Dislocations in amorphous materials

HAL Id: jpa-00211076

https://hal.archives-ouvertes.fr/jpa-00211076

Submitted on 1 Jan 1989

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are pub- lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

S.F. Edwards, Anita Mehta

To cite this version:

S.F. Edwards, Anita Mehta. Dislocations in amorphous materials. Journal de Physique, 1989, 50 (18), pp.2489-2503. �10.1051/jphys:0198900500180248900�. �jpa-00211076�

Dislocations in amorphous ^materials

S. F. Edwards and Anita Mehta

Cavendish Laboratory, University ^of Cambridge, Madingley Road, Cambridge ^CB3 OHE, ^G.B.

(Reçu ^{le 9 mars 1989,} accepté le 25 avril 1989)

Résumé. ²⁰¹⁴ Le but principal ^{de cet article est} de fournir une meilleure compréhension ^des

matériaux amorphes, plus particulièrement ^des systèmes ^{vitreux et} granulaires, ^en indiquant ^les

domaines où le comportement ^{de ces derniers} peut être semblable. Une attention spéciale ^est portée ^aux systèmes granulaires ^{en tant} que ^nouveau sujet ^d’étude, d’importance croissante, ^en physique ^{et nous} présentons ^{une revue des} progrès ^récents accomplis ^{dans la} compréhension ^de

leurs propriétés statiques ^et dynamiques. ^{La liaison} sous-jacente ^{entre ces} dernières, ^{en terme de} transmission de force conduisant à des flux, ^{est discutée est} des spéculations ^{sont faites sur un}

mécanisme possible de transmission.

Abstract. ²⁰¹⁴ The general aim of this paper is ^to provide ^{a better} understanding ^of amorphous materials, with special ^{reference to} glassy ^and granular systems, indicating ^{areas where the}

behaviour of these two may be similar. We lay special emphasis ^on granular systems, ^{as befits} their importance ^{as a} newly emerging ^{field of} study ⁱⁿ physics, ^and present ^{a review of recent} progress in understanding their statics and dynamics. ^The underlying connection between the latter in the form of transmission of stress leading ^to flow, ^is discussed, ^and speculations ^{are made}

as to the possible mechanism of this transmission.

Classification

Physics ^Abstracts

05.20 ^- 05.40 ^- 05.60 ^- 05.90

Introduction.

In 1964 Jacques ^Friedel

[1]

published ^{a treatise on} dislocations, which covered that subject magisterially, showing how the mechanical properties ^of crystalline solids could be explained

and tracing back the way in which the electronic ^structure of metals was related to their mechanical properties using ^such concepts. ^In writing in honour of Professor Friedel, ^we thought it would be interesting ^to look forward to new fields where the concepts required ^are

still being ^{worked out and one} day may reach the elegance achieved in Friedel’s book.

One is often struck in physics by the fact that a particular ^{class of} problems is resolved by

certain concepts ^which clearly ^{do not} apply ^{in a related} problem. ^For example, ^{one can solve}

the problem of electrons in ^a metal

(a

subject with massive and

illuminating

contributions from

Friedel)

^{and hence see} why ^a metal is cohesive. But there are other crystalline ^solids

which are manifestly ^{not metals, but which are} cohesive and with remarkably ^similar binding energies ^to metals. The general principle ^{is that} something ^{must stick the atoms} together, ^but

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphys:0198900500180248900

it can be the metallic, ionic, ^{or covalent} bonds, ^or indeed the Van der Waals or hydrogen

bonds at a weaker level.

Now in metals, ^for example, ^the strength ^{of the} material, ^{and its} plastic flow, depend ^{on the}

dislocations in the metal. It depends ^{on how} easily they ^are created and destroyed, ^what

energy threshold is

required

^{to move} them, ^{and so on.}

Strength

and flow arise however in

non-crystalline materials such as glasses ^{as well as in} granular systems. ^{There must be a} way of

sustaining ^{stress in these} materials, ^{and a} way in which they flow. The manifestations of small deformation elasticity ^{such as} compressibility ^can obviously be tackled by the behaviour of forces due directly ^{to the atoms or molecules.}

