Free energy of low temperature antiphase structures in a FCC nearest-neighbour antiferromagnetic Ising model by the Monte Carlo method

HAL Id: jpa-00211117

https://hal.archives-ouvertes.fr/jpa-00211117

Submitted on 1 Jan 1989

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are pub- lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

Free energy of low temperature antiphase structures in a FCC nearest-neighbour antiferromagnetic Ising model

by the Monte Carlo method

F. Livet

To cite this version:

F. Livet. Free energy of low temperature antiphase structures in a FCC nearest-neighbour antiferro- magnetic Ising model by the Monte Carlo method. Journal de Physique, 1989, 50 (19), pp.2983-2990.

�10.1051/jphys:0198900500190298300�. �jpa-00211117�

Free _energy of low temperature antiphase structures in a FCC

nearest-neighbour antiferromagnetic Ising ^model by ^{the Monte}

Carlo method

F. Livet

Laboratoire de Thermodynamique ^et Physico-Chimie Métallurgique, ENSEEG, ^B.P. 75,

38042 Saint-Martin-d’Hères, ^France

(Reçu ^{le 10} février 1989, révisé le 3 mai 1989, accepté ^{le 6} juin 1989)

Résumé.

Les alliages CFC à mise

ordre (25 ^{et 50} %) ^sont modélisés par

hamiltonien

d’Ising à interaction de premier ^voisin antiferromagnétique. Par la méthode de Monte Carlo,

montre que la dégénérescence ^{à T}

^{0 des} structures à antiphases construites à partir ^de L12 ^et L10 ^{est levée à} T ~ 0. Les états les plus ^{stables sont}

antiphase. L’énergie ^libre superficielle ^des antiphases ^{est calculée}

fonction de la température ^et de la distance entre

antiphases. ^A partir des résultats obtenus,

discute les diverses manières d’utiliser la méthode de Monte Carlo.

Abstract.

Binary ordering ^FCC alloys of 25 and 50 at % concentrations

modelled by

antiferromagnetic ^nearest neighbour Ising ^model. By the Monte Carlo method, it is shown that the antiphase degeneracy ^of L12 ^and L10 structures at T

0 is raised at T ~ 0. The most stable states have

antiphases. The surface free energy of the antiphases is calculated and its variations

versus

T and

the distance between antiphases

studied. From the results obtained,

discussion is carried out of the various

of the Monte Carlo method.

Classification

Physics ^Abstracts

64.60c

05.50

75.1OH

Introduction.

A lot of alloys ^with high temperature ^{FCC structure} exhibit order-disorder low temperature phase transitions. The model system ^{of such a} behaviour is AuCu [1, 2]. ^This system ^{has low} temperature L12 ^and Llo structures in the range of 25 % and 50 % atomic concentrations, respectively.

The observed phase diagram ^{can here be} roughly ^described by ^an Ising nearest-neighbour

Hamiltonian [3].

Since this Hamiltonian leads to strong degeneracies of the ordered states at T

0, ^{it is an}

excellent tool to compare the various approximations ^{used to} calculate the entropy ^{of the} phases ^{at T #: 0.}

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphys:0198900500190298300

2984

The phase diagram obtained from (1) has been calculated by ^the Bragg-Williams ^{mean field} approximation [4], by the cluster variational method [5, 6], by ^{low and} high temperature expansions [7] ^and by the Monte Carlo method [3, ^{8, 9,} 10].

Close to the 25 % and 50 % concentrations, ^the degeneracy appears among the various

antiphase structures built from L12 ^and Llo with any ^set of (1/2 1/2 0) antiphase ^{vectors and}

with the antiphase planes perpendicular ^{to the} (0 0 1) ^direction (see Fig. 1). Some of these

antiphase structures are observed in the CuAu system ^{close to the} ordering temperature [2].

The aim of this paper is ^to show how the Monte Carlo method can provide precise ^{values of}

the free energy of these various structures and to compare their relative stability. ^The

notation used in the study of ANNNI model (see ^Ref. [11]) is also used here : 00 >

corresponds ^{to no} antiphase, (i j... ) corresponds ^{to a} periodic ^{structure with two} antiphases separated by i periods of the FCC lattice and the next two separated by j periods...

Fig. 1.

^{Sketch of some} structures studied.

