Copper-deficiency in Ln2-xCexCuO4 (Ln=Nd, Gd) crystals and oxygen disorder in Gd2CuO4 crystals

HAL Id: jpa-00212391

https://hal.archives-ouvertes.fr/jpa-00212391

Submitted on 1 Jan 1990

HAL is a multi-disciplinary open access

archive for the deposit and dissemination of

sci-entific research documents, whether they are

pub-lished or not. The documents may come from

teaching and research institutions in France or

abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est

destinée au dépôt et à la diffusion de documents

scientifiques de niveau recherche, publiés ou non,

émanant des établissements d’enseignement et de

recherche français ou étrangers, des laboratoires

publics ou privés.

Copper-deficiency in Ln2-xCexCuO4 (Ln=Nd, Gd)

crystals and oxygen disorder in Gd2CuO4 crystals

Ph. Galez, G. Collin

To cite this version:

579

LE

JOURNAL

DE

_PHYSIQUE

Short Communication

Copper-deficiency

in

_Ln2-xCexCuO4

_{(Ln=Nd, Gd) crystals}

and

oxygen

disorder

in

Gd2CuO4

crystals

Ph. Galez and G. Collin

C.P.C.M., DPhG,

C.E.N.

_Sachay,

91191 Gif sur

_Yvette,

France

(Requ

le 24 novembre 1989,

_accepté

sous

_{forme définitive}

le 16

_{janvier 1990)}

Résumé. 2014 La structure de _sept monocristaux de

_{Nd2-xCexCuO4 (x=0 et x=0.18)}

et

_Gd2CuO4

est

déterminée par diffraction des rayons X. Tous les cristaux ont la structure

_tétragonale

T’ du

_Nd2CuO4

(groupe

d’espace

I4/mmm,

n°

_139).

Un défaut de cuivre de l’ordre de 3 à 6% est trouvé dans six cristaux alors _que les deux sites de

_{l’oxygène (dans}

les

_plans

_CuO2

_O(1)

et entre les

_plans

de terre rare

O(2))

sont

_{complètement}

_occupés

dans la limite d’erreur. Les

_ellipsoïdes

de vibration des sites

_Nd,

Cu et

_{O(2) sont}

_plus

_{allongés parallèlement}

à l’axe c dans les cristaux recuit sous

_atmosphère

inerte que dans les cristaux bruts de croissance. L’atome

d’oxygène

des

_plans

_CuO2

_(O(1))

dans

_Gd2CuO4

est trouvé décentré dans la direction de l’axe a de 0.18

₍₂₎

Å.

Abstract. 2014 The structure of _seven

Nd2-xCexCuO4

(x=0 and x=0.18)

and

_{Gd2CuO4 single crystals}

is determined

_by

means of

_X-ray

diffraction. All

_crystals

have the

_{Nd2CuO4 tetragonal}

T’ structure, space group

I4/mmm (139).

The _copper site is found deficient

_{(3 -}

_6%)

in six

_crystals

whereas both

oxygen sites

_(within

the

_CO2

_planes

_O(1)

and between rare earth

_layers

₀₍₂₎₎

remain

_{fully occupied}

within standard deviation. The vibration

_{ellipsoids of Nd,}

Cu and

_O(2)

_appear to be more

_ellongated

in the c direction in Nd-based

_crystals

reannealed in an inert

_atmosphere

than in _as-grown ones. The oxygen of the

CuO2

basal

_plane

₍₀₍₁₎₎

in

_Gd2CuO4

is found off-centered in the a direction

_by

0.18

(2)

Å.

1

_Phys.