But the general ^{class of} amorphous materials is much wider than that of crystals, ^and

dislocation theory ^{must be a} particular instance of a more general way of looking ^{at stress}

transmission and stress crisis in the substance. Sometimes it is clear from the nature of the material how stress is transmitted and the physical circumstances are seen to be very ^remote from crystalline solids. For example margarine ^is typical ^{of a mixed} system ^which consists of

crystals ^of lipid surrounded by oil. The fat crystals ^{tend to stick to one} another, ^{so one can see}

two limiting regimes. ^{The first}

(Fig. 1)

^{is when one has a low} population density ^{of fat} crystals,

which tend to link up ^to form chains ; the second is when one has a well connected network

(Fig. 2)

^of crystals permeated by ^oil.

Fig. 1. Fig. 2.

Fig. ^{1. -} Configuration showing ^low population density ^of lipid crystals ^{in oil.}

Fig. ^{2. -} Configuration showing high population density ^of lipid crystals ^{in oil.}

It is obvious that the second of these cases represents margarine in its bulk solid state, whereas the first would behave like a highly ^viscous liquid. Clearly ^{one can} arrange the behaviour of the material empirically ^{to suit} the needs of the consumer who wishes to apply ^so

much force to his knife to

spread

^the margarine ^{on his bread ; but one} also should be able to calculate the strength directly. ^This example ^{is remote from} crystalline systems. ^An apparently ^{more similar} system would be that of amorphous ^{silica, common} glass, which looks like crystalline material and has ^a very similar strength ^{to covalent or ionic} crystals. ^However

when one starts to consider this problem ^{in detail,} it has very different features, ^{and shares} difficulties with the mathematical description ^of granular systems. ^{We shall} study ^these problems ^here by reviewing progress that has already ^{been made, and} by offering ^{some new}

ideas and speculations ^{of our own.}

1. The description ^of amorphous ^materials.

Although ^our primary interest is in glassy systems, ^the problem ^{of a} powder ^{is a} good ^{one to}

consider for it removes any temptation ^{to use} quasi-crystalline descriptions. ^The ergodic

theorem is normally thought ^{of as a} consequence of the dynamics ^{of atoms, but it is} important

to realise that any operation ^{which acts} macroscopically

(i.e.

^{not on} individual

entities),

^will

result in conditions which can be called ergodic. ^Thus given ^a powder, operations ^{such as} shaking, stirring ^or rolling, ^{do not} discriminate between individual grains and result in a

material which has a minimal specification. ^For example, close-packed spheres ^{have an}

average coordination of twelve, but this value can almost reach thirteen. Thus a demon can construct a solid whose density ^{is, at least}

initially,

higher ^than close-packed. Maybe ^a patient

demon could do this on a large ^{scale also, but if a} volume of hard spheres is treated by shaking

or stirring ^or rolling, ^{one achieves a} density which is below face-centred cubic, and which lies between two well defined limits, ^a maximum random packing, ^{and a} minimum. For a powder

of spheres ^{i.e. a} system ^where temperature ^is unimportant, ^{but one} for which the Van der Waals forces are minor compared ^{to the stresses which are} easily transmitted from outside - the kind of powder ^one knows well in everyday ^{life - the} system clearly ^{has a} total number of

particles N, ^{a volume} V, ^{and an} entropy S ^{but no} temperature T, total energy E, ^{and free}

energy F. The question then arises as to how one describes it. The same problem appears in

principle ⁱⁿ glasses ^{when one} is well below

Tg,

^{the glass} transition temperature.

We can argue

[2-4]

^{that the matter} is resolved by ^{a table of} analogies. ^For ordinary

statistical thermodynamics, ^the system is conservative and has a Hamiltonian H such that all states with E ⁼ H are equally probable. Thus in this the microcanonical ensemble, ^the probability distirbution is

where the entropy S is the normalization got ^from realising that because

we must have

The transition to the more useful canonical ensemble comes from defining temperature ^{T and} free energy F via

In a granular system where the conventional definition of E does not constitute a key thermodynamic quantity, ^we suggest

[2,

3,

4]

^{that the} key quantity ^must be the volume V and that there must be a function W which gives the volume in terms of the positions ^and

orientations of the constituent grains ^{of the} powder, ^or molecules of the glass. ^{Thus we can}

define

where À, ^the analogue of Boltzmann’s constant, is such that S has the dimension of volume.

