Comparing the Expressiveness of Description Logics

Comparing the Expressiveness of Description Logics

Ali Rezaei Divroodi

Institute of Informatics, University of Warsaw Banacha 2, 02-097 Warsaw, Poland

rezaei@mimuw.edu.pl

Abstract. This work studies the expressiveness of the description log- ics that extendALCreg (a variant of PDL) with any combination of the features: inverse roles, nominals, quantified number restrictions, the uni- versal role, the concept constructor for expressing the local reflexivity of a role. We compare the expressiveness of these description logics w.r.t.

concepts, positive concepts, TBoxes and ABoxes. Our results about sepa- rating the expressiveness of description logics are based on bisimulations and bisimulation-based comparisons. They are naturally extended to the case when instead ofALCreg we have any sublogic ofALCreg that ex- tendsALC.

1 Introduction

Expressiveness (expressive power) is a topic studied in the fields of formal lan- guages, databases and logics. The Chomsky hierarchy provides fundamental re- sults on the expressiveness of formal languages. In the field of databases, the works by Fagin [11, 12], Immerman [15, 16], Abiteboul and Vianu [1] provide important results on the expressiveness of query languages. Many results on the expressiveness of logics have also been obtained, e.g. in [13, 15, 3, 17, 22, 18, 23].

The expressiveness of description logics (DLs) has been studied in a number of works [2, 5, 6, 19, 20]. In [2] Baader proposed a formal definition of the expres- sive power of DLs. His definition is liberal in that it allows the compared logics to have different vocabularies. His work provides separation results for some early DLs. In [5] Borgida showed that certain DLs have the same expressiveness as the two or three variable fragment of first-order logic. The class of DLs considered in [5] is large, but the results only concern DLs without the reflexive and transi- tive closure of roles. In [6] Cadoli et al. considered the expressiveness of hybrid knowledge bases that combine a DL knowledge base with Horn rules. The used DL is ALCN R. The work [19] by Kurtonina and de Rijke is a comprehensive work on the expressiveness of DLs that are sublogics of ALCN R. It is based on bisimulation and provides many interesting results. In [20] Lutz et al. char- acterized the expressiveness and rewritability of DL TBoxes for the DLs that are sublogics of ALCQIO. They used semantic notions such as bisimulation, equisimulation, disjoint union and direct product.

This work studies the expressiveness of the DLs that extendALC_reg (a vari- ant of PDL) with any combination of the features: inverse roles, nominals, quan- tified number restrictions, the universal role, the concept constructor for express- ing the local reflexivity of a role. We compare the expressiveness of these DLs w.r.t. concepts, positive concepts, TBoxes and ABoxes. Our results about sep- arating the expressiveness of DLs are based on bisimulations and bisimulation- based comparisons studied in our joint works [8–10]. They are naturally extended to the case when instead ofALCreg we have any sublogic ofALCregthat extends ALC.

Our work differs significantly from all of [2, 5, 6, 19, 20], as the class of con- sidered DLs is much larger than the ones considered in those works (we allow PDL-like role constructors as well as the universal role and the concept con- structor∃r.Self) and our results about separating the expressiveness of DLs are obtained not only w.r.t. concepts and TBoxes but also w.r.t. positive concepts and ABoxes.

The rest of this paper is structured as follows. In Section 2 we recall notation and semantics of DLs, including the notion of positive concepts [10]. In Section 3 we recall the definitions of bisimulations and bisimulation-based comparisons as well as some invariance or preservation results of [8–10]. In Section 4 we present our results on the expressiveness of DLs. Section 5 concludes this work.

2 Notation and Semantics of Description Logics

Our languages use a finite set ΣC ofconcept names(atomic concepts), a finite set ΣR of role names (atomic roles), and a finite set ΣI of individual names.

LetΣ=ΣC∪ΣR∪ΣI. We denote concept names by letters likeAandB, role names by letters likerands, and individual names by letters likeaandb.

We consider someDL-featuresdenoted byI(inverse),O(nominal),Q(quan- tified number restriction),U(universal role),Self(the local reflexivity of a role).

Aset of DL-featuresis a set consisting of some or zero of these names. We some- times abbreviate sets of DL-features, writing, e.g., IOQ instead of {I, O, Q}.

