Dear customer,
It is with great pleasure and pride that L.L. Industries presents to you its brand new catalogue! As the well-illustrated and detailed product offering you have been accustomed to has remained, certain changes have been made to facilitate your search such as the addition of measuring tables, a dependable reference tool, providing you a better knowledge of bolts’
dimensions and standards.
As you probably know, L.L. Industries has known considerable growth in the last years. This growth has encouraged us to make certain important changes throughout the company; Therefore,
L.L. Industriesis proud to present its now larger team of well-trained, competent and qualified employees, ready and eager to serve you! Also, we have recently moved our business into new 8000sq.ft offices, allowing us to offer you, a bigger range of products, more storage capacities and an open window to wider horizons. As an example, L.L. Industries now offers a brand new range of specialized tools (drills, hand taps, dies, etc).
Please call us for more information concerning these new exciting products! As well, we are of course capable of offering you custom-made products, based on your drawings.
In our effort to offer great products at great prices, L.L. Industries is now dealing with the fasteners import market. This represents important savings for you!
Finally, it is important that you know that we have sales represen- tatives on the road, looking forward to meet with you! By doing so, we will be better equipped in understanding your needs and offering you the right products every time! As well, in order to serve you better, come visit our new and exciting website as of November 2008 at : www.llindustries.qc.ca
Cher client,
C’est avec fierté et surtout un grand plaisir que L.L. Industries vous présente son tout nouveau catalogue. Certains changements ont été apportés afin de vous simplifier la tâche. Nous avons ajoutés des tableaux de mesures qui vous seront assurément d’une grande efficacité. Ils vous permettront de vous y référer en tout temps pour connaître les dimensions ainsi que les normes sur les boulons.
Comme vous le savez sûrement, L.L. Industries connaît une très grande expansion depuis quelques années. Évidemment, cette expansion nous a mené vers plusieurs changements au fil du temps : Puisqu’une expansion signifie assurément une aug- mentation du personnel, nous avons maintenant plus d’employés qualifiés et compétents pour vous offrir un service hors-pair.
Nous avons également récemment emménagé dans de nouveaux locaux afin de vous offrir un meilleur service, une plus grande variété de produits ainsi qu’une plus grande capacité de stockage. Ces nouveaux locaux de 8,000 pieds carrés permettent également un élargissement des horizons. En effet, nous avons maintenant une nouvelle gamme d’outils spécialisés disponibles pour répondre à vos besoins (mèches, taraud à main, filières, etc.) N’hésitez pas à nous contacter pour obtenir plus de détails sur ces produits. De plus, nous vous offrons toujours la possibilité de fabrication selon vos dessins.
Depuis quelques temps, L.L. Industries a également rejoint le marché de l’importation. Évidemment, cette opportunité permet des économies de masse importantes pour nos clients.
En terminant, nous tenons à vous rappeler que nos représentants
peuvent se déplacer pour vous rencontrer sur place. De cette
façon, ils seront plus en mesure de cerner vos besoins et de vous
fournir la marchandise adéquate. Notez également qu’à compter
de novembre 2008, nous aurons un site Internet pour mieux vous
servir : www.llindustries.qc.ca
BOULONS ET VIS À SIX PANS CREUX :
1- Boulons hexagonaux
2- Boulons hexagonaux filetés au complet 3- Boulons de Trackshoe
4- Vis hexagonales à rebords 5- Vis hexagonales à rebords dentelés 6- Corps de boulon ajusté à tête hexagonale 7- Boulons de charrue à tête ovale 8- Boulons de carrosserie 9- Boulons d'échelle 10- Boulons d'élévateur
11- Boulons de charrue à tête fraisée 12- Corps de boulon à tête fraisée à ergot 13- Tire-fond à tête hexagonale
14- Vis à tête rectangulaire à angles abattus 15- Vis calibrée avec tête à 12 pointes 16- Vis à tête cylindrique à six pans creux 17- Vis à tête cylindrique mince à six pans creux 18- Vis à épaulement à six pans creux