From this one can define a compactivity

and an effective volume Y by

Now at this point the reader might complain that this is a very elaborate way of writing

down the well-known concept ^{of free} volume, ^{but to our mind the current} literature lacks the

precision of these formulae which are direct analogues ^of statistical mechanics. Having ^thus

set out the basic formalism of our statistical mechanical approach ^to powders, ^{we can now} proceed ^to apply ^{it to somewhat more} realistic situations.

We reproduce here the model calculation of Edwards

[2]

^to illustrate the spirit of the above

approach ^{- the} problem of the mixture of two grains ^is mapped ^{onto the} Bragg-Williams problem of the A-B alloy, ^{and we seek a} solution for the variation of the domains of A, B and A-B with respect ^{to the} compactivity X ^{and the} degree ^to which the grains aggregate preferentially among themselves. We model the W function so as to reproduce the crudest

possible assumption ^- less volume is ^« wasted ^» on average if grains ^{of the same} size cluster

together ^{than if} grains of different sizes do :

with

niA(B) being 1(0)

depending ^{on whether an}

A(B)

grain ^is present

(absent).

^{This is} mapped

as usual onto an Ising ^model

with J, ^the exchange given by

and ai = ^± 1

depending

^on whether site i is occupied by ^{an A or a B atom. The mean field}

solution of Bragg and Williams gives

[2]

^{as usual}

with z as the coordination number of the lattice. Thus for

J/AX

^{1, the two} powders ^are totally ^{miscible, but as}

J/AX >

1, ^the

powders

^{tend to have} unequal mixed domains until at

X - 0, the material separates into domains of pure A and pure B.

We see from the above that even this relatively ^crude modelling reproduces ^a qualitative

feature of powder mixtures that one observes in nature : however a more detailed analysis

[3]

gives ^{one the two ordered states} observed in nature, where in addition to the so-called

« ferromagnetic ^{» one} gets ^{a «} stacking ^» solution, i.e., ^{one where a «} layered ^» arrangement of the grains ^is preferred ^so that each A rests on a base of B and vice versa. This can be done

[3]

by mapping ^the binary ^{mixture onto the} eight-vertex ^{model of} spins, and the results thus obtained show good agreement with results of computer simulation experiments

[5].

Thus despite ^{the crude nature of some of our} assumptions, e.g. those involved in neglecting

the non-lattice-based aspects ^{of such} granular systems, the above shows in our view the

underlying strengths ^{of our} statistical mechanical approach ^to the statics of these systems. ^In the next section, ^{we will} attempt ^to relate this framework to the transmission of stress in such systems, ^{and to the} consequent flow, ^once resistance to motion

(e.g.

in the form of

friction)

has been overcome.

2. Statics and dynamics.

We have argued that there are two limits to the natural density ^of packed amorphous

material. Clearly ^{if the} material is at its maximum density in the presence of boundaries, ^{it can}

transmit stress but it cannot flow. Thus if the compactivity parameter X ⁼ 0 there is no flow and the « viscosity » of the material appears ^to be infinite. The resistance to flow then decreases until X = 00 which is the lowest solid density. After that the material has the attributes of ^a liquid ^{and is} outside this discussion. The compactivity ^{has an} average value

across the materials, but will fluctuate as will the effective volume Y and it will be these fluctuations which permit ^{flow. Of course} all that is being said is that some configurations permit rearrangement, ^{and some do not. It can} be shown that the coordination of a particle ^is

a good criterion for discussing the condition of an amorphous ^material and the minimum free volume comes with the maximum coordination which has X ⁼ 0, whereas the lowést density

comes when all

(meta)stable

coordinations are equally likely and X = 00. This gives ^{a useful}

way ^to think of the cooling ^{of a} glass, ^{for one can} summarize well known facts about cooling ⁱⁿ

the symbolic diagrams that constitute figures ^{3 and 4.}

Fig. 3. Fig. 4.