From now on, if not stated otherwise, let Φbe any set of DL-features and let L stand forALC_reg.

Definition 2.1. The DL languageLΦ allowsrolesandconcepts defined induc- tively as follows:

– ifr∈Σ_R thenris a role ofLΦ

– ifA∈Σ_C thenA is a concept ofL_Φ

– ifR andS are roles ofLΦ andC is a concept ofLΦ then

• ε,R◦S,RtS,R^∗ andC? are roles ofLΦ

• >,⊥,¬C,CtD, CuD,∃R.C and∀R.C are concepts ofLΦ

• ifI∈ΦthenR⁻ is a role ofLΦ

• ifO∈Φanda∈Σ_I then{a}is a concept of L_Φ

• ifQ∈Φ,r∈ΣR andnis a natural number then≥n r.Cand≤n r.C are concepts ofLΦ

• if{Q, I} ⊆Φ,r∈Σ_R andnis a natural number then≥n r⁻.C and≤n r⁻.C are concepts ofL_Φ

• ifU ∈ΦthenU is a role ofLΦ

• ifSelf∈Φandr∈Σ_R then∃r.Selfis a concept of LΦ. 2 The following definition introduces positive concepts ofLΦ.

Definition 2.2. LetL^pos_Φ be the smallest set of concepts andL^pos_Φ,∃,L^pos_Φ,∀be the smallest sets of roles defined recursively as follows:

– ifr∈ΣR thenris a role ofL^pos_Φ,∃andL^pos_Φ,∀,

– ifI∈Φandr∈Σ_R thenr⁻ is a role ofL^pos_Φ,∃andL^pos_Φ,∀, – ifR andS are roles ofL^pos_Φ,∃andC is a concept ofL^pos_Φ

thenε,R◦S,RtS,R^∗ andC? are roles ofL^pos_Φ,∃, – ifR andS are roles ofL^pos_Φ,∀andC is a concept ofL^pos_Φ

thenε,R◦S,RtS,R^∗ and (¬C)? are roles ofL^pos_Φ,∀, – ifA∈ΣC thenA is a concept ofL^pos_Φ ,

– ifO∈Φanda∈ΣI then{a} is a concept ofL^pos_Φ , – ifSelf∈Φandr∈ΣR then∃r.Selfis a concept ofL^pos_Φ ,

– ifC is a concept ofL^pos_Φ ,R is a role ofL^pos_Φ,∃ andS is a role ofL^pos_Φ,∀ then

• >,CtD,CuD,∃R.C and∀S.C are concepts ofL^pos_Φ ,

• ifQ∈Φ,r∈Σ_R andnis a natural number then≥n r.Cand≤n r.(¬C) are concepts ofL^pos_Φ ,

• if{Q, I} ⊆Φ,r∈ΣR andnis a natural number then≥n r⁻.C and≤n r⁻.(¬C) are concepts ofL^pos_Φ ,

• ifU ∈Φthen∀U.C and∃U.C are concepts ofL^pos_Φ .

A concept ofL^pos_Φ is called apositive conceptofLΦ. 2 We introduce bothL^pos_Φ,∀ and L^pos_Φ,∃ due to the test constructor of roles. The concepts ∃(A?).B and ∀((¬A)?).B are positive concepts. As we will see, they are equivalent toAuB andAtB, respectively.¹

IfΦ is empty then we abbreviate LΦ by L. We use letters like R and S to denote arbitrary roles, and use letters likeCandDto denote arbitrary concepts.

We refer to elements of Σ_R also as atomic roles. Let Σ_R^± = Σ_R∪ {r⁻ | r ∈ Σ_R}. From now on, bybasic roleswe refer to elements of Σ_R^± if the considered language allows inverse roles, and refer to elements ofΣ_Rotherwise. In general, the language decides whether inverse roles are allowed in the considered context.

Aninterpretation I = h∆^I,·^Ii consists of a non-empty set ∆^I, called the domain of I, and a function·^I, called the interpretation function of I, which maps every concept nameAto a subsetA^Iof∆^I, maps every role namerto a binary relation r^I on ∆^I, and maps every individual nameato an element a^I of∆^I. The interpretation function·^I is extended to complex roles and complex concepts as shown in Figure 1, where #Γ stands for the cardinality of the set Γ. We writeC^I(x) to denotex∈C^I, and writeR^I(x, y) to denotehx, yi ∈R^I.