19- Vis à tête fraisée à six pans creux 20- Vis à tête ronde à six pans creux 21- Vis de pression à tête carrée
22- Vis de pression à six pans creux à pointe cuvette 23- Vis de pression à six pans creux à pointe plate 24- Vis de pression à six pans creux à pointe conique 25- Vis de pression à six pans creux à pointe téton 26- Vis de pression fendue
27- Vis de pression à six pans creux à bout en laiton ou en nylon
BOLT AND SOCKET SCREWS:
1- Hexagon cap screws 2- Tap bolts
3- Trackshoe bolts 4- Hexagon flange bolts 5- Hexagon flange serrated bolts 6- Hexagon fits bolts
7- Scraper bolts 8- Carriage bolts 9- Step bolts 10- Elevator bolts 11- Plow bolts 12- Bucket tooth bolts 13- Lag screws 14- T-bolts
15- Countr-Bor screws 16- Hexagon socket cap screws 17- Low head hex socket cap screws 18- Hexagon socket shoulder bolts 19- Hexagon flat socket cap screws 20- Hexagon button socket cap screws 21- Square head set screws
22- Hexagon socket set screws cup point 23- Hexagon socket set screws flat point 24- Hexagon socket set screws cone point 25- Hexagon socket set screws dog point 26- Slotted set screws
27- Hexagon socket set screws brass or nylon tip
ÉCROUS :
1- Écrous hexagonaux 2- Écrous hexagonaux minces
3- Écrous hexagonaux à embasse cylindrique 4- Écrous hexagonaux à embasse dentelé 5- Écrous indesserrables hexagonaux type Stover 6- Écrous indesserrables avec insertion en nylon 7- Écrous hexagonaux de jonction
8- Écrous indesserrables avec rondelle dentelée 9- Écrous à chape
10- Écrous pour rainures en T 11- Écrous carrés
12- Écrous hexagonaux à crénaux 13- Écrous hexagonaux à crénaux dégagés 14- Écrous hexagonaux bas à crénaux 15- Écrous hexagonaux bas à crénaux dégagés 16- Écrous à pression
17- Écrous à oreilles 18- Écrous flottants 19- Écrous en T 20- Écrous en cage
21- Pièces filetées pour insérer dans le bois
22- Pièces filetées pour insérer dans le bois avec embasse 23- Manchons filetés
NUTS:
1- Hexagon nuts 2- Hexagon jam nuts 3- Hexagon flange nuts 4- Hexagon flange serrated nuts 5- Hexagon Stover lock nut 6- Hexagon nylon insert lock nuts 7- Hexagon connection nuts 8- Hexagon K-lock nuts 9- Hexagon cap nuts 10- Nuts T-slot 11- Square nuts 12- Hexagon slotted nuts 13- Hexagon castle nuts 14- Hexagon thin slotted nuts 15- Hexagon thin castle nuts 16- Press nuts
17- Wing nuts 18- Floating nuts 19- T-nuts 20- Cage nuts
21- Threaded insert for wood
22- Threaded insert for wood with flange 23- Sleeve nuts
AMORTISSEURS DE VIBRATION :
24- Amortisseurs fileté intérieur 25- Amortisseurs fileté extérieur
26- Amortisseurs fileté intérieur et extérieur
ANTI-VIBRATION MOUNTS:
24- Anti-vibration with internal threads 25- Anti-vibration with external threads
26- Anti-vibration with internal and external threads
RONDELLES :
1- Rondelles plates
2- Rondelles plates de carrosserie 3- Rondelles d'ajustage
4- Rondelles élastiques cintrées 5- Rondelles plates type Belleville 6- Rondelles à portée sphérique 7- Rondelles à rotule concave 8- Rondelles obliques
9- Frein d'écrous droit à ailerons 10- Frein d'écrous d'équerre à ailerons 11- Rondelles élastiques
12- Rondelles élastiques à dents espacées extérieures 13- Rondelles élastiques à dents chevauchantes extérieures 14- Rondelles élastiques à dents espacées intérieures 15- Rondelles élastiques à dents chevauchantes intérieures 16- Rondelles de blocage type Nord-Lock
17- Rondelles de sécurité type Schnorr 18- Anneaux de sureté pour arbres 19- Joints toriques
WASHERS:
1- Flat washers 2- Repair washers 3- Shim washers 4- Curved spring washers 5- Belleville washers 6- Spherical washers 7- Conical seats washers 8- Bevel washers 9- Tab washers 10- Double tab washers 11- Lock washers
12- External tooth lock washers 13- External tooth lock washers serrated 14- Internal tooth lock washers 15- Internal tooth lock washers serrated 16- Lock washers type Nord-Lock 17- Locking disks spring type Schnorr 18- Retaining washers for shaft 19- O-rings
MANCHONS :
20- Manchons cylindriques non filetés 21- Manchons cylindriques filetés 22- Manchons hexagonales filetés
SPACERS:
20- Round spacer not tapped 21- Round threaded spacer 22- Hexagon threaded spacer
GOUPILLES :
1- Goupilles cylindriques
2- Goupilles cylindriques à trou taraudé 3- Goupilles coniques
4- Goupilles coniques à trou taraudé 5- Goupilles tendeuses à ressort 6- Goupilles à ressort en spirale 7- Axes de chape
8- Goupilles fendues
9- Agrafes pour goupilles d'attelage 10- Agrafes pour goupilles d'attelage double 11- Goupilles d'attelage rapide
12- Goupilles d'attelage rapide avec épaulement 13- Goupilles de sûreté
14- Goupilles en épingles à cheveux 15- Goupilles de verrouillage 16- Goupilles de verrouillage
PINS:
1- Dowel pins 2- Pull out dowel pins 3- Taper pins 4- Pull out taper pins 5- Slotted spring pins 6- Coiled spring pins 7- Clevis pins 8- Cotter pins 9- Hitch pin clips 10- Double hitch pin clips 11- Quick release hitch pins
12- Quick release hitch pins shoulder type 13- Safety pins
14- Hair pin cotters 15- Tab lock pins 16- Lock pins
OUTILS COUPANTS :
17- Forets droits
18- Forets à queue conique au cône Morse 19- Forets à queue cylindrique réduite 20- Alésoirs
21- Taraud à main ou mécanique 22- Filières hexagonales 23- Filières rondes 24- Extracteur de boulons 25- Fraise de précision
26- Dispositifs de mesure pour les filets
CUTTING TOOLS:
17- Parrallel shank twist drills HSS 18- Morse taper shank twist drills HSS
19- Parrallel shank twist drills with reduced shank 20- Reamers
21- Hand taps or machine taps 22- Hex dies
23- Round dies 24- Screw extractors 25- Precision countersinks 26- Pitch gauges
BAGUES DE RETENUE :
1- Extérieur série R1000 2- Extérieur série R1200 3- Extérieur série R2000 4- Intérieur série R3000 5- Intérieur série R3100 6- Intérieur série R4000 7- Extérieur série R4100
RETAINING RINGS:
1- External serie R1000 2- External serie R1200 3- External serie R2000 4- Internal serie R3000 5- Internal serie R3100 6- Internal serie R4000 7- External serie R4100
PIÈCES POUR LA SOUDURE :
8- Écrous hexagonaux à souder 9- Écrous carrés à souder 10- Écrous ronds à souder 11- Écrous à souder série P1 12- Écrous à souder série P2 13- Écrous à souder série S1 14- Écrous à souder série S2 15- Vis à souder série UN 16- Vis à souder série MN 17- Vis à souder série NN
WELD FASTENERS:
8- Hexagon weld nuts 9- Square weld nuts 10- Round weld nuts 11- Weld nuts series P1 12- Weld nuts series P2 13- Weld nuts series S1 14- Weld nuts series S2 15- Weld screws series UN 16- Weld screws series MN 17- Weld screws series NN
RIVETS AVEUGLES ET SOLIDES :
18- Rivets aveugles à tête fraisée 19- Rivets aveugles à tête domée 20- Rivets aveugles à tête large 21- Rivets solides à tête ronde 22- Rivets solides à tête ronde large 23- Rivets solides à tête fraisée
BLIND AND SOLID RIVETS:
18- Contersunk head blind rivets 19- Dome head blind rivets 20- Large flange head blind rivets 21- Round head solid rivets 22- Truss head solid rivets 23- Countersunk head solid rivets
TENDEURS :
1- Tendeurs 2- Tendeurs oeil & oeil 3- Tendeurs crochet & crochet 4- Tendeurs oeil & crochet
TURNBUCKLES:
1- Turnbuckles
2- Turnbuckles eye and eye 3- Turnbuckles hook & hook 4- Turnbuckles hook & eye
VIS À OEIL :
5- Boulons à oeil matricés 6- Écrous à oeil matricés 7- Tiges à oeil
8- Boulons à oeil
EYE BOLTS:
5- Shoulder eye bolts 6- Shoulder eye nuts 7- Rod end eyebolts 8- Forged eye bolts
ÉLÉMENTS DE FIXATION :
9- Boulons en U carré 10- Boulons en U 11- Crochets en S 12- Boulons à crochet 13- Pitons à oeil 14- Pitons à oeil pour bois 15- Boulons crochet 16- Pitons crochet pour bois 17- Manille forgée 18- Graisseurs hydrauliques
19- Bouchons à colerette à six pans creux 20- Bouchons à tête hexagonale à colerette 21- Bouchons à six pans creux
22- Clés mâles coudées pour vis à six pans creux
23- Ensemble de clés mâles coudées pour vis à six pans creux
FURNITURE FASTENERS:
9- Square bend U-bolts 10- U-Bolts
11- S-hooks 12- Hook anchors 13- Bent eye bolts 14- Lag screw eyes 15- Hook bolts 16- Screw hooks 17- Forged shackles 18- Grease fittings
19- Hexagon socket screw plugs 20- Hexagon head screw plugs 21- Hex socket pipe plugs 22- Hexagon socket screw keys 23- Hexagon socket screw keys kit
ANNEAUX DE SERRAGE ET DE JONCTION :