Fig. 3. - Diffusion as a function of temperature for various cooling ^rates.

Fig. ^{4. -} Density ^{as a} function of temperature for different cooling ^rates.

The time taken to reach

Tg

^{of the glass}

^depends

^{on the cooling rate.} The fastest rate brings

one to the highest

Tg, Tg max,

the slowest to the

Tg, Tg

^{min. For a thermal system such as a glass,}

there will now be slow processes that will take the system down from

Tg max

^to

Tg

^{min - for a powder,} there exist analogues ^to these slow relaxation processes ^on which work is currently in progress

[6].

In general ^{these are} complex ^and highly cooperative, ^but when, ^{as in the case of a} glass, they ^are thermally driven it is well known that they ^are governed by ^a simple law, variously

known as the law of Vogel and Fulcher or Doolittle or Williams, Landel and Ferry

[7].

^{The lax}

is that there is an essential singularity in the run-up ^to

Tg,

^{i.e. a} relaxation time r such that

A simple derivation of this law has been given by Edwards and Vilgis

[8]

who argue, in the current language, ^{that an excess at one}

point

waits until a reduction occurs at an adjacent point. This reduction itself depends ^on another reduction. It is

illuminating

^to discuss this in the language of barriers ^- if ^a is the probability ^{that a} barrier obstructs the motion of the

« excess », i.e. the particles ^under consideration, ^then clearly ^{the time taken} by the latter to move will be increased by ^{a factor} involving ^{a. To be more} precise : ^if Do is the free diffusion

coefficient, and D that in the presence of barriers, ^then

Do

^{1 and}

^D-1,

^the corresponding

diffusion times, ^must be related by ^{a series in a -} this is because if there is only ^{one barrier,}

the time taken is increased by a ; ^{if there are two} barriers, ^{one of which can} only ^{move if the}

other one does so first, then the time will be increased by

a 2 ;

^{and so on.} Thus in the mean

field approximation ^{we can} write,

or

and ^{a =} 1 corresponds ^{to the} glassified state, i.e. where the barriers ^are frozen in so that ^no further diffusion occurs. This is the so-called glass transition. The above was derived under the assumption that each barrier moves independently of the others ^- however when a

cooperative ^motion of the barriers _occurs, so that e.g. three barriers ^move around in ^a loop ^at

the same time, the motion is further modified, and the series is, with this correction

[8]

where _{a 1} is the weight ^{of a closed} loop. ^{This can} be evaluated to give

with B a constant ^- on recognising ^that

D-1/r,

^this gives ^{us back}

(18),

^the Vogel-Fulcher

(V-F)

^form.

This calculation becomes rigorous ^for systems ^{where mean field} analysis ^is rigorous e.g. for

long rod molecules moving ^{in an} entanglement ^{tube, but the} universality of the V-F form suggests, ^as is often the case, that mean field arguments ^are much better than one might expect. Indeed if the V-F is a mean field formula, ^more subtle versions can be expected ^{to fit} experiment ^{a little} better, and formulae like

exp - A / (T - Tg) (1 + f3)

^are found in the literature. If the relaxation time has the V-F form, it allows us to consider the set of curves in

figures 3 and 4 for then one can argue that if the cooling ^rate exceeds the relaxation rate of the

cooling

liquid,

^the liquid glassifies. ^{Thus of}

Tgo

^{is the glass} temperature

(i.e.

the minimum

Tg

^{of our}

^diagrams)

^and

Tg

^{the glass} temperature found with a cooling ^rate

d1J/dt ==

^R, say, then

so that for R ⁼ 0,

Tg

⁼

T gO.

The formula has no validity for R >

8 -

^{1 for that} gives

Tg

^{= oo} and in fact there is a maximum

7g

corresponding ^{to X =} oo, after which point ^a glass

cannot occur as it would not be connected. Clearly ^{a more elaborate} argument ^is required ^but

formula

(23)

does fit much data quite well. Thus ^a

quite

reasonable first approximation

emerges for which ^a detailed argument

[9]

^{will be} published ^later.