1. Description of the calculations.

The general method has been described in [12], following ^a previous work of Vanneau (see

Ref. [13]).

1.1 M.C. SIMULATIONS.

All calculations reported ^{here are carried} out at constant atomic concentrations (Canonical Ensemble) ^{on a} lattice of N

2 048 atoms. This lattice is initially

in one of the completely ^ordered structures studied (« ground states ») L12 (25 %) ^or Llo (50 % ) ; ^{and the} (11), (22), (44 ) ^antiphase structures corresponding ^{to these two}

concentrations. These are the only structures which can be studied here (L

^{8 with}

2 048 FCC atoms).

The Metropolis algorithm [14] ^{is used to}

equilibrate

^the system ^{at a} given temperature ^T during ⁷ 000 Monte Carlo steps (MCS).

The energy E of the system ^{is then} regularly sampled (E

^{0 in the} completely ^ordered states). Samples ^are carried among ^at least 100 000 MCS (up ^{to 1000 000} MCS).

The 28 first short range order parameters ^{are also} calculated, ^{in order to} verify ^the

metastability of the initial structure. It is observed that the systems studied remain metastable if Ts 0.95 To (assuming kTo/J ^{is 1.81 at 25 % and 1.73 at 50} %). ^At higher temperatures,

irregular antiphases appear, apparently destroying ^the long range order, though ^the energies

remain in the same range.

The number of states of each energy is counted and the result is the normalized distribution

f T(E) ^{for each} structure. This distribution can be written :

where g (E) is the total number of states of energy E of the ^structure and Z (T) ^{is the} partition

function ((3

1 /kB T) ; g (E) is. the density ^{of states of the structure studied.}

From formula (2), g(E) can be obtained and all thermodynamic ^{functions can be} deduced,

if Z(T) is known. Figure 2 shows the distributions fT(E) computed ^{in the} L12 structure at three temperatures (1.4 J, ^1.65 J, 1.72 J).

Fig. ^2.

Distributions f T(E) ^{in the} L12 (25 %) structures at kT/J ^{= 1.4,} 1.6 and 1.72.

1.2 CALCULATION OF Z(T).

Z(T) ^can be calculated from formula (2) if any ^exact value of

g (E) is known :

In practice, gex(E) ^can only be calculated at low E and f T (E ) ^has significant ^{values at these} energies ^{in the case} of the lowest temperatures ^studied (see Fig. 2).

At these temperatures, ^the f T(E) obtained with the various antiphase structures do not differ. For this reason, Z(T) is here assumed to be the same.

On the other hand, gex(E) ^{has a} polynomial expression ^{in N. The} higher ^{order terms of the}

12 first polynomials ^are exactly calculated and their next terms are estimated from Monte Carlo calculations with small systems (i.e. ^{N 2} 048). The latter terms introduced only ^{a few} percent correction on geX (E). In every ^case g (0 ) ^{= 1.}

A least squares fit method has been used ^to determine Z in the finite system studied from

2986

formula (3) :

The values of Z ( T) ^at higher temperatures ^are deduced from the

overlap ^method

^{If two}

distributions fT(E) ^{obtained at T and T’} overlap :

In the case studied (see Fig. 2) ^three temperatures provide ^{an excellent} overlap. ^{Table 1}

shows the values of 11N ^Log (Z(T)/Z(T’)) ^obtained by ^{the least} squares fit method.

Table 1.

1 IN Log Z (T)IZ (T’) ^{in the} different structures studied.

1.3 DENSITY OF STATES.

The density ^{of states} g (E) ^{of each structure} is deduced from formula (2). ^In practice, the function Ig (e) ^is tabulated :

with e

E/NJ.

Figure 3 shows the results obtained in the L12 (25 %) structure. The relative errors can be close to 3 x 10- 4 and only 150 different energy ^{states are} explored in the ordered systems ^with 2 048 atoms. It is observed that the values of Ig (s) ^{are about the same} for the various

antiphases ^{if E 0.08. At} increasing E, increasing differences appear between the

L12 ^and Llo phases (higher Ig ( E )) ^{and the} antiphase ^ones (lower Ig (e». These differences remain nevertheless small : 25 (2) ^{x 10- 5} between the L12 and (11) (D022) structures if

E =

0.2 at 25 %.