1 That the concept≤n R.(¬A) is positive should not be a surprise, as∀R.Ais equiv- alent to≤0R.(¬A).

(R◦S)^I =R^I◦S^I (RtS)^I =R^I∪S^I (R^∗)^I = (R^I)^∗

(C?)^I ={hx, xi |C^I(x)}

ε^I ={hx, xi |x∈∆^I} U^I =∆^I×∆^I (R⁻)^I = (R^I)⁻¹

>^I =∆^I

⊥^I =∅ (¬C)^I =∆^I\C^I (CtD)^I =C^I∪D^I (CuD)^I =C^I∩D^I

{a}^I ={a^I}

(∃r.Self)^I ={x∈∆^I |r^I(x, x)}

(∃R.C)^I={x∈∆^I | ∃y[R^I(x, y) andC^I(y)]

(∀R.C)^I={x∈∆^I | ∀y[R^I(x, y) impliesC^I(y)]}

(≥n R.C)^I={x∈∆^I |#{y|R^I(x, y) andC^I(y)} ≥n}

(≤n R.C)^I={x∈∆^I |#{y|R^I(x, y) andC^I(y)} ≤n}

Fig. 1.Interpretation of complex roles and complex concepts.

Aterminological axiomin LΦ, also called ageneral concept inclusion(GCI) in LΦ, is an expression of the form C v D, where C and D are concepts of LΦ. An interpretation I validates an axiomCvD, denoted byI |=C vD, if C^I⊆D^I.

ATBoxinLΦis a finite set of terminological axioms inLΦ. An interpretation I is amodelof a TBoxT, denoted byI |=T, if it validates all the axioms ofT. An individual assertion in LΦ is an expression of one of the forms C(a) (concept assertion), R(a, b) (positive role assertion), ¬R(a, b) (negative role as- sertion),a=b, anda6=b, whereC is a concept andRis a role inLΦ.

Given an interpretationI, define that:

I |=a=b if a^I =b^I, I |=a6=b if a^I 6=b^I, I |=C(a) if C^I(a^I) holds, I |=R(a, b) if R^I(a^I, b^I) holds,

I |=¬R(a, b) if R^I(a^I, b^I) does not hold.

We say thatI satisfiesan individual assertion ϕifI |=ϕ.

AnABoxinLΦis a finite set of individual assertions inLΦ. An interpretation I is a model of an ABoxA, denoted byI |=A, if it satisfies all the assertions ofA.

3 Bisimulations and Bisimulation-Based Comparisons

Bisimulation is a very useful notion for DLs. It can be used for analyzing ex- pressiveness of DLs (as investigated in [19] and the current paper), minimizing interpretations [8–10] and concept learning in DLs [21, 25, 14, 7, 24, 26]. The fol- lowing definition comes from our joint works [8–10].

Definition 3.1. Let I and I⁰ be interpretations. A binary relation Z ⊆∆^I×∆^I0 is called an L_Φ-bisimulation between I and I⁰ if the following conditions hold for everya∈Σ_I,A∈Σ_C,r∈Σ_R,x, y∈∆^I,x⁰, y⁰∈∆^I0:

Z(a^I, a^I0) (1)

Z(x, x⁰)⇒[A^I(x)⇔A^I0(x⁰)] (2) [Z(x, x⁰)∧r^I(x, y)]⇒ ∃y⁰∈∆^I0[Z(y, y⁰)∧r^I0(x⁰, y⁰)] (3) [Z(x, x⁰)∧r^I0(x⁰, y⁰)]⇒ ∃y∈∆^I[Z(y, y⁰)∧r^I(x, y)], (4) ifI∈Φthen

[Z(x, x⁰)∧r^I(y, x)]⇒ ∃y⁰∈∆^I0[Z(y, y⁰)∧r^I0(y⁰, x⁰)] (5) [Z(x, x⁰)∧r^I0(y⁰, x⁰)]⇒ ∃y∈∆^I[Z(y, y⁰)∧r^I(y, x)], (6) ifO∈Φthen