1- Colliers de serrage-traditionnel 2- Colliers de serrage-un morceau 3- Colliers de serrage-deux morceaux 4- Colliers de serrage de jonction traditionnelle 5- Colliers de serrage de jonction un morceau
SHAFT COLLARS AND COUPLING:
1- Set screw collars traditional 2- Clamping collars one piece 3- Clamping collars two pieces 4- Set screw couplings traditional 5- Clamping couplings one piece
SYSTÈME DE FIXATION DANS LE BÉTON :
6- Cales d'ancrage 7- Manchons d'ancrage 8- Tampons expansibles
9- « Tapcon » vis à tête fraisée cruciforme avec filet haut et bas 10- « Tapcon » vis hexagonale rainurée à rondelle avec filet haut et bas
CONCRETE FASTENING SYSTEM:
6- Wedge anchors 7- Sleeve anchors 8- Anchor bolt
9- “Tapcon” flat phillips with Hi-Lo tapping thread 10- “Tapcon” hex washer slot with Hi-Lo tapping thread
BOUTONS DE VIS À OREILLES ET DIVERS :
11- Boutons de vis en L pour vis à six pans creux 12- Boutons de vis en T pour vis à six pans creux 13- Vis à oreilles
14- Boutons de vis moletée pour vis à six pans creux
15- Boutons de vis moletée avec épaulement pour vis à six pans creux 16- Boutons sphériques taraudés
17- Mousquetons 18- Chapes à fourche 19- Collier de serrage 20- Goujons entièrement filetés 21- Goujons
22- Boulons pour table 23- Boulons de suspension 24- Tiges filetées
THUMBSCREW KNOBS AND MISCELLANEOUS:
11- L knobs for socket cap screws 12- Tee knobs for socket cap screws 13- Wing screws
14- Thumbscrew knobs for socket cap screws 15- Thumbscrew with shoulder for socket cap screws 16- Ball knobs with internal thread
17- Snaps hooks 18- Yokes 19- Hose Clamps 20- Full thread studs 21- Studs
22- Hanger bolts 23- Dowel screws 24- Threaded Rods
Ovale Oval
Ronde Round
Fraisée Countersunk
Bombé Binding
Tronconique Pan
Cylindrique Fillister
Évasé Truss
Hex rainurée Hex slotted
Hex à rondelle Hex washer head
Hex rainurée à rondelle Hex washer slotted
Fendue Slotted
Cruciforme Cross recessed
Carrée Square
Carrée et fendue Socket and slotted
Hexagone Hexagon
Type A Type AB Type B Type C Type U
Vis à filetage coupant Thread-cutting
Type F Type 1 Type 23
Vis auto-perçante Self-drilling screw
Tek
Hexagonale Hexagon
Din 964 Din 963 Din 85 Din 84 Din 7985 D933
Torx Torx
Vis à filetage roulant Thread-rolling
Type 25 Hex avec goupille
Hex with pin
Torx avec goupille Torx with pin
One Way One way
Spanner Spanner
Tri-Wing Tri-Wing
Tampruf Tampruf
Taptite Vis taraudeuse
Thread-forming
Fraisée avec épaulement Flat undercut
Carrée et cruciforme Square and cross recessed
Din 965 D966
VIS MÉCANIQUES / MACHINE SCREWS:
• Charte de tête impériale / Inch Series Head Available Chart
• Charte de tête métrique / Metric Series Head Chart
PRISE / DRIVE:
PRISE DE SÉCURITÉ / SECURITY DRIVE:
DÉSIGNATIONS DU TYPE DE FILET / TYPE DESIGNATIONS THREAD:
VIS À TÊTE HEXAGONALES 931/933
Diamètre E M1,6 M2 M2,5 M3 M4 M5 M6 M7 M8 M10 M12 M14 M16
PITCH 0.35 0.40 0.45 0.50 0.70 0.80 1.00 1.00 1.25 1.50 1.75 2.00 2.00
du 1 9.00 10.00 11.00 12.00 14.00 16.00 18.00 20.00 22.00 26.00 30.00 34.00 38.00
filetage 2 - - - - - 22.00 24.00 26.00 28.00 32.00 36.00 40.00 44.00
LT 3 - - - - - - - - - 45.00 49.00 53.00 57.00
H. tête H 1.10 2.00 1.70 2.00 2.80 3.50 4.00 4.80 5.30 6.40 7.50 8.80 10.00
Largeur F 3.20 5.50 5.00 5.50 7.00 8.00 10.00 11.00 13.00 17.00 19.00 22.00 24.00
Largeur G 3.48 6.01 5.45 6.01 7.66 8.79 11.05 12.12 14.38 17.77 20.03 23.35 26.75
Diamètre E M18 M20 M22 M24 M27 M30 M33 M36 M39 M42 M45 M48
PITCH 2.50 2.50 2.50 3.00 3.00 3.50 3.50 4.00 4.00 4.50 4.50 5.00
du 1 42.00 46.00 50.00 54.00 60.00 66.00 72.00 78.00 84.00 90.00 96.00 102.00
filetage 2 48.00 52.00 56.00 60.00 66.00 72.00 78.00 84.00 90.00 96.00 102.00 108.00
LT 3 61.00 65.00 69.00 73.00 79.00 85.00 91.00 97.00 103.00 109.00 115.00 121.00
H. tête H 11.50 12.50 14.00 15.00 17.00 18.70 21.00 22.50 25.00 26.00 28.00 30.00
Largeur F 27.00 30.00 34.00 36.00 41.00 46.00 50.00 55.00 60.00 65.00 70.00 75.00
Largeur G 30.14 33.53 35.72 39.98 45.20 50.85 55.37 60.79 66.44 71.30 75.95 82.60
1≤125mm 125mm < 2 ≤200mm 3 > 200mm
Toutes mesures et informations sont à titre indicatif.
DIMENSIONS DES BOULONS DE PRÉCISION HEXAGONALE
Diamètre Diamètre du corps E Largeur sur pans F Larg. sur arêtes G
nominal Max. Min. Nom Max. Min. Max. Min.
