SOME RECENT DEVELOPMENTS IN MAGNETISM IN CZECHOSLOVAKIA
By LUBO0160 VALENTA,
Faculty of Technical and Nuclear Physics, Prague, Czechoslovakia.
Résumé. 2014 On présente
unrésumé de quelques-uns des derniers résultats obtenus
enmagné-
tisme
enTchécoslovaquie. Il
concerneles questions suivantes : 1. Relaxations magnétiques dans MnFe2O4. 2. Variations de la largeur de la raie de la résonance
enfonction de l’aimantation spontanée de ferrites polycristallins de manganèse et de manganèse et de zinc et la vérification
expérimentale de la théorie de Clogston et al. 3. Une nouvelle possibilité d’interprétation des dévia-
tions de la loi pour la perméabilité initiale dans le
casdu mécanisme de rotation du vecteur d’aiman- tation. 4. L’approche à la saturation. 5. Une nouvelle méthode de
mesurede l’effet magnétocalorique
des ferrites. 6. L’introduction conséquente de l’idée de L. Néel des sous-réseaux magnétiques dans
la théorie de Heisenberg et
sagénéralisation pour le
casde ferrimagnétisme et antiferromagnétisme
et des lames minces de spin arbitraire. 7. L’influence de l’inhomogénéité- du champ démagnétisant
sur
la résonance ferromagnétique. 8. La théorie de la structure des domaines élémentaires
auxlames minces de MnBi. 9. L’interprétation de l’hystérésis du coefficient démagnétisant balistique.
10. Sur la définition du paramètre p caractérisant les dimensions des échantillons nonellipsoïdaux.
11. La désaimantation des matériaux ferromagnétiques par
unchamp alternatif magnétique.
Abstract. 2014 Some
newresults obtained recently in magnetism in Czechoslovakia
arebriefly
summarized : 1. Magnetic relaxation in MnFe2O4. 2. Dependence of the line breadth of the
resonance line
onthe spontaneous magnetization in polycrystalline manganese and manganese
zinc ferrites and the question of the experimental verification of the theory of Clogston and al.
3. A
newpossibility of explaining the deviations from the initial permeability law for the
caseof rotation of the vector of the spontaneous magnetization. 4. Concerning the spontaneous magne- tization
nearsaturation. 5. A
newmethod for measuring of the magnetocaloric effect in ferrites.
6. About the consequent introduction of the Néel’s idea of the magnetic sublattices in Heisenberg’s theory and its generalization for ferrimagnetics, antiferromagnetics and thin films with
anarbi- trary spin. 7. Influence of the inhomogenity of the demagnetizing field
onthe ferromagnetic
resonance.
8. The theory of the domain structure in thin films of MnBi. 9. The explanation
of the hysteresis of the ballistic demagnetizing factor. 10. Concerning the definition of the para- meter p characterizing the non-ellipsoidal specimens. 11. Demagnetization of ferromagnetic
materials by
analternating magnetic field.
JOURNAL DE
PHYSIQUE 20, 1959,
1. Introduction.
-In this paper
abrief sum-
mary is given of some new results obtained recently
in magnetism in Czechoslovakia. Most of them
are as yet unpublished, some are preliminary
results or concern
apart of à wider programme. -
In addition some papers are mentioned which were
published in Czech or Slovak only.
2. Ferrimagnetism and antiferromagnetism.
-a) EXPERIMENTAL PART.
-1. Krupicka and
Vilim [1] have recently found well pronounced
relaxations of the Richter type in manganese fer- rites with the general formula
MnFe204.xMn3O4-YO (0 x 0,37).
The activation energies obtained from their experi-
ments are in good agreement with those obtained from acoustical relaxation effects [2], [3]. Measu-
rements of the temperature dependence of the
electrical conductivity, made recently by Zâvéta [4]
also show similar results with one exception in the
stoichiometric ferrite MnFe204, where the acti-
vation energy measured was about 0,08 eV while
that obtained from magnetic relaxation is approxi- mately 0,3 eV. It seems to be reasonable to con-
clude from this that there exist some divalent ions
of Fe in MnFe2O4 and hence some manganese ions with higher valence than two.