Z(x, x⁰)⇒[x=a^I ⇔x⁰ =a^I0], (7) ifQ∈Φthen

ifZ(x, x⁰) holds then, for every role namer, there exists a bijection h:{y|r^I(x, y)} → {y⁰|r^I0(x⁰, y⁰)}such thath⊆Z, (8) if{Q, I} ⊆Φthen (additionally)

ifZ(x, x⁰) holds then, for every role namer, there exists a bijection h:{y|r^I(y, x)} → {y⁰|r^I0(y⁰, x⁰)}such thath⊆Z, (9) ifU ∈Φthen

∀x∈∆^I∃x⁰∈∆^I0Z(x, x⁰) (10)

∀x⁰∈∆^I0∃x∈∆^IZ(x, x⁰), (11)

ifSelf∈Φthen

Z(x, x⁰)⇒[r^I(x, x)⇔r^I0(x⁰, x⁰)]. (12) By (2⁰), (7⁰) and (12⁰) we denote the conditions obtained respectively from (2), (7) and (12) by replacing equivalence (⇔) by implication (⇒). If the conditions (2), (7) and (12) are replaced by (2⁰), (7⁰) and (12⁰), respectively, then the relation Z is called an LΦ-comparisonbetweenI andI⁰ [10]. 2 As shown in [4], the PDL-like role constructors are “safe” for the conditions (3)-(6). That is, we need to specify these conditions only for atomic roles, and as a consequence, they also hold for complex roles.

Definition 3.2. A conceptCin LΦ isinvariantforLΦ-bisimulation if, for any interpretation I,I⁰ and any LΦ-bisimulation Z between I and I⁰, if Z(x, x⁰) holds thenx∈C^I iffx⁰∈C^I0. A TBoxT inL_ΦisinvariantforL_Φ-bisimulation if, for every interpretationsI andI⁰, if there exists anL_Φ-bisimulation between I andI⁰ then I is a model of T iffI⁰ is a model of T. The notion of whether an ABox inLΦ isinvariant forLΦ-bisimulation is defined similarly. 2

Definition 3.3. An interpretationIis said to beunreachable-objects-free(w.r.t.

the considered language) if every element of∆^Iis reachable from somea^I, where a∈Σ_I, via a path consisting of edges being instances of basic roles. 2

The following theorem comes from our joint work [8].

Theorem 3.4.

1. All concepts in LΦ are invariant forLΦ-bisimulation.

2. IfU ∈Φ then all TBoxes inLΦ are invariant forLΦ-bisimulation.

3. LetT be a TBox inLΦ andI,I⁰ be unreachable-objects-free interpretations (w.r.t.LΦ) such that there exists anLΦ-bisimulation betweenI andI⁰. Then I is a model of T iffI⁰ is a model ofT.

4. LetAbe an ABox inLΦ. IfO∈ΦorAcontains only assertions of the form C(a)thenA is invariant forLΦ-bisimulation.

Definition 3.5. A conceptC ofLΦ ispreserved byLΦ-comparisonsif, for any interpretations I, I⁰ and any LΦ-comparison Z between I and I⁰, if Z(x, x⁰)

holds andx∈C^I thenx⁰∈C^I0. 2

The following theorem comes from our joint work [10].

Theorem 3.6. All concepts of L^pos_Φ are preserved byLΦ-comparisons.

4 Comparing the Expressiveness of Description Logics

Definition 4.1. Two conceptsC andDareequivalentif, for every interpreta- tion I, C^I =D^I. Two TBoxes T1 and T2 are equivalent if, for every interpre- tationI,I is a model ofT1 iffI is a model ofT2. Two ABoxes A1 andA2 are equivalentif, for every interpretationI,I is a model ofA1iffIis a model ofA2. Definition 4.2. We say that a logicL1 is at most as expressive as a logic L2

w.r.t. concepts (resp. positive concepts, TBoxes, ABoxes), denoted byL1≤CL2

(resp. L1 ≤P C L2, L1 ≤T L2, L1 ≤A L2), if every concept (resp. positive concept, TBox, ABox) in L1 has an equivalent concept (resp. positive concept, TBox, ABox) in L2.

