motion Patterns

Bard J. Geesaman, Richard T. Born, Roger B. H. Tootell, and

Richard A. Andersen

C hapter 4 ...

195 A Novel Speed Illusion Involving Complex Motion

Patterns Related to Cortical Area MSTd

Bard J. Geesaman and Ning Qian

(Submitted to Vision Research)

(6)

Chapter 1: Cortical Area MST and Optical Flow: A Review

Chap ter

1

(7)

Chapter 1: Cortical Area MST and Optical Flow: A Review

Introduction

The purpose of this article is to review what is known about the medial superior temporal (MST) area of the macaque monkey. The first section is dedicated to a discussion of the anatomy and physiology of this cortical area. The remainder of the article is a discussion of the various roles that MST may be playing in visual information processing. Particular emphasis is given to reviewing the literature of ego-motion (direction of heading) representation and pattern motion perception. In addition, we will consider strategies thought to be used by other species to solve these problems. The scope of the discussion will be quite broad, drawing on studies from physiology, psychophysics, and computational neurobiology. In the spirit of systems neuroscience, an attempt will be made to integrate all three approaches. We will propose that the function MST plays is likely to be quite generic and that this region could potentially be involved in many perceptual processes.

Anatomy and Physiology

MST is located medial and anterior to area MT on the floor and anterior bank of the superior temporal sulcus (STS) of the macaque. The long axis of this region is oriented mediolaterally and has a length of approximately 4-5

mm along this direction (Desimone and Ungerleider, 1986; Saito et al, 1986).

Anatomical tracer studies have demonstrated connections with visual polysensory areas in posterior prestriate, parietal, temporal, and frontal cortex (Boussaoud et al, 1990). By far its heaviest input is from area MT, anatomically implicating MST in the processing stream believed to analyze visual motion. Heavy lateral connections to area FST in the fundus of the

STS have been established, although the significance of these connections

and the role that FST is playing in the hierarchy of motion processing has yet to be determined. Other local projections within the STS include reciprocal connections to polysensory association areas (Desimone and