From the preliminary results it seems probable
that the presence of divalent iron ions causes some new relaxations. Hence the relaxation spectrum consists, at least, of two bands corresponding to
the changes of valence of iron resp. manganese ions. In the range of frequencies used up to now, the corresponding maxima are superposed, and
their existence may be inferred from the asymetry
of the temperature dependence of tg 8, where 8
denotes the loss angle.
Because of the rather lower activation energy in the relaxation caused by iron ions,
asuperposition
of iron and manganese maxima appears with increas-
ing frequency. A lowering of the effective acti- vation energy follows in consequence. In this way the decrease of the activation energy in manganese ferrite with the decreasing oxygen content may also be explained (see table I).
It should be mentioned, that relaxations of the
same type have been found by Krupicka in manga-
nese zinc ferrites and in manganese magnesium
ferrites also.
2. Reinvestigating his recent results [5], [6]
Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphysrad:01959002002-3041400
415 TABLE 1
obtained on polycrystalline manganese and man- ganese zinc ferrites, Krupicka bas found
awell-
defined linear dependence of v’M: (Ma is the spon- taneous magnetization)
onAH (line breadth of the
resonance line) in the region of temperatures
-180 °C-0 °C (see fit. 1). The examined speci-
FIG. 1.
-Dependence of the line breadth
on
spontaneous magnetization.
niens differ in the content of the oxygen which
implies
adifférence in Curie temperature (81 OC
resp. 111 OC). Nevertheless the curves for the
spontaneous.magnetization plotted against reduced temperature T/Tg were the same.
These results are in good agreement with the theory proposed for monocrystals by Clogston et
al. [7] where a linear increase of AH with VE,
and for the same materials with the différent Curie
temperatures the decrease with increasing T, is to
be expected. For the comparison of the theory
with experiment it is supposed that, due to the low
value of the crystal anisotropy, the AH in poly- crystals is mainly determined by the size of the individual crystals. Furthermore the slope of the
curves in fig. 1 should, according to [7], be pro-
portional to the mean square deviation of the effective exchange field which really seems to be greater in specimens with the higher content of
oxygen and hence of the vacancies in the lattice.
3. An interesting observation concerning the
initial permeability in sintered -ferrites has been made by Sternberk. It concerns the deviations from the usually used law
where uo is the initial permeability, K the first anisotropy constant and k
aconstant more closely
defined by the nature of the crystal anisotropy.
As is known, (1) has been derived for the process of the rotation of the vector of magnetization and
the deviations are interpreted as caused by the
mechanism of the motion of Bloch walls. Stern-
berk’s idea is the following : One may suppose the ferrite in the first approximation to be com- posed of crystal grains situated in the hollows of the surrounding medium. The effective internal field is then the sum of the external field He plus
the Lorentz’ field 4 M. Sternberk has shown the Lorentz’ field u 3 7rM. Sternberk has shown
(see also [8], [9]) that for the relative volume occu- pied by the ferrite grains lying in the limits
0,75 V 1 and for £ > 10 where uo is the
initial permeability of the tested material Ma J[K[
should normally lie between 1-2. In table II there are compared different values taken from many papers. The agreement with the rather crude model is quite satisfactory.
4. Let us remark, that Sternberk has been led [9]
to similar conclusions also from the investigation
of the behaviour near saturation of some
nickel, manganese and manganese zinc ferrites.
5. The low heat conductivity in ferrites makes the measurement of the magnetocaloric effect in
these materials very difficult. This has been studied classically (see e.g. the papers [10, 11, 12, 13]) using thermo-electrical éléments. Zâveta [14]
has therefore proposed the use of the adiabatic
change of the electrical resistance connected with the change of the magnetic field.
His idea is the following : First of all the depen-
dence of the electrical resistance
onthe tempe-
rature R(T)H-O and R(T)H=Hm is found. Then the
adiabatic change of the resistance (AR)s with
H
=Hmis measured. Nowthe difference between
(dR)s and (OR)T for the isothermic change (see
416
TABLE II
(1) Calculated from the
data
oneffective field of the crystal anisotropy 2Kl/Ms resp. 0,2 KIM..