1/4 0.2500 0.2500 0.2450 7/16 0.438 0.428 0.505 0.488
5/16 0.3125 0.3125 0.3065 1/2 0.500 0.489 0.577 0.557
3/8 0.3750 0.3750 0.3690 9/16 0.562 0.551 0.650 0.628
7/16 0.4375 0.4375 0.4305 5/8 0.625 0.612 0.722 0.698
1/2 0.5000 0.5000 0.4930 3/4 0.750 0.736 0.866 0.840
9/16 0.5625 0.5625 0.5545 13/16 0.812 0.798 0.938 0.910
5/8 0.6250 0.6250 0.6170 15/16 0.938 0.922 1.083 1.051
3/4 0.7500 0.7500 0.7410 1 1/8 1.125 1.100 1.299 1.254
7/8 0.8750 0.8750 0.8660 1 5/16 1.312 1.285 1.516 1.465
1 1.0000 1.0000 0.9900 1 1/2 1.500 1.469 1.732 1.675
1 1/8 1.1250 1.1250 1.1140 1 11/16 1.688 1.631 1.949 1.859
1 1/4 1.2500 1.2500 1.2390 1 7/8 1.875 1.812 2.165 2.066
1 3/8 1.3750 1.3750 1.3630 2 1/16 2.062 1.994 2.382 2.273
1 1/2 1.5000 1.5000 1.4880 2 1/4 2.250 2.175 2.598 2.480
Longueur du filetage LT
Diamètre Hauteur tête H Pour boulons Pour boulons
nominal de≤6'' de >6''
de longueur de longueur
Nom Max. Min. Nominale Nominale
1/4 0.2500 5/32 0.163 0.150 0.750 1.000
5/16 0.3125 13/64 0.211 0.195 0.875 1.125
3/8 0.3750 15/64 0.243 0.226 1.000 1.250
7/16 0.4375 9/32 0.291 0.272 1.125 1.375
1/2 0.5000 5/16 0.323 0.302 1.250 1.500
9/16 0.5625 23/64 0.371 0.348 1.375 1.625
5/8 0.6250 25/64 0.403 0.378 1.500 1.750
3/4 0.7500 15/32 0.483 0.455 1.750 2.000
7/8 0.8750 35/64 0.563 0.531 2.000 2.250
1 1.0000 39/64 0.627 0.591 2.250 2.500
1 1/8 1.1250 11/16 0.718 0.658 2.500 2.750
1 1/4 1.2500 25/32 0.813 0.749 2.750 3.000
1 3/8 1.3750 27/32 0.878 0.810 3.000 3.250
1 1/2 1.5000 15/16 0.974 0.920 3.250 3.500
SPÉCIFICATION POUR SERRAGE
GRADE 2JUSQU'À 6'' DE LONG GRADE 5
STRESS TENSILE PROOF CLAMP TORQUE TENSILE PROOF CLAMP TORQUE
AREA SQ. IN. STRENGHT LOAD LOAD STRENGHT LOAD LOAD
DIA. & CHARGE DE CHARGE CHARGE DE CHARGE
FILET/PO SURFACE RUPTURE D'ÉPREUVE SERREMENT DRY LUB RUPTURE D'ÉPREUVE SERREMENT DRY LUB
AU PO2 K/PSI LBS LBS FT. LB FT. LB K/PSI LBS LBS FT. LB FT. LB
1/4-20 ,0318 74 1750 1310 5,5 4,2 120 2700 2020 8 6,3
-28 ,0364 74 2000 1500 6,3 4,7 120 3100 2320 10 7,2
5/16-18 ,0524 74 2900 2160 11 8 120 4450 3340 17 13
-24 ,0580 74 3200 2400 12 9 120 4900 3700 19 14
3/8-16 ,0775 74 4250 3200 20 15 120 6600 4950 30 23
-24 ,0878 74 4800 3620 23 17 120 7450 5600 35 25
7/16-14 ,1063 74 5850 4380 32 24 120 9050 6780 50 35
-20 ,1187 74 6550 4900 36 27 120 10100 7570 55 40
1/2-13 ,1419 74 7800 5850 50 35 120 12100 9050 75 55
-20 ,1599 74 8800 6600 55 40 120 13600 10200 85 65
9/16-12 ,1820 74 10000 7500 70 55 120 15500 11600 110 80
-18 ,2030 74 11200 8400 80 60 120 17300 12950 120 90
5/8-11 ,226 74 12400 9320 100 75 120 19200 14400 150 110
-18 ,256 74 14100 10560 110 85 120 21800 16350 170 130
3/4-10 ,334 74 18400 13800 175 130 120 28400 21300 260 200
-16 ,373 74 20500 15390 200 140 120 31700 23780 300 220
7/8-9 ,462 60 15200 11430 170 125 120 39300 29450 430 320
-14 ,509 60 16800 12600 180 140 120 43300 32450 470 350
1-8 ,606 60 20000 15000 250 190 105 51500 38600 640 480
-14 ,679 60 22400 16800 280 210 105 57700 43300 720 540
1-1/8-7 ,763 60 25200 18900 350 270 105 56500 42300 790 590
-12 ,856 60 28200 21200 400 300 105 63300 47500 890 670
1-1/4-7 ,969 60 32000 24000 500 380 105 71700 53800 1120 840
-12 1,073 60 35400 26550 550 420 105 79400 59600 1240 930
1-1/2-6 1,405 60 46400 34800 870 650 105 10400 78000 1950 1460
-12 1,581 60 52200 39150 980 730 105 11700 87700 2200 1640
GRADE 8 GRADE 12
STRESS TENSILE PROOF CLAMP TORQUE TENSILE PROOF CLAMP TORQUE
AREA SQ. IN. STRENGHT LOAD LOAD STRENGHT LOAD LOAD
DIA. & CHARGE DE CHARGE CHARGE DE CHARGE
FILET/PO SURFACE RUPTURE D'ÉPREUVE SERREMENT DRY LUB RUPTURE D'ÉPREUVE SERREMENT DRY LUB
AU PO2 K/PSI LBS LBS FT. LB FT. LB K/PSI LBS LBS FT. LB FT. LB
1/4-20 ,0318 150 3800 2850 12 9 180 4610 3450 10 11