We say that a logic L₂ is more expressive than a logic L₁ (or L₁ is less expressive than L₂) w.r.t. concepts (resp. positive concepts, TBoxes, ABoxes), denoted by L₁ <_C L₂ (resp. L₁ <_{P C} L₂, L₁ <_T L₂, L₁ <_A L₂), if L₁ ≤_C L₂ (resp. L1 ≤P C L2, L1 ≤T L2, L1 ≤A L2) and L2 6≤C L1 (resp. L2 6≤P C L1,

L26≤T L1,L26≤AL1). 2

The following proposition clearly holds.

Proposition 4.3. If a logic L₁ is at most as expressive as a logic L₂ w.r.t.

concepts (resp. positive concepts, TBoxes, ABoxes) and a logic L₂ is at most as expressive as L3 w.r.t. concepts (resp. positive concepts, TBoxes, ABoxes) then L1 is at most as expressive as L3 w.r.t. concepts (resp. positive concepts, TBoxes, ABoxes).

Lemma 4.4. Let Φ₁ andΦ₂ be sets of DL-features such that Φ₁ ⊆Φ₂. Denote L₁=L_Φ1 andL₂=L_Φ2. Let I,I⁰ be interpretations andZ anL₁-bisimulation between I andI⁰.

1. IfL1≤CL2,x∈∆^I, x⁰ ∈∆^I0, Z(x, x⁰)holds, and there exists a conceptC ofL2 such that x∈C^I butx⁰6∈C^I0, thenL1<CL2.

2. Suppose that U ∈ Φ₁ or both I and I⁰ are unreachable-objects-free. If L1≤T L2 and there exists a TBox T in L2 such that I is a model of T butI⁰ is not, thenL1<_T L2.

3. Suppose O∈Φ₁. IfL₁≤_AL₂ and there exists an ABox A in L₂ such that I is a model of AbutI⁰ is not, thenL₁<_AL₂.

Proof. Consider the first assertion. Suppose L₁ ≤_C L₂, x ∈ ∆^I, x⁰ ∈ ∆^I0, Z(x, x⁰) holds and there exists a conceptCofL2such thatx∈C^Ibutx⁰ 6∈C^I0. We prove thatL2 6≤C L1. For the sake of contradiction, supposeL2≤C L1. It follows that there exists a conceptC⁰ofL1that is equivalent toC. Thus,x∈C^0I butx⁰6∈C^0I0. Hence,C⁰is not invariant forZ, which contradicts Theorem 3.4(1).

Therefore,L1<CL2.

Consider the second assertion. Suppose L1 ≤T L2 and there exists a TBox T inL2such thatI is a model ofT butI⁰ is not. We prove thatL26≤T L1. For the sake of contradiction, supposeL2≤T L1. It follows that there exists a TBox T⁰ inL1that is equivalent to T. Thus, I is a model ofT⁰ butI⁰ is not, which contradicts Theorem 3.4(2) or Theorem 3.4(3). Therefore,L1<_T L2.

Consider the third assertion. SupposeL1 ≤A L2 and there exists an ABox A in L2 such that I is a model ofA but I⁰ is not. We prove thatL2 6≤A L1. For the sake of contradiction, supposeL₂≤_AL₁. It follows that there exists an ABoxA⁰ inL₁ that is equivalent toA. Thus, I is a model ofA⁰ but I⁰ is not, which contradicts Theorem 3.4(4). Therefore,L₁<_AL₂. 2 Lemma 4.5. Let Φ₁ andΦ₂ be sets of DL-features such that Φ₁ ⊆Φ₂. Denote L1 =LΦ₁ andL2 =LΦ₂. LetI,I⁰ be interpretations and Z an L1-comparison between I and I⁰. If L1 ≤P C L2, x ∈ ∆^I, x⁰ ∈ ∆^I0, Z(x, x⁰) holds, and there exists a positive conceptCofL2such thatx∈C^I butx⁰6∈C^I0, thenL1<P CL2. Proof. SupposeL1≤P C L2, x∈∆^I,x⁰ ∈ ∆^I0, Z(x, x⁰) holds and there exists a positive concept C of L2 such that x ∈ C^I but x⁰ 6∈ C^I0. We prove that L26≤P CL1. For the sake of contradiction, suppose L2 ≤P C L1. It follows that there exists a positive concept C⁰ of L1 that is equivalent to C. Thus,x∈C^0I butx⁰6∈C^0I0. It follows thatC⁰ is not preserved byZ, which contradicts Theo-

rem 3.6. Hence,L1<P CL2. 2

From now on, we assume thatΣC and ΣR are not empty and ΣI contains at least two individual names. Let{a, b} ⊆ΣI,A∈ΣC andr∈ΣR.