(2) ) Precise composition unknown.
(8) Measured
onthe powdered material (see Birks [38]).
(4) Calculated
onthe basis of Guillaud’s [47] and Pauthenet’s [46] data using for the density p the value p::: 5 g’/cn13
FiG. 2.
-To the derivation of the Eq. (3).
(fin. 2) enables us to find the required (LlT)B. This
is because
where e is practically the same for R(T)H-o
and R(T)H"’Hm (k is the Boltzmann’s constant).
From the geometry one may see that
If elk is found graphically from (2) then we may find (A T)s from (3).
The applicability of the method has been tested
by Zàvéta
onthe manganese ferrite
MnOFe2O3 + 0,08 Mn3o4 + 0,055 0 (fig.3).
FIG. 3.
-Temperature dependence
of the magnetocaloric effect.
A typical anomaly is seen at the Curie point.
Thus the usefulness of the proposed method is
quite evident.
417
b) THEORY. - 6. The great progress made in the last years in the theory of ferrimagnetism and antiferromagnetism is intimately connected with the use of the idea of the magnetic sublattices as introduced by Néel (see first of all his fundamental papers [15, 16]). The thorough investigation of
the applicatibility of this idea in the theory thus
seems désirable.
The author [17] tried to find what the results
would be if this idea were introduced into Hei-
senberg’s theory when using the modification given by Van Vleck [18]. The hamiltonian used had the usual form for the exchange interaction. The
crystal lattice is supposed to be composed of Néel’s
lattices. Similarly to [19], [20] the existence of the sublattices is characterised quantum-mecha- nically by the supposition that the spins of the particular sublattices have the definite eigenvalues simultaneously. The hamiltonian of this system is formulated in terms of the " rot’ated " spin operators
asused by Oguchi [21]. Using the approximations equivalent to those of Van Vleck [18] one obtains the dependence of the spon- taneous magnetization on the temperature and the intensity of the magnetic field.
The theory includes for this model the theory of
the ferrimagnetism, antiferromagnetism and the theory of thin films proposed recently by the
author [20]. The results obtained are analogous
to those obtained from the molecular field theory
as
given by Néel [16], Yafet and Kittel [22] etc...
and to those obtained by Van Vleck [23] using the
method of Stoner [24]. For the special case
S =1/2 the theory agrees with the theory of
Vlasov and lshmukhametov [19] and with that of the author [20]. The angle between the directions of the magnetization in the sublattices may be
expressed in terms of the exchange integrals.
Hence the principal possibility follows for the
experimental determination of the exchange inte- grals.
The corresponding situation in the region of
low temperatures is
nowbeing investigated.
3. Concerning the influence of the inhomogenity
of the demagnetizing field on ferromagnetic
résonance.
-7. It is interesting to know how the departures from the homogeneity of the magnetics
field within the specimens change the results obtain- ned in the case of the homogenous magnetization.
The first qualitative study has been given by Pilscikov [25] and Frait [26]. Moreover Frait has
now
shown [27] how to treat the problem quanti- tatively in the case when we are able to calculate
the internal magnetic field in the ferromagnetic body. It is tben possible to calculate the permea-
bility as
afunction of the coordinates. The mean
value of some function of u, say f(u) >, e,g, of
the components of the complex permeability, may
be then obtained from
where ha(x, y, z) is the intensity of the high fre-
quency magnetic field and the integration is
extended over the whole volume of the specimen.
Calculating f({J..) > in dependence on the inten- sity of the static external field, one obtains the
resonance curves, which can be compared with experiment.
FIG. 4.
-Résonance
curvefor the absorption in plane parallel rectangular FeNi plate (78 % Ni).
theoretical curve,-.-.-... experi-
mental
curve.fi- external magnetic field, frequency
9 000 MHz.