The picture ^{so far has} only ^{talked of «} fluctuations » and not attempted ^to quantify ^their

size. Clearly there will be a spread ^of sizes, ^{and the} relaxation will depend ^{on this} spread. ^For example if the relaxation time T is really

7 ( A )

^{such that}

our crudest analysis above will relate

top 7- > .

^But the actual formulae should use

T (À )

^{and be} averaged ^{in some correct} way. In particular ^a correlation function will decay ^like

not like e-’/’. A simple example, ^{when T - e À’, and P is} like p

exp ( v À b),

gives ^on using steepest ^{descents to solve}

(25)

^for large ^times,

the stretched exponential. The forms of P and T require ^{models of} course, which must be

sufficiently complicated ^to contain the indices a and b.

Much of the above discussion has concentrated on glasses ; ^the dynamics ^of granular systems ^{is much more} complicated although ^{it is our view}

[6]

^{that some of the} underlying principles ^here might ^have analogies with those that hold in glassy systems. ^{In order to} indicate where these resemblances may lie, ^we will review in the next section what is known about granular dynamics, and include some brief remarks about our work in this area at

present. Finally ^{in section 4, we} will include some speculations about the transmission of stress in these systems ^and try ^{to see whether or not the} analogue ^{of a} dislocation can be the

operative mechanism for stress propagation ⁱⁿ amorphous systems.

3. Dynamics ^of granular systems.

The dynamics ^of granular systems, ^or powder ^{mechanics as it was}

traditionally

known, ^has been extensively ^studied by ^chemical engineers

[10, 11] ;

^however physicists have turned their attention to it only recently, ^so that while many ^current experimental configurations

[12, 13]

(when

shorn of their digitised

sophistication)

^are remarkably ^{similar to} those studied earlier

[10, 11],

^{the nature of the}

questions

addressed reflects the different approaches ^{of the two} disciplines. It will be our purpose in this section first ^to sketch the development of this difficult and fascinating field, ^{and then to} pose the questions ^{that are} currently being addressed, giving

indications of possible ^answers where available.

To start with, ^we lay ^{out three} principles ^of powder ^mechanics

[10]

^{- as} early ^{as 1885,}

Reynolds [14]

observed that « a

tightly

packed ^{mass of} granules inclosed within a flexible

envelope invariably ^increases in volume when the envelope is deformed : if the envelope ^is

inextensible but not inflexible, ^no deformation is possible ^{until the} applied forces-rupture ^the

bag

^or fracture the granules » - this expresses the fundamental principle of dilatancy ^of powders. ^The application ^{of shear stress then causes erstwhile} granular contacts to slacken : and surfaces of sliding, permitting ^relative displacements ^of granules, ^are thereby ^formed.

The

principle of

mobilisation of friction ^{then states} that the frictional force between any ^two

grains ^{in a} powder ^{at rest can} take any value between ^zero and ^some threshold value for the onset of relative motion - thus the stress distribution in a powder ^{at rest is} indeterminate. If the frictional force due to shear of a powder reaches its limiting value, ^a surface of sliding ^is

formed. Another consequence of this principle ^{is the} occurrence of a range of equilibrium

states, hence of bulk densities and angles of repose. As the powder begins ^to flow, however,

the grains ^are constantly rearranged - for conditions of steady flow e.g. through apertures, ^it

seems that there must be a restriction on the previous condition. This then leads to the

principle of minimisation of energy, which ^states that under such conditions, energy is minimised in a well-defined manner thus enabling ^{one to} calculate flow rates at apertures, ^for instance.

It was realised before

[10]

^{that to cause a} powder ^{to flow, it had to be} brought ^{into a state of} ready sliding, ^{or to a} so-called « critical voids ratio » ^- although ^the identity ^{of these} descriptions ^has yet ^{to be} rigorously proven, it ^seems reasonable to conjecture ^{that this must}

be so, and this is indeed the hypothesis ^{that we} have made in an earlier section. One of the chief questions ^{then at this} stage, ^{concerns the onset of flow - in a} system with open boundaries, ^{is there a critical} compactivity

(or

^more precisely, ^{when one} recognises ^the possible first-order nature

[13]

^{of this} transition and takes into account the principle ^of

mobilisation of friction, ^{is there a} small range of critical

compactivities)

^at which flow will

begin ? Also, ^{once flow has} begun, ^{is there some} simple way in which it ^can be characterised ? We have made some preliminary attempts ^{to answer these} questions ^{based on the} theory ^of generalised avalanche processes, in work which is ^to be published shortly

[15].