France 51

₍₁₉₉₀₎

579-586 ler AVRIL _1990,

Classification

Physics

Abstracts 61.10-61.70B-74.70

1. Introduction.

Superconductivity

was

_recently

discovered in the

_{Ln2_~Ce~.CuO~}

_(Ln

=

_Nd,

_Pr,

_Sm,

Eu)

and

Ln2-x ThxCu04

(Ln

=

Nd,

Pr) copper-oxide

materials with a critical

_temperature

_up to 24 K four x=O. 16

_{[1 - 3].}

These

_compounds

are not

_{spontaneously}

_{superconducting}

but need to be annealed

580

(900 °C)

in an inert

_{atmosphere (N2, Ar)}

to achieve

_{superconductivity. X-ray}

_absorption

near-edge

structure measurements of the Ce

_L3

_edge

_{[4, 5],}

Ce ionic-radius

_analysis

_{[6, 7]}

and Ce

_X-ray

photoemission

measurements

_[8]

indicate that the valence of Ce is

_greater

than + 3. These

com-pounds

can therefore be considered as

_{electron-doped superconductors}

in

_agreement

with Hall

coefhcient measurements

_{[1, 9]}

which show

_that,

in the normal _state, the

_transport

_properties

are

essentially

due to electrons. At least one

_parent

_compound

of these

_materials,

_namely

_Nd2Cu04,

exhibits

_magnetic

order of the Cu moments at 245 K with an

_{antiferromagnetic}

_arrangement

of

spins

in the

_Cu02

_{planes [10, 11].}

At room

_temperature,

all

_{electron-doped superconductors}

have the

_Nd2Cu04

_tetragonal

T’

structure

_(space

_group

_{I4/mmm, Z=2) [12]}

which differs from the related

_high

_temperature

tetra-gonal

T structure of

_{La2Cu04_y}

in that the two

_apical

_oxygen atoms are removed from the

_(0,0,

z)

position

to the

_{(0, 1/2, 1/4)}

_position

_(Fig.

_1).

Hence the coordination numbers of Cu and Ln

(Ln

=

Nd, Pr, Sm,

Eu)

become

respectively

4

(square plane)

and 8 instead of 6

_(octahedral)

and

9.

Fig.

1. -

Body

centered

_tetragonal

unit cells of the

_high

_temperature T-structure of

_La2CU04

_(left)

and the

T’-structure

of

_{Nd2 CU 04}

_{right).

Several neutron and

_{X-ray powder}

diffraction structural studies have been

_performed

on

these

_compounds.

The main results for the

_prototype

material

_{Nd2-~Ce~.Cu04}

can be

summa-rized as follow :

(i)

the c

_parameter

decreases from 12.17

A

to 12.06

A

when the Ce content is increased from

x = 0 tox =

_0.20,

upper limit of the

solubility

range, while the a

_parameter

remains

quasi-constant

at 3.945

A

_{[8, 13],}

(ii) superlattice

reflexions have been

_reported

_by

Izumi et al. in

_agreement

with electron diffraction results

_[14]

while other _groups did not mention such extra

_{peaks [8,12,13,15]}

and

(iii) oxygen-deficiency

on both sites

_{0{1) (within}

the

_Cu02

_planes

_{(0, 1/2, 0))}

and

_{0(2) (o,1/2,}

1/4)

have been encountered

_by

Izumi et al.

_[14]

and

_{’~akayama-Muromashi et}

al.

_[16]

on

supercon-ducting NdissCeo isCuO4

and on Ce free

_sample.

For non-reannealed

_{(non-superconducting)}

Ndl.85CeO.15CU04,

only

the

₀₍₂₎

site was found deficient. In the

_light

of

_{thermogravimetry}

underestimated

and,

eventually,

that _oxygen defects are introduced at least into the

₀₍₁₎

site

_by

reduction.

We have

_performed

a detailed

_{Ndz_x Cex Cu04}

_{single crystal analysis, using}

_X-ray

_diffraction,

in order to obtain valuable structural information and to

_{investigate possible}

structural

_changes

between _as-grown and reannealed

_samples.

One

Gd2Cu04

single crystal

is also included in the

present

study.

2.