In fig. 4
acomparison is made of the theoretical
curve with the experimental one obtained from the
measurement on
aFe-Ni alloy with 78 % Ni for a specimen in the form of a plane parallel rectangular plate. The agreement is quite satisfactory.
4. Thin films.
-8. As shown by Màlek and Kambersky [28] an explanation may be given for
the domain structure found recently by Williams
et al. [29] on thin films of MnBi. An explanation
may also be given, based
onKittel’arefined theory ([30], § 3,lb). The différence lies in the f act, that in
Màlek’s and Kambersky’s Itreatment the magnetics
interaction of both surfaces is incittded. They
obtained the density of the demagnetizing energy per square centimeter
where T is the thickness of the film and D is thé
domain size. The surface density y of thé Blocli
wall has been estimated at 15 erg cm-2. The energy of the Bloch walls is therefore
From the minimum condition for the sum of both
énergies they obtained the dependence of tbe size
FIG. 5.
-Dependence of the domain size
on
the thickness in MnBi films.
of the domains on the thickness T of the thin film (see fig. 5). ForT--10-5emitisD2-3.10-5em.
For T 10-g cm the domain structure practically disappears. For T > 10- 5
cmD increases
asTl/2
similarly to the theory of Kittel. Williams et al.
have found D ~ 3-6.10-5
cmfor T ss 10- 5 cm.
It has been shown that neither
amore precise
calculation of the Bloch wall energy, nor
achange
in the form of domain patterns (e.q. chess-board
pattern) essentially change the results. As
acon-
sequence of the great anisotropy there is
nopossi- bility for domains magnetized parallel to the sur-
face.
At the end it follows that for thin films of MnBi used
asthe storage elements, their resolution
power is limited to 109 informations/cm2.
5. Magnetostatics. - 9. In 1950 Janus et al. [31]
have discovered the hysteresis of the ballistic demagnetizing factor NB (see Fig. 6). Hajko and
Daniel-Szabô [32] have found
asimple expla-
nation : The infiniteness of NB is inferred from the fact that in the centre of
arod where M == 0 we
fin d that there is
ademagnetizing field Hdem 0
which is formally expressed
asHdem
= -NB M.
Thus the origin of the demagnetizing field must be
in the other parts of the specimen. Hence the
traditional suppositions usually made about the magnetization in rods must be abandoned and
replaced by some new one which respects the real
situation. These conclusions have been confirmed
experimentally by Hajko and Daniel-Szabô as
shown in fig. 7. There the ratio of the magne- tization at the place studied to the absolute value
of the simultaneous one in the centre of the rod is plotted against the distance from the centre.
The sequence of the curves from 1 to 6 corresponds
Fie. 6.
-Ilysteresis of tbe ballistic deinagnetization factor (measured by V. Ilajko and J. Daniel-Szabô).
FIG. 7.
-Dependence of thé rémanent magne fixation li
rods
onthe distance froin the centre of thé rod measured
on
the descendent part of thé hysteresis loop.
to the motion along the decreasing part of the hysteresis loop from the upper top to the lower one.
10. Hajko [33] has proved that for uniformly
magnetized rectangular rods the ballistic dema-
gnetizing factor is formally the same
asin the case
419 of the ellipsoidal and cylindrical specimens when
the parameter p is defined after Schneider [34J
aswhere 1 is the length of the rod and a, b its trans-
versal dimensions. It may be easily shown that Hajko’s arguments may be generalized for rods
with any cross section which have a centre of sym-
metry. Then A’B
=Q where Q is the angle in
which both basic planes perpendicular to the axis
of the rod, are seen from the centre. For long rods
we have again approximately.
if we de fine
where Fis the surface of the cross-section.
6. On the demagnetization of ferromagnetic
materials by alternating magnetic field. -11. Star- ceva and Shur [35] observed that in some cases thé
application of a decreasing alternating magnetic
field results in
anincrease of the remanent magne- tization and may be accompanied by the change of
its sign. Hajko and Daniel-Szab6 investigated
this effect
ontoroidal specimens made from magne-
tically soft metallic and ferritic materials. The initial magnetic state has been obtained in the way
seen in fig. 8. The results of their experiments
Fie. 8.