1.4 LINEAR EXTRAPOLATION OF Ig ( E ). - In all ordered structures (an exemple ^is given ⁱⁿ

Fig. 3), Ig (s) ^{exhibits a} linear behaviour at e

0.21 :

Fig. ^3.

^{Plot of} Ig (e)

^Ln (g (e ))/ N ^{for the L12} (25 %) ^structure.

The coefficients

and y have been calculated by ^a least squares fit from e

0.21 to

8 ⁼

0.29. The results are given in table II.

Table II.

Linear extrapolations of Ig (e) ^{used in} formula (6).

In this table, ^the

^{HT »} (High Temperature) ^values correspond ^{to a} precise re-calculation of the free energy in the disordered system. ^{In this} calculation, ^{the same} overlapping ^method

has been used as in [12], ^but Z(T) has been corrected from finite size effects :

The correction term is two orders of magnitude higher ^{than the errors} of the calculation. The

same linear behaviour as (6) ^{is observed on the curve} Ig ( E ) ^at

HT » if 0.5

0.58.

In all _cases, linear extrapolations ^of Ig (e) ^with (6) have been used from e

0.24 to

E ⁼

0.58. The validity ^{of these} extrapolations is further discussed.

2. Results.

From Ig (e), ^all thermodynamic ^{functions are deduced} precisely ^{at all} temperatures T 0.99 To.

Figures ⁴ and 5 show the results obtained at 25 % and 50 % respectively. ^{The free} energies

F/N ^are always smaller in thé (oo) ^states. The differencies observed are low (see ^Tab. 1).

2988

Fig. ^4.

Free energy, entropy and energy ^at 25 % composition.

Fig. ^5.

Free energy, entropy and energy ^at 50 % composition.

Only the differences between the oo > and 11 > structures are large enough ^to be visible in the figures given ^and only ^{close to} To. On the other hand, e (T) ^and S(T)/kN ^{are more}

contrasted. In these figures

HT » results are also given.

3. Antiphase ^free energy.

The difference in free energy per ^atom 03B4F(i) ^{between an antiphase} structure i i >

(i = 1, 2, 4 ) ^and the oo > phase ^{is here} always positive ^{and it can be} expressed ^{as a surface}

Fig. 6. Fig. 7.

Fig. ^6.

Antiphase free energy f S (i , T) ^{at 25 %.}

Fig. ^7.

Antiphase free energy fs(1 , T ) ^{at 50 %.}

free _{energy :}

if the unit surface is a2 (a ^{is the lattice} parameter ^{of the}

^{HT » FCC} lattice). Figures ^{6 and 7}

show the variations of fs(1 ) ^versus T and i for the two concentrations studied.

4. Discussion.

CVM [6] ^{and low} temperature expansions [15] have shown that the 00) structures are more

stable than the (11) structures. This result compares well with, ^for instance, ^{CVM result} given ⁱⁿ [6] : 03B4F (1 )/J

^{8.78 x 10-4 at} kB ^T = 1.8 and C

25 %. The present ^{result is}

6F(1)/7= 1.1 ^{x 10- 3.}

It appears here that the 00) structures are always ^{the most stable ones. In the case of the} Llo structure, fs(1) ~ fs(2). ^{In the case of} L12, fs(2) ^is significantly higher ^than f s (1 ). ^As the lattice used in our Monte Carlo study ^is relatively small, ^the given ^{values of} fs(4) ^{are not} very reliable.

Now, ^{let us} discuss the linear behaviour of Ig (s) observed in ordered systems ^if 0.2

0.29 and in disordered systems ^{if 0.5}

^0.58 (see ^also [16]).

The slopes y of Ig ( E ) ^{for the ordered} structures (Tab. II) ^are higher ⁱⁿ the 00) structures.

In the latter case, they ^are very close (although lower) ^{to the}

^HT

(disordered) ^{values of y.}

On the other hand, ^the corresponding values of

are also the closest between the

00) ^{and the}

^HT

values. These results suggest that, though ^{the 0.29}

^0.5 region ^is

not explored ^here, there exists a continuity ^of Ig (s) between the fluctuations of

(oo) ^{ordered states} and the « HT » fluctuations. The shape of this continuous function

lgo (e) ^should then be linear in the whole 0.21

0.58 _range. This brings ^a justification ^of

the linear extrapolations ^{uses in our} calculations. It is suggested ⁱⁿ [16] that this behaviour is related to the first order character of the transition studied here.