Lemma 4.6.

1. For any pairhL1,L2iamonghLI,LOQUSelfi,hLQ,LIOUSelfi,hL_Self,LIOQUi, we have that:L16≤CL2, L16≤P C L2, L16≤T L2, L16≤AL2.

I

a^I:A b^I

u1 u2

I⁰

a^I0:A b^I0 v1

LI vs.

LOQUSelf

C=∀r∀r⁻¹.A

I

a^I :A u

I⁰

a^I0 :A v1 v2

LQvs.

LIOUSelf

C= (≤1r.¬A)

I

a^I:A u1 u2

I⁰

a^I0 :A v1 v2

LSelf vs.

LIOQU

C=∃r∃r.Self

I

a^I=b^I:A u

I⁰

a^I0 :A b^I0 :A

v1 v2

LO vs.

LIQUSelf

C={b}

I

a^I:A

I⁰

a^I0 :A v LU vs.

LIOQSelf

C=∀U.A

Fig. 2.An illustration for Lemma 4.6.

2. L_O6≤_CL_IQUSelf, L_O6≤_{P C}L_IQUSelf, L_O6≤_T L_IQUSelf. 3. LU 6≤CLIOQSelf, LU 6≤P C LIOQSelf, LU 6≤ALIOQSelf.

Proof. Let us compareL_I withL_OQUSelf. Consider the interpretationsI,I⁰and the relationZshown in the first part of Figure 2. The arrows denote the instances of rin I and I⁰. The instances of Ain I andI⁰ are explicitly indicated in the figure. LetB^I =B^I0 =∅for allB ∈ΣC\ {A},s^I=s^I0 =∅for alls∈ΣR\ {r}, and c^I = a^I, c^I0 = a^I0 for all c ∈ ΣI \ {a, b}. The dotted lines in the figure indicate the instances of a binary relationZ⊆∆^I×∆^I0. It can be checked that Z is anLOQUSelf-bisimulation betweenI andI⁰. Consider the positive concept C=∀r∀r⁻¹.AofLI. Clearly,a^I ∈C^Ibuta^I0 6∈C^I0. By Theorem 3.4(1),Cdoes not have any equivalent concept inLOQUSelf. Hence,LI 6≤C LOQUSelf. As Z is also anLOQUSelf-comparison betweenIandI⁰, by Theorem 3.6,Cdoes not have any equivalent positive concept in LOQUSelf either. Hence,LI 6≤P C LOQUSelf. Consider the TBoxT ={AvC}. SinceI |=T butI⁰6|=T, by Theorem 3.4(3), T does not have any equivalent TBox in LOQUSelf. Hence LI 6≤T LOQUSelf. Consider the ABox A={C(a)}. SinceI |=Abut I⁰ 6|=A, by Theorem 3.4(4), Adoes not have any equivalent ABox inL_OQUSelf. HenceL_I 6≤_AL_OQUSelf.

The proofs for the other pairs of logics can be done similarly, usingI,I⁰,C specified in the next parts of Figure 2. For the parts without the presence ofb,

letb^I=a^I andb^I0 =a^I0. 2

Theorem 4.7. Let ΦandΦ⁰ be subsets of{I, O, Q, U,Self}.

1. IfΦ⊂Φ⁰ thenL_Φ<_CL_Φ⁰ andL_Φ<_{P C} L_Φ⁰. 2. IfΦ6⊆Φ⁰ thenLΦ6≤CLΦ⁰ andLΦ6≤P C LΦ⁰. 3. IfΦ⊂Φ⁰ andΦ⁰\Φ6={U} thenLΦ<T LΦ⁰. 4. IfΦ6⊆Φ⁰ andΦ\Φ⁰6={U} thenLΦ6≤T LΦ⁰. 5. IfΦ⊂Φ⁰ andΦ⁰\Φ6={O} thenLΦ<ALΦ⁰. 6. IfΦ6⊆Φ⁰ andΦ\Φ⁰6={O} thenLΦ6≤ALΦ⁰.