--To the préparation of the initiai magne tic states.
(fig. 9), show thé variation of the i-eiiiaiienu
magnetization Jr after
anapplication of an alter- nating magnetic field with
amaximum ampli-
tude Il.. In their experiments the amplitude
decreased continuously to zero. Similarly to [35]
all these results may again be qualitatively explained by the Kondorsky’s hypothesis of
domains in the crystal with different critical fields.
Similar curves have been found by Hajko and
Daniel-Szabô for the dependence of the apparent
remanent induction in ferromagnetic rods and ellipsoids.
.Fie. 9.
-Dependence of the remanent magnetization Jr
on
the maximum amplitude of the alternating magnetic
field.
7. Acknowledgements.
-The author would like
to express his hearty tbanks to his friends and colleagues Dr. S. Krupicka, Dr. J. Sternberk,
K. Zâvéta, Dipl. phys., Z. Frait, CSc., Z. 8/làlek, CSc.
V. Kambersky, Dipl. phys., Doc. Dr. V. Hajko
and Doc. J. Daniel-Szabô for the aid in preparation
of this report.
REFERENCES
[1] KRUPI010CKA (S.), VILÍM (F.), Czechosl. J. Phys., 1957, 7, 723.
[2] FINE (M. E.), CHION (C.), Phys. Rev., 1957, 105, 121.
[3] GIBBONS (D. F.), J. Appl. Physics, 1957, 28, 810.
[4] ZÁV011ATA (K.), Czechosl. J. Phys., in print.
[5] KRUPI010CKA (S.), Czechosl. J. Phys., 1956, 6, 458.
[6] KRUPI010CKA (S.), Czechosl. J. Phys., 1957, 7, 344.
[7] CLOGSTON (A. M.), SUHL (H.), WALKER (L. R.),
ANDERSON (P. W.), J. Phys. Chem. Solids, 1956, 1,
129.
[8] STERNBERK (J.), Czechosl. J. Phys., 1957, 7, 372.
[9] STERNBERK (J.), Dissertation. Czechosl. Acad. Sc., Prague, 1958 (in Czech.)
[10] WEISS (P.), PICCARD (A.), C. R. Acad. Sc., Paris, 1918, 166, 352.
[11] WEISS (P.), FORRER (R.), Ann. Physique, 1926, 5, 153.
[12] POTTER (H. H.), Proc. Roy. Soc., 1934, 146, 362.
[13] CLARK (C. A.), SUCKSMITH (W.), Proc. Roy. Soc., 1954,
A 225, 147.
[14] ZÁV011ATA (K.), To be published in Czechosl. J. Phys.
[15] NÉEL (L.), Ann. Physique, 1932, 17, 61 ; 1936, 5, 232.
[16] NÉEL (L.), Ann. Physique, 1948, 3, 137.
[17] VALENTA (L.), Czechosl. J. Phys., to be published.
[18] VAN VLECK (J. H.), The Theory of Electric and
Magnetic Susceptibilities, Oxford, 1932.
420
[19] VLASOV (K. B.), ISHMUKHAMETOV (B. Kh.), J. Exp.
Theor. Phys., U. S. S. R., 1954, 27, 75.
[20] VALENTA (L.), IAN USSR, 1957, 21, 879 ; Czechosl.
J. Phys., 1957, 7,127 ; 1957, 7,136.
[21] OGUCHI (T.), Progr. Theor. Phys., 1953, 9, 7.
[22] YAFET (Y.), KITTEL (Ch.), Phys. Rev., 1952, 87, 290.
[23] VAN VLECK (J. H.), J. Chem. Phys., 1941, 9, 85.
[24] STONER (E. C.), Proc. Leeds Phil. Soc., 1930, 2, 56.
[25] PILS010CIKOV (A. I.), IAN USSR, 1956, 20, 1286.
[26] FRAIT (Z.), Report
onthe Czechoslovak-Polish Confe-
rence on