_{Experimental.}

Several Nd-based

_crystals

were

_prepared

_using

two different

_methods,

_growth

from a flux

(CuO)

between 1150 ° C and 1000 ° C for the Ce free

_{samples (N1,}

_{N2, N3,}

_N4)

and

_spontaneous

crystallisation

from the

_powders

at 1200 ° C for the

_{Ce-containing}

_{samples (N5, N6).}

N3 was

extracted from the

_shiny

free surface of the

_preparation,

N1 and N4 from the innermost

_layers

of this surface and N2 from the flux at the bottom of the

_preparation.

N4 and N6 were further annealed at 900 ° C under

_{flowing nitrogen}

for 12 hours. The

_Gd2Cu04

_crystal

_(Gd)

was obtained

by

spontaneous

crystallisation

at 1200 ° C.

All the

_crystals

were found

_tetragonal

with

_systematic

extinction conditions

_{corresponding}

to

a

_body

centered unit cell in

agreement

with

_unpublished

_X-ray

_powder

diffraction results. 8 - 2B and scans

_performed

on the

_{(200), (020)}

and

₍₀₀₆₎

reflexions of each

_sample

revealed a

_high

crystalline quality

and no trace of

_twinning.

The Ce content of N5 and N6 was estimated from the

c

_parameter

to lie between 0.17 and 0.19

_{(Thb. I).}

The data collection was

_performed

on a half

sphere

of the

_reciprocal

_space

_up to 65°

_{(Mo Ka).}

After

_absorption

_correction,

the

_independent

reflexions were obtained as an _average of 8

_equivalent

reflexions. The whole set of

_independent

reflexions were

_kept

in the refinement

_including

those with zero

_intensity.

%ble 1. - Lattice

parameters

(A)

and volume

_of

unit cell

_(A3).

The lattice constants are obtained

from a

reflexion

centering

routine

_{(25 reflexions).}

3. Results and discussion.

The first refinement was _{carried out,}

_using

atomic structure

_factors,

with the structural results

of Rietveld

_analysis

as

_starting

_parameters

_[14,16J,

_isotropic

thermal

_parameters

and

_occupations

factors constrained to their ideal values. The

_temperature

factors for all sites were then allowed

to be

_anisotropic

with

_symmetry

constraints

Ull

=

_U22

for

Nd(Ce),

Cu and

0(2)

sites and

_{Uij -}

0

582

3.1 COPPER DEFICIENCY. - For six

crystals (Nl,

N2, N3, N5,

N6 and

_Gd),

a

_significant

copper-deficiency

was found which led to a decrease of the R-factor. In table III are

_reported

the results

of the

_Rl/R2

ratio

_{(respectively}

without and with a variation of the Cu

_{occupancy) compared}

with the minimum value it should exhibit to be

_{statistically significant}

_{1?b,n-m,O.OOS [17].}

In _{all cases,} the

_{Rt/ R2}

ratio is

_higher

than R. Furthermore it is to be noted that :

(i)

the standard deviations on the

_occupation

factors of Cu are at least four times lower than the deviation from the ideal value and

(ii)

the decrease of the R-factor is all the more

_important

than the

_deficiency

is

_significant.

This

_{copper-deficiency}

could result from a

_preparation

_temperature

of

_{crystals higher}

than the maximum

_stability

_temperature

of CuO

_{(~ 1050 ° C).}

Above this

_{temperature CU20}

rather than CuO is the stable form of

_copper

oxide which leads to a

_fugacity

of

_copper.

Indeed a reddish

hue,

caracteristic of

Cu20,

is observed in the flux after

_crystal

_growth.

In addition

_{Nl, N2,}

N3 and N4

_prepared

at lower

_temperature

than

_N5,

N6 and Gd and with CuO in excess exhibit a

smaller

_deficiency.

Such a defect has

_already

been encountered in

_{YBa2Cu30~_y crystals [18]}

but affects

_only

the

_Cu(l)

site

_(chain

_site)

because of lower

_preparation

_temperature.