If this function lgo ( E ) is linear from _{El =} 0.21 to E2 0.58, ^{it can be} easily ^{shown that}

table II gives ^{estimates of :}

Log (Z (To ) )/N

^a, J/kB To

y and of the energy jump ^{at the} transition: à e = 03B52 - E1.

From table II, kB To/J =1. 81 ^at 25 % and 1.73 at 50 %.

In a study ^with only ² 048 atoms, ^the hydrodynamic slowing ^{down at the} transition is not

strong : ^no hysteresis is observed here. Moreover, it is observed that if the disordered states

are sampled ^at To ^{T 1.02} To, ^{the curve} f T (E ) ^{has a}

^double hump » shape (sometimes

called a « camel’s back »). Here, ^it happens ^that J/kB T is intermediate between yyçr (or y (oo) ^and yantiphases (see ^Tab. II). ^{In such a case, if} 03B51

E2, the Monte Carlo

sampling explores ^two types ^{of states :} (i) disordered states with energy probabilities proportional ^to exp ((y HT - 03B2 ) E) (increasing exponential) ^and (ii) ^{ordered states with}

numerous antiphases, ^whose probability distribution is close to a decreasing exponential. ^The

latter states have a strong probability ^of occurring ^{in a finite} system. ^For instance, ^{it can be}

shown in our case (L

8 ) ^{that the} ( 11 ) structures, having ^a higher multiplicity, ^{are more} probable ^at every T To ^than the 00) ^structure.

The occurrence of the antiphase structures, if the disordered system ^is slowly cooled, ^leads

to overestimate of the ordering temperatures (as ⁱⁿ [8]). ^{The most stable} phase ^{cannot be}

obtained by ^{this method} and the free energy of the ordered structures cannot be calculated.

The effects described above should decrease on increasing ^L. Unfortunately, ^{due to the} hydrodynamic showing down, ^the exploration ^of Ig (E) ^between el and E2 becomes then

extremely ^difficult.

2990

Acknowledgments

The author wants to thank A. Finel, ^F. Ducastelle, ^C. Bichara, ^{J. P.} Gaspard, G. Martin and F. Bley ^for having stimulated this work.

References

[1] ^HANSEN M., Contribution of binary alloys (M. ^{C. Graw Hill,} New-York) ^1958.

[2] ^{WATANABE D.,} FISHER P. M. J., ^J. Phys. ^Soc. Jpn ²⁰ (1965) ^2170.

[3] ^BINDER K., Phys. ^{Rev. Lett. 45} (1980) ^811.

[4] ^{SHOCKLEY W., J. Chem.} Phys. ⁶⁰ (1974) ^1071.

[5] VAN BALL C. M., Physica (Utredit) ⁶⁴ (1973) ^571.

[6] ^{FINEL A.,} DUCASTELLE F., Europhys. ^{Lett. 1} (1986) ^135.

[7] ^{STYER D. F.,} Phys. ^{Rev. B 32} (1985) ^393-399.

[8] PHANI M. K. and LEBOWITZ J. L., Phys. ^{Rev. B 21} (1980) ^4027-4037.

[9] ^{ACKERMANN H., CRUSIUS S., INDEN} G., ^{Acta Met.}

[10] ^{DIEP H.} T., ^GHAZALIA A., ^BERGE B., ^LALLEMAND P., Europhys. ^{Lett. 2} (1986) ^603.

[11] ^{SELKE W.,} Phys. Rep. ¹⁷⁰ (1988) ^213.

[12] ^BICHARA C., GASPARD J. P., MATHIEU J. C., Phys. Rev. Lett. A 119 (1987) ^462.

[13] ^{TORRIE G.} M., VALLEAU J. P., ^Chem. Phys. ^{Lett. 28} (1974) ^578.

[14] METROPOLIS N., ROSENBLUTH A. W., ROSENBLUTH M. N., TELLER A. H. and TELLER E., ^J.

Chem. Phys. ²¹ (1953) ^1087.

[15] ^DANIELAN A., Phys. Rev. A 133 (1964) ^1344.

[16] ^BICHARA C., ^Thèse d’Etat, Marseille, ^France (1987).