-28 ,0364 150 4350 3250 14 10 180 5270 3950 12 13
5/16-18 ,0524 150 6300 4700 24 18 180 7590 5700 19 21
-24 ,0580 150 6950 5200 27 20 180 8410 6300 20 23
3/8-16 ,0775 150 9300 6980 45 35 180 11230 8450 30 33
-24 ,0878 150 10500 7900 50 35 180 12730 9550 35 38
7/16-14 ,1063 150 12800 9550 70 50 180 15410 11550 55 60
-20 ,1187 150 14200 10650 80 60 180 17210 12900 60 65
1/2-13 ,1419 150 17000 12750 110 80 180 20570 15450 85 95
-20 ,1599 150 19200 14400 120 90 180 23180 17400 95 105
9/16-12 ,1820 150 21800 16350 150 110 180 26390 19800 120 140
-18 ,2030 150 24400 18250 170 130 180 29430 22100 135 150
5/8-11 ,226 150 27100 20350 210 160 180 32770 24550 170 185
-18 ,256 150 30700 23000 240 180 180 37120 27800 190 205
3/4-10 ,334 150 40100 30100 380 280 180 48430 36350 265 290
-16 ,373 150 44800 33500 420 310 180 54080 40600 330 355
7/8-9 ,462 150 55400 41600 600 450 180 66990 50300 475 505
-14 ,509 150 61100 45800 670 500 180 73800 55400 520 585
1-8 ,606 150 72700 54500 910 680 180 87870 65900 550 775
-14 ,679 150 81500 61100 1020 760 180 98450 73800 700 900
1-1/8-7 ,763 150 91600 68700 1290 970 180 110630 83000 1025 1150
-12 ,856 150 102700 77000 1440 1080 180 124120 93100 1150 1325
1-1/4-7 ,969 150 116300 87200 1820 1360 180 140500 105400 1400 1600
-12 1,073 150 128800 96600 2010 1510 180 155580 116700 1600 1750
1-1/2-6 1,405 150 168600 126500 3160 2370 180 203720 152800 2900 3250
-12 1,581 150 189700 142200 3560 2670 180 229240 171900 3300 3650
MARQUAGE ET PROPRIÉTÉS MÉCANIQUES ASTM, SAE ET ISO POUR BOULONNERIE EN ACIER
Nominal MECHANICAL PROPERTIES
Identification Specification Fastener Material Size Proof Yield Tensile
Grade Mark Description Range Load Strength Strength
(In.) (psi) Min (psi) Min (psi)
ASTM A307 Bolts, Low Carbon Steel 1/4 thru 4 60,000
Grades A&B Screws,
SAE J429 Studs Low or Medium 1/4 thru 3/4 55,000 57,000 74,000
Grade 2 Carbon Steel Over 3/4 to 1-1/2 33,000 36,000 60,000
ASTM A193 AISI 4140, 4142 1/4 thru - 105,000 125,000
Grade B7 OR 4105 2-1/2 95,000 115,000
Over 2-1/2 75,000 100,000
ASTM A193 CrMoVa Alloy thru 4 105,000 125,000
Grade B16 Steel Over 4 95,000 115,000
thru 7 85,000 100,000
ASTM A193
Grade B8 AISI 304
1/4 and 30,000 75,000
ASTM A193 Larger
Grade B8M AISI 316
ASTM A193 AISI 304 1/4 thru 3/4 100,000 125,000
Grade B8 Bolts, Strain Hardened Over 3/4 80,000 115,000
Screws, thru 1 65,000 105,000
Studs for Over 1 50,000 100,000
ASTM A193 High-Temperature AISI 316 thru 1-1/4 95,000 110,000
Grade B8M Service Strain Hardened Over 1-1/4 80,000 100,000
thru 1-1/2 65,000 95,000
50,000 90,000
SAE J429 Medium 1/4 thru 1 85,000 92,000 120,000
Grade 5 Bolts, Carbon Steel Over 1 to 1-1/2 74,000 81,000 105,000
ASTM A449 Screws, Quenched 1/4 thru 1 85,000 92,000 120,000
Studs and Tempered Over 1 to 1-1/2 74,000 81,000 105,000
Over 1-1/2 thru 3 55,000 58,000 90,000
ASTM A325 Medium Carbon 1/2 thru 1 85,000 92,000 120,000
Type 1 Steel, Quenched 1-1/8 thru 74,000 81,000 105,000
and Tempered 1-1/2
ASTM A325 High Strength Low Carbon
Type 2 Structural Martensitic Steel, 1/2 thru 1 85,000 92,000 120,000
Bolts, Quenched and Tempered
ASTM A325 Atmospheric Corrosion 1/2 thru 1 85,000 92,000 120,000
Type 3 Resisting Steel, 1-1/8 thru 74,000 81,000 105,000
Quenched and Tempered 1-1/2
ASTM A354 Bolts, Alloy Steel 1/4 thru 2-1/2 105,000 109,000 125,000
Grades BC Studs Quenched and Tempered 2-3/4 thru 4 105,000 99,000 115,000
SAE J429 Medium Carbon
Grade 8 Bolts, Alloy Steel
Screws, Quenched and Tempered 1/4 thru 120,000 130,000 150,000
ASTM A354 Studs Alloy Steel 1-1/2
Grade BD Quenched and Tempered
No Grade Mark
B7
B16
B8
B8M
B8
B8M
A325
A325
A325
BC
Toutes mesures et informations sont à titre indicatif.