Proof. Consider the first assertion and suppose Φ ⊂ Φ⁰. Since every concept (resp. positive concept) of L_Φ is also a concept (resp. positive concept) of L_Φ⁰, we have that LΦ ≤C LΦ⁰ (resp. LΦ ≤P C LΦ⁰). Since Φ⁰ \Φ 6= ∅, at least one feature amongI,O,Q,U,Self belongs toΦ⁰\Φ. Consider the caseI∈Φ⁰\Φ.

The cases of other features are similar and omitted. For the sake of contradiction, suppose LΦ⁰ ≤C LΦ (resp.LΦ⁰ ≤P CLΦ). SinceLI ≤CLΦ⁰ (resp.LI ≤P C LΦ⁰) andLΦ≤CLOQUSelf(resp.LΦ≤P C LOQUSelf), it follows thatLI ≤C LOQUSelf

(resp.LI ≤P CLOQUSelf), which contradicts Lemma 4.6. Therefore, LΦ<CLΦ⁰

(resp.LΦ<P CLΦ⁰).

Consider the second assertion and suppose Φ 6⊆ Φ⁰. Since Φ\Φ⁰ 6= ∅, at least one feature among I,O, Q,U, Self belongs to Φ\Φ⁰. Consider the case I ∈ Φ\Φ⁰. The cases of other features are similar and omitted. For the sake of contradiction, suppose LΦ ≤C LΦ⁰ (resp. LΦ ≤P C LΦ⁰). Since LI ≤C LΦ

(resp.LI ≤P C LΦ) andLΦ⁰ ≤C LOQUSelf (resp.LΦ⁰ ≤P C LOQUSelf), it follows that L_I ≤_CL_OQUSelf (resp.L_I ≤_{P C} L_OQUSelf), which contradicts Lemma 4.6.

Therefore,L_Φ6≤_CL_Φ⁰ (resp.L_Φ6≤_{P C}L_Φ⁰).

Consider the third assertion and suppose Φ ⊂ Φ⁰ and Φ⁰ \Φ 6= {U}. At least one feature among I, O, Q, Self belongs to Φ⁰ \Φ. Consider the case I ∈ Φ⁰\Φ. The cases of other features are similar and omitted. Since Φ ⊂Φ⁰,

L_Φ≤_T L_Φ⁰. For the sake of contradiction, supposeL_Φ⁰ ≤_T L_Φ. SinceL_I ≤_T L_Φ⁰ and L_Φ ≤_T L_OQUSelf, it follows that L_I ≤_T L_OQUSelf, which contradicts Lemma 4.6. Therefore, L_Φ<_T L_Φ⁰.

Consider the fourth assertion and supposeΦ6⊆Φ⁰andΦ\Φ⁰6={U}. At least one feature amongI,O,Q,Selfbelongs toΦ\Φ⁰. Consider the caseI∈Φ\Φ⁰. The cases of other features are similar and omitted. For the sake of contradiction, suppose L_Φ ≤_T L_Φ⁰. Since L_I ≤_T L_Φ and L_Φ⁰ ≤_T L_OQUSelf, it follows that LI ≤T LOQUSelf, which contradicts Lemma 4.6. Therefore,LΦ6≤T LΦ⁰.

Consider the fifth assertion and suppose Φ ⊂ Φ⁰ and Φ⁰ \Φ 6= {O}. At least one feature among I, Q, U, Self belongs to Φ⁰ \Φ. Consider the case I ∈ Φ⁰\Φ. The cases of other features are similar and omitted. Since Φ ⊂Φ⁰, L_Φ≤_AL_Φ⁰. For the sake of contradiction, supposeL_Φ⁰ ≤_AL_Φ. SinceL_I ≤_AL_Φ⁰ and LΦ ≤A LOQUSelf, it follows that LI ≤A LOQUSelf, which contradicts Lemma 4.6. Therefore, LΦ<ALΦ⁰.

