YIC2013 Second ECCOMAS Young Investigators Conference 2–6September 2013, Bordeaux, France
Error Estimation for The Convective Cahn – Hilliard Equation
G. S¸ims¸ek
a,∗, K. G. van der Zee
a, E. H. van Brummelen
aaEindhoven University of Technology
Multiscale Engineering Fluid Dynamics,5600 MB Eindhoven, Netherlands
∗G.Simsek@tue.nl
Abstract.In this contribution we consider the a-posteriori error analysis of the convective Cahn–Hilliard [4] model for varying P´eclet number and interface-thickness (diffusivity) parameter. The adaptive discretization strategy uses mixed finite elements, a stable time-stepping algorithm and residual-based a-posteriori error estimation [2, 5].
Keywords:mixed finite element method; a-posteriori error analysis; error estimation and mesh/modeling adaptation
1 INTRODUCTION
The Cahn–Hilliard phase-field (or diffuse-interface) model has a wide range of applications where the interest is the modelling of phase segregation and evolution of multiphase flow systems. In order to capture the physics of these systems, diffuse-interface models presume a nonzero interface thickness between immiscible constituents, see [1].
The multiscale nature inherent in these models (interface thickness and domain size of interest) urges the use of space-adaptivity in discretization.
1.1 The Model
LetΩ⊂Rdbe a bounded domain withd= 1,2,3and∂Ωbe the boundary which has an outward unit normaln.
The convective Cahn-Hilliard equation can be written as follows:
Find the real valued functions(c, µ) : Ω×[0, T]→RforT >0such that
∂tc− 1
P e4µ+∇ ·(uc) = 0 in ΩT := Ω×(0, T] µ=φ0(c)−2∇c in ΩT
c(·,0) =c0 in Ω
∂nc=∂nµ= 0 on ∂ΩT :=∂Ω×(0, T],
where∂t(·) = ∂(·)/∂t,∂n(·) = n· ∇(·)is the normal derivative,φis the real-valued free energy function,uis a given function such that∇ ·u= 0inΩandu·n = 0on∂Ω,P eis theP´ecletnumber andis the interface thickness.
The nonlinear energy functionφ(c)is of the double well form and we consider the followingC2-continuous func- tion:
φ(c) :=
(c+ 1)2 c <−1,
1
4 c2−12
c∈[−1,1],
(c−1)2 c >1.
The total free energy of the system is
E(c) :=
Z
Ω
φ(c) +2 2|Oc|2
dx.
2 G. S¸ ims¸ek et al. |Young Investigators Conference 2013
1.2 Weak Formulation
In order to obtain the weak formulation, we consider the following function space and the corresponding norm as a suitable space forµ:
V :=L2(0,T;H1(Ω)), kvk2V :=
Z T 0
kv(t)k2H1 (Ω)dt and the space suitable for the phase variablecis
W :={v∈V :vt∈V0},
whereV0 :=L2(0,T; [H1(Ω)]0)is the dual space ofV with the normkvtk2W :=kvk2V +kvtk2V0, where
kvtk2V0 :=
Z T 0
kvt(t)k2[H1(Ω)]0dt.
Then the weak form of the problem becomes:
Find(c, µ)∈Wc0×V:
hct, wi+ (u∇c, w) + 1
P e(∇µ,∇w) = 0 ∀w∈H1(Ω) (µ, v)−(φ(c), v) +2(∇c,∇v) = 0 ∀v∈H1(Ω), fort∈[0,T], whereWc0is the subspace ofW of which the trace att= 0coincide withc0.
To derive an a-posteriori error representation, we will employ the mean-value-linearized adjoint problem. The dual problem can be defined in terms of dual variables(p, χ)where the dual variablepis a function in the space
Wq¯:={v∈W :v(T) = ¯q}. Then the dual problem can be written such as:
Find(p, χ)∈Wq¯×V:
−∂tp+u∇p+24χ−φ0(c,ˆc)χ=q1 in Ω×[0, T) χ− 1
P e4p=q2 in Ω×[0, T) p= ¯q on Ω× {t=T}
∂np=∂nχ= 0 on ∂Ω×[0, T], where the nonlinear functionφ0(c,ˆc)is a mean-value-linearized function
φ0(c,ˆc) = Z 1
0
φ00(sc+ (1−s)ˆc)ds.
2 CONCLUSION
This analysis for the convective model forms a basic step in our research and will be helpful for a broad analysis of the coupled Cahn–Hilliard/Navier–Stokes system [3] which is the desired model for future research.
REFERENCES
[1] Anderson, D.M., McFadden, G.B., Wheeler, A.A.. Diffuse-Interface Methods in Fluid Mechanics. Annu. Rev. Fluid Mech.30:139–65,1998.
[2] Bartels, S., M¨uller, R.. A-posteriori error controlled local resolution of evolving interfaces for generalized Cahn–Hilliard equations.Interfaces and Free Boundaries12:45–73,2010.
[3] Boyer, F., Lapuerta, C., Minjeaud, S., Piar, B., Quintard, M.. CahnHilliard/NavierStokes Model for the Simulation of Three-Phase Flows.Transport in Porous Media82:463-483,2012
[4] Kay, D., Styles, V., S¨uli, E.. Discontinuous Galerkin Finite Element Approximation of the Cahn–Hilliard Equation with Convection.SIAM J. Numer. Anal.47:2660–2685, 2009.
[5] Van der Zee, K. G., Oden, J. T., Prudhomme, S., Hawkins-Daarud, A. Goal-oriented error estimation for Cahn–Hilliard models of binary phase transition.Numer. Methods Partial Differ. Equations27:160–196, 2011.