IDENTIFICATION DE MARQUAGE POUR BOULONNERIE
Grade Nominal Proof Hardness See
Identification Specification Material Size (In.) Load Rockwell Note
Marking Stress ksi Min Max
ASTM A563 - Grade O 1/4 thru 69 B55 C32 3,4
ASTM A563 - Grade A Carbon 1-1/2 90 B68 C32 3,4
ASTM A563 - Grade B
Steel 1/4 thru 1 120
B69 C32 3,4
over 1 thru 1-1/2 105 Carbon Steel
ASTM A563 - Grade C May be Quenched 1/4 thru 4 144 B78 C38 5
and Tempered Carbon Steel
ASTM A563 - Grade DH Quenched 1/4 thru 4 175 C24 C38 6
and Tempered Steel
ASTM A194 - Grade 2H Quenched 1/4 thru 4 175 C24 C38 7
and Tempered
NOTES:
1. In addition to the indicated grade marking, all grades, except A563 grades O, A and B, must be marked for manufacturer identification.
2. The markings shown for all grades of A194 nuts are for cold formed and hot forged nuts. When nuts are machined from bar stock the nut must be additionally marked with the letter 'B'.
3. Nuts are not required to be marked unless specified by the purchaser. When marked, the identification marking shall be the grade letter O, A or B.
4. Properties shown are those of nonplated or noncoated coarse thread hex nuts.
5. Properties shown are those of coarse thread heavy hex nuts.
6. Properties shown are those of coarse thread heavy hex nuts.
7. Properties shown are those of coarse 8-pitch thread heavy hex nuts.
8. Hardnesses are Brinell Hardness Numbers.
9. The nut manufacturer, at his option, may add other markings to indicate the use of atmospheric corrosion resistant steel.
10. Specifications: ASTM A563 -- Carbon and Alloy Steel Nuts.
ASTM A194/A194M -- Carbon and Alloy Steel Nuts for Bolts for High Pressure and High Temperature Service.
A490
No Mark 10.9 or 109 8.8 or 88
MARQUAGE ET PROPRIÉTÉS MÉCANIQUES ASTM, SAE ET ISO POUR BOULONNERIE EN ACIER
Nominal MECHANICAL PROPERTIES
Identification Specification Fastener Material Size Proof Yield Tensile
Grade Mark Description Range Load Strength Strength
(In.) (psi) Min (psi) Min (psi)
ASTM A490 High Strength Alloy Steel 1/2 thru 150,000 min.
Structural Quenched and Tempered 1-1/2 120,000 130,000 170,000 max.
Bolts ISO R898
Class 4.6 Bolts, Medium Carbon 33,000 36,000 60,000
Screws, Steel All sizes
ISO R898 Studs Quenched and Tempered thru 1-1/2
Class 5.8 55,000 57,000 74,000
ISO R898 85,000 92,000 120,000
Class 8.8
Bolts, Alloy Steel All sizes
Screws, Quenched and thru 1-1/2
ISO R898 Studs Tempered 120,000 130,000 150,000
Class 10.9 No
Grade Mark
Toutes mesures et informations sont à titre indicatif.
Grâce à notre capacité et nos aptitudes supérieures, L.L. Industries est en mesure de vous fournir des solutions infinies pour tous vos besoins en boulonnerie. Peu importe le projet, petit ou grand, simple ou complexe, L.L. Industries est là.
Superior capability and capacity allow us to provide infinite solutions for your fastener requirements. Whatever the job description large or small, complex or simple, L.L. Industries will deliver.