In the

_present

case,

however,

the

_Cu02

_planes

are concerned and this should affect both

_{superconducting}

and

magnetic properties

of

_Nd2-xCexCu04

_crystals.

In fact Thrascon et al.

_reported

that

_they

could

not obtain zero resistance down to 2.5 K in the basal

_plane

of

_{superconducting}

Nd~_~CexCu04

(x

= 0.14 and x =

0.16)

crystals

while it is

currently

achieved at 20 K in

polycrystalline

ceramics

[19].

However we

_point

out that this

_deficiency

is not

_systematic

since it is not observed in N4. It

seems to be

_closely

related to the

_preparation

method and _{may vary} from

_crystal

to

_crystal

as a

function of local

_{surrounding during}

_growth.

We now come to the

_problem

of _oxygen content.

_Keeping

in mind the

_copper

defect

_reported

above,

it is reasonable to think that it should induce a related _oxygen

_deficiency

at least on the

0(1)

site. However no

_significant

deviation from the ideal value was found

_except

for the

₀₍₁₎

site of N2

_{(Thb. II).}

Our results do not allow to _{draw any definite conclusion.}

’1’able II. - Structural

parameters

for

N2, N5,

N6 and Gd

_(space

_group

_I4~mmm;

Z =

2).

The

_possibility

of interstitial oxygen at the _apex

_position

03

_(0,

0,

z)

was also

_{investigated.}

Indeed some electronic

_density

was found at this site

_resulting

in a

_slight

decrease of the R factor and in

_large

standard deviations over the

_multiplicity

g, the

_{position z}

and the

_temperature

factor B. However the additional _oxygen content

_(about

the same for all

_{crystals :}

_doped

or

_undoped,

reannealed or

_not)

was found to be

_{approximately}

0.25

₍₁₂₎

which is unrealistic. Moreover the refined 03

_position

_(z

_{N 0.2)}

would lead to much too short Nd-03 and 02-03 distances. This

result,

although

highly

unprobable,

may indicate

complex

structural _{features associated with}

oxy-gen disorder which can

_hardly

be solved with

_X-ray

diffraction.

_Single

_crystal

neutron diffraction is needed to answer this

_question.

Thble III. -

Refinement

results and Cu _occupancy.

3.2 EFFECTIVE VALENCE OF CERIUM IN Nd-BASED CRYSTALS.

_{- Knowing}

the _average distances between atoms in one

_compound,

it is

_possible

to

_compute

the ionic radius of each element and therefore its valence state for a certain coordination number. From our structural results we

may evaluate the mean valence state of cerium in

_{Nd2_ x Ce~ CuO4}

_{(x =}

0.18 f

_1).

In table IV is

reported

the _{average distance} between the rare earth ion and its

_eight

_surrounding

_oxygens for each

_crystal.

For Ce-free

_sample

this distance is 2.501

₍₁₎

A

in

_good

_agreement

with the theoretical

value,

2.499

_A,

_computed

from the

_following

ionic radii :

In

_{Ce-containing}

_crystals

_(N5

and

_N6),

we find

_2.4945(10)

to

which leads to a mean ionic

_radius,

1.1045(10)

5i,

and

_eventually

to a mean valence state of

cerium,

_{3.61(7), computed}

from :

The error bar takes into account both the standard deviation on distances and the

_uncertainty

on Ce content

_(x

= 0.18 ~

1).

This result is similar to that found

by

Hor et

al., 3.59,

from the

variation of the volume of the unit cell

_[8]

but much lower than that

_{computed by Huang et aL}

from the decrease of the c

_parameter,

3.84 and would lead to a total extra-electron concentration of

_1.17(13)

x

10+21

CM-3

in the absence of _any other chemical difference between

Nd2Cu04

and

Ndl.82CCO.18CU04-584

Stable IV - Ln-Ox distances

_(A).