Consider the last assertion and supposeΦ6⊆Φ⁰andΦ\Φ⁰6={O}. At least one feature amongI,Q,U,Selfbelongs toΦ\Φ⁰. Consider the caseI∈Φ\Φ⁰. The cases of other features are similar and omitted. For the sake of contradiction, suppose LΦ ≤A LΦ⁰. Since LI ≤A LΦ and LΦ⁰ ≤A LOQUSelf, it follows that LI ≤ALOQUSelf, which contradicts Lemma 4.6. Therefore, LΦ6≤ALΦ⁰. 2

Definition 4.8. We define ALC to be the sublogic of ALCreg such that the role constructors ε, R◦S, RtS, R^∗ and C? are disallowed. We say that L is a sublogic of ALCreg that extends ALC, denoted ALC ≤ L ≤ ALCreg, if it extends ALC with some of those role constructors. For Φ ⊆ {I, O, Q, U,Self}

and ALC ≤ L ≤ ALCreg, let LΦ and L^pos_Φ be defined as usual in the spirit of

Definitions 2.1 and 2.2. 2

Corollary 4.9. Let L be any sublogic of ALC_reg that extends ALC and let Φ andΦ⁰ be subsets of{I, O, Q, U,Self}.

1. IfΦ⊂Φ⁰ thenL_Φ<_CL_Φ⁰ andL_Φ<_{P C} L_Φ⁰. 2. IfΦ6⊆Φ⁰ thenLΦ6≤CLΦ⁰ andLΦ6≤P C LΦ⁰. 3. IfΦ⊂Φ⁰ andΦ⁰\Φ6={U} thenLΦ<T LΦ⁰. 4. IfΦ6⊆Φ⁰ andΦ\Φ⁰6={U} thenLΦ6≤T LΦ⁰. 5. IfΦ⊂Φ⁰ andΦ⁰\Φ6={O} thenLΦ<ALΦ⁰. 6. IfΦ6⊆Φ⁰ andΦ\Φ⁰6={O} thenLΦ6≤ALΦ⁰.

Proof. Just observe that the conceptsClisted in Figure 2 do not use any of the role constructorsε,R◦S,RtS,R^∗,C?. All the lemmas and theorems given in this paper hold for the case whenLΦis a sublogic ofALCreg that extendsALC.

Their proofs do not require any change. 2

Figure 3 illustrates the relationship between the expressiveness of all the DLs that extendL, whereALC ≤ L ≤ ALC_reg, with any non-empty combination of the featuresI,O,Q,U,Self. Note that the problems whetherLΦ<T LΦ⁰ when Φ⁰\Φ={U}and whetherLΦ<ALΦ⁰ whenΦ⁰\Φ={O}remain open.

L

LQ LU

LO

LI LSelf

LOQ LOU

LISelf

LIU

LIQ

LIO LOSelf LQU LQSelf LUSelf

LIOQ LIOU LIOSelf LIQU LIQSelf LIUSelf LOQU LOQSelf LOUSelf LQUSelf

LIOUSelf

LIOQSelf

LIOQU LIQUSelf LOQUSelf

LIOQUSelf

Fig. 3.Comparing the expressiveness of description logics, whereALC ≤ L ≤ ALCreg. If there is a path from a logic L2 down to a logic L1 that contains either a normal edge or at least two edges thenL2 is more expressive thanL1 w.r.t. concepts, positive concepts, TBoxes and ABoxes. If the path is a dotted edge thenL2is more expressive thanL1 w.r.t. concepts, positive concepts and TBoxes. If the path is a dashed edge thenL2 is more expressive thanL1 w.r.t. concepts, positive concepts and ABoxes.

5 Conclusions

Analyzing the expressiveness of logics is a theoretical topic that has attracted a lot of logicians. In this paper we have studied the expressiveness of large classes of DLs. Namely, we have provided results about separating the expressiveness of the DLs that extendL, whereALC ≤ L ≤ ALCreg, with any combination of the features I, O, Q, U, Self. Our separation results are w.r.t. concepts, positive concepts, TBoxes and ABoxes. Our work differs significantly from all of [2, 5, 6, 19, 20], as the class of considered DLs is much larger than the ones considered in those works and our results about separating the expressiveness of DLs are obtained not only w.r.t. concepts and TBoxes but also w.r.t. positive concepts and ABoxes.

Acknowledgements

This work was supported by the Polish National Science Centre (NCN) under Grant No. 2011/01/B/ST6/02759. I am grateful to my supervisor, dr hab. Linh Anh Nguyen, for his guidance. I would also like to thank the anonymous reviewers for comments and suggestions.