^An alternative and closely related way is ^{to state} that what one really ^{needs is a} good microscopic theory ^of

surfaces of sliding, ^which separate rapidly moving ^from nearly stationary material - this underlines the need for ^an ab-initio approach ^{based on} dynamical equations ^{of motion, which}

are the subject ^{of some of our current work}

[16].

A thorough ^and comprehensive ^account of many experiments dealing ^{with the} dynamics ^of granular piles ^{is to} be found in the excellent book by ^Brown and Richards

[10].

^{We choose}

however to focus on an experiment ^{which has been the} motivation for several experiments ⁱⁿ

the recent past, ^{of which a} great variety ^of questions ^has been asked - this will illustrate the

point made in the opening paragraph ^{of this section, as well as serve to link us with the state of}

the art, ^{as it} were, ^at present.

The so-called rotating cylinder ^method of Franklin and Johanson

[17]

^{was used} by ^{them to}

measure the instantaneous surface angle ^{of a} granular pile ^that partially ^{filled a} rotating ^drum.

We quote, for historical interest, and for purposes of comparison ^{with current} experiments

the account given ^{in reference}

[10] :

« At very low rotation speeds the material surged ^{as it}

was raised beyond its maximum angle of repose, subsequently collapsing ^{to a low} angle.

Increasing ^the speed of rotation increased the frequency ^of surging ^{until, at} about 2.5- 3 r.p.m., the surface became substantially steady,

exhibiting

only ^minor ripples

(Fig. 5).

^At higher speeds

(but

well below the critical speed ^at which material becomes centrifuged ^{to the}

curved

surface)

the free surface assumed an elongated S-shape... ^»

Fig. ^{5. - Free} surface of granular pile ⁱⁿ rotating cylinder experiment ^{above a threshold} frequency ^of

rotation.

This served as a clear signal ^{to modern} experimenters of the appearance of instabilities in the free surface of granular piles when these were submitted to enforced motion ; equally ^the

« surges »

(or

avalanches, ^{in more modem}

parlance)

^{seemed to be} clearly worthy ^of study.

Before proceeding ^{to describe recent} studies of these matters, ^we _{pose the} questions ^{that even}

this sketchy ^{account would arouse : how,} for instance would the free surface of a granular pile

look as a function of different frequencies ^and amplitudes of rotation and/or vibration ? What, if any, of the experimental parameters, e.g. the aspect ^{ratio and} shape ^{of the} cell, size, shape ^{and texture} of the beads ^or the nature of the surrounding medium, might influence this transition ? Could one explain theoretically ^{the nature} of the instabilities ? Can one

understand theoretically ^{the onset of an} avalanche ? Could one measure the frequency spectrum ^{of these} avalanches, and understand them, ^{at least at some} crude level ?

To answer the first of these

questions,

Rajchenbach ^and Evesque

[12]

^{submitted a}

parallelepipedic

^cell partially filled with monodisperse glass spheres ^{to vertical} vibrations of

varying amplitude. Beyond ^{a threshold} amplitude, they observed that the horizontal free surface became unstable, ^and the surface spontaneously ^{assumed an} angle 0 ^{to the} horizontal ; ^a permanent ^current of avalanches was observed to flow in this regime. ^The instability appeared ^{to have a} convective nature in that the transport ^of particles ^{down the} slope ^was compensated

(Fig. 6)

^for by ^{a reverse} transport ^of particles in the bulk from the bottom to the top. ^{This state was seen to} persist ^until yet another threshold was reached,

which heralded the onset of chaotic behaviour, ^with temporal ^and spatial intermittency ^of particle ^{flow at} the free surface.

Fig. ^{6. -} Appearance ^of convective instability ^above threshold of amplitude ^of vibration ; the downward flow along ^the slope ^is compensated ^for by ^an upward flow in the bulk.