3.3 ANISOTROPY. - In all Nd-based

_crystals

the

₀₍₁₎

site exhibit

_{strongly anisotropic}

tempe-rature factors

_(U22

_U11,

_U~3)

due to Cu attraction

_along

the b direction

_{(Thb. V).}

For other

sites,

we must

_distinguish

between _as-grown

_(Nl,

_N2,

N3 and

_N5)

and reannealed

_crystals

_(N4

and

N6).

In the first _{case, the} Cu and

₀₍₂₎

thermal

_parameters

are found

_isotropic

within standard deviation while the Nd site exhibit smaller

_temperature

factor in the c direction. For the latter

crystals

however,

the

Nd,

Cu and

_Q(2)

sites have

_larger

thermal

_parameter

in the c direction than

within the basal

_plane.

Another difference between _as-grown and reannealed

_crystals

is

_readily

seen from table I : N4 and N6 have a lower c

_parameter

than

N1,

N2 or N3 and N5

_{respectively.}

Table

_{V -Anisotropic}

_temperature

_{factors for}

N2,N5

and N6

_(A2

x

104) .

3.4 OFF-CENTERING OF

₀₍₁₎

IN

_{Gd2Cu44. -}

The refinement of Gd was carried out in the same manner as for the other

_crystals.

_Isotropic

thermal

_parameters

for the

_Nd,

Cu and

₀₍₂₎

sites

were found very similar to these of the _as-grown Nd-based

_samples.

In contrast, the

_temperature

factor of

₀₍₁₎

was much

_higher

_{(Beq. =}

_{1.7(4)) indicating}

a

_possible

_{off-centering}

of the atom

10-4

_A2,

U22

=

70(23)

x

10-4A2

and

U33

= 145(40)

x

10-4t~2) .

The x

_parameter

of the atom was

therefore allowed to _vary and reached

_rapidly

its _convergence

_value,

_0.046(5),

that is an absolute

off-centering, 0.18(2)

A.

A

_significant

decrease of the R factor was obtained

_giving

a

_{Ri /R2}

_ratio,

1.093,

higher

than the minimum statistical

value,

1.033. In this

_{configuration,}

the

_temperature

factor of the off-centered atom is

_nearly

divided

_by

two

_(j9eq

=

0.9(2)).

Another feature in

Gd2Cu04

arises from the

_experimental

value of the mean distance

bet-ween the Gd cation and its

_surrounding

_oxygens,

_2.461(1)

_A,

which is

_{significantly}

lower than the theoretical one, 2.443

_A,

_computed

from :

R(Gd3+, VIII)

= 1.053

A

4.

_Summary.

The main feature

_reported

in this work is the occurence of

_copper

defects within the

Cu02

plane resulting

from a

_preparation

_temperature

_higher

than the

_stability

_temperature

of CuO. This result obtained on

_{single crystals}

is in

_agreement

with the

_difficulty

in

_obtaining

zero resistance in the basal

_plane

of

_{Nd2-.pCe.pCu04}

_(x

=

0.14,

0.16) [19].

In _{contrast, no}

significant

_oxygen

deficiency

could be detected

_except

in one

_crystal

extracted from the inner

_part

of the

_preparation.

Further

_{single crystal}

neutron diffraction

_analysis

is

_required

to

_investigate

this

_problem

more

accuratly.

The mean valence state of cerium in

Ndl.82Ceo.18CU04,

evaluated from the mean rare

earth-oxygen

distance,

is found

significantly

higher

than +

3,

3.61(7),

thus

_confirming

the results ob-tained

_by

means of

_X-ray

_absorption

and

_X-ray

_{photoemission}

measurements

_[4,5,8].

Detailed

investigations

of the

_magnetic

and

_transport

_properties

of

_{Nd2_~CexCu04}

are in _progress as well

as

_{single crystal}

neutron diffraction studies.