Qualités de boulons disponibles :
S.A.E. J-429 Grades 2, 5, 8
A.S.T.M. A-193 Grades B5, B6, B6X, B7, B7M, B8, B8C, B8F, B8M, B8T, B16 Classes 1, 1A, 2, pour usage à haute température A.S.T.M. A-307 Grades A & B
A.S.T.M. A-320 Grades L7, L7A, L7B, L7C, L43, B8, B8C, B8F, B8M, B8T Classes 1, 1A, 2, pour usage à basse température A.S.T.M. A-325 Type 1, 3*, (*anti-corrosion)
A.S.T.M. A-354 Grades BB, BC, BD A.S.T.M. A-449
A.S.T.M. A-490
Lamalloy L9 Résistance supérieure
Métrique Classes 4.6, 4.8, 5.6, 5.8, 6.6, 8.8, 10.9, 12.9
Qualités d'écrous disponibles :
A.S.T.M. A-194 Classes 1, 2, 2H, 2M, 3, 4, 6, 6X, 7, 8, 8C, 9F, 8M, 8T A.S.T.M. A-307 Grades A & B
A.S.T.M. A-325 Type 1, 3* (*anti-corrosion) A.S.T.M. A-563 Grades A, B, C, D, DH, O S.A.E. J-995 Grades 2, 5, 8 Lamalloy L9 Résistance supérieure Métrique Grades 04AU, 5AU, 6, 8, 10, 14H
Acier inoxydable :
18-8, 301, 302, 303, 304, 304L, 305, 309, 310, 316, 316L, 317, 317L 321, 384, 410, 416, 420, 430, 431, 501, 904L, 17-4PH, 254SMO
Filets disponibles :
Gros filet, filet fin, filet extra-fin, B.S.W., B.S.F., métrique, classes 2A, 2B, 3A, 3B, 5A, 5B
Formes disponibles :
Carré, acme, à tuyau, UN, UNR, UNJ, filet gauche ou droit, coupé ou roulé
Autres métaux :
Laiton, bronze, aluminium, alloy, monel, titane, nickel, inconel, cuivre, nylon, teflon
Placages disponibles :
Zinc blanc, zinc jaune, zinc noir, cadmium blanc, cadmium jaune, nickel, cuivre, laiton, oxyde noir, décapage, revêtement de phosphate, galvanisation à chaud, galvanisation mécanique
Insertions de nylon :
Long Lok, Nylon Patch, Scotch Grip, Nylon Pellet
Quality Of Bolts Available:
S.A.E. J-429 Grades 2, 5, 8
A.S.T.M. A-193 Grades B5, B6, B6X, B7, B7M, B8, B8C, B8F, B8M, B8T, B16 Class 1, 1A, 2, for high temperature service
A.S.T.M. A-307 Grades A & B
A.S.T.M. A-320 Grades L7, L7A, L7B, L7C, L43, B8, B8C, B8F, B8M, B8T Class 1, 1A, 2, for low temperature service
A.S.T.M. A-325 Type 1, 3*, (*anti-corrosion) A.S.T.M. A-354 Grades BB, BC, BD
A.S.T.M. A-449 A.S.T.M. A-490
Lamalloy L9 Stronger quality
Metric Class 4.6, 4.8, 5.6, 5.8, 6.6, 8.8, 10.9, 12.9
Quality Of Nuts Available:
A.S.T.M. A-194 Class 1, 2, 2H, 2M, 3, 4, 6, 6X, 7, 8, 8C, 9F, 8M, 8T A.S.T.M. A-307 Grades A & B
A.S.T.M. A-325 Type 1, 3* (*anti-corrosion) A.S.T.M. A-563 Grades A, B, C, D, DH, O S.A.E. J-995 Grades 2, 5, 8 Lamalloy L9 Stronger quality
Metric Grades 04AU, 5AU, 6, 8, 10, 14H
Stainless Steel:
18-8, 301, 302, 303, 304, 304L, 305, 309, 310, 316, 316L, 317, 317L 321, 384, 410, 416, 420, 430, 431, 501, 904L, 17-4PH, 254SMO
Threads Available:
U.N.C., U.N.F., U.N.E.F., B.S.W., B.S.F., Metric, class 2A, 2B, 3A, 3B, 5A, 5B
Threads Shapes Available:
Square, acme, pipe thread, UN, UNR, UNK, UNJ, right or left thread, cut thread or rolled thread
Others Metals:
Brass, bronze, aluminum, alloy, monel, titanium, nickel, inconel, copper, nylon, teflon
Plating Available:
White zinc, yellow zinc, black zinc, white cadmium, yellow cadmium, nickel, copper, brass, black oxide, stripping, phosphate coating, hot dip galvanized, mechanical galvanized
Locking Inserts:
Long Lok, Nylon Patch, Scotch Grip, Nylon Pellet
3440, BOUL. DES ENTREPRISES, LOCAL 104 TERREBONNE [QUÉBEC] J6X 4J8
TÉL.: 450 968-2228 FAX : 450 968-0666
INFORMATION@LLINDUSTRIES.QC.CA
W W W. L L I N D U S T R I E S . Q C . CA
Conception:www.revolutionpub.com