Eventually

the

₀₍₁₎

site in

_Gd2Cu04

_appeared

to be off-centered in the a direction

_(0.18(2)

5i)

which can

_perhaps

be related to the lack of

_{superconductivity}

in

Gd2_ x Cex Cu04.

Acknowledgements.

The authors thank J. Godard for his

_help

in

_growing

the

_crystals

and for

_making

available a

high

temperature

furnace.

References

[1]

TOKURA

_Y.,

TAKAGI H. and UCHIDA S., Nature 337

₍₁₉₈₉₎

345.

[2]

MARKERT J. T. and MAPLE M. _B., Solid State Commun. 70

₍₁₉₈₉₎

145.

[3]

MARKERT J. _T., EARLY E. A., BJORNHOLM

_T.,

GHAMATY

S.,

LEE B.

_W.,

NEUMEIER J. _J., PRICE R.

_D.,

SEAMAN C. L. and MAPLE M. _B.,

_Physica

C 158

₍₁₉₈₉₎

178.

[4]

TRANQUADA J.

_M.,

HEALD S.

_M.,

MOODENBAUGH A. _R., LIANG G. and CROFT

_M.,

Nature 337

₍₁₉₈₉₎

720.

[5]

ALP E.

_E.,

MINI S.

M.,

RAMANATHAN

M.,

DABROWSKI

B.,

RICHARDS D. R. and HINKS D.

G.,

Phys.

Rev. B 40

₍₁₉₈₉₎

2617.

[6]

HUANG T. _C., MORAN _E., NAZZAL A. _I., TORRANCE J. B. and WANG P.

_W.,

_Physica

C 159

₍₁₉₈₉₎

625.

[7]

HOR P.

_H.,

XUE Y.

Y.,

SUN Y.

Y.,

TAO Y. C., HUANG Z. J., RABALAIS W. and CHU C.

W.,

Physica

C 159

( 1989) 629.

586

[9]

TAGAKI

H.,

UCHIDA S. and TOKURA _Y.,

_Phys.

Rev. Lett. 62

₍₁₉₈₉₎

1197.

[10]

AKIMITSU

_J.,

SAWA

_H.,

KOBAYASHI _T., FUJIKI H. and YAMADA

_{Y., J.}

_Phys.

Soc.

_Jpn

58

₍₁₉₈₉₎

2646.

[11]

SKANTHAKUMAR

S.,

ZHANG

H.,

CLINTON T.

_W.,

LI W.

_H.,

LYNN J.

W.,

FISK Z. and CHEONG S.

_W.,

Physica

C 160

₍₁₉₈₉₎

124.

[12]

SINGH K.

_K.,

GANGULY P. and GOODENOUGH J.

_{B., J.}

Solid State Chem. 52

₍₁₉₈₄₎

254.

[13]

HUANG T

_C.,

MORAN

E.,

NAZZAL A. I. and TORRANCE J.

_B.,

_Physica

C 158

₍₁₉₈₉₎

148.

[14]

IZUMI

_E,

MATSUI _Y., TAKAGI H., UCHIDA S., TOKURA Y. and ASANO _H.,

_Physica

C 158

₍₁₉₈₉₎

433.

[15]

GOPALAKRISHNAN

_J.,

SUBRAMANIAN M. A., TORARDI C.

C.,

ATTFIELD J. P. and SLEIGHT A.

W,

Mat. Res. Bull. 24

₍₁₉₈₉₎

321.

[16]

TAKAYAMA-MUROMACHI

_E.,

IZUMI

_F.,

UCHIDA

Y.,

KATO K. and ASANO

_H.,

_Physica

C 159

₍₁₉₈₉₎

634.

[17]

HAMILTON C.

_W.,

International tables for

_{crystallography}

_(Kynoch

_Press)

4

₍₁₉₇₄₎

291.

[18]

COLLIN

_G.,

AUDIER A. C. and COMES

R., J.

Phys.

France 49

₍₁₉₈₉₎

383.
